RHINO TM 60, TM 100, TM 72, TM 84 Parts Manual

®

®

TM 60/72

R

84/100

Rear Discharge Rotary Mowers

Pub 05-14 Part No. 00779788P

PART'S MANUAL

An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part of
the safe operation of this machine and must be maintained
with the unit at all times.
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is
not with the equipment, contact your dealer or Servis-Rhino
(800-446-5158) to obtain a Free copy before operating the
equipment.

READ, UNDERSTAND, and FOLLOW

RHINO

1020 S. Sangamon Ave.
Gibson City , IL 60936
800-446-5158
Email: [e-mail]

®

© 2007 Alamo Group Inc.

TO THE OWNER/OPERATOR/DEALER

All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who
recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to
be used with all its safety equipment properly attached to minimize the chance of accidents.

BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.

Observe the rules of safety and common sense!

WARRANTY INFORMATION:

Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration Form
in full and return it within 30 Days. Make certain the Serial Number of the Machine is recorded on the Warranty Card
and on the Warranty Form that you retain. The use of "will-fit" parts will void your warranty and can cause catastrophic
failure with possible injury or death.

PARTS

SECTION

Parts Section – 1

PARTS ORDERING GUIDE

The following instructions are offered to help eliminate needless delay and error in processing
purchase orders for the equipment in this section.

1. The Parts Section is prepared in logical sequence and grouping of parts that belong to the
basic machine featured in this manual. Part Numbers and Descriptions are given to help
locate the parts and quantities required.

2. The Purchase Order must include the name and address of the person or organization
ordering the parts, who should be charged, and if possible, the serial number of the machine
for which the parts are ordered.

3. The Purchase Order must clearly list the quantity of each part, the complete and correct part
number (be sure to include all periods), and the basic name of the part.

4. The Manufacturer reserves the right to substitute parts where applicable.

5. Some parts are unlisted items which are special production items not normally stocked and
are subject to special handling. Request a quotation for such parts before sending a
Purchase Order.

6. The Manufacturer reserves the right to change prices without prior notice.

NOTE: Please refer to The Safety Section in the front of this Manual for the proper

Part Number when ordering Replacement Safety Decals.

For maximum safety and to guarantee optimum product reliability, always use
genuine Servis-Rhino Parts. The use of inferior replacement parts may cause
premature or catastrophic failure which could result in serious injury or death.
Direct any questions regarding parts to:

RHINORHINO

RHINO

RHINORHINO

®

1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: [e-mail]

©2007 Alamo Group Inc.

Parts Section – 2

PART NAME INDEX

A-FRAME ASSEMBLY TM100................................................................................................................................................................... 4

A-FRAME ASSEMBLY TM60 72................................................................................................................................................................ 6

A-FRAME ASSEMBLY TM84..................................................................................................................................................................... 8

ANTI-SCALP ROLLER PARTS TM60 TM72 (OPTIONAL) TM84 (STANDARD)............................................................................... 10

AXLE & TIRE ASSEMBLY....................................................................................................................................................................... 11

DRIVELINE ASSEMBLY (TM100)........................................................................................................................................................... 13

DRIVELINE ASSEMBLY (TM60/TM72/TM84)....................................................................................................................................... 15

GEARBOX ASSEMBLY............................................................................................................................................................................ 16

LOWER DRIVE ASSEMBLY.................................................................................................................................................................... 18

ROLLER KIT TM100.................................................................................................................................................................................. 20

SPINDLE ASSEMBLY............................................................................................................................................................................... 21

UPPER DRIVE ASSEMBLY...................................................................................................................................................................... 22

