Re-Verber-Ray MP-40-80N, MP-40-150N, MP-50-115N, MP-50-200N, MP-50-150N Insert Manual

MP Series

Insert Manual

For complete installation instructions, see the Tube Heater General Manual
that accompanies this Series Insert Manual.

The MP Series Infrared Tube Heater is a positive pressure, modulating radiant heater system. This insert
manual is a supplement to the Tube Heater General Manual and provides specific information related to
the MP Series model. All persons involved with the installation, operation and maintenance of the heater
system must read and understand the information in this insert manual and the accompanying Tube
Heater General Manual.

For Your Safety

If you smell gas:

!

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this equipment.

This heater must be installed and serviced by trained gas installation and service
personnel only. Failure to comply could result in personal injury, asphyxiation, death,
fire or property damage.

In locations used for the storage of combustible materials, signs must be posted to
specify the maximum permissible stacking height to maintain the required clearances
from the heater to the combustibles. Signs must either be posted adjacent to the
heater thermostats or in the absence of such thermostats, in a conspicuous location.

Not for residential use! Do not use this heater in the home, sleeping quarters,
attached garages, etc. Installation of a commercial tube heater system in

residential indoor spaces may result in property damage, serious injury,
asphyxiation or death.

• Do not try to light any appliance. • Immediately call your gas supplier from a neighbor’s phone.

• Do not touch any electrical switch. • Follow the gas supplier’s instructions.

• Do not use any phone in your building. • If you cannot reach your gas supplier, call the fire department.

Keep these instructions for future reference.

LIOMP-Rev. 02012

Print: 1M-2/12(DRP)

MP Series

Contents

1.0 Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Labels and Their Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Clearances to Combustibles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Gas Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Electrical Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Thermostat and Other Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Zoning Heaters and Configuring ‘Master/Slave’ Heaters . . . . . . . . . . . . . . . . . . . . . . 8

Building Management Systems and Other Remote Analog Signals. . . . . . . . . . . . . . 8

Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Internal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Configuring the Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

‘Options’ DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

‘Address’ DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Tube Installation Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Sequence of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Performance Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.0 Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.0 Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Heater Components and Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

MP Series Kit Contents Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Approvals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

NOTE: See Page 16 for a list of available models and specifications.

2

Air Metering Orice

DO NOT REMOVE

TP-114

TP-3014

3"

SAMPLE

MP Series

1.0 Safety • Safety Labels and Locations

1.0 Safety

Read and understand all safety information and warnings in this Insert Manual and the Tube
Heater General Manual before installation, operation and maintenance of the radiant tube
heater system.

Safety Labels and Their Locations

Product safety signs or labels should be replaced by the product user when they no longer are legible.
Contact either your local distributor or the product manufacturer for obtaining replacement signs or labels.

HOT

120V

- 120V HEATER INPUT -

F/N: LLV3EP1

NEUTRAL

EARTH

F/N: LLAC

Air Metering Orifice

HOT

NEUTRAL

120V

EARTH

- 120V HEATER INPUT -

Back Panel

2. Remove top cover (2 thumbscrews).

3. Remove tsix (6) 1/4” screws.

4. Lift and remove panel.

KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.

F/N: LLV3EP18

F/N: LLTB018 (Natural Gas)

F/N: LLTB019 (LP Gas)

F/N: LLV3EP6

(Operational Indicator Lights)

Top Panel

FAN COMPARTMENT

1. Disconnect gas & electricity.

SERVICE ACCESS PANEL

SERVICE ACCESS PANEL

KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.

4. Swing hinged panel downward.

3. Remove top cover.

2. Remove four (4) thumbscrews.

1. Disconnect gas & electricity.

CONTROLS & GAS VALVE COMPARTMENT

F/N: LLTCL001L2/LLTCL002C2/LLTCL002R

Safety & Clearance Labels

KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.

CAUTION: HOT SURFACE.

SERVICE ACCESS PANEL

cover upward and outward.

2. Remove cover by lifting top

1. Disconnect gas & electricity.

IGNITER & FLAME SENSE COMPARTMENT

Bottom Panel

F/N: LLLOGO19
MP Series
Logo Label

F/N: LLLOGO1 Re-Verber-Ray Logo Label

3

!

AVOID EQUIPMENT FAILURE

THIS 10 FT. TUBE IS THE

COMBUSTION CHAMBER.

THIS TUBE MUST BE THE FIRST TUBE

FOLLOWING THE BURNER CONTROL BOX.

!

INSTALLER

The combustion chamber utilizes either 409
stainless, titanium alloy or aluminized steel -

depending on the model number of your heater.

Rotate the tube’s welded seam to bottom.

Consult the manual(s) for further details.

MP-40-150N

Data on this label is for the model shown on this label. If your heater has been converted,
this information is not accurate. Please contact the factory for assistance.

BURNER COMPONENTS:

Serial #: 0112DETR21400 0001

Gas Valve:
Circuit Board:
Wire Harness:
N.O. Switch:
N.O. VL Orifice:
N.C. Switch:
N.C. VL Orifice:
Diff Switch:
Diff VL Orifice:
Igniter:
Burner:
16” Tube:
Ind. Lights:

Diag. Light:
Term. Block:
Transformer:
Fan:
Alt. Fan:
Alt. Fan Usage:
Relay:
Filter:
24 Volt In:
120 Volt In:
Gas In:
Extra VL Orifice:

Production Code:
Version:

Add-on:
Stock:

Internal Use Only:

HEATER

TYPE:

Electric:
Tag:

Special 1:
Special 2:

Gas:
Air:

C1

C1 C2 C3

None

N/A

MP-150

10.11

Valve Assy - Nat
Mod Controller
Mod Wiring Harness
None
None
None
None
IS22010051F5166
Grey (+ / -)
Norton
Mid
4” Gen.
Yellow - 24V

(Specify TP-#’s)

3240
3250
3254
N/A

N/A

1264A

50
201B
3380
328

1428
None
40 VA
Fasco Lg.
50Hz - 120V
When Specified
Picker x2
None
3 T-plug
6’ Blk. Cord
7/8” FC
None

N/A
826
3015
None

None
N/A

333
FC-36

X

X-X”

TP-204#
TP-3014#XX-X”

LLWT0XX
None

X

X-X”

X
X.X”

Orifice Type:

1.0 Safety • Safety Labels and Locations • Clearance to Combustibles

MP Series

SERVICE ACCESS PANEL

IGNITER & FLAME SENSE COMPARTMENT

1. Turn off gas & electricity.

2. Remove cover by lifting top

cover upward and outward.

CAUTION: HOT SURFACE.

KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.

F/N: LLTB026

SERVICE ACCESS PANEL

IGNITER & FLAME SENSE COMPARTMENT

1. Disconnect gas & electricity.

2. Remove cover by lifting top

cover upward and outward.

