Page 1
®
RICOH GROUP COMPANIES
A166/A187/A189
PARTS CATALOG
PN: RCPC2003
Page 2
Page 3
®
®
®
A166/A187/A189
PARTS CATALOG
RICOH GROUP COMPANIES
Page 4
Page 5
A166/A187/A189
PARTS CATALOG
PN: RCPC2003
Page 6
Page 7
It is the reader's responsibility when discussing the information contained within this
document to maintain a level of confidentiality that is in the best interest of Ricoh
Corporation and its member companies.
NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY
FASHION AND DISTRIBUTED WITHOUT THE PRIOR
PERMISSION OF RICOH CORPORATION.
All product names, domain names or product illustrations, including desktop images,
used in this document are trademarks, registered trademarks or the property of their
respective companies.
They are used throughout this book in an informational or editorial fashion only and for
the benefit of such companies. No such use, or the use of any trade name, or web
site is intended to convey endorsement or other affiliation with Ricoh products.
2000 RICOH Corporation. All rights reserved.
Page 8
Page 9
LEGEND
PRODUCT CODE COMPANY
GESTETNER RICOH SAVIN
A166 2703 AFICIO 2003 SDC1 03
A187 2703D AFICIO 2103 SDC1 03A
A189 2703DE AFICIO 22 03 SDC 1 03 E
A548 Auto Reverse Document Feeder (DF61)
A550/A549 Paper Tray Unit (PS280/PS290)
A555 Sorter Stapler (ST10)
A718 Film Projector Unit (SPU3)
A579 Holder (Type B)
DOCUMENTATION HISTORY
REV. NO. DATE COMMENT
* 10/96 Original Printing
Page 10
Page 11
A166/A187/A189 PARTS CATALOG
A166 PARTS LOCATION AND LIST
TABLE OF CONTENTS
LOCATION OF UNIT............................................ 4
1. EXTERIOR (A166).......................................... 10
2. EXTERIOR 2 (A166)....................................... 12
3. PLATEN COVER (A166)................................. 14
4. OPTICS SECTION 1 (A166)........................... 16
5. OPTICS SECTION 2 (A166)........................... 18
6. OPTICS SECTION 3 (A166)........................... 20
7. OPTICS SECTION 4 (A166)........................... 22
8. LD UNIT (A166)............................................... 24
9. BY-PASS FEED SECTION (A166)................. 26
10. PAPER FEED SECTION 1 (A166).................. 28
11. PAPER FEED SECTION 2 (A166).................. 30
12. PAPER REGISTRATION (A166).................... 32
13. PAPER TRAY SECTION (A166)..................... 34
14. TONER HOPPER (A166)................................ 36
15. DEVELOPMENT UNIT (A166)........................ 38
16. TRANSFER BELT UNIT 1 (A166)................... 40
17. TRANSFER BELT UNIT 2 (A166)................... 42
18. DRUM SECTION (A166)................................. 44
19. DRUM CLEANING (A166).............................. 46
20. TRANSFER BELT CLEANING (A166) ........... 48
21. TRANSPORT UNIT (A166)............................. 50
22. FUSING UNIT 1 (A166) .................................. 52
23. FUSING UNIT 2 (A166) .................................. 54
24. FUSING UNIT 3 (A166) .................................. 56
25. PAPER EXIT SECTION (A166)...................... 58
26. SWEEPER (A166)........................................... 60
27. DRIVE SECTION 1 (A166) ............................. 62
28. DRIVE SECTION 2 (A166) ............................. 64
29. ELECTRICAL SECTION 1 (A166).................. 66
30. ELECTRICAL SECTION 2 (A166).................. 68
31. ELECTRICAL SECTION 3 (A166).................. 70
32. ELECTRICAL SECTION 4 (A166).................. 72
33. FRAME SECTION 1 (A166)............................ 74
34. FRAME SECTION 2 (A166)............................ 76
35. FRAME SECTION 3 (A166)............................ 78
36. SCANNER MOTOR CONTROL
BOARD (A166)................................................ 80
37. SYSTEM CONTROL BOARD (A166)............. 82
38. IPU BOARD (A166)......................................... 86
39. PRINTER MAIN BOARD (A166)..................... 92
40. MEMORY BOARD (A166) .............................. 96
i
Page 12
41.I/O CONTROL BOARD 1 (A166)..................... 98
14. TONER HOPPER (A187/189)........................ 36
42.I/O CONTROL BOARD 2 (A166).....................100
43. DECAL AND DOCUMENT (A166)..................102
44. SPECIAL TOOLS (A166)................................106
A166 PARTS INDEX
PARTS INDEX...................................................... 2
A187/A189 PARTS LOCATION AND LIST
LOCATION OF UNIT........................................... 3
1. EXTERIOR (A187/189)................................... 10
2. EXTERIOR 2 (A187/189)................................ 12
3. PLATEN COVER (A187/189) ......................... 14
4. OPERATION PANEL (A189) .......................... 16
5. OPTICS SECTION 1 (A187/189).................... 18
6. OPTICS SECTION 2 (A187/189).................... 20
7. OPTICS SECTION 3 (A187/189).................... 22
8. OPTICS SECTION 4 (A187/189).................... 24
9. LD UNIT (A187/189) ....................................... 26
15. DEVELOPMENT UNIT (A187/189)................ 38
16. TRANSFER BELT UNIT 1 (A187/189)........... 40
17. TRANSFER BELT UNIT 2 (A187/189)........... 42
18. DRUM SECTION (A187/189)......................... 44
19. DRUM CLEANING (A187/189) ...................... 46
20. TRANSFER BELT CLEANING (A187/189).... 48
21. TRANSPORT UNIT (A187/189)..................... 50
22. FUSING UNIT 1 (A187/189)........................... 52
23. FUSING UNIT 2 (A187/189)........................... 54
24. FUSING UNIT 3 (A187/189)........................... 56
25. PAPER EXIT SECTION (A187/189) .............. 58
26. DUPLEX UNIT 1 (A187/189).......................... 60
27. DUPLEX UNIT 2 (A187/189).......................... 62
28. DUPLEX UNIT 3 (A187/189).......................... 64
29. SWEEPER (A187/189)................................... 66
30. DRIVE SECTION 1 (A187/189)...................... 68
31. DRIVE SECTION 2 (A187/189)...................... 70
10. BY-PASS FEED SECTION (A187/189).......... 28
11. PAPER FEED SECTION 1 (A187/189) .......... 30
12. PAPER FEED SECTION 2 (A187/189) .......... 32
13. PAPER REGISTRATION (A187/189)............. 34
32. ELECTRICAL SECTION 1 (A187/189) .......... 72
33. ELECTRICAL SECTION 2 (A187/189) .......... 74
34. ELECTRICAL SECTION 3 (A187/189) .......... 76
35. ELECTRICAL SECTION 4 (A187/189) .......... 78
ii
Page 13
36. FRAME SECTION 1 (A187/189)..................... 80
3. PAPER FEED SECTION 2 (A548).................. 6
37. FRAME SECTION 2 (A187/189)..................... 82
38. FRAME SECTION 3 (A187/189)..................... 84
39. SCANNER MOTOR CONTROL
BOARD (A187/189)......................................... 86
40. SYSTEM CONTROL BOARD (A187)............. 88
41. SYSTEM CONTROL BOARD (A189)............. 92
42. IPU BOARD (A187)......................................... 96
43. IPU BOARD (A189).........................................102
44. PRINTER MAIN BOARD (A187/189)..............108
45. MEMORY BOARD (A187/189) .......................112
46. I/O CONTROL BOARD 1 (A187/189).............114
47. I/O CONTROL BOARD 2 (A187/189).............116
48. IPU SUB BOARD (A189)................................118
49. DECAL AND DOCUMENT (A187/189)...........120
50. SPECIAL TOOLS (A187/189).........................122
A187/A189 PARTS INDEX
PARTS INDEX...................................................... 2
4. TRANSFER BELT UNIT (A548)...................... 8
5. PAPER EXIT SECTION (A548) ...................... 10
6. DRIVE SECTION (A548)................................. 12
7. DECAL AND DOCUMENT (A548).................. 14
AUTO REVERSE DOCUMENT FEEDER A548 PARTS
INDEX
PARTS INDEX ..................................................... 2
PAPER TRAY UNIT A550/A549 PARTS LOCATION
AND LIST
1. EXTERIOR (A549/A550)................................. 2
2. PAPER FEED SECTION (A549/A550) ........... 4
3. ELECTRICAL SECTION (A549/A550)............ 6
4. DRIVE SECTION (A549/A550)....................... 8
5. PAPER TRAY UNIT (A549/A550)................... 10
6. DECAL AND DOCUMENT (A549/A550)......... 12
PAPER TRAY UNIT A550/A549 PARTS INDEX
AUTO REVERSE DOCUMENT FEEDER A548 PARTS
LOCATION AND LIST
1. EXTERIOR (A548)........................................... 2
2. PAPER FEED SECTION 1 (A548) .................. 4
PARTS INDEX ..................................................... 2
SORTER STAPLER A555 PARTS LOCATION AND LIST
1. EXTERIOR (A555) .......................................... 2
2. STAPLE UNIT (A555)...................................... 4
iii
Page 14
3. TRAY DRIVE SECTION (A555) ...................... 6
4. COPY TRAY SECTION (A555)....................... 8
5. ELECTRICAL SECTION (A555)...................... 10
6. JOINT UNIT (A555)......................................... 12
7. DECAL AND DOCUMENT (A555) .................. 14
SORTER STAPLER A555 PARTS INDEX
PARTS INDEX...................................................... 2
FILM PROJECTOR UNIT A718 PARTS LOCATION
AND LIST
1. EXTERIOR (A718)........................................... 2
2. LENS UNIT (A718).......................................... 4
3. ELECTRICAL SECTION (A718)...................... 6
4. MIRROR UNIT (A718)..................................... 8
5. ACCESSORIES (A718)................................... 10
FILM PROJECTOR UNIT A718 PARTS INDEX
Parts Index .......................................................... 2
HOLDER TYPE B A579 PARTS LOCATION AND LIST
1.Holder Type B (A579)....................................... 2
HOLDER TYPE B A579 PARTS INDEX
Parts Index .......................................................... 2
iv
Page 15
A166
PARTS LOCATION AND LIST
Page 16
Page 17
This section instructs you as to the numbers and names of the parts of this machine
Page 18
Page 19
LOCATION OF UNIT
1. EXTERIOR (A166)
See Page 10
4. OPTICS SECTION 1 (A166)
2. EXTERIOR 2 (A166)
See Page 12
5. OPTICS SECTION 2 (A166)
3. PLATEN COVER (A166)
See Page 14
6. OPTICS SECTION 3 (A166)
See Page 16
A166 4 Parts Location and List
See Page 18
See Page 20
Page 20
LOCATION OF UNIT
7. OPTICS SECTION 4 (A166)
See Page 22
10. PAPER FEED SECTION 1 (A166)
8. LD UNIT (A166)
See Page 24
11. PAPER FEED SECTION 2 (A166)
9. BY-PASS FEED SECTION (A166)
See Page 26
12. PAPER REGISTRATION (A166)
See Page 28
A166 5 Parts Location and List
See Page 30
See Page 32
Page 21
LOCATION OF UNIT
13. PAPER TRAY SECTION (A166)
See Page 34
16. TRANSFER BELT UNIT 1 (A166)
14. TONER HOPPER (A166)
See Page 36
17. TRANSFER BELT UNIT 2 (A166)
15. DEVELOPMENT UNIT (A1466)
See Page 38
18. DRUM SECTION (A166)
See Page 40
A166 6 Parts Location and List
See Page 42
See Page 44
Page 22
LOCATION OF UNIT
19. DRUM CLEANING (A166)
See Page 46
22. FUSING UNIT 1 (A166)
20. TRANSFER BELT CLEANING (A166)
See Page 48
23. FUSING UNIT 2 (A166)
21. TRANSPORT UNIT (A166)
See Page 50
24. FUSING UNIT 3 (A166)
See Page 52
A166 7 Parts Location and List
See Page 54
See Page 56
Page 23
LOCATION OF UNIT
25. PAPER EXIT SECTION (A166)
See Page 58
28. DRIVE SECTION 2 (A166)
26. SWEEPER (A166)
See Page 60
29. ELECTRICAL SECTION 1 (A166)
27. DRIVE SECTION 1 (A166)
See Page 62
30. ELECTRICAL SECTION 2 (A166)
See Page 64
A166 8 Parts Location and List
See Page 66
See Page 68
Page 24
LOCATION OF UNIT
31. ELECTRICAL SECTION 3 (A166)
See Page 70
34. FRAME SECTION 2 (A166)
32. ELECTRICAL SECTION 4 (A166)
See Page 72
35. FRAME SECTION 3 (A166)
33. FRAME SECTION 1 (A166)
See Page 74
See Page 76
A166 9 Parts Location and List
See Page 78
Page 25
1. EXTERIOR (A166)
Rev. 02/98
A166 10 Parts Location and List
Page 26
1. EXTERIOR (A166)
Rev. 02/98
Index
No.
