1
REWIRE SECURITY
GPS 303 VEHICLE
TRACKING DEVICE
DETAILED USER GUIDE
VER 05.15
Thank you for purchasing Rewire Security GPS-303. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before using this
product. Please note that specification and information are subject to changes without prior
notice in this manual. Any change will be integrated in the latest release. The manufacturer
assumes no responsibility for any errors or omissions in this document.
2
Contents
1. SUMMARY ...................................................................................................... 4
2. APPLICATIONS ............................................................................................. 4
3. HARDWARE DESCRIPTION ...................................................................... 4
4. ACCESSORIES ............................................................................................... 5
5. SPECIFICATIONS ......................................................................................... 5
6. USAGE ............................................................................................................. 5
6.1. INSTALLATION ................................................................................................................. 5
6.2 SIM CARD INSTALLATION .............................................................................................. 6
6.3 TURNING THE GPS-303 “ON” ........................................................................................... 6
6.4 GSM/GPS LED INDICATOR ............................................................................................. 7
6.5 CHANGING YOUR TRACKER’S PASSWORD .......................................................................... 7
6.6 AUTHORIZATION ............................................................................................................... 8
6.7 SMS TEXT MESSAGE LOCATING ....................................................................................... 9
6.8 INTERVAL TRACKING ........................................................................................................ 9
6.9 SMART ANGLE UPDATING ................................................................................................ 11
6.10 GPS DRIFT SUPPRESSION .............................................................................................. 11
6.11 EXACT STREET ADDRESS BY SMS ................................................................................. 12
6.12 CELL-ID TRACKING (LBS) ........................................................................................... 12
6.13. VOICE SURVEILLANCE ................................................................................................. 13
6.14.DATA LOGGING ............................................................................................................. 13
6.15. DATA UPLOAD .............................................................................................................. 15
6.16. FORWARDING INCOMING SMS MESSAGES.................................................................... 15
6.17. SIM CARD BALANCE ENQUIRY ................................................................................... 16
6.18. ALARMS ...................................................................................................................... 16
6.18.1 Low battery alarm................................................................................................ 17
6.18.2 Power disconnection alarm.................................................................................. 17
6.18.3 Geo-fence (Virtual fence/barrier) alarm .............................................................. 17
6.18.4 Multi-area management ....................................................................................... 18
6.18.5 Movement alarm .................................................................................................. 19
6.18.6 Over speed alarm ................................................................................................. 20
6.18.7 ACC (Ignition/voltage) alarm.............................................................................. 21
6.18.8 Vibration alarm .................................................................................................... 21
6.19 THEFT ALARM ............................................................................................................... 22
6.20 DISARM ..................................................................................................................... 22
3
6.21 STATUS ENQUIRY .......................................................................................................... 23
6.22 HARDWARE RESET ........................................................................................................ 23
6.23 STANDBY MODES .......................................................................................................... 23
6.24 IMEI NUMBER REQUEST ............................................................................................... 25
6.25 TIME SETTING ............................................................................................................... 25
6.26 TCP / UDP SWITCH ...................................................................................................... 25
6.27 GPRS SETTING ....................................................................................................... 25
6.28 GPRS ECONOMY MODE ................................................................................................ 27
7． TROUBLESHOOTING ............................................................................ 28
4
1. Summary
1.1 GPS-303 can locate any remote vehicle by using Geographic Locating System and send
instant sms or Internet reports to the user by using GSM and GPRS network. It is an ideal
Information, Telematics and Security solution for your vehicle as it is able to send real-time
alerts as well as location reports.
1.2 Features
1.2.1 Dustproof and waterproof IP66 level.
1.2.2 Built-in GSM, GPS antenna.
1.2.3 GPS and LBS (Location based service) tracking solutions.
1.2.4 SMS/GPRS/Internet Network data transmission
1.2.5 Remote Configuration support
1.2.6 Built-in vibration sensor and microphone.
2. Applications
Vehicle tracking, Fleet management, Motorbike tracking, Vehicle security or tracking any
moving device that works on 12v or 24v
3. Hardware Description
GPS/POWER/GSM indicator
Microphone
5
4. Accessories
No.
Name
Specifications
Applicable
model
1 Harness
3PIN
Standard for
type B
5. Specifications
Content
Specification
DIM
8.9×5.0×1.6cm
Weight
65g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS
sensitivity
-159dBm
GPS
accurancy
5m
GPS start time
Cold status 45s
Warm status 35s
Hot status 1s
Supported
Voltage
12 V -24V
Back up
battery
Chargeable 3.7V 500mAh Li-ion battery
Storage Temp
-40°C to +85°C
Operation
Temp.
