MSI-7300 Dyna-Link 2
Digital Tension Dynamometer
CRANE SCALES
Standard Features
• Tension dynamometer with six-digit, 1.00 in (25.4 mm) LCD display
• Two C alkaline batteries for capacities up to 10,000 lb (5,000 kg)
• Two D alkaline batteries for capacities 25,000 lb (12,500 kg) and above
Additional Options
(Contact MSI for application consultation)
• Crosby® top and bottom shackles
• Portable transport case
• Serial output cable
www.ricelake.com | Phone: 800-472-6703
356
• Rugged remote control (control for Off, Zero, Tare and other functions)
• RF modem install for connectivity to MSI-8000, MSI-8000HD RF, MSI-8004HD RF remote display
(100 ft line of sight)
• Heavy capacity configurations (60 to 275 Ton)
• Audible alarm
®
• Wi-Fi or Bluetooth
communications (additional use with MSI-ScaleCore Connect (available for download
at Google Play Store))
• Potential receivers: MSI-8000, MSI-8000HD RF, MSI-8004HD RF, TranSend, LaserLight2
Part Number/Price
Part # MSI Part # Description Capacity Resolution Est. Weight Price
139162 502967-0001 MSI-7300 1,000 lb F/A 1,000 lb (500 kg) 0.5 lb (0.2 kg) 8 lb (3.6 kg) Consult
139163 502967-0002 MSI-7300 2,500 lb F/A 2,500 lb (1,250 kg) 1 lb (0.5 kg) 9 lb (4.0 kg) Consult
139164 502967-0003 MSI-7300 5,000 lb F/A 5,000 lb (2,500 kg) 2 lb (1.0 kg) 9 lb (4.0 kg) Consult
139165 502967-0004 MSI-7300 10,000 lb F/A 10,000 lb (5,000 kg) 5 lb (2.0 kg) 11 lb (5.0 kg) Consult
139166 502967-0005 MSI-7300 25,000 lb F/A 25,000 lb (12,500 kg) 10 lb (5 kg) 19 lb (8.6 kg) Consult
139167 502967-0006 MSI-7300 50,000 lb F/A 50,000 lb (25,000 kg) 20 lb (10 kg) 29 lb (13 kg) Consult
139168* 502967-0007 MSI-7300 100,000 lb F/A 100,000 lb (50,000 kg) 50 lb (20 kg) 65 lb (30 kg) Consult
Optional Configurations (for connectivity to MSI-8000 RF Remote Display) F/A
139441 503381-0001 MSI-7300 RF module 1,000 lb (500 kg) 0.5 lb (.2 kg) 8 lb (3.6 kg) Consult
139442 503381-0002 MSI-7300 RF module 2,500 lb (1,250 kg) 1 lb (.5 kg) 9 lb (4 kg) Consult
139443 503381-0003 MSI-7300 RF module 5,000 lb (2,500 kg) 2 lb (1 kg) 9 lb (4 kg) Consult
139444 503381-0004 MSI-7300 RF module 10,000 lb (5,000 kg) 5 lb (2 kg) 11 lb (5 kg) Consult
139445 503381-0005 MSI-7300 RF module 25,000 lb (12,500 kg) 10 lb (5 kg) 19 lb (8.6 kg) Consult
139446 503381-0006 MSI-7300 RF module 50,000 lb (25,000 kg) 20 lb (10 kg) 29 lb (13 kg) Consult
139447* 503381-0007 MSI-7300 RF module 100,000 lb (50,000 kg) 50 lb (20 kg) 65 lb (30 kg) Consult
159168* N/A MSI-7300 RF module 120,000 lb (60,000 kg) 50 lb (20 kg) 57 lb (26 kg) Consult
159169* N/A MSI-7300 RF module 180,000 lb (90,000 kg) 100 lb (50 kg) 74 lb (36 kg) Consult
159170* N/A MSI-7300 RF module 260,000 lb (130,000 kg) 100 lb (50 kg) 100 lb (45 kg) Consult
159171* N/A MSI-7300 RF module 380,000 lb (190,000 kg) 200 lb (100 kg) 169 lb (77 kg) Consult
Optional rugged remote
Specifications
Accuracy:
0.1% FS of rated capacity (up to 50 ton)
0.5.% FS of rated capacity (50 ton and above)
Enclosure:
NEMA Type 4, IP65, anodized corrosion-resistant finish
Material:
2024 aircraft grade aluminum
Capacities above 100 K have zinc plated enclosures
and 4340 load cell bodies
Design Overload:
200% Safe/700% Ultimate* (except where noted)
Functions:
On/Off, Zero, Hi-Speed Peak Hold, Setpoints, Total,
Tare, Auto-Off, Motion Filter
Display:
Six-digit, 1.00 in (25.4 mm) LCD
Displayable Units:
Pounds, kilograms, kilonewtons, tons, metric tons
LED Annunciators:
Function 1, Function 2, Setpoint 1, Setpoint 2
LCD Annunciators:
Net, Center of Zero, Stable, Battery Test,
Peak Hold, Total
Power:
Two C alkaline batteries for capacities
up to 10,000 lb two D alkaline batteries
for capacities 25,000 lb–100,000 lb
Operating Time:
From 150 to 300 hours in typical use depending on
unit capacity and battery configuration. Approximately
25 to 30 hours with optional RF modem link installed.