CAUTION: HOT SURFACE.

KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.

Controls Compartment

SERVICE ACCESS PANEL

F/N: LLTB025R

SERVICE ACCESS PANEL

RE-VERBER-RAY INFRA-RED RADIANT TUBE HEATER

®

FOR OUTDOOR USE AND INDOOR (Non-Residential) INSTALLATION ONLY.
Class IIIA Permanent Label

MODEL NO.

INPUT BTU/H

MP-40-150N

MP

Volts AC:

120V - 60Hz

AMPS - Starting:

4.8

AMPS - Running:

1.1

Combustion Chamber:

4” Black Coated Aluminized

DESIGN COMPLIES WITH:

ANSI Z83.20b-2004-GAS FIRED LOW INTENSITY INFRA-RED HTR.

DETROIT RADIANT PRODUCTS COMPANY

21400 HOOVER ROAD - WARREN, MI
[phone] - www.drp-co.com

FOR USE WITH

155,000 / 150,000 / 98,000

Natural Gas

Manifold Pressure:

Heater Type

3.5 in.

W.C.P.

C1

Maximum Inlet Pressure:

Minimum Mounting Angle:

14 in.

W.C.P.

045DEGREES

Minimum Inlet Pressure:

Maximum Mounting Angle:

5.0 in.

W.C.P.

For stainless steel upgrades: The combustion tube is 409 Series stainless steel.

Serial No.: 1011XXXXXXXXXX 0001

DEGREES

16” Burner Tube Combustion Chamber

: LLTB024L

F/N

SAMPLE

Burner Control Box Component Label

(located inside the center compartment lid)

RE-VERBER-RAY INFRA-RED RADIANT TUBE HEATER

®

FOR OUTDOOR USE AND INDOOR (Non-Residential) INSTALLATION ONLY.
Class IIIA Permanent Label

MODEL NO.

MP-40-150N

Volts AC:

120V - 60Hz

AMPS - Starting:

4.8

AMPS - Running:

1.1

Combustion Chamber:

4” BC Titanium

DESIGN COMPLIES WITH:

ANSI Z83.20b-2004-GAS FIRED LOW INTENSITY INFRA-RED HTR.

DETROIT RADIANT PRODUCTS COMPANY

21400 HOOVER ROAD - WARREN, MI
[phone] - www.drp-co.com

INPUT BTU/H

155,000 / 97,000

Manifold Pressure:

4.1 in.

Maximum Inlet Pressure:

14.0 in.

Minimum Inlet Pressure:

5.0 in.

SAMPLE

For stainless steel upgrades: The combustion
tube is 409 Series stainless steel.

W.C.P.

W.C.P.

W.C.P.

FOR USE WITH

Natural Gas

Heater Type

C1

Version:

10/11

Minimum Mounting Angle:

045Degrees

Maximum Mounting Angle:

Degrees

Serial No.: 1011DETR021400 0001

Radiant Tube(s)

Rating
Plate

Fan Compartment

F/N: LL01 - Clearance Safety Tag
(Affix adjacent to heater’s thermostat)

Clearance to Combustibles

Clearance to combustibles is defined as the minimum distance that must exist between the tube surface,
or reflector, and any combustible items (see Figure 1.1). It also pertains to the distance that must be
maintained from moving objects around the tube heater.

Placement of explosive objects, flammable objects, liquids and vapors close to
the heater may result in explosion, fire, property damage, serious injury or death.
Do not store or use explosive objects, liquids or vapor in the vicinity of the heater.

F/N: LLTB004 (orange)

(150,000 - 200,000 BTU/h models only)

WARNING

4

MP Series

1.0 Safety • Clearance to Combustibles

When installing the tube heater system, clearances to combustibles for the model tube heater and
configuration must be maintained. Refer to Chart 1.1 below to determine the required distances for your model.

Chart 1.1 • Clearance to Combustibles in Inches (See Figure 1.1 for Mounting Angles)

Mounting

Model Number

MP-(25,30,40)-80[N,P]

with 1 side shield 0° 29 8 6 66
with 2 side shields 0° 16 16 6 66
20 ft. from burner 0° 7 7 6 30

MP-(30,40,50)-115[N,P]

with 1 side shield 0° 42 8 6 76
with 2 side shields 0° 20 20 6 76
20 ft. from burner 0° 7 7 6 30

MP-(40,50,60) -150[N,P]

with 1 side shield 0° 42 8 6 83
with 2 side shields 0° 23 23 6 83
20 ft. from burner 0° 11 11 6 46

MP-(50,60,70)-200 [N,P]

with 1 side shield 0° 54 8 6 100
with 2 side shields 0° 30 30 6 100
20 ft. from burner 0° 11 11 6

Angle*

0° 14 14 6 66

45° 39 8 10 66

0° 20 20 6 76

45° 58 8 10 76

0° 24 24 6 83

45° 58 8 10 83

0° 41 41 6 100

45° 63 8 10 100

Front Behind Top Below

Sides

The minimum end clearance for all models is 12 inches.

50

* Maximum mounting angle is 45°. Heaters mounted on an angle between 0° to 45° must maintain

clearances posted for 0° or 45°; whichever is greater.

The stated clearance to combustibles represents a surface temperature of 90°F (32°C) above room
temperature. Building materials with a low heat tolerance (such as plastics, vinyl siding, canvas, tri-ply,
etc.) may be subject to degradation at lower temperatures. It is the installer’s responsibility to assure that
adjacent materials are protected from degradation.

Figure 1.1 • Mounting Angles

0° Mounting Angle

with 2 Side Shields

(P/N: SSE)

Top

Side Side

0° Mounting Angle 45° Mounting Angle

Top

Side

Side

Front

Top

Behind

0° Mounting Angle

with 1 Side Shield

(P/N: SSE)

Top

Front Behind

Below

Below

Below

Below

5

2.0 Installation • Gas Requirements • Electrical Requirements

!

2.0 Installation

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause property
damage, serious injury or death. Read and understand the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment. Only
trained, qualified gas installation and service personnel may install or service this equipment.

Not for residential use! Do not use this heater in the home, sleeping quarters, attached
garages, etc. Installation of a commercial tube heater system in residential indoor

spaces may result in property damage, serious injury or death.

Instructions for the following are detailed in the Tube Heater General Manual:

• Design considerations

• Hanger suspension and placement

• Tube layout and assembly

• Burner control box suspension

• Reflectors (and accessories)

• Venting and combustion air intake

• Gas requirements

• Baffle assembly

MP Series

Note: Electronic versions of all manuals are available at www.detroitradiant.com, or upon request.

Gas Requirements

Manifold pressure of the heater is pre-set at the factory. No adjustment should be necessary.
During the verification process, a tolerance of ±10% of the full scale is acceptable due to varying
atmospheric conditions.

