RH1P
Parts List
09-May-2014
This parts list is current as of the above revision date.
See http://www.rheempartslists.net/92-42800-RH1P.pdf for the current revision.
Air Handlers
Table of Contents
Model Explanation... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... Page 3
Parts Numbers
Panels - Miscellaneous (1)... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... Page 4
Panels - Miscellaneous (2)... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... Page 5
Electrical Group (1).. .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... Page 6
Electrical Group (2).. .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... Page 7
Blower Group (1) ..... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... ... Page 8
Blower Group (2) ..... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... ... Page 9
Coil Parts ....... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . .. Page 10
Heater Kits . . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... Page 10
Drawings/Photographs
Exploded View .. ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... . ... Page 11
Blower Assembly .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... ... Page 12
Notes/Disclaimer . .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .. Page 13
Page 2 of 13
09-May-2014
92-42800-RH1P
MODEL NUMBER EXPLANATION
R H 1 P 2 4 1 7 S T A N A A ***
1 2 3 4 5 6 7 8 9 10 11 12 13
(1) BRAND (8) METERING DEVICE
T = TEV
(2) AIR HANDLER E = EEV
P = Piston
(3) STAGE OF AIRFLOW
1 = Single (9) MAJOR SERIES
A = First
(4) MOTORTYPE
P = PSC (10) CONTROLS
C = Communicating
(5) CAPACITY (BTU/HR) N = Non-Communicating
18 = 18,000 BTU/HR
24 = 24,000 BTU/HR (11) VOLTAGE
30 = 30,000 BTU/HR A = 115/1/60
36 = 36,000 BTU/HR D = 460/3/60
42 = 42,000 BTU/HR J = 208-230/1/60
48 = 48,000 BTU/HR T = 220-240/1/50
60 = 60,000 BTU/HR
(12) MINOR SERIES
(6) WIDTH A = First
17 = 17.5 in. (600 - 1200 CFM)
21 = 21 in. (800 - 1600 CFM) (13) OPTION CODE
24 = 24.5 in. (1400 - 1800 CFM) Blank = None
(7) COIL SIZE
S = Standard
M = Medium
H = High
SERIAL NUMBER EXPLANATION
W 0 7 0 9 9 9 9 9 9
1 2 3 4
1 PRODUCTION LOCATION
W = Nuevo Laredo (West)
2 WEEK OF PRODUCTION
3 YEAR OF PRODUCTION
4 PRODUCTION NUMBER
Page 3 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
1 Cabinet AE-100682-31 AE-100682-31 AE-100682-31 AE-100682-31 AE-100682-31 AE-100682-31
2 Coil Door AE-100685-32 AE-100685-32 AE-100685-32 AE-100685-32 AE-100685-32 AE-100685-32
3 Top Cover Plate AE-100686-31 AE-100686-31 AE-100686-31 AE-100686-31 AE-100686-31 AE-100686-31
4 Blower Door AE-100684-31 AE-100684-31 AE-100684-31 AE-100684-31 AE-100684-31 AE-100684-31
5 Access Panel AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31
6 Drain Pan - Vertical See RCH Coil Parts List
7 Drain Pan - Horizontal See RCH Coil Parts List
8 Plate - Block Off AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01
9 Cabinet Brace AE-101134-02 AE-101134-02 AE-101134-02 AE-101134-02 AE-101134-02 AE-101134-02
10 Middle Brace AE-101054-01 AE-101054-01 AE-101054-01 AE-101054-01 AE-101054-01 AE-101054-01
13a Heat Barrier AE-100683-02 AE-100683-02 AE-100683-02 AE-100683-02 AE-100683-03 AE-100683-03
13b Heat Barrier Side (2) AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01
No.Notes
1 Cabinet AE-100682-31 AE-100682-31 AE-100682-31 AE-100682-32 AE-100682-33 AE-100682-33
2 Coil Door AE-100685-32 AE-100685-32 AE-100685-32 AE-100685-33 AE-100685-34 AE-100685-34
3 Top Cover Plate AE-100686-31 AE-100686-31 AE-100686-31 AE-100686-32 AE-100686-32 AE-100686-32
