MSI-4260 Port-A-Weigh
CRANE SCALES
Standard Features
• Crane unit with five-digit, 1.2 in (30 mm) LED display
• Top lifting eye or shackle, bottom thrust bearing swivel hook
• 12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz
battery charger (NA plug standard)
Additional Options
(Contact MSI for application consultation)
• Rugged remote control (control for Off, Zero, Tare and other functions)
• RF modem install for connectivity to MSI-8000, MSI-8000HD RF,
www.ricelake.com | Phone: 800-472-6703
MSI-8004HD RF remote display (100 ft line of sight)
• NTEP Certified configuration
• Anti-heat shielding for high temperature applications
• Substitute bottom swivel hook with shackle
• Oversized top lifting eye or shackle
• Oversized bottom hook
• Universal direct power supply; 85-265 VAC, 47–440 Hz / 130–300 VDC
• Low headroom top adapter
• Audible alarm
®
• Wi-Fi or Bluetooth
communications (additional use with MSI-ScaleCore Connect
(available for download at Google Play Store))
• Potential receivers: MSI-8000, MSI-8000HD RF, MSI-8004HD RF, TranSend, LaserLight2
• Custom top and bottom interfaces
• Factory Mutual and ATEX approved Intrinsically Safe models available
Approvals
Optional
Optional
Specifications
Accuracy:
± (0.1% +1 d) of applied load
Resolution:
3,000 to 5,000 d standard (up to 10,000 d available)
Enclosure:
NEMA Type 4, IP66 marine grade 356 alloy anodized
cast aluminum
Lifting Eye, Shackle & Hook:
Crosby® or equal with 360° thrust-bearing swivel hook
Design Overload:
200% Safe / 500% Ultimate (except where noted)
Functions:
Power: Turns unit on or off
Zero: Zeros applied load up to 100% of capacity
(limited range in NTEP Certified configuration)
Tare: Tares applied load and displays weight in Net
mode F1: Programmable as test, units, net/gross, total
and peak hold
Display:
Five-digit, 1.2 in (30 mm) LED with programmable
brightness control
Displayable Units:
Pounds or kilograms selectable
Annunciators:
COZ, Net, Gross, Total, Peak, Low Battery, lb/kg,
Motion, Setpoints
Power:
12 volt rechargeable battery. 115/230 VAC battery
charger is included
Operating Time:
Up to 200 hours between charging with typical use,
less with RF Modem option
Operating Temperature:
-40º F to 122° F (Industrial)
Auto-Off Mode:
Select for 15, 30, 45 minutes, 1 hour or Off
Auto Sleep Mode:
Power down during non-use and power up with
weight change or any key press
Service Counters:
Counts number of lifts over percentage of capacity and
lifts over capacity
Calibration:
Digital
Filtering:
OFF, LO, HI-1, HI-2 selectable
Warranty:
One-year limited warranty
Approvals:
NTEP CC 89-090 - 500 lb-2,000 lb (250 kg-1,000 kg)
NTEP CC 89-090A1 - 5,000 lb-70,000 lb (2,000 kg-
35,000 kg)
344
Optional rugged remote
An ISO 9001 Registered Company © 2019 Rice Lake Weighing Systems 01/19 Prices and specifications subject to change without notice. Visit ricelake.com for current prices.