Manifold Pressure Inlet Pressure

Type of Gas

Natural 4.10 Inches. W.C. 1.65 Inches W.C. 6.00 Inches W.C. 14.00 Inches W.C.

Propane 11.0 Inches. W.C. 4.80 Inches W.C. 12.00 Inches W.C. 14.00 Inches W.C.

IMPORTANT: Consult the Tube Heater General Manual for gas connection requirements.

@ Maximum Rate @ Minimum Rate Minimum Maximum

Electrical Requirements

• 120 Volt - 60 Hz GRD, 3-wire.

• Low voltage thermostat connection.

• Starting current 4.8 amps.

• Running current 1.1 amps.

Shielded thermostat wire of 18 AWG is recommended for connection to the heater from the thermostatic
controller. The MP Series heater is pre-set by the factory for use with the Premium User Interface (TP-PUI).

NOTICE

6

MP Series

!

2.0 Installation • Thermostat and Other Controls

WARNING

Electric Shock

Field wiring to the tube heater must be connected and grounded in accordance with national,
state, provincial, local codes and to the guidelines in the Tube Heater General Manual and
Series Insert Manual. In the United States refer to the most current revisions to the ANSI/NFPA
70 Standard and in Canada refer to the most current revisions to the CSA C22.1 Part I Standard.

Thermostat and Other Controls

The MP Series heater is designed to operate on various control configurations. The available control
options are:

A. Premium User Interface.
B. Potentiometer with On/Off switch.
C. Single-Stage Thermostat with optional room temperature sensor.

“A” Premium User Interface

The Premium User Interface (TH-PUI) is a smart logic controller that offers the optimal
performance out of your MP Series heater. It modulates the heater(s) with a full PID Controller
considering various inputs and outputs. It utilizes the current set temperature, the room
temperature (based on an on-board thermistor or an externally connected zone sensor), mode
selected, and other items to set the speed of modulation. Therefore, the heater output immediately
responds to a change in air temperature. For installation of this device, see Figure 2.2 on Page 10.

“B” Potentiometer

A linear 10k Ohm potentiometer can be used as a control device for the MP Series. This allows
the user to manually control the heaters firing rate based on the dial position. The heater will
modulate in increments of 1%, and vary from minimum firing rate to the full firing rate. An On/Off
switch or timer is necessary to allow for the heater to shut off. For installation with this device,
see Figure 2.3 on Page 11.

“C” Single-Stage Thermostat

A single stage heating thermostat can be used as a control device for the MP Series. This allows
the user to utilize a desired field supplied thermostat that best suits their individual needs. The
heat control is designed for use with a 2-wire heating system, (R & W) and is low voltage. The
heater cannot power the thermostat. The thermostat selected must not have a heat anticipator. For
installation with this device, see Figure 2.4 on Page 12.

When using a single stage thermostat, the use of a zone sensor is highly recommended. The unit will operate
without this accessory, but will then only modulate based on a predetermined algorithm that considers cycle
timing and history. Therefore the heater will not respond to rapid changes in air temperatures.

NOTICE

7

2.0 Installation • Thermostat and Other Controls • Zoning Heaters • Control Devices

MP Series

Zoning Heaters and Configuring ‘Master/Slave’ Heaters

The MP Series is designed to allow for several heaters within the same zone to simultaneously modulate
in synchronization when connected to a single control device. This configuration requires one ‘Master’
heater that is connected directly to the heat control device, and the remaining ‘Slave’ heaters are to be
wired to the ‘Master’ heater. The ‘Slave’ heaters will modulate based on the control signal from the
‘Master’ heater. During the operation of the system, all the ‘Slave’ heaters will modulate at the same
percentage rate of the full input as the ‘Master’ heater.

When wiring multiple heaters together for zoning, the heaters must be wired in series with a ‘Master’
heater utilizing a shielded thermostat wire. Connect the heaters via the appropriate wiring diagram. See
Pages 9-12 for more information.

Building Management Systems and Other Remote Analog Signals

A Building Management System or a Remote Analog Signal may be used as a controlled device for the
MP Series. This allows the heater(s) to be controlled directly by the output of the Building Management
System directly dictates the heaters firing rate. The analog signal can be either 0-10VDC or 4-20mA.

A Premium User Interface (P/N: PUI) MUST be used in order to connect the Building Management
System to the heater.

8

MP Series

2.0 Installation • Thermostat and Other Controls • Field Wring

Field Wiring

Field Supplied Control Wire: 18AWG plenum rated thermostat wire that is shielded w/ drain wire is

recommended for optimal performance.

Installing the Control Wire: Each heater includes a thermostat wire grommet to allow for thermostat wire
to be brought into the burner box. Insert the grommet into the low voltage wiring access hole. Feed the
thermostat wire through the grommet, piercing the rubber with the wire to ensure a tight seal. Ensure
enough wire length is available to make the proper connections. Tie the thermostat wire into a loose knot,
as shown in Figure 2.1. Ensure knot is loose enough to not cause any damage to the wire. This will allow
for a strain relief for the connections to the heater.

Figure 2.1 • Image for feeding the wire and showing the knot

Connections to the Heater: The control devices are connected to the Modulating Circuit Board (P/N:

TP-3250) via the thermostat terminal strips provided. The installer must select the appropriate thermostat
terminal strip to connect to the board depending on the control configuration desired. The unit will provide
the suitable voltage for each control device. DO NOT provide an external power supply to the thermostat
terminal strips. Damage to the circuit board may result and is not covered by warranty.

Three (3) thermostat terminal strips are included with each heater to allow for connections to the heater.
Note that only one terminal strip will be used for each application, as selected by the installer. The
remaining thermostat terminal strips can be discarded or kept with the manual for future reference.

• TP-3228 – 8 circuit terminal strip to be used with Diagram “A”.

• TP-3225 – 5 circuit terminal strip to be used with Diagram “B”.

• TP-3224 – 4 circuit terminal strip to be used with Diagram “C”.

