Ricoh A007 Modification Bulletin FT5580
MODIFICATION BULLETIN CORRECTION
ISSUED ON: December 31, ’92
MODIFICATION BULLETIN CORRECTION
Model : F30/31
MB No. : 25 Issued on: December 28, ’87
The following item (S) is (are) mentioned by mistake. Please replace the MB with the new one.
* Part number correction
Incorrect:
Correct:
Page Index No. Incorrect P/N Correct P/N Description
57 8 A0073791
Page Index No. Incorrect P/N Correct P/N Description
57 8 A0073791
A0073728 Transport Fan Cover
A0073928 Transport Fan Cover
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 98 Page 1 of 2 ISSUED ON: Oct. 31, ’90
Model F30/31 Volt/Hz
Modified Article Mylar Sael - 18 x 76
Reason for
To make the machine run quieter
Modification
A mylar seal has been added to prevent noise caused by friction between the drum stay and the drum flange.
P/N Description Q’ty Index No. Page
AA150246 Mylar - 18 x 76 1 *74 41
* New Index
Date of
Modification
Serial Number
43
42
#74
P/N AA150246
T.Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 98 Page 2 of 2 ISSUED ON: Oct. 31, ’90
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16 030010XXXX
RICOH FT5590 115/60 USA, CANADA A007-17 40010XXXXX
RICOH FT5590 110/60 TAIWAN A007-19 40010XXXXX
NASHUA 7150D 220,240/50 EUROPE etc. A007-25 030009XXXX
KALLE 9048DZ 220,240/50 EUROPE A007-26 359100XXXX
RICOH FT5590 220,240/50 EUROPE etc. A007-27 40010XXXXX
RICOH FT5590 220,240/50 ASIA etc. A007-29 4000921629
P.B. M750 115/60 USA, CANADA A007-51 010XXXX
NASHUA 7150 115/60 S. AMERICA A007-56 035010XXXX
RICOH FT5580 110/60 TAIWAN A007-59 41010XXXXX
NASHUA 7150 220,240/50 EUROPE etc. A007-65 035010XXXX
KALLE 9048Z 220,240/50 EUROPE A007-66 360100XXXX
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11 009XXXX
SAVIN 7500 115/60 USA, CANADA A019-15 94009XXXXX
NASHUA 7150C 115/60 S. ANERICA A019-16 036009XXXX
RICOH FT6620 115/60 USA, CANADA A019-17 202010XXXX
NASHUA 7150C 220,240/50 EUROPE etc. A019-25 036009XXXX
KALLE 9052DZ 220,240/50 EUROPE A019-26 366100XXXX
RICOH FT6620 220,240/50 EUROPE etc. A019-27 202009XXXX
RICOH FT6620 220,240/50 ASIA etc. A019-29 202009XXXX
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67 41010XXXX
RICOH FT5580 220,240/50 ASIA etc. A007-69 41010XXXX
INFOTEC 9150Z 220,240/50 EUROPE A007-76 351090XXXX
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-07
MODIFICATION BULLETIN NO. 100 Page 1 of 3 ISSUED ON: November 15, ’90
Model F30/31 Volt/Hz
Modified Article Positioning Stud
Reason for
To prevent the holder from flexing
Modification
Draw
No.
Old Parts
No.
AA143032 Positioning Stud - End Block 2 ---- 1 X/ 25 45
New Parts
No.
AA143302
AA148256 Cap Nut 0 ---- 1 /X 77 45
Description
Positioning Stud - Front End
Block
Date of
Modification
A.B.C. Q’ty Used
Old →
Rank Part No. Description Index No. Page
New
0 ---- 1 /X as a set x/o 76 45
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
Serial Number
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhall.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
DETAILS OF MODIFICATION
The positioning stud-end block (P/N AA143032) has been modified so that it can accept a cap nut. The cap nut
prevents the holder from flexing which could cause noise from the cleaning unit.
The old part (#AA143032) and new parts (P/N AA143302, P/N AA148256) are interchangeable as a set.