4 Blower Door AE-100684-31 AE-100684-31 AE-100684-31 AE-100684-32 AE-100684-32 AE-100684-32
5 Access Panel AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31
6 Drain Pan - Vertical See RCH Coil Parts List
7 Drain Pan - Horizontal See RCH Coil Parts List
8 Plate - Block Off AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01
9 Cabinet Brace AE-101134-02 AE-101134-02 AE-101134-02 AE-101134-03 AE-101134-03 AE-101134-03
10 Middle Brace AE-101054-01 AE-101054-01 AE-101054-01 AE-101054-02 AE-101054-02 AE-101054-02
13a Heat Barrier AE-100683-03 AE-100683-03 AE-100683-03 AE-100683-05 AE-100683-06 AE-100683-06
13b Heat Barrier Side (2) AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Insulation - Cabinet 68-101121-01 68-101121-01 68-101121-01 68-101121-01 68-101121-01 68-101121-01
Insulation Retainer Rod (2) 45-102868-02 45-102868-02 45-102868-02 45-102868-02 45-102868-02 45-102868-02
Insulation - Coil Door 68-101577-06 68-101577-06 68-101577-06 68-101577-06 68-101577-06 68-101577-06
Insulation - TopCover Plate 68-101122-01 68-101122-01 68-101122-01 68-101122-01 68-101122-01 68-101122-01
Insulation - Blower Door 68-101576-01 68-101576-01 68-101576-01 68-101576-01 68-101576-01 68-101576-01
Insulation - Access Panel 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01
Touch-upPaint - Granite/Steel Gray (Aerosol) PD523018 PD523018 PD523018 PD523018 PD523018 PD523018
Touch-up Paint - Granite/Steel Gray (Paint
Pens)
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Insulation - Cabinet 68-101121-01 68-101121-01 68-101121-01 68-101121-02 68-101121-03 68-101121-03
Insulation Retainer Rod (2) 45-102868-02 45-102868-02 45-102868-02 45-102868-03 45-102868-03 45-102868-03
Insulation - Coil Door 68-101577-06 68-101577-06 68-101577-06 68-101577-07 68-101577-08 68-101577-08
Insulation - TopCover Plate 68-101122-01 68-101122-01 68-101122-01 68-101122-02 68-101122-02 68-101122-02
Insulation - Blower Door 68-101576-01 68-101576-01 68-101576-01 68-101576-02 68-101576-02 68-101576-02
Insulation - Access Panel 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01
Touch-upPaint - Granite/Steel Gray (Aerosol) PD523018 PD523018 PD523018 PD523018 PD523018 PD523018
Touch-up Paint - Granite/Steel Gray (Paint
Pens)
RH1P
18
17
ST
AN
AA
PANELS, SHEET METAL, MISCELLANEOUS
PD523019 PD523019 PD523019 PD523019 PD523019 PD523019
RH1P
36
17
ST
AN
AA
PANELS, SHEET METAL, MISCELLANEOUS
PD523019 PD523019 PD523019 PD523019 PD523019 PD523019
RH1P
18
17
ST
AN
JA
RH1P
36
17
ST
AN
DA
RH1P
24
17
ST
AN
AA
RH1P
36
17
ST
AN
JA
RH1P
24
17
ST
AN
JA
RH1P
36
21
ST
AN
JA
RH1P
30
17
ST
AN
AA
RH1P
42
21
ST
AN
AA
RH1P
30
17
ST
AN
JA
RH1P
42
21
ST
AN
DA
Page 4 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
1 Cabinet AE-100682-33 AE-100682-33 AE-100682-33 AE-100682-33 AE-100682-35 AE-100682-35
2 Coil Door AE-100685-34 AE-100685-34 AE-100685-34 AE-100685-34 AE-100685-36 AE-100685-36
3 Top Cover Plate AE-100686-32 AE-100686-32 AE-100686-32 AE-100686-32 AE-100686-33 AE-100686-33
4 Blower Door AE-100684-32 AE-100684-32 AE-100684-32 AE-100684-32 AE-100684-33 AE-100684-33
5 Access Panel AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31 AE-101133-31
6 Drain Pan - Vertical See RCH Coil Parts List
7 Drain Pan - Horizontal See RCH Coil Parts List
8 Plate - Block Off AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01
9 Cabinet Brace AE-101134-03 AE-101134-03 AE-101134-03 AE-101134-03 AE-101134-04 AE-101134-04
10 Middle Brace AE-101054-02 AE-101054-02 AE-101054-02 AE-101054-02 AE-101054-03 AE-101054-03