9

2.0 Installation • Thermostat and Other Controls • Field Wiring

Figure 2.2 • Field Wiring Diagram “A”

A. Premium User Interface

MP Series

FOR USE WITH TP-3228

SLAVE HEATER

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

MASTER DIP SETTINGS

SLAVE DIP SETTINGS

MASTER HEATER

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

BK

LEGEND

PREMIUM

USER

INTERFACE

NOTE: SHIELD GROUND MUST BE TIED TO GROUND, AS SHOWN

10

MP Series

2.0 Installation • Thermostat and Other Controls • Field Wiring

Figure 2.3 • Field Wiring Diagram “B”

B. 10k OHM Potentiometer

FOR USE WITH TP-3225 MASTER DIP SETTINGS

SLAVE DIP SETTINGS

MASTER HEATER SLAVE HEATER

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

LEGEND

11

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

2.0 Installation • Field Wiring Diagrams

Figure 2.4 • Field Wiring Diagram “C”

C. Single-stage thermostat

MP Series

FOR USE WITH TP-3224

ROOM

THERMISTOR

MASTER DIP SETTINGS

SINGLE-STAGE

THERMOSTAT

SLAVE DIP SETTINGS

MASTER HEATER SLAVE HEATER

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

LEGEND

+15V

485-

485+

GND

CHASIS GND

485-

485+

GND

12

MP Series

2.0 Installation • Internal Wiring

Field Wiring

Before field wiring this appliance - Check existing wiring; replace if necessary.
Note: If any of the original wire supplied with the appliance must be replaced, it must be replaced with

wiring material having a temperature rating of at least 105°C and a voltage rating of 660V.

Figure 2.5 • MP Series Internal Wiring Diagram

COM.

24VAC

- PWM

+ PWM

BOARD

CIRCUIT

MODULATING

BRBK

VALVE ENABLED

N.O. RELAY

L1 (RELAY)

L2 (BLOWER)

L2 (NEUTRAL)

FLAME

SENSOR

G

GROUND

NEUTRAL

MODULE

IGNITION

VALVE

THERMOSTAT

L2 (NEUTRAL)

L1

F.C. TEST PINS

SIC1

PROBE

Y

BL

RELAY

TRANSFORMER

W W

BK

OW

R

RBL

Y

BL

BK

BR

BK

BK

BLOWER

SWITCH

PRESSURE

BK

BK

BK

BK

IGNITER

W

P.S.

LIGHT

INDICATOR

LIGHT

VALVE

INDICATOR

BK

BK

GAS VALVE

R

G

L2L1

BK W

W

BK

W

BK

BK

13

2.0 Installation • Configuring the Heater

MP Series

Configuring the Heater

The MP Series heater utilizes DIP switches on the modulating controller to configure various options
available. The DIP switches are located under the modulating circuit board cover (See Figure 2.6), and
are labeled “Options” and “Address”. These switches have to be configured correctly in order for the unit
to properly function.

Figure 2.6 • Projected View of DIP Switches

Address DIP Switch

Options DIP Switch

‘Options’ DIP Switches

1 ‘Master/Slave’: This switch determines if the heater is a ‘Master’ or ‘Slave’.

• ‘Master’ Option: Selected if heater is stand-alone or ‘Master’ of a zoned system.

• ‘Slave’ Option: Selected if heater is a ‘Slave’ in a zoned system and is connected to a ‘Master’.

2 Outdoor Air Probe: This switch determines if an outdoor air sensing probe is installed (sold

separately, must be used in conjunction with a Premium User Interface).

3 Premium User Interface: This switch determines if a Premium User Interface (TH-PUI) is used as a

heat demand control device. (Use Field Wiring Diagram A - Figure 2.2 ).

4 Potentiometer: This switch determines if a linear taper 10K Ohm potentiometer is used as a heat

demand control device. (Use Field Wiring Diagram B - Figure 2.3).

5 Thermostat: This switch determines if a single stage thermostat is used as a heat demand control

device (Use Field Wiring Diagram C - Figure 2.4).

6 Economy Mode*: This switch determines if ‘Economy Mode’ is the desired mode of operation.

7 Standard Mode*: This switch determines if ‘Standard Mode’ is the desired mode of operation.

8 Comfort Mode*: This switch determines if ‘Comfort Mode’ is the desired mode of operation.

*If Premium User Interface is connected, the mode selection switches are inoperative. Modes are selected
from the controller. For more information on the modes, see Page 19.

14

MP Series

Slave Heater Slave Heater

2.0 Installation • Configuring the Heater

Standard Configuration: From the factory, the heater is configured as follows:

1 ’Master’ Heater: ON
2 Outdoor Air Probe: OFF
3 Premium User Interface: ON
4 Potentiometer: OFF
5 Thermostat: OFF
6 Economy Mode: OFF
7 Standard Mode: ON
8 Comfort Mode: OFF

Figure 2.7 • Standard Configuration of DIP Switches

*If outdoor air sensor is equipped, switch DIP#2 to the ON position.
Use Diagram “A” on Page 8 for connecting the Premium User Interface to the heater.

‘Address’ DIP Switches

The Address DIP Switches are only utilized in a ‘Master/Slave’ installation or for BMS configurations. All
other configurations ignore the settings of these switches. When addressing a heater for a ‘Master/Slave’
configuration, the ‘Slave’ heaters must be addressed for proper operation. Each ‘Slave’ must have its own
unique configuration, determined by the installer. Up to 256 unique combinations can be configured.

Setting the ‘Slave’ Heater(s): The ‘Slave’ heater configuration is set by selecting the ‘Slave’ position on
switch #1 in the “Options” DIP Switches. The address switches become active when the ‘Slave’
configuration is selected. On the Address DIP Switches, configure each heater so that each heater has its
own unique configuration. An example is provided below for a three heater zone system.

Figure 2.8 • Example of three DIP Switches

Master Heater

(Factory Default)

(One Address Configuration)

Slave Heater

Slave Heater

(Different Configuration)

8

7

6

54

321

ON

COMFORT

STANDARD

ECONOMY

EXT. THERMOSTAT

POTENTIOMETER

USER INTERFACE

OA SENSOR*

MASTER

8

7

6

54

321

ON

8

7

6

54

321

ON

COMFORT

STANDARD

ECONOMY

EXT. THERMOSTAT

POTENTIOMETER

USER INTERFACE

OA SENSOR*

MASTER

8

7

6

54

321

ON

8

7

6

54

321

ON

COMFORT

STANDARD

ECONOMY

EXT. THERMOSTAT

POTENTIOMETER

USER INTERFACE

OA SENSOR*

MASTER

8

7

6

54

321

ON

15

2.0 Installation • Product Specifications

Product Specifications

Chart 2.1 • Specifications

Model

Number

Gas Type

(Select one)

Blast Mode Rate

(BTU/h Input)

Standard Modulating

MP Series

Range (BTU/h Input)

Straight Length

U-Tube Length

Min. Dist. From Burner

to Elbow or U-bend

Standard Weight (lbs.)

Stainless Steel Weight

(lbs.)