MODIFICATION BULLETIN NO. 100 Page 2 of 3 ISSUED ON: November 15, ’90
Holder
Old
#25
P/N AA143032
Holder
#77
P/N AA148256
#76
P/N AA143302
New
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 100 Page 3 of 3 ISSUED ON: November 15, ’90
MODEL NAME V/Hz DESTINATION
JAPAN PRODUCTION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16 030011XXXX
RICOH FT5590 115/60 USA, CANADA A007-17 40011XXXXX
RICOH FT5590 110/60 TAIWAN A007-19 4011XXXXXX
NASHUA 7150D 220,240/50 EUROPE etc. A007-25 030011XXXX
KALLE 9048DZ 220,240/50 EUROPE A007-26 359110XXXX
RICOH FT5590 220,240/50 EUROPE etc. A007-27 40011XXXXX
RICOH FT5590 220,240/50 ASIA etc. A007-29 40011XXXXX
P.B. M750 115/60 USA, CANADA A007-51 011XXXX
NASHUA 7150 115/60 S. AMERICA A007-56 035011XXXX
RICOH FT5580 110/60 TAIWAN A007-59 41011XXXXX
NASHUA 7150 220,240/50 EUROPE etc. A007-65 035011XXXX
KALLE 9048Z 220,240/50 EUROPE A007-66 360110XXXX
RICOH FT5580 220,240/50 EUROPE etc. A007-67 41011XXXXX
RICOH FT5580 220,240/50 ASIA etc. A007-69 41011XXXXX
MODEL NAME V/Hz
P.B. D750 115/60
SAVIN 7500 115/60
NASHUA 7150C 115/60 S. ANERICA A019-16 036011XXXX
RICOH FT6620 115/60
NASHUA 7150C 220,240/50 EUROPE etc. A019-25 036010XXXX
KALLE 9052DZ 220,240/50 EUROPE A019-26 366 110XXXX
RICOH FT6620 220,240/50 EUROPE etc. A019-27 202010XXXX
RICOH FT6620 220,240/50 ASIA etc. A019-29 202010XXXX
MODEL NAME V/Hz
RICOH FT6620 115/60
DESTINATION
USA,
CANADA
USA,
CANADA
USA,
CANADA
DESTINATION
USA,
CANADA
JAPAN PRODUCTION
CODE SERIAL NUMBER
A019-11 010XXXX
A019-15 94010XXXXX
A019-17 202011XXXX
REI PRODUCTION
CODE SERIAL NUMBER
A019-06
INFOTEC 9150Z 220,240/50 EUROPE A007-76 351110XXXX
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60
USA,
CANADA
A019-07
MODIFICATION BULLETIN NO. 101 Page 1 of 2 ISSUED ON: Jan. 15, ’91
Model F30/31 Volt/Hz
Modified Article Power Pack - PCC and power pack - T & S
Reason for
Parts standardization
Modification
To standardize F30/31 and F40 parts, the power packs have been changed as follows:
Old P/N New P/N Description Q’ty Interchangeability Index No. Page
AZ310001 AZ310008 Power Pack - pcc 1 O/O 13 57
AZ320006 AZ320050 Power Pack - T & S 1 O/O 16 57
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 101 Page 2 of 2 ISSUED ON: Jan. 15, ’91
MODEL NAME V/Hz DESTINATION
JAPAN PRODUCTION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16 030101XXXX
RICOH FT5590 115/60 USA, CANADA A007-17 40101XXXXX
RICOH FT5590 110/60 TAIWAN A007-19 40101XXXXX
NASHUA 7150D 220,240/50 EUROPE etc. A007-25 030012XXXX
KALLE 9048DZ 220,240/50 EUROPE A007-26 359011XXXX
RICOH FT5590 220,240/50 EUROPE etc. A007-27 40012XXXXX
RICOH FT5590 220,240/50 ASIA etc. A007-29 40012XXXXX
P.B. M750 115/60 USA, CANADA A007-51 012XXXX
NASHUA 7150 115/60 S. AMERICA A007-56 035101XXXX
RICOH FT5580 110/60 TAIWAN A007-59 41012XXXXX
NASHUA 7150 220,240/50 EUROPE etc. A007-65 035101XXXX
KALLE 9048Z 220,240/50 EUROPE A007-66 360011XXXX
RICOH FT5580 220,240/50 EUROPE etc. A007-67 41101XXXXX
RICOH FT5580 220,240/50 ASIA etc. A007-69 41101XXXXX
MODEL NAME V/Hz DESTINATION
P.B. D750 115/60
SAVIN 7500 115/60
NASHUA 7150C 115/60 S. ANERICA A019-16 036101XXXX
RICOH FT6620 115/60
NASHUA 7150C 220,240/50 EUROPE etc. A019-25 036101XXXX
KALLE 9052DZ 220,240/50 EUROPE A019-26 366011XXXX
RICOH FT6620 220,240/50 EUROPE etc. A019-27 202101XXXX
RICOH FT6620 220,240/50 ASIA etc. A019-29 202101XXXX
MODEL NAME V/Hz DESTINATION
RICOH FT6620 115/60
USA,
CANADA
USA,
CANADA
USA,
CANADA
USA,
CANADA
JAPAN PRODUCTION
CODE SERIAL NUMBER
A019-11 101XXXX
A019-15 94101XXXXX
A019-17 202101XXXX
REI PRODUCTION
CODE SERIAL NUMBER
A019-06
INFOTEC 9150Z 220,240/50 EUROPE A007-76 351120XXXX
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60
USA,
CANADA
A019-07
MODIFICATION BULLETIN NO. 102 Page 1 of 4 ISSUED ON: Jan. 31, ’91
Model F30/31 Volt/Hz
Modified Article Operation Panel Cover
Reason for
As per field rewuest
Modification
Draw
No.