-20°C to +65°C
Humidity
5%--95% non-condensing
6. Usage
6.1. Installation
6.1.1 Please ensure that the installation is performed by a qualified and experienced
technician. Rewire Security does not accept liability for any damages caused due to incorrect
installation.
6
6.1.2 Connect the wires with the original car circuit as shown below:
(When the ACC is connected to your vehicle’s ignition, the GPS-303 will know if your
ignition is ON or OFF depending on the voltage)
6.2 SIM CARD Installation
Use the screwdriver included with the device to open bottom cover and insert
the SIM card to the designated sim card slot. Do not forget to activate your sim
card by making a quick call if you are using a pay as you go sim card. If you
would like to use GPRS/Internet tracking, make sure your sim card's internet
tracking is enabled.
Ensure your phone has the "show caller id" option enabled, otherwise you
will not get any response from your tracker.
6.3 Turning the GPS-303 “on”
Connect the positive & negative wire, red & black ones, with 12V or 24V car
power system, wait for 1 minute after connecting power to and move the backup
battery switch to "on" position. (The switch is located next to the sim card slot
inside the casing)
7
6.4 GSM/GPS LED Indicator
Red LED: LED ON = Charging
LED OFF = Fully charged
FAST flashing fast = Low power
Green LED: LED flashing once a second = GSM mode
LED flashing once every three seconds = GPRS mode
LED constantly ON = No GSM reception
Blue LED: LED flashing = GPS fix established
LED OFF = No GPS reception
6.5 Changing your tracker’s password
Send SMS "password+old password+space+new password" to GPS-303 to
change its password.
Example : password123456 99999
Response: password OK
If you forget your password, you can restore it to the default password using the
command "adminpassword13142324".
Please note that you don't have to change the default password as without your
tracker's sim card phone number, it is not possible to have access to the tracker.
Make sure the new password is in 6 digits.
8
When reading this user manual, you will notice that we have used "+" and
"space" between some words;
"+" between two words means they should be written together as one word and
"space" between two words means you should leave one character space
between two words.
e.g. : sleep+123456+space+shock this should be sent to the tracker as
follows;
sleep123456 shock
6.6 Authorization
You have to save your phone number as authorized user to be able to use certain
functions as movement alerts, sos alerts and reports. You can authorize up to 5
numbers. Authorization can be done in two different ways;
6.6.1 Dial the GPS-303’s number 10 times from your mobile phone and it will
register your mobile phone number as the authorized number automatically
6.6.2 Send SMS “admin+password+space+cell phone number” to set up an
authorized number. All the other authorized numbers must be set by the first
authorized number.
Example: admin123456 07776665554
Response: admin OK
Depending on your network and phone, the tracker may read your number in
internatonal format. If you notice that the GPS-303 doesn’t send you any alarm
notifications after or doesn’t respond to your calls with a location report after
9
setting yourself as the authorized number, try authorizing your number in
international format;
Example: admin123456 +447776665554
Response: admin OK
6.6.3 Delete authorization Send SMS：“noadmin+password+space+authorized
number” to delete the authorized number.
6.7 SMS Text Message locating
If there aren't any authorized numbers set-up, GPS-303 will reply to all calls
with a location report. If there are authorized numbers set-up, only authorized
numbers will be able to receive location report from the tracker.
The SMS text message will include coordinates, current speed, time and date. It
will also contain a direct Google Map link for smartphone users.
*If you request your tracker's location and receive blank text message with no
coordinates or location information, this means your tracker has not established a gps
fix yet. Once it establishes a gps fix it will send another text message with the new
coordinates.
6.8 Interval Tracking
GPS-303 can send automatic location reports at set intervals. If SMS mode is
active, reports will be sent as SMS text messages. If GPRS tracking mode is
active, location report updates will be uploaded to the online tracking server.
10
6.8.1 Continuous interval tracking:
Send SMS “fix030s***n+password” to the GPS-303, it will reply the
latitude & longitude continuously at 30 seconds fixed intervals.
Note: Minimum interval setting is 10s.
Example: fix030s***n123456
Please note that you will not get a response for this message.
6.8.2 Smart interval tracking:
Please activate "Continuous interval tracking" before selecting this function.
Send sms command "distance+password+space+distance" to activate smart
interval tracking. GPS-303 will reply "Distance ok" and it will start uploading
its location at pre selected time intervals and distance.
Example: distance123456 0050
Response: distance OK
This means that distance is 50 meters; the number must be 4 digits. This will
configure the GPS-303 to send its location every 50 meters.
To set this function on live tracking mode: Set time interval first and then
distance interval, GPS-303 will locate upon the time and distance.
6.8.3 To Cancel auto-tracking: Send SMS “nofix+password” to the tracker
device to
cancel the auto-tracking (auto-reporting).
