RM310
3+1 burners gas grill
1. Out door use only
2. This grill in not intended to be installed in or on
recreational vehicles and/or boats.
Dear customer,
Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the
basis of the latest technical knowledge and produced using reliable and high quality components.
Please take a few minutes before starting operation of the gas grill unit and read the following operating
instructions. The instruction shall be marked directions to the installer to leave them with the consumer
and to the consumer to retain them for future reference.
Example only: SERIAL#______MFG. DATE________ PURCHASE DATE:________
Question, problems, missing parts? Before returning to your retailer, call our customer
1
RM310
3+1 burners gas grill
service department at 1-866-898-8187, M-F 9:00am-5:00pm.
TABLE OF CONTENTS
z Safety Information………………………………………………………………………………………………………………………….……
z Package Contents List…………………………………………………………………………………………………………………….……
z Assembly Instructions………………………………………………………………………………………………………………………….
z Regulator & Hose Instructions, Gas Tank Instructions………………………………………………………….……….…
z Operating instructions…………………………………………………………………………………………………………………………
z Cooking Tips………………………………………………………………………………………………………………………………..………
z Care and maintenance………………………………………………………………………………………………………………....……
z Troubleshooting…………………………………………………………………………………………………………………….……………
z Warranty……………………………………………………………………………………………………………………………………..….….
Danger
If you smell gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
1. Do not store or use gasoline or
other flammable liquids or vapors
in the vicinity of this or any other
appliance.
2. An LPcylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.
2
RM310
3+1 burners gas grill
z
Safety Information
Warning
z
Failure to comply with these instructions could result in a fire or explosion that could cause serious
bodily injury, death or property damage.
z
Spiders and small insects can spin webs and nest in the grill burner tubes during transit and
warehousing which can lead to a gas flow obstruction resulting in a fire in and around the burner
tubes. This type of “FLASHBACK FIRE” can cause serious grill damage and create an unsafe
operating condition for the user.
To reduce the chance of a FLASHBACK FIRE you must clean the burner tubes as follows before
initial use. Also do this at least once a month in summer and fall or whenever spiders are active in your
area, and if your grill has not been used for an extended period of time.
-1. Remove the screw from the rear of each burner using a Phillips head screwdriver.
-2.Carefully lift each burner up and away from the gas valve orifice.
-3.Check and clean the burner tubes for insects and insect nests. A clogged tube can lead to a fire
beneath the grill.
-4.Refer to the figure below and perform one of these 3 cleaning methods:
METHOD 1: Bend a stiff wire or wire coat hanger into a small hook as shown and run
the hook through the burner tube and inside the burner several times to remove debris.
METHOD 2:Use a bottle brush with a flexible handle and run the brush through the burner
tube and inside the burner several times to remove any debris.
METHOD 3: Use an air hose to force air through each burner tube. The forced air should pass
debris or obstruction through the burner and out the ports.
For safe operation ensure the gas valve assembly orifice is inside the burner tube before using your grill.
See figure. If the orifice is not inside the burner tube, lighting the burner may cause an explosion and/or
fire resulting in serious bodily injury and/or property damage.
3
RM310
3+1 burners gas grill
Warning
Liquid Propane Gas (LPG) grill models must be used with the liquid propane gas regulator
assembly supplied. Any attempt to convert the grill from one fuel type to another is extremely
hazardous and will void the warranty.
Grill shall be used only outdoors and shall not be used in a building, garage or any other enclosed area.
Never obstruct the flow of ventilation air around your gas grill cabinet.
Never disconnect the gas regulator assembly or any gas fitting while your grill is lit. A lit grill
can ignite leaking gas and cause a fire or explosion which could result in property damage, personal
injury or death.
Keep the gas regulator hose away from any heated surface and dripping grease. Avoid
unnecessary twisting of the hose. Visually inspect the hose prior to each use for cuts,
cracks, excessive wear, or other damage. If the hose appears damaged, do not use the gas
grill. Call 1-866-898-8187 for a Richman replacement gas hose assembly
Warning
z The gas hose should be inspected after each use-look for any cuts, cracks, excessive wear or other
damage. Let the hose be replaced every two years by a qualified technician or the retailer only.
z OnlyusehoseandregulatorsapprovedforLPGGas.
z Avoid twisting and bending of the gas hose.
z Keep the gas hose or any other electrical cords away from hot surfaces of the grill.
z The gas hose must comply with national regulations and should not be longer than 1.5 meters.
Grill Installation Codes
The installation must conform with local codes or, in the absence of local codes, with either the national
fuel gas code, ANSI Z 223.1/NFPA 54, Natural gas and propane installation code, CSA B149.1, or
propane storage and handling code, B149.2, or the standard for Recreational vehicles, ANSI A 119.2,
and CSA Z240 RV series recreational vehicle code, as applicable.
LP gas grill models are designed for use with a standard 20 lb. Liquid Propane Gas tank, not included
with grill. Never connect your gas grill to an LP gas tank that exceeds this capacity.
