Standard Series
STEREO SPEAKERS
USER’S MANUAL
MODERN SOUND FOR YOUR CLASSIC
www.retromanufacturing.com
Page 2
TABLE OF CONTENTS
WELCOME 2
PRECAUTIONS 3
INSTALLATION INSTRUCTIONS 4
SPECIFICATIONS 6
LIMITED WARRANTY 7
INSTALLATION NOTES 8
The information enclosed in this manual is to be used as a guide to
assist you with installation and operation of your speakers. This guide
does not cover every installation possibility, vehicle, or every aspect
of the installation process.
Retro Manufacturing, LLC, or its subsidiaries, assume no responsibility
for any installation. This manual may be updated from time to time.
Visit our website for the latest version:
www.retromanufacturing.com.
1
Page 3
WELCOME
Thank you for purchasing RetroSound®
Standard-Series Stereo Speakers.
RetroSound® Stereo Speakers
• Standard magnet structure for thin
design and high power handling
• Treated foam surround for smooth, natural sound
®
• Mylar
• Poly cone for accurate mid-bass
• Dip-cut back plate for extended pole piece excursion
RetroSound
sound quality. A standard magnet structure ensures high
power handling capability and excellent bass response.
They use treated foam surrounds for a smooth, natural midbass response and exceptional durability in the automotive
environment. Mylar® tweeters produce crisp, clear, natural
high frequencies. The back plate is dip-cut, which enables
extended pole piece excursion for high output.
tweeters for crisp, clear highs
®
standard-series stereo speakers offer outstanding
Copyright 2016 Retro Manufacturing, LLC
2
Page 4
PRECAUTIONS
Precautions
It is best to consult a professional installation
specialist to help with your installation.
Prior to installation, always follow these rules:
• Carefully read and understand the instructions
before attempting installation.
• Always disconnect the negative (-) battery
terminal. Failure to do so may result in
damage to the unit, re, injury or death.
• Use high quality connectors to prevent
re or damage to the unit.
• Check the installation area before drilling. Make sure
you won’t drill into the gas tank, fuel lines, brake lines,
hydraulic lines, vacuum lines or electrical wiring.
• Never run wires underneath the vehicle.
• Avoid running wires over sharp edges. Use rubber
grommets to protect any wires routed through metal.
3
Page 5
INSTALLATION INSTRUCTIONS
The following tools may be needed for installation
of your RetroSound® speakers
• #2 Phillips screwdriver
• Battery post wrench
• Hand held drill with assorted bits
• Wire strippers
• Wire crimpers
• Wire cutters
Included in your box are two speakers, speaker wires,
speaker grilles (some models) and mounting screws.
Before installation, disconnect the negative (-) battery
terminal to prevent damage to your system.
Mounting
1. Run speaker wires before installing your speakers.
Avoid sharp edges that could fray or cut the wiring.
Use rubber grommets to protect any wires that need to
be routed through metal. Use high quality connectors to
minimize signal loss. Never run wires outside the vehicle.
2. Determine the area where the speakers are to be
mounted. Ensure that the area is large enough to
accommodate the entire speaker diameter and
that there is enough mounting depth for the speaker
magnet. If you are mounting your speakers in the
doors, check all door functions (windows, door
locks, etc) through their entire range of motion
to ensure the speaker will not obstruct them.
Copyright 2016 Retro Manufacturing, LLC
4
Page 6
INSTALLATION INSTRUCTIONS
3. If you are cutting speaker holes, refer
to the specication chart to determine
the nominal mounting diameter.
4. Using the speaker grille as a template, mark
the locations for the speaker mounting screws.
Drill the holes with a 1/8-inch drill bit.
5. Feed the speaker wires through the opening and
connect to the speaker terminals. Take care to connect
the negative wire to the negative (-) speaker terminal,
and positive to the positive (+) speaker terminal.
6. Fit the speaker into the cutout. Fit the grille over the
speaker. Mount them using the enclosed screws.
Tighten until the speaker is snug and in place to
prevent rattling. Do not overtighten screws.
5
Page 7
SPECIFICATIONS
MODEL S-42 S-52 S-412 S-692
Nominal Diameter (inch) 4 5.25 4x10 6x9
Description 2-Way 2-Way 2-Way 2-Way
Nominal Impedance 4ohm 4ohm 4ohm 4ohm
Frequency Response 65H-21kHz 50Hz-21kHz 43Hz-21kHz 40Hz-21kHz
Sensitivity (SPL@1w/1m) 88dB 87dB 87dB 90dB
Power Handling (watts RMS/peak) 25/50 25/50 25/50 50/100
Speaker Grille NO NO NO YES
Mounting Depth (inch) 1.4 1.7 2.3 3.1
Mounting Depth (mm) 36 44 59 79
*The above specications are subject to change without notice.
Copyright 2016 Retro Manufacturing, LLC
6
Page 8
LIMITED WARRANTY
If your unit does not work properly because of defects in materials or workmanship, Retro
Manufacturing, LLC (collectively referred to as “the warranter”) will, for the length of the
period indicated in the chart below, which starts with the date of original purchase (“warranty
period”), at its option either (a) repair your unit with new or refurbished parts, or (b) replace it
with a new or refurbished unit. The decision to repair or replace will be made by the warranter.
CATEGORIES PARTS LABOR
Speakers
During the “Labor” warranty period, there will be no charge for labor. During the “Parts”
warranty period, there will be no charge for parts. You must mail in your unit prepaid during
the warranty period. This warranty only applies to products purchased and serviced in the
United States or Puerto Rico. This warranty is extended only to the original purchaser of a new
product which was not sold “as is.” A purchase receipt or other proof of the original purchase
date is required for warranty service.
To handle a warranty issue, contact us at [email protected] or 888.325.1555 for
a Return Authorization number. All returns and warranty issues must be accompanied by a
Return Authorization (RA) number. Any product received without a RA number will be refused.
LIMITED WARRANTY-LIMITS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship. This warranty
ALSO DOES NOT COVER damages which occurred during shipment, failures which are caused
by products not supplied by the warranter, failures which result from accident, misuse, abuse,
neglect, pest infestation, mishandling, misapplication, alteration, faulty installation, set-up
adjustment, improper voltage, lightning strikes, maladjustment of consumer control, improper
maintenance, modication, commercial use or rental use of the product, or service by
anyone other than Retro Manufacturing, LLC, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY”. THE
WARRANTER IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS SYSTEM, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples,
this excludes damages for lost time, cost of having someone remove or re-install an installed
unit if applicable, travel to and from the servicer. The items listed are not exclusive, but are
for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specic legal rights and you may also have other rights which vary
from state to state. If a problem with this unit develops during or after the warranty period,
you may contact your dealer or Retro Manufacturing, LLC. Warranty only valid in U.S.A. and
Canada only.
One (1) Year One (1) Year
7
Page 9
INSTALLATION NOTES
Copyright 2016 Retro Manufacturing, LLC
8
Page 10
MODERN SOUND FOR YOUR CLASSIC
Retro Manufacturing, LLC, 7370 Eastgate Road, Suite 125 Henderson, NV 89011
p) 888.325.1555 | f) 702.483.2229 | www.retromanufacturing.com