Example: nofix123456
11
6.9 Smart angle updating
The tracker will update the positions automatically to web server once the
vehicle changes driving direction over a pre set angle value. This function is
only available in GPRS mode.
Send sms command "angle+password+space+angle" to activate.
Example: angle123456 45
Response: angle ok
The angle must be 3 digits, default angle value is 30 degree.
6.10 GPS drift suppression
GPS signal can be affected with many factors like weather and location.
Surrounding buildings or trees can reduce GPS signal strength. Clouds also
degrade the signal and the locating accuracy may drop, causing your GPS-303
to show up in different locations in a 50 meter radius time to time. If you are
using live (GPRS) tracking you may notice your GPS-303 doing 20-50meter
jumps on your map when the vehicle is actually stationary. GPS drift
suppression is used to avoid this. When activated, GPS-303 will stop sending
GPRS data to live tracking server when the ignition is OFF. GPRS drift
suppression also helps with sim card economy as the GPRS mobile data will
only be used while the vehicle is moving.
This function is switched "OFF" by default. Send "suppress+password" to
GPS-303 to activate, it will reply" suppress drift ok". The GPS data will stop
updating if the vehicle is stationary. GPS data will update automatically once
12
vehicle starts moving. Please note that the ACC (ignition) detection wire (white)
on your tracker should be connected for this function to work.
Example: suppress123456
Response: suppress ok
To cancel: send "nosuppress+password" to the GPS-303
Example : nosuppress123456
Response: No suppress ok
6.11 Exact street address by SMS
You must set the APN of your GSM network provider for the SIM card used in
GPS-303 before using this function. If your local GSM network requires user
name and password for GPRS, please set it up according to the GPRS
instructions in chapter 6.27. Send SMS “address+password” to GPS-303 after
APN has been set up and it will reply in exact address including street name.
Example: address123456
Response: 20a Park street, clifton, bristol, bs1 5ja
6.12 Cell-ID tracking (LBS)
If GPS-303 is unable to establish a solid GPS fix, it will calculate its location
using Cell-id info. Location reports will include the GPS coordinates of the
last known position as well as a LAC code. Entering the LAC code to the
"Manual Track" menu of the web tracking platform will enable you to see the
tracker's current location. You can also send command "address+password" to
13
the tracker to request exact address. GPS-303 will automatically switch to
tracking by LBS in GPRS mode. Accuracy of LBS (also known as Cell-id
tracking) depends on the distance to the nearest GSM Network Cell Tower or
Base Station. In urban areas this accuracy varies between 25-100 meters.
6.13. Voice Surveillance
GPS-303 is in Tracking mode by default. When voice surveillance mode is
activated, it will automatically answer incoming calls rather than replying with
its location information.
To activate the monitor mode, send SMS "monitor+password" to GPS-303. It
will reply "monitor ok" and switch to "monitor" mode.
Example: monitor123456
Response: monitor OK
Do not forget to switch back to tracker mode once you have finished using the
voice surveillance. When GPS-303 is in monitor mode it will stop updating its
position and it will shut the GPS module "OFF". To change back to tracker
mode use command "tracker+password"
Example: tracker123456
Response: tracker OK
6.14.Data logging
15.1 Auto logging：If GPS-303 loses GSM or GPRS signal, it can store the
14
tracking position and alerts automatically on to the flash drive upon the pre-set
conditions. When GSM signal is acquired, all the event alerts will be auto-sent
to authorized numbers and the live tracking server.
15.2 Logging at preset intervals: Send SMS: “save030s005n+password” to
GPS-303, it will reply “save ok”, and will log the lat, long locations every 30
seconds for 5 times. (S: second, m: minute; h: hour).
Example: save030s005n123456
Response: save ok
15.3 Continuous logging：Send SMS:”save030s***n+password” to GPS-303,
it will reply “save ok”.
Example: save030s***n123456
Response: save ok
15.4 Log Clearance: send SMS: “clear+password” to GPS-303, it will
reply “clear ok”.
Example: clear123456
Response: clear ok
15.5 Logging Volume: Built-in flash 1MB (store about 16,000 positions). This
volume can be expanded by using a Micro SD card which can be inserted into
slot provided. Please refer to section 3.3 to see where micro SD card needs to
be inserted. A 2GB card would be sufficient for up to 10 months.
Data logging function also enables you to use your GPS-303 as a GPS logger.
You can download the location data to your PC by using the free PC software
provided, through USB connection.
15
6.15. Data upload
6.15.1 Auto Upload: If there is no GSM reception, GPS-303 will save all GPS
data to its built-in memory and upload this information to the live tracking
server automatically when the GSM reception is back to normal. This way
tracking data won't get lost while driving through areas with no or low GSM
reception. If you do not wish to use this feature, you can turn it "OFF" by
sending the SMS command "autoload+password+space+off"
Example: autoload123456 off
Response: autoload off OK
6.15.2 Specified date upload： Send SMS: “load+password+space+year month
date” to GPS-303. It will reply: “load ok” and will upload the tracking data of
the specified time/date.
