STAINLESS STEEL
Giving you more in
“
Hot Water
”
AUSTRALIAN MADE STAINLESS STEEL GAS WATER HEATERS
STAR PERFORMERS FROM AQUAMAX
AquaMax gas water heaters offer you more than just 5 Star
energy efficiency.
With Stainless Steel cylinders across the range they are the
preferred choice for homeowners and plumbers alike.
Providing hot water recovery of up to 185 litres per hour,
there is an AquaMax model to suit even the largest household.
G390 SS G340 SS G270 SS
OUTSTANDING FEATURES
5 STAR ENERGY EFFICIENCY
to help you save on energy bills
STAINLESS STEEL CYLINDERS
can resist corrosion for longer than conventional
enamelled steel cylinders
3
®
10 YEAR CYLINDER WARRANTY
HOT WATER RECOVERY FROM
135 TO 185 LITRES AN HOUR
to have you back in hot water faster, and also
handy in times of heavy hot water demand
SIGNIFICANTLY LIGHTER
than traditional enamelled steel cylinder water
heaters, which assists in easier installation
NO ANODE REQUIRED
so reducing lifetime service costs
INBUILT MIXING VALVE
on AquaMax G390SS so you can adjust the hot
water delivery to as much as 205L in an hour
(depending on temperature chosen)*
*NOTE: the inbuilt mixing valve is not an approved temperature limiting device.
Applications requiring tempering to comply with AS3498 must have a
tempering valve installed in accordance with AS3500.4
1
2
Giving you more in
“
Hot Water
”
TOP OF FLUE OUTLET 850
PTR
VALVE
1410
TOP OF FLUE OUTLET 850
HOT WATER
OUTLET
COLD
305
345
565
240
10
1210
GAS
335
475
ANODE
FITTING
GAS
INLET
COLD
WATER
INLET
G270VE
COLD
WATER
INLET
WA
GAS
INLET
AQUAMAX GAS WATER HEATER SPECIFICATIONS
TOP OF FLUE VENT 840
TOP OF FLUE VENT 840
SPECIFICATIONS
Number of people Served
Cylinder Capacity
Nominal gas consumption
AGA Star Rating Index
Recovery rate at 45°C rise
Installation type
Pressure & Temperature Relief
Valve setting
Max. water supply pressure w/o ECV
Cylinder material
Water inlet connection
Water outlet connection
Gas connection
Warranty (Cylinder
WaterMark Licence No.
Overall height
Width (approx.)
Depth (approx.)
AGA Approval No.
Weight empty (approx.)
Model
Gas type
G390 SS
(WITH MIXING VALVE)
3-6
G390SS
Natural
155 Litres
40 MJ/Hr
5 Stars
185 Litres/Hr
External only
1400 kPa/99°C
1120 kPa
stainless steel
Rp 3/4” (20mm) Female
Rp 3/4” (20mm) Female
1/2" flared compression
)1
10 years
WMKA00200
1625mm
520mm
610mm
AGA6114G
65 kg
2
G340 SS
2-5
G340SS
Natural
155 Litres
40 MJ/Hr
5 Stars
185 Litres/Hr
External only
1400 kPa/99°C
1120 kPa
stainless steel
Rp 3/4” (20mm) Female
Rp 1/2” (15mm) Female
1/2" flared compression
10 years
WMKA00200
1635mm
520mm
610mm
AGA6114G
65 kg
2
G270 SS
2-4
G270SS
Natural
130 Litres
33 MJ/Hr
5 Stars
145 Litres/Hr
External only
1400 kPa/99ºC
1120 kPa
stainless steel
Rp 3/4” (20mm) Female
Rp 1/2” (15mm) Female
1/2" flared compression
10 years
WMKA00200
1410mm
475mm
565mm
AGA7477G
46 kg
2
COLD
INLET
TER
GAS
10
240
565
345
HOT WATER
OUTLET
PTR
475
VALVE
G270SS
1410
1210
GAS
INLET
305
335
COLD
A.B.N. 37 138 189 689
Part No.
AQ0905033-F
10
320
270
610
415
520
PTR VALVE
(outlet 2)
optional
G390SS
MIXED HOT
WATER
OUTLET
(outlet 1)
COLD
WATER
INLET
GAS
360
®
GAS
INLET
330
COLD
1 Warranty: 10 years parts on cylinder, 1 year parts and labour on cylinder and all other components, when installed in a domestic
2 Based on cold water temperature of 15ºC
3 Note: AquaMax Stainless Steel Water Heaters are not recommended for installation in some areas. Refer to the AquaMax website
Aquamax Australia Pty Ltd 463-467 Warrigal Road Moorabbin Vic 3189 Toll Free: 1800 676 000
Ph: (03) 9532 2200 Sales Fax: (03) 9532 5244 Service Fax: (03) 9556 5534
Email: sales@aquamax.com.au For more information visit www.aquamax.com.au
® Registered Trademark of AquaMAX Australia Pty Ltd.
© Copyright 2011 AquaMAX Australia Pty Ltd. Neither whole nor part of this publication may be reproduced without permission
1625
dwelling. For all other installations, warranty period is one year parts and labour on all components. Conditions apply, see the
AquaMax warranty set out in the Owner’s Guide and Installation Instructions or view at www.aquamax.com.au
for details of areas not recommended and for which product is not covered by warranty.
HOT WATER
OUTLET
COLD
WATER
INLET
GAS
10
320
270
610
415
520
PTR VALVE
G340SS
GAS
INLET
330
360
COLD
1635