Old Parts
No.
New Parts
No.
A0071510 Operation Panel Cover - LT 0 ---- 1 F30 Dup./F31 62 53
A0071511 Operation Panel Cover - A4 0 ---- 1 F30 Dup./F31 RICOH 62 53
A0071512 Operation Panel Cover - A4 0 ---- 1 F30 62 53
A0071513 Operation Panel Cover 0 ---- 1 F30 Dup./F31 INFOTEC 62 53
A0071514 Operation Panel Cover 0 ---- 1 F30 62 53
A0071515 Operation Panel Cover 0 ---- 1 F30 P.B. P.B. 62 53
Description
Date of
Modification
A.B.C.
Rank Part No. Description Index No. Page
Q’ty Used
Old → New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
Serial Number
A0191515 Operation Panel Cover 0 ---- 1 F31 62 53
A0191506 Operation Panel Cover 0 ---- 1 F31 SAVIN 62 53
A0071516 Operation Panel Cover - A4 0 ---- 1 F30 Dup./F31 62 53
A0071517 Operation Panel Cover - A4 0 ---- 1 F30NASHUA NASHUA 62 53
A0071518 Operation Panel Cover - LT 0 ---- 1 F30 Dup./F31 62 53
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhall.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
MODIFICATION BULLETIN NO. 102 Page 2 of 4 ISSUED ON: Jan. 31, ’91
Draw
No.
Old Parts
No.
New Parts
No.
A0071519 Operation Panel Cover - LT 0 ---- 1 F30 ---- NASHUA 62 53
A0071520 Operation Panel Cover 0 ---- 1 F30 ---- INFOTEC 9150DZ 62 53
A0071527 Operation Panel Cover 0 ---- 1 F30 DUP. RICOH-TAIWAN 62 53
A0071528 Operation Panel Cover 0 ---- 1 F30 62 53
Description
A.B.C. Q’ty Used
Old →
Rank Part No. Description Index No. Page
New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
DETAILS OF MODIFICATION
As per field request the operation panel cover has been registered as a service part.
MODIFICATION BULLETIN NO. 102 Page 3 of 4 ISSUED ON: Jan. 31, ’91
1
62
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 102 Page 4 of 4 ISSUED ON: Jan. 31, ’91
MODEL NAME V/Hz DESTINATION
JAPAN PRODUCTION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60
SAVIN 7500 115/60
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
MODEL NAME V/Hz DESTINATION
RICOH FT6620 115/60
USA,
CANADA
USA,
CANADA
USA,
CANADA
USA,
CANADA
A019-11
A019-15
A019-17
REI PRODUCTION
CODE SERIAL NUMBER
A019-06
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60
USA,
CANADA
A019-07
MODIFICATION BULLETIN NO. 104 Page 1 of 2 ISSUED ON: March 31, ’91
Model F30/31 (SAVIN only) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts catalog correction
Modification
Please correct your parts catalog as follows:
Incorrect P/N Correct P/N Description Index No. Page
52056592 52056593 Large Cassette Body 25 19
52056595 52056596 Small Cassette Body 25 19
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 104 Page 2 of 2 ISSUED ON: March 31, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11
SAVIN 7500 115/60 USA, CANADA A019-15
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60 USA, CANADA A019-17
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-08
MODIFICATION BULLETIN NO. 105 Page 1 of 2 ISSUED ON: April 15, ’91
Model F30/31 Volt/Hz
Modified Article Corona Wires
Reason for
To facilitate service
Modification
To facilitate service, the platinum corona wires have been registered as service parts.
