Rice Lake Weighing Systems 920i Operating Manual

Download

Page 1

Programmable Indicator/Controller

Disponible

en Español

Visite ricelake.com/spanish

para ver todos los materiales

RLWS disponibles en Español

Technical Manual

Version 5

July 17, 2019

PN 67887 Rev G

Page 2

An ISO 9001 registered company

Rice Lake Weighing Systems

is a registered trademark of

Rice Lake Weighing Systems.

All other brand or product names within this publication are trademarks or

registered trademarks of their respective companies.

All information contained within this publication is, to the best of our knowledge, complete and

accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make

changes to the technology, features, specifications and design of the equipment without notice.

The most current version of this publication, software, firmware and all other product

updates can be found on our website:

www.ricelake.com

Page 3

Technical training seminars are available through Rice Lake Weighing Systems. Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department.

Contents

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2.1 Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2.2 Interface Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2.3 LED Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.4 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.4.1 Option Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.4.2 Expansion Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.4.3 Relay Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4.4 DC Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4.5 Outdoor Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.1 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3 Indicator Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.1 Gross/Net Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.2 Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.3 Zero Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.4 Acquire Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.5 Keyed Tare (Preset Tare) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.6 Remove Stored Tare Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3.7 Print Ticket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.4 Accumulator Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.5 Softkey Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.6 USB Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.7 Contrast Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.8 Hardware and Firmware Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.2 Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.2.1 Remove Back Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.2.2 Install Back Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.3 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.3.1 Sealed USB Connectors – Optional. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.3.2 Load Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.3.3 Serial Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.3.4 USB Communications (Port 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.3.5 Keyboard Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.3.6 Digital I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.4 Ground Cables/Wires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.4.1 Stripping Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.5 Installing Option Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.6 Expansion Board Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Page 4

920i Programmable Indicator/Controller

Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars

3.6.1 Expansion Board Serial Port Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.7 CPU Board Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.8 Battery Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.8.1 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.9 Parts Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.9.1 LED Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.10 Replacement Parts Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.0 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.1 iRev™ Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.2 Serial Command Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.3 Configuration Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.4 Front Panel Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.5 Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.6 Scales Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.6.1 Digital Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.6.2 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.6.3 Unit Conversion Factors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.6.4 Calibration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.7 Serial Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.7.1 Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.7.2 Port 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.7.3 Port 2 with Serial Interface Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.7.4 Port 2 with USB Interface Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4.7.5 Port 3 and 4 Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.7.6 RS-485 Port Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.7.7 Local/Remote Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.7.8 Custom Stream Formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.8 Feature Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.8.1 Contact Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

4.8.2 Regulatory/Industrial Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

4.8.3 Regulatory Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4.9 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

4.10 Setpoints Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4.11 Digital I/O Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4.12 Analog Output Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4.13 Fieldbus Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4.14 Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

5.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.1 Gravity Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.2 Front Panel Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.2.1 Five-Point Linearization (WLIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

5.2.2 Rezero Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.3 Serial Command Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.4 iRev Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

6.0 iRev . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

6.1 Install iRev Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

6.2 Open iRev . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

ii Visit our website www.RiceLake.com

Page 5

Contents

6.3 Saving and Opening Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

6.4 Hardware Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

6.5 Configuring Scales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

6.5.1 Configuring Other Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

6.5.2 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

6.6 Configuring the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

6.7 Connecting to the Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

6.7.1 Download to Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

6.7.2 Upload Configuration to iRev . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

6.8 Installing Firmware Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

7.0 USB Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

7.1 USB Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

7.2 Connecting a USB Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

7.3 Using USB Hubs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

7.4 Disconnecting a USB Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

7.5 Loading Configuration Files and Databases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

7.5.1 Loading Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

7.5.2 Loading Database Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

7.6 Saving Configuration Files and Databases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

7.7 Loading New Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

8.0 Print Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.1 Print Formatting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.1.1 General Weight Data Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.1.2 Accumulator Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

8.1.3 Truck Mode Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

8.1.4 Setpoint Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

8.1.5 Auditing Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

8.1.6 Formatting and General-Purpose Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

8.1.7 User Program-Dependent Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

8.1.8 Alert Format Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

8.2 LaserLight Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.3 Default Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.4 Customizing Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

8.4.1 Using iRev . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

8.4.2 Using the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

8.4.3 Using Serial Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

9.0 Truck Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

9.1 Using the Truck Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

9.2 Using the Truck Regs Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

9.3 Weigh-In Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

9.4 Weigh-Out Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

9.5 Single-Transaction Tare Weights and IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

10.0 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

10.1 Batch and Continuous Setpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

10.2 Setpoint Menu Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

10.3 Batch Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

10.4 Batching Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Page 6

920i Programmable Indicator/Controller

Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars

11.0 Serial Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

11.1 The Serial Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

11.1.1 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

11.1.2 USB Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

11.1.3 Reporting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

11.1.4 Clear and Reset Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

11.1.5 Parameter Setting Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

11.1.6 Normal Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

11.1.7 Batching Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

11.1.8 Database Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

11.2 Widget Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

11.2.1 Scale Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

11.2.2 Bitmap Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

11.2.3 Bargraph Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

11.2.4 Label Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

11.2.5 Numeric Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

11.2.6 Symbol Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

12.0 Maintenance/Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

12.1 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

12.1.1 Option Card Diagnostic Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

12.1.2 Using the HARDWARE Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

12.1.3 User Program Diagnostic Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

12.1.4 Using the XE Serial Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

13.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

13.1 Total Scale Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

13.2 Serial Scale Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

13.3 Stream Formatting Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

13.3.1 Toledo 8142 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

13.3.2 Cardinal 738 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

13.3.3 Weightronix WI -120 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

13.4 Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

13.5 Audit Trail Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

13.5.1 Displaying Audit Trail Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

13.5.2 Printing Audit Trail Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

14.0 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

15.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

15.1 Dimension Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

15.2 Printed Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

iv Visit our website www.RiceLake.com

Page 7

Introduction

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

1.0 Introduction

This manual is intended for use by service technicians responsible for installing and servicing the 920i Programmable Indicator/ Controller. This manual applies to Version 5+ of the 920i software, which is compatible with both the serial interface and USB

hardware versions of the indicator.

Manuals and additional resources are available from the Rice Lake Weighing Systems website at

www.ricelake.com

Warranty information can be found on the website at www.ricelake.com/warranties

1.1 Safety

Safety Signal Definitions:

Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes hazards that are exposed when guards are removed.

Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes hazards that are exposed when guards are removed.

Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.

Indicates information about procedures that, if not observed, could result in damage to equipment or corruption to and loss of data.

General Safety

Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals.

Failure to heed could result in serious injury or death.

Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by qualified service personnel only.

Do not allow minors (children) or inexperienced persons to operate this unit.

Do not operate if the enclosure is not completely assembled.

Do not use for purposes other than weight taking.

Do not place fingers into slots or possible pinch points.

Do not use this product if any of the components are cracked.

Do not exceed the rated specification of the unit.

Do not make alterations or modifications to the unit.

Do not remove or obscure warning labels.

Do not submerge.

Before opening the enclosure, ensure the power cord is disconnected from the power source.

Page 8

920i Programmable Indicator/Controller

Note

1.2 Overview

The 920i is a programmable, multi-channel digital weight indicator/controller. The configuration can be performed using:

• the front panel

• an attached USB-type keyboard (or PS/2 keyboard, if using a serial interface)

• the iRev 5 utility

Custom event-driven programs can be written with the iRite compiled with an iRite compiler utility, which can only be downloaded to the indicator. The Rice Lake Weighing Systems Web Update Utility can be used to download firmware upgrades to a PC from the Rice Lake Weighing Systems website; iRev 5 provides functions for installing the new software into the 920i.

1.2.1 Enclosures

The 920i is available in four enclosures: universal enclosure with tilt-stand, deep enclosure, panel mount enclosure and a wall mount enclosure. Stainless steel enclosures are rated for NEMA Type 4X/IP66. This manual provides assembly drawings and replacement part lists for the universal model; supplemental documentation provides information specific to the panel mount and wall mount models.

1.2.2 Interface Board

Choice of interface board (serial or USB) determines the menu structure of Port 2.

USB Interface Card – onboard USB support for a host PC and the following devices:

• one flash drive

• two printers

• and/or one keyboard (connecting more than one device requires a USB hub)

The USB interface card applies only to Port 2. Serial Interface Card – external DB-9 and DIN-8 connectors for serial connection to a PC and attachment of PS/2 remote

keyboard (cannot be used with the USB card).

language up to 512 K in program size. These programs are

1.2.3 LED Backlight

The 920i display is now shipped with an improved LED backlight, replacing the CCFL (Fluorescent) backlight. The improved LED backlight is compatible with all older CPU boards (green solder mask), however, a new power supply cable is required. For the new blue CPU board (PN 180902) a retrofit cable is not required to power the LED backlight. See Figure 3.9.1 on page 21.

The CCFL (Fluorescent) backlight is still available for purchase.

1.3 Features

• LCD display, 4.6'' x 3.4''

• Selectable character sizes from 0.25'' to 1.2''

• 60 configurable operator prompts

• Display up to four scale channels per screen with required Legal for Trade information

• 32 scale accumulators

• Five softkeys with 10 user-defined, 14 preset functions per screen

• 10 programmable display screens

• Millivolt calibration, 5-point linearization and geographical calibration

• NEMA Type 4X/IP66 stainless steel enclosure

• Selectable A/D measurement rate up to 960/second

• 100 setpoints, 30 configurable setpoint types

• Two slots for option cards

• 1,000-ID truck register for in/out weighing

2 Visit our website www.RiceLake.com

Page 9

• 64 K user on-board NV RAM

• User programmable 128 K flash memory

• Re-flash memory to upgrade firmware

• Power for 16, 350 ohms load cells per A/D board

• Local-remote indicators

• Multi range/interval

• Alibi™ storage

• Audit trail tracking

• Peak hold

• Rate of change

• Support for A/D scale or serial scale inputs. The maximum number of scale inputs is 28; these can be combined to represent up to 32 scale configurations

• Six digital I/O channels on main board, each configurable as input or output

• Four serial ports on main board (Ports 1–4) support duplex RS-232 up to 115200 bps. Port 2 supports hardware handshaking and remote keyboard input, o

r as a UBS Type A and Type B port. Ports 3 and 4 support 20mA output,

Port 4 supports 2-wire RS-485 communications

• Available in 115 VAC and 230 VAC North American and European versions

USB Standard Features

• USB interface card on Port 2

• The USB card is supported on PN 109549 and PN 180902 CPU boards.

• The 920i for USB interface requires firmware version 5.0 or higher

Introduction

Connector Types:

• Standard Type A: 920i connects to keyboard, ASCII font label ticket printers and flash drives

• Standard Type B: 920i connects to PC USB Interface Functions:

• Supports weigh mode and configuration mode functions

• Supports upload of databases and .920 configuration file

• Supports download of databases, .920 configuration file, iRite, COD file and firmware file

• Sanity checks for command errors

Flash Drives:

• Supports USB 2.0

• Create sub directories by unit ID and database name

• Use the root directory for generic files

Optional Wash-Down Connectors

• Sealed receptacle

• Connectors - cables

• USB cover - flash drive and receptacle

Other Features

• Configurable print formats can be defined for up to 1000 characters each. These formats are used to print gross or net weights, truck in/out weights, setpoint weights, accumulator weights, alert messages and header information. Additional print formats can be created with iRite.

• Six truck modes to store and recall weights for gross, tare, and net printing. The truck register contains fields for ID number, weight, and the transaction time and date. Weights can be stored permanently or erased at the end of the transaction.

• The setpoint engine supports 31 configurable setpoint kinds. Setpoints can be arranged in a sequential batch routine of up to 100 steps. If setpoints are configured as free running setpoints, they can be tied to program control. This allows for simultaneous batching operations to be written with the iRite language.

Page 10

920i Programmable Indicator/Controller

Note

1.4 Options

The CPU board provides two slots for installing A/D or other option cards. Additional option cards can be added using either two-card or six-card expansion boards connected to the CPU board via the expansion bus. Available option cards include:

Communication protocol cards

EtherNet/IP, DeviceNet, Profibus, Profinet, ControlNet, and Remote I/O cards must be installed in an onboard slot. They must not be installed on an expansion card.

1.4.1 Option Cards

Any of the listed option cards can be installed in Slot 2 of the CPU board or in any available slot of an attached expansion board.

Option Card PN

A/D Single Channel 68532 A/D Dual Channel 68533 Analog Output Single Channel 0-10V and 0-20mA 67602 Analog Output Dual Channel, 0-10V and 0-20 mA 103138 Serial Port Dual Channel Full Duplex RS232 and 4 Wire RS485 67604 I/O 24 Channel 67601 Memory Module 1 Meg 67600 Pulse Counter 12VDC Supply 67603 Ethernet TCP/IP Interface Card, Embedded Device Server 10/100baseT 71986 EtherNet/IP, Protocol for Allen-Bradley PLC. 87803 DeviceNet™ Interface 68541

Allen-Bradley

PROFIBUS ControlNet Right Angle BNC Connector 103136

PROFINET Converter, Ethernet Thin Server UDS-1100, 10/100 RJ45 232 Serial to Ethernet 65383 Ethernet Wireless Embedded Device Server 10/100 base-T 98057 Dual Analog input 0-10V 0-20mA With Dual Thermocouple Inputs; requires 2.05 software or higher 87697

Remote I/O Interface

DP Interface

Interface

Table 1-1. 920i Option Cards

68539

68540

187816

1.4.2 Expansion Boards

Table 1-2 lists the expansion boards available for the panel mount and wall mount enclosures. The panel mount enclosure can

accommodate a single 2-card expansion board; the wall mount enclosure supports either a 2-card or a 6-card expansion board. Any of the available option cards can be installed in any available expansion board slot.

A second 2- or 6-card expansion board can also be connected to the 920i, providing up to 14 option card slots. Consult factory for details. See Section 3.6 on page 18 for detailed information about slot and serial port assignments for expanded system configurations.

Expansion Board Part No.

2-card expansion board for panel mount enclosure, slots 3–4. Inc 2 inch, 34 pin ribbon cable and power supply cable. 71743 2-card expansion board for wall mount enclosure, DC powered. 179488 2-card expansion board for deep universal and panel mount, DC powered. 180047 2-card expansion board for wall mount enclosure, slots 3–4. Inc 24 inch, 34 pin ribbon cable and power supply cable. 69782 6-card expansion board for wall mount enclosure, slots 3–8. Inc 16 inch, 34 pin ribbon cable and power supply cable. 69783

Table 1-2. Part Numbers for 920i Expansion Boards

See Section 3.6 on page 18 for detailed information about expansion board configurations.

4 Visit our website www.RiceLake.com

Page 11

Introduction

1.4.3 Relay Options

8-, 16-, and 24-channel relay racks are available for all 920i systems. Relays can be installed internally in the wall mount enclosure; all other models require an external enclosure for the relays. Consult factory for details.

1.4.4 DC Power Supplies

Two DC power supplies are available for mobile 920i applications:

PN 97474, 12-24 VDC supply PN 99480, 10–60 VDC supply

Consult factory for more information.

1.4.5 Outdoor Display

Optional outdoor displays that are available for use of the 920i in bright, sunlit environments:

LCD Display, Transflective, CCFL B/L (PN 164375). Not compatible with CPU PN 180902. LCD Display, Transflective, LED B/L (PN 186276). See Figure 3.9.1 on page 21 for compatibility with CPU boards.

Consult factory for details.

Page 12

920i Programmable Indicator/Controller

10/20/2017

12:14PM

Select Part

SCALE #1

Start Setup Menu

Scale

0.0

Gross g

Select a Part

Accept Count:

Accept Total:

Reject Count:

Reject Total:

8910

21 20 19

2.0 Operation

2.1 Front Panel

Weight information is displayed with a graphical scale in six font sizes up to 1.2''. Up to four scale widgets can be displayed in Legal for Trade, multiple-scale applications. Display contrast can be adjusted with the LCD contrast potentiometer or CONTRAST parameter. The display can be graphically configured using iRev software.

Figure 2-1. 920i Front Panel

Item No. Description

1 Navigation Keys – used to enter values; scroll through menus 2 Enter – save entries from the numeric keypad 3 Numeric Entry – used for entering numbers or keyed tares 4 Clear – backspace when entering numbers/letters 5 Decimal – Inserts a decimal point as needed 6 Print – sends an on-demand print format out a communications port, provided the conditions for standstill are met 7 Units – switches the weight display to an alternate unit 8 Tare – performs a predetermined tare function as set in the TAREFN parameter; set in the Scale menu 9 Gross/Net – toggles the weight display between gross and net mode; if a tare value has been entered or acquired, the net value is the gross

weight minus the tare 10 Zero – sets the current gross weight to zero 11 Softkeys – keys that can be configured to provide additional operator functions 12 Display – status areas on the display are used for operator prompts and entering data; the remainder of the display can be graphically

configured for representation of a specific application 13 Standstill Symbol – scale is at standstill or within the specified motion band 14 Center of Zero Symbol – indicates that the current gross weight reading is within +/- 0.25 display divisions of the acquired zero 15 Tare Symbol – indicates that a tare has been acquired and stored in the system

• T = pushbutton tare; see Section 2.3.4 on page 7

• PT = keyed tare, see Section 2.3.5 on page 7 16 Weight Display – current weight displays 17 Units Indicator – current unit of display 18 Gross/Net Indicator – indicates whether the weight value is in Net or Gross mode 19 Scale in use – indicates the scale that is currently being read by indicator 20 Time – displays current time 21 Date – displays current date

Table 2-1. Key and Icon Descriptions

6 Visit our website www.RiceLake.com

Page 13

Operation

2.2 Operating Modes

The 920i has two modes of operation.

Weigh Mode

The indicator displays gross, net or tare weights as required, using the secondary display to indicate scale status and the type of weight value displayed. Weigh mode is the only mode in which the 920i can operate (without breaking the seal) once configuration is complete and a legal seal has been affixed the indicator.

Configuration Mode

Many of the procedures described in this manual require the indicator to be in configuration mode, including calibration. See Section 4.0 on page 24.

2.3 Indicator Operations

Basic 920i operations are summarized in this section.

2.3.1 Gross/Net Mode

If a tare value has been entered or acquired, the net value is equal to gross minus the tare value.

Press to toggle between Gross (Brutto) and Net modes. If there is no tare, the display remains in gross mode.

Annunciators at the end of the weight indicates the current mode.

2.3.2 Units

Press to toggle between primary, secondary and tertiary units.

2.3.3 Zero Scale

1. In gross mode, remove all weight from the scale and wait for to display.

2. Press . displays, indicating the scale is zeroed.

2.3.4 Acquire Tare

1. Place a container on the scale and wait for to display.

2. Press to acquire a tare weight of the container. 0 displays with Net.

2.3.5 Keyed Tare (Preset Tare)

1. Enter a value from the numeric keypad.

2. Press

. Net displays indicating the keyed tare weight is in the system.

2.3.6 Remove Stored Tare Value

1. Remove all weight from the scale and wait for to display.

2. Press (in OIML mode, press ). 0 displays with Gross.

2.3.7 Print Ticket

With displayed, press to send data to the serial port.

To print tickets using auxiliary formats, press the number key for the format and press

Example:

To print using AUXFMT2, press

2 on the numerical keypad, then .

Print.

Page 14

920i Programmable Indicator/Controller

2.4 Accumulator Functions

The accumulator must be enabled to use in weigh mode or setpoint operations.

Weight (net if a tare is entered) is accumulated when a print operation is performed by pressing , or entering a digital input or a serial command. The scale must return to zero (net zero if a tare is entered) before the next accumulation.

Display Accum softkey can be configured to display the current accumulator value. Printing while the accumulator is

The displayed or when the setpoint PSHACCUM function is enabled, uses the ACCFMT print format.

Press twice to clear the accumulator.

2.5 Softkey Operations

Softkeys are defined to provide additional operator functions for specific applications. Softkey assignments are listed on the tabs shown at the bottom of the LCD display and are activated by pressing the arrow keys below the tabs.

The displayed softkeys are determined by the indicator configuration and program. Use the FEATURE menu to enable softkeys.

Softkey Description

Time/Date Displays current time and date; allows time and date change Display Tare Displays tare value for the current scale Display Accum Displays accumulator value, if enabled, for the current scale Display ROC Displays rate-of-change value, if enabled, for the current scale Setpoint Displays a menu of configured setpoints; allows display and change of some setpoint parameters Batch Start Starts a configured batch Batch Stop Stops a running batch and turns off all associated digital outputs. Requires a batch start to resume processing Batch Pause Pauses a running batch; same as stop, but digital outputs, if on, are not turned off Batch Reset Stops a batch and resets it to the first batch step Weigh In Allows truck ID entry; generates weigh-in ticket for truck weighing applications Weigh Out Allows truck ID entry; generates weigh-out ticket for truck weighing applications Truck Regs

Unit ID Allows display or change of Unit ID Select Scale For multi-scale applications, provides a prompt to enter the scale number to be displayed Diagnostics

Alibi Allows previous print transactions to be recalled and reprinted Contrast Adjusts the screen contrast Test Future functionality Stop Sends AuxFmt1 out its configured port to prompt a red light on a LaserLight Go Sends AuxFmt2 out its configured port to prompt a green light on a LaserLight Off Sends AuxFmt3 out its configured port to turn a LaserLight red/green light off Screen Allows multiple display screens without a user program F1–F10 User-programmable keys; defined by application USB Allows the changing of USB devices (and that device’s corresponding function) while in Weigh mode More… For applications with more than five defined softkeys, the More… softkey is automatically assigned to the fifth position.

Displays truck register; allows deletion of individual or all entries; truck register can be printed by pressing the register is displayed

Provides access to diagnostic displays for attached iQUBE

Press

More… to toggle between groups of softkeys

junction boxes

Table 2-2. Configurable Softkeys

Print key while the truck

8 Visit our website www.RiceLake.com

Page 15

Operation

Note

2.6 USB Functions

With the USB interface card installed, the 920i supports a connection to a host PC and the following devices:

• one flash drive

• two printers

• and/or one keyboard

Connecting more than one device requires a USB hub.

Version 5 Rev L boards (or higher) are required for USB functionality.

USB Device Functions Supported

Host PC Data transfer of configuration files, database files and iRite programs* Flash Drive Download boot monitor and core to the indicator, data transfer of configuration files, database files and iRite programs** Printer(s) If using more than one printer, the lowest numbered USB port on the hub will determine Printer #1 Keyboard Inputs text and numeric characters * Download of boot monitor and core from a PC to the indicator is not supported.

** Transfer of iRite files from 920i to flash drive is not supported.

Table 2-3. USB devices and functions

To select the target USB device to be used, see Section 4.0 on page 24.

2.7 Contrast Adjustment

To adjust the contrast, use the CONTRAST parameter in the Features menu. Front panel adjustment can be made by assigning a softkey. This is available for CPU Board Rev H-N, PN 109549, and CPU board PN 180902.

When Port 2 has the Serial Interface option, there is also a potentiometer for contrast adjustment on interface card.

2.8 Hardware and Firmware Compatibility

• CPU board (PN 67612) revision A-G was the initial release and covered versions 1 and 2 Revision E-G had an increase in memory to support version 3

• CPU board (PN 109549) Rev H-N, supported iQube

• CPU board (PN 180902) Rev B of higher, an LED backlight, replaces the CCFL (Fluorescent) backlight

Important Information Regarding the 920i CPU Board

Beginning with Revision H, the CPU board supports only firmware 3.14 or higher. This does not affect any pre-existing user programs, contact Rice Lake Weighing Systems for performance issues.

CPU Board

Revision

Part Number 67612

A-D 1.00 1.00 2.08 N/A

E 1.10 1.00 4.00 N/A

F-G 1.12 1.00 5.XX* N/A

Part Number 109549

H 1.13 3.14 5.XX* N/A

L-N** 2.03 3.14 5.XX* 1.01

Part Number 180902

B** 2.03 3.14 5.XX* 1.01

* Refer to current release version ** Supports USB Interface

Recommended

Boot Monitor Minimum Core

Table 2-4. Hardware and Software Compatibility

and USB, and requires a minimum core of 3.14.00

Maximum

Core

Minimum USB

Version

Page 16

920i Programmable Indicator/Controller

CAUTION

WARNING

16 12

Torque backplate screws

to 15 in-lb (1.7 N-m)

IMPORTANT

3.0 Installation

This section describes procedures for connecting load cells, digital I/O and serial communications cables to the 920i. Replacement parts lists for the universal model are included for the service technician. See the 920i technical manual (PN

67887) for dimension drawings of the all models.

