RCCL
Parts List
23-August-2017
This parts list is current as of the above revision date.
See http://www.rheempartslists.net/92-42800-RCCL.pdf for the current revision.
Coils - Commercial
Page 2
Table of Contents
Model Explanation..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . . Page 3
Parts Numbers
Replacement Parts ..... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . ... Page 4
Drawings/Photographs
Coil Assembly .... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . .... Page 5
Notes/Disclaimer .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .... . . .. Page 6
Page 2 of 6
23-August-2017
92-42800-RCCL
Page 3
R C C L - D 50 13 S
1 2 3 4 5 6 7 8
1 TRADE BRAND IDENTIFICATION 7 COOLING CAPACITY
R = Rheem/Ruud 13 = 120,000 BTU/HR (Grooved Tube)
2 COILS 8 SWEAT
3 TYPE
C = Cased Coil - Standard
4 L = Upflow, R-410A
5 D = Manufactured by Rheem (Serial Numbers FXXXXxxxx)
D = Sourced (Serial Numbers AXXXXxxxx)
6 PLENUM WIDTH
50 = 50-1/2 in.
F 0 8 1 7 9 9 9 9
(1) (2) (3) (4)
(1) PLANT CODE
F = Fort Smith, AR
A = Sourced
(2) WEEK OF PRODUCTION
(3) YEAR OF PRODUCTION
(4) PRODUCTION NUMBER
SERIAL NUMBER EXPLANATION (Units Produced with serial number FXXXXxxxx)
MODEL NUMBER EXPLANATION
Page 3 of 6
23-August-2017
92-42800-RCCL
Page 4
MODEL
No. Notes
Stk Drain Pan 686047
Stk Expansion Valve 611039
Stk Strainer 83-41419-02
No. Notes
1 Stk Drain Pan Assembly (includes End Plates) AS-90953-01
2 Coil Assembly (includes Drain Pan Assy & TXV/Distributor Assembly) AS-90912-01
2a Air Baffle AE-90957-01
3 Stk TXV/Distributor Assembly 61-42662-27
3a Liquid Line 82-105329-01
4 Support Plate - Liquid Line AE-53516-02
5 Right Side Panel AS-84755-02
6 Left Side Panel AS-84754-02
7 Back Panel AS-84758-06
8 Front Access Panel AS-84765-06
9 Tubing Panel Assembly AS-90968-01
9a Grommet 56-22521-03
10 Case Top Cover Support AE-76720-01
11 Case Bottom Channel AE-76714-01
TYPE
PLENUMWIDTH
CAPACITY
DRAIN PANSECTION - Serial Number AXXXXxxxx
METERING SECTION - Serial Number AXXXXxxxx
MODEL
TYPE
PLENUMWIDTH
CAPACITY
COIL/DRAIN PANSECTION - Serial Number FXXXXxxxx
METERING SECTION - Serial Number FXXXXxxxx
PANELS - Serial Number FXXXXxxxx
RCCL
D
50
13
RCCL
D
50
13
Page 4 of 6
23-August-2017
92-42800-RCCL
Page 5
Coil Assembly
Page 5 of 6
23-August-2017
92-42800-RCCL
Page 6
NOTES
Stk It is recommended that stock be maintained for this part.
N/A Not Applicable
DISCLAIMER: This document is intended to provide general replacement parts information to aid qualified
service personnel in the repair of these models. The complete Model and Serial Number of the unit under repair
should be specified when selecting and ordering replacement parts. Specifications and illustrations are subject
to change without notice. Document 92-42800-RCCL supersedes all previous parts lists for these models. See
http://www.rheempartslists.net/92-42800-RCCL for the latest revision of this document. The manufacturer
assumes no obligation for errors or omissions. Service personnel must verify the proper and safe operation of
equipment after the replacement of any original components.