Example: load123456 20110425
Response: load ok
6.16. Forwarding incoming SMS messages
GPS-303 can forward incoming messages from pre-set phone numbers . To
activate this function, send "forward+password+space+third party phone
number" from an authorised phone number. GPS-303 will reply "forward ok",
and start forwarding SMS messages coming from that number. Only one
number can be set-up for SMS forwarding.
Example: forward123456 07776665544
Response: forward ok
16
To cancel SMS forwarding: send SMS command "noforward+password".
Example: noforward123456
Response: no forward ok
6.17. SIM Card Balance Enquiry
Send SMS command "balance+password+space+carrier’s phone
number+space+code" to the tracker, it will forward the content to the
specified phone number and return the content from the specified phone
number.
Example: balance123456 0262 check
Ps: This function assumes that the GSM Network provider has the option where
you can check your Sim Card’s balance by sending a command to a specific
number; which is 0262 in this example.
6.18 Alarms
6.18.1 Low battery alarm
Send SMS “lowbattery+password+space+on”, it will reply “low
battery+location” to authorized numbers 2 times in total in 15 minutes
intervals when the voltage of battery is lower than 3.55V.
Example: lowbattery123456 on
This function is active by default, send SMS lowbattery+password+space+off”
to deactivate.
Example: lowbattery123456 off
17
6.18.2 Power disconnection alarm
This function is deactivated by default. Send "extpower+password+space+on”
to activate, GPS-303 will send SMS “power alarm+location” to authorized
numbers every 3 minutes if the external power has been disconnected
Example: extpower123456 on
To cancel: Send SMS “extpower+password+space+off”
Example: extpower123456 off
6.18.3 Geo-fence (Virtual fence/barrier) alarm
This function allows you to create safety zones of your choice. When GPS-303
enters or leaves this pre-determined zone, it will send geo-fence alarm warning
to authorized numbers.
When GPS-303 stays immobile in a place for 3-10 minutes, you can send SMS
“stockade+password+space+latitude,longitude;latitude,longitude” to GPS-303
to set the zone. In case of a breach, it will send SMS “stockade!+location” to
authorized numbers every 3 minutes. It will stop sending alarm once it returns
back to the zone.
Note: The first latitude & longitude is coordinate of the top left corner of the
Geo-fence, while the second latitude & longitude is the coordinate of the bottom
right corner.
Example: stockade123456 51.460959, -2.622643; 51.456842, -2.604446
You can obtain co-ordinates of any location from Google Maps by clicking on
desired location and selecting "what's here?"
18
To Cancel: Send SMS “nostockade+password” to deactivate this function.
If you are using live tracking on our server www.gpslive.co.uk , geo-fence
zones can also be created online.
Example: nostockade123456
6.18.4 Multi-area management
6.18.4.1 To Set an Area for multi-management
Send SMS command
"area+password+space+latitude,longitude+space+areaname,distanceM" to
activate (distance unit: M for meter, K for kilometer).
Example: area123456 22.353648,113.543678 school,800M
Response: area ok
Note: 5 areas at most and the distance between two points can't be less than the
total distance in the 2 commands. Different areas can't cover each other.
6.18.4.2 Delete areas
Send SMS command:"noarea+password+space+area name" to delete an area.
Example: noarea123456 school
Response: noarea ok
6.18.4.3 Rename and set distance
Send SMS command "rename+password+space+old name;new
name,distanceM" to activate. If name is not repeated and area doesn't cover
other areas, it will reply "rename ok!" if configuration was successful.
Example: rename123456 area01;school,800M
19
The new area name will be "school", and will covers area of a radius of 800
meters.
6.18.4.4 Activate multi-area management
Send SMS command "area+password+space+on" to activate. When GPS-303
enters the pre set area, it will send SMS "area location" to all authorized phone
numbers, and it will send same SMS when goes out of the area.
Example: area123456 on
Response: area on ok
6.18.4.5 Deactivate Multi-area management
Send SMS command "area+password+space+off" to deactivate.
Example: area123456 off
Response: area off ok
6.18.5 Movement alarm
Set up: when GPS-303 stays immobile in a place for 3-10 minutes with GPS
signal reception you can send SMS “move+password+space+0200” to activate
movement alarm the movement alert with an area radius of 200 meters.
Maximum radius limit is 999 meters. GPS-303 will reply “move OK”. In case
of such a movement it will reply SMS "move+location" to authorized numbers
at 3 minutes intervals.
Example: move123456 0250
Response: move ok
Note: Setting the radius less than 100 meters may result in false movement alert.
