Rheem 15PJL User Manual

15PJL

Parts List

02-October-2017

This parts list is current as of the above revision date.

See http://www.rheempartslists.net/92-42805-15PJL.pdf for the current revision.

Heat Pumps

Table of Contents

Model Explanation. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. Page 3

Parts Numbers

Panels - Miscellaneous (Granite-Steel Gray) ..................................................................... Page 4

Panels - Miscellaneous (Neutra Green) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. Page 5

Electrical-Fan Group.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . Page 6

Coil Parts . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. Page 7

Compressor Group . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . Page 8

Accessories ..................................................................................................... Page 9

Drawings/Photographs

Exploded View .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . Page 10

Control Box Assembly .......................................................................................... Page 11

Valve Mounting Detail........................................................................................... Page 12

Notes/Disclaimer ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. Page 13

Page 2 of 13

02-October-2017

92-42805-15PJL

1 5 P J L 1 8 A 0 1
1 2 3 4 5 6 7

(1) SEER (5) COOLING CAPACITY (BTU/HR)
15 = SEER Rating 018= 18,000
024= 24,000
(2) MODEL 030= 30,000
P = Heat Pump 036= 36,000
042= 42,000
(3) VOLTAGE 048= 48,000
J = 208-230/1/60 060= 60,000

(4) DESIGN SERIES (6) CABINET
(7) NAMEPLATE

7 9 7 8 W 0 2 1 0 9 9 9 9 9

(1) COMPRESSOR IDENTIFICATION NUMBER
(2) PRODUCTION LOCATION
(3) WEEK OF PRODUCTION
(4) YEAR OF PRODUCTION
(5) PRODUCTION NUMBER

1 2 3 4 5

MODEL NUMBER EXPLANATION

SERIAL NUMBER EXPLANATION

Page 3 of 13

02-October-2017

92-42805-15PJL

No. Notes

1 Cabinet AE-100726-82 AE-100726-82 AE-100726-83 AE-100726-84
2 CabinetPanel AE-100727-82 AE-100727-82 AE-100727-83 AE-100727-84
3 BasePan AS-100058-02 AS-100058-02 AE-101588-03 AE-101588-03
4 ControlBox-2 inch diameter capacitor AE-100654-81 AE-100654-81 N/A AE-100654-83
4 ControlBox-2-1/2 inch diameter capacitor N/A N/A AE-100654-82 N/A
5 ControlBoxCover AE-100657-81 AE-100657-81 AE-100657-81 AE-100657-81
6 Top Panel AE-100652-82 AE-100652-82 AE-100652-83 AE-100652-83
8 Grille 95-100906-03 95-100906-03 95-100906-04 95-100906-04

Center Cap - Blank (for Grille) 91-101123-09 91-101123-09 91-101123-09 91-101123-09
12 Valve Mounting Panel AE-57780-01 AE-57780-01 AE-57780-01 AE-100185-81
14 Service Valve - Suction See Coil Group
15 Service Valve - Liquid See Coil Group
17 Low Voltage Cover AE-57756-01 AE-57756-01 AE-57756-01 AE-57756-01

Touch-up Paint - Granite/Steel Gray (Aerosol) PD523018 PD523018 PD523018 PD523018

Touch-up Paint - Granite/Steel Gray (Paint Pens) PD523019 PD523019 PD523019 PD523019

No. Notes

1 Cabinet AE-100726-84 AE-100726-84 AE-100726-84
2 Cabinet Panel AE-100727-84 AE-100727-84 AE-100727-84
3 Base Pan AE-101588-03 AE-101588-03 AE-101588-03
4 Control Box -2inch diameter capacitor AE-100654-83 N/A N/A
4 Control Box -2-1/2inch diameter capacitor N/A AE-100654-84 AE-100654-84
5 Control Box Cover AE-100657-81 AE-100657-81 AE-100657-81
6 Top Panel AE-100652-83 AE-100652-83 AE-100652-83
8 Grille 95-100906-04 95-100906-04 95-100906-04

Center Cap - Blank (for Grille) 91-101123-09 91-101123-09 91-101123-09
12 Valve Mounting Panel AE-100185-81 AE-100185-81 AE-100185-81
14 Service Valve - Suction See Coil Group
15 Service Valve - Liquid See Coil Group
17 Low Voltage Cover AE-57756-01 AE-57756-01 AE-57756-01

Touch-up Paint - Granite/Steel Gray (Aerosol) PD523018 PD523018 PD523018

Touch-up Paint - Granite/Steel Gray (Paint Pens) PD523019 PD523019 PD523019

MODEL
COOLING CAPACITY
VARIATION

SHEET METAL PARTS, MISCELLANEOUS (Granite/Steel Gray, After Date Code 4811)