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -3

A-FRAME ASSEMBLY TM100

ITEM PART NO. QTY. DESCRIPTION

1 00779999 1 FLAT,DRIVELINE HOLDER
2 00779751 2 WDMT,LOWER LINK - TM100
3 00786022 1 ARM,FRONT A-FRAME - LH TM100

00786021 1 ARM,FRONT A-FRAME - RH TM100 (NOT SHOWN)
4 00779659 2 ARM,UPPER LINK - TM100
5 00779644 2 ARM,REAR A-FRAME - TM100
6 00748823 5 HHCS 1/2-13UNC 1-1/2 PL5
7 00001800 14 LOCKNUT TLM 1/2 NC PLB
8 00779848 2 BUSHING,LOWER A-FRAME
9 00779850 1 BUSHING,TOP LINK
10 00001400 9 FLATWASHER 5/8 PL STD
11 00695100 12 LOCKNUT TOPLOCK 5/8NC PLB
12 00779867 6 BUSHING,UPPER LINK
13 00779869 1 PIN,TOP LINK
14 37107B13 1 CLIP-X HAIR PIN (NOT SHOWN)
15 02957007 1 HHCS 5/8 NC 5 PL8
16 00779868 2 PIN,CAT I-II QH

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -4

A-FRAME ASSEMBLY TM100

Continued...
ITEM PART NO. QTY. DESCRIPTION

17 02793900 2 HHCS 7/8-9UNC 2-1/2 GR 5
18 00750226 2 NUT TOPLOCK 7/8 NF PLC
19 00779846 2 PIN,HITCH - 1-3/16 DIA.
20 00773592 2 PIN, SAFETY LOCK LYNCH
21 00750227 2 FLATWASHER 7/8 PL STD
22 00750952 3 HEXB,5/8NC X 2-1/2,ZP,GRD5
23 02845500 3 HEXB 5/8 NC 2 PL5
24 00779866 2 BUSHING,UPPER LINK
25 00606000 2 PIN,COTTER 3/16X2
26 00776031 1 CANISTER, PARTS MANUAL

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -5

A-FRAME ASSEMBLY TM60 72

ITEM PART NO. QTY. DESCRIPTION

1 00779605 2 ARM,REAR A-FRAME - TM60

00779618 2 ARM,REAR A-FRAME - TM72
2 00779999 1 FLAT,DRIVELINE HOLDER
3 00779985 2 ARM,UPPER LINK
4 00779997 2 ARM,FRONT A-FRAME
5 00779991 2 PLATE,LOWER LINK
6 00777564 2 BUSHING,LOWER OUTSIDE HITCH
7 00773592 2 PIN, SAFETY LOCK LYNCH
8 00779866 2 BUSHING,UPPER LINK
9 00779847 2 BUSHING,LOWER A-FRAME
10 00779845 2 PIN,HITCH - 1-3/16 DIA.
11 00779869 1 PIN,TOP LINK
12 00779748 2 ASY,CAT.1 HITCH PIN W/LW & NUT
13 00779849 1 BUSHING,TOP LINK
14 37107B13 1 CLIP-X HAIR PIN
15 00779867 6 BUSHING,UPPER LINK
16 00606000 2 PIN,COTTER 3/16X2

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -6

A-FRAME ASSEMBLY TM60 72

Continued...
ITEM PART NO. QTY. DESCRIPTION

17 00750952 4 HEXB,5/8NC X 2-1/2,ZP,GRD5
18 00695100 12 LOCKNUT TOPLOCK 5/8NC PLB
19 00748823 5 HHCS 1/2-13UNC 1-1/2 PL5
20 00001800 8 LOCKNUT TLM 1/2 NC PLB
21 02845500 2 HEXB 5/8 NC 2 PL5
22 02845800 1 HEXB,5/8 NC X 4-1/2 GRD5 ZP
23 00001400 9 FLATWASHER 5/8 PL STD
24 00750227 2 FLATWASHER 7/8 PL STD
25 00776031 1 CANISTER, PARTS MANUAL

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -7

A-FRAME ASSEMBLY TM84

ITEM PART NO. QTY. DESCRIPTION

1 00779630 2 ARM, REAR A-FRAME
2 00785486 1 FLAT, DRIVELINE HOLDER
3 00779659 2 ARM, UPPER LINK TM84/TM100
4 00785716 2 ARM, FRONT A-FRAME TM84
5 00786029 1 WDMT, LOWER LINK - LH TM84