For details, please refer to F30/31 RTB No. 048.
Page Index P/N Description
41 61 #A0079540 Main Corona Wire (1 PC/Set)
39 34 #A0079542 Transfer Corona Wire (1 PC/Set)
41 67 #A0079541 PQC Corona Wire (1 PC/Set)
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 105 Page 2 of 2 ISSUED ON: April 15, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16 Service Parts Only
RICOH FT5590 115/60 USA, CANADA A007-17 Service Parts Only
RICOH FT5590 110/60 TAIWAN A007-19 Service Parts Only
NASHUA 7150D 220,240/50 EUROPE etc. A007-25 Service Parts Only
KALLE 9048DZ 220,240/50 EUROPE A007-26 Service Parts Only
RICOH FT5590 220,240/50 EUROPE etc. A007-27 Service Parts Only
RICOH FT5590 220,240/50 ASIA etc. A007-29 Service Parts Only
P.B. M750 115/60 USA, CANADA A007-51 Service Parts Only
NASHUA 7150 115/60 S. AMERICA A007-56 Service Parts Only
RICOH FT5580 110/60 TAIWAN A007-59 Service Parts Only
NASHUA 7150 220,240/50 EUROPE etc. A007-65 Service Parts Only
KALLE 9048Z 220,240/50 EUROPE A007-66 Service Parts Only
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11 Service Parts Only
SAVIN 7500 115/60 USA, CANADA A019-15 Service Parts Only
NASHUA 7150C 115/60 S. AMERICA A019-16 Service Parts Only
RICOH FT6620 115/60 USA, CANADA A019-17 Service Parts Only
NASHUA 7150C 220,240/50 EUROPE etc. A019-25 Service Parts Only
KALLE 9052DZ 220,240/50 EUROPE A019-26 Service Parts Only
RICOH FT6620 220,240/50 EUROPE etc. A019-27 Service Parts Only
RICOH FT6620 220,240/50 ASIA etc. A019-29 Service Parts Only
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06 Service Parts Only
RICOH FT5580 220,240/50 EUROPE etc. A007-67 Service Parts Only
RICOH FT5580 220,240/50 ASIA etc. A007-69 Service Parts Only
INFOTEC 9150Z 220,240/50 EUROPE A007-76 Service Parts Only
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06 Service Parts Only
SAVIN 7500 115/60 USA, CANADA A019-08 Service Parts Only
MODIFICATION BULLETIN NO. 106 Page 1 of 2 ISSUED ON: April 15, ’91
Model F30/31 Volt/Hz
Modified Article Cleaning Blade
Reason for
Parts standardization
Modification
For the purpose of parts standardization, a new cleaning blade (P/N A0073565) replaces
cleaning blade P/N 52053565 and P/N A0093565.
The interchangeability of the old and new blades is O/O.
Old P/N New P/N Description Q’ty interchangeability Index No. Page
52053565 A0073565 Cleaning Blade 1 → 1 O/O 48 45
Date of
Modification
Serial Number
P/N Model in which cleaning blade is used
52053565 F3/4, F9, F30/31, F33/34, F80, F85, F90
A0093565 F12, F13, F23, F24, F25
T .Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 106 Page 2 of 2 ISSUED ON: April 15, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11
SAVIN 7500 115/60 USA, CANADA A019-15
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60 USA, CANADA A019-17
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-08
MODIFICATION BULLETIN NO. 107 Page 1 of 3 ISSUED ON: April 30, ’91
Model F30/31 Volt/Hz
Modified Article Cleaning Brush Drive Shaft Set
Reason for
1. Answer to field request
Modification
Draw
No.
Old Parts
No.
A0079520 A0079521 Cleaning Brush Drive Shaft Set 1 → 1 X/O ---- ----
New Parts
No.
A0079520 Cleaning Brush Drive Shaft Set 0 → 1 ---- ----
Description
Date of
Modification
A.B.C.
