Ricoh A177, A176, A175 Part List
®
®
RICOH GROUP COMPANIES
A175/A176/A177
PARTS CATALOG
PN: RCPC7650
A175/A176/A177
PARTS CATALOG
®
®
RICOH GROUP COMPANIES
A175/A176/A177
PARTS CATALOG
PN: RCPC7650
LEGEND
PRODUCT CODE COMPANY
GESTETNER RICOH SAVIN
A175 2651 FT7650 9500
A176 2760 FT7660 9600
A177 2770 FT7670 9700
A610 DOCUMENT FEEDER
A607 DOCUMENT HANDLER
A609 LARGE CAPACITY TRAY
A608 SORTER
A606 SORTER STAPLER
DOCUMENTATION HISTORY
REV. NO. DATE COMMENTS
*9/96
17/98
Original Printing
Reprint
TABLE OF CONTENTS
A175/A176/A177 PARTS LOCATION AND LIST
LOCATION OF UNIT............................................................ 2
1. EXTERIOR 1.................................................................. 12
2. EXTERIOR 2.................................................................. 14
3. EXTERIOR 3.................................................................. 16
4. EXTERIOR 4.................................................................. 18
5. PLATEN COVER............................................................ 20
6. OPERATION PA N EL ..... ........................ ........................ 22
7. OPTICS SECTION 1...................................................... 24
8. OPTICS SECTION 2...................................................... 26
9. OPTICS SECTION 3...................................................... 28
10. OPTICS SECTION 4...................................................... 30
11. OPTICS SECTION 5...................................................... 32
12. OPTICS SECTION 6...................................................... 34
13. OPTICS SECTION 7...................................................... 36
14. TANDEM TRAY 1 (A176/A177/A191/A192)........... ........ 38
15. TANDEM TRAY 2 (A176/A177/A191/A192)........... ........ 40
16. UNIVER SA L TR AY ........................................................ 42
17. PAPER TRAY................................................................. 44
18. LCT TRAY 1 (A176/A177)............ .. .. .. .. .. .. .. .................. .. 46
19. LCT TRAY 2 (A176/A177)............ .. .. .. .. .. .. .. .................. .. 48
20. PAPER FEED U NIT.......... .... .... .... .... .... .... .... .... .... .... .... . 50
21. VERTICAL TRANSPORT............................................... 52
22. BY-PASS FEED UNIT.................................................... 54
23. PAPER FEED SEC T ION 1.............. .... .... .... .... .... .... .... ... 56
24. PAPER FEED SEC T ION 2.............. .... .... .... .... .... .... .... ... 58
25. DRUM UNIT 1.............. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 60
26. DRUM UNIT 2.............. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 62
27.TONER BOTTLE HOLDER............................................. 64
28.TONER HOPPER SECTION........................................... 66
29. DEVELOP ME N T U N IT................................................... 68
30. TRANSFER BELT UNIT................................................. 70
31. FUSING UNIT 1.............................................................. 72
32. FUSING UNIT 2.............................................................. 74
33. INVERTER AND EXIT SECTION 1................................ 76
34. INVERTER AND EXIT SECTION 2................................ 78
35. DUPLEX UNIT 1............................................................. 80
36. DUPLEX UNIT 2............................................................. 82
37. DUPLEX UNIT 3............................................................. 84
38. DRIVE SECTION 1......................................................... 86
39. DRIVE SECTION 2......................................................... 88
40. PAPER BANK DRIVE 1 ................................................. 90
41. PAPER BANK DRIVE 2 ................................................. 92
42. ELECTRICAL SECTION 1 ............................................. 94
43. ELECTRICAL SECTION 2 ............................................. 96