1 A166 5253 Memory Board 1
2 AW03 0070 Optical Fiber - 75 1000mm 1
3 A166 5645 DC Harness SCU 1
4 A166 5695 SCSI Harness 1
5 A187 5268 SCU Board (115V) 1
5 A187 5258 SCU Board (NRG)(230V) 1
5 A187 5251 SCU Board (RIC/INF)(230V) 1
6 A166 1474 Operation Panel Ass’y (LT) 1
6 A166 1475 Operation Panel Ass’y (A4) 1
7 A166 1525 Key Top Cover 1
8 A166 1382 Left Cover - System Control 1
9 A166 1380 Front Cover - System Control 1
10 A166 1828 Scanner Left Cover 1
11 AA14 3454 Stepped Screw - M3 2
12 A134 1921 Scale - Left - Printing (A4) 1
12 A133 7156 Left Scale (LT) 1
13 A166 1826 Scanner Front Cover 1
14 A134 1924 Exposure Glass 1
15 AA14 3219 Stepped Screw 3
16 A134 1922 Rear Scale (A4) 1
16 A133 7157 Rear Scale (LT) 1
17 A166 1837 Decal - Caution 1
18 A166 1829 Scanner Rear Cover 1
19 A153 1357 Operating Instruction Holder 1
20 A166 1319 Rivet 2
21 A166 1346 Left Cover Cap 1
22 A166 1366 Switch Cover 1
23 A166 1306 Rear Cover Ass’y 1
24 A166 1301 Right Rear Cover 1
25 A166 1827 Scanner Right Cover 1
26 A166 1291 Right Middle Cover 1
27 A166 1381 Right Cover - System Control 1
28 A166 1271 Front Right Cover 1
29 A187 1528 Operation Decal (LT) 1
29 A187 1529 Operation Decal (A4) 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
30 A166 5880 Operation Panel Bracket - SCU 1
31 A166 5874 Bracket - NV SCU 1
32 C225 2866 Decal - Key Top Cover (REX) 1
32 A153 6409 Decal - Keytop Cover (NRG) 1
32 C225 2867 Decal - Cover - Panel (NSA) 1
33 A166 1504 SP Large Decal 1
34 A166 1506 SP Small Decal 1
101 0434 0060B Philips Tapping Screw - M4x6
102 0443 0060B Hexagon Tapping Screw - M3x6
103 0802 5094 Tapping Truss Head Screw - M4x8
104 0452 3008B Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
A166 11 Parts Location and List
Page 27
1. EXTERIOR (OPERATION PANEL) (A166)
A166 11 Parts Location and List
A
Page 28
1. EXTERIOR (OPERATION PANEL) (A166)
Index
No.
*
*
38 A166 1508 Key Top Cover - SP 1
39 A166 1510 Lower Case - Operation Panel 1
40 A166 1530 Key Top - Counter 1
41 A166 1531 Key Top - Start 1
42 A166 1538 Key Top - Color Mode 1
43 A166 1540 Key Top - Color 1C 1
44 A166 1542 Key Top - Paper Select 1
45 A166 1544 Key Top - Auto Density 1
46 A166 1548 Key Top - Clear Mode 1
47 A187 1486 Upper Case - Operation Panel (LT) 1
47 A187 1487 Upper Case - Operation Panel (A4) 1
48 A187 1492 Sheet - Upper Right (LT) 1
48 A187 1493 Sheet - Upper Right (A4) 1
49 A187 1494 Sheet - Upper (LT) 1
49 A187 1495 Sheet - Upper (A4) 1
50 A187 1496 Sheet - Middle (LT) 1
50 A187 1497 Sheet - Middle (A4) 1
51 A187 1498 Sheet - Sorter Operation (LT)(Basic) 1
51 A187 1499 Sheet - Sorter Operation (A4)(Basic) 1
52 A187 1504 Sheet - Behind (LT)(Basic) 1
52 A187 1505 Sheet - Behind (A4)(Basic) 1
53 A187 1546 Key Top - Behind (Basic) 1
54 A166 1515 Operation Panel Board 1
55 A153 1453 Key Top - Interrupt 1
56 A153 1455 Key Top - Program 1
57 A153 1456 Key Top - 10 key 1
58 A153 1457 Key Top - Clear/Stop 1
59 A166 1504 SP Large Decal 1
60 A166 1506 SP Small Decal 1
Part No.
A166 1474 Operation Panel Ass’y (LT) 1
A166 1475 Operation Panel Ass’y (A4) 1
Description
Q’ty Per
Assembly
Index
No.
Part No.
Description
Rev. 08/98
Q’ty Per
Assembly
A166 11 Parts Location and List
B
Page 29
2. EXTERIOR 2 (A166)
A166 12 Parts Location and List
Page 30
2. EXTERIOR 2 (A166)
Index
No.
1 A166 1231 Front Cover (RIC) 1
1 A166 6712 Front Cover (NRG) 1
1 A166 6713 Cover - Front - BF (INF) 1
1 A166 6714 Cover - Front - BF (SVN) 1
2 A166 1378 Decal - Emblem (RIC) 1
2 A153 6423 Support Cover (INF) 1
2 A166 6730 Emblem (SVN) 1
3 A166 1349 Cap - DFUnit 1
4 A166 6118 Transfer Belt Unit Release Knob 1
5 A166 1332 Upper Inner Cover 1
6 A166 3218 Development Unit Handle 1
7 A166 1266 Front Left Cover 1
8 A153 4461 Copy Tray Ass’y 1
9 AF04 3077 Copy Tray Guide 1
10 A166 1346 Left Cover Cap 2
11 A166 1361 Power Cord Cap 1
12 A166 1379 IC Card Cap 1
13 A166 1281 Left Cover 1
14 A166 1326 Inner Cover - Safety Switch 1
15 A166 1341 Transport Inner Cover 1
16 A166 6531 Collection Bottle Band 1
17 A166 6523 Disposed Toner Tank 1
18 AA00 0059 Caution Decal - English 1
19 5442 3664 Toner Collection Bottle Cap - Small 1
20 A007 3785 Toner Collection Bottle Cap 1
21 AW23 0009 Toner End Sensor 1
22 A166 5658 Toner Collection Relay Harness 1
23 A166 1372 Decal - Adding Toner 1
24 A166 1363 Hinge Pin 2
25 A166 1374 Decal - Operation 1
26 A166 1335 Cover - Toner Cartridge Black 1
27 AA00 0195 Decal - High Temperature 1
28 A166 1369 Decal - Toner Cartridge 1
29 A166 3219 Grip Support Plate 1
30 AA00 1373 Decal - Main Switch 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
31 C225 2867 Decal - Cover - Panel (NSA) 1
31 A166 6751 Model Name Plate - GES 1
31 A166 6752 Model Name Plate - NSA 1
31 A166 6753 Model Name Plate - REX 1
31 A166 6754 Model Name Plate - SVN 1
31 A153 6406 Model Name Plate (NRG) 1
32 AF04 3076 Copy Tray Slide 1
33 AF04 3069 Copy Tray 1
34 A166 1386 IC Card Cap 3
35 A166 1376 Color Decal (RIC) 1
101 0802 5094 Tapping Truss Head Screw - M4x8
102 0452 4008B Tapping Bind Screw - M4x8
103 0452 3010B Tapping Bind Screw - M3x10
Part No.
Description
Q’ty Per
Assembly
A166 13 Parts Location and List
Page 31
3. PLATEN COVER (A166)
A166 14 Parts Location and List
Page 32
3. PLATEN COVER (A166)
Rev. 08/98
Index
No.
1 5448 2804 Platen Cover Sheet 1
2 AA16 2053 Platen Cover Pad 1
3 A134 1394 Front Platen Cover 1
4 A053 1957 Flex Hinge - Platen Cover 2
5 A134 1395 Rear Platen Cover 1
6 A134 1396 Original Holder 1
7 A100 1324 Positioning Sensor Shutter 1
8 A100 1310 Platen Cover Hinge Ass’y 1
9 A100 1325 Hinge Spacer 1
10 A153 1380 Platen Cover Bracket 1
11 AA14 8447 Guide Pin - Platen Cover 2
12 A134 1392 Platen Cover Ass’y 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0414 0142W Tapping Screw - M4x14
Part No.