Rank Part No. Description Index No. Page
Q’ty Used
Old → New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
Serial Number
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
DETAILS OF MODIFICATION
MODIFICATION BULLETIN NO. 107 Page 2 of 3 ISSUED ON: April 30, ’91
1. In answer to the field’s request, we have registered the cleaning brush drive shaft
set (#A0079520) as a service part. (This part number is mentioned in RTB No. 46)
This set is composed of the following parts:
Item P/N Description Q’ty
1 A0073570 Cleaning Brush Drive Shaft 1
2 AA143302 Positioning Stud - Front End Block 1
3 AA148256 Cup Nut 1
2. The cleaning brush drive shaft included in this set (#A0079520) will be changed
from #A0073570 (round type pin) to #A0073573 (square type pin).
Therefore, the part number for the cleaning brush drive shaft set will be changed
from #A0079520 to #A0079521.
Item P/N Description Q’ty
1 A0073573 Cleaning Brush Drive Shaft 1
2 AA143302 Positioning Stud - Front End Block 1
2
1
Round Pin
3
2
1
3
3 AA148256 Cap Nut 1
NOTE: An another MB for the change of the drive shaft will separatedly be issued as
soon as new shaft is fitted to the production machines.
Square Pin
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 107 Page 3 of 3 ISSUED ON: April 30, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11
SAVIN 7500 115/60 USA, CANADA A019-15
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60 USA, CANADA A019-17
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-08
MODIFICATION BULLETIN NO. 108 Page 1 of 2 ISSUED ON:April 30, ’91
Model F30/31 Volt/Hz
Modified Article Parts Catalog
Reason for
Parts catalog correciton
Modification
Please correct your parts catalog as follows:
Addition
P/N Description Q’ty Index No. Page
AB013081 Gear - 18T 2 * 24 11
AB013082 Gear - 18T (Black) 1 * 25 11
* New Index No.
#25
P/N AB013082
Date of
Modification
Serial Number
#24
P/N AB013081
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 108 Page 2 of 2 ISSUED ON:April 30, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11
SAVIN 7500 115/60 USA, CANADA A019-15
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60 USA, CANADA A019-17
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-08
MODIFICATION BULLETIN NO. 109 Page 1 of 2 ISSUED ON:April 30, ’91
Model F30/31 Volt/Hz
Modified Article Parts Catalog
Reason for
Parts catlog correction
Modification
Please correct your parts catalog as follows:
Correction
P/N Description Q’ty Index No. Page
Incorrect A0073604 Cleaning Brush Holder 1 37 45
Correct A0073602 Cleaning Brush Holder 1 37 45
Date of
Modification
Serial Number
37
38
37
38
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 109 Page 2 of 2 ISSUED ON:April 30, ’91
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
NASHUA 7150D 115/60 S. AMERICA A007-16
RICOH FT5590 115/60 USA, CANADA A007-17
RICOH FT5590 110/60 TAIWAN A007-19
NASHUA 7150D 220,240/50 EUROPE etc. A007-25
KALLE 9048DZ 220,240/50 EUROPE A007-26
RICOH FT5590 220,240/50 EUROPE etc. A007-27
RICOH FT5590 220,240/50 ASIA etc. A007-29
P.B. M750 115/60 USA, CANADA A007-51
NASHUA 7150 115/60 S. AMERICA A007-56
RICOH FT5580 110/60 TAIWAN A007-59
NASHUA 7150 220,240/50 EUROPE etc. A007-65
KALLE 9048Z 220,240/50 EUROPE A007-66
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
P.B. D750 115/60 USA, CANADA A019-11
SAVIN 7500 115/60 USA, CANADA A019-15
NASHUA 7150C 115/60 S. ANERICA A019-16
RICOH FT6620 115/60 USA, CANADA A019-17
NASHUA 7150C 220,240/50 EUROPE etc. A019-25
KALLE 9052DZ 220,240/50 EUROPE A019-26
RICOH FT6620 220,240/50 EUROPE etc. A019-27
RICOH FT6620 220,240/50 ASIA etc. A019-29
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT6620 115/60 USA, CANADA A019-06
RICOH FT5580 220,240/50 EUROPE etc. A007-67
RICOH FT5580 220,240/50 ASIA etc. A007-69
INFOTEC 9150Z 220,240/50 EUROPE A007-76
REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
RICOH FT5590 115/60 USA, CANADA A007-06
SAVIN 7500 115/60 USA, CANADA A019-08
Loading...