44. ELECTRICAL SECTION 3 ............................................. 98
45. MAIN CONTROL BOARD..............................................100
46. DECAL AND DOC U MENT..... .................................... ....104
47. SPECIAL TOOL S ........... ................................................108
A175/A176/A177 PARTS INDEX
PARTS INDEX...................................................................... 2
TABLE OF CONTENTS
(Continued)
DOCUMENT FEEDER A610 PARTS LOCATION AND LIST
LOCATION OF UNIT . ............ .............................................. 2
1. EXTERIOR (A610).......... .. .................. .. .. .. .. .. .................. 4
2. ORIGINAL FEED SECTION 1 (A610)... .. .. .. .. .. .. .............. 6
3. ORIGINAL FEED SECTION 2 (A610)... .. .. .. .. .. .. .............. 8
4. ORIGINAL FEED SECTION 3 (A610)............................. 10
5. TRANSPORT SECTION (A610) ..... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 12
6. INVERTER AND EXIT SECTION (A610)........ .. .. .. .. .. .. .. .. 14
7. ELECTRICAL SECTION (A610) . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 16
8. DECAL AND DOCUMENT (A610) .................................. 18
DOCUMENT FEEDER A610 PARTS INDEX
Parts Index . .. .. .. .. .. .. .. .. .................. .. .. .. .. .................. .. .. .. .. .. .... 2
DOCUMENT HANDLER A607 PARTS LOCATION AND
LIST
LOCATION OF UNIT . ............ .............................................. 2
1. EXTERIOR (A607)............. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
2. FEED-IN SECTION (A607)................ .. .. .. .. .. .. .. .. .. .. .. .. .. .. 6
3. SEPARATION SECTION (A607)................................... 8
4. FEED-OUT SECTION (A607).................. .. .................. .. 10
5. TRANSPORT SECTION (A607) .... .. .. .. .. .. .. .. .. .. .. .. .. ........ 12
6. INVERTER SECTION (A607) .... .. .. .. .. .. .. .. .................. .. .. 14
7. EXIT SECTION 1 (A607).............. .. .. .. .. .. .. .................. .. .. 16
8. EXIT SECTION 2 (A607).............. .. .. .. .. .. .. .................. .. .. 18
9. ORIGINAL TABLE (A607).. .. .. .. .. .. .. .. .. .. .................. .. .. .. .. 20
10. FRAME SECTION (A607) .............................................. 22
11. ELECTRICAL SECTION (A607) .................................... 24
12. MAIN CONTROL BOARD (A607).................... .. .. .. .. .. .. .. 26
13. DECAL AND DOCUMENT (A607)..................... .. .. .. .. .. .. 30
DOCUMENT HANDLER A607 PARTS INDEX
PARTS INDEX..................................................................... 2
LARGE CAPACITY TRAY A609 PARTS LOCATION AND
LIST
LOCAT ION OF UN IT... .............. .................... .................... . 3
1. EXTERIOR (A609) .......................................................... 4
2. LIFT TRAY DRIVE (A609)............................................... 6
3. LIFT PAPER TRAY (A609).............................................. 8
4. PAPER FEED SECTION (A609)................... .. .. .. .. .. .. .. .. .. 10
5. PAPER FEED GUIDE (A609) ..... .. .................. .. .. .. .. .. ...... 12
6. DECAL AND DOCUMENT (A609) .................................. 14
LARGE CAPACITY TRAY A609 PARTS INDEX
Parts Index . .. .. .. .. .. .. .. .. .. .................. .. .. .. .. .................. .. .. .. .. .. .. 2
SORTER A608 PARTS LOCATION AND LIST
LOCATION OF UNIT.......................................................... 2
1. EXTERIOR (A608)............. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
2. TRANSPORT SECTION 1 (A608)....... .. .. .. .. .. .. .. .. .. .. .. .... 6
3. TRANSPORT SECTION 2 (A608)....... .. .. .. .. .. .. .. .. .. .. .. .... 8
4. STAPLER UNIT 1 (A608)... .. .. .. .. .. .. .. .. .. .. .. .. .. .. ................ 10
5. STAPLER UNIT 2 (A608)... .. .. .. .. .. .. .. .. .. .. .. .. .. .. ................ 12
6. STAPLER UNIT 3 (A608)... .. .. .. .. .. .. .. .. .. .. .. .. .. .. ................ 14