4
RM310
3+1 burners gas grill
PRE-ASSEMBLY
Read and perform the following pre-assembly instructions:
□ Tools Required for Assembly include:
․protective work gloves
․protective eyewear
․Phillips Head Screwdriver (included in hardware pack in Parts Box)
□ You will need assistance from another person to handle the grill head and other large, heavy parts.
□ Open lid of shipping carton and remove parts box and packing materials. Lay a cardboard sheet on
floor and use as a work surface to protect floor and grill parts from scratches.
□ Slice all four corners with a utility knife to lay open the carton. This allows you to remove the grill
head and components packed inside.
□ Use the Hardware and Part Diagrams to ensure all items are included and free of damage.
Do not assemble or operate the grill if it appears damaged or missing parts.
1. Out door use only
2. This grill in not intended to be installed in or on recreational vehicles and/or boats.
5
RM310
3+1 burners gas grill
z
Package and Hardware Contents List
NO.
1
2
3
DESCRIPTION QTY NO. DESCRIPTION QTY
Fr i ebox Assembl y
Warming Rack
8
Bot t l e Opener
9
1
El ec t r oni c I gni t er
10
Electronic Igniter Holder
11
1
Cas e Body Ba ck Pane l
2
12
1
1
1
1
1
Cooking Grids
Case Body Ri ght Panel
4
Fl ame Tamers
5
Ri gnt Rent
6
7
3
13
Door Handl e
1
14
1
15
16
1
17
Ri ght Door
Tank Bol t
Swivel Locking Caster
3
1
1
1
1
Ri ght Si de Bur ner Ass embl y
Swi vel Cast er
6
RM310
3+1 burners gas grill
NO.
18
19
20 1
21 1
22 2
DESCRIPTION QTY NO. DESCRIPTION QTY
Mot or Base
Lef t Vent
Lef t Dr awer As se mbl y
Ga r e a s e Bo x
Ti s s ue Hanger Hol der
1
27
1
Lef t Door
28
Manual I gni t er Sti ck
29
30 1
Codi ment Tray
1
1
1
23
Car t Bear m Fr ont
24
Ti s sue Hanger
25
Door Mag n e t
26 1
Cas e Body Lef t Panel
1
31 1
Gas Tank Barrier Bar
32
1
33
2
34
35
36
Door - hi nge
Door Crosspi ece
Bottom Panel
St r ai ght Cast er
Warming Rack Holder
2
1
1
2
2
7
RM310
3+1 burners gas grill
NO.
A
B
C
D
E
F
G
H
DESCRIPTION QTY
SUS430 1/ 4" - i n. X12- mm Tr us s
He a d S c r e w wi t h l o c k i n g wa s h e r
Q235 1/ 4"- i n. X10- mm Truss Head Screw
Q235 5/ 32"- i n. X10- mm Truss Head Screw
SUS430 1/ 4" - i n. X10- mm St age Sc r ew
Flat Silicom Washer
SUS430 5/ 32" i n. X10mm Truss Head Screw
Q235 5/ 32 Nut
SUS430 1/ 4" - i n. X10- mm Tr us s
He a d S c r e w wi t h l o c k i n g wa s h e r
26
19
13
2
2
10
6
2
8
RM310
3+1 burners gas grill
z
Parts Diagram
1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
36
9
10
11
2
3
4
5
6
7
8
12
13
14
15
33
34
35
16
17
9
RM310
3+1 burners gas grill
z
Assembly Instructions
Step 1. Install Casters and Tank Bolt
□
Place the Bottom Panel (34) upside down and attach the 4 Casters to the Caster Seats. Use care to
install each Caster into the correct position.
□
Insert the Tank Bolt (15) to the front of the Bottom Panel (34) as shown picture.
35
15(1X)
16(1X)
17(1X)
34(1X)
35(2X)
A(16X)
15
16
A
17
34
Step 2. Install Case Body and Gas Tank Barrier Bar
□ Attach the Case Body (11, 12 & 26) and the Door Crosspiece (33) to the Bottom Panel (34) as shown
picture.
□
Attach the Gas Tank Barrier Bar (36) to the Bottom Panel(34) and the Case Body Back Panel(11)
26
C
12
11
B
31
11(1X)
12(1X)
26(1X)
31(1X)
33
33(1X)
B(9X)
C(6X)
10
RM310
3+1 burners gas grill
Step 3. Install Firebox Assembly to Case Body Assembly and
connection of Electric Igniter
□
Place the Firebox Assembly（1）ontheCaseBodyAssemblyandlockitupby6TrussHead
Screws（B）. We recommend using 2 people to lift the Firebox Assembly (1)
□
Connect the Electric Igniter to Switch Line and Igniter Wire Line tighten as shown
1
B
9
1 (1X)
9 (1X)
B(6X)
Step 4. Install Door Magnet, Electronic Igniter and Battery
□Attach Door Magnet(25) to the Front Cart Beam（23）as shown picture.
