RLNL-G
Parts List
04-October-2014
This parts list is current as of the above revision date.
See http://www.rheempartslists.net/92-42800-RLNL-G.pdf for the current revision.
Package Air Conditioners - Commercial
Page 2
Model Explanation..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .. Page 3
Parts Numbers
Panels - Miscellaneous 036-060 . . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . Page 4
Panels - Miscellaneous (Granite-Steel Gray) 090-151 (1) .. ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .... Page 5
Panels - Miscellaneous (Granite-Steel Gray) 090-151 (2) .. ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .... Page 6
Panels - Miscellaneous (Granite-Steel Gray) 180-300 (1) .. ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .... Page 7
Panels - Miscellaneous (Granite-Steel Gray) 180-300 (2) .. ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .... Page 8
Electrical Group 036-060 ..... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... .... Page 9
Electrical Group 090-151 (1) . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .... Page10
Electrical Group 090-151 (2) . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .... Page11
Electrical Group 180-300 (1) . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .... Page12
Electrical Group 180-300 (2) . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .... Page13
Fan Group 036-060. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... . Page 14
Fan Group 090-151. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... . Page 15
Fan Group 180-300. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... . Page 16
Blower Group 036-048. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... .... Page 17
Blower Group 060 ... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... Page 18
Blower Group 090-151. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... .... Page 19
Blower Group 180-300. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... .... Page 20
Coil Parts 036-060. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .. Page 21
Coil Parts 090-151. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .. Page 22
Coil Parts 180-300. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .. Page 23
Compressor Group 036-060 . . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ... Page 24
Compressor Group 090-151 . . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ... Page 25
Compressor Group 180-300 . . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ... Page 26
Heater Kits ... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . . Page 27
Accessories 036-151 . . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... Page28
Accessories 180-300 . . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... Page29
Drawings/Photographs
Exploded View 036-060... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . Page 30
Top Panel View 036-060 ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ... Page 31
Control Box 036-060. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . Page 32
Blower Assembly 036-060 ... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ... Page 33
Blower Motor Mount Assembly 036-060.. . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . .. Page 34
Coil Group Cut-away View 036-060 . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ... Page 35
Evaporator Coil - Filter Parts 036-060 ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . . Page 35
Evaporator Coil Parts 036-060 . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .. Page 36
Compressor - Refrigeration Group 036-060 .... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . .. Page 37
Reheat Circuit Assembly 036-060..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . Page 38
TXV Identification Guide . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ... Page 39
Exploded View 090-151... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . Page 40
Exterior - Front 090-151 .... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... .... Page 41
Exterior - Back 090-151. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ... Page 41
Filter-Coil Assembly 090-151 .... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... Page42
Condenser Coil Assembly 090-151... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... . Page 42
Front Panel Brackets 090-151.. . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . . Page 43
Filter Frame Assembly 090-151 .. . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... Page44
Blower Assembly 090-151 ... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ... Page 44
Control Box 090-151. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . Page 45
Low Voltage Shields 090-151 .. . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . . Page 46
Reheat Circuit Assembly 090-151..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . Page 47
Exterior - Front 180-300 .... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... .... Page 48
Exterior - Rear 180-300..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... Page48
Base Pan Assembly 180-300 . . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . .. Page 49
Base Rail Assembly 180-300 .... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . .... Page49
Front Panel Brackets 180-300.. . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . . Page 50
Interior - Coil 180-300 .. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . .. Page 50
Heat Compartment 180-300 ..... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... Page 51
Condenser Bulkhead 180-300 ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ... Page 51
Filter Frame Assembly 180-300 ... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ... Page 52
Blower Assembly 180-300 ... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ... Page 52
Control Box 180-300. . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . Page 53
Electric Heat Block-Off 180-300..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . .. Page 54
Reheat Circuit Assembly 180-300..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . Page 55
Notes/Disclaimer . . ..... ..... . ..... . ..... ..... . ..... ...... ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . ..... ..... . ..... . Page56
Page 2 of 56
04-October-2014
92-42800-RLNL-G
Page 3
R L N L - G 090 C L 000 AA A 1 2 3 4 5 6 7 8 9 10 11
1 TRADE NAME 8 DRIVE PACKAGE L = Belt Drive (R = VFD - Belt Drive) 2 L = PACKAGE AIR CONDITIONER M = Belt Drive - High Static (S = VFD - Belt Drive - High Static) Commercial T = VFD - Belt Drive - High Static (090)
3 EFFICIENCY DESIGNATION 9 ELECTRIC HEAT- (Resistance Heat) N = High Efficiency 000 = No Resistance Heat 006 = 6 kW Resistance Heat 4 DESIGN SERIES 010 = 10 kW Resistance Heat L = R-410A 012 = 12 kW Resistance Heat 015 = 15 kW Resistance Heat 5 TECHNICALVARIATION 020 = 20 kW Resistance Heat G = DDC with Reheat 024 = 24 kW Resistance Heat 030 = 30 kW Resistance Heat 6 COOLING CAPACITY (BTUH) 040 = 40 kW Resistance Heat 036 = 36,000 050 = 50 kW Resistance Heat 048 = 48,000 060 = 60 kW Resistance Heat 060 = 60,000 075 = 75 kW Resistance Heat 090 = 90,000 120 = 120,000 10 OPTION CODES 151 = 150,000 180 = 180,000 11 ECONOMIZER OPTIONS 240 = 240,000 A = No Economizer 300 = 300,000 H = Single Enthalpy Economizer with Barometric Relief J = Single EnthalpyEconomizer with Barometric Relief and SmokeDetector 7 ELECTRICAL DESIGNATION C = 208-230/3/60 D = 460/3/60 Y = 575/3/60
1 2 3 4 5