Recommended

Mounting Height

Combustion Chamber

(Black Coated)

Radiant Emitter Tube(s)

(Black Coated)

36” Baffle Pieces

MP-25-80

MP-30-80

MP-30-115

MP-40-80

MP-40-115

MP-40-150

MP-50-115

MP-50-150

MP-50-200

MP-60-150

MP-60-200

MP-70-200

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

N or LP

85,000

85,000

120,000

85,000

120,000

155,000

120,000

155,000

200,000

155,000

200,000

200,000

52

,000 - 80,000

52

,000 - 80,000

75

,000 -

52

,000 - 80,000

75

,000 -

97,5

00 -

75

,000 -

97,5

00 -

130

,000 -

97,5

00 -

130

,000 -

130

,000

115

115

150

115

150

194

150

194

194

,000

,000

,000

,000

,000

,000

,000

,000

,000

26’-9” 13’-1” 10 ft. 120 N/A 12’ to 20’ Alum Alum 5

31’-5” **17’-9” 10 ft. 160 195 12’ to 20’ Alum Alum 4

31’-5” **17’-9” 15 ft. 160 N/A 14’ to 22’ Alum Alum 5

41’-1” 22’-9” 10 ft. 190 235 12’ to 20’ Alum Alum 3

41’-1” 22’-9” 15 ft. 190 235 15’ to 25’ Alum Alum 4

41’-1” 22’-9” 20 ft. 190 235 15’ to 28’ Titan Alum 5

50’-9” **27’-5” 15 ft. 235 290 15’ to 28’ Alum Alum 3

50’-9” **27’-5” 20 ft. 235 290 17’ to 30’ Titan Alum 4

50’-9” **27’-5” 25 ft. 235 N/A 19’ to 37’ Titan Alum 2

60’-5” 32’-5” 20 ft. 265 330 17’ to 32’ Titan Alum 3

60’-5” 32’-5” 25 ft. 265 N/A 19’ to 37’ Titan Alum 1

70’-1” **37’-3” 25 ft. 300 N/A 19’ to 42’ Titan Alum 1

* Model requires stainless steel tube clamp (P/N: TP-220) to be located at the seam between the primary

combustion chamber and the secondary combustion tube downstream of the burner control box.

** Model requires 5EA-SUB accessory package when installing in a ‘U’ configuration (P/N: TF1B).

IMPORTANT: Reference box label to determine the number of required baffle sections for each model
heater.

Titan = Black coated titanium stabilized aluminized steel.
Alum = Black coated aluminized treated steel.

16

MP Series

2.0 Installation • Tube Installation Sequence

Tube Installation Sequence

Figure 2.9 • Tube Installation Sequence

Important! The combustion chamber & radiant tube sections must be installed in the following order.

25 Foot

30 Foot

40 Foot

Stainless steel clamp location on 200,000 BTU/h models (P/ N: TP-220).

50 Foot

60 Foot

70 Foot

Stainless steel clamp location on 200,000 BTU/h models (P/ N: TP-220).

Stainless steel clamp location on 200,000 BTU/h models (P/ N: TP-220).

Key

Burner Control Box with
16-inch Burner Tube

Black Coated Combustion
Chamber Tube*

Black Coated Aluminized Combustion
Chamber/Radiant Emitter Tube

P/N: TP-26A

P/N: TP-26A, TP-26B

Standard Tube Clamp

P/N: TP-21B

Stainless Steel Tube

Clamp (P/N: TP-220)

200,000 BTU/h models only - Located
between 1st and 2nd 10 ft. tube sections.

Baffle Location

* Aluminized tubes (80,000 to 115,000 BTU/h models) P/N: TP-26A.

* Titan tubes (150,000 to 200,000 BTU/h models) P/N: TP-26B.

NOTE: Refer to the Tube Heater General Manual, Chart 3.6 (Page 23) for secured reflector joints.

17

3.0 Operation • Sequence of Operation

MP Series

3.0 Operation

!

WARNING

This heater must be installed and serviced by trained gas installation and service
personnel only.

Do not bypass any safety features or the heater’s built in safety mechanisms will be
compromised.

Note: Reference the Tube Heater General Manual for installation requirements.

Sequence of Operation

There are two (2) main controllers for the MP Series heater. The TP-351A is the ignition controller, and is
responsible for the ignition sequence, flame monitoring, and safety lock-out features. The TP-3250 is the
modulating controller, and is responsible for the call for heat, modulating the gas valve and blower speed,
selecting the performance curve or mode, and handles various passive inputs and outputs for controlling
devices. These two devices will be referred to as their TP-#’s during the sequence of operation.

Standby:

TP-351A - 120VAC is held at the circuit of the circuit board.
TP-3250 - 24VAC and 120VAC is held at the circuit board.

Starting Circuit:

The TP-3250 checks various inputs to select the performance curve, model, and appropriate mode of
operation. After successful determination of all internal checks, the TP-3250 will output the conditioned
120VAC to the blower motor and 120VAC to the common side of the pressure switch.

Once operational static pressure is achieved, the differential switch will close, sending the 120VAC to the
TP-351A and the PS indicator light, initiating the ignition sequence. The glo-bar is energized with 120VAC
for 45 seconds from the TP-351A. Once the time is achieved, the TP-351A switches on the 120VAC for the
valve circuit and switches off the power to the glo-bar. The 120VAC from the TP-351A valve circuit is used
to power the coil side of the isolation relay and sends power to the TP-3250 to indicate the start of the
ignition sequence. The isolation relay switches 24VAC from the transformer to the primary coil of the gas
valve and valve indicator light.

Once the gas valve circuit is energized from the TP-351A, flame should be present on the burner and
visible through the sight glass. The flame rod monitors the burner flame through flame rectification, and
can be measured in micro-amps (this can be verified at the flame current test pins on the TP-351A).
Minimum required micro-amps are 1.0mA, and should be present during burner operation.

If the burner fails to light or flame is not detected within 8 seconds, the gas valve circuit is de-energized
and the control performs an “inter-purge” delay before attempting another ignition sequence. The control
will attempt 2 additional trials of ignition before entering the soft lock out sequence. In the soft lockout
sequence, the gas valve will be turned off immediately. After 1 hour, if the thermostat is still calling for
heat, the TP-351A will automatically reset and attempt a new trial for ignition. After multiple attempts to
ignite the burner have failed, the TP-351A enters a hard lockout mode. The control will not open the gas
valve unless there is an intervention by the user. The reset can be done by either resetting the thermostat
or removing the 120 VAC for a period of 5 seconds.

18

MP Series

3.0 Operation • Sequence of Operation • Performance Curves

Running Circuit:

After ignition, the flame rod continuously monitors the flame presence. If sense of flame is lost for a time
of 1.0 seconds or greater, the TP-351A closes the gas valve circuit and a new trial for ignition sequence is
initiated.

Modulating Circuit:

Pre-heat – During the ignition sequence, the TP-3250 operates the blower and gas valve at 100% operation
to optimize ignition. Once ignition is established, the heater will enter a pre-heat cycle for 90 seconds,
operating the blower motor and gas valve at 100%. However, if the heater has cycled in the previous 5
minutes, the controller will skip the pre-heat cycle, and go straight to modulating operation.