20
The fault alert occurs if GPS position is miscalculated due to bad GPS reception.
Inaccurate GPS reading will cause the GPS-303 to think that it is in a different
location, possibly further from its current location, thus the processor will
accept this as a movement and trigger the movement alarm. However, this may
only occur if the GPS-303 is installed improperly in a place where it can't
receive good signal.
To Cancel: Send SMS “nomove+password” to deactivate the movement alarm.
Example: nomove123456
Response: nomove ok
6.18.6 Over speed alarm
Over speed alarm will be triggered when GPS-303 exceeds speed limit
predetermined by you. Setup: Send SMS “speed+password+space+speed” to
GPS-303 and it will reply “speed ok!”. This means that you have set up over
speed alarm successfully.
Example: speed123456 080 .
080 refers to 80km/h. When your vehicle's speed exceeds 80km/h, GPS-303
will send SMS “speed+080!+ location” to authorized numbers.
To cancel: Send SMS “nospeed+password” to deactivate the over speed alarm.
Note: Recommended minimum setting for over speed alarm is 30km/s.
Example: nospeed123456
Response: nospeed ok
21
6.18.7 ACC (Ignition/voltage) alarm
This function is switched "OFF" by default. To activate, send "ACC+password"
to GPS-303, it will reply "ACC ok" and send "ACC on+latitude & longitude" to
authorized numbers when the ignition of the vehicle has been switched "ON";
and it will send “ACC off+latitude & longitude" to authorized numbers, which
means the ignition of the vehicle is "OFF".
Example: acc123456
Response: acc ok
Send SMS command "noACC+password" to disable this function.
Example: noacc123456
6.18.8 Vibration alarm
Setup: Shock sensor alarm is deactivated by default. Send SMS command
“shock+password” to activate. When the GPS-303 detects vibration, it will send
SMS “Sensor alarm+location” to authorized numbers.
Example: shock123456
Response: shock ok
To cancel shock sensor alarm send sms command : "noshock+password".
Example: noshock123456
Response: no shock ok
Shock sensor sensitivity configuration:
The sensitivity of the built-in shock sensor has three different levels:
22
First level: Alarm will be triggered with a slight vibration, send command
"sensitivity+password+space+1" to choose this setting.
Second level: Alarm will be triggered after detecting 8 vibrations in 2
seconds, send command "sensitivity+password+space+2" to choose
this setting
Third level: Alarm will be triggered after detecting 25 vibrations in 5
seconds, send command "sensitivity+password+space+3" to choose this
setting.
6.19 Theft alarm
Send sms command “arm+password” to activate the theft alarm, the GPS-303
will enter arm state and and reply “Tracker is activated”.
GPS-303's alarm can not be armed if the ignition is "on" and it will reply “set up
fail! pls turn off ACC”.
Example: arm123456
ACC alarm and Vibration alarm will automatically be activated once the theft
alarm is activated.
6.20 DISARM
Send command “disarm+password” to deactivate/disarm the theft alarm, the
GPS-303 will deactivate the alarm and reply “Tracker is deactivated”.
23
6.21 Status enquiry
Send SMS command “check+password” to the GPS-303 to check its current
status.
Example: check123456
Response:
Power: ON/OFF
Battery: 100%
GPRS: ON/OFF
GPS: OK/NO GPS
ACC: OFF/ON
GSM Signal: 1-32
6.22 Hardware reset
Send SMS “reset+password” to reset the GSM & GPS module of your
GPS-303.
Example: reset123456
Response: reset ok
6.23 Standby modes
6.23.1 Sleep by time
Send sms command "sleep+password+space+time" to activate. If none of the
24
alarms/alerts has been set, the GPS-303 will enter standby mode after 5 minutes
of inactivity. GPS module and LED will switch off. GSM module (phone line)
will stay active. Calling or sending SMS can wake it back up from standby
mode.
Example: sleep123456 time
Response: sleep time ok
6.23.2 Sleep by shock sensor
Send sms command "sleep+password+space+shock" to activate.
The GPS-303 will enter standby mode if no vibration has been detected for 5
minutes. GPS module and LED will both switch off. GSM module will stay
active so you will be able to communicate with the tracker. Vibration,
movement, calling or sending a SMS text message can wake it back up
Example: sleep123456 shock
Response: sleep shock ok
6.23.3 Turning standby modes "off"
Send SMS command ”sleep+password+space+off” to turn all sleep/standby
modes "off".
Example: sleep123456 off
Response: sleep off ok
25
6.24 IMEI number request
Send SMS "imei+password" to the GPS-303 and it will respond with IMEI
number of its GSM module.