MODEL
COOLING CAPACITY
VARIATION

SHEET METAL PARTS, MISCELLANEOUS (Granite/Steel Gray, After Date Code 4811)

15PJL

18

A01

15PJL

42

A01

15PJL

24

A01

15PJL

48

A01

15PJL

30

A01

15PJL

60

A01

15PJL

36

A01

Page 4 of 13

02-October-2017

92-42805-15PJL

No. Notes

1 Cabinet AE-100726-52 AE-100726-52 AE-100726-53 AE-100726-54
2 Cabinet Panel AE-100727-52 AE-100727-52 AE-100727-53 AE-100727-54
3 Base Pan AS-100058-02 AS-100058-02 AE-101588-03 AE-101588-03
4 Control Box -2inch diameter capacitor AE-100654-51 AE-100654-51 AE-100654-51 AE-100654-53
4 Control Box -2-1/2inch diameter capacitor N/A N/A AE-100654-52 N/A
5 Control Box Cover AE-100657-51 AE-100657-51 AE-100657-51 AE-100657-51
6 Top Panel AE-100652-52 AE-100652-52 AE-100652-53 AE-100652-53
8 Grille 95-100906-03 95-100906-03 95-100906-04 95-100906-04

Center Cap - Blank (for Grille) 91-101123-09 91-101123-09 91-101123-09 91-101123-09
12 Valve Mounting Panel AE-57780-01 AE-57780-01 AE-57780-01 AE-100185-51
14 Service Valve - Suction See Coil Group
15 Service Valve - Liquid See Coil Group
17 Low Voltage Cover AE-57756-01 AE-57756-01 AE-57756-01 AE-57756-01

Touch-up Paint - Green (Aerosol) 52-18662-48 52-18662-48 52-18662-48 52-18662-48

Touch-up Paint - Green (Paint Pens) 523010 523010 523010 523010

No. Notes

1 Cabinet AE-100726-54 AE-100726-54 AE-100726-54
2 Cabinet Panel AE-100727-54 AE-100727-54 AE-100727-54
3 Base Pan AE-101588-03 AE-101588-03 AE-101588-03
4 Control Box -2inch diameter capacitor AE-100654-53 AE-100654-53 N/A
4 Control Box -2-1/2inch diameter capacitor N/A AE-100654-54 AE-100654-54
5 Control Box Cover AE-100657-51 AE-100657-51 AE-100657-51
6 Top Panel AE-100652-53 AE-100652-53 AE-100652-53
8 Grille 95-100906-04 95-100906-04 95-100906-04

Center Cap - Blank (for Grille) 91-101123-09 91-101123-09 91-101123-09
12 Valve Mounting Panel AE-100185-51 AE-100185-51 AE-100185-51
14 Service Valve - Suction See Coil Group
15 Service Valve - Liquid See Coil Group
17 Low Voltage Cover AE-57756-01 AE-57756-01 AE-57756-01

Touch-up Paint - Green (Aerosol) 52-18662-48 52-18662-48 52-18662-48

Touch-up Paint - Green (Paint Pens) 523010 523010 523010

MODEL
COOLING CAPACITY
VARIATION

SHEET METAL PARTS, MISCELLANEOUS (Neutra Green, Before Date Code 4811)

MODEL
COOLING CAPACITY
VARIATION

SHEET METAL PARTS, MISCELLANEOUS (Neutra Green, Before Date Code 4811)

15PJL

18

A01

15PJL

42

A01

15PJL

24

A01

15PJL

48

A01

15PJL

30

A01

15PJL

60

A01

15PJL

36

A01

Page 5 of 13

02-October-2017

92-42805-15PJL

No. Notes

7 Stk Fan Motor 51-101774-02 51-101774-02 51-102008-07 51-102870-01

9 Stk Fan Blade 70-102033-02 70-102033-02 70-102011-10 70-21858-17
16 Stk Contactor 42-42478-03 42-42478-03 42-42478-03 42-42478-03
17 Low Voltage Cover See Panels - Miscellaneous
18 Control Box Bottom AE-100655-01 AE-100655-01 AE-100655-01 AE-100655-01
19 Capacitor -Compressor/Fan See Compressor Group
20 Stk DefrostControlBoard 47-102684-02 47-102684-02 47-102684-02 47-102684-02
21 Low Ambient Control See Accessories Group