Description
Q’ty Per
Assembly
A166 15 Parts Location and List
Page 33
4. OPTICS SECTION 1 (A166)
A166 16 Parts Location and List
Page 34
4. OPTICS SECTION 1 (A166)
Index
No.
1 A166 5974 Scanner Release Rod 1
2 A166 1910 Rod Holder 2
3 A166 1677 Right Support Cover 1
4 A028 7277 Entrance Gate Cushion 2
5 AA15 0657 Seal 4
6 AA15 0636 Seal - 90x29.5x0.2 1
7 A134 1926 Exposure Glass Stopper 4
8 A166 1812 Left Scale Bracket 1
9 A069 1883 Shoe - Scanner 8
10 A134 1791 Spring Plate - 2nd Mirror 4
11 AB03 2717 Pulley - 26Z 4
12 A166 1742 2nd Mirror Ass’y 2
13 A096 1873 Scanner Shoe Pin 8
14 AA13 2174 Spacer - M8 2
15 A166 1728 1st Scanner Unit 1
16 A1661736 Spring Plate - 1st Mirror 2
17 A166 1737 1st Mirror 1
18 AW02 0022 Photointerruptor 1
19 AX52 0029 Exposure Lamp - 75V 160W 1
20 A166 5135 Exposure Lamp Harness 1
21 A166 1685 Platen Cover Bracket 1
22 AW11 0017 Thermostat - 140°C - AC120V 15A 1
23 A134 5370 Relay Harness - Scanner Lamp 1
24 A134 1726 Wire Stopper Plate 2
25 A134 1933 Right Stopper - Exposure Glass 1
26 A134 1932 Stay - Scanner Upper Right 1
27 A134 1782 2nd Scanner Ass’y 1
28 A134 1773 Rear Terminal 1
29 A134 1771 Front Terminal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0313 0140B Philips Pan Head Screw - M3x14
102 0443 0060B Hexagon Tapping Screw - M3x6
103 0434 0060B Philips Tapping Screw - M4x6
104 0314 0120B Philips Pan Head Screw - M4x12
105 0720 0060E Retaining Ring - M6
Part No.
Description
Rev. 08/98
1.
Q’ty Per
Assembly
A166 17 Parts Location and List
Page 35
5. OPTICS SECTION 2 (A166)
A166 18 Parts Location and List
Page 36
5. OPTICS SECTION 2 (A166)
Index
No.
1 A134 1962 Bracket Home Sensor 1
2 AW02 0072 Photointerruptor 1
3 A166 5100 Front Scanner Harness 1
4 A166 5110 Rear Scanner Harness 1
5 A166 5131 Scanner Scsi Harness 1
6 A187 5090 Scanner IPU Board 1
7 A166 1777 Scanner Motor Control Board 1
8 A166 5126 Scanner AC Harness 1
9 A134 5372 Harness - Scanner Lamp 1
10 AZ23 0051 Lamp Regulator (115V) 1
10 AZ23 0063 Lamp Regulator - 230V 1
11 A166 5120 Scanner DC Harness 1
12 A166 1752 CCD Drive Board 1
13 A166 5080 IDU Board 1
14 AW01 0072 Original Sensor 2
15 A166 1775 Inner Cover IPU 1
16 1607 0672 Ferrite Core 1
17 A166 1778 Motor Control Board Bracket 1
18 A166 5115 Original Sensor Harness 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0314 0120B Philips Pan Head Screw - M4x12
102 0443 0060B Hexagon Tapping Screw - M3x6
103 0951 4010B Philips Screw With Washer - M4x10
104 0434 0060B Philips Tapping Screw - M4x6
Part No.
Description
Q’ty Per
Assembly
A166 19 Parts Location and List
Page 37
6. OPTICS SECTION 3 (A166)
A166 20 Parts Location and List
Page 38
6. OPTICS SECTION 3 (A166)
Index
No.
1 A166 1791 Board Bracket 1
2 AX64 0066 Fan Motor - DC24V 0.04A 1
3 AW01 0030 Original Sensor 1
4 AX40 0063 Anticondensation Heater - 120V9W 1
5 A166 1802 Fan Casing 2
6 AX64 0067 Fan Motor - DC24V 0.13A 2
7 AA04 3460 Timing Belt - S2M 290 1
8 AA06 0221 Gripper Solenoid Spring 1
9 A166 1715 Motor Bracket 1
10 A134 1724 Cushion - Stepper Motor 1
11 AB03 0459 Timing Pulley -22z 1
12 AX06 0124 Motor - DC24V 53W 1
13 A134 1728 Fly Wheel 1
14 A069 5352 Ground Wire - Scanner 1
15 A166 5120 Scanner DC Harness 1
16 AW02 0084 Photointerruptor 1
17 A166 1796 Connector Bracket 1
18 AW03 0039 Optical Fiber - 75 700mm 1
19 A166 1786 Fan Motor Bracket 1
20 AX64 0065 Fan Motor - DC24V 0.8A 1
21 AW03 0032 Optical Fiber 1
22 A166 1672 BRU Board Bracket 1
23 A166 1678 Scanner Clamp Bracket 1
24 A166 1671 IPU Board Bracket 1
25 A166 1699 Scanner Rail Stay 1
26 A166 1667 Spring Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0314 0250B Philips Pan Head Screw - M4x25
102 0450 4035B Philips Tapping Screw - M4x35
103 1105 0291 Wire Saddle
104 1102 4052 Optional Connector
105 1102 5981 Fiber Connector
106 0434 0060B Philips Tapping Screw - M4x6
107 0951 4006B Philips Screw With Washer - M4x6
108 0451 4008B Philips Tapping Screw - M4x8
109 0801 0149 Philips Pan Head Screw - M4x6
110 0575 0050E Hexagon Headless Set Screw - M5x5
111 0314 0100B Philips Pan Head Screw - M4x10
112 0443 0060B Hexagon Tapping Screw - M3x6
113 1105 0246 Spacer
114 0353 0080B Screw - M3X8
Part No.
Description
Q’ty Per
Assembly
A166 21 Parts Location and List
Page 39
7. OPTICS SECTION 4 (A166)
A166 22 Parts Location and List
Page 40
7. OPTICS SECTION 4 (A166)
Index
No.
1 A166 1697 Right Scanner Guide 1
2 A166 1696 Left Scanner Guide 1
3 A166 1694 Front Frame 1
4 AB03 2718 Drive Pulley 2
5 AA05 0085 Scanner Wire 2
6 AA06 0221 Gripper Solenoid Spring 2
7 A134 1677 Front Tension Bracket 1
8 A166 1657 Scanner Frame 1
9 A166 1664 Left Grip 1
10 AA15 3022 Seal 1
11 A166 1674 Dust Filter 80 1
12 AA15 0661 Seal 2
13 A166 1902 Scanner Left Hinge 1
14 A166 1683 Lens Holder 2
15 A134 1698 Idle Pulley 2
16 A166 1773 Flat Cable Guide 1
17 AA14 0547 Drive Shaft 1
18 AA15 0656 SCSI Entrance Seal 1
19 A134 1678 Rear Tension Bracket 1
20 A134 1680 Guide - Flexible Harness 1
21 A166 1689 Rear Frame 1
22 A134 1722 Bracket - Drive Shaft 1
23 AB00 0021 Timing Pulley - 63Z 1
24 A166 1905 Scanner Right Hinge 1
25 A166 1669 Right Grip 1
26 AB03 2717 Pulley - 26Z 2
27 AA15 0662 Seal 2
28 AA15 0663 Seal 5
29 AA05 1026 Scanner Stopper Wire 1
30 A166 1698 Pulley Cover 1
31 AA15 0660 Seal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0805 3368 Ball Bearing - 8 X 16 X 5mm
102 1105 0328 Harness Clamp - ES-0505
103 0720 0060B Retaining Ring - M6
104 0414 0080B Binding Self-tapping Screw - M4x8
105 0434 0060B Philips Tapping Screw - M4x6
106 0451 4008B Philips Tapping Screw - M4x8
107 0951 4006B Philips Screw With Washer - M4x6
108 0575 0050E Hexagon Headless Set Screw - M5x5
109 1105 0199 Clamp
110 0434 0102B Tapping Screw - M4x8
Part No.
Description
Index
Rev. 09/98
Q’ty Per
Assembly
A166 23 Parts Location and List
Page 41
8. LD UNIT (A166)
A166 24 Parts Location and List
Page 42
8. LD UNIT (A166)
Index
No.
*A187 2052 LD Unit (115V) 1
*A187 2051 LD Unit (230V) 1
1 A134 5190 LSD Board 2
2 A187 2092 LD Unit 1
3 A166 5390 Polygon Motor 1
4 A166 2081 Mirror Ass’y 1
5 A166 2078 Lens - Blt 1
6 A166 2076 Front Lens Holder 1
7 A166 2077 Rear Lens Holder 1
8 A166 2083 Front Mirror Holder 1
9 A166 2084 Rear Mirror Holder 1
10 AA15 2360 Seal 1
11 A166 2062 Shielding Glass 1
12 A166 2066 Shielding Glass Guide 1
13 AC02 0074 Cylindrical Lens 1
14 A100 2056 Plate - Cylindrical Lens 1
15 A166 5655 Polygon Harness 1
16 A187 5653 Synchronizing Harness 1
17 A187 5654 LD Control Harness 1
18 A166 2106 LD Unit Cover 1
19 AA00 0600 Decal - LD 1
20 AA00 0602 Decal LD Cover 1
21 A166 2112 Left Harness Bracket 1
22 A166 2114 Front Harness Bracket 1
23 A166 2116 Right Harness Bracket 1
24 A166 2055 Optical Housing 1
25 A187 5701 Grounding Wire - 55 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0353 0060W Philips Pan Head Screw - M3x6
102 0414 0080B Binding Self-tapping Screw - M4x8
103 1105 0234 Clamp
Part No.
Description
Q’ty Per
Assembly
A166 25 Parts Location and List
Page 43
9. BY-PASS FEED SECTION (A166)
A166 26 Parts Location and List
Page 44
9. BY-PASS FEED SECTION (A166)
Rev. 02/98
Index
No.