7. PAPER EXIT SECTION (A608)..................................... 16
8. SHIFT TRAY SECTION (A608)................ .. .................. .. 18
TABLE OF CONTENTS
9. DRIVE AND ELECTRICAL SECTION 1 (A608)............. 20
10. DRIVE AND ELECTRICAL SECTION 2 (A608)....... .. .. .. 22
11. FRAME SECTION (A608) .............................................. 24
12. MAIN CONTROL BOARD (A608).................... .. .. .. .. .. .. .. 26
13. DECAL AND DOCUMENT (A608)..................... .. .. .. .. .. .. 30
SORTER A608 PARTS INDEX
Parts Index . .. .. .. .. .. .. .. .. .................. .. .. .. .. .................. .. .. .. .. .. .... 2
SORTER STAPLER A606 PARTS LOCATION AND LIST
LOCATION OF UNIT ........................................................... 2
1. EXTERIOR (A606) .......................................................... 4
2. STAPLER SECTION 1 (A606) ........................................ 6
3. STAPLER SECTION 2 (A606) ........................................ 8
4. ELECTRICAL SECTION (A606) . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 10
5. BIN DRIVE SECTION (A606).......................................... 12
6. STAPLER DRIVE SECTION (A606)............................... 14
7. TRANSPORT SECTION (A606) ..... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 16
8. PAPER EXIT SECTION (A606) ...................................... 18
9. FRAME SECTION (A606). .. .. .. .. .. .. .. .. .. .. .. .. .. .................. .. 20
10. PUNCH UNIT (A606)...................... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 22
11. DECAL AND DOCUMENT (A606)..................... .. .. .. .. .. .. 24
(Continued)
SORTER STAPLER A606 PARTS INDEX
PARTS INDEX..................................................................... 2
A175/A176/A177
PARTS LOCATION AND LIST
This secti on instr ucts you as to the numbers and names of the parts of this machine
LOCATION OF UNIT
1. EXTERIOR 1
4. EXTERIOR 4
See Page 12
2. EXTERIOR 2
5. PLATEN COVER
See Page 14
3. EXTERIOR 3
See Page 16
6. OPERATION PANEL
See Page 18
A175/A176/A177 3 Parts Location and List
See Page 20
See Page 22
LOCATION OF UNIT
7. OPTICS SECTION 1
See Page 24
10. OPTICS SECTION 4
8. OPTICS SECTION 2
See Page 26
11. OPTICS S ECTION 5
9. OPTICS SECTION 3
See Page 28
12. OPTICS SECTION 6
See Page 30
A175/A176/A177 4 Parts Location and List
See Page 32
See Page 34
LOCATION OF UNIT
13. OPTICS S ECTION 7
See Page 36
16. UNIVERSAL TRAY
14. TANDEM TRAY 1 (A176/A177/A191/A192)
See Page 38
17. PAPER TRAY
15. TANDEM TRAY 2 (A176/A177/A191/A192)
See Page 40
18. LCT TRAY 1 (A176/A177)
See Page 42
A175/A176/A177 5 Parts Location and List
See Page 44
See Page 46
LOCATION OF UNIT
19. LCT TRAY 2 (A176/A177)
See Page 48
22. BY-PASS FEED UN IT
20. PAPER FEED UNIT
See Page 50
23. PAPER FEED SECTION 1
21. VERTICAL TRANSPORT
See Page 52
24. PAPER FEED SEC T ION 2
See Page 54
A175/A176/A177 6 Parts Location and List
See Page 56
See Page 58
LOCATION OF UNIT
25. DRUM UNIT 1
See Page 60
28. TONER HOPPER SECTION
26. DRUM UNIT 2
See Page 62
29. DEVELOPMENT UNIT
27. TONER BOTTLE HOLDER
See Page 64
30. TRANSFER BEL T UN IT
See Page 66
A175/A176/A177 7 Parts Location and List
See Page 68
See Page 70
LOCATION OF UNIT
31. FUSING UNIT 1
See Page 72
34. INVERTER AND EXIT SECTION 2
32. FUSING UNIT 2
35. DUPLEX UNIT 1
See Page 74
33. INVERTER AN D EXI T SECT I ON 1
See Page 76
36. DUPLEX UNIT 2
See Page 78
A175/A176/A177 8 Parts Location and List
See Page 80
See Page 82
LOCATION OF UNIT
37. DUPLEX UNIT 3
See Page 84
40. PAPER BANK DRIVE 1
38. DRIVE SECTIO N 1
See Page 86
41. PAPER BANK DRIVE 2
39. DRIVE SECTIO N 2
See Page 88
42. ELECTRIC AL SEC T ION 1
See Page 90
A175/A176/A177 9 Parts Location and List
See Page 92
See Page 94
LOCATION OF UNIT
43. ELECTRICAL SECTION 2
See Page 96
44. ELECTRIC AL SEC T ION 3
See Page 98
A175/A176/A177 10 Parts Location and List
This page intentionally left blank
A175/A176/A177 11 Parts Location and List
1. EXTERIOR 1
A175/A176/A177 12 Parts Location and List
1. EXTERIOR 1
Index
No.