Low Pressure Control 47-103670-05 47-103670-05 47-103670-05 47-103670-05

No. Notes

7 Stk Fan Motor-BeforeDateCode 1112 51-102870-03 51-102008-07 51-102728-11

7 Stk Fan Motor-After Date Code 1112 51-101774-13 51-102008-07 51-102728-11

9 Stk Fan Blade 70-21858-17 70-102011-10 70-21858-17
16 Stk Contactor 42-42478-03 42-42478-03 42-42478-02
17 Low Voltage Cover See Panels - Miscellaneous
18 Control Box Bottom AE-100655-01 AE-100655-01 AE-100655-01
19 Capacitor -Compressor/Fan See Compressor Group
20 Stk DefrostControlBoard - Before Date Code 1112 47-102684-02 47-102685-04 47-102685-04
20 Stk DefrostControlBoard - After Date Code 1112 47-102684-08 47-102685-04 47-102685-04
21 Low Ambient Control See Accessories Group

Low Pressure Control 47-103670-05 47-103670-05 47-103670-05

MODEL
COOLING CAPACITY
VARIATION

ELECTRICAL/FANGROUP

MODEL
COOLING CAPACITY
VARIATION

ELECTRICAL/FANGROUP

15PJL

18

A01

15PJL

42

A01

15PJL

24

A01

15PJL

48

A01

15PJL

30

A01

15PJL

60

A01

15PJL

36

A01

Page 6 of 13

02-October-2017

92-42805-15PJL

No. Notes

11 Stk CondenserCoil AS-103032-03 AS-103032-03 AS-101768-03 AS-103014-03
13 Valve Mounting Bracket AE-57781-01 AE-57781-01 AE-57781-01 AE-57781-01
14 Service Valve - Suction 61-21368-23 61-21368-23 61-21368-07 61-21368-07
15 Service Valve - Liquid 61-21368-05 61-21368-05 61-21368-05 61-21368-05
22 Bulkhead Valve 61-22369-04 61-22369-04 61-22369-04 61-22369-04

Locknut - Bulkhead Valve 63-22368-01 63-22368-01 63-22368-01 63-22368-01
Low Pressure Control 47-102240-04 47-102240-04 47-102240-04 47-102240-04
Access Valve Body 61-18542-01 61-18542-01 61-18542-01 61-18542-01
Valve Core 61-18551-01 61-18551-01 61-18551-01 61-18551-01
Valve Cap 83-100635-01 83-100635-01 83-100635-01 83-100635-01
Stk Filter Drier 83-41719-04 83-41719-04 83-41719-04 83-41719-04
Charge Compensator N/A N/A N/A 83-25361-01
Stk TXV/Distributor Assembly 61-102437-19 61-102437-20 61-102437-21 61-102437-21
Stk,1 ReversingValve - See Note 1 61-102498-04 61-102498-04 61-102498-09 61-102498-09
Stk Solenoid Coil - Reversing Valve 61-101713-92 61-101713-92 61-101713-92 61-101713-92
Wiring Harness - Reversing Valve 61-26149-03 61-26149-03 61-26149-03 61-26149-03
Tube Assembly - Bulkhead Valve AS-105377-08 AS-105377-08 N/A AS-105377-05

No. Notes

11 Stk Condenser Coil AS-101760-03 AS-102099-03 AS-101771-01
13 Valve Mounting Bracket AE-57781-02 AE-57781-02 AE-57781-02
14 Service Valve - Suction 61-21368-22 61-21368-08 61-21368-08
15 Service Valve - Liquid 61-21368-05 61-21368-05 61-21368-05
22 Bulkhead Valve 61-22369-04 61-22369-04 61-22369-04

Locknut - Bulkhead Valve 63-22368-01 63-22368-01 63-22368-01
Stk Low Pressure Control 47-102240-04 47-102240-04 47-102240-04

Stk

Stk
Access Valve Body 61-18542-01 61-18542-01 61-18542-01

Valve Core 61-18551-01 61-18551-01 61-18551-01
Valve Cap 83-100635-01 83-100635-01 83-100635-01
Stk Filter Drier 83-41719-04 83-41719-04 83-41719-04
Charge Compensator N/A 83-25361-05 N/A
Stk TXV/Distributor Assembly 61-102437-22 61-102437-23 61-102437-24
Stk,1 ReversingValve - See Note 1 61-102498-09 61-101684-06 61-102498-03
Stk Solenoid Coil - Reversing Valve 61-101713-92 61-101713-92 61-101713-92
Wiring Harness - Reversing Valve 61-26149-03 61-26149-03 61-26149-03
Tube Assembly - Bulkhead Valve AS-105377-06 AS-105377-07 AS-105377-07