1 A166 2696 Vertical Transport Cover 1
2 A134 2692 By-pass Feed Table Ass’y 1
3 A166 2682 Vertical Transport Guide 1
4 A134 2587 Switch Bracket 1
5 A166 5652 Vertical Transfer Harness 1
6 AW02 0069 Photointerruptor 1
7 AF02 2079 Vertical Driven Roller 3
8 A166 2690 Spring Plate 9
9 AA15 1998 Cushion - 10x30x5 1
10 5215 2621 Snap Ring - M6 1
11 A134 2746 By-pass Feed Cover 1
12 A134 2707 Front Fence Rack 1
13 5447 2927 Friction Pad - B 1
14 A134 2741 By-pass Feed Entrance Guide 1
15 A134 2721 Front Paper Guide 1
16 A134 2711 Front Side Fence 1
17 A134 2726 Rear Paper Guide 1
18 A134 2716 Rear Side Fence 1
19 A134 2701 By-pass Feed Guide 1
20 A134 2697 By-pass Feed Table 1
21 A134 2705 Magnet Catch Plate 1
22 A134 5282 Paper Size Sensor Board 1
23 A134 2706 Rear Fence Rack 1
24 G011 3305 Gear - 16T 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1204 2356 Micro Switch - AM51612A531
102 0313 0140B Philips Pan Head Screw - M3x14
103 0452 4010B Tapping Bind Screw - M4x10
104 0414 0082F Philips Truss Head Screw - M4x8
105 0965 3006B Tapping Screw With Flat Washer M3x6
Part No.
Description
Q’ty Per
Assembly
A166 27 Parts Location and List
Page 45
10. PAPER FEED SECTION 1 (A166)
A166 28 Parts Location and List
Page 46
10. PAPER FEED SECTION 1 (A166)
Index
No.
1 A166 2843 Harness Guide 1
2 A166 5651 By-pass Feed Harness 1
3 AW02 0075 Photointerrupter 1
4 A166 2841 Release Bracket 2
5 A166 2803 By-pass Feed Cover 1
6 AA06 0625 Spring 1
7 A166 2839 Pressure Lever 1
8 A166 2831 DC Solenoid - Pressure 1
9 AA06 0624 Spring 1
10 A166 2819 DC Solenoid - Pick-up 1
11 AA06 0622 Spring 1
12 A166 2778 Spring Bracket 1
13 A166 2768 Pick-up Arm 1
14 A166 2766 Paper Feed Support Plate 1
15 AA06 0623 Spring 1
16 A166 2776 Pressure Arm 1
17 AF03 1025 Feed Roller 1
18 AF03 0024 Pick-up Roller 1
19 5447 2681 Snap Ring 3
20 AB01 1343 Idle Gear - 23z 1
21 A134 2661 Feeler Roller 1
22 A166 2847 Paper End Feeler 1
23 A166 2845 Spring Plate 1
24 AW50 0012 Push Switch 1
25 A134 2659 By-pass Feed Housing 1
26 A166 2855 Upper Guide Plate 1
27 A166 2856 Lower Guide Plate 1
28 A166 2853 Middle Guide Plate 1
29 A134 2663 Separation Guide 1
30 AF03 2025 Separation Roller 1
31 A134 2674 Torque Limitter - 400fg 1
32 A134 2668 Separation Driven Shaft 1
33 AA06 3499 Pressure Spring 1
34 AA08 0037 Bushing - 6 mm 1
35 AB01 1344 Gear - 16Z 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
36 AB01 1345 Gear - 20Z 1
37 A166 2783 Separation Shaft 1
38 AB01 1346 Gear - 27Z 1
39 AX20 0101 Magnetic Clutch - 2.5Kgf 35z 1
40 AA08 3010 Clutch Roller - 6x14x10 1
41 AA14 0602 Feed Shaft 1
42 A166 2849 Drive Support Plate 1
43 5053 0447 Bushing - 6mm 3
44 A166 2779 Grounding Plate 1
45 A166 2785 Grounding Plate 1
46 AA10 0010 Snap Ring - Pick Up Sol 1
101 1102 5144 Connector - 2p
102 1102 5195 Connector - 5p
103 0622 0100E Spring Pin - 2x10mm
104 0720 0040B Retaining Ring - M4
105 0802 5237 Binding Self-tapping Screw - M4x10
106 0313 0040B Philips Pan Head Screw - M3x4
107 0414 0080B Binding Self-tapping Screw - M4x8
108 0451 4008B Philips Tapping Screw - M4x8
109 0414 0060B Tapping Screw - M4x6
110 0434 0060B Philips Tapping Screw - M4x6
111 1105 0310 Wire Clamp
Part No.
Description
Q’ty Per
Assembly
A166 29 Parts Location and List
Page 47
11. PAPER FEED SECTION 2 (A166)
A166 30 Parts Location and List
Page 48
11. PAPER FEED SECTION 2 (A166)
Index
No.
1 AA08 0189 Feed Roller Bushing - Front 1
2 A157 2782 Paper Tray Holder 2
3 A157 2794 Lock Arm Stopper 1
4 A157 2804 Shield Plate - Paper End Sensor 1
5 A157 2802 Paper End Sensor F 1
6 A157 2775 Feed Roller Shaft 1
7 A157 2770 Feed Roller 2
8 AF03 1027 Paper Feed Roller 4
9 A048 2863 Release Arm - Paper End 1
10 AA06 6104 Spring 1
11 AW02 0075 Photointerrupter 1
12 A157 2788 Lift Arm 1
13 A157 2781 Tray Positioning Rail 1
14 AA15 0383 Right Rail Sheet 1
15 AA06 0640 Spring 1
16 A157 2785 Right Rail 1
17 AA08 0190 Lift Arm Bushing 1
18 AA06 6249 Spring 1
19 A157 2786 Lift Arm Stopper 1
20 AA14 3445 Stud - M4 1
21 A157 2795 Stopper Bracket 1
22 AA06 3205 Spring 1
23 A157 2773 Feed Roller Holder 1
24 A157 2800 Paper End Sensor Bracket 1
25 A157 2783 Left Rail 1
26 AW50 0010 Push Switch 1
27 A134 2941 Bracket - Paper Sizesensor 1
28 AA08 2047 Bushing - 8x16x7 1
29 A166 2641 Paper Feed Shaft Ass’y 1
30 AX20 0124 Magnetic Clutch 1
31 A157 2772 Paper Stripper Shaft 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
102 0414 0080B Binding Self-tapping Screw - M4x8
103 0720 0025E Retaining Ring - M2.5
104 0720 0060E Retaining Ring - M6
105 0413 0082B Tapping Screw - M3x8
106 0443 0060B Hexagon Tapping Screw - M3x6
107 0720 0030B Retaining Ring - M3
Part No.
Description
Q’ty Per
Assembly
A166 31 Parts Location and List
Page 49
12. PAPER REGISTRATION (A166)
A166 32 Parts Location and List
Page 50
12. PAPER REGISTRATION (A166)
Index
No.
1 AG05 0079 Registration Knob 1
2 A166 5649 Regist Sensor Harness 1
3 AA08 2021 Bushing - 8x12x10mm 2
4 AA08 2047 Bushing - 8x16x7 2
5 AW02 0068 Photointerruptor 1
6 AA08 0037 Bushing - 6 mm 2
7 AA06 3291 Spring 2
8 A166 2570 Lower Guide Plate 1
9 AF02 1055 Upper Registration Roller 1
10 AF02 0356 Lower Registration Roller 1
11 AF02 0357 Transfer Roller 1
12 A166 2596 Upper Guide Plate 1
13 A166 2629 Drive Unit 1
14 A166 2716 Paper Feed Guide Plate 1
15 AX20 0122 Magnetic Clutch - 0.049n.M35z 1
16 AX20 0123 Magnetic Clutch - 0.98n M25z 1
17 A166 2617 Registration Sensor Bracket 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1105 0199 Clamp
102 1105 0243 Wire Saddle
103 0720 0060B Retaining Ring - M6
104 0720 0040B Retaining Ring - M4
105 0434 0060B Philips Tapping Screw - M4x6
106 0451 4008B Philips Tapping Screw - M4x8
107 0443 0060B Hexagon Tapping Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
A166 33 Parts Location and List
Page 51
13. PAPER TRAY SECTION (A166)
A166 34 Parts Location and List
Page 52
13. PAPER TRAY SECTION (A166)
Index
No.
1 A166 2870 Paper Tray Ass’y 1
2 A166 2877 Front Paper Stripper 1
3 A157 2766 Front Stopper Lever 1
4 A157 2767 Front Stopper Spring 1
5 AF01 6072 Front Side Fence 1
6 A166 2884 Rear Paper Stripper 1
7 A157 2768 Rear Stopper Lever 1
8 A157 2769 Rear Stopper Spring 1
9 A157 2762 End Fence Spring 1
10 AF01 7015 Paper End Fence 1
11 A157 2806 Bottom Tray Sheet 1
12 AB01 3868 Gear - 16Z 1
13 AF01 3004 Bottom Plate Pad 1
14 A134 2956 Paper Feed Front Cover 1
15 AF01 0069 Paper Tray Frame 1
16 A157 2758 Decal - Paper Setting 1
17 AF01 6073 Rear Side Fence 1
18 A157 2805 Decal - Paper Set 1
19 A157 2765 Bottom Plate Spring 1
20 AF01 5027 Paper Size Slider 1
21 AF01 1039 Tray Bottom Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
Part No.
Description
Q’ty Per
Assembly
A166 35 Parts Location and List
Page 53
14. TONER HOPPER (A166)
A166 36 Parts Location and List
Page 54
14. TONER HOPPER (A166)
Index
No.
*A166 3013 Development Unit (RIC) 1
*A166 3014 Development Unit 1
1 A166 3322 Collection Coil Cover 2
2 A166 3312 Black Toner Hopper Ass’y 1
3 AA08 0205 Bushing - 6mm 3
4 A166 3325 Toner Supply Roller Pad 4
5 A166 3323 Entrance Pad - Toner Supply Roller 4
6 AA08 0207 Bushing - 6mm 3
7 AA15 3020 Seal 6
8 AA13 2192 Collar 8
9 AA15 1242 Rear Seal - Toner Supply Shaft 16
10 A166 3330 Toner Supply Roller 4
11 A166 3301 Toner Supply Side Plate 1
12 AA06 0282 Pressure Spring 1
13 A166 5647 Development Harness 1
14 A166 3224 Gear Head 1
15 AB01 1366 Gear - 42z 4
16 H085 1521 Drive Gear - ADF Feed : Z17 4
17 AA15 3006 Seal 4
18 AW02 0021 Photointerruptor - 175487-3 1
19 A166 3217 H.P. Sensor Bracket 1
20 A166 3307 Positioning Sensor Link - Black 2 1
21 AA06 6552 Spring 1
22 A166 3306 Positioning Sensor Link - Black 1 1
23 AW02 0083 Photointerruptor 1
24 A166 3222 Sensor Bracket 1
25 A166 1339 Bracket - Upper Inner Cover 1
26 A166 3336 Small Shutter Bracket 3
27 A166 3332 Shutter Cover-toner Collection Coil 6
28 A166 3334 Large Shutter Bracket 3
29 A166 3232 Toner Supply Motor 1
30 AB01 1369 Gear - 56Z 1
31 AB01 7407 Gear - 12Z/41Z 2
32 A049 2194 Seal 2
Part No.