1 COMPRESSOR IDENTIFICATIONNUMBER 2 PRODUCTION LOCATION: 3 WEEK OF PRODUCTION 4 YEAR OF PRODUCTION 5 PRODUCTION NUMBER
1234 F 50 08 00001
MODEL NUMBER EXPLANATION
SERIAL NUMBER EXPLANATION
Page 3 of 56
04-October-2014
92-42800-RLNL-G
Page 4
No. Notes
1 Base Rail - Side (2) AE-58900-01 2 Base Rail - Condenser End AE-58901-01 3 Base Rail - EvaporatorEnd AE-58902-01 4 Outdoor Coil Base Pan AS-59051-01H 5 Indoor Coil Base Pan AS-58910-05 6 Condenser Bulkhead AS-103276-02 7 Blower Bulkhead Assembly (Does not include Blower Extensions, Cover Plate, Insulation Retainer) AS-103385-01 8 Blower Extension - Front AE-58928-01 9 Blower Extension - Back AE-58928-02
Cover Plate (On the Blower Extension - Front to coverthe Limit Control opening) AE-76216-01 Insulation Retainer AE-59059-01
10 Wire Chase Insulation Assembly AS-103291-01 11a Corner Post (2) AS-58965-01H 11b Center Post AS-58966-01H
13 Louvered Panel AS-59028-01H
14 Louvered Panel AS-59028-03H
15 Louvered Panel AS-59028-02H
16 Return/Supply Cover Assembly AS-58992-01H
17 Rear Panel (Includes Insulation, Filler Panel, and Stripping) AS-58976-01H
18 Filler Panel - (Return Air Filler) AE-58974-01
Filler Panel Stripping AE-58897-10 19 Blower/Filter Access Panels (2) AS-58990-01H 20 Post - Left End AS-58973-01H 21 Front Panel Assembly AS-59132-01H 22 Electric Heat Access PanelAssembly AS-58987-04H 23 Control Box Access Door AS-103284-01H
24a Control Box Insert Panel AS-103283-01H 24b Disconnect Plate AS-90756-05H 24c Receptacle Plate AS-90756-02H
25 Front Post AS-103288-01H 26 Indoor CoilTop Panel Assembly AS-58979-01H
27a Condenser Top Panel AS-58981-01H 27b Support - Condenser Top Panel AE-58980-01
29 Wire Grille 95-101660-01 31 Control Box (w/o components) AS-103281-01
MODEL TECHNICALVARIATIONS COOLING CAPACITY
PANELS, MISCELLANEOUS PARTS
RLNL-
G
036-060
Page 4 of 56
04-October-2014
92-42800-RLNL-G
Page 5
No. Notes
BASE RAILS:
A Base Rail - Front AE-90575-15 AE-90575-15 AE-90575-15 B Base Rail - Right AE-90576-03 AE-90576-03 AE-90576-03 C Base Rail - Rear AE-90575-04 AE-90575-04 AE-90575-04 D Base Rail - Left AE-90576-04 AE-90576-04 AE-90576-04
BASE PANS:
E Outdoor Coil Base Pan AS-90577-05H AS-90577-05H AS-90577-14H F Indoor Coil Base Pan AS-90577-12 AS-90577-12 AS-90577-12
INSIDE CABINET:
G Entry Plate AE-90614-01 AE-90614-01 AE-90614-01 H Entry Plate AE-90614-01 AE-90614-01 AE-90614-01
J Heat Compartment Side AE-90598-09 AE-90598-09 AE-90598-09
K Blower Deck AS-90592-13 AS-90592-13 AS-90592-13
L Wireway AE-90718-05 AE-90718-05 AE-90718-05
M Condenser Bulkhead AS-90609-41 AS-90609-41 AS-90609-41
No. Notes
1 Control Box Door Assembly - w/Hinges, Latch, Gasket,Insulation AS-102872-14H AS-102872-14H AS-102872-14H 2a Bracket - Top Panel (Left) AS-102859-16H AS-102859-16HAS-102859-16H 2b Bracket - Top Panel (Center) AS-102859-15H AS-102859-15H AS-102859-15H 2c Post - Blower Section AS-102682-12H AS-102682-12H AS-102682-12H 3a Bracket - Bottom Panel (Left) AS-102859-17H AS-102859-17H AS-102859-17H 3b Bracket - Blower/Heater Compartment AS-102859-14H AS-102859-14H AS-102859-14H 3c Bracket - Bottom Panel (Right) AS-102859-13H AS-102859-13H AS-102859-13H
Latch Assembly - Control Box Door (2) 64-102855-01 64-102855-01 64-102855-01 4 Post Assembly - Indoor Coil Section AS-90620-17H AS-90620-17H AS-90620-24H 5 Control Box Cover AE-90713-02 AE-90713-02 AE-90713-02 6 Control Mounting Plate AE-90712-06 AE-90712-06 AE-90712-06
7a Low Voltage Shield (BeforeF3512) - Upper Straight AE-90742-08 AE-90742-08 N/A 7a Low Voltage Shield (After F3512) - Upper Angled AE-90742-12 AE-90742-12 AE-90742-12 7b Low Voltage Shield (BeforeF3512) - Lower AE-90742-03 AE-90742-03 N/A 7b Low Voltage Shield (After F3512) - Lower AE-90742-11 AE-90742-11 AE-90742-11 7c Low Voltage Shield - Middle Strip AE-90742-09 AE-90742-09 AE-90742-09
8 Control Box Back Insulation Assembly AS-90601-06 AS-90601-06 AS-90601-06 9 Mounting Bracket AE-90779-02 AE-90779-02 AE-90779-02
10 Electric Heat Blockoff Plate AS-90720-02 AS-90720-02 AS-90720-02 11 Terminal Block See Electrical Group 12 Electric Heat Access PanelAssembly - w/Hinges, Latch, Gasket, Insulation AS-102872-18H AS-102872-18H AS-102872-18H
Latch Assembly - Electric Heat Door (2) 64-102855-01 64-102855-01 64-102855-01
13 PowerEntry Plate Assembly AS-90774-11H AS-90774-11H AS-90774-11H 14 Blower Access Panel Assembly - w/Hinges, Latch, Gasket, Insulation AS-102872-16HAS-102872-16HAS-102872-16H
Latch Assembly - Blower Access Panel (3) 64-102855-01 64-102855-01 64-102855-01
16 Heat Mounting Frame Assembly AS-90754-02 AS-90754-02 AS-90754-02 17 Condenser Coil Access Panel - Front AS-90631-09H AS-90631-09H AS-90631-11H 18 Front Corner Post AS-90701-06H AS-90701-06H AS-90701-05H
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - RAILS, BASE PANS, INSIDE CABINET
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - FRONT
RLNL-
G
090
RLNL-
G
090
RLNL-
G
120
RLNL-
G
120
RLNL-
G
151
RLNL-
G
151
Page 5 of 56
04-October-2014
92-42800-RLNL-G
Page 6
No. Notes
RIGHT:
19 Air Stop N/A N/A N/A
Louver PanelAssembly AS-90789-01H AS-90789-01H
REAR:
21 Rear Corner Post AS-90702-03H AS-90702-03H AS-90702-04H 22 Condenser Coil Access Panel-Rear AS-90631-05H AS-90631-05H AS-90631-12H 23 Rear Panel AS-90618-02H AS-90618-02H AS-90618-02H 24 Supply Cover AS-90626-02H AS-90626-02H AS-90626-02H 25 Return Cover AS-90628-02H AS-90628-02H AS-90628-02H
LEFT:
26 Upper Left Panel AS-90624-03H AS-90624-03H AS-90624-03H 27 Lower Left Panel AS-90624-04H AS-90624-04H AS-90624-04H 28 Left Corner Panel AS-90755-07H AS-90755-07H AS-90755-07H 29 Plate - Receptacle AS-90756-02H AS-90756-02H AS-90756-02H 30 Plate - Disconnect AS-90756-03H AS-90756-03H AS-90756-03H 31 Button Plug (2) 45-22980-06 45-22980-06 45-22980-06 32 Button Plug 45-22980-05 45-22980-05 45-22980-05
TOP:
33 Top Panel Assembly AS-90775-38H AS-90775-38H AS-90775-38H 34 Condenser Top Panel AS-90703-09H AS-90703-09H AS-90703-08H 35 Venturi (2) AS-90632-03H AS-90632-03H AS-90632-03H 36 Wire Grille (2) 95-100906-09 95-100906-09 95-100906-09 43 Drain Pan- Removable See Coil Group
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - RIGHT, REAR AND LEFT SIDES
RLNL-
G
090
RLNL-
G
120
RLNL-
G
151
See
Accessories
Page 6 of 56
04-October-2014
92-42800-RLNL-G
Page 7
No. Notes
BASE RAILS:
A Front AS-90827-03 AS-90827-03 AS-90827-03 B Right AE-90576-06 AE-90576-06 AE-90576-06 C Rear AS-90827-04 AS-90827-04 AS-90827-04 D Left AE-90576-05 AE-90576-05 AE-90576-05
BASE PANS:
E Outdoor Base Pan AS-90583-09H AS-90583-09H AS-90583-09H F Indoor Coil Base Pan - Return Air AS-90577-09 AS-90577-09 AS-90577-09 G Indoor Coil Base Pan - Supply Air AS-90577-10 AS-90577-10 AS-90577-10
INSIDE CABINET PANEL/PIECES:
H 1 Entry Plate AE-90614-01 AE-90614-01 AE-90614-01 H 2 Entry Plate - Rooftop AE-90614-02 AE-90614-02 AE-90614-02
I Post - Blower Section AS-102682-07H AS-102682-07H AS-102682-07H J Heat Compartment Side AE-90598-08 AE-90598-08 AE-90598-08
K Blower Deck Assembly AS-90592-11 AS-90592-11 AS-90592-11
L Wireway AE-90718-04 AE-90718-04 AE-90718-04
M Condenser Bulkhead AS-90609-17 AS-90609-17 AS-90609-17 N Divider Panel - Between Coils AE-90735-05 AE-90735-05 AE-90735-05 O Bulkhead Support AE-102725-01 AE-102725-01 AE-102725-01 P Primary Drain Pan AS-103030-02 AS-103030-02 AS-103030-02
Air Stop - Outdoor Coil- Front AE-90706-13 AE-90706-13 AE-90706-13
Air Stop - Outdoor Coil- Rear AE-90706-12 AE-90706-12 AE-90706-12
U Coil Support Top AE-102700-03 AE-102700-03 AE-102700-03
No. Notes
