3D IMAGING AND DIMENSIONING SYSTEM
iDimension® 100
DIMENSIONING / MAILING / PARCEL SCALES
iDimension 100 is designed for use on a workstation, table or bench in retail,
office and shipping environments. This is the first Rice Lake Weighing Systems
iDimension series product that provides all the necessary hardware for an
out-of-the-box solution.
Standard Features
• Dimensions parcels in less than 2/10
• Includes USB operator display (no PC interface required) for:
– Operator configuration and zero height feature
www.ricelake.com | Phone: 800-472-6703
– Displays dimensions, status and weight if scale is directly attached
• Requires virtually no special alignment or special handling while placing an object under the work area
• Low resolution overhead image available in .jpg or .bmp format, used for verification,
tracking and claim protection
• Converts irregular shapes like cylinders, spheres, tubes, polybags and uneven shapes to 0.5 in NTEP
Certified cubed dimensions
• Dimensions flats, less than 1.2 in height, with the use of a connected scale or flat detection located
on the iDimension 100’s base plate
• Automatic or manual operator modes:
– Automatic operating mode is the standard out of the box configuration which allows you to move
the parcel under the work area without the press of a button
– Manual operating mode is for use with custom or 3
by an attached bar code scanner, software function or demo display when interfaced to a PC
• Interfaces with most NTEP Certified shipping scales and Rice Lake BenchPro™ BP-S
• Quick assembly: Includes all necessary tools and components for a complete out-of-the-box solution and
immediate use with minimal operator training
• No additional installation of software required on your PC. When connected to a network, the embedded
firmware provides access to additional displays and configuration parameters.
• Connect to a PC and communicate directly over the network via static IP or DCHP.
Use our open web service interface to take advantage of additional built-in features like
a low resolution image of each dimension weight and more.
• Contact the factory for an up-to-date listing of 3
compatible with the iDimension Series
®
• UPS Worldship
ready – Simply connect the iDimension Series to a USB Hub. Connect your compatible
scale and cable assemblies from the USB hub to the PC’s RS-232 or USB port, cables purchased separately.
ths
of a second
rd
party software interface that can be triggered
rd
party shipping and inventory management systems
Specifications
Physical Dimensions:
Length: 25 in (63.5 cm)
Width: 14.25 in (36 cm)
Height: 63.8 in (162 cm)
Weight: 28.5 lb (13 kg)
Power Requirements:
Single power source 110-240 V external power supply,
US power cord
Object Colors:
All opaque packaging; some variances may occur with
glossy surfaces or shrink wrap
Measurement Surfaces:
Level tables and scales with flat black painted weight
platters. The background should have a contrasting
color for items to be dimensioned. Avoid polished or
glossy surfaces like stainless steel weight platters
for best performance.
Operating Temperature:
41° F to 104° F (5° C to 40° C)
Humidity:
Non-condensing
Mechanical Environment Class:
M1
Electromagnetic Class:
E1
I/O Ports:
(1) USB type A port (interface to scale or
barcode scanner)
(1) 10/100/100BASE-T Ethernet port
(interface to PC/Network)
Package Contents:
iDimension 100, assembly tools, calibration object,
USB display and US power cord
Warranty:
One-year limited warranty
Approvals:
NTEP
CE
FCC
OIML
MID
382
An ISO 9001 Registered Company © 2019 Rice Lake Weighing Systems 01/19 Prices and specifications subject to change without notice. Visit ricelake.com for current prices.
3D IMAGING AND DIMENSIONING SYSTEM
iDimension® 100
NTEP Certified Measurement Ranges - Cube
Min (In) Max (In) Division (in)
Length 5.6 48 0.2
Width 5.6 28 0.2
Height 2.4 28 0.2
NTEP Certified Measurement Ranges - Irregular
Min (In) Max (In) Division (in)
Length 6 48 0.5
Width 6 28 0.5
Height 6 28 0.5
Note: Minimum and maximum NTEP Certified capabilities do not reflect non-NTEP Certified
performance specifications. Contact factory for more assistance.
OIML/MID Certified Measurement Range - Cube
Min (CM) Max (CM) Division (CM)
Length 12 80 0.5
Width 10 60 0.5
Height 5 70 0.5
OR
Length 12 120 0.5
Width 10 75 0.5
Height 5 30 0.5
Part Numbers/Price
Part # Description Capacity Dimensions Est. Weight Price
170654 iDimension 100 – – 44 lb Consult
181154 iDimension system (UPS Worldship Compatible), includes scale & USB hub kit – – – Consult
Options/Accessories
184585 BP-S USB shipping scale with painted mild steel weight platter 150 x 0.05 lb (75 x 0.02 kg) 12 x 14 in 17 lb Consult
182994 BP-S USB shipping scale with painted mild steel weight platter 150 x 0.05 lb (75 x 0.02 kg) 12 x 16 in 31 lb Consult
182392 BP-S USB shipping scale with painted mild steel weight platter 100 x 0.02 lb (50 x 0.01 kg) 18 x 18 in 63 lb Consult
182379 BP-S USB shipping scale with painted mild steel weight platter 150 x 0.05 lb (75 x 0.02 kg) 18 x 18 in 63 lb Consult
182383 BP-S USB shipping scale with painted mild steel weight platter 300 x 0.1 lb (150 x 0.05 kg) 18 x 18 in 63 lb Consult
182396 BP-S USB shipping scale with painted mild steel weight platter 300 x 0.1 lb (150 x 0.05 kg) 20 x 20 in 76 lb Consult
182400 BP-S USB shipping scale with painted mild steel weight platter 300 x 0.1 lb (150 x 0.05 kg) 24 x 24 in 131 lb Consult
180771 Kit, USB Hub for use with BenchPro scale and UPS Worldship Compatibility – – – Consult
180007 Kit, USB Hub for use with bar code scanner and scale – – – Consult
176307 QuickScan QD2131 bar code scanner with USB cable – – 4 lb Consult
179081 Kit, Cable Assy. PC Interface, RS-232 – – – Consult
179083 Kit, Cable Assy. PC Interface, USB – – – Consult
Replacement Parts
188098 iDimension 100 USB display – – – Consult
188103 iDimension 100/XL power supply, 50 W 110/230 VAC and US power cord – – – Consult
181246 iDimension 100 main head with firmware – – – Consult
DIMENSIONING / MAILING / PARCEL SCALES
BenchPro BP-S with painted mild steel weight platter