□Attach the Electric Igniter Holder（10）to the Front Cart Beam（23）using Truss Head Screws
□
Put the Electric Igniter to the Electric Igniter Holder as shown and unscrew the electronic igniter cap.
Place the “AA” Battery into the igniter with the positive (+) end up. Screw the electronic igniter cap
back into place.
2
5
10(1X)
2
3
1
0
23(1X)
25(2X)
C(2X)
11
RM310
3+1 burners gas grill
Step 5. Install Front Cart Beam and Vents
□Attach the Front Cart Beam(23) to the front of Firebox Assembly(1) using Truss Head Screws(B)
□
Using Flat Silicon Washer(E) and Stage Screws(D) lock Left Vent(19) and Right Vent(5) to the
Firebox Assembly(1)
19
5
E
D
5 (1X)
19(1X)
B(4X)
D (2X)
B
E (2X)
Step 6. Install Drawer Handle and Tissue Hanger
□
Attach the Drawer Handle(13) to the Front Panel of Drawer using Nuts (G)
□
Attach the Tissue Hanger(24) to the bottom of Drawer using two Tissue Hanger Holder(22) and lock
it up by 4 Truss Head Screws(F)
G
3
4
2
1
13 (1X)
22 (2X)
24 (1X)
F
F (4X)
2
2
G (2X)
12
RM310
3+1 burners gas grill
Step 7. Install Left Drawer Assembly to Firebox Assembly.
□
Loosely screw 2 Truss Head Screws with Locking Washer (A) into two holes on the left side of the
firebox as shown. Slide the Left Drawer Assembly (20) over the heads of those screws and tighten.
A (2X)
Step 8. Secure Left Drawer Assembly to the Firebox
Assembly and install Warming Rack Holder
□Use 3 Truss Head Screws(A) from inside of the firebox to secure attached Left Drawer Assembly as
shown
□Attach the Warming Rack Holder (36)to both inside panel of firebox using 3 Truss Head Screws(F)
F
36
A
A (3X)
F (3X)
36(1X)
13
RM310
3+1 burners gas grill
Step 9. Install Right Side Burner Assembly to Firebox
Assembly.
□
Loosely screw 2 Truss Head screws into the bottom two holes in the right side of the firebox as
shown. Slide the Side Burner Assembly over the heads of those screws and tighten.
A (2X)
Step 10. Secure Right Side Burner Assembly to the Firebox
Assembly and Connection of Side Burner Valve
□
Use 3 Truss Head Screws (A) from inside of firebox to secure attached Right Side Burner Assembly.
□
Attach Right Side Burner Assembly (7) to the firebox from the bottom of Side Burner Assembly as
shown.
□
Connect Side Burner Valve to Connector of Gas Appliance, Switch Line and Ignition Wire Line from
the bottom of the Side Burner Assembly as shown.
□
Attach Left Drawer Assembly (7) to the firebox from the bottom of Left Drawer Assembly as shown.
□Attach the Warming Rack Holder (36) to the right side panel of firebox using 3 Truss Head Screws(F)
F
36
A
A (3X)
F (3X)
36(1X)
C (2X)
C
C
14
RM310
3+1 burners gas grill
Step 11. Install Door Handle and Door-hinge
□Attach the Door Handle (13)to the Doors (14 & 27) using 2 Nuts(G) and the Door-hinge(32)
at the bottom of the Door(14 & 27)
27
14
G
32
13
13 (2X)
14 (1X)
27 (1X)
G (4X)
32(2X)
Step 12. Place Condiment Tray and Manual Igniter Stick into
Case Body Assembly
□
Put the Condiment Tray (30) into two holes of the Left Door (27)
□
Attach the Cover of Manual Igniter Stick (29) and Manual stick (28) to the Door (14) using the Truss
Head Screws(C) and put the Manual stick (28) into the Cover (29)
□
Attach the Bottle Opener (8) to the right side of Side Burner Assembly (7) as shown.
30
28
29
8 (1X)
C
8
C
28 (1X)
29 (1X)
30 (1X)
C (3X)
15
RM310
3+1 burners gas grill
Step 13. Place Flame Tamers, Cooking Grids, Warming Rack,
Side Burner Cooking Grid and Grease Box into the Firebox
Assembly
□
Place the Flame Tamers (4) into the Firebox Assembly (1).
□
Place the Cooking Grids (3) into the Firebox Assembly (1).
□
Place the Warning Rack (2) into the slots along the top of Firebox Assembly (1) as shown.
□
Place the Side Burner Cooking Grid (6) into the Right Side Burner Frame (7).
□
SlidetheGreaseBox(21)fromthebackoftheFireboxAssembly.
2 (1X)
3 (2X)
4 (3X)
6 (1X)
21 (1X)
Step 14. Exchange Vents to Motor Base
□
Unscrew the Vents (5 & 19) and attach the Motor Base (18) to the Firebox Assembly (1) using 2
Truss Head Screws as shown.