Electrostatic sensitive device, observe handling precautions to prevent shock or damage caused from electrostatic discharge.

Failure to heed could result in injury and or product damage.

* This unit can create an electric shock hazard. Procedures requiring work inside the indicator must be performed by

qualified service personnel only.

* The supply cord serves as the power disconnect for the 920i. The power outlet supplying the indicator must be installed

near the unit and be easily accessible.

* Use a wrist strap as a ground to protect components from electrostatic discharge (ESD) when working inside the

indicator enclosure.

3.1 Unpacking

Immediately after unpacking, visually inspect the 920i to ensure all components are included and undamaged. The shipping carton contains the indicator and a parts kit. If any parts were damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately.

3.2 Enclosure

The indicator enclosure must be opened to install option cards and to connect cables for installed option cards.

The 920i has no on/off switch. Before opening the unit, ensure the power cord is disconnected from the power supply.

3.2.1Remove Back Plate

1. Ensure power to the indicator is disconnected.

2. Place the indicator face-down on an anti-static work mat.

3. Remove the screws that hold the backplate to the enclosure body.

4. Lift the backplate from the enclosure and set it aside.

3.2.2 Install Back Plate

1. Position the back plate over the enclosure.

2. Secure with the back plate screws.

3. Torque screws to 15 in-lb (1.7 N-m), using pattern shown in Figure 3-1, to prevent distorting the back plate gasket.

Torqued screws may become less tight as the gasket is compressed during torque pattern, therefore a second torque is required using the same pattern and torque value.

10 Visit our website www.RiceLake.com

Figure 3-1. 920i Enclosure Backplate

Page 17

Installation

Note

3.3 Cable Connections

The parts kits includes cord grip plugs to prevent moisture from entering the enclosure. Use the cable grounding instructions below for wiring into the indicator. Install plugs in all unused cord grips to prevent moisture from entering the enclosure.

3.3.1 Sealed USB Connectors – Optional

For wash down environments, optional sealed USB receptacles are available for use with an optional backplate (PN 119891). For optimal cable routing, it is recommended for the Type-A connector to be on the left and the Type-B connector to be on the right side.

Part No. Description

126476 Receptacle, USB Panel Mount Sealed Circular USB Type-A, with 50 cm pigtail and Type-A end (Approx. 19.68 inches.) 124703 Receptacle, USB Panel Mount Sealed Circular USB Type-A, with 50 cm pigtail and Type-B end 124704 Receptacle, USB Panel Mount Sealed Circular USB Type-B, with 50 cm pigtail and Type-B End 125998 Receptacle, USB Panel Mount Sealed Circular USB Type-A, with 28cm Cable to 5 Pin Connector 125999 Receptacle, USB Panel Mount Sealed Circular USB Type-B, with 28cm Cable to 5 Pin Connector 124689 Dust Cap, USB Flash Drive; for use with above Receptacles 124694 Cover; for use with above Receptacles

Table 3-1. Sealed USB Connectors

To install the sealed watertight USB receptacles:

1. The hole in the backplate is notched. Align the receptacle with the notches, ensuring the key on the housing is inserted in the notch.

Figure 3-2. Sealed USB Receptacles on Backplate

2. Fasten the receptacle so it is flush with the backplate.

3. Connect the interface cables to the headers on the USB card.

4. Re-install the backplate, see Figure 3-1 on page 10.

Sealed cables are available to make a watertight connection. The same type of receptacle and cables are available for Ethernet connections.

Page 18

920i Programmable Indicator/Controller

SIG+

SIG–

JP2JP1

3.3.2 Load Cells

To attach the cable from a load cell or junction box to an installed A/D card, route the cable through the cord grip and ground the shield wire.

Remove connector J1 from the A/D card. The connector plugs into a header on the A/D card. Wire the load cell cable from the load cell or junction box to connector J1 as shown in Table 3-2.

SEN+

SEN–

EXC+

EXC–

Figure 3-3. Single-Channel A/D Card

A/D Card

Connector Pin Function

1 +SIG 2 –SIG 3 +SENSE 4 –SENSE 5 +EXC 6 –EXC

Table 3-2. A/D Card Pin Assignments

If using 6-wire load cell cable (with sense wires), remove jumpers JP1 and JP2 before reinstalling connector J1. For 4-wire installation, leave jumpers JP1 and JP2 on.

If using 6-wire load cell connections on dual-channel A/D cards, remove jumpers JP3 and JP4 for connections to J2. When connections are complete, reinstall load cell connector on the A/D card and use two cable ties to secure the load cell

cable to the inside of the enclosure.

12 Visit our website www.RiceLake.com

Page 19

Installation

LCD Contrast

DIN-8 Connector for

PS/2 Remote Keyboard

DB-9 Connector

for Port 2 / J8

3.3.3 Serial Communications

The four communications ports on the 920i CPU board support full duplex RS-232, 20 mA output or RS-485 communications at up to 115200 bps.

To attach serial communications cables:

1. Route the cable through the cord grip.

2. Ground the shield wire as described in Section 3.3.2 on page 12.

3. Remove the serial connector from the CPU board and wire to the connector.

4. Once cables are attached, plug the connector into the header on the board.

5. Use cable ties to secure serial cables to the inside of the enclosure.

Table 3-3 indicates the pin assignments for Ports 1, 3, and 4. Port 2 provides DIN-8 and DB-9 connectors for remote keyboard

attachment of PS/2-type personal computer keyboards. The DB-9 connector pin assignments for Port 2 are shown in Table 3-4. See Section 3.3.5 on page 14 for information about the PS/2 keyboard interface.

Connector Pin Signal Port

J11 1 GND 1

2 RS-232 RxD 3 RS-232 TxD

J9 1 GND / –20mA OUT 3

2 RS-232 RxD 3 RS-232 TxD 4 +20mA OUT

J10 1 GND / –20mA OUT 4

2 RS-232 RxD 3 RS-232 TxD 4 +20mA OUT 5 RS-485 A 6 RS-485 B

Table 3-3. Serial Port Pin Assignments

Serial ports are configured using the SERIAL menu. See Section 4.7 on page 35 for configuration information. An optional dual-channel serial communications expansion card, PN 67604, is available. Each serial expansion card provides

two additional serial ports, including one port that supports RS-485 communications. Both ports on the expansion card can support RS-232 or 20mA connections.

Figure 3-4. Serial Interface Board Connections

DB-9 Pin Signal

2 TxD 3 RxD 5 GND 7 CTS 8 RTS

Table 3-4. DB-9 Connector Pin Assignments

Page 20

920i Programmable Indicator/Controller

VR1

PB1

LCD

Contrast

DB-9 Connector

DIN-8

Connector

Setup

Switch

Optional

Keyboard Connector

CLK

PWR

RET

DAT

Ribbon Cable Connector

to CPU Board / J8

Type-A Connector Type-B Connector

Note

Figure 3-5. Interface Board, Top View

J4 Pin Color Signal

1 Brown Clock 2 Clear +5v 3 Yellow GND 4 Red Data

Table 3-5. J4 Pin Assignments (Optional Keyboard Connector)

3.3.4 USB Communications (Port 2)

The USB interface provides Type-A and Type-B connectors.

Compatible devices using a Type-A connector include a flash drive, keyboard, USB hub and label and ticket printers. The host PC uses a Type-B connector.

3.3.5 Keyboard Interface

Serial Interface

Serial port 2 on the 920i CPU board provides a PS/2-type keyboard interface for use with a remote keyboard. To use the keyboard interface, set the INPUT parameter for Port 2 (under the SERIAL menu) to KEYBD.

Table 3-6 on page 15 summarizes the 920i specific functions provided by the keyboard interface; most other alphanumeric and

navigational keys provide functions equivalent to those typical for PC operation. Menu parameters and serial commands that affect indicator keypad operation (including the KBDLCK, ZERONLY, and KLOCK serial commands) also affect the remote keyboard.

The keyboard interface is not hot-pluggable. Disconnect power to the 920i before plugging the keyboard cable into the Port 2 connector.

The 920i supports keyboard scan codes 1, 2, and 3.

USB Interface

The 920i USB interface board provides a type-A connection for a USB keyboard interface. To use the keyboard interface, set the DEVICE parameter for Port 2 (under the SERIAL menu) to KEYBOARD.

Table 3-6 summarizes the 920i specific functions provided by the keyboard interface; most other alphanumeric and navigational

keys provide functions equivalent to those typical for PC operation. Menu parameters and serial commands that affect indicator keypad operation (including the KBDLCK, ZERONLY, and KLOCK serial commands) also affect the remote keyboard.

14 Visit our website www.RiceLake.com

Figure 3-6. USB Interface Board Connections

Key Function

F1 Softkey 1

Table 3-6. PS/2 Keyboard Functions

Page 21

Installation

Key Function

F2 Softkey 2 F3 Softkey 3 F4 Softkey 4

F5 Softkey 5 F6 (Alt+Z) ZERO key F7 (Alt+G) GROSS/NET key F8 (Alt+T) TARE key F9 (Alt+U) UNITS key

F10 (Alt+P) PRINT key

F11 Not used F12

Print Screen Same as Print key, in both normal and

setup modes

Table 3-6. PS/2 Keyboard Functions

3.3.6 Digital I/O

Digital inputs can be set to provide several indicator functions, including keypad. Digital inputs are active low (0 VDC), inactive high (5 VDC).

Digital outputs are typically used to control relays that drive other equipment. Outputs are designed to sink, rather than source, switching current. Each output is a normally open collector circuit, capable of sinking 24 mA when active. Digital outputs are wired to switch relays when the digital output is active (low, 0 VDC) with reference to a 5 VDC supply.

J2 Pin J2 Signal

1 +5 VDC 2 GND 3 DIO 1 4 DIO 2 5 DIO 3 6 DIO 4 7 DIO 5 8 DIO 6

Table 3-7. J2 Pin Assignments (Digital I/O)

Digital inputs and outputs are configured using the DIG I/O menu. See Section 4.11 on page 49 for configuration information. An optional 24-channel digital I/O expansion card, PN 67601, is available for applications requiring more digital I/O channels. Digital I/O points can be configured to count active pulse inputs by setting them to PROGIN and using the iRite

DigInSsBbActivate handler. The fastest pulse rate that can be counted using a digital input is 10Hz (10 pulses per second). More demanding applications can use the pulse input option card (PN 67603) to count pulses in the 4–4000Hz range.

Page 22

920i Programmable Indicator/Controller

J11

PORT 1

PORT 3

J10

PORT 4

PIEZO

BUZZER

OPTION

J13

+6VDC

GND

–6VDC

EXPANSION BUS

GND

RS-232 RxD

RS-232 TxD

GND / –20mA OUT

RS-232 RxD

RS-232 TxD

+20mA OUT

RS-232 RxD

RS-232 TxD

+20mA OUT

RS-485 TxD +

RS-485 TxD −

+5VDC

GND

DIO1

DIO2

DIO3

DIO4

INTERFACE

BOARD

CONNECTION

POWER SUPPLY

SW1

SW2

JP3

DIGITAL I/O

PORT 2

OPTION CARD

CONNECTOR

OPTION CARD

CONNECTOR

OPTION CARD LOCATIONS

BATTERY

J15

BOOT

MODE

SLOT 1

SLOT 2

GND / –20mA OUT

REMOTE

SETUP

SWITCH

+5VDC

GND

DIO1

DIO2

DIO3

DIO4

DIGITAL I/O

DIO5

DIO6

Silver

side out

Shield wire (cut)

Cut insulation here for foil shielded cables

Length of foil before folding back on cable insulation

920i Rev G CPU Board PN 67612

Figure 3-7. 920i CPU Board

920i CPU Board Rev H-N, PN 109549 and PN 180902 Rev B+

3.4 Ground Cables/Wires

Except for the power cord, all cables routed through the cord grips should be grounded against the indicator enclosure.

3.4.1 Stripping Cables

Foil Insulated Cable

16 Visit our website www.RiceLake.com

1. Install the grounding clamps on an enclosure stud near the cord grip being used.

2. Secure the ground clamp with hardware included in the hardware kit. Do not tighten the screws at this time.

3. Route the cables through the cord grips and the grounding clamps to determine the cable lengths required to reach the cable connectors.

4. Mark the cables to remove insulation and shield. See Section 3.4.1.

5. Route stripped cables through the cord grips and grounding clamps.

6. Ensure the shields contact the grounding clamps and tighten the ground clamp screws.

Figure 3-8. Foil Insulated Cable

1. Strip the insulation and foil from the cable 1/2'' (15 mm) past the grounding clamp.

2. Fold the foil shield back on the cable where the cable passes through the clamp.

3. Ensure the silver (conductive) side of the foil is turned outward for contact with the grounding clamp.

Page 23

Installation

Braid

CAUTION

PULSE INPUT

CARD

DUAL A/D

CARD

Braided Shielding

Cut insulation here

Figure 3-9. Braided Insulated Cable

1. Strip the insulation and braided shield from a point just past the grounding clamp.

2. Strip another 1/2'' (15 mm) of the insulation to expose the braid where the cable passes through the clamp.

Load Cell Cable

Cut the shield wire just past the grounding clamp. Shield wire function is provided by contact between the cable shield and the grounding clamp.

3.5 Installing Option Cards

Each option card is shipped with installation instructions specific to that card.

Option cards are not hot-pluggable. Disconnect power to the 920i before installing option cards.

The general procedure for all option cards is as follows:

1. Disconnect power to the indicator.

2. Remove backplate as described in Section 3.2.1 on page 10.

3. Carefully align the option card connector with connector J5 or J6 on the CPU board.

4. Press down to seat the option card in the CPU board connector.

5. Use the screws provided in the option kit to secure the other end of the option card to the threaded standoffs on the CPU board.

6. Make connections to the option card as required.

7. Use cable ties to secure loose cables inside the enclosure.

8. When installation is complete, reassemble the enclosure as described in Section 3.2.2 on page 10.

Cable Ties

Install Option Card on the CPU Board

The 920i automatically recognizes all installed option cards when the unit is powered on. No hardware-specific configuration is required to identify the newly-installed card to the system.

Memory Card

Figure 3-10. Install Option Card

Page 24

920i Programmable Indicator/Controller

SLOT 1 SLOT 2

CPU BOARD

SLOT 3 SLOT 4

SLOT 0

SLOT 1 SLOT 2

SLOT 3 SLOT 4 SLOT 5

SLOT 6 SLOT 7 SLOT 8

CPU BOARD

SLOT 0

SLOT 9 SLOT 10

SLOT 1 SLOT 2

SLOT 3 SLOT 4 SLOT 5

SLOT 6 SLOT 7 SLOT 8

SLOT 9 SLOT 10 SLOT 11

SLOT 12 SLOT 13 SLOT 14

CPU BOARD

SLOT 0

Note

3.6 Expansion Board Configurations

Two- and six-card expansion boards allow up to fourteen option cards to be attached to the 920i. Figure 3-11 illustrates the slot numbers assigned for various combinations of two- and six-card expansion boards. A single six-card expansion board is assigned slots 3–8.

CPU Board with Two-Card Expansion Board

The maximum number of option board slots is fourteen: two onboard slots, plus two six-card expansion boards. The two-card expansion board is always placed at the end of the expansion bus. No more than one two-card expansion board can

be used in any system configuration. The panel mount enclosure can accommodate a single two-card expansion board. The wall mount enclosure can accommodate a two-card and/or a six-card expansion board. Systems using two six-card expansion boards are housed in a custom enclosure.

CPU Board with Two- and Six-Card Expansion Boards

CPU Board with Two Six-Card Expansion Boards

Figure 3-11. CPU Board with Expansion Cards

18 Visit our website www.RiceLake.com

Page 25

Installation

SLOT 1 SLOT 2

CPU BOARD

SLOT 3 SLOT 4

SLOT 0

PORT

PORT3PORT

PORTS

5–6

PORTS

7–8

PORTS

9–10

PORTS

11–12

3.6.1 Expansion Board Serial Port Assignments

Serial port numbers are reserved for each option card slot, regardless of the type of cards actually installed. Two port numbers are reserved for each slot that could contain a dual-channel serial expansion card. Table 3-8 shows the port numbers assigned to each slot.

Example: In a system with a two-card expansion board, port assignments are reserved as illustrated in Figure 3-12. If the only serial card installed in this system is in SLOT 4 of the expansion board, the system consists of serial ports 1– 4 (on the CPU board) and ports 11–12.

Figure 3-12. Serial Port Assignments, Two-Card Expansion Board

Serial Port

Slot Number

CPU board 1–4

1 5–6 2 7–8 3 9–10 4 11–12 5 13–14 6 15–16 7 17–18 8 19–20

9 21–22 10 23–24 11 25–26 12 27–28 13 29–30 14 31–32

Assignments

Table 3-8. Expansion Board Serial Port Assignments

Page 26

920i Programmable Indicator/Controller

Note

CAUTION

3.7 CPU Board Removal

To remove the 920i CPU board, use the following procedure:

1. Disconnect power to the indicator. Remove backplate as described in Section 3.2 on page 10.

2. Unplug connectors J9, J10, and J11 (serial communications), J2 (digital I/O), P1 (power supply), and connectors to any installed option cards.

3. Remove any installed option cards.

4. Remove the screws and nuts securing the CPU board.

5. Gently lift the CPU board and disconnect connectors J12 (power to display), J4 (ribbon cable), J3 (keypad connector) and the cable in J8 (Port 2 serial port).

6. Remove CPU board from the enclosure. If necessary, cut cable ties to shift cables out of the way.

To replace the CPU board, reverse the above procedure. Be sure to reinstall cable ties to secure all cables inside the indicator enclosure.

3.8 Battery Replacement

The lithium battery on the CPU board maintains the real-time clock and protects data stored in the system RAM when the indicator is not connected to AC power.

Data protected by the CPU board battery includes time and date, truck and tare memory, onboard database information and setpoint configuration.

Use iRev 4 to store a copy of the indicator configuration on a PC before attempting battery replacement. If any data is lost, the indicator configuration can be restored from the PC.

Memory option card data is also protected by a lithium battery. All database information stored on a memory card is lost if the memory card battery fails.

Watch for the low battery warning on the LCD display and periodically check the battery voltage on both the CPU board and on any installed memory option cards. Batteries should be replaced when the indicator low battery warning comes on, or when battery voltage falls to 2.2 VDC. Life expectancy of the battery is 10 years.

Battery Removal

Place the tip of a finger in notched area near the battery retaining spring and slide the battery out of position on the CPU board.

Figure 3-13. Battery Removal

3.8.1 Replacement

Before replacing the battery, place the indicator in setup mode, then press SAVE/EXIT to save battery-backed memory (NVRAM) to flash. This operation saves the latest configuration information, including setpoint values, stored strings and data, and the onboard database, to flash memory.

Return to weigh mode, power off the indicator, and replace the battery. Use care not to bend the battery retaining spring. When power is restored, a message is shown stating that battery-backed memory is corrupt. Press

saved in flash memory. See Figure 3-7 on page 16 for CPU board battery location and orientation (positive side up).

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of unused batteries according to the manufacturer’s instructions.

Enter to restore the values

20 Visit our website www.RiceLake.com

Page 27

3.9 Parts Kit

Note

Black wire not shown for clarity

Pin 1

Pin 4 Pin 3 Pin 2 Pin 1

Table 3-9 lists the parts kit contents for the universal model.

Part No. Description Qty

42149 Bumper, Rubber Grommet 4 103610 Knob, Black 1/4-20 2 103988 Washer, Nylon 0.515 - 0.52 2

14626 Nut, Kep 8-32NC HEX 4

14862 Screw, Mach 8-32NC x 3/8 12

15133 Washer, Lock NO 8 Type A 4

15631 Cable Tie, 3'' Nylon 4

15665 Gland, Reducing 1/2NPT 2

15887 Terminal Block, 6 Position 1 174928 Label, NOM/NYCE 920i 1

19538 Post Plug, Slotted Black 4

30623 Screw, Mach 8-32NC x 7/16 2

53075 Clamp, Ground Cable Shield 4

70599 Conn, 6 Pos Screw Terminal 1

71125 Conn, 3 Pos Screw Terminal 1

71126 Conn, 4 Pos Screw Terminal 1

75062 Washer, Bonded Sealing #8 14

77180 Conn, 8 Pos Screw Terminal 1

94422 Label, Capacity 0.40 x 5.00 1

Table 3-9. Parts Kit Contents (PN126285)

Installation

3.9.1 LED Backlight

The 920i display is now shipped with an improved LED backlight, replacing the CCFL (Fluorescent) backlight. The improved LED backlight is compatible with all older CPU boards (green solder mask), however, a new power supply cable is required. For the Blue CPU board (PN 180902) a retrofit cable is not required.

The CCFL (Fluorescent) backlight is still available for purchase.

Power AC

Original Power

Cable

67796 Universal 186464 71430 Panel Mt, Deep Univ 186278 71431 Wall Mt 186760 71757 2 Slot Wall Mt 188716 71758 2 Slot Panel Mt, Deep Univ 188717 71430 6 Slot Wall Mt 186278 71759 Expansion 188774

Where Used

Table 3-10. Retrofit Cables for Display with LED Backlight, Used with Green CPU Only

LED

Backlight on

Green CPU

Power DC/DC

Original Power

Cable

67796 Universal 186464 175824 Panel Mt, Deep Univ 187603 158620 Wall Mt 188345 179487 2 Slot Wall Mt DC/DC 189424 181032 2 Slot 180047 Panel Mt DC/DC 189425

Where Used

LED

Backlight on

Green CPU

Figure 3-14. Retrofit Wire Harness for LED Backlight Display with Green CPU Board

Page 28

920i Programmable Indicator/Controller

16 151941

5012

820

4824

42 35

Note

3.10 Replacement Parts Illustrations

Replacement parts information for other enclosures:

* Panel Mount Installation Instructions, PN 69989

* Wall Mount Installation Instructions, PN 69988.

Figure 3-15. Universal Enclosure Parts Illustration

22 Visit our website www.RiceLake.com

Page 29

Installation

CAUTION

Item

Part No. Description Qty

No.

1 53308 Label,1.25 x 1.25 1 2 186275

186276 3 53307 Label, 4.000 x 2.875 1 4 88734 Nut, Breather Vent 1 5 88733 Vent, Breather Sealed 1 6 14862 Screw, Mach 8-32NC x 3/8 4 7 75062 Washer, Bonded Sealing #8 8 8 68661 Standoff, Male-Fem 4-40NC 2 9 67532 Gasket Back Plate 1

10 14822 Screw, Mach 4-40 NC x 1/4 11 11 103610 Knob, Black 1/4-20 2 12 14618 Nut, Kep 4-40NC HEX 2 13 14626 Nut, Kep 8-32NC HEX 3 14 67886 Standoff, Male-FEM 4-40NC 4 15 15631 Cable Tie, 3'' Nylon 1

15650 Mount, Cable Tie 3/4'' 1

16 16861 Label, Warning High 1 17 67529 Enclosure, Universal 1 18 15630 Locknut,1/2 NPT Black 2 19 58248 Nut, Lock 6-32NC HEX Nylon 2 20 69898 Washer, Nylon #4 ID = 0.112 2 21 14845 Screw, Mach 6-32NC x 3/8 4 22 42640 Screw, Mach 1/4-28NF x 0.25 8 23 55708 Screw, Mach 4-40NC x 0.38 2 24 103988 Washer, Nylon 0.515 -0.52 2 25 15134 Washer, Lock NO 8 Type A 3 27 15628 Cord Grip,1/2 NPT Black 2

Display, Module Transmissive, LED B/L Display, Module Transflective, LED B/L

Table 3-11. Universal Enclosure Parts

Item

Part No. Description Qty

No.