1 A096 1303 Fusing Unit Guide Lever 1
2 A176 1318 Cap - 16 5
3 A176 1299 Cap - 22 4
4 A176 1302 Left Lower Cover 1
5 AA14 3416 Stepped Screw - M4x3 10
6 A176 1301 Cap - 34x65 1
7 A176 1295 Upper Left Cover 1
8 A176 1297 Mirror Clamp Cover 1
9 A096 5310 Auto Response Sensor 1
10 A096 1282 Position Sensor Cap 1
11 A176 1281 ADF Cover 1
12 A176 1286 Upper Cover 1
13 A176 1462 Operation Panel Ass’y - A4 1
13 A176 1461 Operation Panel Ass’y - LT 1
13 A176 7910 Operation Panel Ass’y - SVN 1
14 A096 1376 Inner Cover - Main Switch 1
15 A175 1380 Left Door Ass’y (KOR)(A175) 1
15 A175 7286 Left Door Ass’y (INF)(A175) 1
15 A175 7886 Left Door Ass’y (SVN)(A175) 1
15 A176 1378 Left Door Ass’y (RIC) 1
15 A176 7081 Left Door Ass’y (NRG) 1
15 A176 7286 Left Door Ass’y (INF)(A191) 1
15 A176 7886 Left Door Ass’y (SVN)(A176) 1
15 A177 1380 Left Door Ass’y (KOR)(A177) 1
15 A177 7286 Left Door Ass’y (INF)(A192) 1
15 A177 7886 Left Door Ass’y (SVN)(A177) 1
16 A096 1339 Decal - Add Toner 1
17 A096 1338 Decal - Misfeed Removal 1
18 A096 1327 Magnet Catch Plate 1
19 A096 1325 Left Switch Lever 1
20 A096 1383 Grip Inner Cover 1
21 A176 1324 Grip Cover 1
22 A176 1310 Louver 1
23 A096 1328 Duplex Guide Lever 1
24 A096 1337 Hinge Shaft - Lower Left 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
25 A096 1326 Lower Left Hinge 1
26 A175 1340 Right Door Ass’y (A175)(RIC) 1
26 A176 1343 Right Door Ass’y (A176/A191)(RIC) 1
26 A177 1340 Right Door Ass’y (A177/A192)(RIC) 1
26 A176 1340 Right Door Ass’y (KOR/NRG/INF/SVN) 1
27 A096 1348 Lower Switch Lever 1
28 A096 1345 Lower Right Hinge 1
29 A096 1367 Right Guide Lever 1
30 A096 1349 Magnet Catch Plate 1
31 A096 1343 Upper Switch Lever 1
32 AG07 0004 Magnetic Catch 1
33 A060 2512 Registration Roller Knob 1
34 A096 1371 Inner Cover - Door Switch 1
35 AA10 0006 Flat Nut - 3.6x9.5x0.8 2
36 A176 1315 Right Lower Cover 1
37 A096 1309 Spring Plate 2
38 A176 1308 Right Middle Cover 1
39 A176 1298 Cap - Matt 2
40 A176 1317 Cap - 34x55 2
41 A176 1305 Upper Right Cover 1
42 A176 1364 Rear Lower Cover 1
43 A548 6131 Cushion - 20x190x30 1
44 A376 4911 Stepped Screw - Left Hinge 2
45 A176 1363 Rear Upper Cover 1
46 A096 1313 Cover Bracket 2
47 A175 5409 ARS Harness 1
48 A096 1377 Left Door Stopper 1
49 A176 1304 Decal - Main Switch Off (KOR) 1
49 A176 1303 Decal - Main Switch (KOR) 1
50 A176 1384 Dust Protection Filter (A177/A192 only) 1
51 A176 1328 Left Door Seal -12x12x150 1
52 A096 1344 Upper Right Hinge 1
53 A176 1365 Cap - 38x77 1
Part No.