The blower motor and modulating coil on the gas valve are energized directly from the TP-3250
modulating controller. The controller utilizes PID logic to match the selected performance curve to the
heater’s operation. Based on the determined system configuration, the control will operate as needed to
match the desired system performance.

Performance Curves

The MP Series is programmed to operate on several different performance curves. These curves are to
allow the user to select the desired operation that best accommodates their specific needs. The
performance curves can be selected either by the Premium User Interface (TP-PUI) or by setting the DIP
switches located under the control cover (Pages 14-15). The three modes are as follows:

• Economy Mode: Unit operates to maximize thermal efficiency.

• Comfort Mode: Unit operates to maximize perceived human comfort.

• Standard Mode: Unit operates as a balance between comfort and economy mode.

Economy Mode: Economy Mode is intended to maximize thermal efficiency. It is designed to provide a
system that is more thermally efficient than the other modes due to quicker dissipation of heat. This
mode is recommended for applications such as:

• Aircraft hangars

• Car washes

• Pole barns

• Foundries

• Unpopulated warehouses

Comfort Mode: Comfort Mode is designed to minimize temperature differentials across the length of
the heater. It is intended to provide a system that has a greater perceived comfort than the other modes
because of the reduction of extreme temperature zones. This mode is recommended for applications
such as:

• Patios

• Loading docks

• Break areas and lunch rooms

• Parts counters and service desks

• Golf driving ranges

• Woodworking shops

• Kennels

Standard Mode: Standard Mode is a balance between Comfort Mode and Economy Mode. It is
intended to provide a system that is moderately thermal efficient while still minimizing the greater
temperature differentials associated with economy mode. This mode is recommended for applications
such as:

• Populated warehouse heating

• Service garages

• Fire Stations

• Manufacturing

• Auto showrooms

19

3.0 Operation • Sequence of Operation • Diagnostics

MP Series

Shut-down:

When the thermostat is satisfied, the TP-3250 will de-energize the 120VAC power to the common side of
the pressure switch, de-energizing the thermostat circuit on the TP-351A. The blower motor will continue
to cycle for a period of 2 minutes for a post-purge cycle.

NOTE: Due to the PID Controller optimizing the output of the heater, the unit may run for a short period
after the call for heat has been satisfied.

For extended shut down periods:

Set external controller devices to off or lowest setting.

1

Turn OFF the 120VAC to the heater.

2

Turn OFF the manual shut-off valve in the heater’s gas supply line.

3

Prior to start up after seasonal extended shut-down, an inspection of the heater must be performed by

4

trained gas installation and service personnel. This will ensure optimal operation and years of trouble­free service.

Diagnostics

Lockout:

The controls will automatically lockout the heater system when an external or system fault occurs. There
are two types of lockout:

Soft Lockout: The heater will attempt to light three times. In the event of a failed ignition, (gas pressure,

valve, no flame sense etc.), the heater will enter a soft lockout period for 15 minutes and
then attempt to light three more times before entering a Hard Lockout mode.

Hard Lockout: If proof of flame is not established, a component failure occurs or blockages are evident,

the heater will enter hard lockout. If lockout occurs, the control can be reset by briefly
interrupting the power source. The control will not open the gas valve unless there is an
interruption by the user.

Figure 3.1 • Operational Indicator Lights (see Charts 3.1 through 3.3 for Operation & Diagnostic LEDs)

HOT

NEUTRAL

120V

EARTH

- 120V HEATER INPUT -

Amber Light (24V)

Indicates Gas Valve

Operation

Amber Light (120V)

Indicates Pressure
Switch Actuation

20

MP Series

LED2

LED3

LED4

LED5

LED6

LED1

LED1

3.0 Operation • Diagnostics

Figure 3.2 • Circuit Board LEDs

LED1

LED2

LED3

LED4

LED5

LED6

Chart 3.1 • Operation LED

LED Color Description Operation

1

Green Relay ON On if relay ON to ignition module.

Chart 3.2 • Diagnostic LEDs

LED Color Description Operation

2

3

4

5

6

Green Power On if power to unit.

Green Heat On if call for heat.

Green Fan On if fan energized.

Green Valve On if valve energized.

Red Service Errors (see Chart 3.3).

Chart 3.3 • Flash Code Status LED (located on Circuit Board)

Each of the following status codes is a two digit number with the first digit determined by the number of
short flashes and the second digit by the number of long flashes.

LED Short Flash: 0.5 Seconds ON, 0.5 Seconds OFF.
LED Long Flash: 1.5 Seconds ON, 1.5 Seconds OFF.

LED CODE

(Number of Flashes) STATUS / ERROR

1-1 Long Run Time - Actual temperature fails to rise after 4 hours of consecutive running.

1-2 Blower - Fan is on but static pressure is not reading properly.

1-3 Ignition Module Failure - Ignition module failed to initiate sequence of ignition.

1-4 Ignition Soft Lockout - Control will auto reset after 15 minutes. See lockout in diagnostics

section.

2-1 Ignition Hard Lockout - Ignition module will NOT auto reset; unit will not operate unless

there is an interruption by the user.

2-2 Sensor Error - External temperature sensor is shorted or reading open.

2-3 Internal Software Error - Failure with software on modulating controller.

2-4 Model Selection or Setup Error - Invalid model selection DIP Switch configuration

3-2 Error with User Interface - Short was detected in user interface.

21

4.0 Troubleshooting Guide

4.0 Troubleshooting Guide

MP Series

Turn on control
device for heat.

Does the fan

blower turn on?

Yes

Does the

pressure switch

light turn on?

Yes

No

No

Replace or

repair damaged

components.

Yes

Is the control

device or

thermostat wire

damaged?

Does the igniter

warm up and turn

red?

No

Yes

Find source of

electrical problem

and repair.

No

Does the heater
have 120VAC at

the power entry

cord?

Pressure switch light is burned out.

Replace light.

Yes

No

Does the igniter

warm up and

turn red?

Yes

Does the valve

light turn on?

Yes

Does the gas

valve open?

No

No

No

Does the igniter

appear to be

physically

damaged?

Yes

Replace igniter.

Does the gas valve open?

(Usually a distinct

‘click’ noise occurs).

Check inlet pressure to

the heater. Is it within the

minimum and maximum

allowable range as per the

rating plate?

No

Temporarily disconnect igniter

from harness and check the

resistance. Is it within the

range of 50-400 Ohms?

No

Replace igniter.

No

Yes

Gas valve light is burned

out. Replace light.

Are the wires

to and from

the gas valve

properly

connected?

Yes

No

Yes

Continued on Page 24

No

Yes

Adjust inlet pressure.

Continued on Page 24

22

MP Series

4.0 Troubleshooting Guide

NOTICE

Start
Question

Is there 90-120VAC

across the fan wire

leads?