Example: imei123456
Response: 359710055889966
6.25 Time setting
Send SMS command “time+space+zone+password+space+time” to GPS-303, It
will reply “time OK”
Example: time zone123456 0 (0 is gmt 0 UK time zone)
Response: time ok
If your country time zone is minus, send the time zone with a "-" symbol.
Example: time zone123456 -8
Response: time ok
6.26 TCP / UDP Switch
Command:"gprs+password,1,1" switch to UDP mode.
Command: "gprs+password,0,0" switch back to TCP mode, this is the default
mode.
6.27 GPRS SETTING
GPRS tracking mode allows GPS-303 to upload its location data to a web server
at preset intervals.
26
APN , Update intervals and server's ip address must be configured to be able to
use GPRS (live internet) tracking.
6.27.1 APN SETTING
6.27.1.1 APN stands for Access Point Name and differs with each GSM
network. For more information, contact your local SIM card network operator.
Send SMS “APN+password+space+APN”, GPS-303 will reply “APN OK” if
succeeded.
Example: apn123456 orangeinternet
Response: apn ok
Note: orangeinternet is the APN code for pay as you go services of Orange
GSM network. the APN varies with different GSM network operators in
different countries, please check with your local GPRS network operator to
get the correct APN. See examples below for some UK networks.
apn123456 data.lycamobile.co.uk ->lyca mobile UK
apn123456 uk.lebara.mobi -> Lebara UK
apn123456 everywhere -> ee pay as you go
6.27.1.2 APN User Name and password Setup
Most networks do not require password authentication while setting up the APN.
However, if your network requires this setting please configure as following:
Send SMS “up+password+space+user+space+password”, If succeeded,
GPS-303 will reply “user, password ok!”.
Example: up123456 data user
27
Note: 123456 is password of GPS-303, data is the user name for GPRS login,
user is the password for GPRS login.
6.27.2Server IP and Port Setup
This setting will configure the GPS-303 to upload its location to the selected
live tracking server.
Send SMS “adminip+password+space+IP+space+port” to GPS-303. It will
reply “adminip ok” if succeeded
Example: adminip123456 178.159.0.78 10200
Response: adminip ok
Note: 178.159.0.78 is the IP address of default server www.gpslive.co.uk
and 10200 is the port.
6.28 GPRS economy mode
If activated GPS-303 will gprs economy mode after being stationary
for 10 minutes, GPRS will disconnect and connect again when vehicle starts
moving.
To activate this function: Send "less gprs+password on", GPS-303 will reply
"less gprs on ok".
Example: less gprs123456 on
Response: less gprs on ok
To deactivate: Send "less gprs+password off".
28
Example: less gprs123456 off
Response: less gprs off ok
6.29 Switching between “SMS” and “GPRS” mode
The default mode is “GPRS”
To activate GPRS mode, send SMS command “GPRS+password”
Example: gprs123456
Response: gprs ok
To activate SMS mode, Send SMS command “SMS+password”.
Example: sms123456
Response: sms ok
7． TROUBLESHOOTING
Faults
Solution
No LED light
Please make sure GPS-303 is wired correctly & receiving
power from the 12 or 24v source
29
No dial tone
First check the LED lights on GPS-303. If GPS-303 is
Receiving power , no dial tone means there is no GSM.
1- Check if the sim card you are using is active.
2- Test the sim card in a mobile phone and see if the
network you are using does not have any reception
issues in your area.
No response to
Text commands
First ensure there is dial tone when you call GPS-303’s
Sim number. If there is a dial tone, there are two possible
causes for GPS-303 not to respond to your commands;
1- There is no balance/credit in the sim card you are using.
2- You are using a wrong password (default:123456)
No location report
SMS after calling
GPS-303
1- If there is an authorized phone number registered,
GPS-303 will only respond to authorized phone numbers
with SMS location reports.
2- Ensure that you are not calling from a witheld or
private phone number.
30
Wrong position
In GPRS mode
(internet/ live
Tracking)
1- If your GPS-303 is showing up in the middle of the
ocean just outside the gulf of guinea, it hasn't sent any
data or position co-ordinates to the server and it is
currently on default , zero coordinate position. Please
check your APN, GPRS server ip / port and interval
settings. Some networks may have a few different APN
settings for different sim cards or bundles. We
recommending contacting your sim network provider to
obtain the correct APN information.
2- If your GPS-303 is still showing up at a previous
location, this means it hasn't sent any position data to the
Online tracking server since you have left that location.
If this is a persistent problem, your GPS-303 may not be
receiving sufficient GPS signal, and that may cause
delayed position update.
31
Wrong position
In SMS mode
1- Check if the position report starts with the word "Last".
If so, this means that GPS-303 hasn't established a GPS
fix since and it is showing the last position it did have a
solid GPS fix and it hasn’t established a GPS connection
since.