MSI-4260 Port-A-Weigh
Part Number/Price
Part # MSI Part # Description Capacity Resolution Est. Weight Price
139460 503413-0001 MSI-4260B 500 lb F/A 500 lb (250 kg) 0.2 lb (0.1 kg) 53 lb (24 kg) Consult
139461 503413-0002 MSI-4260B 2,000 lb F/A 2,000 lb (1,000 kg) 1.0 lb (0.5 kg) 53 lb (24 kg) Consult
139462 503413-0003 MSI-4260B 5,000 lb F/A 5,000 lb (2,500 kg) 1.0 lb (0.5 kg) 62 lb (28 kg) Consult
139463 503413-0004 MSI-4260B 10,000 lb F/A 10,000 lb (5,000 kg) 2.0 lb (1.0 kg) 62 lb (28 kg) Consult
139464 503413-0005 MSI-4260B 20,000 lb F/A 20,000 lb (10,000 kg) 5.0 lb (2.0 kg) 105 lb (47 kg) Consult
139465 503413-0006 MSI-4260B 30,000 lb F/A 30,000 lb (15,000 kg) 10 lb (5.0 kg) 125 lb (55 kg) Consult
139466* 503413-0007 MSI-4260B 50,000 lb F/A 50,000 lb (25,000 kg) 10 lb (5.0 kg) 235 lb (106 kg) Consult
139467** 503413-0008 MSI-4260B 70,000 lb F/A 70,000 lb (35,000 kg) 20 lb (10 kg) 270 lb (121 kg) Consult
139468*** 503413-0009 MSI-4260B 100,000 lb F/A 100,000 lb (50,000 kg) 20 lb (10 kg) 420 lb (189 kg) Consult
Options/Accessories
Part # MSI Part # Description Est. Weight Price
150971 503508-0001
139381 503208-0001 MSI-8000 RF remote display (requires MSI-4260 equipped with RF modem option 2) 5 lb (2.25 kg) Consult
173014 N/A RF rugged remote control (requires MSI-4260 equipped with RF modem) N/A Consult
153591 N/A MSI-8000HD Remote Display, AC power and tilt bracket option 3 lb Consult
159221 N/A Universal crane scale transport cart 180 lb (82 kg) Consult
178004 N/A LaserLight2, 4 in (101 mm) six-digit RF scoreboard 21 lb (10 kg) Consult
178006 N/A LaserLight2, 6 in (152 mm) six-digit RF scoreboard 37 lb (17 kg) Consult
Consult N/A AC direct power supply Consult
Consult N/A Audible set point alarm Consult
Consult N/A Anti-heat shield Consult
152123 N/A Retrofit kit 4260 to 4260B 8 lb Consult
176956 N/A Option kit, 4260B Wi-Fi RF 0 lb Consult
Consult N/A Option kit, 4260B Bluetooth
Accessories
150367 D00559-0004 Battery assembly, 12 V rechargeable 7 lb (3 kg) Consult
140994 Battery assembly Consult
167777 Battery assembly, 12 V Consult
170606 Battery charger 12 V SLA Consult
138006 502221-0001 Universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard) 4 lb (2 kg) Consult
138007 502221-0002 Universal 115/230 VAC, 50/60 Hz battery charger (UK plug standard) 4 lb (2 kg) Consult
138008 502221-0003 Universal 115/230 VAC, 50/60 Hz battery charger (EC plug standard) 4 lb (2 kg) Consult
149549 503486-0001 Universal 115/ 230 VAC 50/60 Hz (NA plug standard) battery charger for MSI-8000 remote display 3 lb (1.4 kg) Consult
4260 Sub Hook with Shackle
Consult N/A 500 to 10,000 lb, 6.5 ton shackle NC
Consult N/A 20,000 to 30,000 lb, 17 ton shackle NC
Consult N/A 50,000 lb, 25 ton shackle Consult
Consult N/A 70,000 lb, 40 ton shackle Consult
Consult N/A 100,000 lb, 55 ton shackle Consult
4260 Oversize Lifting Eye/Shackle
Consult N/A 500 to 10,000 lb capacity Consult
Consult N/A 20,000 to 30,000 lb capacity, adapter with 25 ton shackle Consult
Consult N/A 50,000 to 70,000 lb capacity Consult
Consult N/A 100,000 lb capacity Consult
* 490% of kg capacity
** 475% of lb capacity/430% of kg capacity
*** 450% of kg capacity
Option kit 4260B RF remote display (RF modem install for connectivity with MSI-8000 remote
display and rugged remote)
®
RF 0 lb Consult
N/A Consult