Operating Temperature:
- 40º F to 122° F (Industrial)
Calibration:
Digital
Filtering:
OFF, LO, HI selectable
Data Output:
Serial RS-232
Warranty:
Two-year limited warranty
An ISO 9001 Registered Company © 2019 Rice Lake Weighing Systems 01/19 Prices and specifications subject to change without notice. Visit ricelake.com for current prices.
Page 2
MSI-7300 Dyna-Link 2
Digital Tension Dynamometer
Part Number/Price
Part # MSI Part # Description Capacity Resolution Est. Weight Price
159172** N/A MSI-7300 RF module 550,000 lb (275,000 kg) 200 lb (100 kg) 336 lb (152 kg) Consult
®
176806 N/A MSI-7300 1,000 lb F/A with Bluetooth
176807 N/A MSI-7300 2,500 lb F/A with Bluetooth
176808 N/A MSI-7300 5,000 lb F/A with Bluetooth
176809 N/A MSI-7300 10,000 lb F/A with Bluetooth
176810 N/A MSI-7300 25,000 lb F/A with Bluetooth
176811 N/A MSI-7300 50,000 lb F/A with Bluetooth
176812 N/A MSI-7300 100,000 lb F/A with Bluetooth
176813 N/A MSI-7300 1,000 lb F/A with Wi-Fi RF 1,000 lb (500 kg) 0.5 lb (0.2 kg) 8 lb (3.6 kg) Consult
176814 N/A MSI-7300 2,500 lb F/A with Wi-Fi RF 2,500 lb (1,250 kg) 1 lb (0.5 kg) 9 lb (4.0 kg) Consult
176815 N/A MSI-7300 5,000 lb F/A with Wi-Fi RF 5,000 lb (2,500 kg) 2 lb (1.0 kg) 9 lb (4.0 kg) Consult
176816 N/A MSI-7300 10,000 lb F/A with Wi-Fi RF 10,000 lb (5,000 kg) 5 lb (2.0 kg) 11 lb (5.0 kg) Consult
176817 N/A MSI-7300 25,000 lb F/A with Wi-Fi RF 25,000 lb (12,500 kg) 10 lb (5 kg) 19 lb (8.6 kg) Consult
176818 N/A MSI-7300 50,000 lb F/A with Wi-Fi RF 50,000 lb (25,000 kg) 20 lb (10 kg) 29 lb (13 kg) Consult
176819 N/A MSI-7300 100,000 lb F/A with Wi-Fi RF 100,000 lb (50,000 kg) 50 lb (20 kg) 65 lb (30 kg) Consult
176822* N/A MSI-7300 120,000 lb F/A with Bluetooth
176823 N/A MSI-7300 180,000 lb F/A with Bluetooth
176824 N/A MSI-7300 260,000 lb F/A with Bluetooth
176825 N/A MSI-7300 380,000 lb F/A with Bluetooth
176826** N/A MSI-7300 550,000 lb F/A with Bluetooth
RF *** 1,000 lb (500 kg) 0.5 lb (0.2 kg) 8 lb (3.6 kg) Consult
®
RF *** 2,500 lb (1,250 kg) 1 lb (0.5 kg) 9 lb (4.0 kg) Consult
®
RF *** 5,000 lb (2,500 kg) 2 lb (1.0 kg) 9 lb (4.0 kg) Consult
®
RF *** 10,000 lb (5,000 kg) 5 lb (2.0 kg) 11 lb (5.0 kg) Consult
®
RF *** 25,000 lb (12,500 kg) 10 lb (5 kg) 19 lb (8.6 kg) Consult
®
RF *** 50,000 lb (25,000 kg) 20 lb (10 kg) 29 lb (13 kg) Consult
®
RF *** 100,000 lb (50,000 kg) 50 lb (20 kg) 65 lb (30 kg) Consult
®
RF *** 120,000 lb (60,000 kg) 50 lb (20 kg) 57 lb (26 kg) Consult
®
RF *** 180,000 lb (90,000 kg) 100 lb (50 kg) 74 lb (36 kg) Consult
®
RF *** 260,000 lb (130,000 kg) 100 lb (50 kg) 100 lb (45 kg) Consult
®
RF *** 380,000 lb (190,000 kg) 200 lb (100 kg) 169 lb (77 kg) Consult
®
RF *** 550,000 lb (275,000 kg) 200 lb (100 kg) 336 lb (152 kg) Consult
CRANE SCALES