00786028 1 WDMT, LOWER LINK - RH TM84 (NOT SHOWN)
6 00777564 2 BUSHING, LOWER OUTSIDE HITCH
7 00773592 2 PIN, SAFETY LOCK LYNCH
8 00779866 1 BUSHING, UPPER LINK
9 00779848 2 BUSHING, 84/100 LOWER A-FRAME
10 00785739 2 BUSHING, TM84 A-FRAME LOWER
11 00779869 1 PIN, TOP LINK
12 00779748 2 ASY, CAT.1 HITCH PIN W/LW & NUT
13 00779850 1 BUSHING, 84/100 TOP LINK
14 37107B13 1 CLIP-X HAIR PIN
15 00779867 6 BUSHING, UPPER LINK
16 00003300 2 HEX CAP 3/4-10 X 4 GR.5

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -8

A-FRAME ASSEMBLY TM84

Continued...
ITEM PART NO. QTY. DESCRIPTION

17 00750952 4 HEXB, 5/8NC X 2-1/2, ZP, GRD5
18 00695100 12 LOCKNUT, TOPLOCK 5/8NC PLB
19 00002701 4 FLATWASHER 3/4 PL STD
20 00000200 1 NUT 3/4 NC HEX PL
21 02845500 2 HEXB, 5/8 NC PL5
22 02845800 1 HEXB, 5/8 NC X 4-1/2 GRD5 ZP
23 00001400 9 FLATWASHER, 5/8 PL STD
24 00750227 2 FLATWASHER, 7/8 PL STD
25 00776031 1 CANISTER, PARTS MANUAL

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -9

ANTI-SCALP ROLLER PARTS TM60 TM72 (OPTIONAL) TM84 (STANDARD)

ITEM PART NO. QTY. DESCRIPTION

00785018 - KIT,HD ANTI-SCALP ROLLER
1 00750959 3 HEXB,1/2NC X 1,ZP,GRD5
2 00001800 3 LOCKNUT TLM 1/2 NC PLB
3 4909 1 ROLLER-FRONT
4 00785014 1 WDMT,HD ROLLER PIN
5 00785017 1 BRACKET,TM ROLLER

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -10

AXLE & TIRE ASSEMBLY

ITEM PART NO. QTY. DESCRIPTION

1 00779851 4 BUSHING,1-1/8 AXLE DEPTH - TM60 & TM72

00779852 4 BUSHING,1-3/8 AXLE DEPTH - TM84 & 100
2 00778145 4 PIN,AXLE- TM60/72/84 (SEMI-PNEUMATIC)

00778144 4 PIN,AXLE - TM84, 100 (PNEUMATIC)
3 00779871 8 BUSHING,FLANGED
4 00779844 4 PIN,LYNCH (CLIP) 3/8 X 2.25
5 00764386 4 GREASE FITTING,8MMX1 STRAIGHT
6 00779747 4 RING,EXTERNAL SNAP - 1.125 PLT- TM60 & TM72

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -11

AXLE & TIRE ASSEMBLY

Continued...
ITEM PART NO. QTY. DESCRIPTION

7 00779743 4 RING,EXTERNAL SNAP - 1.625 PLT- TM60/72/84/100

00779742 4 RING,EXTERNAL SNAP - 1.375 PLT - TM84 & TM100
8 00002700 16 FLATWASHER 1/2 PL STD
9 00750959 7 HEXB,1/2NC X 1,ZP,GRD5
10 00001800 8 LOCKNUT TLM 1/2 NC PLB
11 00999418 4 HHCS 1/2-13UNC 3-1/2 PL5
12 00779859 4 WDMT,FORK - TM60/TM72

00779860 4 WDMT,FORK - TM72/84

00779861 4 WDMT,FORK - TM84/100
13 00779791 4 ASY,PNEUMATIC TIRE & WHEEL (TM60/TM72)

00779790 4 ASY,SEMI-PNEUMATIC TIRE & WHL (TM60/72/84)

00769884 4 TIRE-FM100 13 X 6.50-6 4PLY (TM84/TM100)