13a Heat Barrier AE-100683-06 AE-100683-06 AE-100683-06 AE-100683-06 AE-100683-07 AE-100683-07
13b Heat Barrier Side (2) AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01
No.Notes
1 Cabinet AE-100682-35 AE-100682-35
2 Coil Door AE-100685-36 AE-100685-36
3 Top Cover Plate AE-100686-33 AE-100686-33
4 Blower Door AE-100684-33 AE-100684-33
5 Access Panel AE-101133-31 AE-101133-31
6 Drain Pan - Vertical See RCH Coil Parts List
7 Drain Pan - Horizontal See RCH Coil Parts List
8 Plate - Block Off AE-100455-01 AE-100455-01
9 Cabinet Brace AE-101134-04 AE-101134-04
10 Middle Brace AE-101054-03 AE-101054-03
13a Heat Barrier AE-100683-08 AE-100683-08
13b Heat Barrier Side (2) AE-104241-01 AE-104241-01
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Insulation - Cabinet 68-101121-03 68-101121-03 68-101121-03 68-101121-03 68-101121-04 68-101121-04
Insulation Retainer Rod (2) 45-102868-03 45-102868-03 45-102868-03 45-102868-03 45-102868-04 45-102868-04
Insulation - Coil Door 68-101577-08 68-101577-08 68-101577-08 68-101577-08 68-101577-09 68-101577-09
Insulation - TopCover Plate 68-101122-02 68-101122-02 68-101122-02 68-101122-02 68-101122-03 68-101122-03
Insulation - Blower Door 68-101576-02 68-101576-02 68-101576-02 68-101576-02 68-101576-03 68-101576-03
Insulation - Access Panel 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01 68-101644-01
Touch-upPaint - Granite/Steel Gray (Aerosol) PD523018 PD523018 PD523018 PD523018 PD523018 PD523018
Touch-up Paint - Granite/Steel Gray (Paint
Pens)
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Insulation - Cabinet 68-101121-04 68-101121-04
Insulation Retainer Rod (2) 45-102868-04 45-102868-04
Insulation - Coil Door 68-101577-09 68-101577-09
Insulation - TopCover Plate 68-101122-03 68-101122-03
Insulation - Blower Door 68-101576-03 68-101576-03
Insulation - Access Panel 68-101644-01 68-101644-01
Touch-upPaint - Granite/Steel Gray (Aerosol) PD523018 PD523018
Touch-up Paint - Granite/Steel Gray (Paint
Pens)
RH1P
42
21
ST
AN
JA
PANELS, SHEET METAL, MISCELLANEOUS
PD523019 PD523019 PD523019 PD523019 PD523019 PD523019
RH1P
60
24
ST
AN
DA
PANELS, SHEET METAL, MISCELLANEOUS
PD523019 PD523019
RH1P
48
21
ST
AN
AA
RH1P
60
24
ST
AN
JA
RH1P
48
21
ST
AN
DA
RH1P
48
21
ST
AN
JA
RH1P
48
24
ST
AN
DA
RH1P
48
24
ST
AN
JA
Page 5 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
17 Stk Transformer 46-101944-01 46-101905-01 46-101944-01 46-101905-01 46-101944-01 46-101905-01
18 Stk Control Board 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05
11 Terminal Block 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02
No.Notes
17 Stk Transformer 46-101944-01 46-101946-01 46-101905-01 46-101905-01 46-101944-01 46-101946-01
18 Stk Control Board 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05
11 Terminal Block 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Wiring Harness - 5 Pin Molex to 3 stripped
wires (For T-Stat)
Wiring Harness - 5 Pin Molex to 5 stripped
wires (For T-Stat)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Relay to Terminal
Block)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Motor and Terminal
Block)
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Wiring Harness - 5 Pin Molex to 3 stripped
wires (For T-Stat)
Wiring Harness - 5 Pin Molex to 5 stripped
wires (For T-Stat)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Relay to Terminal
Block)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Motor and Terminal
Block)
RH1P
18
17
ST
AN
AA
ELECTRICAL GROUP
45-102645-02 N/A 45-102645-02 N/A 45-102645-02 N/A
