Lightweight & Durable – With All the Right Connections.

RHEEM AIR HANDLERS & COILS

We Thought of Everything... And Then Some.

The new Rheem aluminum coil used in our air handlers, cased coils and replacement coils is not only more durable
than a traditional copper coil, it’s also lighter and easier to handle. And you’re going to love the copper refrigerant
connections we’ve included, making installation so easy, you’ll be able to finish the job in no time.

360˚ Performance

The new Rheem aluminum coil is built to perform like
a champion. Its all-aluminum construction makes it
extra durable, allowing the coil to run better and last
longer. Even the endplates are aluminum, so the unit
looks as good as it runs. Every coil is factory-tested,
checked for leaks and held to the highest industry
standards. If it doesn’t pass the test, it doesn’t go in
the box. We’re also proud that the coil’s robust design
far exceeds normal operating pressures. Precise
heat-control of the automated brazing oven during the
brazing process means you get a quality braze joint
every time. So, you can guarantee your customers
one of the most durable, long-lasting products on the
market today.

360˚ Integration

™

EcoNet

EcoNet is an exclusive technology that allows Rheem heating, cooling and water
heating products to communicate with each other on one integrated network. In
addition to giving homeowners an easy way to control the most energy-consuming systems in the home – from home or
on-the-go – it also makes it faster and easier for you to accurately install, set up and maintain a complete home comfort system.

™

™

360˚ Installability

We thought long and hard about features that would
make our new aluminum coil easier to install – like
our factory-provided copper refrigerant connections.
These transitions allow you to braze copper to copper
in the field to create a familiar field braze joint, making
installation faster and easier. Our new multi-poise
coils are also lighter and can handle any installation
orientation. And the condensate drain connections are
angled at 45 degrees, providing maximum clearance –
so the entire system installs like a breeze.

™

360˚ Serviceability

Servicing a new Rheem aluminum coil takes less
time due to several deliberate changes. For starters,
we’ve redesigned the mechanical TXV fittings, so
if the expansion valve needs replacing, you won’t
need to un-sweat the connections. We’ve also given
you easier access to the internal components of the
coil, and you won’t need any special jobsite tools. A
standard nut driver or drill attachment will do the trick,
getting you in and out faster, and saving you time and
your customers money.

™

What is 360°+1?

For nearly a century, Rheem has been the industry leader, pioneering numerous industry firsts
that meet the needs of homeowners and dealers. We consider the work that goes into installing
and servicing our products as well as how we can deliver the best homeowner experience… and
then we take it further. That’s 360°+1.

We engineered performance, innovation and everyday improvements into even the smallest
details, resulting in four key product feature categories:

360˚ Performance

™

360˚ Installability

™

360˚ Serviceability

™

360˚ Integration

We took it a step further and delivered “PlusOne™” advantages – unique Rheem innovations
designed to make your job easier while providing homeowners with the ultimate home
comfort experience.

™

FULL OFFERING OF RHEEM AIR HANDLERS AND COILS

Model Description

Features

Aluminum Coil

Features

Copper Coil

Features

Comfort
Control2

System

EcoNet

-enabled

™

Features

Thermostatic

Expansion

Valve (TXV)

Air Handlers

RH1P PSC Single-Stage Airflow X X

RH1T

RH1V

RH2T

RH2V

RH2T

RH2V

RHMV

RHSL

1

1

2

2

2

1

Constant Torque

Single-Stage Airflow

Constant CFM

Single-Stage Airflow

Constant Torque

Two-Stage Airflow

Constant CFM

Two-Stage Airflow

Constant Torque

Two-Stage Airflow

Constant CFM

Two-Stage Airflow

Constant CFM

Modulating Airflow

PSC Single-Stage Airflow X X

RHLL1Constant Torque Single-Stage Airflow X X

RHKL1Constant CFM Single-Stage Airflow X X

NEW!

NEW!

NEW!

NEW!

NEW!

NEW!

NEW!

NEW!

X X

X X

X X X

X X X

X X X

X X X

X X X

Features

Electronic

Expansion

Valve (EEV)

RHPN1Constant CFM Two-Stage Airflow X X X

RHPL1Constant CFM Two-Stage Airflow X X X

RHML1Constant Torque Two-Stage Airflow X X

RBHP

RHAL

RHBL

Constant Torque Single-Stage Airflow

(34" Cabinet Height)

3

3

Front Return PSC

Single-Stage Airflow

Front Return Constant Torque

Single-Stage Airflow

X X

X X

X X

Coils

RCF

2

RCF

RCH

1

RCFN

1

Existing models to be phased out in 2015

Cased/Uncased

Furnace N-Coil

Cased/Uncased

Furnace N-Coil

Uncased Replacement

Air Handler N-Coil

Cased N-Coil X X

NEW!

NEW!

X X

X X

X X

2

Noted air handlers and coil are to be matched with inverter-driven

and two-stage outdoor models: RA17, RA20, RP17, RP20

3

Existing models RHAL/RHBL will be replaced with an all-aluminum air handler in 2015

360˚ Performance

™

• All-aluminum construction – reduces weight and provides

extra durability

• Corrosion-resistant aluminum endplates – the unit looks as good

as it runs

• 100% factory-tested – for optimal performance

• Airflow pressure drop performance is equal to previous models –

ensures preserved performance ratings

• Lanced fin design – increases system efficiency and performance

360˚ Installability

• Copper refrigerant connections – allow dealers to braze copper to

copper in the field to create a familiar field braze joint

• Multi-poise coil – enables handling of any installation orientation

• Two sets of ¾" condensate drain connectors – connections exit the

coil at 45-degree angle for maximum clearance on installations

360˚ Serviceability

• Mechanical TXV fittings – make expansion valve replacement easy • Easy service access – no need for special jobsite tools

™

™

• N-coil design – maintains one of the shortest coil heights in the

industry; great solution for space-constrained areas

• High-grade condensate drain pan – for durable product

performance in high-temperature applications

• Precision braze joints – superior heat control results in quality

braze joints

• Matched with 1.5-ton to 5-ton systems – offers full product line

of installation options

• Bi-directional airflow compatible – eliminates the need to switch

internal components from horizontal left to right application

• Universal duct flanges – allow the new coil to be installed in a variety

of plenum applications

• Foil-faced insulation – inhibits mold growth and insulates the coil for

improved indoor air quality

Why Rheem?

Relationship, Dedication and Innovation

Rheem makes customers our first priority. Our approach as a company is to keep the dialogue

ongoing and to listen. Then act. The innovations we’ve developed throughout the years in both the

HVAC and water heating industries are a direct result of that process. And we have a long list of

industry firsts to show for it, with more to come. Rheem is dedicated to providing the products your

customers need and the opportunities you want to expand your offerings and increase profitability.

That’s the Rheem 360°+1 approach to partnership.

Learn more at MyRheem.com/360.