00787072 1 BEARING AND BUSHING KIT (TM60/TM72)
14 00779762 2 WDMT,AXLE - TM60

00779763 2 WDMT,AXLE - TM72

00779764 2 WDMT,AXLE - TM84

00779765 2 WDMT,AXLE - TM100

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -12

DRIVELINE ASSEMBLY (TM100)

ITEM PART NO. QTY. DESCRIPTION

00767954 2 YOKE.Q.D.KIT - PLASTIC

00775458 - DRIVELINE TRACTOR HALF 540 RPM

00775460 - DRIVELINE, 540 CAT 4

00775461 - DRIVELINE, IMPLEMENT HALF 540

00775465 1 SHIELD,INNER HALF

00777332 1 OUTER SHIELD HALF

1416601 1 ZERK
1 00775353 2 YOKE 1-3/8-6 SPLINE ASGE
10 -------- 1 INNER SHIELD
11 8393 2 BEARING RING
12 00756005 2 DECAL-ROTATING DRIVELINE
13 00756004 2 DECAL-SHIELD MISSING
14 00759217 1 SCREW 1/2 LG #8 PAN

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -13

DRIVELINE ASSEMBLY (TM100)

Continued...
ITEM PART NO. QTY. DESCRIPTION

15 00775465 1 SHIELD,INNER HALF
16 00767954 2 YOKE.Q.D.KIT - PLASTIC
2 00189700 2 CROSSKIT 35R U -JOINT KIT 35R
3 8384 2 SPRING PIN 10MM X 90MM
4 00775317 1 YOKE INBOARD 1B
5 0921000332 1 TUBE, SHAFT
6 00775426 1 PROFILE,OUTER 2A
7 00775318 1 YOKE INBOARD 2A
8 -------- 2 SHIELD CONE
9 -------- 1 OUTER SHIELD

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -14

DRIVELINE ASSEMBLY (TM60/TM72/TM84)

ITEM PART NO. QTY. DESCRIPTION

00774924A - DRIVELINE
1 00764500A 2 COMPLETE COLLAR YOKE
10 00775107 1 DRIVELINE, ASY, INNER HALF
11 00774079 2 KIT,SLIDE COLLAR REPAIR
2 00756231 2 CROSS & BEARING KIT SERIES 40
3 00759169 1 PIN ROLL 8mm X 60mm
4 00759165 1 PIN ROLL INNER TUBE
5 00764506 1 COLLAR-GUARD-RETAINER
6 00754330 6 BOLT, NYLON - SAFETY SHIELD]
7 00764507 1 COLLAR-GUARD-RETAINER
8 00768342 1 SHIELD, ASY, CMPLT
9 00768294 1 DRIVELINE, HALF ASY, OUTER

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -15

GEARBOX ASSEMBLY

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -16

GEARBOX ASSEMBLY

Continued...
ITEM PART NO. QTY. DESCRIPTION

00777688 - ASY,GEARBOX
1 00778239 1 HOUSING GEARBOX
10 00778241 1 SHAFT INPUT
11 00763206 1 SEAL, INPUT SHAFT
12 00754757 1 BEARING
13 00778242 1 COVER GEARBOX
14 00778243 1 SHIM
15 00755633 1 PLUG,3/8"
16 00756649 1 SNAP RING
17 00778244 1 GEAR ,CROWN
18 00772980 1 PLATE
19 00771879 1 SHIM
2 2716532 2 SNAP RING
20 00778245 1 SHAFT, PINION
21 00778246 1 WASHER, EXTERNAL TOOTH
22 4840 1 NUT, CASTLE
23 00771856 4 BOLT METRIC
24 00778187 1 PLUG,BREATHER DIPSTICK
25 70497 1 COTTER PIN
3 2716540 1 CAP PLUG
4 00564800 1 BEARING, BALL
5 00754761 2 SHIM
6 2716564 1 SHIM KIT
7 00755615 2 BEARING
8 2716656 1 LOCKNUT
9 00778240 1 SEAL OUTPUT