N/A 45-102645-01 N/A 45-102645-01 N/A 45-102645-01
45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17
45-24258-23 45-24258-21 45-24258-23 45-24258-21 45-24258-23 45-24258-21
RH1P
36
17
ST
AN
AA
ELECTRICAL GROUP
45-102645-02 N/A N/A N/A 45-102645-02 N/A
N/A 45-102645-01 45-102645-01 45-102645-01 N/A 45-102645-01
45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17
45-24258-23 45-24258-21 45-24258-21 45-24258-21 45-24258-23 45-24258-21
RH1P
18
17
ST
AN
JA
RH1P
36
17
ST
AN
DA
RH1P
24
17
ST
AN
AA
RH1P
36
17
ST
AN
JA
RH1P
24
17
ST
AN
JA
RH1P
36
21
ST
AN
JA
RH1P
30
17
ST
AN
AA
RH1P
42
21
ST
AN
AA
RH1P
30
17
ST
AN
JA
RH1P
42
21
ST
AN
DA
Page 6 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
17 Stk Transformer 46-101905-01 46-101944-01 46-101946-01 46-101905-01 46-101946-01 46-101905-01
18 Stk Control Board 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05 47-100436-05
11 Terminal Block 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02 45-23222-02
No.Notes
17 Stk Transformer 46-101946-01 46-101905-01
18 Stk Control Board 47-100436-05 47-100436-05
11 Terminal Block 45-23222-02 45-23222-02
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Wiring Harness - 5 Pin Molex to 3 stripped
wires (For T-Stat)
Wiring Harness - 5 Pin Molex to 5 stripped
wires (For T-Stat)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Relay to Terminal
Block)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Motor and Terminal
Block)
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Wiring Harness - 5 Pin Molex to 3 stripped
wires (For T-Stat)
Wiring Harness - 5 Pin Molex to 5 stripped
wires (For T-Stat)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Relay to Terminal
Block)
Wiring Harness - 1 strip lead and 1
connector to single connector (Control
Transformer to Blower Motor and Terminal
Block)
RH1P
42
21
ST
AN
JA
ELECTRICAL GROUP
N/A 45-102645-02 N/A N/A N/A N/A
45-102645-01 N/A 45-102645-01 45-102645-01 45-102645-01 45-102645-01
45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17 45-24258-17
45-24258-21 45-24258-23 45-24258-21 45-24258-21 45-24258-21 45-24258-21
RH1P
60
24
ST
AN
DA
ELECTRICAL GROUP
N/A N/A
45-102645-01 45-102645-01
45-24258-17 45-24258-17
45-24258-21 45-24258-21
RH1P
48
21
ST
AN
AA
RH1P
60
24
ST
AN
JA
RH1P
48
21
ST
AN
DA
RH1P
48
21
ST
AN
JA
RH1P
48
24
ST
AN
DA
RH1P
48
24
ST
AN
JA
Page 7 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
15 Stk Blower Assembly (Includes items 16-22) AS-101929-01 AS-101931-01 AS-101929-02 AS-101931-02 AS-101929-03 AS-101931-03
16 Mounting Bracket - Control Board AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01
17 Transformer See Electrical Group
18 Control Board See Electrical Group
19 Blower Housing w/Wheel 70-101729-01 70-101729-01 70-101729-01 70-101729-01 70-101729-02 70-101729-02
20 Motor Mount - Band 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04
21 Motor Mount - Arm (4) 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10
22 Stk Blower Motor (PSC) 51-102175-01 51-102177-01 51-102175-02 51-101728-02 51-102175-03 51-102177-03
23 Mounting Bracket Cover AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01
No.Notes
15 Stk Blower Assembly (Includes items 16-22) AS-101929-04 AS-101932-01 AS-101931-04 AS-101931-04 AS-101929-05 AS-101932-02
16 Mounting Bracket - Control Board AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01
17 Transformer See Electrical Group
18 Control Board See Electrical Group
19 Blower Housing w/Wheel 70-101729-02 70-101729-02 70-101729-02 70-101729-02 70-101729-08 70-101729-08