18 (1X)
H (2X)
16
RM310
3+1 burners gas grill
Step 15. Place LP Cylinder into the Cabinet
□Place the LP cylinder down into the tank support hole in the bottom of the cabinet. Use the tank bolt
to secure the tank in a fixed position with tank valve faces to the front.
Do Not Hook Up the LP Cylinder to the Regulator Assembly at this time.
Step 15. Congratulations – Assembly is now Complete
□Remove any additional labels or packing material from the grill except the CSA label. Be sure to clean
all foam packing material out of all areas.
□Please proceed to and read the remaining sections of the Operator’s Manual prior to hooking up your
LP cylinder or operating your grill.
17
RM310
3+1 burners gas grill
z
Regulator & Hose Instructions, Gas Tank Instructions
Gas Installation
Correct LP gas tank use
z LP gas grill models are designed for use with a standard 20 lb. (9.1kg) Liquid Propane Gas (LP Gas)
tank, which is not included with the grill. Never connect your gas g rill to an LP gas tank that
exceeds this capacity. A tank of approximately 12” (305mm) in diameter by 18-1/2”(472mm) high
is the maximum size LP gas tank to use. You must use an “OPD” gas tank which offers a listed
Overfill Prevention Device. This safety feature prevents tanks from being overfilled which can cause
malfunction of the LP gas tank, regulator and grill.
z The LP gas tank must be constructed and marked in accordance with the Specifications for LP-Gas
Cylinders of the U.S. Department of Transportation (D.O. T.) or the National Standard of Canada,
CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods; and
Commission, as applicable.
z The LP gas tank must have a shutoff valve terminating in a LP gas supply tank valve outlet that is
compatible with a Type 1 tank connection device. The LP gas tank must also have a safety relief
device that has a direct connection with the vapor space of the tank.
z The tank supply system must have a means for vapor withdrawal.
z The LP gas tank used must have a collar to protect the tank valve.
z Never connect an unregulated LP gas tank to your gas grill. The gas regulator assembly supplied
with your gas grill is adjusted to have an outlet pressure of 11”water column (W.C.) for connection
to an LP gas tank. Only use the regulator and hose assembly supplied with your gas grill.
Replacement regulators and hose assemblies must be those specified by Richman.
z Have your LP Gas dealer check the release valve after every filling to ensure it remains free of
defects.
z Always keep the LP gas tank in an upright position. Do not subject the LP gas tank to excessive
heat.
z Never store an LP gas tank indoors. If you store your gas grill indoors, always disconnect the LP
gas tank first and store it safely outside.
z LP gas tanks must be stored outdoors in a well-ventilated area and out of the reach of children.
z Disconnected LP gas tanks must not be stored in a building, garage, or any other enclosed area.
z The regulator and hose assembly can be seen after opening the door (if applicable) and must be
inspected before each use of the grill. If there is excessive abrasion or wear or if the hose is cut, it
must be replaced prior to using the grill again.
z Never light your gas grill with the lid closed or before checking to ensure the burner tubes are fully
seated over the gas valve orifices.
z
Never allow children to operate your grill. Do not allow children or pets to play near your grill
.
18
RM310
3+1 burners gas grill
z Use of alcohol or drugs may impair the ability to assemble and operate the appliance.
z Keep a fire extinguisher readily accessible. In the event of an oil or grease fire, do not attempt to
extinguish with water. Use a type B extinguisher or smother with dirt, sand, or baking soda.
z In the event of rain, cover the grill and turn off the burner and gas supply.
z Use your grill on a level, stable surface and ensure the locking casters are locked before use.
z Do not leave the grill unattended when in use.
z Do not move the appliance when in use.
z Allow the grill to cool before moving or storing.
z Do not use your grill as a heater.
z This grill is not intended to be installed in or on recreational vehicles and /or boats.
Warning
A. Do not store a spare LP gas tank under or near this appliance.
B. Never fill the tank beyond 80 percent full;
C. If the information in “(a)”and “(b)” is not followed exactly, a fire causing death or serious injury may
occur.
It is very important to keep your appliance’s clear and away from any combustible materials.
Maintain at least 24 inches of clearance from sides and back and do not use under overhead
combustible construction.
19
RM310
3+1 burners gas grill
NO overhead combustible
construction
Notes about LP Gas Tank Exchange Programs
z Many retailers that sell grills offer you the option of replacing your empty LP gas tank through an
exchange service. Use only those reputable exchange companies that inspect, precision fill, test
and certify their tanks. Exchange your tank only for an OPD safety feature equipped tank as
described in the LP gas tank section of this manual.
z Always keep new and exchanged LP gas tanks in an upright position during use, transit or storage.
z Leak test new and exchanged LP gas tanks BEFORE connecting one to your grill.
Testing for gas leak
z Test all connections for gas leaks before first use, at the beginning of each new season, or when
gas cylinder was changed.
z Make sure procedure is carried our in well ventilated area and never in a presence of flame, sparks
or heat source. If you smell gas, never attempt to light the grill.
z Make sure that all temperature knobs on the grill are in the OFF position.
z Open the gas valve of the gas cylinder and/or the pressure regulator.
z Test all connections for leaks. For testing use a half water/half soap solution. Apply the solution to
the connection points with a brush.