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -17

LOWER DRIVE ASSEMBLY

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -18

LOWER DRIVE ASSEMBLY

Continued...
ITEM PART NO. QTY. DESCRIPTION

1 00779818 3 PULLEY,SINGLE GROOVE - 5.8" PD

00779819 3 PULLEY,SINGLE GROOVE - 6.9" PD
2 00779831 1 V-BELT - TM60

00779832 1 V-BELT - TM72

00779833K 1 V-BELT - TM84

00779834K 1 V-BELT - TM100
3 00779772 1 SPRING,EXT. IDLER-1 OD X 5.0 L
4 00779816 2 PULLEY,IDLER - 5.75 OD - TM60

00779843 2 PULLEY,IDLER - 6.25 OD - TM72

00779817 2 PULLEY,IDLER - 6.75 OD - TM84/TM100
5 00779824 1 BEARING,IDLER ARM - 1-3/8 OD
6 00779827 1 BLADE,CCW UPDRAFT - TM60

00779828 1 BLADE,CCW UPDRAFT - TM72

00779829 1 BLADE,CCW UPDRAFT - TM84
7 15B1200 3 WASHER 3/4 P SAE
8 00765813 1 KEY-SQ 1/4 X 3/4 LG
9 00779771 1 NUT,HEX JAM CNT LOCK 5/8 NC PL
10 00766480 3 BOLT,BLADE 5/8-18 X 1-1/2 LH
11 00001400 1 FLATWASHER 5/8 PL STD
12 00777722 3 NUT,HEX TOPLOCK JAM 3/4-10 PLA
13 00753642 4 HHCS,3/8NC X 1-1/4,ZP,GRD5
14 00750952 1 HEXB,5/8NC X 2-1/2,ZP,GRD5
15 03101646 4 LOCKWASHER,3/8,MEDIUM-ZP
16 00008300 1 HHCS 5/8 NC 1-3/4 PL5
17 00695100 1 LOCKNUT TOPLOCK 5/8NC PLB
18 00779754 1 WDMT,DECK - TM60

00779755 1 WDMT,DECK - TM72

00779756 1 WDMT,DECK - TM84

00779757 1 WDMT,DECK - TM100
19 00779821 1 ASY,EXTENDED SPINDLE
20 00779750 1 WELDMENT, IDLER ARM
21 00779830 1 BLADE,CCW UPDRAFT - TM100
22 00769392 1 BLADE SUPPORT
23 00001800 2 LOCKNUT TLM 1/2 NC PLB
24 02892000 2 HHCS 12-13 NC X 1-1/2 PL8

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -19

ROLLER KIT TM100

ITEM PART NO. QTY. DESCRIPTION

1 14010060 2 BEARING
2 00770448 1 WLDMT,HEAVY DUTY ROLLER
3 00770449 1 WLDMT,HEAVY DUTY ROLLER PIN
4 00001800 3 LOCKNUT TLM 1/2 NC PLB
5 00750959 3 HEXB,1/2NC X 1,ZP,GRD5
6 00779796 1 BRACKET,ROLLER - TM100

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -20

SPINDLE ASSEMBLY

ITEM PART NO. QTY. DESCRIPTION

00779821 - ASY,EXTENDED SPINDLE
1 00766549 2 SEAL
2 70044 2 BEARING CUP LM48510
3 5312314 2 BEARING CONE LM48548
4 4720 1 GREASE FITTING 1/8 SELF TAP
5 00779823 1 HOUSING,EXTENDED SPINDLE
6 00785257 1 ASY,SHAFT W/SEAL PROTECTOR
7 00777723 1 NUT,SPECIAL ADJUSTING 1-3/8-18
8 02957080 1 SHSS 1/4 NC 1/4
9 00765411 1 SEAL,PROTECTOR

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -21

UPPER DRIVE ASSEMBLY

ITEM PART NO. QTY. DESCRIPTION

1 00779820 1 PULLEY,SINGLE GROOVE -12.5" PD (TM60/72)

00779826 1 PULLEY,SINGLE GROOVE - 9.0" PD (TM84/100)
2 00777688 1 ASY,GEARBOX
3 4840 1 NUT,HEX SLOTTED M24 X 2
4 00758582 1 SHIELD,IMPLEMENT
5 00779835 1 SHIELD,RH BELT - TM60
6 00779836 1 SHIELD,LH BELT - TM60