20 Motor Mount - Band 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04
21 Motor Mount - Arm (4) 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10
22 Stk Blower Motor (PSC) 51-102175-04 51-102182-01 51-101728-04 51-101728-04 51-102175-05 51-102182-02
23 Mounting Bracket Cover AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Stk BlowerWheel 703012 703012 703012 703012 703014 703014
Stk Capacitor - Blower Motor 43-101666-55 43-101666-55 43-101666-58 43-101666-55 43-101666-56 43-101666-56
Capacitor Strap AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Stk BlowerWheel 703014 703014 703014 703014 703023 703023
Stk Capacitor - Blower Motor 43-101666-43 43-101666-43 43-101666-43 43-101666-43 43-101666-57 43-101666-57
Capacitor Strap AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12
RH1P
18
17
ST
AN
AA
RH1P
36
17
ST
AN
AA
RH1P
18
17
ST
AN
JA
BLOWER GROUP
RH1P
36
17
ST
AN
DA
BLOWER GROUP
RH1P
24
17
ST
AN
AA
RH1P
36
17
ST
AN
JA
RH1P
24
17
ST
AN
JA
RH1P
36
21
ST
AN
JA
RH1P
30
17
ST
AN
AA
RH1P
42
21
ST
AN
AA
RH1P
30
17
ST
AN
JA
RH1P
42
21
ST
AN
DA
Page 8 of 13
09-May-2014
92-42800-RH1P
MODEL
CAPACITY
No.Notes
15 Stk Blower Assembly (Includes items 16-22) AS-101931-05 AS-101929-06 AS-101932-03 AS-101931-06 AS-101932-03 AS-101931-06
16 Mounting Bracket - Control Board AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01 AE-101049-01
17 Transformer See Electrical Group
18 Control Board See Electrical Group
19 Blower Housing w/Wheel 70-101729-08 70-101729-08 70-101729-08 70-101729-08 70-101729-08 70-101729-08
20 Motor Mount - Band 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04 70-19927-04
21 Motor Mount - Arm (4) 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10 70-19929-10
22 Stk Blower Motor (PSC) 51-101728-05 51-102175-06 51-102182-03 51-101728-06 51-102182-03 51-101728-06
23 Mounting Bracket Cover AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01 AE-101797-01
No.Notes
15 Stk Blower Assembly (Includes items 16-22) AS-101932-04 AS-101931-07
16 Mounting Bracket - Control Board AE-101049-01 AE-101049-01
17 Transformer See Electrical Group
18 Control Board See Electrical Group
19 Blower Housing w/Wheel 70-101729-04 70-101729-04
20 Motor Mount - Band 70-19927-04 70-19927-04
21 Motor Mount - Arm (4) 70-19929-10 70-19929-10
22 Stk Blower Motor (PSC) 51-102182-04 51-101728-07
23 Mounting Bracket Cover AE-101797-01 AE-101797-01
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Stk BlowerWheel 703023 703023 703023 703023 703023 703023
Stk Capacitor - Blower Motor 43-101666-57 43-101666-57 43-101666-57 43-101666-57 43-101666-57 43-101666-57
Capacitor Strap AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12 AE-50892-12
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
MAJOR SERIES/CONTROLS
VOLTAGE/MINORSERIES
Stk BlowerWheel 703015 703015
Stk Capacitor - Blower Motor 43-101666-57 43-101666-57
Capacitor Strap AE-50892-12 AE-50892-12
RH1P
42
21
ST
AN
JA
RH1P
60
24
ST
AN
DA
RH1P
48
21
ST
AN
AA
BLOWER GROUP
RH1P
60
24
ST
AN
JA
BLOWER GROUP
RH1P
48
21
ST
AN
DA
RH1P
48
21
ST
AN
JA
RH1P
48
24
ST
AN
DA
RH1P
48
24
ST
AN
JA
Page 9 of 13
09-May-2014
92-42800-RH1P
MODEL
No.Notes
12 Replacement Coil w/TXV RCH-2417STAMUA RCH-3617STAMUA RCH-3621STAMUA RCH-4821STAMUARCH-4824STAMUA RCH-6024STAMUA
DrainPan - Vertical See specified RCH Coil Parts List
TXV See specified RCH Coil Parts List
No.Notes
Heater Kit - 3kW/208-240/1
Heater Kit - 5kW/208-240/1
Heater Kit - 7kW/208-240/1
Heater Kit - 10kW/208-240/1