20
RM310
.
3+1 burners gas grill
z If the bubbles occur, immediately turn off the gas supply on the valve of the gas cylinder. Tighten
all connections again and repeat the test.
z If gas bubbles still occur, do not use the grill and contact your retailer.
Warning
Never check for gas leaks using a match or any other open flame, Risk of explosion.
Warning
When your gas cylinder is empty, do not try to refill it by yourself but bring it back to an authorized
reseller who will safely refill it or exchange it.
Regulator and LP Cylinder Connections
Warning
The gas pressure regulator and hose assembly provided with this outdoor cooking appliance must be used
This regulator is set for an outlet pressure of 11 inches water column.
Regulator:
Your regulator is equipped with a Q.C.C. Type 1 quick connect system. It will not allow gas to flow until
a positive seal has been made. It has a thermal element that will shut off the gas flow if the
temperature reaches 240 degrees F (115 degrees C). It also has a flow-limiting device that will restrict
the flow of gas to 10 cubic feet per hour (0.28 cubic meters per hour).
TO CONNECT THE CYLINDER TO THE REGULATOR AND HOSE
1. Be sure the LP cylinder is “OFF” by turning the hand wheel clockwise until it stops.
2. Place the cylinder into the base cabinet shelf of the grill with the valve facing outward and secure with
the cylinder support ring.
3. Be sure all burner controls are turned to the “OFF” position.
4. Remove the safety cap from the cylinder valve.
5. Center the nipple of the regulator into the cylinder valve.
6. Turn the black nut clockwise until it stops.
21
RM310
3+1 burners gas grill
Hand Tighten Only. Do Not Use A Wrench.
CAUTION: When the appliance is not in use the gas must be turned off at the tank.
Flow Limiting Valves on LP Gas Tanks
Your LP gas tank is equipped with a flow limiting valve that will restrict the flow of gas due to a sudden
change in pressure. This can often activate without your knowledge. You will notice among other things
that your grill does not get as hot as it should, will take longer to heat up, or you may not be able to
light all burners. If you notice any of the above, then you should reset the valve and clear your gas line.
To do this
1. Ensure the LP gas tank valve is OFF.
2. Disconnect the regulator from the LP gas tank.
3. Open all burner control knobs including the side burner to Hi/Light at the same time.
4. Close all burner control knobs to OFF.
5. Let the LP gas tank stand for at least 10 minutes.
6. Reconnect the regulator assembly to the LP gas tank.
7. Slowly, meaning about 1/4 turn at a time, turn on the LP gas valve.
8. Follow the burner lighting procedures to light the burner farthest away from the gas source.
9. The flow limiting valve should now be reset.
This flow limiting valve is triggered by sudden changes in pressure. This can be caused by a leak, faulty
connection of the regulator to the LP gas tank, turning on the LP gas tank valve too quickly, or turning
the burners off by turning the LP gas tank valve off before turning the burner control knobs to off. Note:
always turn off your burners using the burner control knobs first before turning the LP gas tank valve off.
Transportation and Storage
1. Place a dust cap on the cylinder valve outlet whenever the cylinder is not in use. Only install the type
of dust cap on the cylinder valve outlet that is provided with the cylinder of propane valve. Other types
of caps or plugs may result in leakage.
2. Always transport your cylinder in an upright position.
3. Do not smoke when transporting your cylinder.
Disconnecting A Liquid Propane Gas (LPG) Tank From Your Grill
Make sure the burner valves and LP gas tank valve are off. (Turn clockwise to close.)
Detach the hose and regulator assembly from the LP gas tank valve by turning the quick coupling nut
22
RM310
3+1 burners gas grill
counterclockwise
z
Operating instructions
Warning
Before using the gas grill, make sure that you have read and understood all safety instruction and
warning in this manual!
Set up
z This gas grill is only intended for outdoor use. Place the grill in a well-ventilated location.
z Make sure that there are no flammable objects near or over the grill, Keep the gas grill at least
meter away from flammable objects.
z Do not place the grill under a pavilion, sun umbrella or similar objects.
Burn-off procedure
z Before using the gas grill for the first time, burn-off residues of foreign matter remaining from the
manufacturing process.
z With hood open, operate the gas grill at high temperature about 10-15mins(Igniting the grill)
z After all residues are burned, turn off the unit, allow it to cool down and clean(Cleaning and care)
Igniting the grill
z Unscrew the lid of the battery compartment and insert a battery with the minus side first into the
battery compartment. Screw the lid onto the battery compartment again. Use this method to
replace the battery, when the battery is low and the spark weak.
z Openthelidofthegrill.MakesurethatgasvalveknobsareintheOFF
position
HIGH HIGH HIGH
LOWLOWLOW
z Open the valve of the gas cylinder.
z Keep your face and body as far away from the grill as possible while igniting.
z Push and turn the valve knob to the IGNITE/HI position, press the ignition button down, until you
hear a click. Repeat 3 or 4 times until the burner lights.
z If the grill does not ignite right away, wait for 5 minutes to give the gas time to disperse.
z After the burner has been ignited, ignite the other burners using the valve knobs. Push each one
23
RM310
3+1 burners gas grill
and set it to the IGNITE/HI position to ignite it. All burners can be used together or in any
preferable combinations.
z Adjust the heat by turning the valve knob(s) between LO and IGNITE/HI position.