(NRG/INF/SVN) (RIC-ASIA)
Description
Q’ty Per
Assembly
Index
No.
33 A166 3036 Toner Supply Unit (RIC) 1
33 A166 3037 Toner Supply Unit 1
34 A166 3308 Link Holder 1
35 A166 3225 Gear Release Bracket 1
36 A166 3193 Stopper Dev Unit 1
37 A166 3285 Seal - Cyan 1
38 A166 3286 Seal - Yellow 1
39 A166 3287 Seal - Magenta 1
101 0720 0040B Retaining Ring - M4
102 0452 4008B Tapping Bind Screw - M4x8
103 0720 0060B Retaining Ring - M6
104 0952 4006B Screw - Small Round - M4x6
105 0434 0060B Philips Tapping Screw - M4x6
106 1105 0310 Wire Clamp
107 0952 4025B Screw - M4X25
108 0952 4006B Screw - Small Round - M4x6
Part No.
Description
(NRG/INF/SVN)(RIC-ASIA)
Q’ty Per
Assembly
A166 37 Parts Location and List
Page 55
15. DEVELOPMENT UNIT (A1466)
A166 38 Parts Location and List
Page 56
15. DEVELOPMENT UNIT (A1466)
Index
No.
1 AA06 0320 Release Spring 1
2 A166 3270 Positioning Roller 1
3 AB01 3947 Gear 1
4 A166 3280 Rear Support Plate - Development 1
5 AB01 3948 Gear 2
6 A166 3170 Idle Gear 1
7 A166 3190 Development Gear 1
8 AA14 3726 Stepped Screw 1
9 AB01 3949 Gear 1
10 A166 3134 Toner Bottle Cap 1
11 A166 3160 Entrance Guide 1
12 A166 3201 Toner Collection Plate 1
13 A166 3295 Collection Plate Seal 1
14 A166 3209 Decal - Development 1
15 A166 3298 Collection Plate Magnet 1
16 A049 2194 Seal 1
17 A049 2195 Seal 1
18 A049 3945 Seal - Black 1
19 A049 3946 Seal - Blue 1
20 A166 3290 Rear Support Plate 1
21 A166 3199 Development Fixing Plate 1
22 AW01 0046 Photosensor - Ee-spy415 1
23 A166 3205 Development Unit Grip 1
24 A166 3235 Optical Sensor Cover 1
25 A166 3133 Sealing Seal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0720 0040B Retaining Ring - M4
102 0952 4006B Screw - Small Round - M4x6
103 0451 4008B Philips Tapping Screw - M4x8
104 0952 3012B Screw - M5X12
Part No.
Description
Q’ty Per
Assembly
A166 39 Parts Location and List
Page 57
16. TRANSFER BELT UNIT 1 (A166)
A166 40 Parts Location and List
Page 58
16. TRANSFER BELT UNIT 1 (A166)
Index
No.
*A166 6002 Transfer Belt Unit 1
1 A166 6115 Belt Cleaning Unit Grip 1
2 A166 6056 Belt Support Roller 1
3 A166 6129 Side Stay 1
4 A166 6068 Cleaning Side Plate 1
5 A166 6087 Transfer Corona Unit Bracket 1
6 A166 6059 Pressure Roller 1
7 A166 6078 Swing Roller Bracket 1
8 A166 6100 Front Rail - Transfer Belt Unit 1
9 A166 6106 Frame Shaft 1
10 A166 6105 Rear Rail - Transfer Belt Unit 1
11 AA14 3074 Stepped Screw - M4x5 4
12 A166 6103 Cushion - Positioning Pin 1
13 A166 6119 Transfer Belt Unit Grip 1
14 A166 5421 Transfer Belt Sensor 1
15 A166 6093 Positioning Sensor Bracket 1
16 A166 6097 Front End Block - Main Corona 1
17 AA06 0251 Spring 1
18 A166 9515 Main Corona Wire (10pcs/set) 1
19 AD02 2328 T/S Corona Rear Cap 1
20 AA17 0019 Seal 1
21 AA06 3143 Spring 1
22 AD02 2263 Front Cover - Main Corona 1
23 A166 6167 Antistatic Brush Holder 1
24 AA12 0079 Antistatic Brush 2
25 A166 6168 Antistatic Brush Holder 1
26 A166 5638 Transfer Belt Position Harness 1
27 A166 6131 Inner Belt Cleaner 1
28 A166 6121 Snap Ring 1
29 A166 6102 Charge Corona Unit 1
30 A166 6110 Rear Corona Wire Terminal 1
31 A166 6111 Spring Pin 1
32 A166 6180 Arm 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0805 3482 Ball Bearing - 8x14x3.5
102 0720 0060B Retaining Ring - M6
103 0952 4006B Screw - Small Round - M4x6
104 0720 0030B Retaining Ring - M3
105 0434 0060B Philips Tapping Screw - M4x6
106 0313 0100B Philips Pan Head Screw - M3x10
107 0315 0100B Philips Pan Head Screw - M5x10
108 0353 0080B Screw - M3X8
Part No.
Description
Q’ty Per
Assembly
A166 41 Parts Location and List
Page 59
17. TRANSFER BELT UNIT 2 (A166)
A166 42 Parts Location and List
Page 60
17. TRANSFER BELT UNIT 2 (A166)
Index
No.
1 A109 6087 Spring Holder Cover - Transfer 1
2 AA06 3546 Spring 1
3 A166 6127 Bracket Disk 1
4 A166 6126 Brake Pad 1
5 A166 6128 Pad Holder 1
6 AA08 4044 Bearing Holder 2
7 AA06 3369 Spring 2
8 A166 6073 Front Side Plate - Transfer 1
9 A053 2132 Bushing - 6x10x3 2
10 A166 6084 Lifting Cam Lever 1
11 A166 6062 Transfer Roller 2
12 A166 6080 Lifting Cam Shaft 1
13 A166 6082 Lifting Cam 2
14 A166 6085 Side Plate 1
15 A166 6059 Pressure Roller 1
16 A166 6052 Transfer Belt Drive Roller 1
17 A166 6050 Transfer Belt 1
18 A166 6075 Rear Side Plate - Transfer 1
19 AB01 3981 Gear - 30Z 1
20 A166 6143 Roller Stopper 1
21 AA12 0080 Antistatic Brush 4
22 A166 6166 Antistatic Brush Holder 1
23 AA12 0079 Antistatic Brush 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0805 3482 Ball Bearing - 8x14x3.5
102 0720 0060B Retaining Ring - M6
103 0720 0040B Retaining Ring - M4
104 0353 0080B Screw - M3X8
105 0314 0080B Philips Pan Head Screw - M4x8
106 0434 0060B Philips Tapping Screw - M4x6
107 0451 4008B Philips Tapping Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
A166 43 Parts Location and List
Page 61
18. DRUM SECTION (A166)
A166 44 Parts Location and List
Page 62
18. DRUM SECTION (A166)
Index
No.
1 A166 3339 DC Solenoid 1
2 A166 3340 Solenoid Bracket 1
3 A109 2287 Drum Flange Knob 1
4 A166 2321 Drum Support Plate 1
5 AD03 3123 Left Casing - Charge Corona 1
6 AW33 0007 Drum Potential Sensor 1
7 A166 5648 Density Sensor Harness 1
8 A166 5400 ID Sensor Board 1
9 A166 2308 Density Sensor Cover 1
10 A166 2307 Optical Lower Frame 1
11 A166 5405 Quenching Lamp 1
12 A166 2305 Grid Wire 1
13 A166 2304 Upper Cover - Drum Unit 1
14 A166 2303 Drum Unit Upper Frame 1
15 AD00 4081 Charge Corona Unit 1
16 A166 2319 Density Sensor Bracket 1
17 A049 2272 Charge Grid - 85T 1
18 A166 2331 Front Fixing Plate 1
19 AD02 2325 Front End Block - Charge Corona 1
20 AD02 2326 Front End Block Cover - Charge 1
21 A166 2327 Knob Screw 1
22 AD02 2266 Rear Cover - Charge Corona 1
23 A166 9516 Charge Corona Wire (10pcs/set) 1
24 5442 2108 Corona Wire Spring 1
25 AD02 2265 Rear End Block - Charge Corona 1
26 5442 2110 Plug - Corona Unit 1
27 A166 2311 Shielding Plate - Density Sensor 1
28 A166 3348 Harness Clamp Bracket 1
29 5409 1855 Mounting Pin 1
30 A166 9510 OPC Drum 1
31 AD03 3124 Right Casing - Charge Corona 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0452 3008B Tapping Screw - M3x8
102 0434 0060B Philips Tapping Screw - M4x6
103 0451 4008B Philips Tapping Screw - M4x8
104 1105 0291 Wire Saddle
105 0801 0149 Philips Pan Head Screw - M4x6
106 0353 0060W Philips Pan Head Screw - M3x6
107 0433 0062B Tapping Screw - M3 X 6 mm
108 0951 3006W Philips Screw With Flat Washer-M3x6
109 0413 0062W Tapping Screw - M3x6
110 0443 0050B Philips Pan Head Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
A166 45 Parts Location and List
Page 63
19. DRUM CLEANING (A166)
A166 46 Parts Location and List
Page 64
19. DRUM CLEANING (A166)
Index
No.
*A166 3511 Drum Cleaning Unit 1
1 A166 3576 Drum Cleaning Blade 1
2 AA06 0632 Spring - Blade 1
3 AD04 7016 Cleaning Entrance Seal 1
4 A166 3591 Entrance Seal 1
5 A166 3511 Drum Cleaning Unit 1
6 A166 3571 Cleaning Blade Holder 1
7 AA15 2256 Seal 1
8 AA15 2255 Seal 1
9 A166 3556 Brush Roller Holder 1
10 AD04 2031 Cleaning Brush Roller 1
11 A166 3581 Toner Collection Pipe 1
12 AA06 3283 Spring 1
13 AD04 3043 Toner Collection Coil - Transfer 1
14 AB01 3966 Gear - 20Z 1
15 AB01 3965 Gear - 16Z 1
16 A166 3566 Brush Roller Drive Shaft 1
17 A166 3593 Cleaning Cover Seal 2
18 A166 3586 Cleaning Seal 1
19 A166 3554 Cleaning Unit Cover 1
20 A166 3596 Lubricant Plate 1
21 A166 3599 Lubricant Spring 1
22 A166 3592 Toner Collection Plate Seal 1
23 A166 3587 Cleaning Blade Seal 2
24 H072 2220 Spacer - M6x10 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0951 3006W Philips Screw With Flat Washer-M3x6
102 0452 3008B Tapping Screw - M3x8
103 0434 0060B Philips Tapping Screw - M4x6
104 0720 0040B Retaining Ring - M4
Part No.