1 Control Box Door Assembly - w/Hinges, Latch, Gasket,Insulation AS-102872-04H AS-102872-04H AS-102872-04H
2a Bracket - Top Panel (Left) AS-102859-01H AS-102859-01H AS-102859-01H 2b Bracket - Top Panel (Center) AS-102969-01H AS-102969-01H AS-102969-01H 2c Post - Blower Section AS-102682-07H AS-102682-07H AS-102682-07H 3a Bracket - Bottom Panel (Left) AS-102859-02H AS-102859-02H AS-102859-02H 3b Bracket - Blower/Heater Compartment AS-102859-11H AS-102859-11H AS-102859-11H 3c Bracket - Bottom Panel (Right) AS-102859-12H AS-102859-12H AS-102859-12H
4 Post Assembly - Indoor Coil Section AS-90620-15H AS-90620-15H AS-90620-15H 5 Control Box Cover AE-90713-05 AE-90713-05 AE-90713-05 6 Control Mounting Panel AE-90712-05 AE-90712-05 AE-90712-05
7a Low Voltage Shield - Control Box (Upper Right) AE-90742-07 AE-90742-07 AE-90742-07 7b Low Voltage Shield - Control Box (Lower Left) AE-90742-06 AE-90742-06 AE-90742-06 7c Thermostat Chase Cover AE-102722-01 AE-102722-01 AE-102722-01
8 Control Box Back AS-90601-05 AS-90601-05 AS-90601-05 9 Mounting Bracket AE-90779-02 AE-90779-02 AE-90779-02
10 Electric Heat Blockoff Plate Assembly (models with no heat) AS-90720-03 AS-90720-03 AS-90720-03 11 Terminal Block - Heat Compartment See Electrical Group 12 Electric Heat Access PanelAssembly - w/Hinges, Latch, Gasket, Insulation AS-102872-06H AS-102872-06H AS-102872-06H 13 PowerEntry Plate Assembly AS-90774-13H AS-90774-13H AS-90774-13H 14 Blower Access Panel Assembly - w/Hinges, Latch, Gasket, Insulation AS-102872-02H AS-102872-02H AS-102872-02H 15 Ground Lug - Heat Compartment SeeElectrical Group 16 Mounting Frame- Heat Exchanger Frame AS-90754-04 AS-90754-04 AS-90754-04
17 Condenser Coil Access Panel-Front AS-90734-08H AS-90734-08H AS-90734-08H 38c Post - Outdoor Coil (Front) See Coil Group 39c Post - Outdoor Coil (Rear) See Coil Group
Louver Panel(Hail Guard) - Left AS-90789-10H AS-90789-10H AS-90789-10H Louver Panel(Hail Guard) - Right AS-90789-09H AS-90789-09H AS-90789-09H
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - RAILS, BASE PANS, INSIDE CABINET
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - FRONT AND RIGHT SIDES
RLNL-
G
180
RLNL-
G
180
RLNL-
G
240
RLNL-
G
240
RLNL-
G
300
RLNL-
G
300
Page 7 of 56
04-October-2014
92-42800-RLNL-G
Page 8
No. Notes
REAR:
22 Condenser Coil Access Panel-Rear AS-90734-09H AS-90734-09H AS-90734-09H
23 Rear Panel - Right AS-90618-08H AS-90618-08H AS-90618-08H
24 Supply Cover AS-90628-03H AS-90628-03H AS-90628-03H
25 Return Cover AS-90628-04H AS-90628-04H AS-90628-04H
LEFT:
26 Upper Left Panel AS-90624-09H AS-90624-09H AS-90624-09H
27 Lower Left Panel AS-90624-08H AS-90624-08H AS-90624-08H
28 Left Corner Panel Assembly AS-90755-05H AS-90755-05H AS-90755-05H
Bracket - Left Corner Panel Assembly (2) AE-90779-01 AE-90779-01 AE-90779-01 Gasket forreceptacle plate 68-42514-08 68-42514-08 68-42514-08
Gasket fordisconnect plate 68-42514-09 68-42514-09 68-42514-09 29 Plate - Install inside Panel-Receptacle AS-90756-02H AS-90756-02H AS-90756-02H 30 Plate - Install inside Panel-Disconnect AS-90756-03H AS-90756-03H AS-90756-03H 31 Button Plug (3) 45-42558-01 45-42558-01 45-42558-01 32 Star Bushing (3) 45-18515-01 45-18515-01 45-18515-01
TOP:
33a Top Panel Assembly - Right AS-90616-04H AS-90616-04H AS-90616-04H 33b Top Panel Assembly - Left AS-90616-05H AS-90616-05H AS-90616-05H 34a Top Panel - Front AS-90633-10H AS-90633-10H AS-90633-10H 34b Top Panel - Middle AS-90633-12H AS-90633-11H AS-90633-11H 34c Top Panel - Rear AS-90633-09H AS-90633-09H AS-90633-09H
35 Venturi
36 Wire Grille 43 Drain Pan- Removable See Coil Group
MODEL TECHNICALVARIATION COOLING CAPACITY
PANELS - REAR, LEFT, ANDTOP
RLNL-
G
180
AS-90632-03H
(4)
95-100906-09
(4)
RLNL-
G
240
AS-90632-03H
(6)
95-100906-09
(6)
RLNL-
G
300
AS-90632-03H
(6)
95-100906-09
(6)
Page 8 of 56
04-October-2014
92-42800-RLNL-G
Page 9
MODEL
No. Notes
Outlet Box 45-41952-02 45-41952-02
Receptacle Cover 45-41953-02 45-41953-02
Receptacle - Ground Fault 45-41954-01 45-41954-01
Pressure Switch Assembly - (Clogged Filter and Fan Proving) 42-103320-26 42-103320-26
Temperature Sensor/Clip Assembly (Liquid Line, LLS1) 47-102710-08 47-102710-08
CONTROL BOXCOMPONENTS: 35 Capacitor (FanOnly) See Fan Group
Strap - Capacitor AE-50892-01 AE-50892-01
Fan Controller 47-104039-01 47-104039-01 36 Stk Comfort Alert 42-101504-03 42-101504-03 37 Stk Blower Contactor - Belt Drive 42-102664-08 42-102664-08 38 Stk Low Voltage Shield AE-103285-01 AE-103285-01 39 Stk Compressor Contactor 42-102664-08 42-102664-08 40 Stk Transformer 46-42515-04 46-42515-05 41 Unit Controller (RTU-C) 47-102883-02 47-102883-02
Low Ambient Control See Accessories 91 Stk Low Pressure Control 47-102240-03 47-102240-03 92 Stk High Pressure Control 47-23699-04 47-23699-04
WIRING HARNESSES:
Wiring Harness - Twist Loc 6 Pin to (6 Pin 3 Strip Leads) 45-102819-03 45-102819-03
Wiring Harness - Reheat (12 pin to 6 terminals, Temperature Sensor LLS2, 2 stripped wires) 45-42522-115 45-42522-115
Jumper - 7 Pin Connector (Unit Configuration) 45-42522-103 45-42522-103
Wiring Harness - Economizer (8 Pin and 9 Pin) to (12 Pin, 4 Pin, 4 Connectors, and 2 Sensors) 45-42522-107 45-42522-107
Wiring Harness - Compressor Control 14 Pin to (two 2 Pin Connectors and 2 Sensors) 45-42522-111 45-42522-111
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC GROUP
RLNL-
G
036-060
C
RLNL-
G
036-060
D
Page 9 of 56
04-October-2014
92-42800-RLNL-G
Page 10
MODEL
No. Notes
CONTROL BOXCOMPONENTS: (57 - 62) 57 Stk Transformer - Control 46-42515-04 46-42515-04 46-42515-04
58a Double RowTerminal Block 45-42548-02 45-42548-02 45-42548-02 58b Blower Relay 42-21571-08 42-21571-08 42-21571-08 58c Ground Lug 45-19000-02 45-19000-02 45-19000-02 58d Accessory Relay 42-19736-05 42-19736-05 42-19736-05
60 Capacitor - FanMotor See FanGroup
61a Stk Unit Controller (RTU-C) 47-102883-02 47-102883-02 47-102883-02 61b Stk Controller - Outdoor FanMotor 47-104039-01 47-104039-01 47-104039-01 61c Stk Variable Frequency Drive (VFD) - Drive Package R 47-104280-01 47-104280-01 47-104282-01 61c Stk Variable Frequency Drive (VFD) - Drive Package S 47-104280-01 47-104281-01 47-104282-01 61c Stk Variable Frequency Drive (VFD) - Drive PackageT 47-104281-01 N/A N/A 62a Stk Contactor - Compressor 42-102664-08 42-102664-08 42-102664-08 62b Stk Contactor w/Auxiliary Switch - Compressor 42-102664-14 42-102664-14 42-102664-14
Comfort Alert 42-101504-03 42-101504-03 42-101504-03
Low Ambient Control Assembly AS-103034-01 AS-103034-01 AS-103034-01
Pressure Switch See Heat Exchanger/Burner
Pressure Switch Assembly - (Clogged Filter and Fan Proving) 42-103320-27 42-103320-27 42-103320-27
Outlet Box 45-41952-02 45-41952-02 45-41952-02
Cover - Receptacle 45-41953-02 45-41953-02 45-41953-02
Receptacle/Ground Fault 45-41954-01 45-41954-01 45-41954-01
High Pressure Control (2) See Coil Group
Low Pressure Control (2) See Coil Group
WIRING HARNESSES:
Wiring Harness - FanMotor #1 See FanGroup
Wiring Harness - FanMotor #2 See FanGroup
Wiring Harness - Twist-Loc (12 Pin and 4 Pin) to 9 Pin 45-42522-100 45-42522-100 45-42522-100
Wiring Harness - 12 Pin from Rooftop Control Unit to (6 Connectors and 1 Temperature Sensor) 45-42522-120 45-42522-120 45-42522-120
Wiring Harness - 4 Pin from Rooftop Control Unit to (3 strip leads forVariableFrequency Drive) 45-42522-121 45-42522-121 45-42522-121
Wirng Harness - Main Power 45-42522-09 45-42522-09 45-42522-09
Wiring Harness - Sensor (8 Pin to 4 Connectors and 2 Temperature Sensors) 45-42522-98 45-42522-98 45-42522-98