2- If the co-ordinates on position report are showing 0 ,
this means that GPS-303 hasn't established a GPS fix yet.
Move your GPS-303 to a position with clear line of sight
Terms and Conditions for the sale of Goods by REM Trading LTD
Contents:
1. Our contract with you
2. Changes to order or terms
3. Delivery of goods
4. If the goods are faulty
5. Seller’s guarantee of goods
6. Price and payment
7. Our liability to you
8. Your cancellation rights
9. Our cancellation rights
10. Information about us and how to contact us
11. How we may use your personal information
12. Other important terms
1. OUR CONTRACT WITH YOU
1.1 These are the terms and conditions on which We supply Goods to you.
1.2 Please ensure that you read these Terms carefully, and check that the details on the
Order and in these Terms are complete and accurate, before you submit the Order. If you
think that there is a mistake, please contact Us to discuss, and please make sure that you
ask Us to confirm any change in writing to avoid any confusion between you and Us.
1.3 We consider that these Terms and the Order constitute the whole agreement between
you and Us.
1.4 When you sign and submit the Order to Us, this does not mean We have accepted your
order for Goods. Our acceptance of the Order will take place as described in clause
32
1.5 If We are unable to supply you with the Goods, We will inform you of this in writing
and We will not process the order. These Terms will become binding on you and Us when
We issue you with a written acceptance of an Order OR We contact you that We are able to
provide you with the Goods, which We will also confirm in writing to you, at which point a
contract will come into existence between you and Us.
1.6 If any of these Terms conflict with any term of the Order, the Order will take priority.
1.7 We shall assign an order number to the Order and inform you of it when We confirm
the Order. Please quote the order number in all subsequent correspondence with Us relating
to the Order.
1.9 The images of the Goods on Our website OR in Our catalogue or brochure are for
illustrative purposes only. Although We have made every effort to display the colors
accurately, We cannot guarantee that your computer‘s display of the colors OR the printed
pictures accurately reflect the color of the Goods. Your Goods may vary slightly from those
images. Although We have made every effort to be as accurate as possible, however all
sizes, weights, capacities, dimensions and measurements indicated on Our website OR in
Our catalogue or brochure have a 2% tolerance.
2. CHANGES TO ORDER OR TERMS
2.1 We may revise these Terms from time to time in the following circumstances:
(a) Changes in how We accept payment from you;
(b) Changes in relevant laws and regulatory requirements
2.2 If We have to revise these Terms under clause 2.1, We will give you at least
one month‘s written notice of any changes to these Terms before they take effect. You can
choose to cancel the contract in accordance with clause 11.
3. DELIVERY OF GOODS
3.1 Please note that timescales for delivery and delivery charges will vary depending on the
availability of the Goods and your address. Please allow for extra time for deliveries to the
Scottish Highlands and Islands OR Ireland.
3.2 We will contact you with an estimated delivery date. Occasionally Our delivery to you
may be affected by an Event Outside Our Control.
3.3 Delivery of an Order shall be completed when We deliver the Goods to the
address you gave Us.
3.4 If We are not able to deliver the whole of the Order at one time due to
operational reasons or shortage of stock, We will deliver the Order in installments.
We will not charge you extra delivery costs for this. However, if you ask Us to deliver the
Order in installments, We may charge you extra delivery costs. Each installment shall
constitute a separate contract governed by these terms. If We are late delivering an
installment or one installment is faulty, that will not entitle you to cancel any other
installment.
3.5 The Goods will be your responsibility from the completion of delivery.
3.6 You own the Goods once We have received payment in full.
4. IF THE GOODS ARE FAULTY
As a consumer, you have legal rights in relation to Goods that are faulty or not as described.
5. SELLER‘S GUARANTEE OF GOODS
5.1 We guarantee that on delivery and for a period of 12 months from delivery, the Goods
shall be free from material defects. However, this guarantee does not apply in the
circumstances described in clause 5.2.
33
5.2 This guarantee does not apply to any defect in the Goods arising from:
(a) Fair wear and tear;
(b) Willful damage, abnormal storage or working conditions, accident, negligence by you
or by any third party;
(c) If you fail to operate or use the Goods in accordance with the user instructions;
(d) Any alteration or repair by you or by a third party who is not one of Our authorized
repairers;
(e) Incorrect installation by you or by a third party who is not one of Our authorized
installers; and
(f) Any specification provided by you.
5.3 This guarantee is in addition to your legal rights in relation to the Goods that are faulty
or not as described.
6. PRICE AND PAYMENT
6.1 The price of the Goods will be set out in Our price list in force at the time We confirm
your Order. Our prices may change at any time, but price changes will not affect Orders
that We have already confirmed with you.