MODEL
COOLING CAPACITY
VARIATION

COIL GROUP

MODEL
COOLING CAPACITY
VARIATION

COIL GROUP

High Pressure Control (90 Deg Elbow with 5/16 inch connection) ­beforeW0311
High Pressure Control (90 Deg Elbow with 1/4 inch connection) - after
W0311

15PJL

18

A01

15PJL

42

A01

N/A N/A 47-26184-02

N/A N/A 47-103669-01

15PJL

24

A01

15PJL

48

A01

15PJL

30

A01

15PJL

60

A01

15PJL

36

A01

Page 7 of 13

02-October-2017

92-42805-15PJL

No. Notes

Compressor ID: 8195 8196 8197 8198
10 Stk Compressor 55-102045-14S 55-102045-24S 55-102045-31S 55-102045-03S
19 Stk Capacitor - Compressor/Fan (2 inch diameter) 43-26261-40 43-101665-09 43-26271-46 43-101666-37
19 Stk Capacitor - Compressor/Fan (2-1/2 inch diameter) N/A N/A 43-101665-46 N/A

Stk Compressor Wiring Harness (Molded Plug) 45-100834-80 45-100834-80 45-100834-80 45-100834-80

Crankcase Heater N/A N/A N/A N/A

Muffler 83-26251-01 83-26251-01 83-26251-01 83-26251-01

Charge Compensator See Coil Group

No. Notes

Compressor ID: 8199 8200 8201
10 Stk Compressor 55-102045-15S 55-102045-06S 55-102045-58S

19 Stk

Capacitor - Compressor (2 inch diameter, for ECM Fan Motor Units) 43-101666-37 N/A N/A
19 Stk

19 Stk

Stk Compressor Wiring Harness (Molded Plug) 45-100834-80 45-100834-80 45-100834-80

Crankcase Heater N/A 44-103663-01 44-103663-01

Muffler 83-26251-01 83-26251-01 83-26251-01

Charge Compensator See Coil Group

MODEL
COOLING CAPACITY
VARIATION

COMPRESSOR GROUP

MODEL
COOLING CAPACITY
VARIATION

COMPRESSOR GROUP

Capacitor - Compressor/Fan (2 inch diameter, for PSC FanMotor
Units)

Capacitor - Compressor/Fan (2-1/2 inch diameter, for PSC FanMotor
Units)
Capacitor - Compressor (2-1/2 inch diameter, for ECM Fan Motor
Units)

15PJL

18

A01

15PJL

42

A01

43-101665-52 43-26271-48 N/A

N/A 43-101665-48 N/A

N/A N/A 43-100510-29

15PJL

24

A01

15PJL

48

A01

15PJL

30

A01

15PJL

60

A01

15PJL

36

A01

Page 8 of 13

02-October-2017

92-42805-15PJL

No. Notes

Low Ambient Control RXAD-A08

Outdoor Thermostat (One Thermostat w/box) RXPT-A01
Outdoor Thermostat (One Thermostat w/o box) RXPT-A02
Outdoor Thermostat (One w/Heat Relay and box) RXPT-A03
Outdoor Thermostat (Two Thermostats w/Heat and box) RXPT-A04
Heat Pump Monitor RXPM-B01
Compressor Time Delay Control RXMD-B01
BlowerTime DelayControl RXMD-C04
High Pressure Control RXAB-A07

MODEL
COOLING CAPACITY
VARIATION

ACCESSORIES

15PJL

ALL
ALL

Page 9 of 13

02-October-2017

92-42805-15PJL

Exploded View

Page 10 of 13

02-October-2017

92-42805-15PJL

Control Box Assembly

Page 11 of 13

02-October-2017

92-42805-15PJL

Valve Mounting Detail

Page 12 of 13

02-October-2017

92-42805-15PJL

NOTES

Stk It is recommended that stock be maintained for this part.

N/A Not Applicable

1 The reversing valve specified for 030, 036, 042 models may be different than the one originally supplied with the

equipment. The use of the specified valve is recommended for improved shifting performance.

DISCLAIMER: This document is intended to provide general replacement parts information to aid qualified
service personnel in the repair of these models. The complete Model and Serial Number of the unit under repair
should be specified when selecting and ordering replacement parts. Specifications and illustrations are subject
to change without notice. Document 92-42805-15PJL supersedes all previous parts lists for these models. See
http://www.rheempartslists.net/92-42805-15PJL for the latest revision of this document. The manufacturer
assumes no obligation for errors or omissions. Service personnel must verify the proper and safe operation of
equipment after the replacement of any original components.

P.O. Box 17010

Fort Smith, AR 72917-7010