Jumper - Unit Configuration (7 Pin Connector) 45-42522-104 45-42522-104 45-42522-104
Plug Harness - Compressor See Compressor Group
Wiring Harness - 6 Pin to Heater Kit 45-102706-09 45-102706-09 45-102706-09
Bypass Plug - Economizer12 Pin AS-61997-55 AS-61997-55 AS-61997-55
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRICAL GROUP
Wiring Harness - Compressor Control (14 Pin to Four 2 Pin Connectors and Three Temperature Sensors)
RLNL-
G
090
C
45-42522-99 45-42522-99 45-42522-99
RLNL-
G
120
C
RLNL-
G
151
C
Page 10 of 56
04-October-2014
92-42800-RLNL-G
Page 11
MODEL
No. Notes
CONTROL BOXCOMPONENTS: (57 - 62) 57 Stk Transformer - Control 46-42515-05 46-42515-05 46-42515-05
58a Double RowTerminal Block 45-42548-02 45-42548-02 45-42548-02 58b Blower Relay 42-21571-08 42-21571-08 42-21571-08 58c Ground Lug 45-19000-02 45-19000-02 45-19000-02 58d Accessory Relay 42-19736-05 42-19736-05 42-19736-05
60 Capacitor - FanMotor See FanGroup
61a Stk Unit Controller (RTU-C) 47-102883-02 47-102883-02 47-102883-02 61b Stk Controller - Outdoor FanMotor 47-104039-01 47-104039-01 47-104039-01 61c Stk Variable Frequency Drive (VFD) - Drive Package R 47-104285-01 47-104285-01 47-104287-01 61c Stk Variable Frequency Drive (VFD) - Drive Package S 47-104285-01 47-104286-01 47-104287-01 61c Stk Variable Frequency Drive (VFD) - Drive PackageT 47-104286-01 N/A N/A 62a Stk Contactor - Compressor 42-102664-08 42-102664-08 42-102664-08 62b Stk Contactor w/Auxiliary Switch - Compressor 42-102664-14 42-102664-14 42-102664-14
Comfort Alert 42-101504-03 42-101504-03 42-101504-03
Low Ambient Control Assembly AS-103034-01 AS-103034-01 AS-103034-01
Pressure Switch See Heat Exchanger/Burner
Pressure Switch Assembly - (Clogged Filter and Fan Proving) 42-103320-27 42-103320-27 42-103320-27
Outlet Box 45-41952-02 45-41952-02 45-41952-02
Cover - Receptacle 45-41953-02 45-41953-02 45-41953-02
Receptacle/Ground Fault 45-41954-01 45-41954-01 45-41954-01
High Pressure Control (2) See Coil Group
Low Pressure Control (2) See Coil Group
WIRING HARNESSES:
Wiring Harness - FanMotor #1 See FanGroup
Wiring Harness - FanMotor #2 See FanGroup
Wiring Harness - Twist-Loc (12 Pin and 4 Pin) to 9 Pin 45-42522-100 45-42522-100 45-42522-100
Wiring Harness - 12 Pin from Rooftop Control Unit to (6 Connectors and 1 Temperature Sensor) 45-42522-120 45-42522-120 45-42522-120
Wiring Harness - 4 Pin from Rooftop Control Unit to (3 strip leads forVariableFrequency Drive) 45-42522-121 45-42522-121 45-42522-121
Wirng Harness - Main Power 45-42522-09 45-42522-09 45-42522-09
Wiring Harness - Sensor (8 Pin to 4 Connectors and 2 Temperature Sensors) 45-42522-98 45-42522-98 45-42522-98
Jumper - Unit Configuration (7 Pin Connector) 45-42522-104 45-42522-104 45-42522-104
Plug Harness - Compressor See Compressor Group
Wiring Harness - 6 Pin to Heater Kit 45-102706-09 45-102706-09 45-102706-09
Bypass Plug - Economizer12 Pin AS-61997-55 AS-61997-55 AS-61997-55
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRICAL GROUP
Wiring Harness - Compressor Control (14 Pin to Four 2 Pin Connectors and Three Temperature Sensors)
RLNL-
G
090
D
45-42522-99 45-42522-99 45-42522-99
RLNL-
G
120
D
RLNL-
G
151
D
Page 11 of 56
04-October-2014
92-42800-RLNL-G
Page 12
MODEL
No. Notes
11 Terminal Block - Heater Compartment 45-21134-04 45-21134-04 45-21134-04 15 Ground Lug - Heater Compartment 45-19000-02 45-19000-02 45-19000-02
CONTROL BOXCOMPONENTS:
57a Stk Transformer - Control 46-42515-04 46-42515-04 46-42515-04 57b Stk Transformer - Discharge Solenoid Relay 46-103324-01 46-103324-01 46-103324-01 58a Terminal Block - Double Row 45-42548-02 45-42548-02 45-42548-02 58b Terminal Block - Power Block 45-41765-01 45-41765-01 45-41765-01 58c Ground Lug 45-19000-02 45-19000-02 45-19000-02 58d Accessory Relay 42-19736-05 42-19736-05 42-19736-05 58e Discharge Solenoid Relay 42-21571-08 42-21571-08 42-21571-08
59 Stk Blower Relay 42-21571-08 42-21571-08 42-21571-08
Pressure Switch Assembly - (Clogged Filter and Fan Proving) 42-103320-27 42-103320-27 42-103320-27
Disconnect Switch Assembly 42-42559-02 42-42559-02 42-42559-02
Outlet Box 45-41952-02 45-41952-02 45-41952-02
Cover - Receptacle 45-41953-02 45-41953-02 45-41953-02
Receptacle/Ground Fault 45-41954-01 45-41954-01 45-41954-01
Low Ambient Assembly AS-103034-01 AS-103034-01 AS-103034-01 60 Run Capacitor See Fan Group
High Pressure Control See Coil Group
Low Pressure Control See Coil Group
61b Stk Unit Controller (RTU-C) 47-102883-02 47-102883-02 47-102883-02 61c Stk Controller - Outdoor Fan Motor 47-104039-01 47-104039-01 47-104039-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage R 47-104281-01 47-104282-01 47-104283-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage S 47-104282-01 47-104283-01 47-104284-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage T N/A N/A N/A 62a Stk Compressor Contactor 42-102664-12 42-102664-12 42-102664-26 62b Stk Compressor Contactor 42-102664-12 42-102664-26 42-102664-26 62c Comfort Alert (2) 42-101504-03 42-101504-03 42-101504-03
WIRING HARNESSES:
Wiring Harness - Motor #1 See Fan Group
Wiring Harness - Motor #2 See Fan Group
Plug Harness - Compressor See Compressor Group
Wirng Harness - Main Power 45-42522-92 45-42522-92 45-42522-92
Jumper - 7 Pin Connector 45-42522-104 45-42522-104 45-42522-104
Bypass Plug - Economizer12 Pin AS-61997-55 AS-61997-55 AS-61997-55
Wiring Harness - 6 Pin to Heater Kit 45-42522-91 45-42522-91 45-42522-91
Wiring Harness - Economizer (12 pin and 4 pin to 9 pin) 45-42522-93 45-42522-93 45-42522-93
Wiring Harness - 8 Pin to 4 Connectors and 2 Temperature Sensors 45-42522-98 45-42522-98 45-42522-98
Wiring Harness - 12 Pin to Flame Sensor 45-42522-119 45-42522-119 45-42522-119
Wiring Harness - 4 Pin toVariable Frequency Drive (VFD) 45-42522-120 45-42522-120 45-42522-120
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC GROUP
Wiring Harness - Compressor Control (14 Pin to Four 2 Pin Connectors and Three Temperature Sensors)
RLNL-
G
180
C
45-42522-118 45-42522-118 45-42522-118
RLNL-
G
240
C
RLNL-
G
300
C
Page 12 of 56
04-October-2014
92-42800-RLNL-G
Page 13
MODEL
No. Notes
11 Terminal Block - Heater Compartment 45-21134-04 45-21134-04 45-21134-04 15 Ground Lug - Heater Compartment 45-19000-02 45-19000-02 45-19000-02
CONTROL BOXCOMPONENTS:
57a Stk Transformer - Control 46-42515-05 46-42515-05 46-42515-05 57b Stk Transformer - Discharge Solenoid Relay 46-103324-02 46-103324-02 46-103324-02 58a Terminal Block - Double Row 45-42548-02 45-42548-02 45-42548-02 58b Terminal Block - Power Block 45-41765-01 45-41765-01 45-41765-01 58c Ground Lug 45-19000-02 45-19000-02 45-19000-02 58d Accessory Relay 42-19736-05 42-19736-05 42-19736-05 58e Discharge Solenoid Relay 42-21571-08 42-21571-08 42-21571-08
59 Stk Blower Relay 42-21571-08 42-21571-08 42-21571-08
Pressure Switch Assembly - (Clogged Filter and Fan Proving) 42-103320-27 42-103320-27 42-103320-27
Disconnect Switch Assembly 42-42559-02 42-42559-02 42-42559-02
Outlet Box 45-41952-02 45-41952-02 45-41952-02
Cover - Receptacle 45-41953-02 45-41953-02 45-41953-02
Receptacle/Ground Fault 45-41954-01 45-41954-01 45-41954-01
Low Ambient Assembly AS-103034-01 AS-103034-01 AS-103034-01 60 Run Capacitor See Fan Group
High Pressure Control See Coil Group
Low Pressure Control See Coil Group