No

Check modulating

controller flash codes.

Bypassing any switch is intended for testing purposes only. Do not leave switch bypassed
during normal operation or the heater’s built-in safety mechanisms will be compromised.

Key

Process
Question

Yes

Corrective
Action

Is the fan obstructed

or locked in place by a

foreign object?

Yes

Remove obstruction.

No

Replace fan.

Re-connect igniter to

harness and check

voltage at igniter during

ignition sequence. Is it

approx. 120VAC?

Yes

Check connector pins

and wires. Repair or

replace.

Correct improper

wiring.

No

Replace

ignition

module.

Is the inlet or outlet of the

heater obstructed, or is
the vent exceeding the

recommended vent lengths?

Remove obstruction.

Reconnect tubing,

free kinks, and remove

obstructions.

Replace pressure switch.

Check modulating

controller flash codes.

Replace ignition module.

Yes

Yes

Yes

No

Is the wiring of the

No

pressure switch

loose, damaged or

disconnected?

Yes No

Correct faulty wiring or

replace damaged wires.

Is the pneumatic tubing to the

pressure switch connected and free

of kinks, damage or obstruction?

No

The heater is equipped with a safety

pressure switch. This is a normally

open, pneumatically operated

switch and is located in the service
compartment. TEMPORARILY place
jumper wires across the terminals of
the switch. Does the igniter warm up

and glow red?

23

4.0 Troubleshooting Guide

MP Series

Continued from Page 22

Yes Yes

Does the burner

ignite?

Yes

there is a restriction in the exhaust.

Pressure switch may be faulty or

No

Turn on the gas supply line.

Is the gas supply valve
to the heater in the “on”

position?

Yes

No

Yes

Confirm inlet is within minimum

and maximum inputs as indicated

on the rating label.

Is the gas pressure ok?

Check inlet pressure to the
heater. Is it within the minimum
and maximum allowable range

as per the rating plate?

No

Continued from Page 22

Check the voltage at

the relay coil during the

ignition sequence.

Is it 120VAC?

Yes

No

No

Yes

Does the burner

stay lit?

No

Does the burner light and

then shut off immediately

Yes

Is the heater

output consistent

with prior

operation?

No

Re-cycle the unit. Check

manifold pressure during

start-up. Is it with the ranges

specified on the rating plate?

Yes

Check inlet pressure to the

heater. Is it within the minimum

Does the heater

stay on until the call

for heat ends?

Yes

For additional information, contact your local

representative or the factory for assistance.

No

Troubleshooting ends.

and maximum allowable range

Adjust inlet pressure.

(1-2 seconds)?

No

as per the rating plate?

Yes

No

Does the burner stay

Yes

on for approximately

8 seconds and then

shut off?

No

Check modulating controller for

flash codes. Consult factory.

Consider the following:

• Change mode selection.

• Addition of a room thermistor.

• Addition of wind barriers.

• Check heat loss calculation.

• Consult factory.

Yes

The heater can shut down or stay on due to:

• Improper grounding.

• Faulty control device.

• High winds.

• Taking combustion air from the attic.

• Dirty environment.

• Improperly positioned baffles.

• Fluctuating gas pressure.

Partial blockage in the venting may

be present. Check for obstructions

and check flash codes.

Yes

24

MP Series

4.0 Troubleshooting Guide

Is there 120VAC on the primary

side of the transformer across

the BLACK and WHITE wires?

No

Is there 24VAC on the

secondary side of the

transformer across the

BLUE and YELLOW wires?

Check for flash codes on the modulating controller.

Replace the ignition module.

Adjust inlet pressure.

No

Yes

Yes

Purge gas lines.

No

Were the

gas lines purged of air?

Is the heater properly grounded?

Is the heater’s polarity correct

(L1 and L2 reversed)?

Yes

Check wiring and repair.

Replace transformer.

Is the relay switching

closed when energized

by the 120V coil?

No

Replace isolation relay.

Does the heater’s gas

type match the gas

supplied?

No

Yes

Yes

Replace valve wire.

No

Disconnect the main
wire to the valve and

check for resistance

across both coil pins.

Is there continuity

through each coil?

No

Replace gas valve.

No

Check manifold
pressure. Are you
reading within the

specified pressures?

Yes

No

Correct grounding

or fix polarity.

Yes

Contact local

representative or

With a micro ammeter, check the

micro Amps on the FS terminals

on the ignition module. Is it

greater than 0.7 Micro-Amps?

No

Is the insulation
of the flame rod

damaged or is the

rod dirty or oxidized?

factory.

Yes

Yes

No

Check modulating controller

for flash codes. Consult

factory.

Check modulating controller

for flash codes. Replace

ignition module.

Replace flame rod or

clean if able.

Replace wire to

flame rod.

25

5.0 Parts • Heater Components and Parts List

5.0 Parts

Figure 5.1 • Burner Assembly Components

3098

70A

331

3008

332

3223

352A

3010

3260

3261

249

3094A

33B

3099A

333

3002A

3240, 3241

76

331

826

3225

3228

3224

212

3060

245

70

3025

3234

351A

3250

3044

3235

3254

68B

204

3096A

264B,E, 1264A

3093

3097A

3011

3012

3001

70

217

222

221

50

205

3094A

3005A

9

10A

3074, 3072, 201B

3015

5

383

321

MP Series

21B

3380

14
15

17

16

3220

328

Chart 5.1 • Parts List

Part # Description Part # Description

TP-5 Flange Gasket TP-70A 1” x 6” Manifold Gasket

TP-9 3/4” EMT Conduit Coupling TP-76 3/8” Rubber Grommet

TP-10A 3/4” x 4” EMT Conduit TP-82 Reflector Center Support (RCS)

TP-14 Sight Glass Gasket TP-105 Aluminum Reflector End Cap

TP-15 Sight Glass TP-106 Reflector End Cap Clips (8 pieces)

TP-16 Sight Glass Washer TP-111 5 ft. x 4” Black Coated Aluminized Steel Tube

TP-17 Sight Glass Kit TP-112 5 ft. Polished Aluminum Reflector

TP-19B 4” Wire Hanger w/ Tension Spring TP-113 Reflector Tension Spring

TP-20C 10 ft. Polished Aluminum Reflector TP-201B High BTU Burner (Color Code - TAN)

TP-20D 10 ft. Stainless Steel Reflector TP-204 Gas Orifice (Consult Factory)

TP-21B 4” Standard Tube Clamp TP-205 Glo-Bar Holder

TP-26A 10 ft. Aluminized Radiant / Combustion Tube TP-212 1/2” N.P.T x 3” Pipe Nipple

TP-26B 10 ft. Titanium Stabilized Combustion Tube TP-217 Brass 1/8” N.P.T. Barb Fitting