00779837 1 SHIELD,RH BELT - TM72

00779838 1 SHIELD,LH BELT - TM72

00779839 1 SHIELD,RH BELT - TM84

TM60 TM72 TM84 TM100
©2014 Alamo Group Inc. Parts Section -22

UPPER DRIVE ASSEMBLY

Continued...
ITEM PART NO. QTY. DESCRIPTION

00779840 1 SHIELD,LH BELT - TM84

00779841 1 SHIELD,RH BELT - TM100

00779842 1 SHIELD,LH BELT - TM100
7 00769933 6 NUT-PLASTIC KNOB 3/8 NC PL
8 00774924A 1 DRIVELINE

00775460 1 DRIVELINE, 540 CAT 4
9 70497 1 M5X50 COTTER PIN
10 00778187 1 PLUG,BREATHER DIPSTICK
11 00765813 4 KEY-SQ 1/4 X 3/4 LG
12 02961255 6 PUSHNUT, BOLT RETAINER, 3/8
13 00695100 12 LOCKNUT TOPLOCK 5/8NC PLB
14 00748823 5 HHCS 1/2-13UNC 1-1/2 PL5
15 00778246 1 WASHER,FLAT
16 00002700 16 FLATWASHER 1/2 PL STD
17 00023500 5 FLATWASHER 5/16 PL
18 00011700 4 LOCKWASHER,5/16 PL STD
19 02958784 4 BOLT METRIC 8XP1.25X20MM PL8.8
20 26168 6 CRG-BLT 3/8 X 1 GR5
21 00779996 1 PLATE,GEARBOX MOUNT
22 00008300 4 HHCS 5/8 NC 1-3/4 PL5

TM60 TM72 TM84 TM100

©2014 Alamo Group Inc. Parts Section -23

SERVIS-RHINO

LIMITED WARRANTY

1. LIMITED WARRANTIES

1.01.Servis-Rhino warrants for one year from the purchase date to the original non-commercial, governmental, or municipal
purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”)
that the goods purchased are free from defects in material or workmanship.

1.02.Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be
defective under normal use and service due to defects in material or workmanship.

1.03.This limited warranty does not apply to any part of the goods which has been subjected to improper or abnormal use,
negligence, alteration, modification, or accident, damaged due to lack of maintenance or use of wrong fuel, oil, or
lubricants, or which has served its normal life. This limited warranty does not apply to any part of any internal
combustion engine, or expendable items such as blades, shields, guards, or pneumatic tires except as specifically found
in your Operator’s Manual.

1.04.Except as provided herein, no employee, agent, Dealer, or other person is authorized to give any warranties of any
nature on behalf of Manufacturer.

2. REMEDIES AND PROCEDURES.

2.01.This limited warranty is not effective unless the Purchaser returns the Registration and Warranty Form to Manufacturer
within 30 days of purchase.

2.02.Purchaser claims must be made in writing to the Authorized Dealer (“Dealer”) from whom Purchaser purchased the
goods or an approved Authorized Dealer (“Dealer”) within 30 days after Purchaser learns of the facts on which the
claim is based.

2.03.Purchaser is responsible for returning the goods in question to the Dealer.

2.04.If after examining the goods and/or parts in question, Manufacturer finds them to be defective under normal use and
service due to defects in material or workmanship, Manufacturer will:
(a ) Repair or replace the defective goods or part(s) or
(b ) Reimburse Purchaser for the cost of the part(s) and reasonable labor charges (as determined by Manufacturer)

if Purchaser paid for the repair and/or replacement prior to the final determination of applicability of the warranty
by Manufacturer.

The choice of remedy shall belong to Manufacturer.

2.05.Purchaser is responsible for any labor charges exceeding a reasonable amount as determined by Manufacturer and
for returning the goods to the Dealer, whether or not the claim is approved. Purchaser is responsible for the trans­portation cost for the goods or part(s) from the Dealer to the designated factory.