61b Stk Unit Controller (RTU-C) 47-102883-02 47-102883-02 47-102883-02 61c Stk Controller - Outdoor Fan Motor 47-104039-01 47-104039-01 47-104039-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage R 47-104286-01 47-104287-01 47-104288-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage S 47-104287-01 47-104288-01 47-104289-01 61d Stk Variable Frequency Drive (VFD) - DrivePackage T N/A N/A N/A 62a Stk Compressor Contactor 42-102664-12 42-102664-12 42-102664-26 62b Stk Compressor Contactor 42-102664-12 42-102664-26 42-102664-26 62c Comfort Alert (2) 42-101504-03 42-101504-03 42-101504-03
WIRING HARNESSES:
Wiring Harness - Motor #1 See Fan Group
Wiring Harness - Motor #2 See Fan Group
Plug Harness - Compressor See Compressor Group
Wirng Harness - Main Power 45-42522-92 45-42522-92 45-42522-92
Jumper - 7 Pin Connector 45-42522-104 45-42522-104 45-42522-104
Bypass Plug - Economizer12 Pin AS-61997-55 AS-61997-55 AS-61997-55
Wiring Harness - 6 Pin to Heater Kit 45-42522-91 45-42522-91 45-42522-91
Wiring Harness - Economizer (12 pin and 4 pin to 9 pin) 45-42522-93 45-42522-93 45-42522-93
Wiring Harness - 8 Pin to 4 Connectors and 2 Temperature Sensors 45-42522-98 45-42522-98 45-42522-98
Wiring Harness - 12 Pin to Flame Sensor 45-42522-119 45-42522-119 45-42522-119
Wiring Harness - 4 Pin toVariable Frequency Drive (VFD) 45-42522-120 45-42522-120 45-42522-120
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC GROUP
Wiring Harness - Compressor Control (14 Pin to Four 2 Pin Connectors and Three Temperature Sensors)
RLNL-
G
180
D
45-42522-118 45-42522-118 45-42522-118
RLNL-
G
240
D
RLNL-
G
300
D
Page 13 of 56
04-October-2014
92-42800-RLNL-G
Page 14
MODEL
No. Notes
32 Stk Fan Motor 51-100998-30 51-100998-30 51-100998-32 33 Stk Capacitor - Fan Motor 43-100496-04 43-100496-04 43-100496-12 34 Stk Fan Blade 70-23594-01 70-23594-01 70-42484-01
No. Notes
32 Stk Fan Motor 51-100998-31 51-100998-31 51-100998-33 33 Stk Capacitor - Fan Motor 43-100496-04 43-100496-04 43-100496-12 34 Stk Fan Blade 70-23594-01 70-23594-01 70-42484-01
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
RLNL-
G
036
C
RLNL-
G
036
D
RLNL-
G
048
C
RLNL-
G
048
D
RLNL-
G
060
C
RLNL-
G
060
D
Page 14 of 56
04-October-2014
92-42800-RLNL-G
Page 15
MODEL
No. Notes
52 Stk Fan Motor (2) 51-42534-24 51-42534-24 51-42534-29
Wiring Harness - Motor #1 (7 wire) 45-102706-01 45-102706-01 45-102706-03
Wiring Harness - Motor #2 (5 wire) 45-102706-02 45-102706-02 45-102706-04 53 Stk Fan Blade (2) 70-42572-04 70-42572-04 70-21858-18 60 Stk Capacitor - Fan Motor (2) 43-100496-12 43-100496-12 43-100496-17
No. Notes
52 Stk Fan Motor (2) 51-42534-25 51-42534-25 51-42534-28
Wiring Harness - Motor #1 (7 wire) 45-102706-01 45-102706-01 45-102706-03
Wiring Harness - Motor #2 (5 wire) 45-102706-02 45-102706-02 45-102706-04 53 Stk Fan Blade (2) 70-42572-04 70-42572-04 70-21858-18 60 Stk Capacitor - Fan Motor (2) 43-100496-12 43-100496-12 43-100496-12
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
RLNL-
G
090
C
RLNL-
G
090
D
RLNL-
G
120
C
RLNL-
G
120
D
RLNL-
G
151
C
RLNL-
G
151
D
Page 15 of 56
04-October-2014
92-42800-RLNL-G
Page 16
MODEL
No. Notes
52 Stk Fan Motor
Wiring Harness - Motor #1 & #4 45-42522-71 45-42522-71 45-42522-71
Wiring Harness - Motor #2 & #5 N/A 45-42522-70 45-42522-70
Wiring Harness - Motor #3 & #6 45-42522-69 45-42522-69 45-42522-69 53 Stk Fan Blade
60 Stk Capacitor - Fan Motor
No. Notes
52 Stk Fan Motor
Wiring Harness - Motor #1 & #4 45-42522-71 45-42522-71 45-42522-71
Wiring Harness - Motor #2 & #5 N/A 45-42522-70 45-42522-70
Wiring Harness - Motor #3 & #6 45-42522-69 45-42522-69 45-42522-69 53 Stk Fan Blade
60 Stk Capacitor - Fan Motor
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
FANGROUP
RLNL-
G
180
C
51-42534-24
(4)
70-42572-04
(4)
43-100496-12
(4)
RLNL-
G
180
D
51-42534-25
(4)
70-42572-04
(4)
43-100496-12
(4)
RLNL-
G
240
C
51-42534-24
(6)
70-42572-04
(6)
43-100496-12
(6)
RLNL-
G
240
D
51-42534-25
(6)
70-42572-04
(6)
43-100496-12
(6)
RLNL-
G
300
C
51-42534-24
(6)
70-42572-04
(6)
43-100496-12
(6)
RLNL-
G
300
D
51-42534-25
(6)
70-42572-04
(6)
43-100496-12
(6)
Page 16 of 56
04-October-2014
92-42800-RLNL-G
Page 17
MODEL
No. Notes
62 Stk Blower Assembly (Includes items 63-66, 68-73 excluding item 72b) AS-101336-01 AS-101336-05 AS-101336-01 AS-101336-05 63 Housing AS-101341-01 AS-101341-01 AS-101341-01 AS-101341-01 64 Stk Bearing FrameTri-Arm (2) 70-41723-03 70-41723-03 70-41723-03 70-41723-03 65 Stk Ball Bearing and Cushion (2) 70-41911-01 70-41911-01 70-41911-01 70-41911-01 66 Stk Blower Shaft 70-21933-02 70-21933-02 70-21933-02 70-21933-02 67 Stk Fixed Pitch Sheave 71-100772-04 71-100772-03 71-100772-04 71-100772-03 68 Blower Support - Left AE-58950-02 AE-58950-02 AE-58950-02 AE-58950-02 69 Stk Wheel 70-23589-01 70-23589-01 70-23589-01 70-23589-01 70 Cut-Off Tabulation AE-64401-05 AE-64401-05 AE-64401-05 AE-64401-05 74 Stk Blower Motor 51-42579-01 51-42579-01 51-42579-01 51-42579-01 75 Stk Variable Pitch Sheave 71-40427-30 71-40427-29 71-40427-29 71-40427-29 76 Stk Belt 71-40235-43 71-40235-43 71-40235-43 71-40235-43
No. Notes
62 Stk Blower Assembly (Includes items 63-66, 68-73 excluding item 72b) AS-101336-05 AS-101336-05 AS-101336-05 AS-101336-05 63 Housing AS-101341-01 AS-101341-01 AS-101341-01 AS-101341-01 64 Stk Bearing FrameTri-Arm (2) 70-41723-03 70-41723-03 70-41723-03 70-41723-03 65 Stk Ball Bearing and Cushion (2) 70-41911-01 70-41911-01 70-41911-01 70-41911-01 66 Stk Blower Shaft 70-21933-02 70-21933-02 70-21933-02 70-21933-02 67 Stk Fixed Pitch Sheave 71-100772-03 71-100772-03 71-100772-03 71-100772-03 68 Blower Support - Left AE-58950-02 AE-58950-02 AE-58950-02 AE-58950-02 69 Stk Wheel 70-23589-01 70-23589-01 70-23589-01 70-23589-01 70 Cut-Off Tabulation AE-64401-05 AE-64401-05 AE-64401-05 AE-64401-05 74 Stk Blower Motor 51-21909-01 51-21909-01 51-21909-01 51-21909-01 75 Stk Variable Pitch Sheave 71-40427-25 71-40427-25 71-40427-25 71-40427-25 76 Stk Belt 71-40235-43 71-40235-43 71-40235-43 71-40235-43
No. Notes
71 Blower Bracket AE-101124-01
72 Blower Bracket - Drive Side AE-101124-04 72a Grommet (Flat) 56-18518-04 72b Cross Brace AE-101467-01
73 Motor Mount Assembly AS-101340-01
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER ASSEMBLY - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER ASSEMBLY - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER MOTOR MOUNTING - BELT DRIVE
RLNL-
G
036
C L
RLNL-
G
036
C M
RLNL-
G
036-048
C/D L/M
RLNL-
G
036
D L
RLNL-
G
036
D
M
RLNL-
G
048
C L
RLNL-
G
048
C M
RLNL-
G
048
D L
RLNL-
G
048
D M
Page 17 of 56
04-October-2014
92-42800-RLNL-G
Page 18
MODEL
No. Notes
62 Stk Blower Assembly (Includes items 63-66, 68-73 excluding item 72b) AS-101336-05 AS-101336-05
63 Housing AS-101341-01 AS-101341-01
64 Stk Bearing FrameTri-Arm (2) 70-41723-03 70-41723-03
65 Stk Ball Bearing and Cushion (2) 70-41911-01 70-41911-01
66 Stk Blower Shaft 70-21933-02 70-21933-02
67 Stk Fixed Pitch Sheave 71-100772-03 71-100772-03
68 Blower Support - Left AE-58950-02 AE-58950-02
69 Stk Wheel 70-23589-01 70-23589-01
70 Cut-Off Tabulation AE-64401-05 AE-64401-05
74 Stk Blower Motor 51-21909-01 51-21909-01
75 Stk Variable Pitch Sheave 71-40427-29 71-40427-29
76 Stk Belt 71-40235-42 71-40235-42
No. Notes
62 Stk Blower Assembly (Includes items 63-66, 68-73 excluding item 72b) AS-101336-05 AS-101336-05
63 Housing AS-101341-01 AS-101341-01
64 Stk Bearing FrameTri-Arm (2) 70-41723-03 70-41723-03
65 Stk Ball Bearing and Cushion (2) 70-41911-01 70-41911-01
66 Stk Blower Shaft 70-21933-02 70-21933-02
67 Stk Fixed Pitch Sheave 71-100772-03 71-100772-03