Description
Q’ty Per
Assembly
A175/A176/A177 13 Parts Location and List
Index
No.
101 0802 5094 Tapping Truss Head Screw - M4x8
102 0414 0082B Binding Self Tapping Screw - M4x8
103 0324 0080W Philips Sunken Head Screw - M4x8
104 0951 4008B Philips Screw With Washer - M4x8
105 0951 4016W Philips Screw W/ Flat Washer - M4x16
106 0314 0080B Philips Pan Head Screw - M4x8
107 0324 0300Z Philips Sunken Head Screw - M4x30
108 0434 0080B Philips Tapping Screw - M4x8
109 0802 5124 Tapping Screw - M3x8
110 0434 0082W Tapping Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
Index
No.
Part No.
Description
Q’ty Per
Assembly
A175/A176/A177 13 Parts Location and List
A
2. EXTERIOR 2
A175/A176/A177 14 Parts Location and List
2. EXTERIOR 2
Index
No.
1 A096 2103 Ozone Filter 1
2 AA15 1773 Rear Duct Seal 1
3 A096 2092 Main Duct 1
4 AA15 1772 Duct Seal 1
5 5446 3648 Stepped Screw - M4 1
6 AA06 0541 Bushing Lock Spring 1
7 A096 4260 Fusing Lock Lever 1
8 A096 4273 Fusing Unit Stopper 1
9 A096 4249 Fusing Unit Rail 1
10 A096 3956 Heater Cover 1
11 AX40 0047 A nticondens ation Heater - 15W (115V) 1
11 AX40 0048 A nticondens ation Heater - 15W (230V) 1
12 A096 3951 Belt Unit Holder 1
13 AA06 6218 Unit Release Spring 1
14 A096 5444 Transfer Belt Harness 1
15 A096 3959 Release Arm 1
16 AA08 0158 B ushing - 12x16x12.1 1
17 6754 2866 Roller - Positioning Guide 2
18 A300 2134 Guide Roller - B 2
19 5447 2681 Snap Ring 2
20 A096 4591 Right Duplex Rail 1
21 A096 5464 Key Counter Connector 1
22 A096 4498 Rear Exit Unit Bracket 1
23 A096 4587 Left Duplex Rail 1
24 A096 3955 Front Holder 1
25 A096 3960 Belt Unit Knob 1
26 AA17 2013 Heater Cover 1
27 A096 5453 Anticondensation Heater Harness 1 1
28 A096 5535 Key Counter Stay 1
29 A096 4263 Lock Lever Knob 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0414 0082B Binding Self Tapping Screw - M4x8
102 0434 0060B Philips Tapping Screw - M4x6
103 0314 0060B Philips Pan Head Screw - M4x6
104 0314 0080B Philips Pan Head Screw - M4x8
105 1102 6247 Connector - 4p
106 0951 4008B Philips Screw With Washer - M4x8
107 1105 0278 Harness Clamp
108 0313 0050B Philips Pan Head Screw - M3x5
109 0720 0040B Retaining Ring - M4
110 0434 0080B Philips Tapping Screw - M4x8
111 1105 0310 Wire Clamp
112 1102 6251 Connector - 8p
113 1102 6249 Connector - 6p
Part No.
Description
Q’ty Per
Assembly
A175/A176/A177 15 Parts Location and List
Loading...