28 67610 Card, A/D Single Channel 1

29 30375 Seal Ring, Nylon PG9 3 30 15626 Cord Grip, Black PG9 3 31 67531 Stand, Tilt 1 32 67613

132791

33 186464

67796 34 15627 Locknut, Black PCN9 3 35 67530 Plate, Interface Board 1 36 42149 Bumper, Rubber Grommet 4 37 45043 Wire Assembly, Ground 4" 1 38 68424 Backplate, Universal 1 39 30376 Seal Ring, Nylon 1/2 NPT 2 40 69290 Battery, 3V Coin Lithium 1 41 94392 Bracket, 25W Power Supply 1 42 67535 Gasket, Interface Board 1 43 111109 Board Interface USB 1

67869 Board Assembly, PS2/DB-9 1 44 16892 Label, Ground Protective 1 45 68662 Cable, Ribbon Interface 1 46 44676 Washer, Bonded Sealing 1 47 85202

85203 48 66502 Overlay, Membrane Switch 1 49 68216 Nameplate, Rice Lake 1 50 117930

186272

Power Supply, 120-240VAC, 25W Power Supply, 12-24 VDC, 25W

Wire Harness for Universal, Green CPU Wire Harness for Universal, Blue CPU

Power Cord Assy,120VAC Power Cord Assy, 240VAC Euro Plug

Board Assembly, Green CPU for CCFL B/L Board Assembly, Blue CPU for LED B/L

To protect against the risk of fire, replace fuses only with same type and rating fuse. See the 920i technical manual (PN 67887) for complete fuse specifications.

Page 30

920i Programmable Indicator/Controller

Note

IMPORTANT

4.0 Configuration

See the 920i technical manual (PN 67887) for section references not found in this manual.

The 920i indicator can be configured by using the front panel keys to navigate through a series of configuration menus or by sending commands or configuration data to an indicator serial port. If there is no serial port on port 2, refer to Section 7.0 on

page 65. Configuration using the menus is described in this section.

Configuration using the serial port can be accomplished using either the serial command set described in Section 11.0 on

page 97 or the iRev 4 configuration utility.

The 920i display and widgets, cannot be accessed through the configuration menus. iRev 4 provides the most complete and efficient configuration interface for the 920i.

4.1 iRev™ Configuration

The iRev configuration utility provides the preferred method for configuring the 920i indicator. iRev 4 runs on a personal computer to set configuration parameters for the indicator. When iRev 4 configuration is complete, configuration data is downloaded to the indicator.

iRev supports both uploading and downloading of indicator configuration data. This capability allows configuration data to be retrieved from one indicator, edited and downloaded to another indicator with an identical hardware configuration.

See Section 6.0 on page 57 for more information about using iRev to configure the 920i.

4.2 Serial Command Configuration

The serial command set can be used to configure the 920i indicator using either a personal computer, terminal, or remote keyboard. Like iRev 4, serial command configuration sends commands to the indicator serial port; unlike iRev 4, serial commands can be sent using any external device capable of sending ASCII characters over a serial connection.

Serial commands duplicate the functions available using the indicator front panel and provide some functions not otherwise available. Serial commands can be used to simulate pressing front panel keys, to configure the indicator, or to dump lists of parameter settings. See Section 11.0 on page 97 for more information about using the serial command set.

4.3 Configuration Switch

To configure the 920i indicator, the indicator must be placed in configuration mode.

Insert non-conductive tool to press switch.

Fillister Head Screw

Figure 4-1. Configure Switch – Universal Model

1. Remove the setup switch access screw on the bottom of the universal enclosure.

2. Insert a small non-conductive tool into the access hole to press the switch. The main menu displays.

3. Set parameters as required for scales/system being used.

4. Once configuration is complete, press the Save and Exit softkey to exit setup mode.

5. Replace the setup switch access screw.

To maintain NTEP certification requirements and to use the scale to record Legal for Trade transactions, the scale must be properly sealed.

* If updating and/or configuring the scale, the seal may need to be broken to enter the menu structure. * Removing or altering the seal voids the NTEP approval. For continued certification the unit must be resealed, by an

authorized agent, when configuration is complete. * There are menus that must be set per NTEP standards, ensure these settings remain NTEP accepted values. * Calibration must be performed by a qualified technician familiar with state and local regulations.

24 Visit our website www.RiceLake.com

Page 31

Configuration

Save

and Exit

SCALES SERIAL FEATURE

FLDBUS VERS

10/20/2017

AVAILABLE A/D’s ASSOCIATED A/D’s

Done

Change

Type

12:14PM

SCALES

CONFIG

Scale 3 Scale 4 Scale 5 Scale 6

SCALES

Scale 2

Scale 1

SCALE 1 SCALE 1

4.4 Front Panel Configuration

Use the CONFIG menu under the SCALES to configure A/D scales.

1. Place the indicator in configuration mode. The main menu displays.

10/20/2017

2. Ensure that SCALES is highlighted and press . The scales menu displays the scales that have been set up. If no scales have been setup, only CONFIG is displayed.

12:14PM

Figure 4-2. Main Menu Display

3. Press or to highlight a scale to revise or highlight CONFIG to setup a new scale.

4. Press . Figure 4-3 displays.

5. Press to highlight the scale to configure.

6. Press the Change Type softkey to select one of the available scale types.

7. Press and use or to highlight the desired scale.

8. Press the Add softkey. The selected type displays under Associated A/D’s.

9. Press Add to associate another A/D or to the scale #n.

10. Press the Done softkey.

11. Repeat Step 2 through Step 10 for each scale.

See Section 13.2 on page 121 for information on configuring serial scales.

Available Scale Types

• A/D’s

• Scales

• Ports

• iQubes

• Prog Scale

Figure 4-3. Scale Configuration Display

List of available scales for scale type selected.

Page 32

920i Programmable Indicator/Controller

SCALES SERIAL FEATURE PFORMT SETPTS DIG I/O ALGOUT FLDBUS VERS

Note

4.5 Main Menu

The 920i indicator can be configured using a series of menus accessed through the indicator front panel when the indicator is in setup mode.

Displays only if Analog Output card is installed

Displays only if Fieldbus card

is installed

Figure 4-4. Configuration Menu Flow

Menu Menu Function

SCALES Configuration – configure and calibrate scales; see Section 4.6 on page 27 SERIAL Serial – configure communications ports; see Section 4.7 on page 35 FEATURE Features – set date and time, truck mode, passwords, keyboard locks, regulatory mode, initial consecutive number value, define softkeys

and setpoint prompts; see Section 4.8 on page 42 PFORMT Print Format – set print format used for header, gross, net, truck in/out, setpoint, and auxiliary ticket formats; see Section 4.9 on page 47 SETPTS Setpoints – configure setpoints and batching mode; see Section 4.10 on page 48 DIG I/O Digital I/O – assign digital input/output functions; see Section 4.11 on page 49 ALGOUT Analog Output – configure analog output module; displayed only if analog output option is installed; see Section 4.12 on page 51 FLDBUS Fieldbus – configure fieldbus parameters for PROFIBUS, PROFINET, DeviceNet, EtherNet/IP and ControlNet communications; displayed

only if one of the listed fieldbus cards is installed VERSION Version – displays installed software version number; the Reset Config softkey on the Version menu can be used to restore all configura-

tion parameters to their default values

Table 4-1. 920i Menu Summary

page 65. Configuration using the menus is described in Section 4.4 on page 25.

Configuration using the serial port can be accomplished using either the serial command set described in Section 11.0 on

page 97 or the iRev 4 configuration utility.

The 920i display and widgets, cannot be accessed through the configuration menus. iRev provides the most complete and efficient configuration interface for the 920i.

26 Visit our website www.RiceLake.com

Page 33

4.6 Scales Menu

SCALE x

DFSENS

32OUT 64OUT

2OUT

8OUT

4OUT

16OUT

128OUT

DFTHRH

20D 50D

250D

10D

100D

NONE

200D

DIGFLT1

128

256

1 2

CONFIG

CALIBR

DIGFLT2

128

256

1 2

DIGFLT3

128

256

1 2

WMTTHRH

number

1000

number

SSTIMEFORMATSPLIT

3INTVL

3RNG

2RNG

2INTVL

OFF

ZTRKBND

number

ZRANGE

1.900000

number

MOTBAND

number

10000

number

GRADS

Specify for

SPLIT = OFF

OFF

RATTRAP

DELAY

PWRUPMD

BOTH

PBTARE

NOTARE

KEYED

TAREFN

30HZ

50HZ

400HZ 480HZ

60HZ

120HZ

100HZ

200HZ

SMPRAT

800HZ 960HZ

25HZ

6.25HZ

12.5HZ

7.25HZ

15HZ

240HZ

OFF

ACCUM

OFF

VISIBLE

OFF

BI-DIR

NORMAL

AUTO

PEAK HOLD

SCALES SERIAL FEATURE PFORMT SETPTS DIG I/O ALGOUT FLDBUS VERS

OVRLOAD

FS+2%

FS+9D

FS+1D

The Scale x menu allows configuration and calibration of each scale. Config lists available and associated A/Ds.

See Figure 4-6 on page 31 and Figure 4-7 on page 34

Configuration

Figure 4-5. Scales Menu

See Figure 4-8

on page 35

Parameter Description

GRADS Graduations – specifies number of full scale GRADS if SPLIT = OFF; GRADS = Capacity / Display Divisions, see Figure 4-7 on

page 34 for display divisions

Settings: 1–9999999 (10000 default), must be consistent with legal requirements and environmental limits on system resolution; For Multi-range and Multi-interval scales (SPLIT the range or interval

Table 4-2. Scale x Menu Parameters

 OFF), the GRADS is calculated using the capacity and display divisions specified for

Page 34

920i Programmable Indicator/Controller

Parameter Description

SPLIT Split – specifies the range or interval of the scale; Settings:

• OFF = full-range (default)

• 2RNG, 3RNG = multi-range

• 2INTVL, 3INTVL = multi-interval

For Multi-range and Multi-interval scales, see Table 4-4 on page 31 and Table 4-6 on page 34

FORMAT Format – specifies scale units: Primary (PRIMAR default), Secondary (SECNDR), Tertiary (TERTIA) or Rate of Change (ROC);

• SPLIT = OFF – see Table 4-4 on page 31

• SPLIT

ZTRKBND Zero Track Band – automatically zeros scale when in a specified range, as long as the input is in the range and scale is at standstill;

zero tracking band is specified in ± display divisions; maximum legal value varies depending on local regulations; Enter Value: 0 (default)

NOTE: For scales using linear calibration, do not set zero tracking band to a value greater than the value set for the first point.

ZRANGE Zero Range – specifies the range within which the scale can be zeroed

Enter Value: 1.900000 (default), Example: ± 1.9% around the calibrated zero point for a total range of 3.8% Indicator must be at standstill to zero the scale; use the default value for Legal-for-Trade applications

MOTBAND Motion Band – sets the level, in display divisions, at which scale motion is detected; if motion is not detected for the SSTIME (default of 1

second) or more, the standstill symbol lights; some operations, including print, tare, and zero, require the scale to be at standstill; the value entered must be in the range of 0-100; maximum legal value varies depending on local regulations.

NOTE: If set to 0, the standstill annunciator is set continuously on, and operations including zero, print, and tare will be performed regardless of scale motion; If 0 is selected, ZTRKBND must also be set to 0

SSTIME Stand Still Time – specifies the length of time the scale must be out of motion, in 0.1-second intervals, before the scale is considered to be

at standstill; Enter Value: 10 (default), values greater than 10 (1 second) are not recommended

OVRLOAD Determines the point at which the display blanks and an out-of-range error message is displayed. Maximum legal value varies depending

on local regulations; Settings: FS+2% (default), FS+1D, FS+9D, FS

WMTTHRH Weighment Threshold – specifies minimum number of grads required to add weighment to the recorded number of weighments

Enter Value, 1000 (default)

DIGFLT1 DIGFLT2 DIGFLT3

DFSENS Digital Filter Cutout Sensitivity – specifies the number of consecutive readings that must fall outside the filter threshold (DFTHRH param-

DFTHRH Digital Filter Cutout Threshold – specifies the filter threshold, in display divisions; when a specified number of consecutive scale readings

RATTRAP

SMPRAT Sample Rate – selects measurement rate, in samples per second, of the analog-to-digital converter; lower sample rate values provide

PWRUPMD Power Up Mode – sets the indicator to go into operation immediately after a brief power up display test; Settings:

TAREFN Enables or disables push-button and keyed tares; Settings:

ACCUM Accumulator – specifies if the scale accumulator is enabled or not. If it is, accumulation occurs whenever a print operation is performed;

Digital Filtering – selects the digital filtering rate used to reduce the effects of mechanical vibration from the immediate area of the scale; selected setting indicates the number of A/D conversions per update that are averaged to obtain the displayed reading; a higher number gives a more accurate display by minimizing the effect of a noisy readings, but slows down the settling rate of the indicator Settings: 1, 2, 4 (default), 8, 16, 32, 64, 128, 256

NOTE: When configuring non-A/D scales, set the DIGFLTx parameters to 1 to disable filtering

See Section 4.6.1 on page 29 for more information about digital filtering

eter) before digital filtering is suspended; Settings: 2OUT(default), 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT See Section 4.6.1 on page 29 for more information about digital filtering

(DFSENS parameter) fall outside of the threshold, digital filtering is suspended; If NONE is selected, the filter is always enabled. Settings: NONE (default), 2D, 5D, 10D, 20D, 50D, 100D, 200D, 250D; See Section 4.6.1 on page 29 for information about digital filtering.

RATTLETRAP increase settling times over standard digital filter selections; Settings: OFF (default), ON – enables RATTLETRAP

greater signal noise immunity; Settings: 6.5HZ, 7.5HZ, 12.5HZ, 15HZ, 25HZ, 30HZ (default), 50HZ, 60HZ, 100HZ, 120HZ, 200HZ, 240HZ, 400HZ, 480HZ, 800HZ, 960HZ

NOTE: The maximum total sample rate for all configured A/D channels—the sum of the sample rates for all scales—is 1200 Hz.

Example: up to ten scales can be configured with 120 Hz sample rates, or up to twenty scales with 60 Hz sample rates

• GO (default) – indicator goes into operation immediately after a brief power up display test

• DELAY – indicator performs a power up display test and enters a 30-second warm-up period. If no motion is detected during warm

• BOTH (default)- - -both push-button and keyed tares are enabled

• NOTARE - - - - - - - no tare allowed (gross mode only)

• PBTARE - - - - - - -push-button tares enabled

• KEYED - - - - - - - -keyed tare enabled

Settings: OFF (default), ON

 OFF – multi-range and multi-interval scales; see Table 4-6 on page 34

– the most effective at filtering repeating vibrations caused by mechanical noise from nearby machines, but may

up, the indicator becomes operational; if motion is detected, the delay timer is reset and the warm up is repeated

Table 4-2. Scale x Menu Parameters (Continued)

28 Visit our website www.RiceLake.com

Page 35

Configuration

Parameter Description

VISIBL Scale Visibility – specifies whether scale data is displayed; Settings: ON (default), OFF PEAK HOLD Peak Hold – used to determine, display, and print the greatest net weight read during a weighing cycle for the displayed scale; weighing

cycle ends when a print command is executed (AUTO setting) or when the peak weight is cleared by pressing

Gross/Net to display gross weight data when using the peak hold function

• OFF (default) - - - -Peak hold function is off

• NORMAL - - - - - - -Positive peak, manual reset. Greatest net weight is held in memory until the weight is removed from the scale

• BI-DIR - - - - - - - - -Bi-directional peak, manual reset. Same as NORMAL, but peak value can be either positive or negative,

• AUTO - - - - - - - - -Positive peak, auto print, auto reset. Automatic print occurs when scale load is 0 ± 10 display divisions and at

NOTE: If the 920 is connected to multiple scales, the auto print function occurs on the displayed scale.

CALIBR Calibration – set parameters for calibration; see Table 4-7 on page 35

and either the

determined by absolute value

standstill. Following the print command, the peak value is cleared and reset automatically

Zero or Print key is pressed

Table 4-2. Scale x Menu Parameters (Continued)

Zero or Print; press

4.6.1 Digital Filtering

Standard digital filtering uses mathematical averaging to eliminate the variant digital readings that the A/D converter sends periodically because of external vibration. Digital filtering does not affect the indicator measurement rate, but does affect the settling time. The selections from 1 to 256 reflect the number of readings averaged per update period. When a reading is encountered that is outside a predetermined band, the averaging is overridden, and the display jumps directly to the new value.

DIGFLTx Parameters

The first three digital filtering parameters, DIGFLT1, DIGFLT2, and DIGFLT3, are configurable filter stages that control the effect of a single A/D reading on the displayed weight. The value assigned to each parameter sets the number of readings received from the preceding filter stage before averaging.

A rolling average is passed to successive filters for an overall filtering effect that is effectively a weighted average of the product of the values assigned to the filter stages (DIGFLT1 x DIGFLT2 x DIGFLT3)

within a time frame corresponding to the sum of the

values (DIGFLT1 + DIGFLT2 + DIGFLT3). Setting the filters to 1 effectively disables digital filtering.

Rattletrap® Filtering

RATTLETRAP digital filtering (RATTRAP parameter set ON) uses a vibration-dampening algorithm to provide a combination of the best features of analog and digital filtering. The RATTLETRAP algorithm eliminates the frequency of a repeating vibration then displays weight equal to the actual weight on the scale less the vibration-induced flaws. It is particularly effective for eliminating vibration effects or mechanical interference from nearby machinery. Using RATTLETRAP filtering can eliminate much more mechanical vibration than standard digital filtering, but will usually increase settling time over standard digital filtering.

Digital Filter Sensitivity and Digital Filter Threshold Parameters

The digital filter can be used by itself to eliminate vibration effects, but heavy filtering also increases settling time. The DFSENS (digital filter sensitivity) and DFTHRH (digital filter threshold) parameters can be used to temporarily override filter averaging and improve settling time:

• DFSENS specifies the number of consecutive scale readings that must fall outside the filter threshold (DFTHRH) before digital filtering is suspended.

• DFTHRH sets a threshold value, in display divisions. When a specified number of consecutive scale readings (DFSENS) fall outside of this threshold, digital filtering is suspended. Set DFTHRH to NONE to turn off the filter override.

Page 36

920i Programmable Indicator/Controller

Setting the Digital Filter Parameters

Fine-tuning the digital filter parameters greatly improves indicator performance in heavy-vibration environments. Use the following procedure to determine vibration effects on the scale and optimize the digital filtering configuration.

1. Place the indicator into setup mode. See Section 4.3 on page 24.

2. Set the digital filter parameters (DIGFLT1–DIGFLT3) to 1.

3. Set DFTHRH to NONE.

4. Return indicator to weigh mode.

5. Remove all weight from the scale and watch the display to determine the magnitude of vibration effects on the scale.

6. Record the weight below which all but a few readings fall. This value is used to calculate the DFTHRH parameter

value in Step 8.

Example: if a heavy-capacity scale (10000 x 5 lb) produces vibration-related readings of up to 50 lb, with occasional spikes to 75 lb, record 50 lb as the threshold weight value.

7. Place the indicator in setup mode and set the DIGFLTx parameters to eliminate the vibration effects on the scale.

(Leave DFTHRH set to NONE.) Find the lowest effective value for the DIGFLTx parameters.

8. Calculate the DFTHRH parameter value by converting the weight value recorded in Step 6 to display divisions:

threshold_weight_value / display_divisions

In the example in Step 6, with a threshold weight value of 50 lb and a display divisions value of 5 lb: 50 / 5 = 10. DFTHRH should be set to 10D for this example.

9. Set the DFSENS parameter high enough to ignore transient peaks. Longer transients (typically caused by lower

vibration frequencies) will cause more consecutive out-of-band readings, so DFSENS should be set higher to counter low frequency transients.

Reconfigure as necessary to find the lowest effective value for the DFSENS parameter.

30 Visit our website www.RiceLake.com

Page 37

4.6.2 Format Menu

PRIMAR

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

GR TROYOZ TROYLB

CUSTOM

NONE

SECNDR

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

GR TROYOZ TROYLB

CUSTOM

NONE

0.453592

number

TERTIA

ROC

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

1.000000

number

UNITS

MIN

SEC

HOUR

INTERVL

number

REFRESH

number

0.1

OFF

FORMAT

DECPNT DSPDIV UNITS MULTDECPNT DSPDIV UNITS

DECPNT

DSPDIV MULT

……

Configuration

Figure 4-6. Format Menu, SPLIT = OFF

Parameter Description

PRIMAR Specifies the decimal position, display divisions, and units used for the primary units SECNDR Specifies the decimal position, display divisions, units, and conversion multiplier used for the secondary units TERTIA Specifies the decimal position, display divisions, units, and conversion multiplier used for the tertiary units ROC Rate of Change – specifies the decimal position, display divisions, conversion multiplier, time units, update interval, and refresh interval

used for the rate of change units

Format Menu if Split = OFF

Table 4-3. Format Menu Parameters

Parameter Description

DECPNT Decimal Point Location – specifies the location of the decimal point or dummy zeros in the unit display; value should be consistent with local

DSPDIV Display Divisions – select the minimum division size for the units displayed weight;

legal requirements; Settings: 8888888-888888.8; Defaults: 8888888 (primary and ROC), 888888.8 (secondary and tertiary)

Settings: 1d (default Primary and ROC), 2d (default Secondary), 5d (default Tertiary)

Table 4-4. Format Parameters – SPLIT = OFF

Page 38

920i Programmable Indicator/Controller

UNITS Units for displayed and printed weight; settings: LB = pound (default Primary); KG = kilogram (default Secondary and Tertiary);

G = gram; OZ = ounce; TN = short ton; T = metric ton; GR = grain; TROYOZ = troy ounce; TROYLB = troy pound; LT = long ton, CUSTOM, NONE, OFF

NOTE: See below for ROC units

Secondary and Tertiary Only

MULT Multiplier – specifies the conversion factor by which the primary units are multiplied to obtain the secondary or tertiary units; the entered

value is the conversion factor for changing pounds to kilograms; Settings: 0.000001-9999999, 0.453592 (default); See Section 4.6.3 on page 33 for a list of multipliers To shift between primary, secondary, and tertiary units, press the UNITS key

Rate of Change (ROC) Only

MULT Multiplier – specifies the conversion factor by which the primary units are multiplied to obtain displayed rate of change units;

Setting: 0.000001-9999999, 1.000000 (default); See Section 4.6.3 on page 33 for information about conversion factors UNITS Rate-of-Change units; Settings: SEC (default), MIN, HOUR INTERVL Update Interval – specifies the number of refreshes over which the rate-of-change is calculated, Enter Value: 10 (default)

Example: REFRESH set to 0.1 second and INTERVL set at 60, each weight value takes 6 seconds (0.1 * 60) to be flushed from ROC data REFRESH Refresh interval – specifies the number of seconds between Rate-of-Change samples; Setting: 0.1(default)-60 For applications using the ROC function, the primary scale should be configured with a finer resolution than the rate of change (ROC) units to prevent a

stepwise appearance in the ROC display. The ROC display step size (weight increment between displayed values) can be roughly calculated as follows: (updates_per_ROC_UNIT) * (PRIMARY_resolution / ROC_resolution) Example, with INTERVL=30; REFRESH =0.1; UNITS=MIN; PRIMARY resolution at 0.1 LB and ROC resolution at 1.0 (LB/ MIN)

• INTERVL * REFRESH = 30 * 0.1 = 3.0 seconds per update (ROC data is flushed every 3.0 seconds)

• With UNITS = MIN, there are 20 ROC data updates per ROC time unit: 60 seconds / 3.0 seconds per update

• The resolution ratio of PRIMARY to ROC units is 0.1 (0.1 / 1.0)

• This configuration provides a step size in the ROC display of 2 LB (2 LB increments between displayed values)

Table 4-4. Format Parameters – SPLIT = OFF (Continued)

Multi-Range and Multi-Interval Scales

The 920i supports multi-range and multi-interval scales. Multi-range scales provide two or three ranges, each extending from zero to the maximum capacity specified for the range, that

can specify different scale intervals (graduations). The scale interval changes as the applied weight increases but does not reset to lower range intervals until the scale returns to zero.

Multi-interval scales divide the scale into two or three partial weighing ranges, each with different scale intervals. The scale interval changes with both increasing and decreasing loads applied.

To configure, use the SPLIT parameter to select 2RNG or 3RNG (for multi-range scales), or 2INTVL or 3INTVL (for multiinterval scales). Selecting a SPLIT value allows specification of decimal point, display divisions and maximum capacity for each range or interval.

32 Visit our website www.RiceLake.com

Page 39

Configuration

Note

4.6.3 Unit Conversion Factors

The 920i has the capability to mathematically convert and display weight in other units. Press to scroll through available units.

Set secondary (SECNDR) and tertiary (TERTIA) units using serial commands.

• To configure secondary or tertiary units using the front panel menus, use the Table 4-5 to find the conversion multiplier for the MULT parameter.