68 Blower Support - Left AE-58950-02 AE-58950-02
69 Stk Wheel 70-23589-01 70-23589-01
70 Cut-Off Tabulation AE-64401-05 AE-64401-05
74 Stk Blower Motor 51-41936-01 51-41936-01
75 Stk Variable Pitch Sheave 71-40427-25 71-40427-25
76 Stk Belt 71-40235-43 71-40235-43
No. Notes
71 Blower Bracket AE-101124-01
72 Blower Bracket - Drive Side AE-101124-04 72a Grommet (Flat) 56-18518-04 72b Cross Brace AE-101467-01
73 Motor Mount Assembly AS-101340-01
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER ASSEMBLY - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER ASSEMBLY - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION DRIVE PACKAGE
BLOWER MOTOR MOUNTING - BELT DRIVE
RLNL-
G
060
C L
RLNL-
G
060
C
M
RLNL-
G
060 C/D L/M
RLNL-
G
060
D
L
RLNL-
G
060
D M
Page 18 of 56
04-October-2014
92-42800-RLNL-G
Page 19
MODEL
No. Notes
64 Stk Blower Assembly (Includes Items 65-68) AS-90757-01 AS-90757-01 AS-90757-01 65 Stk Blower Wheel 70-42540-02 70-42540-02 70-42540-02 66 Bearing FrameTri-Arm (2) 70-42540-05 70-42540-05 70-42540-05 67 Bearing with Bearing Lock (2) 70-41854-02 70-41854-02 70-41854-02 68 Stk Blower Shaft 70-42540-04 70-42540-04 70-42540-04 69 Blower Mounting Angles (2) AE-90708-01 AE-90708-01 AE-90708-01
Blower Angle Stop AE-90709-02 AE-90709-02 AE-90709-02 70 Motor Mount AS-90824-01 AS-90824-01 AS-90824-01 71 Stk Blower Motor - C/DVoltages 51-102826-14 51-102826-14 51-102826-06 72 Stk Variable Sheave 71-42538-02 71-42538-02 71-40427-31 73 Stk Belt 71-40438-30 71-40438-27 71-40438-23 74 Stk Fixed Sheave 71-100774-05 71-100774-02 71-100774-01
Key 94-42551-09 94-42551-09 94-42551-09
Stk Bushing for Sheave w/Screws 71-100773-01 71-100773-01 71-100773-01
No. Notes
64 Stk Blower Assembly (Includes Items 65-68) AS-90757-01 AS-90757-01 AS-90757-01 65 Stk Blower Wheel 70-42540-02 70-42540-02 70-42540-02 66 Bearing Frame Tri-Arm (2) 70-42540-05 70-42540-05 70-42540-05 67 Bearing with Bearing Lock (2) 70-41854-02 70-41854-02 70-41854-02 68 Stk Blower Shaft 70-42540-04 70-42540-04 70-42540-04 69 Blower Mounting Angles (2) AE-90708-01 AE-90708-01 AE-90708-01
Blower Angle Stop AE-90709-02 AE-90709-02 AE-90709-02 70 Motor Mount AE-90710-04 AE-90710-04 AE-90710-04 71 Stk Blower Motor - C/DVoltages 51-102826-14 51-102826-15 51-102826-06 72 Stk Variable Sheave 71-42538-02 71-42538-02 71-40427-11 73 Stk Belt 71-40438-27 71-40438-23 71-40438-31 74 Stk Fixed Sheave 71-100774-02 71-100774-04 71-26254-06
Key 94-42551-09 94-42551-09 94-42551-09
Stk Bushing for Sheave w/Screws 71-100773-01 71-100773-01 71-100773-01
No. Notes
64 Stk Blower Assembly (Includes Items 65-68) AS-90757-01 65 Stk Blower Wheel 70-42540-02 66 Bearing Frame Tri-Arm (2) 70-42540-05 67 Bearing with Bearing Lock (2) 70-41854-02 68 Stk Blower Shaft 70-42540-04 69 Blower Mounting Angles (2) AE-90708-01
Blower Angle Stop AE-90709-02 70 Motor Mount AE-90710-04 71 Stk Blower Motor - C/DVoltages 51-102826-15 72 Stk Variable Sheave 71-42538-02 73 Stk Belt 71-40438-23 74 Stk Fixed Sheave 71-100774-04
Key 94-42551-09
Stk Bushing for Sheave w/Screws 71-100773-01
TECHNICALVARIATION COOLING CAPACITY DRIVE PACKAGE
BLOWER ASSEMBLY GROUP - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY DRIVE PACKAGE
BLOWER ASSEMBLY GROUP - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY DRIVE PACKAGE
BLOWER ASSEMBLY GROUP - BELT DRIVE
RLNL-
G
090
R
RLNL-
G
090
S
RLNL-
G
090
T
RLNL-
G
120
R
RLNL-
G
120
S
RLNL-
G
151
R
RLNL-
G
151
S
Page 19 of 56
04-October-2014
92-42800-RLNL-G
Page 20
MODEL
No. Notes
64 Stk Blower Assembly - Includes Items 65 and 66 (2) AS-90757-06 AS-90757-06 AS-90757-06 65 Stk Blower Wheel (2) 70-42564-02 70-42564-02 70-42564-02 66 Bearing FrameTri-Arm (4) 70-42284-04 70-42284-04 70-42284-04 67 Bearing with Bearing Lock (4) 70-41854-02 70-41854-02 70-41854-02 68 Stk Blower Shaft 70-42564-03 70-42564-03 70-42564-03 69 Blower Connector Angles (3) AE-90798-01 AE-90798-01 AE-90798-01 70 Motor Mount AE-90710-03 AE-90710-03 AE-90710-03 71 Stk Blower Motor - CVoltage 51-102826-15 51-102826-06 51-102826-07 71 Stk Blower Motor - DVoltage 51-102826-15 51-102826-06 51-102826-07 72 Stk Variable Sheave 71-42538-02 71-40427-04 71-40427-59 73 Stk Belt 71-40438-43 71-40438-51 71-40438-54
74a Stk Fixed Sheave 71-100774-08 71-100774-06 71-100774-06 74b Key 94-42551-09 94-42551-09 94-42551-09 74c Stk Bushing for Sheave w/Screws 71-100773-01 71-100773-01 71-100773-01
No. Notes
64 Stk Blower Assembly - Includes Items 65 and 66 (2) AS-90757-06 AS-90757-06 AS-90757-06 65 Stk Blower Wheel (2) 70-42564-02 70-42564-02 70-42564-02 66 Bearing FrameTri-Arm (4) 70-42284-04 70-42284-04 70-42284-04 67 Bearing with Bearing Lock (4) 70-41854-02 70-41854-02 70-41854-02 68 Stk Blower Shaft 70-42564-03 70-42564-03 70-42564-03 69 Blower Connector Angles (3) AE-90798-01 AE-90798-01 AE-90798-01 70 Motor Mount AE-90710-03 AE-90710-03 AE-90710-03 71 Stk Blower Motor - CVoltage 51-102826-06 51-102826-07 51-102826-10 71 Stk Blower Motor - DVoltage 51-102826-06 51-102826-07 51-102826-10 72 Stk Variable Sheave 71-40427-04 71-40427-59 71-40427-60 73 Stk Belt 71-40438-46 71-40438-54 71-102847-01
74a Stk Fixed Sheave 71-100774-08 71-100774-06 71-100774-07 74b Key 94-42551-09 94-42551-09 94-42551-09 74c Stk Bushing for Sheave w/Screws 71-100773-01 71-100773-01 71-100773-01
TECHNICALVARIATION COOLING CAPACITY DRIVE PACKAGE
BLOWER ASSEMBLY GROUP - BELT DRIVE
MODEL TECHNICALVARIATION COOLING CAPACITY DRIVE PACKAGE
BLOWER ASSEMBLY GROUP - BELT DRIVE
RLNL-
G
180
R
RLNL-
G
180
S
RLNL-
G
240
R
RLNL-
G
240
S
RLNL-
G
300
R
RLNL-
G
300
S
Page 20 of 56
04-October-2014
92-42800-RLNL-G
Page 21
No. Notes
EVAPORATOR COIL:
80a Stk Evaporator Coil AS-102260-03 AS-102352-03 AS-102353-03 80b Stk Reheat Coil 65-101478-12 65-101478-12 65-101478-12 80c TXV Bulb Strap Kit 64-101357-01 64-101357-01 64-101357-01 80d Liquid Line Filter Drier 83-22755-03 83-22755-03 83-22755-03 80e Servo Valve - Liquid Line (LLSV) (2) 61-103961-05 61-103961-05 61-103961-05
80f Solenoid Coil (LLSV) (2) 61-103961-09 61-103961-09 61-103961-09
80g Distributor - (Two way - 3/8 in. to 3/8 in.) 83-17467-02 83-17467-02 83-17467-02
81 Top Air Stop AE-58933-01 AE-58933-01 AE-58933-01
Air Stop - Reheat Coil AE-104056-01 AE-104056-01 AE-104056-01 82 Top Coil Support AE-58941-01 AE-58941-01 AE-58941-01 83 Stk Indoor Coil Drain Pan 68-23559-01 68-23559-01 68-23559-01 85 Filter Channels (Center is two channels back-to-back) (3) AE-58934-01 AE-58934-01 AE-58934-01
Filter Keeper AE-59168-01 AE-59168-01 AE-59168-01 86 Filter - Disposable 16x25x1 (2) 54-17531-10 54-17531-10 54-17531-10 88 Header Assembly 82-101745-01 82-101745-02 82-101745-03
Important Note: Different manufacturers of TXV were used on this unit, and the exact part number must be used when making repair.To obtain the correct part number ofTXV either:
1) Provide the part number of TXV assembly by examining unit, or
2) Provide unit model number andTXV manufacturer. (See attached TXV identification guide for assistance.)
Stk TXV (Sporlan) 61-102257-01 61-102257-03 61-102257-04
Stk TXV (Emerson) 61-102258-01 61-102258-03 61-102258-04
CONDENSER COIL:
84a Stk Condenser Coil AS-101714-03 AS-101716-01 AS-101717-01 84b Servo Valve - Hot Gas (HGSV) 61-103961-01 61-103961-01 61-103961-01 84c Solenoid Coil (HGSV) 61-103961-07 61-103961-07 61-103961-07 84d CheckValve 83-102440-05 83-102440-05 83-102440-05
MODEL TECHNICALVARIATION COOLING CAPACITY
COIL GROUP
RLNL-
G
036
RLNL-
G
048
RLNL-
G
060
Page 21 of 56
04-October-2014
92-42800-RLNL-G
Page 22
No.