Heater Kit - 13kW/208-240/1 RXBH-1724A13J RXBH-1724A13J N/A N/A N/A N/A
Heater Kit - 15kW/208-240/1 N/A RXBH-1724A15J RXBH-1724A15J RXBH-1724A15J RXBH-1724A15J RXBH-1724A15J
Heater Kit - 18kW/208-240/1 N/A RXBH-1724A18J RXBH-1724A18J RXBH-1724A18J RXBH-1724A18J RXBH-1724A18J
Heater Kit - 20kW/208-240/1 N/A N/A N/A RXBH-24A20J RXBH-24A20J RXBH-24A20J
Heater Kit - 25kW/208-240/1 N/A N/A N/A RXBH-24A25J RXBH-24A25J RXBH-24A25J
Heater Kit - 30kW/208-240/1 N/A N/A N/A N/A N/A RXBH-24A30J
Heater Kit - 7kW/208-240/3 RXBH-1724A07C RXBH-1724A07C RXBH-1724A07C RXBH-1724A07C RXBH-1724A07C RXBH-1724A07C
Heater Kit - 10kW/208-240/3 RXBH-1724A10C RXBH-1724A10C RXBH-1724A10C RXBH-1724A10C RXBH-1724A10C RXBH-1724A10C
Heater Kit - 13kW/208-240/3 RXBH-1724A13C RXBH-1724A13C N/A N/A N/A N/A
Heater Kit - 15kW/208-240/3 N/A RXBH-1724A15C RXBH-1724A15C RXBH-1724A15C RXBH-1724A15C RXBH-1724A15C
Heater Kit - 18kW/208-240/3 N/A RXBH-1724A18C RXBH-1724A18C RXBH-1724A18C RXBH-1724A18C RXBH-1724A18C
Heater Kit - 20kW/208-240/3 N/A N/A N/A RXBH-24A20C RXBH-24A20C RXBH-24A20C
Heater Kit - 25kW/208-240/3 N/A N/A N/A RXBH-24A25C RXBH-24A25C RXBH-24A25C
Heater Kit - 30kW/208-240/3 N/A N/A N/A N/A N/A RXBH-24A30C
Heater Kit - 7kW/480/3 N/A RXBH-1724A07D RXBH-1724A07D N/A RXBH-1724A07D RXBH-1724A07D
Heater Kit - 10kW/480/3 N/A RXBH-1724A10D RXBH-1724A10D RXBH-1724A10D RXBH-1724A10D RXBH-1724A10D
Heater Kit - 15kW/480/3 N/A RXBH-1724A15D RXBH-1724A15D RXBH-1724A15D RXBH-1724A15D RXBH-1724A15D
Heater Kit - 18kW/480/3 N/A RXBH-1724A18D RXBH-1724A18D RXBH-1724A18D RXBH-1724A18D RXBH-1724A18D
Heater Kit - 20kW/480/3 N/A N/A N/A RXBH-24A20D RXBH-24A20D RXBH-24A20D
Heater Kit - 25kW/480/3 N/A N/A N/A RXBH-24A25D RXBH-24A25D RXBH-24A25D
Heater Kit - 30kW/480/3 N/A N/A N/A N/A N/A RXBH-24A30D
CAPACITY
CABINET SIZE
COIL SIZE/METERING
Horizontal Adapter Kit See specified RCH Coil Parts List
MODEL
CAPACITY
CABINET SIZE
COIL SIZE/METERING
RH1P
18/24
17
ST
RH1P
18/24
17
ST
RXBH-1724A03J
RXBH-1724B03J
RXBH-1724C03J
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RH1P
30/36
17
ST
COIL GROUP
RH1P
30/36
17
ST
HEATER KITS
RXBH-1724A03J
RXBH-1724B03J
RXBH-1724C03J
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RH1P
36
21
ST
RH1P
36
21
ST
N/A N/A N/A N/A
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RH1P
42/48
21
ST
RH1P
42/48
21
ST
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RH1P
48
24
ST
RH1P
48
24
ST
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RH1P
60
24
ST
RH1P
60
24
ST
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
Page 10 of 13
09-May-2014
92-42800-RH1P
Exploded View
Page 11 of 13
09-May-2014
92-42800-RH1P
Blower Assembly
Page 12 of 13
09-May-2014
92-42800-RH1P
NOTES
Stk It is recommended that stock be maintained for this part.
N/A Not Applicable
DISCLAIMER: This document is intended to provide general replacement parts information to aid qualified
service personnel in the repair of these models. The complete Model and Serial Number of the unit under repair
should be specified when selecting and ordering replacement parts. Specifications and illustrations are subject
to change without notice. Document 92-42800-RH1P supersedes all previous parts lists for these models. See
http://www.rheempartslists.net/92-42800-RH1P for the latest revision of this document. The manufacturer
assumes no obligation for errors or omissions. Service personnel must verify the proper and safe operation of
equipment after the replacement of any original components.
P.O. Box 17010
Fort Smith, AR 72917-7010
Loading...