3. LIMITATION OF LIABILITY.

3.01.MANUFACTURER DISCLAIMS ANY EXPRESS (EXCEPT AS SET FORTH HEREIN) AND IMPLIED WARRANTIES

WITH RESPECT TO THE GOODS INCLUDING, BUT NOT LIMITED TO, MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.

3.02.MANUFACTURER MAKES NO WARRANTY AS TO THE DESIGN, CAPABILITY, CAPACITY, OR SUITABILITY FOR

USE OF THE GOODS.

3.03.EXCEPT AS PROVIDED HEREIN, MANUFACTURER SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO

PURCHASER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS, OR DAMAGE
CAUSED OR ALLEGED TO BE CAUSED DIRECTLY OR INDIRECTLY BY THE GOODS INCLUDING, BUT NOT
LIMITED TO, ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES RESULTING FROM

THE USE OR OPERATION OF THE GOODS OR ANY BREACH OF THIS WARRANTY. NOT WITHSTANDING THE

ABOVE LIMITATIONS AND WARRANTIES, MANUFACTURER’S LIABILITY HEREUNDER FOR DAMAGES
INCURRED BY PURCHASER OR OTHERS SHALL NOT EXCEED THE PRICE OF THE GOODS.

3.04.NO ACTION ARISING OUT OF ANY CLAIMED BREACH OF THIS WARRANTY OR TRANSACTIONS UNDER
THIS WARRANTY MAY BE BROUGHT MORE THAN TWO (2) YEARS AFTER THE CAUSE OF ACTION HAS

OCCURRED.

4. MISCELLANEOUS.

4.01.Proper Venue for any lawsuits arising from or related to this limited warranty shall be only in Guadalupe County,

Texas.

4.02.Manufacturer may waive compliance with any of the terms of this limited warranty, but no waiver of any terms shall

be deemed to be a waiver of any other term.

4.03.If any provision of this limited warranty shall violate any applicable law and is held to be unenforceable, then the

invalidity of such provision shall not invalidate any other provisions herein.

4.04.Applicable law may provide rights and benefits to purchaser in addition to those provided herein.

KEEP FOR YOUR RECORDS

ATTENTION: Purchaser should fill in the blanks below for his reference when buying repair parts and/or for proper machine
identification when applying for warranty.

Servis-Rhino Implement Model _______________________________ Serial Number ________________________________

Date Purchased __________________________________________ Dealer ______________________________________

ATTENTION:
READ YOUR OPERATOR'S MANUAL

RHINO

®

1020 S. Sangamon A ve.
Gibson City, IL 60936
800-446-5158
Email: [e-mail]

R

TO THE OWNER/OPERATOR/DEALER

R

To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and
the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily
find the information you need.

The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety
requirements of tractor operators:

REQUIRED OF THE OWNER:

1. Provide a Roll-Over-Protective Structure that meets the requirements of this Standard; and

2. Provide Seatbelts that meet the requirements of this paragraph of this Standard and SAE J4C; and

3. Ensure that each employee uses such Seatbelt while the tractor is moving; and

4. Ensure that each employee tightens the Seatbelt sufficiently to confine the employee to the protected
area provided by the ROPS.

REQUIRED OF THE OPERATOR

1. Securely fasten seatbelt if the tractor has a ROPS.

2. Where possible, avoid operating the tractor near ditches, embankments, and holes.

3. Reduce speed when turning, crossing slopes, and on rough, slick, or muddy surfaces.

4. Stay off slopes too steep for safe operation.

5. Watch where you are going - especially at row ends, on roads, and around trees.

6. Do not permit others to ride.

7. Operate the tractor smoothly - no jerky turns, starts, or stops.

8. Hitch only to the drawbar and hitch points recommended by the tractor manufacturer.

9. When the tractor is stopped, set brakes securely and use park lock, if available.

Keep children away from danger all day, every day...

Equip tractors with rollover protection (ROPS) and keep all machinery
guards in place...

Please work, drive, play and live each day with care and concern for
your safety and that of your family and fellow citizens.

Printed U.S.A.

P/N 00779788PTM 60/72/84/100 PL 07-12