TP-26D 10 ft. 304 Stainless Steel Radiant Tube TP-219 12” Pneumatic Tube for Pressure Switch

TP-26E 10 ft. 409 Stainless Steel Combustion Tube TP-220* Stainless Steel Tube Clamp

TP-31D Interlocking Mounting Bracket (Qty. 2) TP-221 Glo-Bar Holder Gasket

TP-33B 1/2” NPT Shut-off Ball Valve w/ Inlet Tap TP-222 Flame Rod

TP-50 Glo-Bar Igniter TP-245 Plastic 1/8” N.P.T. 90° Barb Fitting

TP-65I 3 ft. Interlocking Turbulator Baffle TP-249 3/16” Pneumatic Tee (Qty. 2)

TP-68B 1/2” Strain Relief Bushing TP-264B Differential Pressure Switch

TP-70 1/2” x 10” Control Box Gasket (Qty. 2) TP-264E Differential Pressure Switch

3033D

828

31D

3014

3004

3003A

26

MP Series

Figure 5.2 • Tube & Reflector Components

5.0 Parts • Heater Components and Parts List

20C/D*, 112

105

106

82

26A/D*, 111

113

19B

105

579

26A/B/E*

21B, 220

65I

Part # Description Part # Description

TP-331 Green Self-tap Ground Screw (Qty. 2) TP-3033D Power Entry Plate

TP-332 1/4” Divider Grommet TP-3044 Gas Manifold

TP-333 6 ft. Black Power Cord w/ Ground TP-3060 Pressure Switch Mounting Bracket

TP-351A Potted Circuit Board - Ignition Controller TP-3072 Low BTU Burner (Color Code - GREEN)

TP-352A Wire Harness for Ignition Controller TP-3074 High BTU Burner (Color Code - ORANGE)

TP-383 Glo-Bar Igniter Plate TP-3093 #8-32 Cage Nut (Qty. 4)

TP-579 4” Wire Hanger TP-3094A #8-32 X ½” Metal Thumb Screw

TP-826 40VA Transformer (120Primary / 24Secondary) TP-3096A Valve Compartment Bottom Panel

TP-828 24VAC Yellow Operational Indicator Light TP-3097A Valve Compartment Top Panel

TP-1018 20” Pneumatic Tube for Pressure Switch TP-3098 Valve Compartment Side Panel

TP-1264A Differential Pressure Switch TP-3099A Controls Mounting Panel

TP-3001 Divider Panel TP-3220 Thermostat Wire Grommet

TP-3002A Plastic End Panel, Control Compartment TP-3223 Anti-Kink Coil (Qty. 2)

TP-3003A Plastic End Panel, Fan Compartment TP-3224 Thermostat Terminal Strip, 4 Circuit (C)

TP-3004 Control Box TP-3225 Thermostat Terminal Strip, 5 Circuit (B)

TP-3005A Plastic Valve Chamber Lid TP-3228 Thermostat Terminal Strip, 8 Circuit (A)

TP-3008 Gas Valve Mounting Bracket TP-3234 Mini Fuse for TP-3250 (3A)

TP-3010 Service Panel Hinge TP-3235 Valve Coil Main Cord (24VRAC)

TP-3011 Igniter Box TP-3240 Natural Gas Valve Assembly

TP-3012 Igniter Box Cover TP-3241 Propane Gas Valve Assembly

TP-3014 Plastic Air Orifice with Screen TP-3250 Circuit Board - Modulating Controller

TP-3015 Fan Blower Assembly (PSC Motor) TP-3254 Wire Harness for Modulating Controller

TP-3025 120VAC Coil Relay TP-3260 4 1/2” Pneumatic Tube (Qty 3)

TP-3015 Fan Blower Assembly (PSC Motor) TP-3261 10” Pneumatic Tube (Qty 2)

TP-3025 120VAC Coil Relay TP-3380 16” HSI Burner Tube w/ Flange and Fittings

* 200,000 BTU/h models only.

27

Kit Contents Check List

MP Series Kit Contents Check List

MP Series Kit Contents - Reference the length column for your model.

TP-19B 4” Hanger

with Tension Spring

TP-82 4” Reflector

Center Support (RCS)

TP-33B 1/2” Shut-

Valve & Inlet Tap)

Off Valve (Ball

TP-3228

Terminal

Connector A

TP-106

Reflector

End Cap Clips

MP Series

TP-3220

Thermostat

Wire Grommet

TP-3225

**TP-19C

FC-36 36” x 3/4”

Stainless Steel

Flexible Gas

Connector

Part No. Description 25 ft. 30 ft. 40 ft. 50 ft. 60 ft. 70 ft.

FC-36 36” x 3/4” S.S. Flexible Gas Connector 1 1 1 1 1 1

TP-19B 4” Hanger w/ Tension Spring 3 4 5 6 7 8

TP-21B 4” Tube Clamp 2 3 4 5* 6* 7*

TP-33B 1/2” Shut-Off Valve & Inlet Tap 1 1 1 1 1 1

TP-82 4” Reflector Center Support 2 3 4 5 6 7

TP-105 Reflector End Cap 2 2 2 2 2 2

TP-106 Reflector End Cap Clips 8 8 8 8 8 8

TP-3220 Thermostat Wire Grommet 1 1 1 1 1 1

TP-3224 Terminal Strip Connector ‘C’ 1 1 1 1 1

TP-3225 Terminal Strip Connector ‘B’ 1 1 1 1 1

TP-3228 Terminal Strip Connector ‘A’ 1 1 1 1 1

LIOGT3 V3 General Tube Heater Manual 1 1 1 1 1 1

LIOMP MP Series Insert Manual 1 1 1 1 1

**TP-829

TP-21B 4” Tube Clamp

**TP-220

TP-105 Reflector

End Cap

**TP-105A

Terminal

Connector B

TP-3224

Terminal

Connector C

General Manual and

MP Series Insert

F/N: LIOGT3 & LIOMP

MP Series

Tube Heater

General Manual

Insert Manual

1

1

1

1

Filled By:

* NOTE: One 4” stainless steel tube clamp (P/N: TP-220) is provided for each 200,000 BTU/h model.

Place as shown on Page 17.

** Part number for models upgraded with stainless steel options.

Approvals

• CSA.

• Indoor approval.

• Outdoor approval with OD-Kit.

• Commercial approval.

Phone: [phone] Fax: [phone]

Printed in U. S. A.

www.detroitradiant.com • [e-mail]

Limited Warranty

• 1 year - Burner box components.

• 5 years - Combustion and radiant tubes.

• 10 years - Stainless steel burner.

• See Page 36 of the General Tube Heater Manual
for terms and conditions.

© 2012 Detroit Radiant Products Co.

21400 Hoover Road • Warren, MI 48089

28
