Revo RM185-OR1 User Manual

18.5-INCH WIDE

LED MONITOR

USER MANUAL

Please read this manual thoroughly before use, and keep it handy for future reference.

SAFETY INSTRUCTIONS ………………………………………………………….….. 2 ~ 3

CAUTIONS …………………………………………………………….......................... 4

FCC RF INTERFERENCE STATEMENT ……………………………....................... 5

CONNECTING WITH EXTERNAL EQUIPMENT …………………………………… 6

INSTALLATION ………………………………………………………………………….. 7

CONTROLS AND FUNCTIONS ……………………………………………………….. 8 ~ 15

MOUNTING GUIDE …………………………………………………………………….. 16

D-SUB CONNECTOR PIN ASSIGNMENTS ………………………………………… 17

POWER MANAGEMENT ……………………………………………………………… 18

SPECIFICATIONS ……………………………………………………………………… 19

TROUBLE SHOOTING GUIDE …………………………………………………......... 20

This Monitor was

Manufactured by ISO 9001

Certified Factory

- 1 -

1. Read these instructions.

2. Keep these Instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this monitor near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

8. Do not install near any heat sources such as radiators, heat registers,stoves, or other

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

Important Safety Instructions

instructions.

monitor (including amplifiers) that produce heat.

A polarized plug has two blades with one wider than the other.

A grounding type plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for your safety.

If the provided plug does not fit into your outlet, consult an electrician for replacement

of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs.

convenience receptacles and the point where they exit from the monitor.

11. Only use attachment/accessories specified by the manufacturer.

12. When a cart is used, use caution when moving

the cart/ monitor combination to avoid injury from tipping over.

13. Unplug the monitor during lightning storms or when unused

for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the monitor

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the monitor, the monitor has been exposed to

rain or moisture or does not operate normally or has been dropped.

- 2 -

- The monitor shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed no the apparatus.

Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation.

“WARNING – To reduce the risk of fire or electric shock, do not expose the monitor to rain or moisture.”

This symbol is intended to alert the user to the presence of uninsulated:

dangerous voltage with in the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating

and maintenance(servicing) instructions in the literature accompanying the

appliance.

- 3-

NEVER REMOVE THE BACK COVER▶

Removal of the back cover should be carried out only by qualified personnel.

DO NOT USE IN HOSTILE ENVIRONMENTS▶

To prevent shock or fire hazard, do not expose the unit to rain or moisture.

This unit is designed to be used in the office or home. Do not subject the unit to vibrations,

dust of corrosive gases.

KEEP IN A WELL VENTILATED PLACE▶

Ventilation holes are provided on the cabinet to prevent the temperature from rising.

Do not cover the unit or place anything on the top of unit.

AVOID HEAT▶

Avoid placing the unit in direct sunshine or near a heating appliance.

TO ELIMINATE EYE FATIGUE▶

Do not use the unit against a bright back ground and where sunlight or other light sources will

shine directly on the monitor.

BE CAREFUL OF HEAVY OBJECT▶

Neither the monitor itself nor any other heavy object should rest on the power cord.

Damage to a power cord can cause fire or electrical shock.

- 4 -

NOTE

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures.

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

- Consult the dealer or an experienced radio, TV technician for help.

connected.

- Only shielded interface cable should be used.

Finally, any changes or modifications to the equipment by the user not expressly approved by

the grantee or manufacturer could void the users authority to operate such equipment.

▶ DOC COMPLIANCE NOTICE

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital

apparatus set out in the radio interference regulation of Canadian Department of

communications.

- 5 -

Before setting up the monitor, ensure that the power to the monitor and other attached

devices are turned off.

※ Notice: Stand & screws are optional.

A. Connecting the stand

1. Place the monitor with its front facing downward on a soft cloth.

2. Assemble the Stand Base into the Stand Body in the correct direction using the included

screws in the accessory box.

Stand BodyStand Base

FS4x12 screws

B. Positioning your display

1. Adjust the position of the panel in various ways for maximum comfort. (Tilt Range: -3°~15°)

15˚-3˚

- 6 -

1. Rear Connection

1. 3.5mm AUDIO OUT.

2. 3.5mm AUDIO IN.

3. VGA.

4. DC 12V.

- 7 -