Igniting the gas grill with a match
1. Open the lid.
2. Ensure all burners are in the “OFF” position.
3. Slowly turn on the gas at the LP cylinder valve if it is not already on.
4. Place a match in the match light stick. This is located in the inner cabinet door.
5. Use the stick to slide the lit match through the cooking grates and the front of the heat diffuser to the
burner you wish to light.
6. Press and turn the burner control knob to “HI/LIGHT”. Continue to push in and hold up to 5 seconds
or until the burner lights.
7. If the burner does not light within 5 seconds, turn the burner control knob to
“OFF”. Wait 5 minutes for gas to clear, and try again.
8. When lit, turn the control knob to the desired heat setting.
MANUALLY LIGHTING THE SIDE BURNER
1.Openthesideburnercover.
2. Ensure the side burner control knob is in the “OFF” position as well as any main burner not in use.
3. Slowly turn on the gas if it is not already on.
4. Strike the match, and place near the top of the burner.
5.Turnthesideburnercontrolknobto“HI/LIGHT”
6. If the burner does not light within 5 seconds, turn the burner control knob to “OFF”. Wait 5 minutes
for the gas to clear, and try again.
7. When lit, turn the side burner control knob to its desired setting
24
RM310
3+1 burners gas grill
Appearance of the flame
z The burner flame should appear blue and stable as shown pictures. There should be no yellow
sparks, loud noise nor should it be raised up from the nozzle.
z A yellow flame mans that there is not enough oxygen supply. Loud noises and a flame raised up
from the nozzle means that there is too much oxygen.
z Check the appearance of the burner flame prior to each use. Should deviations be present,
contact a gas specialist to reset the grill.
Turning off the gas grill
z After each use, turn the temperature knobs to OFF position and let the gas grill cool down on this
position for about 5 minutes. Make sure that the cover is open at this time.
z Close the valve on the gas cylinder. Wait until the gas has completely cooled off before closing the
cover.
z If you do not use the grill for a longer period of time, disconnect the gas cylinder from the grill and
store it in a safe location.
z Cover up your gas grill with a commercially available cover if your do not plan to use it for a longer
period of time.
25
RM310
3+1 burners gas grill
z
Cooking Tips
Before using the gas grill, brush the grill grates with cooking or vegetable oil. Use a brush with a long
handle. The juices from the food drip onto the heater during cooking and vaporize. The steam arising
from this process contributes to the taste of the food.
z Set the temperature knobs to the desired positions in order to reach your desired results.
z A more consistent result can be reached with the cover closed. In this case however, the
temperature should be set to LO.
z With the cover closed, foods such as larger pieces of meat or whole chicken can be cooked.
z When the cover is closed, heat collects inside the gas grill. Therefore, you should avoid opening it
too often as accumulated heat escapes each time and the grilling time increases as a result.
Tips regarding burning grease
z Grease and juice that drips from meat onto the heater produces short spurts of flame which also
contribute to the grilling taste.
z Make sure that not too many spurts of flame are produced, otherwise the meat could be burn.
z Before grilling meat, cut away as much fat as possible and do not use too much marinate do that
the meat does not burn.
z Only use meat that is suitable for grilling. Try to avoid grilling meat with too much fat.
z If a grease fire occurs, turn the temperature knobs to the OFF position. Turn off the gas supply on
the gas cylinder and wait until the fire goes out by itself.
Cleaning and Maintenance
Proper care and maintenance will keep your grill in good operating condition and prolong its life. Follow
these cleaning procedures on a timely basis and your grill will stay clean and operate with minimum
effort.
CAUTION: Be sure your grill is off and cool before cleaning, and a
cleaning your grill
lways wear protective gloves when
Cleaning the Cooking Grids
Wash your cooking grates in a mild soap and warm water solution. You can use a wash cloth, vegetable
brush, or brass bristled brush. Never use any type of steel bristled brush. Dry them when finished.
Cleaning the Flame Tamers
Wash the flame tamers periodically in a soap and warm water solution. Use a vegetable brush to remove
stubborn burnt-on cooking residue. Dry the heat diffusers thoroughly before you reinstall them into the
26
RM310
3+1 burners gas grill
firebox.
CleaningtheGreaseTrayandBox
To reduce the chance of fire, the grease tray and grease pan should be visually inspected before each
grill use. Remove any grease and wash both with a mild soap and warm water solution.
Cleaning the Inside of the Grill Lid
Grease can have a tendency to build up on the inside of the grill lid and could drip onto the deck or patio
when the lid is opened. Visually inspect the inside of the grill lid before each grill use. Remove any
grease and wash with a mild soap and warm water solution.
