Revo REVDN700-2 User Manual

INSTRUCTION MANUAL

WDR Super High Resolution

Day & Night Color Camera

Model No: REVDN700-2

Vandal Proof dome Camera

LIMITATION OF LIABILITY

THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL
RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS
OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE
SUCH CHANGES

CE COMPLIANCE STATEMEN

T

WARNING

This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

PRECAUTIONS

Before installation, carefully read the manual to ensure correct operation and setup,
heeding all warnings and instructions.

Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.

Ensure manual is kept in good condition for future use.

Do not install the device near any heat sources such as radiators, heat registers, stoves,

or other equipment (including amplifiers) that produce heat.

Only use attachments/accessories specified by the manufacturer.

Should any liquid get into the housing, immediately disconnect the device from the
power supply and have it checked by authorized personnel before reusing.

Do not install the device in a place of high humidity or where exposed to gas or oil.

Installation and servicing by authorized personnel only, adhering to local safety
regulations.

Unless you are an authorized technician, never try to dismantle the device. To avoid
electric shock, never remove the screws or covers.

If a camera, do not expose the device to radioactivity. It will cause serious damage to
the CCD.

Use Certified/Listed Class 2 power source only.

Cleaning

Clean the device with a slightly damp soft cloth. Use a mild household detergent. Never
use strong solvents such as thinner or benzene as they might damage the finish of the
unit.

3

TABLE OF CONTENTS

CONTENTS OF PACKAGE ------------------------------------------------------------------------- 4

INTRODUCTION --------------------------------------------------------------------------------------- 5

CAMERA CONNECTIONS -------------------------------------------------------------------------- 6

INSTALLATION ----------------------------------------------------------------------------------------- 7

LENS ADJUSTMENT --------------------------------------------------------------------------------- 9

CAMERA OVERVIEW -------------------------------------------------------------------------------- 10

CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 11

EXTERNAL DIMENSION ---------------------------------------------------------------------------- 20

SPECIFICATIONS ------------------------------------------------------------------------------------- 22

CONTENTS OF PACKAGE

Installation of the camera must be performed by qualified service personnel in
accordance with all local and national electrical and mechanical codes.

Carefully remove the colour camera and its accessories from the carton and verify that
they were not damaged in shipment.

The content of the package includes:

1. Camera in Housing

2. This Manual

3. Accessory Kit for Installing

4. Drilling guide label

4

INTRODUCTION

The camera provided high-quality image using SONY 1/3” CCD and digital signal
processing LSIs.

Features:

z 1/3" Super-HAD CCD
z Super high-resolution (700TVL)
z Wide Dynamic Range
z Day & Night(Auto, Manual, External, Filter delay, Change level adjust)
z 0.1Lux(Color), 0.01 Lux(BW) @ F1.2 50IRE
z Auto Electronic Shutter [1/50(60) ~ 1/100,000] and manual electronic shutter

modes [1/50(60) ~ 1/10,000]

z Sens-Up (~x256)
z 2D-NR
z UDF Function(Ultra Deep Field)
z Multi Camera Configuration Set (4-Sets/Night Profile, Ext DN Profile)

z PVA/PVA+ (Personal Video Analytics)

 Very High Configurable.
 Various Detection Methods(Motion, Loitering Object, Abandon, Scene

Change, Unfocus, Windy Area)

 Various Zone Event Detection Methods, and Event Area Combinations.
 8 Objects Trace, 4 Objects Display

 Concurrent Processing with All Detections, and All Objects.

 Two Counting Block.
 Event String Sending (Editable String)
 Digital Tracking(Using D-PTZ)

 Various Detection Area(MAX. 10 area, Line, Rectangle, 4-Point polygonal)
z Back Light Compensation (EHLC, Auto, Spot)
z i-Freeze Function(Reduce recording space)
z Privacy Mask or Mosaic(MAX. 10 area/4-point polygonal/transparency)
z Digital Image Stabilization.
z Digital PTZ
z Digital Effect (H/V reverse, 180 degree rotate, inverse, freeze)
z White Pixel Removal.
z Focus Aid Function.
z Color Rolling Suppression.
z System Lock (4-character password)
z Auto and Manual white balance modes
z Support Line-Lock external synchronization
z RS-485 Remote camera control
z Multi-Language
z User Certified / Listed Class 2 power source only
z Operates in 12VDC or 24VAC
z IP66

5

CAMERA CONNECTIONS

Connection Cable Description

COLOR Description

RED AC24V/DC12V

WHITE AC24V/DC12V

BLUE RS485(-)

GREEN RS485(+)

YELLOW ALARM OUT

GRAY DN EXT-IN

BLACK&WHITE DN EXT-OUT

BLACK GND

SKY BLUE UTP+(Option)

PINK UTP- (Option)

1) External Day/Night Control

Select Day/Night mode using external equipment, by connecting control lines to the
appropriate terminals.

z DAY&NIGHT EXTERNAL INPUT

Switches the cameras D/N mode to either Day or Night based on the input
status. Refer to the diagram below. The cameras D/N mode must be set to
EXT for this to function.

Black

z DAY&NIGHT OUTPUT

The camera turns on an external IR LED Lamp by detecting the sensitivity on the AGC
level when the D&N mode is set "AUTO" on the OSD menu of the camera.

B

lack&White

‘

2) Alarm Out

- TTL level

z Motion detection signals are output through this port. (YELLOW AND GND)
z Active state is configurable.

3) Power Input Terminal

z RED & WHITE : These terminals accept 24VAC or 12 VDC. When using 12VDC

it is recommended to use a DC power supply that can support an inrush current
of 0.55A

4) Camera Control

z GREEN : RS 485+
z BLUE : RS 485-

5) UTP (Option)

z Video signal through out the UTP Cable (SKY BLUE(+) & PINK(-))

GND

DAY&NIGHT INPUT Gray

DA

Y&NIGHT OUTPUT

GNDBlack

●

●

Open contact: DAY
Close contact: NIGHT

●

● 0V : IR LED OFF (DAY)

6

INSTALLATION

(4x)

1. Loosen the four torx screws located midway up the front of the housing leaving the

screws intact in the front portion. (Fig. 1)

2. Drill the mounting location, using the Drilling guide. (Fig. 3)

3. Attach the housing to the ceiling using suitable fasteners, M6x35 tapping screws are

supplied. Only use if they are suitable. (Fig. 3)

4. Close the housing using the loosen torx screws. (Fig. 2)

*Label is attached at the bottom.

Figure 1

Torx screws
M5x10 (4x)

Torx screws
M5x10

Figure 2

Seal around
the housing
base tightly

7