Example: if the primary unit is pounds and the secondary unit is short tons, set the MULT parameter to 0.000500.

• To configure secondary or tertiary units using serial commands, use the Table 4-5 to find the conversion multiplier for the SC.SEC.MULT or SC.TER.MULT command.

Example: if the primary unit is pounds and the secondary unit is short tons, send the serial command SC.SEC.MULT= 0.0005<CR> to set the multiplier for the secondary units.

Ensure that the secondary decimal point position is set appropriately for the scale capacity in the secondary units. If the converted value requires more digits than are available, the indicator displays an overflow message (

Setting the units is for the display and printed output, it does not change the defaulted units in the stream format. See Section 4.7.8 on page 40.

Example: if the primary units are short tons, secondary units are pounds, and the secondary decimal point is set to 8888.888, the indicator will overflow if 5 tons or more are applied to the scale. With 5 tons applied, and a conversion factor of 2000, the secondary units display needs five digits to the left of the decimal point to display the 10000 lb secondary units value.

OVERFL).

Primary

Unit x Multiplier

grains 0.064799 grams

0.002286 ounces

0.000143 pounds

0.000065 kilograms

0.002083 troy ounces

0.000174 troy pounds

ounces 437.500 grains

28.3495 grams

0.06250 pounds

0.02835 kilograms

0.911458 troy ounces

0.075955 troy pounds

pounds 7000.00 grains

453.592 grams

16.0000 ounces

0.453592 kilograms

14.58333 troy ounces

1.215278 troy pounds

0.000500 short tons

0.000446 long tons

0.000453 metric tons

Secondary/

Tertiary Unit

Primary

Unit

grams 15.4324 grains

kilograms 15432.4 grains

short tons 2000.00 pounds

x Multiplier

0.035274 ounces

0.002205 pounds

0.001000 kilograms

0.032151 troy ounces

0.002679 troy pounds

35.2740 ounces

1000.00 grams

2.20462 pounds

32.15075 troy ounces

2.679229 troy pounds

0.001102 short tons

0.000984 long tons

0.001000 metric tons

907.185 kilograms

0.892857 long tons

0.907185 metric tons

Secondary/

Tertiary Unit

Primary

Unit

metric tons

long tons 2240.00 pounds

troy ounces

troy pounds

x Multiplier

2204.62 pounds

1000.00 kilograms

1.10231 short tons

0.984207 long tons

1016.05 kilograms

1.12000 short tons

1.01605 metric tons 480 grains

31.10348 grams

0.031103 kilograms

1.09714 ounces

0.068571 pounds

0.083333 troy pounds 5760 grains

373.2417 grams

0.373242 kilograms

13.16571 ounces

0.822857 pounds 12 troy ounces

Secondary/

Tertiary Unit

Table 4-5. Conversion Factors

Page 40

920i Programmable Indicator/Controller

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

UNITS

GR TROYOZ TROYLB

CUSTOM

NONE

OFF

2000.000

weight

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

MAX2

5000.000

weight

DECPT3

88.88888

888.8888

8888888

8888800

8888880

8.888888

8888.888

88888.88

888888.8

DDIV3

MAX3

10000.00

weight

If SPLIT = 3RNG or 3INTVL

DECPT1 DDIV1

MAX1

DECPT2

DDIV2

……

FORMAT

Format Menu if SplitOFF

Figure 4-7. Format Menu, SPLIT OFF – 2 or 3 RNG, 2-3 INTVL

Parameter Description

DECPNT 1-3 Decimal Point Location – specifies the location of the decimal point or dummy zeros in the unit display; value should be consistent with local

DDIV 1-3 Display Divisions – for range or interval; selects the minimum division size for the primary units displayed weight;

MAX 1-3 Maximum weight for first range or interval; Setting: weight, 50.00000 (default)

UNITS Units for displayed and printed weight; values are: LB = pound (default); KG = kilogram; G = gram; OZ = ounce; TN = short ton;

legal requirements; Settings 8888888-888888.8; Defaults: 8888888 (DDIV1), 888888.8 (DDIV2 and DDIV3)

NOTE: Decimal point location for third range or interval (SPLIT = 3RNG or 3INTVL only)

Settings: 1D (DDIV1 Default), 2D (DDIV2 Default), 5D (DDIV3 Default);

NOTE: Display divisions for third range or interval (SPLIT = 3RNG or 3INTVL only)

NOTE: Maximum weight for third range or interval (SPLIT = 3RNG or 3INTVL only)

T = metric ton; GR = grain; TROYOZ = troy ounce; TROYLB = troy pound; LT = long ton, Custom, None, Off

34 Visit our website www.RiceLake.com

Table 4-6. Format Menu, SPLIT OFF

Page 41

4.6.4 Calibration Menu

WZERO WVAL WSPAN

WLIN

REZERO

POINT 4 POINT 5POINT 1 POINT 2

POINT 3

……

CALIBR

Figure 4-8. Calibration Menu

Parameter Description

WZERO WVAL WSPAN WLIN

REZERO

For information on configuring an iQUBE2 scale, see the iQUBE2 manual, PN 106113.

Press

Enter to display and edit the zero calibration A/D raw count or millivolts value

Press

Enter to display and edit the test weight value

Press

Enter to display and edit the span calibration A/D count or millivolts value

Press

Enter to display and edit test weight and calibration values for up to five linearization points

Perform linear calibration only after WZERO and WSPAN have been set. Settings: POINT 1 — POINT 5 Press

Enter to remove an offset value from the zero and span calibrations.

NOTE: Use this parameter only after WZERO and WSPAN have been set.

Table 4-7. Calibration Menu Parameters

Configuration

4.7 Serial Menu

See Section 13.2 on page 121 for information on serial data formats.

4.7.1 Ports

Parameter Description

PORT 1 PORT 2 Serial PORT 3 PORT 4 … PORT x

PORT 2 USB Specifies the type of data received by the port:

Specifies the type of data received by the port:

• CMD: - - - - - - - - - Remote command input

• PROGIN: - - - - - - Input routed to user program instead of core

• SCALE:- - - - - - - - Legal-for-trade serial scale input (ports 3 and higher only)

• IND SC: - - - - - - - Industrial (non-legal-for-trade) scale input (ports 3 and higher only)

• DISPLAY: - - - - - - Display data input for remote units in local/remote configurations (ports 3 and higher only)

• IQUBE2: - - - - - - - iQUBE2 serial scale input (ports 3 and higher only); see iQube

• INCLIN:- - - - - - - - Special mode for use with Rice Lake inclinometer (port 1 only)

• KEYBD: - - - - - - - Remote keyboard input (PS/2) (port 2 only)

• KBDPRG: - - - - - - Remote keyboard input for user programs (PS/2) (port 2 only)

NOTE: These selections for port 2 are available only if the USB interface card is installed.

• DEVICE: - - - - - - - Sets target USB device to use: AUTO, NODEVICE, HOSTPC, PRINTER1, PRINTER2, KEYBOARD, or DRIVE

• TERMIN:- - - - - - - Indicates whether files have CR/LF (Windows) or CR (Macintosh previous to OS X) as the line terminator

• ECHO: - - - - - - - - Specifies whether characters received by the port are echoed back to the sending unit

• RESPONSE: - - - - Specifies whether the port transmits replies to serial commands

• EOLDLY: - - - - - - End-of-line delay. Sets the delay period, in 0.1-second intervals, from when a formatted line is terminated to the beginning of the next formatted serial output.

• STREAM: - - - - - - Specifies what data, if any, is streamed from the port.

• INPUT: - - - - - - - - Determines whether the input will be handled by the core or routed to a user program (if present)

Table 4-8. Serial Menu – Port Parameters

manual, PN 106113

Page 42

920i Programmable Indicator/Controller

PORT 1

CMD PROGIN

BAUD

600

1200

38400

115200

57600

300

2400

28800

9600

4800

19200

TERMIN

CR/LF

EOLDLY

number

BITS

8NONE

7ODD

7EVEN

8ODD

8EVEN

STOP BITS

ECHO

OFF

RESPONSE

OFF

HANDSHK

OFF

HRDWAR

XONXOFF

HRDWAR on PORT 2 only

INCLIN

SERIAL

Scale 1

format

OFF

INDUST

LFT

4KEYS

DISPLAY

KEYPAD

If STREAM = LFT or INDUST

STREAM SOURCE SFMT

PRIMAR

SECNDR

TOKENS

TERTIA

NET

GROSS

MOTION

INVALID

ZERO

RANGE

TARE

CMD PROGINKEYBD KBDPRG

…

PORT 2

……

SERIAL

4.7.2 Port 1

4.7.3 Port 2 with Serial Interface Option

36 Visit our website www.RiceLake.com

To display Source, SFMT and Tokens, set Stream to LFT or INDUST

Figure 4-9. Serial Menu, Port 1 Menu Layout

See Figure 4-9

Figure 4-10. Port 2 (with Serial Interface Option) Menu Layout

Page 43

4.7.4 Port 2 with USB Interface Option

DEVICE TERMIN

DRIVE

HOSTPC

PRINTER2

PRINTER1

KEYBOARD

NODEVICE

DRIVE

AUTO

CR/LF

EOLDLY

number

ECHO

OFF

RESPONSE

OFF

STREAM

OFF

INDUST

LFT

INPUT

CMD

PROGIN

…

PORT 2

……

SERIAL

Figure 4-11. Port 2 (with USB Interface Option) Menu Layout

Device Menu Parameters

DRIVE TERMIN, INPUT, DEVICE AUTO TERMIN, ECHO, RESPONSE, EOLDLY, STREAM, INPUT, DEVICE

If STREAM is set to LFT or INUST, SOURCE, SFMT and TOKENS display after STREAM NODEVICE No parameters available HOSTPC TERMIN, ECHO, RESPONSE, EOLDLY, STREAM, INPUT, DEVICE

If STREAM is set to LFT or INUST, SOURCE, SFMT and TOKENS display after STREAM PRINTER1 TERMIN, EOLDLY, STREAM

If STREAM is set to LFT or INUST, SOURCE, SFMT and TOKENS display after STREAM PRINTER2 TERMIN, EOLDLY, STREAM

If STREAM is set to LFT or INUST, SOURCE, SFMT and TOKENS display after STREAM KEYBOARD INPUT, DEVICE

Table 4-9. Menu Parameters for Device Selected

Configuration

Page 44

920i Programmable Indicator/Controller

PORT 3

SERIAL

PROGIN CMD

SCALE IND SC IQUBE2DISPLAY ICELL

BAUD

600

1200

38400

115200

57600

300

2400

28800

9600

4800

19200

TERMIN

CR/LF

EOLDLY

number

BITS

8NONE

7ODD

7EVEN

8ODD

8EVEN

STOP BITS

HANDSHK

OFF

XONXOFF

OFF

INDUST

LFT

4KEYS

DISPLAY

KEYPAD

STREAM

ADDRESS

number

If PORTTYPE = 485

PORTTYPE

232

485 422

Port 4 Only

PRIMAR

SECNDR

TOKENS

TERTIA

NET

GROSS

MOTION

INVALID

ZERO

RANGE

TARE

If PORT = SCALE or IND SC

format

SFMT

If PORT = CMD or PROGIN and stream is set to

LFT or INDUST, these parameters are displayed.

For selections in SFMT and TOKENS,

refer to If PORT = SCALE or IND SC list.

Scale X

SOURCE

format

SFMT

varies

TOKENS

ECHO

OFF

RESPONSE

OFF

If PORT = PROGIN,

CMD or DISPLAY

4.7.5 Port 3 and 4 Menu Structure

Port Menu Parameters

PROGIN BAUD, BITS, TERMIN, STOP BITS, ECHO, RESPONSE, EOLDLY, HANDSHK, PORTTYPE (Port 4 Only), STREAM

CMD BAUD, BITS, TERMIN, STOP BITS, ECHO, RESPONSE, EOLDLY, HANDSHK, PORTTYPE (Port 4 Only), STREAM

SCALE BAUD, BITS, TERMIN, STOP BITS, EOLDLY, HANDSHK, SFMT, TOKENS, PORTTYPE (Port 4 Only), STREAM IND SC BAUD, BITS, TERMIN, STOP BITS, EOLDLY, HANDSHK, SFMT, TOKENS, PORTTYPE (Port 4 Only), STREAM DISPLAY BAUD, BITS, TERMIN, STOP BITS, ECHO, RESPONSE, EOLDLY, HANDSHK, PORTTYPE (Port 4 Only), STREAM IQUBE2 CONFIG, COMM SEL UPDATE

38 Visit our website www.RiceLake.com

Figure 4-12. Port 3 & 4 Menu Layout

If STREAM is set to LFT or INDUST – SOURCE, SFMT, TOKENS display after STREAM

Table 4-10. Port 3 and 4 Menu Parameters

Page 45

Configuration

Parameter Description

BAUD Baud Rate – select transmission speed for port;

Settings: 9600 (default),19200, 28800, 38400, 57600, 115200, 300, 600, 1200, 2400, 4800

NOTE: The maximum baud rate for ports on serial expansion cards (port number greater than 8) is 19200

BITS Data Bits – selects number of data bits and parity of data transmitted or received by the port.

Settings: 8NONE (default), 7EVEN, 7ODD, 8ODD, 8EVEN

DEVICE (Port 2 - only with USB)

ECHO Echo – specifies if characters received by the port are echoed back to the sending unit; Settings ON (default), OFF EOLDLY End-of-Line Delay – sets the delay period, in 0.1 second intervals, from when a formatted line is terminated to the beginning of the next

HANDSHK Handshaking – specifies whether XON/XOFF flow control characters or hardware handshaking (available only on Port 2) is used;

PORTTYPE Port Type – specifies what Port 4 is used for; if 485 is selected, follow the prompts to specify RS-485 address, see Table 4-12;

RESPONSE Response – sets the port to transmits replies to serial commands; Settings: ON (default) OFF SFMT Stream Format – used for streamed data (SCALE or IND SC scale types); Consolidated Controls format is default; see Section 13.4

SOURCE Source – specifies the source scale for data streamed from the port, if STREAM is set to LFT or INDUST STOP BITS Stop Bite – selects number of stop bits transmitted or received by the port; Settings: 2 (default), 1 STREAM Stream – specifies what data, if any, is streamed from the port;

TERMIN Termination Character – selects termination character for data sent from the port; Settings: CR/LF (default), CR TOKENS TOKENS – (if STREAM is set to LFT or INDUST) parameter can be used to replace tokens used in the data stream from the indicator

Device – selects the target USB device to be used; Settings:

• AUTO – automatically detects the device (default)

• NODEVICE – is used for iRite programming and for safely removing a flash drive

• HOSTPC – is used when connecting directly to a PC. The PC will automatically assign a virtual comm port. Check

• PC – settings to determine which port is assigned

• PRINTER1 – used if one printer is connected

• PRINTER2 – used only if a USB hub is connected; allows more than one Type-B connection; lowest printer ID# is Printer1

• KEYBOARD – supports USB keyboards

• DRIVE – supports USB 2.0 flash drives formatted to the FAT-32 or FAT-16 file system up to 4 Gig maximum

formatted serial output; value is displayed in tenths of a second (10 = 1 second); Enter Value: 0-255, 0 (default)

Settings: OFF (default), XONOFF, HRDWAR

Settings: 232 (default), 485, 422

NOTE: RS-485 communications is compatible with iQUBE ports 5 and higher.

on page 125 for other formats; see Section 4.7.8 on page 40 custom stream formatting

Settings:

• OFF - - - - - - - - - - no streaming

• LFT - - - - - - - - - - streams data at the display rate specified by the DSPRATE parameter

• INDUST - - - - - - - streams data at the A/D update rate specified by the SMPRATE parameter

NOTE: Streaming is not supported for RS-485 connections.

front panel. See Section 4.7.8 on page 40 for more information about custom stream formatting. Settings: PRIMAR, SECNDR, TERTIA, GROSS, INVALID, MOTION, ZERO, NET, OK, RANGE, TARE

. It can be specified for Port 4, and for odd numbered expansion

Table 4-11. Port 1–Port 32 Menu Parameters

4.7.6 RS-485 Port Parameters

Parameter Description

DUPLEX Duplex – sets the RS-485 communications; Settings: HALF (default), FULL ADDRESS Address – sets the decimal indicator address for RS-485 connections; Enter Value: 0-255, 0 (default)

RS-232 communications is disabled if an address other than zero is specified for this parameter

Table 4-12. RS-485 Port Parameters

Page 46

920i Programmable Indicator/Controller

4.7.7 Local/Remote Operation

For truck scale and similar applications, local/remote support provides function equivalent to that of a Legal for Trade remote display with keypad. Scale data from the local indicator is also displayed at the remote unit, and keypad input from the remote allows transactions to be initiated from either the local or remote unit.

To configure for local/remote operation, first set up the local scale (including softkey assignments, truck mode, and database information, as required). Use the SERIAL menu, serial commands, or iRev to set the Local Unit serial parameters shown in

Table 4-13. Configure the remote indicator using the serial parameters listed for the Remote Unit.

Serial

Configuration Parameter

EDP.INPUT#p CMD DISPLAY EDP.STREAM#p DISPLAY KEYPAD EDP.BAUD#p 115200 preferred; local and remote values must match EDP.ECHO#p OFF OFF EDP.RESPONSE#p OFF ON #p = port number

Local Unit Remote Unit

Parameter Value

Table 4-13. Local/Remote Configuration Parameters

4.7.8 Custom Stream Formatting

Each port can be independently configured to stream a default frame format or can be customized to stream a user-defined format. Custom formatting is very similar to the standard print formatting described in Section 8.0 on page 70.

Table 4-14 lists the format identifiers used to configure a custom stream format.

Format

Identifier

<P[G | N | T]> STR.POS# n

<U[P | S | T]> STR.PRI# n

<M[G | N | T]> STR.GROSS# n

<S> STR.MOTION# n

<B [–]n,…> Bit fields. Comma-separated sequence of bit field specifiers. Must be exactly 8 bits. Minus sign ([–]) inverts the bit.

B0 — Always 0 B1 — Always 1 B2 Configuration =1 if even parity B3 Dynamic =1 if MODE=NET B4 Dynamic =1 if COZ B5 Dynamic =1 if standstill B6 Dynamic =1 if gross negative B7 Dynamic =1 if out of range B8 Dynamic =1 if secondary/tertiary B9 Dynamic =1 if tare in system

B10 Dynamic =1 if tare is keyed

Defined By Description

Polarity – specifies positive or negative polarity for the current or specified (Gross/Net/Tare) weight on the source

STR.NEG# n

STR.SEC# n STR.TER# n

STR.NET# n STR.TARE# n

STR.RANGE# n STR.OK# n STR.INVALID# n STR.ZERO# n

scale. Possible values are SPACE, NONE, + (for STR.POS#n), or – (for STR.NEG#n) Units – specifies primary, secondary, or tertiary units for the current or specified weight on the source scale.

Mode – specifies gross, net, or tare weight for the current or specified weight on the source scale.

Status for the source scale. Default values and meanings for each status:

• STR.MOTION# n - MIn motion

• STR.RANGE# n - - OOut of range

• STR.OK# n - - - - - <space>OK

• STR.INVALID# n - IInvalid

• STR.ZERO# n - - - ZCOZ

Table 4-14. Custom Stream Format Identifiers

40 Visit our website www.RiceLake.com

Page 47

Format

Identifier Defined By Description

B11 Dynamic =00 if MODE=GROSS

=01 if MODE=NET =10 if MODE=TARE =11 (not used)

B12 Dynamic =00 if UNITS=PRIMARY

=01 if UNITS=SECONDARY =10 if UNITS=TERTIARY =11 (not used)

B13-B16 Configuration =00 (not used)

=01 if current DSPDIV=1 =10 if current DSPDIV=2 =11 if current DSPDIV=5

B17-B19 Configuration =000 if current DECPNT=8888800

=001 if current DECPNT=8888880 =010 if current DECPNT=8888888 =011 if current DECPNT=888888.8 =100 if current DECPNT=88888.88 =101 if current DECPNT=8888.888 =110 if current DECPNT=888.8888 =111 if current DECPNT=88.88888

B20 Configuration =000 if tertiary DECPNT=8888800

=001 if tertiary DECPNT=8888880 =010 if tertiary DECPNT=8888888 =011 if tertiary DECPNT=888888.8 =100 if tertiary DECPNT=88888.88 =101 if tertiary DECPNT=8888.888 =110 if tertiary DECPNT=888.8888 =111 if tertiary DECPNT=88.88888

<wspec [–] [0]

digit[[.]digit]>

<CR> — Carriage return

<LF> — Line feed

Scale weight Weight for the source scale. wspec is defined as follows:

• wspec indicates if the weight is the current displayed weight (W, w), gross (G, g), net (N, n), or tare (T, t) weight Upper-case letters specify right-justified weights; lower-case specify left-justified

• Optional /P, /S, or /T suffixes can be added before the ending delimiter (>) to specify weight display in primary (/P), secondary (/S), or tertiary (/T) units

• [–] Enter a minus sign (–) to include sign for negative values

• [0] Enter a zero (0) to display leading zeros

• digit[[.][.]digit]

The first digit indicates the field width in characters; decimal point only indicates floating decimal; decimal point with following digit indicates fixed decimal with n digits to the right of the decimal; two consecutive decimals send the decimal point even if it falls at the end of the transmitted weight field

Table 4-14. Custom Stream Format Identifiers (Continued)

Configuration

Page 48

920i Programmable Indicator/Controller

TIME

TIMEFMT TIMESEP

24HOUR

12HOUR

COMMA

COLON

DECFMT

COMMA

DOT

DSPRATE

number

CONSNUM

number

CONSTUP

number

UID

unit_ID

TRUCK

MODE1 MODE2

OFF

MODE3 MODE4

MODE5 MODE6

CFGPWD

number

SPPWD

number

KYBDLK

OFF

ZERONLY

OFF

PROMPTS

PROMPT 1-60

string

SOFTKEYS

Time/Date

Display Tare

<blank>

Display Accum

Display ROC

Setpoint

Batch Start

Batch Pause

Batch Reset

Batch Stop

Weigh In

Truck Regs

Unit ID

Weigh Out

Select Scale

Alibi

Diagnostics

Contrast

Test Stop

Go Off

USB

Screen F1-F10

LOCALE

OFF

LATUDE

number

ELEVAT

number

345

If LOCALE = ON

REGWORD

BRUTTO

GROSS

REGULAT

CANADA

NTEP

OIML

NONE

INDUST

CONTACT

ALIBI

OFF


POSITIVE

NEGATIVE

LANGUAGE

language

ENGLISH

If there is a pot, make sure to center its position

and use the CONTRAST parameter for fine-tuning.

Only available when Port 2 is set to RS-232.

