MODIFICATION BULLETIN NO. 14 Page 1 of 2ISSUED ON: Nov. 30, ’90
ModelF90 Duplex UnitVolt/Hz
Modified ArticleEntrance Relay Roller
Reason for
To improve reliability and durability of entrance relay roller
Modification
Date of
Modification
Under high humidity and high temperature conditions, individual rollers on the entrance relay roller assembly sometimes
slip off the shaft. To improve the reliability and durability of the entrance relay roller, the mat erial of the rollers has been
changed from ester rubber to ether rubber. The interchangeability is X/O.
PageIndexOld P/NNew P/NDescription
3759192078AF023005Entrance Relay Roller
Serial Number
M. Konno, Manager
Reprographic Q. A. Section
Page 2
MODIFICATION BULLETIN NO. 14 Page 2 of 2ISSUED ON: Nov. 30, ’90
MODEL NAME
P.B. D650115/60USA, CANADAA416-11Service Parts Only
SAVIN 7400 DUPLEX
UNIT
NASHUA DU - 140115/60S. AMERICA, etc.A416-16024011XXXX
RICOH AD400115/60USA, CANADAA416-173401014088
NASHUA DU - 140220,240/50EUROPE, etc.A416-25024011XXXX
INFOTEC DUPLEX II 40220,240/50EUROPEA416-26357110XXXX
RICOH AD400220,240/50EUROPEA416-273401014093
V/HzDESTINATIONCODESERIAL NUMBER
115/60USA, CANADAA416-15
Page 3
MODIFICATION BULLETIN NO. 15 PAGE 1 OF 2
ISSUED ON: April 30, ’94
ModelF90 Duplex UnitVolt/Hz
Modified ArticleLED Sensor Type - T
Reason for
Parts standardization
Modification
Date of
Modification
Serial Number
Due to parts standardization with the other products, the follo wing parts have been changed. The interchangeability is O/O.
Old P/NNew P/NDescriptionQ’ty Used
52055251LED Sensor Type - T
AW020041Photointerruptor
3 → 0
0 → 3
Index No.Page
Parts Catalog
433
433
S. Hamano, Assistant General Manager
Technical Support Department
Page 4
MODIFICATION BULLETIN NO. 15 PAGE 2 OF 2
ISSUED ON: April 30, ’94
MODEL NAME
P.B. D650115/60USA, CANADAA416-11Service Parts Only
SAVIN 7400 DUPLEX
UNIT
NASHUA DU – 140115/60S. AMERICA etc.A416-16
RICOH AD400115/60USA, CANADAA416-17
NASHUA DU - 140220/50EUROPEA416-25
INOFTEC DUPLEX II 40220/50EUROPEA416-26
RICOH AD400220/50EUROPEA416-27
V/HzDESTINATIONCODESERIAL NUMBER
115/60USA, CANADAA416-15
Page 5
MODIFICATION BULLETIN NO. 16 PAGE 1 OF 2
ISSUED ON: September 30, ’94
ModelF90 Duplex UnitVolt/Hz
Modified ArticleCushion - Motor
Reason for
To standardize with other models
Modification
To standardize with other models, the part number of the following part has been modified.
Inter-
Old P/NNew P/NDescriptionQ’ty Used
AA161014AA161104Cushion - Motor
3 → 3
change-
ability
O/O415
Date of
Modification
Parts Catalog
Index No.Page
Serial Number
S. Hamano, Assistant General Manager
Technical Support Department
Page 6
MODIFICATION BULLETIN NO. 16 PAGE 2 OF 2
ISSUED ON: September 30, ’94
MODEL NAME
P.B. D650115/60USA, CANADAA416-11
SAVIN 7400 DUPLEX
UNIT
NASHUA DU – 140115/60S. AMERICA etc.A416-16
RICOH AD400115/60USA, CANADAA416-17
NASHUA DU - 140220/50EUROPEA416-25
INOFTEC DUPLEX II 40220/50EUROPEA416-26
RICOH AD400220/50EUROPEA416-27
V/HzDESTINATIONCODESERIAL NUMBER
115/60USA, CANADAA416-15