Annual Cleaning of the Grill Interior
Burning-off excess food after every cookout will keep it ready for instant use. We recommend you
periodically give the entire grill a thorough cleaning to minimize your risk of grease fire and keep the
grill in good shape. Follow these steps:
1. Turn all burner valves to the “OFF” position.
2. Turn the LP gas tank valve to the “OFF” position.
3. Disconnect the regulator assembly from the gas tank. Inspect the hose for cracking, cuts or any other
damage, and replace as necessary. Refer to the Parts List in this Operator’s Manual.
4. Remove and clean the cooking grates, heat diffusers, warming rack, burners, and grease tray.
5. Cover each gas valve orifice with aluminum foil.
6. Brush the inside and bottom of the grill with a fiber pad or nylon brush and wash with a mild soap
and warm water solution. Rinse thoroughly and let dry.
7. Remove aluminum foil from orifices and check each orifice for obstruction.
8. Replace the burners, ensuring the burners fit down over each valve orifice.
9. Check and clean each electrode tip. Adjust the spacing between the tips and the burner as necessary.
The space between the electrode tip and burner should be approximately 3/16”.
10. Replace the heat diffusers, grates, warming rack, and grease tray.
11. Reconnect the gas source and observe the burner flame for correct operation.
Cleaning Exterior Surfaces:
Cleaning Exterior Surfaces: Wash with a mild dish soap and warm water solution. A cloth, soft brush, or
plastic cleaning pad can be used. Rinse thoroughly and wipe dry.
Cleaning Exterior Stainless Steel Surfaces: Wash with a mild dish soap and warm water solution. Clean
and polish with a stainless steel cleaner. There are many good quality stainless steel cleaners and
polishes available. Follow the manufacturer’s directions. Always polish in the direction of the lines. Do
not allow dirt and grease to accumulate. Do not use steel wool as it will scratch the surface. Do not use
abrasive cleaners and scrubbers.
27
RM310
3+1 burners gas grill
CAUTION:
Heat, weathering, machine oils used in the manufacturing of stainless steel, and dirt can all cause
exterior stainless steel surfaces to turn tan in color. In addition, the following products and naturally
occurring substances in the outdoors will damage all stainless steel finishes. Use caution so they will not
come in contact with your grill. Immediately wash them off and dry the stainless steel should they ever
come in contact with your gas grill. They include, but are not limited to, pool chemicals (chlorine and
bromine), lawn fertilizer, ice melting salts, sea or salt water, urine, bird droppings, and tree sap.
z
Failure to comply with these instructions may result in a hazardous situation which, if not
avoided, may result in injury.
z
Keep grill area clear and free from combustible materials, gasoline and other flammable vapors
and liquids.
z
Do not obstruct the flow of air for combustion and ventilation.
z
Keep the ventilation openings of the tank enclosure cabinet free and clear of debris.
Cleaning Burner Tubes and Burner Ports
To reduce the chance of “FLASH-BACK” the procedure below should be followed at least once a month
in late summer or early fall when spiders are most active or when your grill has not been used for a
period of time.
1. Turn all burner valves and gas tank valve to off position.
2. Detach the LP gas regulator assembly from your gas grill.
3. Remove cooking grids, heat diffusers, and grease tray from the grill.
4. Remove the screws from the underside of each burner and lift the burners up and away from the
gas valve orifice.
5. Using a bent stiff wire in the shape of a hook , air hose or a bottle brush, run it through the burner
tube and inside several times to remove any debris.
6. Replace burners, see illustration below.
Step 1. Locate the burner onto the orifice.
Step 2. Secure the main burner on the back wall of fire box with 2 screws.
28
RM310
3+1 burners gas grill
z
Troubleshooting
Problem Solution
The grill does not ignite
immediately.
Pressure regulator makes noise. z Check if the ventilation opening on the pressure regulator is
The burner flame is not blue z Check if there is too much or too little air being supplied.
Ensure that the gas valves are open
z
Check if sparks are produced when igniting the grill
z
Push the temperature knob for 5 seconds before you turn it to
z
ignite the grill.
Ensure that the burners are clean.
z
Checkifthegascylinderisnotempty.
z
plugged. Unplug the opening and wait 10 minutes before
starting again.
z Check if the ventilation openings are covered up. Check the
appearance of the flames.
z Check if the burner is not misaligned.
z Reset the burner.
z Warranty
The manufacturer warrants to the original consumer-purchaser only that this product shall be free from
defects in workmanship and material after correct assembly and under normal and reasonable home use
for the period indicated below beginning on the date of purchase. The manufacturer reserves the right to
require photographic evidence of damage, or that defective parts be returned, postage and/or freight
pre-paid by the consumer, for review and examination.