Not available on USB models

DATE

DATEFMT DATESEP

DDMMYYYY YYYYMMDD

MMDDYYYY

YYYYDDMM

DASH

SEMI

SLASH

FEATURE

CONTRAST

number

4.8 Feature Menu

Parameter Description

DATE Date Format – set date format and date separator character; Settings: DATEFMT, DATESEP

TIME Time Format – set time format and separator character; Settings: TIMEFMT, TIMESEP

DECFMT Decimal Format – set decimal symbol; Settings: DOT, COMMA DSPRATE Display Update Rate – set display update rate, in number of 100-millisecond intervals between updates; Enter Value: 1-80, 1 (default)

CONSNUM Consecutive Numbering – allows sequential numbering for print operations; the consecutive number value is incremented following

CONSTUP Specifies the consecutive number start-up value used when the consecutive number is reset by sending the KCLRCN serial command

UID Unit Identification Number – value specified can be any alphanumeric value, up to eight characters; this number is also used as a folder

Use the

Time/Date softkey or the SD serial command to set the date

Use the

Time/Date softkey or the ST serial command to set the time

Example: 1 provides about 10 updates per second, the maximum value updates the display every 8 seconds

each print operation including <CN> in the ticket format; when the consecutive number is reset, it is reset to the value specified on the CONSTUP parameter; Enter Value: 0-9999999, 0 (default)

or a CLRCN digital input; Enter Value: 0-9999999, 0 (default)

name when the USB file system is used; Enter Value: unit-ID, 1 (default)

Table 4-15. Feature Menu Parameters

Figure 4-13. Feature Menu

42 Visit our website www.RiceLake.com

Page 49

Configuration

Parameter Description

TRUCK Truck Mode – if selected, the indicator switches from normal mode to the selected truck mode; Settings: OFF (default)

MODE1: Auto clear ID, keyed tares, value swapping MODE2: Auto clear ID, no keyed tares, value swapping MODE3: Stored ID, keyed tares, value swapping MODE4: Stored ID, no keyed tares, value swapping MODE5: Stored ID, keyed tares, no value swapping MODE6: Stored ID, no keyed tares, no value swapping

See Section 9.0 on page 77 for more information about using the truck modes

ALIBI Alibi Feature – specifies if data storage is used to allow reprinting of any transaction; Settings: OFF (default), ON

Use the softkey parameter to set a softkey to recall alibi for print transactions

CFGPWD Configuration Password – specify a non-zero value to restrict access to all configuration menus; Enter Value: 0-9999999, 0 (default)

To clear the indicator: press the setup switch, enter 999999 (six nines) at the configuration password prompt; unit performs a RESET-

CONFIGURATION and returns to configuration mode display NOTE: Record the password and keep it in a safe place; if lost or unavailable, the indicator must be cleared (reset configura-

tion and calibration parameters) to continue use

SPPWD Setpoint Password – set a value, above zero, to restrict access to the setpoint menu; it is shared by and can be used to protect the truck

register; if a setpoint password is specified, the password must be entered before deleting entries from the truck register; Enter Value: 19999999, 0 (indicates no password is in place)

CONTRAST SOFTKEYS

KYBDLK Keyboard Lock – disables the keypad in normal mode; Settings; OFF (default), ON ZERONLY Zero Key Only – disables all front panel keys except ZERO in normal mode; Settings; OFF (default), ON PROMPTS Prompts – for use in setpoint names; prompts are referenced by the NAME parameter under the SETPTS menu; prompts can be shown

REGULAT Regulatory mode – specifies the regulatory agency having jurisdiction over the scale site

REGWORD Regulation Word – sets the term displayed when weighing in gross mode; Settings: GROSS (default) BRUTTO CONTACT

LOCALE Locale – enables the LATUDE and ELEVAT parameters; specifying latitude and elevation of the scale site provides compensation for

LATUDE Latitude – specify the latitude of the scale site in degrees; only displayed if LOCALE=ON; Enter Value: 0-90°, 45° (default) ELEVAT Elevation – specify the elevation of the scale site in meters; Enter Value: –9999 through 9999. only displayed if LOCALE=ON; Enter

IMAGE Image – specifies if the indicator display is presented as blue-on-white or white-on-blue; Settings:

LANGUAGE Language – set the language and character set used for prompts and printing; Settings: ENGLISH (default), language

Contrast Level – adjusts contrast of display; a Use the

Add and Remove softkeys to set softkeys to be displayed in weighing mode; Settings: <blank>, Time/Date, Display Tare,

Display Accum, Display ROC, Setpoint, Batch Start, Batch Stop, Batch Pause, Batch Reset, Weigh In, Weigh Out, Truck Regs, Unit ID, Select Scale, Alibi, Diagnostics, Contrast, Test, Stop, Go, Off, Screen, F1–F10, USB

on the display during setpoint execution; Settings: PROMPT 1-60

• OIML, NTEP, and CANADA modes allow a tare to be acquired at any weight greater than zero. NONE allows tares to be acquired at any weight value.

• OIML, NTEP, and CANADA modes allow a tare to be cleared only if the gross weight is at no load. NONE allows tares to be cleared at any weight value.

• NTEP and OIML modes allow a new tare to be acquired even if a tare is already present. In CANADA mode, the previous tare must be cleared before a new tare can be acquired.

• NONE, NTEP and CANADA modes allow the scale to be zeroed in either gross or net mode as long as the current weight is within the specified ZRANGE; In OIML mode, the scale must be in gross mode before it can be zeroed; pressing the ZERO key in net mode clears the tare.

• INDUST provides a set of sub-parameters to allow customization of tare, clear, and print functions in non Legal-for-Trade scale installations; see Section 4.8.2 on page 45

The value specified for this parameter affects the function of the front panel plete description of

Contact – allows specification of contact information for use in iQUBE

gravitational effects; Settings; OFF (default), ON

NOTE: Attached scales must be re-calibrated after changing this parameter from OFF to ON; Gravitational compensation settings do not affect iQUBE

Value: –9999 through 9999 m, 345 m (default)

• Negative (default) – displays blue-on-white when using the stock LCD display, the optional outdoor display uses white-on-blue

• Positive – when using the outdoor display, blue-on-white displays, use the LCD contrast potentiometer to adjust for optimal viewing

Tare and Zero key functions for each of the regulatory modes

scales.

Contrast softkey can be set; Enter Value: 0-127, 55 (default)

Tare and Zero keys; see Table 4-19 on page 46 for a com-

alert messages; see Table 4-17 on page 44.

Table 4-15. Feature Menu Parameters (Continued)

Page 50

920i Programmable Indicator/Controller

CONTACT

address_line_1

ADDR1

address_line_2

ADDR2

address_line_3

ADDR3

contact_name_1

NAME1

PHONE1

phone_number

PHONE2

phone_number

PHONE3

phone_number

email_address

NAME2

contact_name_2

NAME3

contact_name_3

CMPNY

company_name

NEXTCAL

date

Parameter Description

DATEFMT Specifies the format used to display or print the date; Settings: MMDDYYYY (default), DDMMYYYY, YYYYMMDD, YYYYDDMM DATESEP Specifies the date separator character; Settings: SLASH (default), DASH, SEMI TIMEFMT Specifies the format used to display or print the time; Settings: 12HOUR (default), 24HOUR TIMESEP Specifies the time separator character; Settings: COLON (default), COMMA

Table 4-16. Date and Time Format Parameters

4.8.1 Contact Menu

The contact menu allows entry of contact information.

• Display contact information, in setup mode, by entering the Version menu and pressing the

• Display contact information, in weigh mode, by pressing the

Diagnostics softkey.

• Contact information may be used in print formats (see Section 8.0 on page 70).

FEATURE

Contacts softkey.

Figure 4-14. Contact Menu

Parameter Description

CMPNY Company Name – enter the name of the contact company or dealer ADDR1–ADDR3 Address – enter up to three lines of address information for the contact company NAME1–NAME3 Name – enter names of up to three contact persons PHONE1–PHONE3

NEXTCAL Next Calibration – enter the next scheduled calibration date using the month/day/year format of the DATEFMT parameter;

Phone – enter phone numbers for each of the contact persons specified for the NAME

Email – enter the email address of the contact company or dealer; If the iQUBE email messages, enter email address to send messages to; see the iQUBE

separator characters are not required

alert support is used to send automated alert

Installation Manual (PN 106113) for more information

x parameter

Table 4-17. Contact Menu Parameters

44 Visit our website www.RiceLake.com

Page 51

Configuration

REGULAT

INDUST

SNPSHOT

DISPLAY

SCALE

HTARE

YES

ZTARE

YES

KTARE

YES

MTARE

REPLACE

REMOVE

NOTHING

NTARE

YES

CTARE

YES

PRTMOT

YES

PRTPT

YES

PRTHLD

YES

HLDWGH

YES

MOTWGH

YES

AUDAGNCY

NTEP

CANADA

INDUST

NONE

OIML

CHILD ZT

YES

NEGTOTAL

YES

OVRBASE

CALIB

SCALE

FEATURE

RTARE

YES

4.8.2 Regulatory/Industrial Menu

The Industrial setting of the Regulation parameter allows customization of several tare, clear, and print functions for use in non Legal for Trade scale installations. See Section 4.8.3 on page 46 for more information about regulatory mode functions.

Figure 4-15. Regulatory/Industrial Menu Layout

Parameter Description

SNPSHOT Snap Shot – display or scale weight source; Settings: DISPLAY (default), SCALE HTARE Hold Tare – allow tare in display hold; Settings: NO (default), YES ZTARE Zero Tare – remove tare on Zero; Settings: NO (default), YES KTARE Keyed Tare – always allow keyed tare; Settings: YES (default), NO MTARE Multiple Tare – replaces existing Tare when the Tare key is pressed; Settings: Replace (default), Remove Nothing NTARE Negative Tare – allow negative or zero tare; Settings: NO (default), YES CTARE

RTARE Round Tare – round semi-automatic (pushbutton) tare to the nearest display division; Settings: YES (default), NO CHILD ZT Child Zero Tare – clear child scales individually; Settings: NO (default), YES NEGTOTAL Negative Total – allow total scale to display negative value; Settings: NO (default), YES PRTMOT Print Motion – allow print while in motion; Settings: NO (default), YES PRTPT Print Preset Tare – add PT to keyed tare print; Settings: NO (default), YES PRTHLD Print Hold – print during display hold; Settings: NO (default), YES HLDWGH Hold Weighment – allow truck weighment during display hold; Settings: NO (default), YES MOTWGH Motion Weighment – allow truck weighment in motion; Settings: NO (default), YES OVRBASE Over Base – sets an industrial scale to function like an OIML or NTEP scale (see Table 4-20 on page 46)

AUDAGNCY Audit Agency – Audit trail display agency format; Settings: NTEP (default), CANADA, INDUST, NONE, OIML

Clear Tare – allow

Settings: CALIB (default), SCALE

Clear key to clear tare/accumulator; Settings: YES (default), NO

Table 4-18. Regulatory/Industrial Menu Parameters

Page 52

920i Programmable Indicator/Controller

4.8.3 Regulatory Mode Functions

The function of the front panel Tare and Zero keys depends on the value specified for the REGULAT parameter on the Feature menu. Table 4-19 describes the function for the NTEP, CANADA, OIML, and NONE regulatory modes. functions are configurable when the REGULAT mode is set to INDUST.

Tare and Zero key

REGULAT

Parameter Value

NTEP zero or negative no no action ZERO

CANADA zero or negative no no action ZERO

OIML zero or negative no no action ZERO

NONE zero or negative no TARE ZERO

Weight on

Scale

positive no TARE

positive no TARE ZERO

positive no TARE

Tare in

System

yes CLEAR TARE

yes TARE

yes CLEAR TARE

yes no action

yes CLEAR TARE ZERO and CLEAR TARE

yes TARE ZERO and CLEAR TARE

yes CLEAR TARE

Front Panel Key Function

TARE ZERO

• if weight is within ZRANGE

• if weight is outside of

Table 4-19. Tare and Zero Key Functions for REGULAT Parameter Settings

ZRANGE, no action

Table 4-20 includes the default values of the INDUST sub-parameters and the effective (not configurable) values used by the

NTEP, CANADA, OIML, and NONE regulatory modes.

REGULAT / INDUST Parameter REGULAT Mode

Parameter Name Text Prompt INDUST NTEP CANADA OIML NONE

SNPSHOT Display or Scale weight source DISPLAY DISPLAY DISPLAY DISPLAY SCALE HTARE Allow tare in display hold NO ZTARE Remove tare on ZERO NO KTARE Always allow keyed tare YES MTARE Multiple tare action REPLACE NTARE Allow negative tare NO CTARE

RTARE Round semi-automatic (pushbutton) tare to

CHILDZT Clear child scales individually NO NEGTOTAL Allow total scale to display negative value NO PRTMOT Allow print while in motion NO PRTPT Add PT to keyed tare print NO PRTHLD Print during display hold NO HLDWGH Allow weigh during display hold NO MOTWGH Allow weighment in motion NO OVRBASE Zero base for overload calculation CALIB ZERO

Allow

Clear key to clear tare/accumulator

nearest display division

YES YES

Table 4-20. Regulat / Indust Mode Parameters, Comparison with Effective Values of Other Modes

NO NO NO YES NO NO YES NO YES NO YES YES REPLACE NOTHING REPLACE REMOVE NO NO NO YES YES NO NO YES

YES YES NO YES

NO NO NO NO NO NO NO NO NO NO NO YES NO YES YES NO NO NO NO YES NO NO NO YES NO NO NO NO CALIB ZERO CALIB ZERO SCALE ZERO CALIB ZERO

46 Visit our website www.RiceLake.com

Page 53

4.9 Print Format Menu

GFMT NFMT ACCFMT SPFMT TRWIN TRWOUT TRFMT

FMT

format

HDRFMT1

format

HDRFMT2

format

ALERT

SERV

Alert email

server

PHONE

Alert modem

phone

ALERT format ONLY

PFORMT

AUXFMT

AUXFMT1-20

FMT1

format

PORT 4

PORT 3

PORT

PORT 2

PORT 1

None

AUDITFMT

PORT 3 PORT 4

PORT 2

None

PORT

PORT 1

PORT

PORT 4

PORT 3

PORT 2

PORT 1

None

See Section 8.0 on page 70 for information about custom print formatting.

Figure 4-16. Print Format Menu

Parameter Description

GFMT NFMT ACCFMT SPFMT TRWIN TRWOUT TRFMT ALERT HDRFMT1 Header Format 1 – enter header format

HDRFMT2 Header Format 2 – enter header format AUXFMT Aux format 1-20 – enter the format and select the port as needed AUDITFMT Audit format – select the port as needed

Available Formats; Settings:

• FMT – Enter desired formant

• PORT – Select appropriate PORT 1-4 or NONE

• SERV – enter an email server for alerts (ALERT format only)

• PHONE – enter a phone number for alerts (ALERT format only)

Table 4-21. Print Format Menu

Configuration

Page 54

920i Programmable Indicator/Controller

SP CFG

BATCHNG

OFF

MANUAL

AUTO

SETPT 1-100

OFF

PLSRATPLSCNT

–NET ACCUMNETGROSS –GROSS ROC

PAUSE DELAY COUNTERWAITSS AUTOJOG

DIGIN AVG TODCOZ INMOTON INRANGE

TIMERBATCHPR CONCUR

NEVERALWAYS

DINCNT

RESREL–REL+REL %REL

CHKWEIDELTA

SETPTS

4.10 Setpoints Menu

See Section 10.0 on page 80 for more information about configuring and using setpoints. Menus for the various setpoint kinds are described in the figures listed below grouped parameters.

See Figure 10-2 on page 83

See Figure 10-3 on page 84 See Figure 10-4 on page 85

See Figure 10-5 on page 86 See Figure 10-6 on page 87

See Figure 10-7 on page 88 See Figure 10-8 on page 89 See Figure 10-9 on page 90

Figure 4-17. Setpoints Menu Layout

48 Visit our website www.RiceLake.com

Page 55

Configuration

BIT 1

INPUT

OUTPUT

OFF

ZERO

NT/GRS

BIT 2

SLOT 0

BIT 6

UNITS PRINT

TARE

ACCUM

SETPNT

TIMDATE

ESC

CLEAR

DSPTAR

KEY1 KEY2

IDKEY

KEY3

KEY4

KEY5 KEY6 KEY7

KEY9

KEYDP

KEY8

KEY0

ENTER

KBDLOC

HOLD

BATRUN

BATSTRT

BATPAUS

BATRESET

CLRCN

NET

PRIM

GROSS

SEC

CLRTAR

CLRACC

Same as BIT 1

SLOT x

…

PROGIN

NAVUP NAVDN

NAVLFT

NAVRGT

TER

BIT 1

BIT 24

Same as SLOT 0, BIT 1

…

BATSTOP

TRIGGER

OUTSLOT

PARAM

NONE

SLOT 3

number

…

DIG I/O

4.11 Digital I/O Menu

The Digital I/O menu shown in Figure 4-18 is used to assign functions to digital inputs and outputs. SLOT 0 represents the six I/O bits available on the CPU board (connector J2); additional slots, each with 24 I/O bits, are shown only if one or more digital I/O expansion cards are installed.

SLOTx – BIT n: lists available digital I/O slots.

If iQUBE

is configured on an optional serial card, that slot will also be listed for available iQUBE2 digital I/O bits.

Parameter Description

OFF Indicates that the bit is not configured INPUT Assigns the bit as a digital input used for DIGIN setpoints OUTPUT Assigns the bit as a digital output for setpoint or program use PROGIN Assigns the bit as a digital input used to generate a program event ZERO Provides the same function as the front panel ZERO key NT/GRS Provides the same function as the front panel NET/GROSS key (net/gross mode toggle) TARE Provides the same function as the front panel TARE key UNITS Provides the same function as the front panel UNITS key PRINT Provides the same function as the front panel PRINT key ACCUM Adds the current scale weight to the accumulator, if the scale accumulator is enabled SETPNT Provide the same functions as the Setpoint softkey TIMDATE Provide the same functions as the Time/Date softkey ESC Provides a function equivalent to the Cancel softkey

Figure 4-18. DIG I/O Menu

Table 4-22. Digital I/O Bit Parameters

Page 56

920i Programmable Indicator/Controller

Parameter Description

CLEAR Simulates pressing the front panel CLR key DSPTAR Displays the current tare; equivalent to pressing the Display Tare softkey IDKEY Displays a prompt to enter a new unit ID; equivalent to pressing the Unit ID softkey KEY0-9 Simulates pressing a numerical key (KEY1 = pressing the 1 key) KEYDP Simulates pressing the decimal point key on the numeric keypad ENTER Simulates pressing the front panel ENTER key NAVUP Simulates pressing the up arrow key NAVDN Simulates pressing the down arrow key NAVLFT Simulates pressing the left arrow key NAVRGT Simulates pressing the right arrow key KBDLOC Locks the keyboard (indicator front panel) when held low HOLD Holds the current display. Releasing this input clears the running average filter BATRUN Allows a batch routine to be started and run; with BATRUN active (low), the BATSTRT input starts the batch; if

BATRUN is inactive (high), BATSTRT resets the batch BATSTRT Starts or resets a batch routine, depending on the state of the BATRUN input BATPAUS Pauses a batch routine when held low BATRESET Stops the batch sequence and resets to the first batch step BATSTOP Stops the batch routine CLRCN Resets the consecutive number to the value specified in the CONSTUP parameter (FEATURE menu) GROSS Sets display to Gross mode NET Sets display to Net mode PRIM Sets display to primary units SEC Sets display to secondary units TER Sets display to tertiary units CLRTAR Clears the current tare for the active scale CLRACC Clears the active accumulator TRIGGER Used for custom applications only; see Table 4-23

Table 4-22. Digital I/O Bit Parameters (Continued)

Parameter Description

OUTSLOT Specifies the card slot receiving the trigger output; Settings: NONE (default), PORT3 PARAM Specifies the value passed as a parameter to the option card in the specified slot; Enter Value: 0 is default

Table 4-23. Digital I/O – Trigger Parameters

50 Visit our website www.RiceLake.com

Page 57

Configuration

number

SOURCE

PROG

OFFSET

20%

ERRACT

SCALE n

FULLSC

HOLD

ZEROSC

TWZERO

59650

TWSPAN

MODE

GROSS

NET

If SOURCE1≠ PROG

n = slot number of analog output card

ALGOUTn

ALGOUTn+14

If dual-channel card

installed

number

10000

MIN

number

000000

MINNEG

OFF

MAX

OFF

MAXNEG

SCALES SERIAL FEATURE PFORMT SETPTS DIG I/O

VERS

ALGOUT

4.12 Analog Output Menu

The ALGOUT menu is shown only if the analog output option is installed. If the analog output option is installed, configure all other indicator functions and calibrate the indicator itself before configuring the analog output. See the Analog Output Card Installation, PN 69089, for more information.

Figure 4-19. Analog Output Menu

Parameter Description

SOURCE Source – specifies the scale tracked by the analog output; Settings:

• PROG (default) indicates that the analog output is under program control

• SCALEn = 1-32 MODE1 Mode – specifies the weight data tracked by the analog output; Settings: GROSS (default), NET OFFSET Zero Offset – select 0% for 0–10 V or 0–20 mA output; select 20% (default) for 4–20 mA output; this parameter must be set before

calibrating the analog output

ERRACT Error Action – specifies how the analog output responds to system error conditions; Settings:

• FULLSC (default) – set to full value (10 V or 20 mA)

• HOLD – hold current value

• ZEROSC – set to zero value (0 V or 4 mA) MIN Specifies the minimum weight value tracked by the analog output; enter value: 0–9999999, 000000 (default) MINNEG Specify ON if the minimum weight (MIN parameter) is a negative value; Settings: OFF (default), ON MAX Specifies the maximum weight value tracked by the analog output; Enter value: 0–9999999, 10000 (default) MAXNEG Specify ON if the maximum weight (MAX parameter) is a negative value; Settings: OFF (default), ON TWZERO Tweak Zero – enter tweak value to adjust the analog output zero calibration; use a multimeter to monitor the analog output value;

TWSPAN Tweak Span – enter tweak value to adjust the analog output span calibration; use a multimeter to monitor the analog output value;

Enter value: 0–65535, 40 (default)

Enter value: 0–65535, 59650 (default)

Table 4-24. Analog Output Menu Parameters

Page 58

920i Programmable Indicator/Controller

SWAP

NONE

BYTE

DATASIZE

data_size

If SWAP = YES

WORD

BOTH

SCALES SERIAL FEATURE PFORMT SETPTS DIG I/O

VERS

FLDBUS

Software

version

SCALES SERIAL FEATURE PFORMT SETPTS DIG I/O VERS

4.13 Fieldbus Menu

The Fieldbus menu is only displayed if a DeviceNet, PROFIBUS®, EtherNet/IP, or ControlNet option card is installed. The SWAP parameter on the FLDBUS menu enables byte swapping by the iRite BusCommand handler rather than requiring a SWP (SWAPBYTE) instruction in the PLC. Byte swapping is enabled by default for DeviceNet cards; for all other fieldbus cards, byte swapping is disabled by default.

• BYTE swaps bytes within the word before transmission to the scanner

• WORD swaps words 1 and 2, 3 and 4, within a 4-word packet

• BOTH performs both operations, swapping bytes within a word and swapping words within the packet

• NONE disables swapping

The DATASIZE parameter sets the size of the BusCommand handler data transfers. The default value (8 bytes) matches the default data size specified in the EDS and GSD files, and used by the standard discrete transfer commands. DATASIZE can be set to any value from 2–128 bytes (1–64 words), but the value specified must match the data size set for the PLC Scanner I/O data size.

Figure 4-20. Fieldbus Menu

Parameter Description

SWAP Specifies byte-swapping used for the fieldbus card; Settings: NONE, BYTE, WORD, BOTH (Default for DeviceNet is BYTE; default for all

other cards is NONE)

NOTE: In Version 3.08 firmware, this parameter supports values of YES (byte swapping) or NO. Version 3.09 replaces YES with BYTE, NO with NONE, and adds the values WORD and BOTH.

DATASIZE Data Size – specifies the data size, in bytes, that the BusCommand handler transfers; Settings: 2-12, 8 (default); if parameter is set to a

value other than the default (8 bytes), ensure that it matches the Scanner I/O data size specified for the PLC

Table 4-25. Fieldbus Menu Parameters

4.14 Version Menu

The Version menu can be used to check the installed software version or, by using the Reset Config softkey, to restore all configuration parameters to their factory default values. There are no parameters associated with the Version menu: when selected, the indicator displays the installed software version number.

The Contacts softkey on the Version menu allows display of contact information (see Section 4.8.1 on page 44). If an iQUBE2 scale is configured, a

Diagnostics softkey also provides access to iQUBE2 diagnostic information.

Figure 4-21. Version Menu

52 Visit our website www.RiceLake.com

Page 59

5.0 Calibration

WZERO WVAL WSPAN

WLIN

REZERO

POINT 4 POINT 5POINT 1 POINT 2

POINT 3

……

CALIBR

Calibrate

WZERO WVAL

REZERO

1291

Deadload Calibration

+/- Millivolts

Zero Count =>

Last Zero Temp Zero

CALIBR

SCALE1

SCALES

The 920i can be calibrated using the front panel, serial commands or iRev. The following sections describe the calibration procedure for each of the calibration methods.

See the iQUBE

installation manual (PN 106113) for information about configuring iQUBE2 attached scales.

Calibration

Figure 5-1. Calibration Menu

5.1 Gravity Compensation

Gravity compensation for latitude and elevation is available for the 920i. To calibrate with gravity compensation, the LOCALE parameter must be set

ON. The LATUDE (latitude) and ELEVAT (elevation, in meters) parameters must also be set prior to

calibration (Section 4.8 on page 42). If the indicator is moved to a different location, gravity compensation can be applied to a pre-calibrated indicator by adjusting

the LATUDE and ELEVAT parameters.

