MODIFICATION BULLETIN NO. 1 PAGE 1 OF 2
ISSUED ON: February 29, ’96
Model Mini Sorter for NC11 / NC-X / Kite / SP40 / SP50 / A7 / N440 / F11 Volt/Hz
Modified Article Solid State Relay - 240V / 3A
Reason for
Vender change
Modification
Due to vender change, the solid relay has been changed.
Inter-
Old P/N New P/N Description Q’ty Used
12081024 12081258 Solid State Relay - 240V / 3A n → n O/O 105 5
change-
ability
Parts Catalog
Index No. Page
Date of
Modification
Serial Number
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 1 PAGE 2 OF 2
ISSUED ON: February 29, ’96
MODEL NAME V/Hz DESTINATION
SAVIN
20 Bin Sorter 3
NRG SRC240 115/60 S. AMERICA, etc. A423-16 A423-36
RICOH CS2090 115/60 USA, CANADA A423-17 A423-06
NRG SRC240 220/50 EUROPE, etc. A423-25 A423-45
INFOTEC SORTER
7125
RICOH CS2090 220, 240/50 EUROPE, etc. A423-27 A423-47
115/60 USA, CANADA A423-15 A423-08
220/50 EUROPE A423-26 A423-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 3 Page 1 of 2 ISSUED ON: July 31, ’91
Model Sorter for F11/NC11 (European Version Only) Volt/Hz
Modified Article Bin Motor - 220V/240V
Reason for
Due to parts standardization with 115V version
Modification
Due to parts standardization with 115V version, the bin motor has been changed. The interchangeability is O/O.
Old P/N Old Description New P/N New Description Page Index
68035420 Bin Motor - 220V/240V 68035400 Bin Motor - AC14/17W 3 30
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 3 Page 2 of 2 ISSUED ON: July 31, ’91
MODEL NAME V/Hz DESTINATION
NRG SRC240 115/60 S. AMERICA, etc. A423-16 A423-36
RICOH CS2090 115/60 USA, CANADA A423-17 A423-06
NRG SRC240 220/50 EUROPE, etc. A423-25 A423-45
INFOTEC SORTER
7125
RICOH CS2090 220, 240/50 EUROPE, etc. A423-27 A423-47
220/50 EUROPE A423-26 A423-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
Reissued on : November 15, ’91
MODIFICATION BULLETIN NO. 4 Page 1 of 3 ISSUED ON: September 30, ’91
Model Sorter for F11/NC11 Volt/Hz
Modified Article Guide stopper plate
Reason for
Prevention of the upper guide plate dislodgment
Modification
Draw
No.
Old Parts
No.
New Parts
No.
A4142311 Spring Plate - Guide Stopper 0 → 2 * 72 3
Description
Date of
Modification
A.B.C.
Rank Part No. Description Index No. Page
Q’ty Used
Old New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
* New Index
Serial Number
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
DETAILS OF MODIFICATION
The upper guide plate may be dislodged from the guide if handled roughly when removing
jammed paper from the sorter. To hold the upper guide plate, two guide stopper spring
plates (front and rear) have been added.
Upper guide plate
MODIFICATION BULLETIN NO. 4 Page 2 of 3 ISSUED ON: September 30, ’91
Reissued on : November 15, ’91
Guide
Guide stopper spring
plate
T. Ito, Manager
Copier Technical Support
Reissued on : November 15, ’91
MODIFICATION BULLETIN NO. 4 Page 3 of 3 ISSUED ON: September 30, ’91
MODEL NAME V/Hz DESTINATION
NRG SRC240 115/60 S. AMERICA, etc. A423-16 Service Parts Only A423-36
RICOH CS2090 115/60 USA, CANADA A423-17 Service Parts Only A423-06
NRG SRC240 220/50 EUROPE, etc. A423-25 Service Parts Only A423-45
INFOTEC SORTER
7125
RICOH CS2090 220, 240/50 EUROPE, etc. A423-27 Service Parts Only A423-47
220/50 EUROPE A423-26 Service Parts Only A423-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 5 PAGE 1 OF 2
ISSUED ON: February 15, ’94
Model Sorter for F11/NC11/NCX/Kite Volt/Hz
Modified Article Parts Catalog
Reason for
Parts catalog correction
Modification
Please add the following part to your parts catalog.
New P/N Description Q’ty Used
A4231127 Bin Guide
*74
0 → 2
Date of
Modification
Parts Catalog
Index No. Page
* 74 3
* New Index No.
Serial Number
*74
S. Hamano, Assistant General Manager
Technical Support Department
MODIFICATION BULLETIN NO. 5 PAGE 2 OF 2
ISSUED ON: February 15, ’94
MODEL NAME V/Hz DESTINATION
NRG SRC240 115/60 S. AMERICA, etc. A423-16 Service Parts Only A423-36
RICOH CS2090 115/60 USA, CANADA A423-17 Service Parts Only A423-06
NRG SRC240 220/50 EUROPE, etc. A423-25 Service Parts Only A423-45
INFOTEC SORTER
7125
RICOH CS2090 220, 240/50 EUROPE, etc. A423-27 Service Parts Only A423-47
220/50 EUROPE A423-26 Service Parts Only A423-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 6 PAGE 1 OF 2
Reissued on:March 15, ’96
ISSUED ON: February 29, ’96
Model Mini Sorter for NC11 / NC-X / Kite / SP40 / SP50 / A7 / N440 / F11 Volt/Hz
Modified Article
Reason for
Modification
Solid State Relay - 240V / 3A
Vender change
Due to a vender change, th e solid re lay has b een changed.
Inter-
Old P/N New P/N Description Q’ty Used
12081024 12081258 Solid State Relay - 240V / 3A
n → n
change-
ability
O/O 105 5
Date of
Modification
Parts Catalog
Index No. Page
Serial Number
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 6 PAGE 2 OF 2
Reissued on:March 15, ’96
ISSUED ON: February 29, ’96
MODEL NAME V/Hz DESTINATION
SAVIN
20 Bin Sorter 3
NRG SRC240 115/60 S. AMERICA, etc. A423-16 A423-36
RICOH CS2090 115/60 USA, CANADA A423-17 A423-06
NRG SRC240 220/50 EUROPE, etc. A423-25 A423-45
INFOTEC SORTER
7125
RICOH CS2090 220, 240/50 EUROPE, etc. A423-27 A423-47
115/60 USA, CANADA A423-15 A423-08
220/50 EUROPE A423-26 A423-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