29
RM310
3+1 burners gas grill
z
TUBE BURNERS: 1 year LIMITED warranty against perforation.
z
COOKING GRIDS and FLAME TAMERS: 1 year LIMITED warranty: does not
cover dropping, chipping, scratching, or surface damage.
z
STAINLESS STEEL PARTS: 1 year LIMITED warranty against perforation; does not cover
cosmetic issues like surface corrosion, scratches and rust.
z
ALL OTHER PARTS: 1 year LIMITD warranty( includes, but not limited to , valves, flame,
housing, cart, control panel, igniter, regulator, hosed)*Does not cover chipping, scratching,
cracking surface corrosion, scratches or rust.
Upon consumer supplying proof of purchase as provided herein, Manufacturer will repair of replace the
parts which are proven defective during the applicable warranty period. Parts required to complete such
repair or replacement shall be free of charge to you except for shipping costs, as ling as the purchaser is
within the warranty period from the original date of purchase. The original consumer-purchaser will be
responsible for all shipping charges of parts replaced under the terms of this limited warranty. This
limited warranty is applicable in the United States only, is only available to the original owner of the
product and is not transferable. Manufacturer requires reasonable proof of your date of purchase.
Therefore, you should retain your sales receipt and/or invoice. If the unit was received as a gift, please
ask the gift-giver to send in the receipt on your behalf, to the below address. Defective or missing parts
subject to this limited warranty will not be replaced without registration or proof of purchase. This
limited warranty applies to the functionality of the product ONLY and does cover cosmetic issues such as
scratches, dents, corrosions or discoloring by heat, abrasive and chemical cleaners or any tools used in
the assembly or installation of the appliance, surface rust, or the discoloration of stainless steel surfaces.
Surface rust, corrosion, or power paint chipping on metal parts that does not affect the structural
integrity of the product id not considered a defect in workmanship or material and is not covered by the
warranty. This limited warranty will not reimburse you for the cost any inconvenience, food, personal
injury or property damage. If an original replacement part is not available, a comparable replacement
part will be sent. You will be responsible for all shipping charges of parts replaced under the terms of
this limited warranty.
MANAFUCTURER WILL NOT PAY FOR:
z Service calls to your home
z Repairs when your product is used for other than normal, single-family household or residential
use.
z Damage resulting from accident, alteration, misuse, lack of maintenance/cleaning, abuse, fire,
flood, acts of God, improper installation, and installation not in accordance with electrical or
plumbing or misuse of product.
z Any food due to product failures.
30
RM310
3+1 burners gas grill
z Replacement parts or repair labor costs for units operated outside the United States.
z Pickup and delivery of your product.
z Postage fees or photo processing fees for photos sent in as documentation.
z Repairs to parts or systems resulting from unauthorized modification made to the product.
z The removal and/or reinstallation of your product.
z Shipping cost, standard or expedited, for warranty/non warranty and replacement parts
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
Repair or replacement of defective parts is your exclusive remedy under the terms of this limited
warranty. Manufacturer will not be responsible for any consequential or incidental damages arising from
the breach of either this limited warranty or any applicable implied warranty, or for failure or damage
resulting from acts of God, improper care and maintenance, grease fire, accident, alteration,
replacement of parts by anyone other than manufacturer, misuse, transportation, commercial use,
abuse, hostile environments(inclement weather, acts of nature, animal tampering), improper installation
or installation not in accordance with local codes or printed manufacturer instructions.
THIS LIMITED WARRANTY IS THE SOLE EXPRESS WARRANTY GIVEN BY THE MANUFACTURER. NO
PRODUCT PERFORMANCE SPECIFICATION OR DESCRIPTION WHEREVER APPEARING IS WARRANTED BY
MANUFACTURER EXPECT TO THE EXTENT SET FORTH IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTY PROTECTION ARISING UNDER THE LAWS OF ANY STATE, INCLUDING IMPLIED WARRANTY
OF MERCHANTABILITY IR FITNESS FOR A PARTUCULAR PUROSE OR USE, IS HEREBY LIMITED IN
FURATION TO THE DURATION OF THIS LIMITED WARRANTY.
Neither dealers nor the retail establishment selling this product has any authority to make any additional
warranties or to promise remedies in addition to or inconsistent with those stated above. Manufacturer’s
maximum liability, in any event, shall not exceed the documented purchase price of the product paid by
the original con summer. This warranty only applies to units purchased from an authorized retailer and
or re-seller. NOTE: Some states do not allow an exclusion or limitation of incidental or consequential
damages, so some of the above limitations or exclusions may not apply to you; this limited warranty
gives you specific legal rights as set for herein. You may also have other right which vary from state to
state.
If you wish to obtain performance of any obligation under this limited warranty, you should
write to:
MAXUM Holding Co., LTD(USA)
13931 Central Avenue Suite 200 Chino, CA. 91710
All consumer returns, parts orders, general questions, and troubleshooting
31
RM310
3+1 burners gas grill
Assistance can be acquired by calling1-866-898-8187
Customer Service Email Address: customerservice@maxumholding.com
Website Warranty Registration: www.maxumholding.com (RICHMAN Grills Tab)
32
Loading...