Description
Q’ty Per
Assembly
A166 47 Parts Location and List
Page 65
20. TRANSFER BELT CLEANING (A166)
A166 48 Parts Location and List
Page 66
20. TRANSFER BELT CLEANING (A166)
Index
No.
1 A166 6381 Toner Collection Pipe 1
2 A166 6393 Belt Cleaning Holder 1
3 A166 6371 Toner Collection Coil 1
4 A166 5657 Cleaning Relay Harness 1
5 AX12 0043 DC Solenoid 1
6 A166 6336 Release Plate 1
7 AA06 0628 Spring 1
8 A166 6366 Solenoid Cover 1
9 A109 6348 Lever Cushion 1
10 A166 6357 Blade Seal 2
11 A166 6322 Blade Support Plate 1
12 A166 6325 Lever Cushion 1
13 AA06 0627 Spring 1
14 A166 6331 Cleaning Blade - Transfer Belt 1
15 A166 6348 Link Plate - Seal Lever 1
16 AA10 0009 Ring Stopper 1
17 AB01 3978 Gear 1
18 A166 6361 Belt Cleaning Side Plate 1
19 A166 6347 Entrance Seal Lever 1
20 A166 6353 Belt Cleaning Casing 1
21 A166 6359 Belt Cleaning Seal 1
22 A166 6358 Toner Collection Seal 1
23 A166 6341 Entrance Seal 1
24 AA06 0629 Spring 1
25 A109 6369 Entrance Seal Collar 1
26 A166 6363 Toner Collection Plate 2
27 A166 6161 LED Array 1
28 A166 5641 Belt Cleaning Harness 1
29 A166 6368 Cover Front Seal 1
30 A166 6367 Cover Seal 1
31 A166 6388 Blade Release Wedge 1
32 A166 6362 Seal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0952 4006B Screw - Small Round - M4x6
102 0434 0060B Philips Tapping Screw - M4x6
103 0720 0030B Retaining Ring - M3
Part No.
Description
Q’ty Per
Assembly
A166 49 Parts Location and List
Page 67
21. TRANSPORT UNIT (A166)
A166 50 Parts Location and List
Page 68
21. TRANSPORT UNIT (A166)
Index
No.
1 A166 6213 Upper Guide Plate 1
2 A166 6200 Transfer Corona Unit 1
3 A166 3942 Transfer Tank Rail 1
4 A166 6123 Transfer Tank Stay 1
5 A166 6216 Spring Plate 2
6 A166 4455 Spring Plate 2
7 A166 3940 Transfer Tank Frame 1
8 AX64 0068 Fan Motor - DC24V 0.09A 2
9 AF02 2070 Right Transport Roller 2
10 AF02 2069 Left Transport Roller 1
11 AB01 3982 Gear - 30Z 1
12 AA04 0025 Transfer Belt 2
13 A166 6210 Lower Guide Plate 1
14 AD02 2323 Front End Block Cover - Transfer 1
15 A166 6245 Antistatic Brush Holder 1
16 5442 2108 Corona Wire Spring 1
17 AA12 0068 Antistatic Brush 1
18 AD02 2324 Rear End Block Cover - Transfer 1
19 A166 9514 Transfer Corona Wire - (10pcs/set) 1
20 AD02 2321 Front End Block - Transfer Corona 1
21 AA06 3036 Terminal Spring 2
22 AD02 2322 Rear End Block - Transfer Corona 1
23 A166 5650 Transfer Harness 1
24 A166 6230 T/S Corona Casing 1
25 A166 6247 Grounding Plate 1
26 A166 6246 Grounding Plate - Antistatic Brush 1
27 A166 3910 Transfer Tank 1
28 A030 6231 Corona Wire Ring 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1105 0199 Clamp
102 5053 0447 Bushing - 6mm
103 0414 0080W Tapping Screw - M4x8
104 0434 0060B Philips Tapping Screw - M4x6
105 0720 0040B Retaining Ring - M4
Part No.
Description
Q’ty Per
Assembly
A166 51 Parts Location and List
Page 69
22. FUSING UNIT 1 (A166)
A166 52 Parts Location and List
Page 70
22. FUSING UNIT 1 (A166)
Index
No.
*A166 4034 Fusing Unit (115V) 1
*A166 4043 Fusing Unit (230V) 1
1 AA18 0054 Oil Supply Tube 1
2 A166 4014 Oil Supply Unit 1
3 AA11 3021 Heater Terminal 1
4 AA03 1009 Oil Tank 1
5 AA03 6007 Oil Tank Cap 1
6 A166 4290 Knob Joint 1
7 AG05 0080 Fusing Knob 1
8 A166 4297 Drive Release Slider 1
9 AA06 3536 Spring 1
10 AA08 0166 Bushing - 8mm 1
11 A166 4284 Fusing Unit Lever 1
12 5206 2686 Snap Ring 1
13 A166 4350 Fusing And Paper Exit Unit 1
14 A166 4203 Fusing Left Cover 1
15 A166 4199 Fusing Unit Cover 1
16 A166 5656 Fusing Unit Harness 1
17 A166 4092 Connector Bracket 1
18 AA00 0194 Decal - High Temperature 1
19 A166 4267 Oil Cleaning Felt 1
20 A166 4270 Felt bracket 2
21 A166 4098 Thermistor Harness Bracket 1
22 A166 5721 Relay Harness - Oil End Sensor 1
23 A166 4287 Lever Knob 1
24 AB01 3976 Gear - 15Z 1
25 5209 5320 Oil End Sensor 1
26 A166 4089 Oil End Sensor Bracket 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0720 0040B Retaining Ring - M4
102 0952 4006B Screw - Small Round - M4x6
103 0452 4008B Tapping Bind Screw - M4x8
104 0344 0080F Philips Truss Head Screw - M4x8
105 0452 4010B Tapping Bind Screw - M4x10
106 0443 0080W Hexagon Head Tapping Screw - M3x8
107 0950 3005M Philips Screw With Lock Washer M3x5
108 0314 0100B Philips Pan Head Screw - M4x10
Part No.
Description
Q’ty Per
Assembly
A166 53 Parts Location and List
Page 71
23. FUSING UNIT 2 (A166)
A166 54 Parts Location and List
Page 72
23. FUSING UNIT 2 (A166)
Index
No.
1 A166 4122 Scraper Holder 1
2 A166 4123 Fusing Roller Scraper 1
3 A166 4121 Scraper Bracket 1
4 AA06 3284 Spring 1
5 AE03 1021 Bushing - 6mm 2
6 AE03 1022 Bushing - 4mm 4
7 A166 4070 Upper Fusing Stay 1
8 AA00 0178 Decal - Thermofuse 1
9 AA06 3285 Spring 1
10 AB01 3977 Gear - 16Z 1
11 A166 5415 Thermo Fuse 1
12 A166 4102 Oil Supply Pad 1
13 A166 4100 Oil Sump 1
14 A166 5410 Thermistor - Fusing Roller 1
15 AE04 0012 Oil Supply Roller 1
16 AE04 0011 Oil Toff Roller 1
17 A166 4120 Fusing Cleaning Roller 1
18 A166 4124 Cushion 2
19 G012 4617 Stepped Screw - M3 3
20 A166 4363 Oil Sump Stay 1
21 A166 4364 Spur 4
22 A166 4385 Oil Guide 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0951 4008B Philips Screw With Washer - M4x8
102 0952 4006B Screw - Small Round - M4x6
103 0720 0025E Retaining Ring - M2.5
104 0720 0040B Retaining Ring - M4
105 0353 0060W Philips Pan Head Screw - M3x6
106 0443 0060B Hexagon Tapping Screw M3x6 4
Part No.
Description
Q’ty Per
Assembly
A166 55 Parts Location and List
Page 73
24. FUSING UNIT 3 (A166)
A166 56 Parts Location and List
Page 74
24. FUSING UNIT 3 (A166)
Index
No.
1 A166 4080 Adjusting Screw 2
2 A166 4081 Adjusting Plate 2
3 A166 4082 Pressure Roller Lever 2
4 AB01 3983 Gear - 16Z 1
5 A166 4055 Lower Fusing Frame 1
6 AA11 3021 Heater Terminal 1
7 A166 4095 Front Heater Holder 1
8 A166 4125 Oil Pan 1
9 AX44 0091 Fusing Lamp - 120V 670W 1
9 AX44 0092 Fusing Lamp - 230V 670W 1
10 A030 4064 Spacer - Hot Roller 2
11 AE03 0007 Ball Bearing-25x47x12mm 2
12 AE03 2007 Bushing - 20x25x12mm 2
13 AE01 0024 Hot Roller 1
14 AB01 3969 Gear - 45Z 1
15 AX43 0041 Fusing Lamp - 120V 400W 1
15 AX43 0042 Fusing Lamp - 230V 400W 1
16 AE03 0019 Ball Bearing - 7x20x32 2
17 AE02 0066 Pressure Roller (Refer TSB 001 Reissue) 1
17 AE02 0020 Pressure Roller (Refer TSB 001 Reissue) 1
18 A166 4087 Rear Heater Holder 1
19 AW02 0021 Photointerruptor - 175487-3 1
20 A166 4115 Exit Sensor Bracket 1
21 A166 5409 Thermistor - Pressure Roller 1
22 A166 5415 Thermo Fuse 1
23 AB01 3971 Gear - 22Z 1
24 A166 4097 Pressure Roller Heater Holder 1
25 AB01 3975 Gear - 20Z 1
26 H072 2220 Spacer - M6x10 2
27 AB01 3973 Gear - 15Z 1
28 A166 4164 Support Plate 1
29 A166 4111 Shielding Plate 1
30 AA14 0592 Fusing Drive Shaft 1
31 A166 4112 Fusing Entrance Guide 1
32 AA00 0178 Decal - Thermofuse 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
33 0805 3104 Ball Bearing - 8x22x7mm 1
34 AB01 3970 Gear - 22Z 1
35 5053 0223 Bushing - 8mm 1
36 AA13 2013 Spacer - 8.2 1
37 A166 4261 Left Oil Pan Pad 1
39 A166 4265 Rear Left Oil Pan Pad 1
40 A166 4264 Rear Right Oil Pan Pad 1
41 AA06 0673 Pressure Spring 2
42 A166 4133 Cleaning Blade Bracket 1
43 AA14 3258 Stepped Screw - M4x7 1
44 AE04 1003 Oil Cleaning Blade 1
45 A166 4263 Bottom Front Oil Pan Pad 1
46 A166 4266 Front Oil Pan Pad 1
101 0720 0060B Retaining Ring - M6
102 0952 4006B Screw - Small Round - M4x6
103 0443 0060B Hexagon Tapping Screw - M3x6
104 0952 4006B Screw - Small Round - M4x6
105 0314 0060B Philips Pan Head Screw - M4x6
106 0314 0100B Philips Pan Head Screw - M4x10
107 0725 0200E Retaining Ring C - M20
108 0734 0806D Philips Truss Head Screw - M4x5
109 0574 0050B Hexagonal Headless Screw - M4x5
Part No.