5.2 Front Panel Calibration

The calibration menu (Section 4.6.4 on page 35) is used to calibrate the 920i. The zero, span, and linear calibration points provide a set of softkeys used specifically for calibration procedures.

+/–Toggles to allow entry of negative or positive values Last ZeroRecalls the last established zero value to allow calibration without removing tests weights or product from scale. CalibratePerforms calibration for the selected point Temp ZeroTemporarily zeros the displayed weight of a non-empty scale. After span calibration, the difference between the

temp zero and the previously calibrated zero value is used as an offset.

Millivolts (or Counts)

Toggles between display of captured A/D counts and captured millivolts values; allows entry of calibration values in mV or counts

10/20/2017 12:14PM

Figure 5-2. WZERO Calibration Display

Page 60

920i Programmable Indicator/Controller

To calibrate the indicator using the front panel:

1. Place the indicator in setup mode. Scale Configuration displays.

2. Remove all weight from the scale platform.

3. If the test weights require hooks or chains, place the hooks or chains on the scale for zero calibration.

4. Highlight the SCALES menu and press .

5. Select the scale to be calibrated.

6. Press . GRADS displays.

7. Press to CALIBR (Figure 4-8 on page 35).

8. Press to WZERO.

9. Ensure scale is empty and press to display the current WZERO value.

10. Press the

Calibrate softkey to calibrate zero. When complete, the new A/D count for the zero calibration is displayed.

11. Press to save the zero calibration value. WVAL displays.

12. Press to display the stored calibration value.

13. Enter the actual value of the calibration test weights using the numeric keypad.

14. Press to save the value. WSPAN displays.

15. Place test weights on scale.

16. Press to display the current WSPAN value.

17. Press the

Calibrate softkey to calibrate span. The new A/D count for the span calibration is displayed.

18. Press to save the span calibration value. WLIN displays.

19. An optional five-point linearization (WLIN) provides increased scale accuracy by calibrating the indicator at up to five additional points between the zero and span calibrations. See Section 5.2.1 to include in calibration. If not performing linearization, skip the WLIN parameter;

20. An optional re-zero function is used to remove a calibration offset when hooks or chains are used to hang the test weights.See Section 5.2.2 on page 55 to include in calibration.

21. Press to return to the SCALES menu or press the

Save and Exit softkey to exit setup mode.

5.2.1 Five-Point Linearization (WLIN)

If linearization values have previously been entered, these values are reset to zero during calibration.

• WZERO and WSPAN must be calibrated before adding linearization points

• WLIN values must be less than the WSPAN value and must not duplicate WZERO or WSPAN.

To perform linearization, follow the procedure below:

1. With WLIN displayed, press to go to the first linearization point (POINT 1).

2. Press to show the weight value prompt (WGT 1),

3. Press to show the weight value.

4. Place test weights on the scale,

5. Enter the actual test weight value using the numeric keypad.

54 Visit our website www.RiceLake.com

Page 61

6. Press to save the value and move to the calibration (CAL 1) prompt.

Note

7. Press to show the current calibration value,

Calibration

8. Press the

Calibrate softkey to calibrate the linearization point. When complete, the A/D count for the linear calibration

is displayed.

9. Press to save the calibration value and go to the next prompt (POINT 2).

10. Repeat for up to five linearization points.

11. Press to return to WLIN.

5.2.2 Rezero Parameter

The rezero function cannot be used with five-point linear calibration.

1. Remove all weight from the scale including test weights, hooks or chains were used during calibration.

2. Press to return to CALIBR.

3. Navigate to the REZERO.

4. Press to show the current zero value.

5. Press the

Calibrate softkey to adjust the zero and span calibration values.

6. Press or to return to CALIBR menu.

5.3 Serial Command Calibration

To calibrate the indicator using serial commands, the serial port must be connected to a terminal or personal computer. See

Section 3.3.3 on page 13 for serial port pin assignments; see Section 11.0 on page 97 for more information about using serial

commands. Once the indicator is connected to the sending device:

1. Place the indicator in setup mode. CONFIG display.

2. Remove all weight from the scale platform. If the test weights require hooks or chains, place the hooks or chains on the scale for zero calibration.

3. Send the

4. Place test weights on the scale and use the

SC.WVAL#n=vvvvv<CR>

5. Send the SC.WSPAN#n serial command to calibrate span.

6. Up to five linearization points can be calibrated between the zero and span calibration values. Use the following commands to set and calibrate a single linearization point:

The SC.WLIN#n.V1 command sets the test weight value (vvvvv) for linearization point 1. The SC.WLIN#n.C1 command calibrates the point. Repeat using the SC.WLIN#n.Vx and SC.WLIN#n.Cx commands as required for additional linearization points.

7. To remove an offset value, clear all weight from the scale, including hooks or chains used to hang test weights, then send the

8. Send the

SC.WZERO#n serial command (where n is the number of the scale) to calibrate zero.

SC.WVAL command to enter the test weight value in the following format:

SC.WLIN#n.V1=vvvvv<CR> SC.WLIN#n.C1<CR>

SC.REZERO#n serial command.

KSAVEEXIT serial command to save the calibration changes and exit setup mode.

Page 62

920i Programmable Indicator/Controller

Note

5.4 iRev Calibration

The iRev Calibration Wizard provides step-by-step scale calibration. With the 920i connected to the PC, select the Calibration Wizard from the Tools menu. See Section 6.0 on page 57 for a general overview of the iRev utility.

1. In iRev, press Tools and select Calibration Wizard.

2. Select Standard Calibration or Standard with Multi-Point Linearization.

3. Press to continue.

Figure 5-3. iRev 4 Calibration Wizard

4. Select the scale to be calibrated.

5. Enter the test weight used to calibrate the scale. If using chains or hooks to hold the weights, check the box below the test weight value entry. This adds a re-zero step to the calibration sequence.

6. Remove all weights from the scale. If chains or hooks were used, place them on the scale.

7. Press

Calibrate Zero to perform the zero calibration. A message box displays when the process is complete.

8. Apply the test weights to the scale.

9. Press

Calibrate Span to perform the span calibration. A message box displays when the process is complete.

10. If the option for chains or hooks was selected in Step 5, the Rezero displays. Remove all weights from the scale, including chains or hooks.

11. Press

ReZero to calibrate the zero offset.

12. If performing a multi-point linear calibration, up to five other calibration weight values can be entered on the display. The weights must be in ascending order and must not include zero or the span weight. Enter the weight values and

Go to calibrate each point.

press

Figure 5-4. iRev 4 Linear Calibration Display

13. Review the new calibration values and press Finish to close the Calibration Wizard.

To close without saving new values and restore the existing calibration values, press Cancel.

56 Visit our website www.RiceLake.com

Page 63

iRev

Note

IMPORTANT

Note

6.0 iRev

The iRev utility provides a suite of functions used to support configuration, calibration, customization, and backup of the 920i software. Hardware and software configuration, 920i display setup for up to ten display designs, stream and ticket formatting, setpoint configuration, database management, and iRite program editing are all supported by iRev.

Calibration values, scale, setpoint, display configuration, database tables and user programs can be saved and restored to the 920i using iRev (Section 5.4 on page 56).

Other supporting applications provided with iRev include:

• The iRev Editor provides a basic editor and a compiler for writing iRite applications

• The Rice Lake Web Update utility uses an Internet connection to check for and download updates to the iRev and 920i

software

• The iLaunch utility can be installed to display a set of icons used for convenient startup of iRev and its supporting

applications, including the help system

For systems with an iQUBE 1, use iRev 3; All other systems, use iRev 4 and higher.

iRev files are not backwards compatible. The iRev version must be newer or the same as the file to be opened.

Recommended System Requirements:

1.0+ GHz Intel compatible processor

2+ GB of RAM 4+ GB hard drive space Windows 10

Minimum System Requirements:

1.0 GHz Intel compatible processor

1 GB of RAM 850 MB hard drive space (32 bit) 2 GB hard drive space (64 bit) Microsoft Windows® 7 SP1 (32 bit, 64bit) A RS-232 port, RS-485 port, USB Port, or Ethernet (TCP/IP) (on indicators with Ethernet support)

6.1 Install iRev Program

iRev is installed using a standard Windows installation procedure. iRev applications and support files are installed in a directory named iRev; icons for the iRev application, the iRev Editor, Uninstall and the Rice Lake Web Update utility are placed in the Windows Start menu.

6.2 Open iRev

1. Install iRev on an IBM-compatible personal computer.

2. With both indicator and PC powered off, connect the PC serial port to the RS-232 pins on the indicator serial port.

If there is no serial port on port 2, refer to Section 7.0 on page 65.

3. Power up the PC and the indicator. Use the setup switch to place the indicator in setup mode.

4. Start the iRev program.

iRev provides on-line help for each of its configuration displays. Parameter descriptions provided in this manual for front panel configuration can also be used when configuring the indicator using iRev. The interface is different, but the parameters set are the same.

Page 64

920i Programmable Indicator/Controller

6.3 Saving and Opening Files

Files are stored with the .920 extension.

Save a File

Figure 6-1. File / Save As

1. Press the File menu and select Save As...

2. Navigate to the desired save location.

3. Press Save.

Open a Saved File

1. Navigate to the desired file location and double-click the file. In iRev, press the File menu and select Open...,

2. Navigate to and select the desired file.

3. Press

Open.

Open a Saved File (iQUBE 1)

1. Launch iRev 3.

2. Press the File menu and select Open...

3. Navigate to and select the desired file and press open.

6.4 Hardware Configuration

When iRev is started, the Hardware Configuration display is displayed. This display is used to create a virtual hardware configuration for the indicator by dragging and dropping icons for the supported option cards into the empty slots on the display. The slots displayed under Indicator Motherboard, represent the two option card slots on the 920i CPU board and up to twelve slots on attached expansion boards.

CPU board option

Icons to drag and drop on connections to indicate option

card slots

Figure 6-2. iRev 4 Hardware Configuration Display

58 Visit our website www.RiceLake.com

Expansion card option card slots

Page 65

iRev

6.5 Configuring Scales

Scales can be configured by selecting the System Parameters listed in the left column under Hardware. In most applications,

Scales icon, should be configured first. Each scale needs to be associated with an A/D channel or serial scale source.

the

Figure 6-3. iRev 4 Scales Menu

To assign the scale source:

1. Double-click the scale number listed in the Scales menu. The Config Scale #n box displays.

2. Select the scale source type by highlighting the circle.

3. Highlight desired source in the Sources box.

4. Press to move the selected type. They can be moved back by reversing this process.

Figure 6-4. Assign Scale Source

5. Press to save and close box.

Page 66

920i Programmable Indicator/Controller

6.5.1 Configuring Other Parameters

Once the scale source is set, configure the scale, using the remaining icons listed under System Parameters, to create a basic configuration based on the desired application type, units, capacity, and filtering requirements. The Scale Wizard is available to walk through the configuration.

Press (also available under the Tools menu) to open the Scale Wizard and follow the prompts.

Figure 6-5. Scale Wizard

Other configuration parameters, including stream, print, and display formatting, can be accessed by selecting them from the list displayed at the left side display.

6.5.2 Setpoints

Press the Setpoints icon under System Parameters to provide access to configuration parameters for up to 100 setpoints.

60 Visit our website www.RiceLake.com

Figure 6-6. Setpoints Display

Page 67

iRev

Setpoint View

• Configured setpoints can be displayed individually or in groups of 5, 10, or 100

• Setpoint parameters can be changed only when shown individually

• Click on the setpoint view icons in the tool bar to change the view

Figure 6-7. Setpoints View

When the setpoint view is set to a value greater than one, swap and move icons are added to the tool bar, allowing single or multiple setpoints to be reordered.

Batching Wizard

The Batching Wizard is used to set up a basic batch sequence, based on the batch type, number of ingredients, and several batch options.

Figure 6-8. Select Batching Wizard

1. Press Tools during viewing or changing setpoints.

2. Select Batching Wizard to open it, follow the prompts.

Figure 6-9. Batching Wizard

Page 68

920i Programmable Indicator/Controller

6.6 Configuring the Display

The iRev display editor allows the 920i display to be customized by dragging and dropping widgets onto a virtual display, then setting parameters specific to each widget type. (See Section 11.2 on page 109 for widget programming.)

• Up to 10 display configurations can be saved for each indicator file

• Display configurations can be switched within applications using custom programs to drive the 920i

Figure 6-10. Display Editor

6.7 Connecting to the Indicator

This section walks through the connecting of the PC serial port to port 2 of the 920i.

Figure 6-11. Connect to Indicator

1. Select the Hardware Configuration display.

2. Press the Connect icon. iRev attempts to establish communications to the indicator.

Once communications is established, iRev queries the indicator configuration to determine whether the indicator hardware matches the virtual hardware configured in the current iRev file.

• If the hardware matches, the Hardware Configuration section of iRev is disabled, preventing further changes

• If the hardware does not match, there is an option of either canceling the connect operation or overwriting the iRev

hardware configuration with the actual indicator hardware configuration

62 Visit our website www.RiceLake.com

Page 69

iRev

Note

6.7.1 Download to Indicator

Downloads are completed using the Communications menu in the top tool bar. There are two options available for download.

• Download Configuration – allows an iRev configuration file (with or without scale calibration data), setpoint data,

widgets, database tables or an iRite program file to be downloaded to a connected indicator in setup mode

• Download Current Display – allows the download of the currently displayed object, such as the parameter set for one

scale of a multi-scale configuration

Less data is transferred using Download Current Display, so it is typically faster than a full configuration download. There is an increased possibility that the download could fail due to dependencies on other objects.

If the download fails, try performing a complete download using the Download Configuration function. A progress message is displayed during the download indicating the progress of the download and also during the clear

memory indicating its progress.

6.7.2 Upload Configuration to iRev

Uploads are completed using the Communications menu in the top tool bar. Upload Configuration – allows the existing configuration of a connected indicator to be saved to a file on the PC.

• This configuration file provides a backup that can be quickly restored to the indicator if needed

• The file can be edited within iRev 4, then downloaded back to the indicator

The indicator must be in setup mode before uploading or downloading data.

6.8 Installing Firmware Upgrades

This section applies only to 920i units using a serial board only.

New releases of the 920i system firmware can be downloaded and installed using an Internet connection and the Rice Lake Web Update application.

Before upgrading to a new version of 920i system firmware, save a copy of the current indicator configuration using iRev (Section 6.7.2). Reloading the system firmware requires a RESETCONFIGURATION function that resets all configuration and calibration values to factory defaults.

Figure 6-12. Rice Lake iSeries Update Utility

1. Download and install the ISERIES UPDATE UTILITY from the www.ricelake.com onto a PC.

2. Open the iSeries Update Utility and press Check for Updates to check for new version of the 920i firmware.

3. Select the new firmware version and press

Get Selection to download.

4. Disconnect power to the 920i.

5. Connect the PC serial port to port 2 of the 920i. Connection must be made at 38400 bps.

Page 70

920i Programmable Indicator/Controller

J10

PORT 4

SW1

DIGITAL I/O

J15

BOOT

MODE

REMOTE

SETUP

SWITCH

Figure 6-13. SW1 Boot Mode Pins

6. Open the indicator enclosure and place a jumper across the SW1 boot mode pins.

7. Power up the 920i. The indicator stalls at the diagnostic monitor.

8. Click on the

Update Indicator button to download the new firmware. When the download begins, the following

messages are displayed:

Loading… System Diagnostic Monitor v1.14 $

$KNIX $SYSLOAD

When the download is complete, the indicator display shows the following messages:

$DONE

$BOOT

Loading…

The indicator resets and goes to weigh mode.

9. Disconnect power to the indicator.

10. Remove the jumper from across the

SW1 boot mode pins and place it on a single pin.

11. Power up the indicator and reload iRev and iRite files as necessary.

64 Visit our website www.RiceLake.com

Page 71

USB Devices

Note

7.0 USB Devices

The 920i’s USB interface port can be used to connect devices using a type-A or type-B connector.

Version 5.00.00 Rev L boards (or higher) are required for USB functionality. See the iRite programming manual for APIs which can perform USB functions. If running a user program, functions may vary.

Type B

Type A

Figure 7-1. USB Connector Types

Compatible devices using a type-A connector include a flash drive, keyboard, USB hub, and label and ticket printers. The host PC uses a type-B connector.

If using a host PC connection, this connection must terminated prior to switching devices or entering configuration mode on the 920i. Otherwise, Host PC may not display when the USB softkey is pressed once the 920i has returned to weigh mode.

Flash drives allow users to save and load configuration files (.920), save and load database files (.db), load user programs, and update the boot monitor and core firmware. Flash drives must be formatted in the FAT-16 or FAT-32 file system, cannot exceed 4 Gig drive size, cannot exceed eight character name and three character extension. Connecting a USB keyboard allows users to type alphanumeric characters rather than use the front panel buttons.

7.1 USB Driver Installation

Before connecting the 920i to a PC, the appropriate driver must be installed.

1. Open the Rice Lake website at

2. Navigate to the 920i USB page.

3. Click the Downloads tab and expand the Software category.

4. Locate the 920i USB Driver Installation entry and click Download.

5. Save the file to the computer.

6. Extract the .zip.

7. Open the .exe file. The installer automatically detects the version of Windows and installs the appropriate driver.

www.ricelake.com

Figure 7-2. 920i USB Driver Installation

Page 72

920i Programmable Indicator/Controller

Note

7.2 Connecting a USB Device

The 920i will display a list of connected USB devices. Devices in this list can include the following:

• HOSTPC – used to connect directly to a PC. The PC will automatically assign a virtual comm port. Check PC settings to

determine which port is assigned

• PRINTER1 – used if one printer is connected

• PRINTER2 – used only if a USB hub is connected, allowing more than one Type-B connection. In this case, the lowest

printer ID# will be Printer1

• KEYBOARD – supports USB keyboards

• DRIVE – supports USB 2.0 flash drives formatted to the FAT-32 or FAT-16 file system up to 4G maximum

To connect to a USB device:

1. Attach the USB device to the proper USB connector on the indicator. USB connections use Port 2 on the 920i.

2. Press the

If the USB softkey is not displayed, see Section 2.6 on page 9 and Figure 4-13 on page 42 to enable the softkey.

3. Select the proper device type and press Enter.

USB softkey.

7.3 Using USB Hubs

Hubs are necessary if multiple USB devices are desired to be simultaneously connected. To achieve best results, use a selfpowered hub and follow the below instructions when connecting devices:

1. Connect all USB devices to the hub.

2. With the 920i disconnected from power, connect the hub to the 920i.

3. Connect power to the 920i. All USB devices should be recognized on power-up.

7.4 Disconnecting a USB Device

Prior to unplugging a connected USB device,

1. Press the

If the USB softkey is not displayed, see Section 2.6 on page 9 and Figure 4-13 on page 42 to enable the softkey.

2. Select No Device* and press . This also allows a user program to switch devices via API’s.

3. The USB device is now safe to disconnect.

USB softkey.

7.5 Loading Configuration Files and Databases

Certain files may take extended periods of time to load directly from a PC to the 920i. For fastest loading times, using a Flash drive is recommended.

It is also recommended to create a folder matching each 920i’s unit ID number, if using multiple 920i units. When loading configuration files, the unit will load the file contained in a folder matching its UID# (the default UID# is 1). If no folder matching the UID is found, the unit will load the first file found.

66 Visit our website www.RiceLake.com

Page 73

USB Devices

IMPORTANT

Note

12/15/2015 01:57PM

Apply

Serial Port 2 Configuration

Save

Load File Save File

PORT2

SERIAL FEATURESCALES

PORT1 PORT3

USB: Drive

PORT4PORT4

Cancel

Load Configuration (*920)

Device and Exit

Note

7.5.1 Loading Configuration Files

When a file is loaded from a USB flash Drive, the calibration is always included and will overwrite existing calibration. To eliminate this, the 920i configuration file should be downloaded to the indicator before calibration is completed.

If loading a configuration file from a UID subdirectory, ensure the configuration file does not change the unit ID. Otherwise, a .COD file in that subdirectory will not be recognized until the UID is manually reverted to its original number.

File names are limited to eight characters.

1. Using a PC, copy the desired configuration file to the flash drive.

2. Connect the flash drive to the 920i’s type-A USB connector.

3. Press the

If the USB softkey is not displayed, see Section 4.7 on page 35 to enable the softkey.

4. Select Drive and press .

5. Place the indicator in setup mode and navigate to the SERIAL » PORT2 menu.

6. Press the

7. Select Load Configuration (*.920).

USB softkey. If the indicator does not have the USB softkey and one won’t be added, skip to Step 5.

Load File softkey.

8. Press .

7.5.2 Loading Database Files

1. Using a PC, copy the desired database file to the flash drive.

2. Connect the flash drive to the 920i Type-A USB connector.

3. Press the

4. Select Drive and press .

Figure 7-3. Load Configuration Selection *

Loading a configuration file will overwrite existing calibration values. If the file to be loaded does not have the correct calibration, record the current values so they can be entered after the download.

File names are limited to eight characters. If loading a database file, be aware the indicator uses the alias name and a .db file extension when saving database files.

USB softkey.

If the USB softkey is not displayed, see Section 4.7 on page 35 to enable the softkey.

Available menu selections will vary depending on USB device type connected. See Table 4-8 on page 35

Page 74

920i Programmable Indicator/Controller

12/15/2015

01:57PM

Load All Databases (*.db)

Save Conguration (*.920)

Save All Databases (*.db)

Drive

No Device

USB

Scale #

Scale

IMPORTANT

Note

12/15/2015

01:57PM

Save Conﬁguration (*.920)

Save All Databases (*.db)

Drive

No Device

USB

Scale #

Scale

Figure 7-4. Load All Databases selection*

5. Select Load All Databases (*.db) and press .

7.6 Saving Configuration Files and Databases

Certain files may take extended periods of time to save directly from a PC to the 920i. For fastest save times, using a Flash drive is recommended.

When saving a configuration file, the indicator will attempt to save to a folder matching its UID number (the default UID# is 1). If no such folder is found, the file will be saved to the drives root directory and overwrite any existing files matching its UID# followed by the .920 file extension i.e., 1.920i.

When the 920i saves a database, it will use the alias name and a .db file extension.

1. Connect the flash drive to the 920i’s type-A USB port.

2. With the indicator in weigh mode, press the

If the USB softkey is not displayed, see Section 2.5 on page 8 and Figure 4-13 on page 42 to enable the softkey.

USB softkey.

3. Select Save Configuration (*.920) or Save All Databases (*.db) and press Enter.

Figure 7-5. Save Configuration menu*

68 Visit our website www.RiceLake.com

Page 75

USB Devices

7.7 Loading New Firmware

Prior to loading new firmware, save existing configuration and/or databases by using the instructions in Section 7.6 on page 68.

1. Using a PC, copy the boot monitor (ipl.run) and firmware (920i.run) files to a flash drive.

2. Disconnect power and engage the SW1 jumper.

3. Connect the flash drive to the indicator and reconnect power. The following displays:

System Diagnostic Monitor v2.03, 920i loading... jumper enabled checking for connected devices... USB Interface Board checking for firmware update... loading ipl.run boot monitor. Please wait... ****** finishing load erasing FLASH boot sectors... writing to FLASH

The unit resets at this point

System Diagnostic Monitor v2.03, 920i loading... jumper enabled checking for connected devices... USB Interface Board checking for firmware update... updating boot loader erasing FLASH boot sectors... writing to FLASH... DONE cycle power to restart boot monitor

After power cycle

System Diagnostic Monitor v2.03, 920i loading... jumper enabled checking for connected devices... USB Interface Board USB Interface V1.01 On-Line: checking for firmware update... loading 920iPLUS.run boot monitor. Please wait... ******************************* finishing load erasing FLASH blocks... writing data to FLASH... DONE file load complete resetting configuration

4. Disconnect power, remove the SW1 jumper, and reconnect power

Page 76

920i Programmable Indicator/Controller

8.0 Print Format

The 920i provides print formats that determine the format of the printed output when the PRINT key is pressed, a KPRINT serial command is received, or when setpoint push-print or truck weigh-in or weigh-out operations are performed. Supported print formats are: GFMT, NFMT, ACCFMT, SPFMT, TRWIN, TRWOUT, ALERT, AUXFMT1-AUXFMT20, and AUDITFMT. Additionally, two header formats, HDRFMT1 and HDRFMT2, can be inserted into any of the other ticket formats using the

<H2> formatting commands. The particular ticket format used for a given print operation depends on the indicator

and configuration (Table 8-10 on page 73) and the particular operation performed.