6.2 It is always possible that, despite Our best efforts, some of the Goods We sell may be
incorrectly priced. We will normally check prices as part of Our dispatch procedures so that,
where the Goods‘ correct price is less than Our stated price, We will charge the lower
amount when dispatching the Goods to you. If the Goods‘ correct price is higher than the
price stated on Our site. We will contact you to tell you and for your instructions. If the
pricing error is obvious and unmistakeable and could have reasonably been recognized by
you as a mispricing, We do not have to provide the Goods to you at the incorrect (lower)
price.
6.3 Where We are providing Goods to you, you must make payment for Goods in advance
by credit card, debit card, paypal or bank transfer.
7. OUR LIABILITY TO YOU
7.1 If We fail to comply with these Terms, We are responsible for loss or damage you suffer
that is a foreseeable result of Our breach of the Terms or Our negligence, but We are not
responsible for any loss or damage that is not foreseeable. Loss or damage is foreseeable if
they were an obvious consequence of Our breach or if they were contemplated by you and
Us at the time we entered into this contract.
7.3 We only supply the Goods for domestic, private and business use. However, we have no
liability to you for any loss of profit, loss of business, business interruption, or loss of
business opportunity.
8. YOUR CANCELLATION RIGHTS
8.1 Before the Goods are delivered, you have the following rights to cancel and Order for
Goods including where you choose to cancel because We are affected by an Event Outside
Our Control or We change these Terms under clause 3.1 to your material disadvantage:
(a) You may cancel any Order for Goods at any time before We dispatch the Goods.
(b) If you cancel an Order under clause 8.1 (a) and you have made any payment in advance
for Goods that have not been delivered to you, We will refund these amounts to you.
(c) Unfortunately, if you cancel an Order for Goods under clause 8.1 (a) and We have
already dispatched your Goods to you, We will not be able to cancel your Order until it is
delivered. In this case, if you return the Goods to Us, we will have to charge you the cost of
collection or you will have to pay the cost of returning the Goods back to Us. This will not
34
affect your refund for the Goods, but any charge for collection will be deducted from the
refund that is due to you.
9. OUR CANCELLATION RIGHTS
If We have to cancel an Order for Goods before the Goods are delivered:
(a) We may have to cancel an Order before the Goods are delivered, due to an Event
Outside Our Control or the unavailability of stock. We will promptly contact you if this
happens.
(b) If We have to cancel an Order under clause 9(a) and you have made any payment in
advance for Goods that have not been delivered to you, We will refund these amounts to
you.
10. INFORMATION ABOUT US AND HOW TO CONTACT US
10.1 We are a company registered. Our company registration number is 9451681 and Our
registered office is Chandos mews, 34b chandos road, Redland, Bristol, BS6 6PF.
10.2 If you have any questions or if you have any complaints, please contact Us.
You can contact Our customer service team by emailing Us at info@rewiresecurity.co.uk
10.3 If you wish to contact Us in writing, or if any clause in these Terms requires you to
give Us notice in writing (for example, to cancel the contract), you can send this to Us by
e-mail,by hand or by pre-paid post to Chandos mews, 34b chandos road, Redland, Bristol,
BS6 6PF OR info@rewiresecurity.co.uk. We will confirm receipt of this by contacting you
in writing.If We have to contact you or give you notice in writing, We will do so by e-mail,
by hand, or by pre-paid post to the address you provide to Us in the Order.
11. HOW WE MAY USE YOUR PERSONAL INFORMATION
11.1 We will use the personal information you provide to Us to:
(a) provide the Goods;
(b) process your payment for such Goods; and
(c) inform you about similar products or services that We provide, but you may stop
receiving these at any time by contacting Us.
11.2 We will not give your personal data to any other third party.
12 OTHER IMPORTANT TERMS
12.1 We may transfer Our rights and obligations under these Terms to another organization,
and We will always notify you in writing if this happens, but this will not affect your rights
or Our obligations under these Terms.
12.2 This contract is between you and Us. No other person shall have any rights to enforce
any of its terms. However, the purchaser of your property will have the benefit of the
guarantee at clause 6.1 if you transfer it to them, but We and you will not need their consent
to cancel or make any changes to these Terms.
12.3 Each of the paragraphs of these Terms operates separately, If any court or relevant
authority decides that any of them are unlawful, the remaining paragraphs will remain in
full force and effect.
12.4 If We fail to insist that you perform any of your obligations under these Terms, or if
We do not enforce Our rights against you, or if We delay in doing so, that will not mean
that We have waived Our rights against you and will not mean that you do not have to
comply with those obligations. If We do waive a default by you, We will only do so in
35
writing, and that will not mean that We will automatically waive any later default by you.
12.5 These Terms are governed by English law. You and We both agree to submit to the
non-exclusive jurisdiction of the English courts.
Loading...