EVAPORATOR COIL GROUP: 42a Stk Evaporator Coil AS-90656-68 AS-90656-69 AS-90656-75 42b Stk Reheat Coil 65-101478-11 65-101478-11 65-101478-11
TXV Bulb Strap Kit (2) 64-101357-01 64-101357-01 64-101357-01 42c Liquid Line Filter Drier (2) 83-22755-05 83-22755-05 83-22755-05 42d Strap - Filter Drier (2) AE-102132-01AE-102132-01AE-102132-01 42e Stk Servo Valve - Liquid Line (LLSV) (2) 61-103961-05 61-103961-05 61-103961-05
42f Stk Solenoid Coil (LLSV) (2) 61-103961-09 61-103961-09 61-103961-09
Bulb Strap Kit - TXV (2) 64-101357-01 64-101357-01 64-101357-01 42g Stk TXV - Circuit #1 61-101351-11 61-101351-13 61-101351-14 42h Stk TXV - Circuit #2 61-101351-11 61-101351-13 61-101351-14
43 Stk Drain Pan - Removable 68-102699-02 68-102699-02 68-102699-02
FILTER PIECES:
44 Filter Frame AE-90606-11 AE-90606-11 AE-90606-11 45 Air Stop - Bottom AE-102712-10AE-102712-10AE-102712-10 46 Air Stop - Side AE-102712-06AE-102712-06AE-102712-06 47 Top Air Stop Assembly AS-90604-06 AS-90604-06 AS-90604-06 48 Filter Channel (2) AE-102712-08AE-102712-08AE-102712-08 49 Filter Slide (2) AE-102712-11AE-102712-11AE-102712-11 50 Filter (6) 54-42541-01 54-42541-01 54-42541-01
CONDENSER COIL GROUP: 37a Stk Condenser Coil AS-102704-03 AS-90656-42 65-101478-08 37b Stk Condenser Coil AS-102704-03 AS-90656-42 65-101478-08
38 Front Air Stop AE-90706-19 AE-90706-19 N/A 39 Rear Air Stop AE-90706-18 AE-90706-18 N/A
40a,
b 40a Micro-Channel Coil Mounting Base - Left N/A N/A 68-102752-01 40b Micro-Channel Coil Mounting Base - Right N/A N/A 68-102752-02 41a Top Support - Condenser Coil AE-90612-09 AE-90612-02 AE-90612-31 41b Top Support - Condenser Bulkhead AE-90612-03 AE-90612-03 AE-90612-30 41c Stk Servo Valve - Hot Gas (HGSV) 61-103961-10 61-103961-10 61-103961-11 41d Stk Solenoid Coil (HGSV) 61-103961-13 61-103961-13 61-103961-13
Stk High Pressure Control (2) 47-23699-04 47-23699-04 47-103669-01
41e Stk Low Pressure Control (2) 47-101529-09 47-101529-09 47-101529-09
41f Stk Check Valve 83-102440-05 83-102440-05 83-102440-05
Distributor (3/8 x 3/8 x 5/8) 83-17467-03 83-17467-03 N/A
TECHNICALVARIATION
s
COOLING CAPACITY
Bottom Retainer (2) AE-90700-03 AE-90700-02 N/A
COIL GROUP
MODEL
Note
RLNL-
G
090
RLNL-
G
120
RLNL-
G
151
Page 22 of 56
04-October-2014
92-42800-RLNL-G
Page 23
No. Notes
EVAPORATOR COIL GROUP:
40 Air Flow Panel AS-90828-02H AS-90828-02H AS-90828-02H 42a Stk Evaporator Coil AS-102821-03 AS-102652-03 AS-102428-03 42b Stk Reheat Coil 65-101478-13 65-101478-13 65-101478-13 42c Stk Servo Valve - Liquid Line (LLSV) 61-103961-08 61-103961-08 61-103961-08 42d Stk Servo Valve - Liquid Line (LLSV) 61-103961-08 61-103961-08 61-103961-15 42e Stk Solenoid Coil - (LLSV) (2) 61-103961-09 61-103961-09 61-103961-09 42f Stk TXV/Distributor Assembly - Circuit #1 61-102845-01 61-102687-01 61-102815-01 42g Stk TXV/Distributor Assembly - Circuit #2 61-102845-01 61-102687-01 61-102815-01
43 Stk Drain Pan - Removable 68-102699-01 68-102699-01 68-102699-01
FILTER PIECES: 44 Filter Frame AE-90606-10 AE-90606-10 AE-90606-10 45 Air Stop - Bottom AE-102712-17 AE-102712-17 AE-102712-17 46 Air Stop - Side AE-102712-14 AE-102712-14 AE-102712-14 47 Top Air Stop Assembly AS-90604-04 AS-90604-04 AS-90604-04 48 Filter Channel (2) AE-102712-16 AE-102712-16 AE-102712-16 49 Filter Slide (2) AE-102712-15 AE-102712-15 AE-102712-15 50 Filter - 20 in. x 25 in. x 2 in. (8) 54-42541-04 54-42541-04 54-42541-04
CONDENSER COIL: 37 Stk Condenser Coil Assemlby (2) AS-102647-03 AS-102666-03 AS-102666-03
38a Air Stop - Front AE-90706-13 AE-90706-13 AE-90706-13 38b Corner Brace - Top Front AS-90706-16H AS-90706-16H AS-90706-16H 38c Post - Front AS-90706-14H AS-90706-14H AS-90706-14H 39a Air Stop - Rear AE-90706-12 AE-90706-12 AE-90706-12 39b Corner Brace - Top Rear AS-90706-17H AS-90706-17H AS-90706-17H 39c Post - Rear AS-90706-15H AS-90706-15H AS-90706-15H
41 Air Stop- Top Right AS-90753-08H AS-90753-08H AS-90753-08H
41a Top Support - Inner Condenser Coil (2) AE-90612-21 AE-90612-08 AE-90612-08 41b Top Support - Outer Condenser Coil AE-90612-20 AE-90612-11 AE-90612-11 41c TopSupport - Condenser Bulkhead AE-90612-18 AE-90612-06 AE-90612-06 41d Stk High Pressure Control (2) 47-23699-04 47-23699-04 47-23699-04 41e Stk Low Pressure Control (2) 47-101529-09 47-101529-09 47-101529-09 41f Stk Check Valve 83-102440-02 83-102440-02 83-102440-02 41g Filter Drier - Liquid Line (2) 83-22755-11 83-22755-11 83-22755-11 41h Stk Servo Valve - Hot Gas (HGSV) 61-103961-12 61-103961-11 61-103961-14
41i Stk Solenoid Coil - (HGSV) 61-103961-13 61-103961-13 61-103961-13
MODEL TECHNICALVARIATION COOLING CAPACITY
COIL GROUP
RLNL-
G
180
RLNL-
G
240
RLNL-
G
300
Page 23 of 56
04-October-2014
92-42800-RLNL-G
Page 24
MODEL
No. Notes
Compressor ID: 8545 8546
79 Stk Compressor 55-102045-05S 55-102045-04S
Stk Compressor Wiring Harness (Molded Plug) 45-100834-10 45-100834-10
No. Notes
Compressor ID: 8547 8548
79 Stk Compressor 55-102045-11S 55-102045-10S
Stk Compressor Wiring Harness (Molded Plug) 45-100834-10 45-100834-10
No. Notes
Compressor ID: 8549 8550
79 Stk Compressor 55-102045-22S 55-102045-23S
Stk Compressor Wiring Harness (Molded Plug) 45-100834-10 45-100834-10
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
RLNL-
G
036
C
RLNL-
G
048
C
RLNL-
G
060
C
RLNL-
G
036
D
RLNL-
G
048
D
RLNL-
G
060
D
Page 24 of 56
04-October-2014
92-42800-RLNL-G
Page 25
MODEL
No. Notes
Compressor ID: 8533 8537 8636
75 Stk Compressor #1 55-102045-08S 55-102045-27S 55-102471-21S 75 Stk Compressor #2 55-102045-08S 55-102045-27S 55-102471-21S
Contactor - Compressor See Electric Group Stk Plug Harness - Compressor #1 45-102708-01 45-102708-01 45-102708-03 Stk Plug Harness - Compressor #2 45-102708-02 45-102708-02 45-102708-04
No. Notes
Compressor ID: 8534 8538 8637
75 Stk Compressor #1 55-102045-07S 55-102045-28S 55-102471-22S 75 Stk Compressor #2 55-102045-07S 55-102045-28S 55-102471-22S
Contactor - Compressor See Electric Group Stk Plug Harness - Compressor #1 45-102708-01 45-102708-01 45-102708-03 Stk Plug Harness - Compressor #2 45-102708-02 45-102708-02 45-102708-04
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
RLNL-
G
090
C
RLNL-
G
090
D
RLNL-
G
120
C
RLNL-
G
120
D
RLNL-
G
151
C
RLNL-
G
151
D
Page 25 of 56
04-October-2014
92-42800-RLNL-G
Page 26
MODEL
No. Notes
Compressor: 8555 8557 8586
75 Stk Compressor #1 55-23156-20S 55-102471-02S 55-102471-13S 75 Stk Compressor #2 55-23156-20S 55-102471-03S 55-102471-13S
Stk Plug Harness - Compressor #1 45-42522-73 45-42522-73 45-42522-73 Stk Plug Harness - Compressor #2 45-42522-72 45-42522-72 45-42522-72
41d High Pressure Control See Coil Group 41e Low Pressure Control See Coil Group
No. Notes
Compressor: 8556 8558 8587
75 Stk Compressor #1 55-23156-21S 55-102471-09S 55-102471-08S 75 Stk Compressor #2 55-23156-21S 55-102471-07S 55-102471-08S
Stk Plug Harness - Compressor #1 45-42522-73 45-42522-73 45-42522-73 Stk Plug Harness - Compressor #2 45-42522-72 45-42522-72 45-42522-72
41d High Pressure Control See Coil Group 41e Low Pressure Control See Coil Group
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
COMPRESSOR GROUP
RLNL-
G
180
C
RLNL-
G
180
D
RLNL-
G
240
C
RLNL-
G
240
D
RLNL-
G
300
C
RLNL-
G
300
D
Page 26 of 56
04-October-2014
92-42800-RLNL-G
Page 27
MODEL
No. Notes
Electric Element Kits RXJJ-A06C RXJJ-A06D
Electric Element Kits RXJJ-A10C RXJJ-A10D
Electric Element Kits RXJJ-A12C RXJJ-A12D