Description
Q’ty Per
Assembly
A166 57 Parts Location and List
Page 75
25. PAPER EXIT SECTION (A166)
A166 58 Parts Location and List
Page 76
25. PAPER EXIT SECTION (A166)
Index
No.
1 AB01 3967 Gear - 18Z 1
2 A166 4474 Drive Unit Bracket 1
3 5413 1882 Stepped Screw 1
4 A166 4461 Hinge Bracket 1
5 A166 4480 Paper Exit Arm Holder 1
6 A166 4494 Rear Holder - Copy Tray 1
7 A166 4498 Exit Cover Arm 1
8 A166 4492 Exit Cover 1
9 A166 4496 Exit Cover Pawl 1
10 A166 4482 Shielding Plate 1
11 AA12 0084 Anti Static Brush 1
12 A166 4464 Paper Exit Guide 1
13 A166 4017 Driven Roller 2
14 A166 4466 Spring Plate 2
15 A166 4493 Front Holder - Copy Tray 1
16 AA08 2058 Bushing - 6x10x9mm 2
17 AB01 3801 Gear - 30Z 1
18 AA06 3505 Spring 1
19 AF04 0554 Paper Exit Roller 1
20 AF02 5026 Paper Exit Pawl 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0807 4123 Spacer - 6x13x1
102 0443 0060B Hexagon Tapping Screw - M3x6
103 0720 0040B Retaining Ring - M4
104 0434 0060B Philips Tapping Screw - M4x6
105 0434 0200B Tapping Screw - M4x20
106 0451 4008B Philips Tapping Screw - M4x8
107 0452 4008B Tapping Bind Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
A166 59 Parts Location and List
Page 77
26. SWEEPER (A166)
A166 60 Parts Location and List
Page 78
26. SWEEPER (A166)
Index
No.
1 AA06 0631 Spring - Release - Scraper 1
2 A166 6436 Lubricant Support Plate 1
3 A166 3184 Collection Knob 1
4 A166 3198 Toner Collection Bottle 1
5 5442 3664 Toner Collection Bottle Cap - Small 1
6 A166 3195 Toner Collection Guide 1
7 A166 6462 Lubricant Pressure Bracket 1
8 A166 1078 Right Stay 1
9 A166 6422 Lubricant Holder 1
10 AA10 0009 Ring Stopper 2
11 AX12 0043 DC Solenoid 1
12 A166 6150 Bushing 2
13 A109 6425 Brush Roller Spacer 2
14 A166 6431 Lubricant Brush 1
15 AB01 3979 Gear 1
16 AG07 0004 Magnetic Catch 1
17 A109 6430 Lubricant Bar 1
18 A166 6425 Lever Guide Sheet 1
19 A166 6472 Link Solenoid 1
20 AA06 0630 Spring 1
21 A166 6473 Pressure Plate 1
22 A109 6348 Lever Cushion 1
23 A109 6415 Lever Spring 1
24 A166 6427 Spring 2
25 AA14 3025 Stepped Screw - M3 1
26 A166 6428 Spacer - Lubricant Bar 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
102 0453 4010B Tapping Bind Screw - M4x10
103 0805 3385 Bushing - 6mm
104 0720 0030B Retaining Ring - M3
Part No.
Description
Q’ty Per
Assembly
A166 61 Parts Location and List
Page 79
27. DRIVE SECTION 1 (A166)
A166 62 Parts Location and List
Page 80
27. DRIVE SECTION 1 (A166)
Rev. 3/99
Index
No.
1 AX05 0093 Motor - DC24V 9W 1
2 AB01 3961 Gear - 40Z 1
3 A166 2385 Drive Shaft - Transfer Unit 1
4 AA14 5253 Shaft - 4x46 2
5 AB01 0200 Gear - 27Z 1
6 AB01 7403 Gear - 25Z/24Z 1
7 AB01 7402 Gear - 31Z/72Z 1
8 A166 2361 Tightner Arm 1
9 AB03 0388 Pulley - 16Z 1
10 AA06 0634 Spring - Tightener 1
11 AB03 0526 Pulley - 45Z 1
12 A166 2364 Timing Belt - B40S3M318 1
13 AA06 3535 Spring 1
14 A166 2355 Drum Drive Support Plate 1
15 AA06 3534 Spring 1
16 AB01 3960 Gear - 30Z 1
17 AB01 3962 Gear - 20Z 1
18 AB01 7401 Gear - 20Z/60Z 1
19 AB01 3958 Gear - 40Z 1
20 A166 2266 Grounding Wire 1
21 AA13 4099 Bushing 1
22 A166 2261 Drum Shaft Holder 1
23 AD01 5016 Drum Shaft Ass’y 1
24 A166 2401 Fly Wheel - 200 1
25 AB01 3957 Gear - 80Z 1
26 A166 2296 Drum Joint Shaft 1
27 AB01 3980 Gear - 17Z 1
28 A166 2350 Drum Drive Housing 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0720 0060B Retaining Ring - M6
102 0452 4010B Tapping Bind Screw - M4x10
103 0451 4008B Philips Tapping Screw - M4x8
104 0443 0060B Hexagon Tapping Screw - M3x6
105 0574 0060E Hexagon Headless Set Screw - M4x6
106 0951 5014W Philips Screw W/h Flat Washer-M5x14
107 0452 3008B Tapping Screw - M3x8
108 0805 3491 Bearing - 10X26X9
Part No.
Description
Q’ty Per
Assembly
A166 63 Parts Location and List
Page 81
28. DRIVE SECTION 2 (A166)
A166 64 Parts Location and List
Page 82
28. DRIVE SECTION 2 (A166)
Index
No.
1 AX06 0116 Motor - DC24V 20W 1
2 AB01 3953 Gear 1
3 A166 3374 Development Drive Bracket 1
4 AB01 7387 Gear - 14Z/96Z 1
5 A166 3372 Drive Support Plate - Development 1
6 A166 3412 Spacer 1
7 AA14 5249 Development Drive Shaft 1
8 AB01 3952 Gear 1
9 AA06 0633 Tension Spring - Tightener 1
10 A166 1121 Support Plate 1
11 A166 1131 Timing Belt - BS3M549 1
12 A166 5935 Upper Holder - I/O Control Board 2 1
13 AX06 0147 Motor - DC24V 4A 1
14 A238 3390 Development Revolver Bracket 1
15 AB01 3955 Gear 1
16 A166 3391 Hopper Drive Shaft 1
17 C400 2671 Gear Spring 1
18 AB01 3954 Gear 1
19 AB01 4068 Gear-36Z 1
20 AX06 0131 Motor - DC24V 38W 1
21 A187 1101 Drive Unit - Main 1
22 AB01 3959 Gear - 20Z 1
23 A166 1126 Tightner Arm 1
24 AB03 0276 Tightener Pulley 1
25 AB03 0525 Pulley - 24Z 1
26 A166 1124 Thrust Ring 1
27 AA06 3533 Spring 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1105 0421 Card Spacer - Mps-06-0
102 0805 3482 Ball Bearing - 8x14x3.5
103 0805 3497 Bushing - 8x12x3.5mm
104 0574 0080E Hexagon Headless Set Screw - M4x8
105 0720 0040B Retaining Ring - M4
106 0720 0060B Retaining Ring - M6
107 0434 0060B Philips Tapping Screw - M4x6
108 0453 4010B Tapping Bind Screw - M4x10
109 0451 4008B Philips Tapping Screw - M4x8
110 1105 0310 Wire Clamp
Part No.
Description
Q’ty Per
Assembly
A166 65 Parts Location and List
Page 83
29. ELECTRICAL SECTION 1 (A166)
A166 66 Parts Location and List
Page 84
29. ELECTRICAL SECTION 1 (A166)
Index
No.
1 A187 5368 I/O Control Board 1 1
2 A166 1175 Outer Duct - Charge Unit 2
3 AX64 0071 Fan Motor - DC24V 0.17A 3
4 AA01 2092 Dust Filter 1
5 A166 2281 Duct - Charge Corona 1
6 A166 1174 Inner Duct - Charge Unit 1
7 AA01 0089 Ozone Filter 1
8 AX64 0070 Fan Motor - DC24V 0.14A 1
9 A166 1176 Inner Duct - Transfer 1
10 A166 1183 Inner Duct - Fusing 1
11 AZ32 0082 Power Pack 1
12 A187 5369 I/O Control Board 2 1
13 A166 1173 OPC Duct 1
14 AA15 3023 Seal 2
15 A166 5927 Grounding Plate 1
16 AA01 0093 Ozone Filter 1
17 AA01 2098 Dust Filter 1
18 A187 5921 Bracket - I/O Control Board 1 1
19 A166 5931 Bracket - I/O Control Board 2 1
20 A166 1172 Duct Bracket - Fusing 1
21 A166 5938 Power Pack Bracket 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0450 4035B Philips Tapping Screw - M4x35
102 1105 0310 Wire Clamp
103 0434 0060B Philips Tapping Screw - M4x6
104 0451 4008B Philips Tapping Screw - M4x8
105 0453 4010B Tapping Bind Screw - M4x10
106 1105 0243 Wire Saddle
107 1105 0328 Harness Clamp - ES-0505
108 1105 0399 Card Spacer - Mps-10-0
Part No.
Description
Q’ty Per
Assembly
A166 67 Parts Location and List
Page 85
30. ELECTRICAL SECTION 2 (A166)
A166 68 Parts Location and List
Page 86
30. ELECTRICAL SECTION 2 (A166)
Index
No.
