Revo Super Signal User guide

Owner’s Guide

v1.0

PRESETS

SuperSignal

English

TECHNICAL SUPPORT

WARRANTY

Should you encounter problems using this product, please refer to the
troubleshooting section on page 21 of this owner’s guide.
Alternatively, call Revo technical support on :

UK 01555 666161

From outside the UK + 44 1555 666161

Alternatively, e-mail [e-mail] or visit the troubleshooting
section of our website at: www.revo.co.uk/support

ENVIRONMENTAL INFO

PRODUCT DISPOSAL INSTRUCTIONS (WEEE DIRECTIVE)

The symbol shown here and on the product means that it is classed
as Electrical or Electronic Equipment and should not be disposed with
other household or commercial waste at the end of its working life.

The Waste of Electrical and Electronic Equipment (WEEE) Directive
(2002/96/EC) has been put in place to recycle products using best
available recovery and recycling techniques to minimise the impact
on the environment, treat any hazardous substances and avoid the
increasing landfi ll.

For more information please contact your local authority or the retailer
where the product was purchased.

RoHS COMPLIANT & CE MARK

This product has been designed to comply with international
directives on the Restriction of Hazardous Substances (RoHS) and has
been designed and type-tested to comply with EU
requirements and carries a CE mark.

Revo Technologies Ltd warrants to the end user that this product will
be free from defects in materials and workmanship in the course of
normal use for a period of one year from the date of purchase.
This guarantee covers breakdowns due to manufacturing faults and
does not apply in cases such as accidental damage, general wear
and tear, user negligence, modifi cation or repair not authorised by
Revo Technologies Ltd.

To register your purchase please visit www.revo.co.uk/register

COPYRIGHTS AND
ACKNOWLEDGEMENTS

Copyright 2013 Revo Technologies Ltd. All rights reserved.

No part of this publication may be copied, distributed, transmitted or
transcribed without the permission of Revo Technologies Limited.

REVO and SUPERSIGNAL and are trademarks or registered
trademarks of Revo Technologies Ltd.

The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks is under
license. aptX® is a trademark of CSR plc.

Revo Technologies Ltd
The Inox Building, Caldwellside, Lanark,
Scotland, United Kingdom, ML11 7SR

Tel: [phone] Int. Tel: [phone]
Fax: [phone] Int. Fax: [phone]

Email: [e-mail] Website: www.revo.co.uk

SAFETY WARNINGS

• Do not operate this radio near water

• Do not remove screws or casing parts

• Use only the power supply unit supplied

• Avoid small objects and liquids from entering the product

02

DISCLAIMER

Revo Technologies Limited makes no representation or
warranties with respect to the content of this publication, and
specifi cally disclaims any implied warranties of merchantability or
fi tness for any particular purpose. Further, Revo Technologies Limited
reserves the right to make changes to this publication from time to
time, without notifi cation to any person or organisation.

CONTENTS

02 Technical Support

02 Environmental Info

02 Warranty

02 Copyrights and Acknowledgements

02 Disclaimer

03 Welcome / Unpacking

04 Anatomy

05 Remote Control

06 Power Supply

06 Set-Up

07 Control

08 - 09 DAB Radio Mode

10 - 11 DAB Mode Menu Options

12 - 13 FM Radio Mode / AUX IN Mode

14 - 15 Bluetooth Mode

16 - 17 Alarm Clock

18 - 20 System Settings

21 Troubleshooting

WELCOME

Thank you for purchasing our SUPERSIGNAL radio.

SUPERSIGNAL is an expression of our design and engineering
philosophy, and the result of the experience gained through 10 years
of award-winning product design and development. Functionalism
meets craft and technology, a next-generation audio device that will
provide you with many years of enjoyment and reliable service.

This guide has been designed to quickly get you up-and-running
with your radio, offer guidance on the more complex features of
this product and provide information on safety, warranty details and
troubleshooting.

UNPACKING YOUR RADIO

The SUPERSIGNAL box should include the following items:

• SUPERSIGNAL radio

• Remote control and batteries

• Power supply with multi-country adaptors

• Screen cleaning cloth

• Warranty card

• Owner’s guide

Should any item be missing or damaged, please contact your point
of purchase or call Revo directly on [phone]

NOTE: All packaging should be retained for possible future use, it is
the safest way to transport your radio should it be necessary.

03

ANATOMY OF SUPERSIGNAL

Station Presets 1 - 5

Touch-Snooze Area

Power/Standby

PRESETS

Volume Dial

SuperSignal

Joystick Controller

Select Button

Mode

Telescopic

Menu
Info

Alarm

Antenna

Kensington Lock Slot

Stereo RCA Connectors Aux-In DC Power Socket Update Port

04

3.5mm Headphone Connector

REMOTE CONTROL

Power

Mode

Info

Alarm

Skip Back (Fast Rewind)

Scroll Up

Left (Back)

Scroll Down

Presets 1 - 8

BATTERY REPLACEMENT

The SUPERSIGNAL remote control is powered by two AAA
batteries. Depending on usage, the batteries should happily run for
between 1 and 2 years.

Menu
Volume Increase

Volume Decrease

Skip Forward (Fast Forward)
Play / Pause

Right (Forward)

Select

Replace the batteries when button presses seem sluggish, or when
the operating range appears to have reduced signifi cantly.

05

POWER SUPPLY (PSU)

!"#$

Your SUPERSIGNAL radio is supplied with a multi-region power supply,
meaning that it can be operated in a number of countries around
the world.

Simply choose the correct adaptor for your country from the
selection supplied, then follow the instructions below.

SET-UP

Using the PSU supplied, connect one end to the DC power socket found on the

1

rear of your radio, then plug the opposite end into the mains socket on the wall.

SUPERSIGNAL will automatically perform a scan to see

2

what DAB stations are being broadcast in your area.
Therefore please fully extend the antenna before
switching on.

06

3

Press the POWER button once to get started.

CONTROLLING SUPERSIGNAL

In order for you to get the most from your radio, it is important for you
to understand how its joystick and menu system operates.

JOYSTICK CONTROL

Your radio uses a joystick based control system for ease of use.

The joystick controller has four functions (UP, DOWN, LEFT and RIGHT)
and is used in conjunction with a separate SELECT button.

MENU BUTTON

Pressing the button will take you to the Mode Menu for the
particular mode of operation you are in. For example, pressing
when in DAB Mode will take you to the DAB MODE MENU.
Pressing the button for a second time will return you to the
‘playing screen’ that you just left.

You can use the button at any time to reverse out of any menu
that you’re navigating through.

The following system settings can be accessed from any of the mode
menus :

• Sleep

• Equaliser

• Time

• Contrast

• Language

• Factory Reset

• Software Upgrade

• Software Version

See SYSTEM SETTINGS on Page 18 for further details

MODE BUTTON

Pressing the MODE button will sequentially cycle through each of
SUPERSIGNAL’s modes of operation.

‘UP’

‘LEFT’ ‘RIGHT’

‘DOWN’

07