176827 N/A MSI-7300 120,000 lb F/A with Wi-Fi RF 120,000 lb (60,000 kg) 50 lb (20 kg) 57 lb (26 kg) Consult
176828 N/A MSI-7300 180,000 lb F/A with Wi-Fi RF 180,000 lb (90,000 kg) 100 lb (50 kg) 74 lb (36 kg) Consult
176829 N/A MSI-7300 260,000 lb F/A with Wi-Fi RF 260,000 lb (130,000 kg) 100 lb (50 kg) 100 lb (45 kg) Consult
176830 N/A MSI-7300 380,000 lb F/A with Wi-Fi RF 380,000 lb (190,000 kg) 200 lb (100 kg) 169 lb (77 kg) Consult
176831 N/A MSI-7300 550,000 lb F/A with Wi-Fi RF 550,000 lb (275,000 kg) 200 lb (100 kg) 336 lb (152 kg) Consult
* 500% Ultimate overload
** 440% Ultimate overload
*** Bluetooth modems only work with certain Android devices. Please contact MSI for potential applications.
Options/Accessories
Part # MSI Part # Description Est. Weight Price
151357 10541 Shackle anchor, bolt type 3.25 ton for 500 lb-5,000 lb unit 3 lb (1.4 kg)/pair Consult
151355 10538 Shackle anchor, bolt type 6.5 ton for 10,000 lb unit 6 lb (2.7 kg)/pair Consult
141992 10539 Shackle anchor, bolt type 17 ton for 25,000 lb unit 39 lb (17.7 kg)/pair Consult
151356 10540 Shackle anchor, bolt type 25 ton for 50,000 lb unit 63 lb (28.6 kg)/pair Consult
146336 23650-0050 Shackle anchor, bolt type 55 ton for 100,000 lb unit 180 lb (82 kg)/pair Consult
151359 N/A Shackle anchor, bolt type 85 ton for 180,000 lb unit 206 lb (93 kg)/pair Consult
151360 N/A Shackle anchor, bolt type 120 ton for 260,000 lb unit 225 lb (102 kg)/pair Consult
151361 N/A Shackle anchor, bolt type 175 ton for 380,000 lb unit 665 lb (590 kg)/pair Consult
151358 N/A Shackle anchor, bolt type 250 ton for 550,000 lb unit 1,300 lb (318 kg)/pair Consult
139381 503208-0001 MSI-8000 RF remote display (requires MSI-7300 equipped with optional RF modem) 5 lb (2.25 kg) Consult
153591 N/A MSI-8000HD RF remote display, A/C powered with tilt stand 5 lb (2.25 kg) Consult
165313 N/A
145076 14317 Transport crate for 25,000 lb and 50,000 lb capacity unit 35 lb Consult
145073 14311 Transport crate for 100,000 lb capacity unit 42 lb Consult
139470 503414-0002 RS-232 serial cable for MSI-7300 1 lb (0.45 kg) Consult
178004 N/A LaserLight2, 4 in (101 mm) six-digit RF scoreboard 21 lb (10 kg) Consult
178006 N/A LaserLight2, 6 in (152 mm) six-digit RF scoreboard 37 lb (17 kg) Consult
149549 503486-0001 Universal 115/ 230 VAC 50/60 Hz (NA plug standard) battery charger for MSI-8000 remote display 3 lb (1.4 kg) Consult
182223 12V car charger adapter for MSI-8000 1 lb Consult
173014 Rugged remote control N/A Consult
150964 503489-0001 RS-232 13 ft (4 m) serial cable for MSI-8000 1 lb (0.45 kg) Consult
139438 N/A Audible set point N/A Consult
149550 503486-0002 Battery charger for MSI-8000 EC plug N/A Consult
Heavy duty pelican transport case with precision cut
Heavy duty foam for 500 lb-10,000 lb capacity units
10 lb Consult