Each print format can be customized to include up to 1000 characters of information, such as company name and address, on printed tickets. Use the iRev 4 configuration utility, serial commands, or the indicator front panel (PFORMT menu) to customize the print formats.

8.1 Print Formatting Commands

This section lists commands that can be used to format the 920i print formats. Commands included in the format strings must be enclosed between < and > delimiters. Any characters outside of the delimiters are printed as text on the ticket. Text characters can include any ASCII character that can be printed by the output device.

8.1.1 General Weight Data Commands

Supported Ticket Formats – GFMT, NFMT, TRWIN, TRWOUT, ACCFMT, AUXFMTxx, ALERT

Command Description

<G> Gross weight, current scale

<G#n> Gross weight, scale n

<N> Net weight, current scale

<N#n> Net weight, scale n

<T> Tare weight, current scale

<T#n> Tare weight, scale n

<S> Current scale number

Table 8-1. General Weight Data Commands

Gross, net, tare, accumulator, truck, and setpoint weights can be printed in any configured weight units by adding the following modifiers to the gross, net, and tare weight commands:

/P (primary units) /D (displayed units) /S (secondary units) /T (tertiary units)

If not specified, the current displayed units (/D) is assumed.

Example: To format a ticket to show net weight for Scale #3 in secondary units, use the following command: <N#3/ S>

Formatted weight strings contain a 10-digit weight field (including sign and decimal point, with leading zeros suppressed), followed by a space and a two-digit units identifier. Total field length with units identifier is 12 (or 13) characters.

If printing data to a ticket printer, the command <NLnn> must be put at the end of print format command in order for it print.

<H1>

70 Visit our website www.RiceLake.com

Page 77

8.1.2 Accumulator Commands

Supported Ticket Formats – GFMT, NFMT, ACCFMT, AUXFMTxx

Command Description Command Description

<A> Accumulated weight, current scale <AC#n> Number of accumulations, scale n <A#n> Accumulated weight, scale n <AT> Time of last accumulation, current scale <AA> Average accumulation, current scale <AT#n> Time of last accumulation, scale n <AA#n> Average accumulation, scale n <AD> Date of last accumulation, current scale <AC> Number of accumulations, current scale <AD#n> Date of last accumulation, scale n

Table 8-2. Accumulator Commands

8.1.3 Truck Mode Commands

Supported Ticket Formats – TRWIN, TRWOUT

Command Description

<TID> Truck ID number <TR1> Gross weight for current ticket in displayed units <TR2> Tare weight for current ticket in displayed units <TR3> Net weight for current ticket in displayed units

Table 8-3. Truck Mode Commands

TR1, TR2, and TR3 truck ticket weight data includes keywords INBOUND, KEYED, RECALLED, as necessary.

Print Format

8.1.4 Setpoint Commands

Supported Ticket Formats – SPFMT

Command Description

<SCV> Setpoint captured value <SN> Setpoint number <SNA> Setpoint name <SPM> Setpoint mode (gross or net label) <SPV> Setpoint preact value <STV> Setpoint target value

Table 8-4. Setpoint Commands

8.1.5 Auditing Commands

Supported Ticket Formats – All

Command Description

<CD> Last calibration date <NOC> Number of calibrations <NOW> Number of weighments since last calibration

Table 8-5. Auditing Commands

Last calibration date (<CD>) and number of calibrations (<NOC>) are updated whenever WZERO, WVAL, WSPAN, or REZERO are changed. Number of weighments (<NOW> command) is incremented whenever the scale weight exceeds 10% of scale capacity. Scale must return to gross or net zero before the value can be incremented again.

Page 78

920i Programmable Indicator/Controller

8.1.6 Formatting and General-Purpose Commands

Supported Ticket Formats – All

Command Description

<nnn>

<TI> Time <DA> Date <TD> Time and date <UID> Unit ID number (up to 8 alphanumeric characters) <CN> Consecutive number (up to 7 digits) <H1> Insert header format 1 (HDRFMT1); see Table 8-10 on page 73 <H2> Insert header format 2 (HDRFMT2); see Table 8-10 on page 73 <CR> Carriage return character <LF> Line feed character

<NLnn>

<SPnn>

<SU> Toggle weight data format (formatted/unformatted)

ASCII character (nnn = decimal value of ASCII character) Used for inserting control characters (STX, for example) in the print stream.

New line (nn = number of termination (<CR/LF> or <CR>) characters) If nn is not specified, 1 is assumed. Value must be in the range 1–99

Space (nn = number of spaces) If nn is not specified, 1 is assumed. Value must be in the range 1–99

Table 8-6. Formatting and General Purpose Commands

8.1.7 User Program-Dependent Commands

Supported Ticket Formats – All (<USnn>, <AN>) AUXFMTx only (<EVx>)

Command Description

<USnn> Insert user print text string (from user program, SetPrintText API) <EVx> Invoke user program print handler x (PrintFmtx) <AN> Enables the addition of an Alibi Ticket Number

Table 8-7. User Program-Dependent Commands

8.1.8 Alert Format Commands

Supported Ticket Formats – All

Command Description

<COMP> Company name (up to 30 characters) <COAR1>

See the iQUBE

<COML> Contact e-mail address (up to 30 characters) <ERR> Alert error message (system-generated) ALERT Ticket Format Only

installation manual (PN 106113) for more information about using alerts.

Contact company address, lines 1–3 (up to 30 characters)

Contact names (up to 20 characters)

Contact phone numbers (up to 20 characters)

Table 8-8. Alert Format Commands

72 Visit our website www.RiceLake.com

Page 79

Print Format

8.2 LaserLight Commands

Commands to operate the Stop, Go (circle or arrow) and Off display elements on a LaserLight. These commands are used for front panel softkeys.

Traffic Light

State Aux Fmt Dry Contact

Stop AuxFmt1 Dig0 and Dig1 open circuit |00DO3! Green Circle AuxFmt2 Dig0 open circuit; Dig1 pulled low |00DO2! Green Arrow AuxFmt3 Dig0 pulled low; Dig1 open circuit |00DO1! Off AuxFmt4 Dig0 and Dig1 pulled low |00DO0!

Serial

Command

Table 8-9. LaserLight Commands

8.3 Default Print Formats

Table 8-10 shows the default print formats for the 920i and lists the conditions under which each print format is used. HDRFMT1

and HDRFMT2 specify header information that can be used by other ticket formats. The contents of HDRFMTx can be inserted by using the <H1> and <H2> formatting commands.

Format Default Format String Used When

GFMT GROSS<G><NL2><TD><NL> Weigh mode, no tare in system

NFMT

ACCFMT ACCUM <A><NL><DA> <TI><NL>

SPFMT <SCV><SP><SPM><NL> Setpoint print operation with PSHPRNT=ON

TRWIN

TRWOUT

TRFMT REG ID: <TID>: <TR2> SCALE<S> <TD><NL> Truck register currently displayed

ALERT

HDRFMT1 HDRFMT2

AUXFMTxx GROSS<G><NL2><TD><NL> Formats AUX1FMT—AUX20FMT

AUDITFMT Fixed format; cannot be edited

NOTE: In OIML and CANADA modes, the letters PT (preset tare) are automatically inserted after the printed tare weight. When using Version 3 of iRev with older indicator software, the single auxiliary format (AUXFMT) is handled as AUXFMT1.

GROSS<G><NL>TARE<SP><T><NL>NET<SP2><N> <NL2><TD><NL>

<NL>ID<SP><TID><NL2>GROSS<TR1> <NL2><DA><SP><TI><NL>

<NL6>ID<SP><TID><NL2>GROSS<TR1><NL>TARE<SP> <TR2><NL>NET<SP2><TR3><NL2><DA><SP><TI><NL>

COMPANY NAME<NL>STREET ADDRESS<NL> CITY, ST ZIP<NL2>

Table 8-10. Default Print Formats

Weigh mode, tare in system

Accumulator enabled and displayed, or setpoint print operation with PSHACCM=ON

Press the

Alert message is sent to specified port when error indication is generated by an attached iQUBE

See the iQUBE2 Installation Manual (PN 106113) for more information

Must be inserted into other print format

Press

a DUMPAUDIT serial command

Weigh In softkey, enter truck ID number, and press Enter

Weigh Out softkey, enter truck ID number, and press Enter

Print when audit trail is displayed, or in response to

Page 80

920i Programmable Indicator/Controller

GFMT NFMT ACCFMT SPFMT TRWIN TRWOUT TRFMT

FMT

format

HDRFMT1

format

HDRFMT2

format

ALERT

SERV

Alert email

server

PHONE

Alert modem

phone

ALERT format ONLY

PFORMT

AUXFMT

AUXFMT1-20

FMT1

format

PORT 4

PORT 3

PORT

PORT 2

PORT 1

None

AUDITFMT

PORT 3 PORT 4

PORT 2

None

PORT

PORT 1

PORT

PORT 4

PORT 3

PORT 2

PORT 1

None

8.4 Customizing Print Formats

The following sections describe procedures for customizing print formats using the iRev 4 configuration utility, serial commands, or the front panel (PFORMT menu). See Section 4.7.8 on page 40 for information about custom stream formatting.

8.4.1 Using iRev

The iRev 4 configuration utility provides a ticket formatting grid with a tool bar. The grid allows the construction of the ticket format without using the formatting commands (<NL> and <SP>) required by the front panel or serial command methods. Using iRev 4, type text directly into the grid, then select weight value fields from the tool bar and place them where they will appear on the printed ticket.

Figure 8-1. iRev Print Format Editor

8.4.2 Using the Front Panel

If there is no access to equipment for communication through a serial port or are working at a site where such equipment cannot be used, use the PFORMT menu to customize the print formats

Each print format can be edited from the front panel using a character selection. Use the navigation keys (up, down, left, right) to move around and between the format command line and the character selection list.

74 Visit our website www.RiceLake.com

Figure 8-2. Print Format Menu Layout

Page 81

Print Format

Cancel

FMT PORT

PORT

GROSS<G><NL2><TD><NL>

A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

Default Restore

GFmt => GROSS<G><NL2><TD>

Home End

GFMT

PFORMT

a b c d e f g h i j k l m n o p q r s t u v w x y z

! # $ & ? @ ( ) < > + * % = / \ “ . , : ; ” ^ _ “ | ~ [ ] { }

Note

10/20/2017

12:14PM

Figure 8-3. Character Selection

To add a character:

1. Position the cursor in the format where the character is to be added.

2. Use the

3. Use the navigation keys to highlight the character to add and press

up key to return to the character selection list.

Enter.

The new character is added to the left of the current cursor location in the format string. To add a blank space to a string:

1. Position the cursor to the right of where the space is to be inserted in the format string

2. Highlight the SP character in the selection list and press

enter.

To delete a character:

1. Position the cursor to the right of the character to be deleted from the format string.

2. Press the

Clear key.

To add a special character:

1. Insert the

< and > delimiter characters from the selection list.

2. Use the numeric keypad to insert the decimal ASCII value (1–255) of the character between the delimiters.

Example, insert <2> to add the STX character to the print format.

To save the edited format string: Position the cursor in the format string and press enter. Softkeys shown on the character selection display provide additional

functions:

Default – Restores the string to its default value. Home – Positions cursor at the beginning of the format string. Cancel – Exits without saving changes to the format string. End – Positions cursor at the end of the format string. Restore – Restores the string to its previously saved value.

Print Test softkey is shown under the FMT parameter after exiting the character selection display. If a printer is attached, this

A key can be used to verify the edited string format before exiting setup mode.

The Print Test softkey is not available for the HDRFMTx formats. These formats can be output only when inserted into one of the printable ticket formats by using the <H1> or <H2> print format commands.

Page 82

920i Programmable Indicator/Controller

8.4.3 Using Serial Commands

Using a PC, terminal, or remote keyboard attached to one of the 920i serial ports, use the serial command set described in

Section 8.1 on page 70 to customize the print format strings.

To view the current setting of a format string, type the name of the print format and press the the current configuration of the GFMT format, type GFMT.FMT and press

Enter. The indicator responds by sending the current

configuration for the gross format:

GFMT.FMT=<G> GROSS<NL>

To change the format, use the GFMT.FMT or NFMT.FMT serial command followed by an equals sign (=) and the modified print format string. For example, to add the name and address of a company to the gross format, send the following serial command:

GFMT.FMT=MOE'S DUMP<NL>2356 EAST HIGHWAY ROAD<NL>SMALLTOWN<NL2><G> GROSS<NL>

A ticket printed using this format might look like the following:

MOE'S DUMP 2356 EAST HIGHWAY ROAD SMALLTOWN

1345 LB GROSS

The ticket above could also be formatted by specifying the company address information in the HDRFMT1 ticket format, then substituting the <H1> command for the address in the GFMT ticket format:

HDRFMT1=MOE'S DUMP<NL>2356 EAST HIGHWAY ROAD<NL>SMALLTOWN<NL2> GFMT.FMT=<H1><G> GROSS<NL>

enter key. For example, to check

76 Visit our website www.RiceLake.com

Page 83

Truck Modes

Note

Weigh OutWeigh In Truck Regs

lbGross

9.0 Truck Modes

The truck in/out modes are used to handle multiple truck ID numbers and weights. Truck IDs can be up to 16 alphanumeric characters in length.

Six truck modes combine stored ID, keyed tare, and value swapping features in various ways:

Value

Mode Stored IDs Keyed Tares

MODE1 NO YES YES MODE2 NO NO YES MODE3 YES YES YES MODE4 YES NO YES MODE5 YES YES NO MODE6 YES NO NO

OFF

Table 9-1. Truck Mode Features

Stored IDs – keeps a database of truck IDs and weigh-in weights in the indicator’s memory. The indicator can automatically store up to 1000 truck IDs and tares; or it can clear the information after printing a weigh-out ticket. For example, if the same truck seldom crosses the scale, it may not be practical to save its ID number and weigh-in weight. However, if that same truck crosses the scale many times each day, it’s more convenient to store the information in the indicator memory and recall it when needed. Stored IDs and weights are available in modes 3, 4, 5, and 6.

Keyed tares – allows manual entering of the tare weight using the numeric keypad and the in modes 1, 3, and 5. To use keyed tares, an incoming truck must be empty at weigh-in, full at weigh-out.

Swapping

Tare key. Keyed tares are available

Some local regulations require the tare weight to be read from the scale. If so, don’t use the keyed tares feature.

Value swapping – ensures that the lowest of two weight values associated with a particular ID number is used as the tare weight. For example, if a truck crosses the scale fully loaded at weigh-in, then unloads and crosses the scale empty at weighout, the indicator automatically assigns the lesser (empty truck) weight as the tare. Value swapping is available in modes 1, 2, 3 and 4.

9.1 Using the Truck Modes

To select a truck in/out mode:

1. Press the setup switch to enter setup mode.

2. Use the navigation keys to go to the FEATURE menu.

3. Navigate to the TRUCK sub-menu to select the mode.

4. Go

right to the softkeys sub-menu and configure the Weigh In, Weigh Out, and Truck Regs softkeys. These keys are

required when using the truck modes.

10/20/2017

12:14PM

Scale #1

12500

Figure 9-1. Truck Mode Softkeys

Page 84

920i Programmable Indicator/Controller

Note

9.2 Using the Truck Regs Display

The Truck Regs display is shown by pressing the Truck Regs softkey in weighing mode. The display contains an alphabetical list of stored truck IDs, weigh-in weights (in primary units), and the time and date of the weigh-in transaction

Figure 9-2. Truck Register Display

Softkeys shown at the bottom of the Truck Regs display are described below.

Page Up – displays previous page of the truck register. Page Down – displays next page of the truck register. Cancel – exits to weighing mode. Delete – deletes the highlighted truck ID from the truck register. Delete All – deletes all truck IDs from the truck register.

The truck register can be printed to an attached printer by pressing the printed register uses the TRFMT print format. See Section 8.3 on page 73.

If a non-zero setpoint password is configured (SPPWD parameter on the FEATURE menu), password must entered before any truck register entries can be deleted.

Print key while the Truck Regs display is shown. The

9.3 Weigh-In Procedure

In modes 1 and 2, the indicator erases truck ID numbers and tare weights from memory after the transaction. In modes 3–6,the truck ID and weigh-in weight values are saved after the weigh-out ticket has been processed.

The general weigh-in procedure is as follows:

1. The empty truck moves onto the scale for weigh-in.

2. Press the

3. A prompt is shown to enter the truck ID (up to eight alphanumeric characters). Enter the ID, then press the

4. Indicator generates the weigh-in ticket:

5. Truck leaves the scale.

Weigh In softkey.

Enter key.

ID 304812 GROSS 15000. LB INBOUND 01/14/2002 10:24 AM

78 Visit our website www.RiceLake.com

Page 85

Truck Modes

9.4 Weigh-Out Procedure

The general weigh-out procedure is as follows:

1. The loaded truck moves onto the scale for weigh-out.

2. If truck ID is known, press the If ID is not known, press the

note the ID number, then press the Cancel softkey to return to the weight display. From the weight display, press Weigh

, key in the ID, then press the Enter key.

Out

3. Indicator generates the weigh-out ticket. In modes 1 and 2, the ID is deleted once the weigh-out ticket is processed.

Weigh Out softkey, enter the ID, and press the Enter key.

Truck Regs softkey to view list of stored IDs (Figure 9-2). Scroll to the correct truck ID,

9.5 Single-Transaction Tare Weights and IDs

One-time transactions are supported in all modes that can be configured to use stored IDs (modes 3–6). This function allows one-time weighing of trucks without adding the truck ID and weigh-in weight to the permanent truck register.

To use this function, press the a decimal point as part of the ID are erased from the truck register when the transaction is complete.

Weigh In or Weigh Out softkey, then enter a truck ID containing a decimal point. IDs entered with

Page 86

920i Programmable Indicator/Controller

Note

10.0 Setpoints

The 920i indicator provides 100 configurable setpoints for control of both indicator and external equipment functions. Setpoints can be configured to perform actions or functions based on specified parameter conditions. Parameters associated with various setpoint kinds can, for example, be configured to perform functions (print, tare, accumulate), to change the state of a digital output controlling indicator or external equipment functions, or to make conditional decisions.

Weight-based setpoints are tripped by values specified in primary units only.

10.1 Batch and Continuous Setpoints

920i setpoints can be either continuous or batch setpoints. Continuous setpoints are free-running: the indicator constantly monitors the condition of free-running setpoints at each A/D

update. The specified setpoint action or function is performed when the designated setpoint parameter conditions are met. A digital output or function assigned to a free-running setpoint continuously changes state, becoming active or inactive, as defined by the setpoint parameters.

Batch setpoints are active one at a time, in an ordered sequence. The 920i can use setpoints to control up to 100 separate batch processing steps.

A digital output associated with a batch setpoint is active until the setpoint condition is met, then latched for the remainder of the batch sequence.

To use batch setpoints, activate the BATCHNG parameter on the SETPTS menu. This parameter defines whether a batch sequence is automatic or manual. AUTO sequences repeat continuously, MANUAL sequences require a BATSTRT signal. The BATSTRT signal can be initiated by a digital input, serial command, an iRite program.

For setpoint kinds that can be used as either continuous or batch setpoints, the BATCH parameter must also be set ON. (Setpoint kinds that can only be used as batch setpoints do not require the BATCH parameter.) If the setpoint is defined but the BATCH parameter is off, the setpoint operates as a continuous setpoint, even during batch sequences.

In applications that contain both batch setpoint routines and continuous setpoints, continuous setpoints should be kept separate from the batch sequence. This is especially true when using CONCUR or TIMER setpoints to perform actions or functions based on the batch sequence. CONCUR and TIMER setpoints should not be included in the referenced START and END setpoint sequence.

Batch Start softkey, or the StartBatch function in

Kind Description Batch Continuous

OFF Setpoint turned off/ignored GROSS Gross – performs functions based on gross weight; target weight entered is considered a positive gross weight X X NET Net – performs functions based on net weight; target weight entered is considered a positive net weight value X X –GROSS Negative Gross – performs functions based on gross weight; target weight entered is considered a negative gross X X –NET Negative Net – performs functions based on net weight; target weight entered is considered a negative net weight X X ACCUM Accumulator – compares value of setpoint to source scale accumulator; accumulator setpoint is satisfied when

value of source scale accumulator meets the value and conditions of the accumulator setpoint ROC Rate of Change – performs functions based on the rate-of-change (ROC) value X X +REL Positive Relative – performs functions based on a specified value above a referenced setpoint, using the same

weight mode as the referenced setpoint –REL Negative Relative Setpoint – performs functions based on a specified value below a referenced setpoint, using

the same weight mode as the referenced setpoint %REL Percent Relative Setpoint – performs functions based on a specified percentage of the target value of a

referenced setpoint, using the same weight mode as the referenced setpoint; the actual target value of the %REL

setpoint is calculated as a percentage of the target value of the referenced setpoint RESREL Result Relative – relative to a result setpoint; performs functions based on specified percentage of captured value

of a referenced setpoint, using same weight mode as referenced setpoint; actual target value of RESREL setpoint

is calculated as a percentage of captured value of the referenced setpoint, rather than the target value PAUSE Pause – pauses the batch sequence indefinitely; BATSTRT signal must be initiated to continue the batch process X DELAY Delay – delays batch sequence for a specified time; length of delay (in 0.1 sec) is specified in VALUE parameter X WAITSS Wait for Standstill – suspends the batch sequence until the scale is at standstill X

Table 10-1. Setpoint Kinds

X X

80 Visit our website www.RiceLake.com

Page 87

Setpoints

Kind Description Batch Continuous

COUNTER Counter – specifies number of consecutive batch sequences to perform; counter setpoints should be placed at

beginning of a batch routine AUTOJOG Auto Jog – automatically checks the previous weight-based setpoint to verify the setpoint weight value is satisfied

in a standstill condition; if previous setpoint was not satisfied when at standstill, the AUTOJOG setpoint activates

the digital output of previous weight-based setpoint for a period of time, specified on the VALUE parameter;

auto-jog process repeats until previous weight-based setpoint is satisfied when the scale is at standstill

NOTE: An AUTOJOG digital output is used to signify an auto-jog operation is being performed. AUTO-

JOG should not be assigned to the same digital output as the related weight-based setpoint.

COZ Center of Zero – monitors for a gross zero condition; digital output associated with this setpoint kind is activated

when the referenced scale is a center of zero; no value is required for this setpoint INMOTON In Motion – monitors for an in-motion condition; digital output associated with this setpoint is activated when the

scale is not at standstill; no value is required for this setpoint INRANGE In Range – monitors for an in-range condition; digital output associated with this setpoint is activated when the

scale is within capacity range; no value is required for this setpoint. BATCHPR Batch Processing Signal – digital output associated with this setpoint is activated whenever a batch sequence is

in progress; no value is required for this setpoint TIMER Timer – tracks the progress of a batch sequence based on a timer; timer value (in 0.1 sec) on the VALUE param-

eter, determines the length of time allowed between start and end setpoints; indicator START and END parame-

ters are used to specify the start and end setpoints; if the END setpoint is not reached before the timer expires,

the digital output associated with this setpoint is activated CONCUR Concur – allows a digital output to remain active over a specified portion of the batch sequence; two types of con-

cur setpoints can be configured:

Type 1 (VALUE=0): the digital output associated with this setpoint becomes active when the START setpoint

becomes the current batch step and remains active until the END setpoint becomes the current batch step

Type 2 (VALUE > 0): if a non-zero value is specified for the VALUE parameter, that value represents the timer, (in

0.1 second) for this setpoint; the digital output associated with this setpoint becomes active when the START

setpoint becomes the current batch step and remains active until the timer expires

NOTE: The digital output assigned to the Concur Setpoint should not be used by another Concur

setpoint; this may cause a conflict in setting the output state.

DIGIN Digital Input – requires a specific group of digital inputs to be in low (0 VDC) state to satisfy the setpoint; digital

output associated with this setpoint is held in low (0 VDC) state until inputs selected for digital input mask are all

in a low state AVG Average – performs functions based on calculated average weight over a specified number of A/D samples

NOTE: This setpoint is based on the raw A/D weight value, rather than the rounded value shown on the

display. Example: if 50.0 displays, but the actual raw A/D value is 49.99, the setpoint is not be satisfied.

