43-3808A

OWNER’S MANUAL — Please read before using this equipment.

"+/2146#06"

#

#

If an icon appears at the
end of a paragraph, go
to the side head box on
that page with the
corresponding icon for
pertinent information.

Signifies a

—

Rý

Warning

....

— Signifies a

Caution

Signifies

#

—

Important

text

%106'065

The FCC Wants You

to Know .................... 3

Features ................... 4

Preparation ............... 6

Operation ................ 11

Remote Operation .. 17

Care ....................... 19

Service and Repair . 19

4'#&"6*+5"$'(14'"
+056#..#6+10

Your Digital Answering System is ETL
listed to UL standards and meets all
applicable FCC requirements.

To reduce the risk the of fire or

WARNING:

shock hazard, do not expose this produ ct to rain or
moisture.

CAUTION

..

RISK OF ELECTRIC

TO REDUCE THE RISK OF ELEC-

CAUTION:

TRIC SHOCK, DO NOT REMOVE COVER OR
BACK. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.

The lightning symbol is intended to alert you
to the presence of uninsulat ed dangerous
voltage within this product’s enclosu re th at
might be of sufficient magnitude to consti­tute a risk of electric shock. Do not open the
product’s case.

The exclamation symbol is intende d to in­form you that important operating and
maintenance instructions are incl uded in

!

the literature accompanying this p roduct.

SHOCK

DO NOT OPEN

..

!

(%%"56#6'/'06

Your answering system complies with
Part 68 of

FCC Rules

request, provide the FCC registration
number and the REN to your telephone
company. Both numbers are on the
bottom of your system.

. You must, upon

© 2002 RadioShack Corporation.

RadioShack and RadioShack.com are trademarks used

All Rights Reserved.

by RadioShack Corporation.

"016'"±"

±

You must not connect

FCC Statement

your answering system
to:

• coin-operated
systems

• party-line systems

• most electronic key
telephone systems

We have designed your answering
system to conform to federal
regulations, and you can connect it to
most telephone lines. However, each
answering system (and each device,
such as a telephone or answering
machine) that you connect to the
telephone line draws power from the
telephone line. We refer to this power
draw as the device's ringer equivalence
number, or REN on the bottom of your
answering system.

If you use more than one phone or other
device on the line, add up all of the
RENs. If the total is more than five
(three in rural areas), your telephones
might not ring. If ringer operation is
impaired, remove a device from the line.

In the unlikely event that your phone
causes problems on the phone line, the
phone company can temporarily
discontinue your service. If this
happens, the phone company attempts
to notify you in advance. If advance
notice is not practical, the phone
company notifies you as soon as
possible and advises you of your right
to file a complaint with the FCC.

Also, the phone company can make
changes to its lines, equipment,
operations, or procedures that could

2

affect the operation of this telephone.
The telephone company notifies you of
these changes in advance, so you can
take the necessary steps to prevent
interruption of your telephone service.

6*'"(%%"9#065";17"
61"-019

This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications.

However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to try
to correct the interference by one or
more of the following measures:

FCC Rules

. These limits are

The FCC Wants You to Know

3

• Reorient or relocate the receiving
antenna.

• Increase the separation between
the equipment and receiver.

• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.

• Consult your local RadioShack
store or an experienced radio/TV
technician for help.

• If you cannot eliminate the
interference, the FCC requires that
you stop using your answering
system.

Changes or modifications not expressly
approved by RadioShack may cause
interference and void the user’s
authority to operate the equipment.

You must use shielded interface cables
with this equipment.

Features

4

('#674'5

Your RadioShack Digital Answering
System is a sophisticated, fully digital
message center that stores all
messages on a computer chip. This
gives you advanced capabilities over
tape-based answering machines.
Because this telephone answering

system is fully digital, there are no tape
mechanisms to wear out and no tapes
to bother with.

Day/Time Stamp

— records the day

and time each message was recorded.

Call Screening

— lets you listen to
incoming calls so you can decide
whether or not to answer a call.

Remote Operation

— lets you operate
the system while you are away from
your home or office.

Multiple Outgoing Messages (OGM)

— lets you set the system to play your
message or the prerecorded message,
or just play your announcement without
recording the caller’s message.

High Memory Capacity

— lets you
record up to 25 minutes of messages,
memos, and two-way phone
conversations.

Voice Activated Recording (VOX )
Detection

— the system stops
recording when the caller hangs up or
after 7 seconds of silence to help
conserve memory space.

Features

5

24'2#4#6+10

Preparation

±

• The system cannot
operate without AC
power.

• Do not press any
button while you
are plugging the
adapter into the AC
outlet. If you
accidentally press
a button, reset the
system by
unplugging the
adapter from the
AC outlet and re­inserting it.

"016'5"±"

+056#..+0)"6*'"$#%-72"
$#66'4;

If AC power fails or you unplug the
system, one 9V alkaline battery (not
supplied) is needed to save any re­corded messages and the settings for
the day and time. For the best
performance and longest life, we
recommend you use a RadioShack
alkaline battery.

1. Use a Phillips screwdriver to re­move the screw on the battery
compartment cover, then remove
the cover.

2. Attach a 9V alkaline battery to the
terminals and place the battery in
the compartment.

3. Replace the cover and secure it
with the screw.

Replace the battery when
on the display while the system is
connected to AC power.

appears

Be

Be

BeBe

%100'%6+0)"#%"219'4

Insert the supplied AC adapter’s barrel
plug into the
the system, then plug the adapter into a

jack on the back of

DC 9V

6
