R for Rabbit Lullabies Instructions For Assembly And Use

1

R for Rabbit Lullabies – The Singing Baby

Cradle.

Revised Manual

INSTRUCTIONS FOR ASSEMBLY AND USE

For the safety of your child please read these instructions and keep for future

reference.

2

Box Contents

A. Bassinet

B. Canopy and Net

C. Left Support Arch

D. Right Support Arch

E. Front Support Leg

F. Rear Support Leg

G. Adapter (if supplied)

3

1. As picture, insert the left tube of front support leg (E) into the right one, until a
“click”. Follow same method for rear support leg (F).

2. Open Left and Right Support Arch (C、D) as below picture shown until a “click”.

3. Combine the Arch Support groups (mentioned in step2) and support legs
mentioned in step1 as below picture, until a “click” sound.. ASSEMBLY AND USE

4

4. Unfold the bassinet (A) as below picture.

5. Insert the hanging tubes of bassinet into the connecting holes on the driving part
groups, until a “click” sound.

6. Assemble canopy and net (B), as below picture. Secure it by snaps located on the
top of bassinet.

5

7. Press the lock button then the swing can stop swing. And release the lock button
can make swing normally.

6

Operation Board Instruction

A .Power on/off

B. Speed button. 5 Speeds, from slow to fast

(Press 5th speed and press again to stop)

C. Music button, 12 songs.

(Press to start from 1st song, press again to move to next. Press longer for 3-5
seconds to stop)

D. Speed light

F. Timer（15mins, 30mins, 60mins）

G. Nature song button

H. Timer light

K. Battery door (Need 4 SIZE AA battery）

7

FAILURE TO FOLLOW THESE WARNINGS AND THE ASSEMBLY INSTRUCTIONS
COULD RESULT TO SERIOUS INJURY OR DEATH