Electric Element Kits RXJJ-A15C RXJJ-A15D
Electric Element Kits RXJJ-A20C RXJJ-A20D
Electric Element Kits RXJJ-A24C RXJJ-A24D
No. Notes
Electric Element Kits RXJJ-CC10C RXJJ-CC10D
Electric Element Kits RXJJ-CC15C RXJJ-CC15D
Electric Element Kits RXJJ-CC20C RXJJ-CC20D
Electric Element Kits RXJJ-CC30C RXJJ-CC30D
Electric Element Kits RXJJ-CC40C RXJJ-CC40D
Electric Element Kits RXJJ-CC50D RXJJ-CC50D
No. Notes
Electric Element Kits RXJJ-CE20C RXJJ-CE20D
Electric Element Kits RXJJ-CE40C RXJJ-CE40D
Electric Element Kits RXJJ-CE60C RXJJ-CE60D
Electric Element Kits RXJJ-CE75C RXJJ-CE75D
TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC HEATER KITS
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC HEATER KITS
MODEL TECHNICALVARIATION COOLING CAPACITY ELECTRICAL DESIGNATION
ELECTRIC HEATER KITS
RLNL-
G
036-060
C
RLNL-
G
090-151
C
RLNL-
G
180-300
C
RLNL-
G
036-060
D
RLNL-
G
090-151
D
RLNL-
G
180-300
D
Page 27 of 56
04-October-2014
92-42800-RLNL-G
Page 28
No. Notes
DDC Economizer with Single Enthalpy and Barometric Relief AXRD-TKCM3 DDC Economizer with Single Enthalpy,Smoke Detector and Barometric Relief AXRD-UKCM3 Non-PoweredConvenience Outlet RXRX-AN02 Service Disconnect RXRX-AP02 Dual Enthalpy Kit RXRX-AV02 CO2 Sensor RXRX-AR02 PowerExhaust - C Voltage AXRX-BGF04C PowerExhaust - D Voltage AXRX-BGF04D Fresh Air Damper Manual AXRF-FBA1 Fresh Air Damper Motorized AXRF-FBB1 Louver Kit - (3 Sides) AXRX-AAD01B Comfort Alert RXRX-AZ01 BACnet Communication Card RXRX-AY01 Lonworks Communication Card RXRX-AY02 Low Ambient Control RXRZ-A04 Room Humidity Sensor RHC-ZNS4 Room Temperature and Relative Humidity Sensor RHC-ZNS5
No. Notes
Horizontal Economizer with Single Enthalpy and Smoke Detector AXRD-SJCM3 Horizontal Economizer with Single Enthalpy AXRD-RJCM3
Louver Panel- Option AXRX-AAD01C Carbon Dioxide Sensor RXRX-AR02 Dual Enthalpy Kit RXRX-AV03 Manual FreshAir (Left Panel Mounted) AXRF-KDA1 Motor Kit forAXRF-KDA1 RXRX-AW02 Manual FreshAir Damper (Horizontal Return Mounted) AXRF-JDA1 Motorized Fresh Air Damper (Horizontal Return Mounted) AXRF-JDB1 Modulating Motor Kit w/position feedback for AXRF-KDA1 RXRX-AW04 Outdoor Coil Louver Kit AXRX-AAD01C Comfort Alert RXRX-AZ01 Convenience Outlet - Option RXRX-AN01 Low Ambient Control Kit (One per Compressor) RXRZ-C02 BACnet Communication Card RXRX-AY01 LonWorks Communication Card RXRX-AY02 Room Humidity Sensor RHC-ZNS4 Room Temperature and Relative Humidity Sensor RHC-ZNS5
No. Notes
Economizer - Single Enthalpy AXRD-PJCM3 Economizer - Single Enthalpy w/Smoke Detector AXRD-SJCM3 Horizontal Economizer - Single Enthalpy AXRD-RJCM3
No.
PowerExhaust RXRX-BFF02C PowerExhaust RXRX-BFF02D PowerExhaust RXRX-BFF02Y
MODEL TECHNICALVARIATION COOLING CAPACITY
OPTIONS AND ACCESSORIES
MODEL TECHNICALVARIATION COOLING CAPACITY
ACCESSORIES
MODEL TECHNICALVARIATION COOLING CAPACITY
ECONOMIZERS
MODEL TECHNICALVARIATION COOLING CAPACITY
POWER EXHAUST
RLNL-
G
036-060
RLNL-
G
090-120
RLNL-
G
090-120
RLNL-
G
090-120
Page 28 of 56
04-October-2014
92-42800-RLNL-G
Page 29
No. Notes
Carbon Dioxide Sensor RXRX-AR02 Dual Enthalpy Kit RXRX-AV03 Manual FreshAir Damper AXRF-KFA1 Motorized Kit forAXRF-KFA1 RXRX-AW03 Modulating Motor Kit w/position feedback for AXRF-KFA1 RXRX-AW05 Unwired Convenience Outlet RXRX-AN01 Comfort Alert (1 Per Compressor) RXRX-AZ01 BACnet Communication Card RXRX-AY01 LonWorks Communication Card RXRX-AY02 Low Ambient Control Kit (1 Per Compressor) RXRZ-C02 Louver PanelKit (Hail Guard) - Left and Right (Granite/Steel Gray) AXRX-AAD01L
No. Notes
Downflow Economizer - Single Enthalpy AXRD-PMCM3 Downflow Economizer - Single Enthalpy w/Smoke Detector AXRD-SMCM3 Horizontal Economizer - Single Enthalpy AXRD-RMCM3
No.
PowerExhaust (208/230V) RXRX-BGF05C PowerExhaust (460V) RXRX-BGF05D
PowerExhaust (575V) RXRX-BGF05Y
MODEL TECHNICALVARIATION COOLING CAPACITY
ACCESSORIES
MODEL TECHNICALVARIATION COOLING CAPACITY
ECONOMIZERS
MODEL TECHNICALVARIATION COOLING CAPACITY
POWER EXHAUST
RLNL-
G
180-300
RLNL-
G
180-300
RLNL-
G
180-300
Page 29 of 56
04-October-2014
92-42800-RLNL-G
Page 30
Exploded View 036-060
Page 30 of 56
04-October-2014
92-42800-RLNL-G
Page 31
Top Panel View 036-060
Page 31 of 56
04-October-2014
92-42800-RLNL-G
Page 32
Control Box 036-060
Page 32 of 56
04-October-2014
92-42800-RLNL-G
Page 33
Blower Assembly 036-060
Page 33 of 56
04-October-2014
92-42800-RLNL-G
Page 34
Blower Motor Mount Assembly 036-060
Page 34 of 56
04-October-2014
92-42800-RLNL-G
Page 35
Coil Group Cut-away View 036-060
Evaporator Coil - Filter Parts 036-060
Page 35 of 56
04-October-2014
92-42800-RLNL-G
Page 36
Evaporator Coil Parts 036-060
Page 36 of 56
04-October-2014
92-42800-RLNL-G
Page 37
Compressor - Refrigeration Group 036-060
Page 37 of 56
04-October-2014
92-42800-RLNL-G
Page 38
Reheat Circuit Assembly 036-060
Page 38 of 56
04-October-2014
92-42800-RLNL-G
Page 39
TXV Identification Guide
Page 39 of 56
04-October-2014
92-42800-RLNL-G
Page 40
Exploded View 090-151
Page 40 of 56
04-October-2014
92-42800-RLNL-G
Page 41
Exterior - Front 090-151
Exterior - Back 090-151
Page 41 of 56
04-October-2014
92-42800-RLNL-G
Page 42
Filter-Coil Assembly 090-151
Condenser Coil Assembly 090-151
Page 42 of 56
04-October-2014
92-42800-RLNL-G
Page 43
Front Panel Brackets 090-151
Page 43 of 56
04-October-2014
92-42800-RLNL-G
Page 44
Filter Frame Assembly 090-151
Blower Assembly 090-151
Page 44 of 56
04-October-2014
92-42800-RLNL-G
Page 45
Control Box 090-151
Page 45 of 56
04-October-2014
92-42800-RLNL-G
Page 46
Low Voltage Shields 090-151
Page 46 of 56
04-October-2014
92-42800-RLNL-G
Page 47
Reheat Circuit Assembly 090-151
Page 47 of 56
04-October-2014
92-42800-RLNL-G
Page 48
Exterior - Front 180-300
Exterior - Rear 180-300
Page 48 of 56
04-October-2014
92-42800-RLNL-G
Page 49
Base Pan Assembly 180-300
Base Rail Assembly 180-300
Page 49 of 56
04-October-2014
92-42800-RLNL-G
Page 50
Front Panel Brackets 180-300
Interior - Coil 180-300
Page 50 of 56
04-October-2014
92-42800-RLNL-G
Page 51
Heat Compartment 180-300
Condenser Bulkhead 180-300
Page 51 of 56
04-October-2014
92-42800-RLNL-G
Page 52
Filter Frame Assembly 180-300
Blower Assembly 180-300
Page 52 of 56
04-October-2014
92-42800-RLNL-G
Page 53
Control Box 180-300
Page 53 of 56
04-October-2014
92-42800-RLNL-G
Page 54
Electric Heat Block-Off 180-300
Page 54 of 56
04-October-2014
92-42800-RLNL-G
Page 55
Reheat Circuit Assembly 180-300
Page 55 of 56
04-October-2014
92-42800-RLNL-G
Page 56
NOTES
Stk It is recommended that stock be maintained for this part.
N/A Not Applicable
DISCLAIMER: This document is intended to provide general replacement parts information to aid qualified service personnel in the repair of these models. The complete Model and Serial Number of the unit under repair should be specified when selecting and ordering replacement parts. Specifications and illustrations are subject to change without notice. Document 92-42800-RLNL-G supersedes all previous parts lists for these models. See http://www.rheempartslists.net/92-42800-RLNL-G for the latest revision of this document. The manufacturer assumes no obligation for errors or omissions. Service personnel must verify the proper and safe operation of equipment after the replacement of any original components.
P.O. Box 17010
Fort Smith, AR 72917-7010
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