TOD Time of Day – performs functions when the internal clock time of the indicator matches the specified setpoint time X X DELTA Delta Weight – satisfied when change in weight on the scale is equal to or exceeds the absolute value specified

for the setpoint CHKWEI Checkweigher – allows specification of over- and under-weight value; up to three digital outputs can be

configured to represent overweight, underweight, and accept conditions PLSCNT Pulse Counter – performs functions based on pulse counts received by a pulse input card X X PLSRAT Pulse Rate – performs functions based on the pulse rate received by a pulse input card X ALWAYS Always – setpoint always satisfied; typically used to provide an endpoint for true/false branching batch routines X NEVER Never – setpoint is never satisfied; it is used to branch to a designated setpoint in true/false branching batch

routines in which batch will not continue through the normal sequence of batch setpoints DINCNT Digital Input Count – counts pulses received at the specified digital input X X

X X

Table 10-1. Setpoint Kinds (Continued)

Page 88

920i Programmable Indicator/Controller

SP CFG

BATCHNG

OFF

MANUAL

AUTO

SETPT 1-100

OFF

PLSRATPLSCNT

–NET ACCUMNETGROSS –GROSS ROC

PAUSE DELAY COUNTERWAITSS AUTOJOG

DIGIN AVG TODCOZ INMOTON INRANGE

TIMERBATCHPR CONCUR

NEVERALWAYS

DINCNT

RESREL–REL+REL %REL

CHKWEIDELTA

SETPTS

10.2 Setpoint Menu Parameters

Figure 10-1 shows the general structure of the setpoint menu. Group menus for setpoint kinds are shown on the following

pages; parameter descriptions for the menus are provided in Table 10-3 on page 91. See Table 10-1 on page 80 for descriptions of each of the setpoint kinds.

See Figure 10-2 on page 83

See Figure 10-3 on page 84 See Figure 10-4 on page 85

SETPT 1– SETPT 100

BATCHNG Batching Enable – OFF (default), AUTO or MANUAL: allows batch sequence to run

See Figure 10-5 on page 86 See Figure 10-6 on page 87

See Figure 10-7 on page 88 See Figure 10-8 on page 89 See Figure 10-9 on page 90

Parameter Description

Setpoint Kind; Settings: OFF (default), GROSS, NET, –GROSS, –NET, ACCUM, ROC, +REL, –REL, %REL, RESREL, PAUSE, DELAY, WAITSS, COUNTER, AUTOJOG, COZ, INMOTON, INRANGE, BATCHPR, TIMER, CONCUR, DGIN, AVG, TOD, DELTA, CHKWEI, PLSCNT, PLSRAT, ALWAYS, NEVER, DINCNT Batch or Continuous Setpoints: GROSS, NET, –GROSS, –NET, ACCUM, ROC, +REL, –REL, %REL, RESREL. DIGIN, DINCNT, AVG, TOD Batch Sequences Only: PAUSE, DELAY, WAITSS, COUNTER, AUTOJOG, DELTA, PLSCNT, ALWAYS, NEVER Continuous Setpoints Only: COZ, INMOTON, INRANGE, BATCHPR, TIMER, CONCUR, PLSRAT, CHKWEI See Table 10-1 on page 80 for more information about setpoint kinds

• MANUAL: requires BATSTRT digital input, BATSTART serial command, iRite

program before the batch sequence can run.

• AUTO: allows batch sequences to repeat continuously

Figure 10-1. Setpoint Menu

Batch Start softkey, or StartBatch function in an

Table 10-2. Setpoint and Batching Menu

82 Visit our website www.RiceLake.com

Page 89

Setpoints

–NET ACCUMNET

GROSS

–GROSS ROC

Same as GROSS

number

VALUE SOURCE TRIP

HIGHER

INBAND

LOWER

OUTBAND

number

BANDVAL

number

HYSTER

PREACT

OFF

LEARN

FLOW

number

PREVAL

number

PREADJ

If TRIP=INBAND

TRIP=OUTBAND

If TRIP=HIGHER

TRIP=LOWER

If PREACT≠OFF

If TRIP=HIGHER

TRIP=LOWER

PREACT=LEARN

PREACT=FLOW

PRESTAB

number

PCOUNT

PREACT=LEARN

PREACT=FLOW

number

TOLBAND

If TRIP=HIGHER or TRIP=LOWER

and BA TCH=O N

BATCH

OFF

CLRACCM

OFF

CLRTARE

OFF

PSHACCM

OFF

PSHPRNT

OFF

PSHTARE

OFF

WAITSSONQUIET

ALARM

OFF

ACCESS

HIDE

OFF

NAME

NONE

1–60

SLOT

NONE

List of available

scales

List of available

digital I/O slots

1–100

If BATCH=ON

DIGOUT

List of available

output bits for

specied slot

If SLOT≠NONE

PREACT=LEARN

PREACT=FLOW

number

TOLCNT

GROSS, NET, –GROSS,

and

–NET setpoints only

GROSS, NET, –GROSS, and –NET setpoints only

GROSS, NET, –GROSS, –NET,

and ACCUM

setpoints only

SENSE

NORMAL

INVERT

BRANCH

Figure 10-2. GROSS, NET, –GROSS, –NET, ACCUM, and ROC Setpoint Parameters

Page 90

920i Programmable Indicator/Controller

–REL

%REL

+REL

RESREL

Same as +REL

number

VALUE TRIP

HIGHER

INBAND

LOWER

OUTBAND

number

BANDVAL

number

HYSTER PREACT

OFF

LEARN

FLOW

number

PREVAL

number

PREADJ

If TRIP=INBAND

TRIP=OUTBAND

If TRIP=HIGHER

TRIP=LOWER

If PREACT≠OFF

If TRIP=HIGHER

TRIP=LOWER

PREACT=LEARN

PREACT=FLOW

PRESTAB

PREACT=LEARN

PREACT=FLOW

number

PCOUNT

PREACT=LEARN

PREACT=FLOW

BATCH

OFF

CLRACCM

OFF

CLRTARE

OFF

PSHACCM

OFF

PSHPRNT

OFF

PSHTARE

OFF

WAITSSONQUIET

ALARM

OFF

ACCESS

HIDE

OFF

NAME

NONE

1–60

If BATCH=ON

RELNUM

1–100

SLOT

NONE

List of available

digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠NONE

number

TOLBAND

If TRIP=HIGHER or TRIP=LOWER

and BATCH=ON

number

TOLCNT

SENSE

NORMAL

INVERT

BRANCH

1–100

84 Visit our website www.RiceLake.com

Figure 10-3. +REL, –REL, %RELS and RESREL Setpoint Parameters

Page 91

Setpoints

DELAY, WAITSS, and AUTOJOG setpoints

PAUSE and COUNTER setpoints

number

VALUE

CLRACCM

OFF

CLRTARE

OFF

PSHACCM

OFF

PSHPRNT

OFF

PSHTARE

OFF

WAITSSONQUIET

ALARM

OFF

ACCESS

HIDE

OFF

NAME

NONE

1–60

ACCESS

HIDE

OFF

NAME

NONE

1–60

BRANCH

1–100

COUNTER

setpoints only

COUNTER

setpoints only

SOURCE

List of available

scales

WAITSS

setpoints only

DELAY and

WAITSS

setpoints only

SLOT

NONE

List of available digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

SLOT

NONE

List of available digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

SENSE

NORMAL

INVERT

SENSE

NORMAL

INVERT

number

VALUE

DELAY and

AUTOJOG

setpoints only

Figure 10-4. PAUSE, COUNTER, DELAY, WAITSS, and AUTOJOG Setpoint Parameters

Page 92

920i Programmable Indicator/Controller

TIMER and CONCUR setpoints

COZ, INMOTON, INRANGE, and BATCHPR setpoints

ACCESS

HIDE

OFF

NAME

NONE

1–60

ACCESS

HIDE

OFF

NAME

NONE

1–60

number

VALUE

SOURCE

List of available

scales

COZ, INMOTON,

and INRANGE setpoints only

START

1–100

END

1–100

SLOT

NONE

List of available digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

SLOT

NONE

List of available

digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

SENSE

NORMAL

INVERT

SENSE

NORMAL

INVERT

Figure 10-5. COZ, INMOTON, INRANGE, and BATCHPR Setpoint Parameters

86 Visit our website www.RiceLake.com

Page 93

DIGIN, AVG, and TOD setpoints

ALARM

OFF

ACCESS

HIDE

OFF

NAME

NONE

1–60

BATCH

OFF

CLRACCM

OFF

CLRTARE

OFF

PSHACCM

OFF

PSHPRNT

OFF

PSHTARE

OFF

WAITSSONQUIET

BRANCH

1–100

If BATCH=ON

DIGIN and AVG

setpoints only

SOURCE

List of available

scales

time entry

TIME

time entry

DURATION

TOD setpoints only

SLOT

NONE

List of available

digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

DIGIN and TOD

setpoints only

DIGIN and AVG

setpoints only

SENSE

NORMAL

INVERT

number

VALUE TRIP

HIGHER

INBAND

LOWER

OUTBAND

number

BANDVAL

If TRIP=INBAND

TRIP=OUTBAND

SOURCE

List of available

scales

number

NSAMPLE

AVG setpoints only

DIN SLOT

List of installed

digital I/O cards

DIN MASK

24-bit mask of

digital inputs

DIGIN setpoints only

Setpoints

Figure 10-6. DIGIN, AVG, and TOD Setpoint Parameters

Page 94

920i Programmable Indicator/Controller

DELTA

number

VALUE

ACCESS

HIDE

OFF

NAME

NONE

1–60

CLRACCM

OFF

CLRTARE

OFF

PSHACCM

OFF

PSHPRNT

OFF

PSHTARE

OFF

WAITSSONQUIET

BRANCH

1–100

SOURCE

List of available

scales

CHKWEI

number

SOURCE

List of available

scales

number

ACCESS

HIDE

OFF

NAME

NONE

1–60

VOVERVUNDER

SLOT

NONE

List of available

digital I/O slots

DIGOUT

List of available

output bits for

specied slot

If SLOT≠ NONE

SLOT

NONE

List of available

digital I/O slots

DUNDER

List of available

output bits for

specied slot

If SLOT≠ NONE

DACCEPT

List of available

output bits for

specied slot

DOVER

List of available

output bits for

specied slot

SENSE

NORMAL

INVERT

Figure 10-7. DELTA and CHKWEI Setpoint Parameters

88 Visit our website www.RiceLake.com

Page 95

number

number OFF

WAITSS

List of available

scales

PLSCNT

HIDE

OFF

NONE

1–60

BRANCH

1–100

SLOT

NONE

List of available digital I/O slots

number

VALUE PSHPRNT

OFF

WAITSS

SOURCE

List of available

scales

PLSRAT

ACCESS

HIDE

OFF

NAME

NONE

1–60

NONE

List of available digital I/O slots

TRIP

HIGHER

INBAND

LOWER

OUTBAND

number

BANDVAL

If TRIP=INBAND

TRIP=OUTBAND

OFF

SENSE

NORMAL

INVERT

NORMAL

INVERT

VALUE COAST PSHPRNTSOURCE ACCESS NAMEBATCH

SLOT SENSE

Setpoints

Figure 10-8. PLSCNT and PLSRAT Setpoint Parameters

Page 96

920i Programmable Indicator/Controller

ALWAYS NEVER

BRANCH

1–100

DINCNT

DIN SLOT

NONE

DIN MASK

number

VALUE

number

PRECOUNT BATCH

OFF

ACCESS

HIDE

OFF

NAME

NONE

1–60

SLOT

NONE

List of available

digital I/O slots

SENSE

NORMAL

INVERT

List of available

digital input

slots

List of digital

input bits

1–24

Figure 10-9. ALWAYS, NEVER, and DINCNT Setpoint Parameters

90 Visit our website www.RiceLake.com

Page 97

Setpoints

Parameter Description

VALUE Setpoint Value – enter a number

TRIP Trip – specifies whether the setpoint is satisfied when the weight is higher or lower than the setpoint value, within a band established

BANDVAL Band Value – setpoints with TRIP=INBAND or OUTBAND, specifies a weight equal to half the band width; band established around the

HYSTER Hysteresis – specifies a band around the setpoint value that must be exceeded before the setpoint, once off, can trip on again;

PREACT Preact – allows the digital output associated with a setpoint to shut off before the setpoint is satisfied to allow for material in suspension;

PREVAL Preact Value – specifies the preact value for setpoints with PREACT set to ON, LEARN, or FLOW; depending on the TRIP setting

PREADJ Preact Adjustment Factor – setpoints with PREACT set to LEARN, specifies a decimal representation of the percentage of error correction

PRESTAB Preact Stabilization Time-Out – setpoints with PREACT set to LEARN, specifies the time, in 0.1-sec intervals, to wait for standstill before

PCOUNT Preact Learn Interval – setpoints with PREACT set to LEARN, specifies the number of batches after which the preact value is

TOLBAND Tolerance band – setpoints with TRIP set to HIGHER or LOWER, specifies a tolerance band around the target weight; if the captured

TOLCNT Tolerance count – setpoints with TRIP set to HIGHER or LOWER, specifies the number of consecutive batch cycles in which the tolerance

RELNUM Relative Number – for relative setpoints, specifies the number of the relative setpoint; Enter Value: 1-100

BATCH Batch – specifies whether the setpoint is used as a batch (ON) or continuous (OFF – default) setpoint CLRACCM Clear Accumulator – specify ON (OFF – default) to clear the accumulator when the setpoint is satisfied CLRTARE Clear Tare – specify ON (OFF – default) to clear the tare when the setpoint is satisfied PSHACCM Push Accumulator – specify ON (OFF – default) to update the accumulator and perform a print operation when the setpoint is satisfied;

PSHPRNT Push Print – specify ON (OFF – default) to perform a print operation when the setpoint is satisfied; specify WAITSS to wait for standstill

PSHTARE Push Tare – specify ON (OFF – default) to perform an acquire tare operation when the setpoint is satisfied

• For weight-based setpoints: Specifies the target weight value, 0–9999999

• For time-based setpoints: Specifies, in 0.1-second intervals, a time value in the range 0–65535

• For COUNTER setpoints: Specifies the number of consecutive batches to be run, 0–65535

• For PLSCNT setpoints, specifies a number of pulses, 0–9999999, received by a pulse input card

• For PLSRAT setpoints, specifies a pulse rate in Hz, 0-65535, received by a pulse input card

around the value, or outside of that band; Settings: HIGHER (default), LOWER, INBAND, OUTBAND In a batch sequence with TRIP=HIGHER, the associated digital output is active until the setpoint value is reached or exceeded; with TRIP=LOWER, the output is active until the weight goes below the setpoint value

setpoint value is VALUE ±BANDVAL; Enter Value: 0-9999999

Enter Value: 0-9999999

Settings: OFF (default)

• ON – adjusts setpoint trip value up or down (depending on the TRIP parameter setting) from setpoint value using a fixed value specified on the PREVAL parameter

• LEARN – can be used to automatically adjust the PREACT value after each batch; it compares the actual weight at standstill to the target setpoint value and adjusts the PREVAL by the PREADJ value times the difference after each batch

• FLOW – provides dynamic compensation for material flow rate in determining when to shut off the digital output; rather than waiting for the specified weight to be reached, FLOW uses the change in weight over time to anticipate when the TRIP minus PREACT weight value will be reached

specified for the setpoint, the setpoint trip value is adjusted up or down by the PREVAL value; Enter Value: 0-9999999

applied (0.5 = 50%, 1.0 = 100%) each time a PREACT adjustment is made; Enter Value: 0-9999999, 0.500000 (default)

adjusting the PREACT value; setting this parameter to a value greater than zero disables the learn process if standstill is not achieved in the specified interval; Enter Value: 0-65535, 0 (default)

recalculated; the default value, 1, recalculates the preact value after every batch cycle; Enter Value: 0-65535, 1 (default)

weight is not within the specified tolerance band, the preact learn function is not applied and the batch is paused (based on the value of the TOLCNT parameter) until restarted or reset; Enter Value: 0-9999999, 0 (default)

band must be exceeded before the batch process is paused; when the specified value is met, the batch is paused and an error message is displayed; the batch must be restarted or reset to clear the error message; the special value of zero means that the batch is never paused for an out-of-tolerance condition; Enter Value: 0-65535, 1 (default)

Target weight for this setpoint is determined as follows:

• REL setpoints, the value of the relative setpoint plus the value (VALUE parameter) of the +REL setpoint

• REL setpoints, the value of the relative setpoint minus the value of the –REL setpoint

• %REL setpoints, the percentage (specified on the VALUE parameter of the %REL setpoint) of the target value of the relative setpoint

• RESREL setpoints, the percentage (specified on the VALUE parameter of the RESREL setpoint) of the captured value of the relative setpoint

specify ONQUIET to update the accumulator without printing

after setpoint is satisfied before printing

NOTE: PSHTARE acquires the tare regardless of the value specified for the REGULAT parameter on the FEATURE menu.

Table 10-3. Setpoint Parameters Descriptions

Page 98

920i Programmable Indicator/Controller

Parameter Description

NOTE: If two or more of the CLR xxxx and PSH xxxx parameters are set on, the actions specified by those parameters are performed in the following order when the setpoint is satisfied: 1) clear accumulator; 2) clear tare; 3) accumulate; 4) print; 5) acquire tare

ALARM Specify ON (OFF – default) to display the word ALARM on the primary display while the setpoint is active (batch setpoints) or while the

START Start – specifies starting setpoint number; do not specify number of the TIMER or CONCUR setpoint itself; TIMER or CONCUR setpoint

END End – specifies ending setpoint number; do not specify number of the TIMER or CONCUR setpoint itself; TIMER or CONCUR setpoint

ACCESS

NAME Name – specify number of an assigned prompt; up to 60 prompt names can be specified in the PROMPTS menu;

SLOT Slot Number – lists all available digital I/O slots; this parameter specifies the slot number of the digital I/O card referenced by the DIGOUT

DIGOUT Digital Output – lists all digital output bit numbers available for the specified SLOT; this parameter is used to specify the digital output bit

BRANCH Branch – specifies the setpoint number to which the batch sequence is to branch, if the current setpoint is not satisfied upon initial

TIME Time – for TOD setpoints, specifies the time at which the setpoint becomes active. The format used to enter the time (12-hour or 24-hour)

DURATION Duration – for TOD setpoints; specifies the length of time that the digital output associated with this setpoint changes state; value is

NSAMPLE Number of Samples – for AVG setpoints; specify the number of A/D samples used to calculate the average weight; Enter Value 1-65535 SOURCE Source – specify the scale number used as the source for the setpoint DIN SLOT Digital Input Slot – for DIGIN and DINCNT setpoints; specify the slot number from which digital inputs will be read DIN MASK Digital Input Mask – for DIGIN and DINCNT setpoints; specify the bits used as inputs to the setpoint; Use the Select softkey to select bits VUNDER Value Under – for CHKWEI setpoints; specifies the lower weight limit; Enter Value: 0-9999999 VOVER Value Over – for CHKWEI setpoints; specifies the upper weight limit; Enter Value: 0-9999999 DUNDER Digital Output Under – for CHKWEI setpoints; specifies the bit number of digital output activated when the scale weight is less than the

DACCEPT Digital Output Accept – for CHKWEI setpoints, specifies the bit number of digital output activated when the scale weight between the

DOVER Digital Output Over – for CHKWEI setpoints; specifies the bit number of digital output activated when the scale weight is greater than the

COAST Coast – for PLSCNT setpoints; specifies the time delay (in 0.1 second intervals) inserted between reaching the setpoint target value and

SENSE Sense – specifies whether the value of the digital output associated with this setpoint is inverted when the setpoint is satisfied;

setpoint is not tripped (continuous setpoints)

begins when starting setpoint begins; Enter Value: 1-100

stops when ending setpoint begins; Enter Value: 1-100 Access – specifies the access allowed to setpoint parameters shown by pressing

• ON (default): Values can be displayed and changed

• HIDE: Values cannot be displayed or changed

• OFF: Values can be displayed but not changed

Enter Value: 1-60, NONE (default)

parameter

associated with this setpoint; use the DIG I/O menu to assign bit function to OUTPUT.

NOTE: For continuous setpoints, the digital output becomes active (low) when the condition is met; for batch setpoints, the digital output is active until the setpoint condition is met

evaluation; Enter Value: 1-100, 0 (default) indicates that no branch is taken

is based on the value specified for the TIMEFMT parameter

entered in hours, minutes, and seconds (hh:mm:ss); all other operations associated with this setpoint (print, tare, or accumulate) are performed at the end of the specified duration

VUNDER value specified

VUNDER and VOVER values specified

VOVER value specified

capture of the actual pulse count; Enter Value: 0-65535

Settings: Normal (default), Invert

Setpoint softkey in normal mode.

Table 10-3. Setpoint Parameters Descriptions (Continued)

92 Visit our website www.RiceLake.com

Page 99

Setpoints

WARNING

10.3 Batch Operations

Softkeys can be configured to allow operator control of batch operations from the 920i front panel (see Figure 10-10), Softkeys can be configured using iRev 4, serial commands, or the FEATURE menu (see Section 4.8 on page 42).

Figure 10-10. Batching Softkeys

• Setpoint: Display or change assigned setpoints.

Batch Start: Starts batch process.

•

Batch Pause: Pauses an active batch and turns off all digital outputs except those associated with concurrent and timer

• setpoints. Processing is suspended until Batch Start is pressed again. Pressing Batch Start resumes the batch and reenergizes all digital outputs turned off by the

• Batch Reset: Stops and resets an active batch to the beginning of the process.

Batch Stop: Stops an active batch and turns off all associated digital outputs.

•

To prevent personal injury and equipment damage, software-based interrupts must always be supplemented by emergency stop switches and other safety devices necessary for the application.

Batch Pause.

Batching Switch

The batching switch option, PN 19369, comes as a complete unit in an FRP enclosure, with legend plate, locking stop switch (mushroom button), and a run/start/abort 3-way switch.

Both switches are wired into the indicator’s digital I/O terminal strip as shown in Figure 10-12 on page 94. Each switch uses a separate digital input.

Once cables and switches have been connected to the indicator, use the setup switch to place the indicator in setup mode. Use the digital I/O menu (Section 4.11 on page 49) to configure digital input and output functions.

Figure 10-11. Batching Switch

Page 100

920i Programmable Indicator/Controller

WARNING

RED

WHITE

BLACK

RED

BLACK

EMERGENCY STOP SWITCH

ABORT/START SWITCH

A B O R T

S T A R T

NO NC NC

NO NO

+5VDC

GND

DIO1

DIO2

DIO3

DIO4

DIGITAL I/O

12 4563

CPU BOARD

7 8

DIO5

DIO6

Note

When configuration is complete, exit setup mode. Initialize the batch by turning the 3-way switch to ABORT, then unlock the STOP button (the STOP button must be in the OUT position to allow the batch process to run). The batching switch is now ready to use.

If no digital input is assigned to BATRUN, batching proceeds as if BATRUN were always on: the batch will start when the 3-way switch is turned to START, but the STOP mushroom button will not function.

Start/

E-Stop

Closed Closed Starts Batch

Closed Open n/a Open Closed Aborts Batch Open Open Pauses Batch

DIO 1 = BatStrt (red)

DIO 2 = BatRun (white)

Abort

(Also used as restart)

To begin a batch process, turn the 3-way switch to START momentarily. If the STOP button is pushed during the batch process, the process halts and the button locks in the IN position.

The START switch is ignored while the STOP button is locked in the IN position. The STOP button must be turned counterclockwise to unlock it, then released into the OUT position to enable the 3-way switch.

To restart an interrupted batch from the step where it left off:

1. Unlock STOP button (OUT position)

2. Turn 3-way switch to START

To restart an interrupted batch from the first batch step:

1. Push the STOP button.

2. Turn 3-way switch to ABORT

3. Unlock STOP button (OUT position)

4. Turn 3-way switch to START

To abort an interrupted batch:

1. Push the STOP button.

2. Turn 3-way switch to ABORT.

3. Unlock STOP button (OUT position). A new batch can now be started.

Figure 10-12. Batching Switch Wiring Diagram Example

If the Stop button is pushed in, it is in the open position. If the Stop button is pulled out, it is in the closed position.

Use this procedure (or the BATRESET serial command) to initialize the new batch routine following any change to the setpoint configuration.

94 Visit our website www.RiceLake.com