1 A166 5961 Connector Bracket - Cassette Bank 1
2 AW03 0039 Optical Fiber - 75 700mm 1
3 A166 5611 Rear Left DC Harness 1
4 A166 5632 Rear Right DC Harness 1
5 A166 2271 Receptacle - Charge Corona 1
6 AD02 1117 Transfer Corona Receptacle - Belt 1
7 AD02 1116 Transfer Corona Receptacle 1
8 A166 3363 Bias Terminal 1
9 AA06 3068 Spring Connector 2
10 A166 5631 AC Harness 1
11 5446 5832 Connector Guide Pin 2
12 A166 5952 Power Cord Cover 1
13 A166 5560 Power Supply Cord - 120V 1
13 A166 5561 Power Supply Cord - 230V 1
14 A166 5955 Sorter Connector Bracket 1
15 A166 5956 Optical Fiber Bracket 1
16 AW03 0069 Optical Fiber - 75 1200mm 1
17 A166 3400 Development Bias Terminal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1105 0316 Clamp
102 1105 0310 Wire Clamp
103 0434 0060B Philips Tapping Screw - M4x6
104 0443 0060B Hexagon Tapping Screw - M3x6
105 0801 0149 Philips Pan Head Screw - M4x6
106 1102 4052 Optional Connector
107 0451 4008B Philips Tapping Screw - M4x8
108 0452 3008B Tapping Screw - M3x8
109 1607 0317 Ferrite Core - ESD-R-19
Part No.
Description
Q’ty Per
Assembly
A166 69 Parts Location and List
Page 87
31. ELECTRICAL SECTION 3 (A166)
A166 70 Parts Location and List
Page 88
31. ELECTRICAL SECTION 3 (A166)
Index
No.
1 A166 1182 Power Unit Duct 1
2 AX64 0065 Fan Motor - DC24V .08A 1
3 AG07 0004 Magnetic Catch 1
4 A166 9099 Main Counter 1
5 A166 5941 Switch Bracket 1
6 A166 5943 Safety Switch Release Lever 1
7 A166 5942 Safety Switch Bracket 1
8 AX64 0065 Fan Motor - DC24V .08A 1
9 A166 1178 Fan Motor Bracket 1
10 A166 6535 Collection Bottle Holder 1
11 A166 6142 Stopper Bracket 1
12 A166 6070 Transfer Unit Guide Plate 1
13 AX40 0021 Anti-condensation Heater-115V 18W 1
13 AX40 0022 Anti-condensation Heater - 240V 18W 1
14 A166 5967 Key Counter Bracket 1
15 A166 5659 Key Counter Harness 1
16 5420 1515 Plate - Key Counter 1
17 AX40 0063 Anticondensation Heater - 120V9W 1
17 AX40 0064 Anti Condensation Heater - 230V9W 1
18 A166 1181 Front Right Duct 1
19 AA01 0092 Ozone Filter 1
20 AX64 0065 Fan Motor - DC24V .08A 1
21 A187 4625 Heat Sink 1
22 A166 6120 Transfer Belt Unit Cap 1
23 AA15 3030 Seal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0450 4035B Philips Tapping Screw - M4x35
102 1204 1545 Main Switch
103 1204 2437 Interlock Switch
104 0323 0080B Philips Sunk Screw - M3x8
105 0434 0060B Philips Tapping Screw - M4x6
106 0451 4030B Philips Tapping Screw - M4x30
107 1105 0199 Clamp
108 1105 0291 Wire Saddle
Part No.
Description
Q’ty Per
Assembly
A166 71 Parts Location and List
Page 89
32. ELECTRICAL SECTION 4 (A166)
A166 72 Parts Location and List
Page 90
32. ELECTRICAL SECTION 4 (A166)
Index
No.
1 A166 1083 Sorter Stay 1
2 AZ24 0030 DC Power Supply Unit - 115V 1
2 AZ24 0035 DC Power Supply Unit - 230V 1
3 A166 5891 SCU Release Rod 1
4 A166 5646 Front DC Harness 1
5 A187 5362 Printer Main Control Board 1
6 A166 5870 SCU Base 1
7 A166 5881 Board Bracket 1
8 A166 5722 Grounding Harness 1
9 AA01 0095 Ozone Filter 1
10 A166 5877 LD Cover - Synchronizing 1
11 A166 5879 SCU Fan Cover 1
12 A166 5976 Fan Motor Bracket 1
13 AX64 0074 Fan Motor - DC24V 0.08A 1
14 A166 5979 Exit Fan Motor Bracket 1
15 AX64 0066 Fan Motor - DC24V 0.04A 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0443 0060B Hexagon Tapping Screw - M3x6
102 1105 0334 Edge - 17
103 0451 4030B Philips Tapping Screw - M4x30
104 1105 0199 Clamp
105 1105 0291 Wire Saddle
106 1105 0316 Clamp
107 1105 0310 Wire Clamp
108 1107 0745 Fuse - 1A 250V
Part No.
Description
Q’ty Per
Assembly
A166 73 Parts Location and List
Page 91
33. FRAME SECTION 1 (A166)
A166 74 Parts Location and List
Page 92
33. FRAME SECTION 1 (A166)
Index
No.
1 A166 5957 Left Grip Cover 1
2 A166 4148 Connector Bracket - Fusing 1
3 A134 1072 Right Bracket - Grip Plate 1
4 A134 1071 Left Grip Plate 2
5 A166 5924 SCU Right Release Arm 1
6 A166 5971 Right Hinge Bracket 1
7 A166 5926 Holder - I/O Control Board 1 1
8 A166 5959 Rear Right Harness Guide 1
9 A166 1357 Right Middle Cover Bracket 1
10 A166 5925 Hinge - I/O Control Board 1 1
11 A166 5958 Right Grip Cover 1
12 A166 1177 Duct Bracket - Transfer 1
13 A166 5939 Power Pack Holder 2
14 A166 5937 Lower Holder - I/O Control Board 2 1
15 A134 1073 Left Bracket - Grip Plate 1
16 A166 5970 Left Hinge Bracket 1
17 A166 5951 Left Release Arm - Scanner 1
18 A166 3420 Rear Release Holder 1
19 A166 5935 Upper Holder - I/O Control Board 2 1
20 A166 4094 Stopper (230V) 1
21 A166 5973 Grounding Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
102 1005 0335 Earth Mark
103 1105 0310 Wire Clamp
104 1106 0458 Bushing - 9.9mm
105 1105 0292 Wire Saddle
Part No.
Description
Q’ty Per
Assembly
A166 75 Parts Location and List
Page 93
34. FRAME SECTION 2 (A166)
A166 76 Parts Location and List
Page 94
34. FRAME SECTION 2 (A166)
Index
No.
1 A134 1071 Left Grip Plate 2
2 A134 1073 Left Bracket - Grip Plate 1
3 A166 5962 Connector Bracket - Cleaner 1
4 A166 1354 Cover Hinge - Front Right 1
5 A166 1353 Front Stopper Bracket 1
6 A166 3926 Positioning Plate 1
7 A134 1072 Right Bracket - Grip Plate 1
8 A166 3935 Positioning Shaft Support Plate 1
9 A166 4285 Fusing Unit Lever 1
10 A166 5946 Switch Bracket 1
11 A166 1355 Front Right Lower Bracket 1
12 A166 4280 Fusing Unit Rail 1
13 A166 4296 Rod Holder 2
14 A166 4295 Drive Release Link 1
15 A166 4292 Drive Release Rod 1
16 AA06 0635 Spring - Release 1
17 A166 1091 Lower Transfer Stay 1
18 A166 3925 Transport Misfeed Knob 1
19 A166 3928 Front Positioning Shaft 1
20 A166 5968 Key Counter Fixing Bracket 1
21 AA06 6272 Spring 1
22 A069 2704 Guide Roller - 6x12x7.5 2
23 A166 3920 Release Plate - Transfer Tank 1
24 A166 3194 Stopper Chain 1
25 A166 6118 Transfer Belt Unit Release Knob 1
26 AA15 3029 Seal 1
27 AA15 3027 Seal 1
28 AA15 3028 Seal 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
102 0952 4006B Screw - Small Round - M4x6
103 0453 4010B Tapping Bind Screw - M4x10
104 0720 0040B Retaining Ring - M4
105 0720 0060B Retaining Ring - M6
Part No.
Description
Q’ty Per
Assembly
A166 77 Parts Location and List
Page 95
35. FRAME SECTION 3 (A166)
A166 78 Parts Location and List
Page 96
35. FRAME SECTION 3 (A166)
Index
No.
1 A166 2712 Lock Holder 1
2 AH01 0007 Rubber Foot 4
3 A166 1356 Front Left Lower Bracket 1
4 A166 1084 DC Drive Stay 1
5 A166 1082 Upper Development Rail 1
6 A166 1077 Left Stay 1
7 A166 2250 Drum Rail 1
8 A166 6101 Paper Tray Rail 1
9 A157 1087 Middle Stay 1
10 AX40 0063 Anticondensation Heater - 120V9W 1
10 AX40 0064 Anti Condensation Heater - 230V9W 1
11 A166 5982 Exit Fan Harness Guide 1
12 AA15 3025 Seal 1
13 AA01 0094 Ozone Filter 1
14 A166 1078 Right Stay 1
15 A166 2694 Hinge Bracket 1
16 A166 5635 Relay Harness - Vertical Transport 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0434 0060B Philips Tapping Screw - M4x6
102 0960 4010B Philips Flange Screw - M4 X 10
Part No.
Description
Q’ty Per
Assembly
A166 79 Parts Location and List
Page 97
36. SCANNER MOTOR CONTROL BOARD (A166)
A166 80 Parts Location and List
Page 98
36. SCANNER MOTOR CONTROL BOARD (A166)
Index
No.
*A166 1777 Scanner Motor Control Board 1
1 A109 5159 Heat Sink 1
2 A166 1778 Motor Control Board Bracket 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1101 0328 Connector Pin Contact
102 1102 1119 Pin Connector - 5p
103 1102 4212 Ct Header - 15p
104 1102 5304 Connector - 5p
105 1402 1205 IC - RL102F
106 1407 1970 TTLIC - SN74LS07N
107 1407 4235 IC - SLA5011 LF802
108 1407 4236 IC - SLA5012 LF802
109 1408 1013 IC - Si - 7501
110 1600 1669 Resistor - 1.0 Ω ±5% 5W
111 1601 7508 Resistor Array - 4.7 K
112 1602 7077 Capacitor - 270PF ±10% 50V
113 1604 1387 Capacitor - 220 µF 50V
114 1604 1993 Capacitor - 100µF 25V
115 1604 2166 Capacitor - 100µF 50V ±20%
116 1605 0258 Capacitor - 15P
117 1605 0636 Capacitor - 0.1µF
118 1606 1135 Capacitor - 470PF 50V
119 1630 3101 Resistor - 100Ω - 1/10W
120 1630 3102 Resistor - 1KΩ 1/10W ±5%
121 1630 3103 Resistor - 10KΩ 1/10W ±5%
122 1630 3202 Resistor - 2KΩ -1/10W
Part No.
Description
Ω
Q’ty Per
Assembly
A166 81 Parts Location and List
Page 99
37. SYSTEM CONTROL BOARD (A166)
A166 82 Parts Location and List
Page 100
37. SYSTEM CONTROL BOARD (A166)
A166 83 Parts Location and List
Loading...
