RT29
Two Way Radio
We are grateful that you chose our two way radio.
We believe this Two Way Radio will provide dependable
and reliable communication to personal operating at peak
efficiency. The transceivers incorporate the latest in
advanced technology. As a result, We feel strongly that
you will be pleased with the quality and features of this
product!
Two Way Radio
Before using this Two way radio, please read
the manual which contains important operating
instructions for safe usage, RF Energy Awareness,
control information and operational instructions
for compliance with RF Energy Exposure limits
in applicablenational and international standards,
and also read the operational instructions for safe use.
Unpacking and Checking Equipment
Supplied Accessories
Preparation
Use Li-ion Battery
Battery Characteristic
Charge Li-ion Battery
Install/Remove Battery Pack
Install/ Remove Antenna
Install/ Remove Belt Clip
Install Hand Strap
Getting Started
Basic Operation
State of Indicator light
Channel Switch
Power Switch/ Volume control
PTT Switch
Side key Definition
Squelch Level
Time-out Timer（TOT)
Scan Switch
Non-standard CTCSS self programming
Voice Prompt Selection
Battery Save Mode
Battery Voltage Prompt
Busy Channel Lockout
High/Middle/Low Output Power Selection
Wide/Narrow Bandwidth Selection
VOX
Frequency Read/Write Encryption
Scrambler Function
CTCSS/DCS
CTCSS(50)
DCS(116*2)
Technical Specifications
Warnings
01
01
02
03
03
03
04
05
05
05
06
08
08
08
08
08
08
09
10
10
11
11
12
12
12
12
13
13
14
14
14
15
15
17
18
UNPACKING AND CHECKING EQUIPMENT
We recommend that you open the packing box before use and
check carefully the main transceiver in the packing box and the
supplied accessories. If any item missed or damaged during
shipment, please contact the shipper or local dealer.
Supplied Accessories
Item
Antenna
Battery
Belt Clip
Adapter
Desktop Charger
Hand Strap
User's Manual
Antenna
Desktop Charger
Battery
Hand Stra p
Belt Clip Adapter
User's Manual
01
Notice:
·Do not charge the battery for a long time!
If battery is not fully charged within schedule time, stop
charging. Otherwise the battery may be overheat and smoke
and burst into fire.
·Do not throw the battery into micro-wave oven and highpressure
container!
·Prevent the break as well as liquid spilling battery from fire!
If the battery is spilling(or exuding smelly smell), put it away
from inflammable area. The electrolyte spilling from the battery
is easy to catch fire, and it will cause battery smokes or bursts
into fire suddenly.
·Do not use abnormal battery!
If battery smells smelly, different colors, out of shape or any
abnormal display, please remove the battery from charger or
operating device and do not use it .
·Please use standard charger
The charger supplied is specialized designed for this
transceiver only, it will charge the battery more scientific
reasonable, and safety.
Do not charge the battery for a long time!
1.Use Li-ion Battery
·Charge the battery before use.
·To prevent battery pack from discharging, please remove the
battery from transceiver or device when it is not in use, and then
store it in a cool dry place
·For battery long time storage
1. Remove the battery from device
2. If possible,discharge battery.
3. Store it in a cool(below 25℃) and dry place.
2.Battery Characteristic
·The capacity of battery will reduce step by step after being
charged and discharged again and again.
·Battery will be aged even without any usage.
·It will cost longer time to charge the battery in cool and dry place.
·Battery working life will be reduced if being charged in hotter
place. Battery ages more quickly when stored in hot place.
Please do not leave battery in car and put it near any heating
device.
· If battery working life becomes shorter, please replace it
even it is fully charged. If go on being charged and discharged,
the electrolyte will spill.
3.Charge Li-ion Battery
When charger is power on, put battery in and full connected, the
light will turn red, start charging. When battery has been fully
charged, the green light on.
02 03
4. Install/Remove Battery Pack
Note:
· Do not short circuit battery pack terminals or throw battery
pack into fire.
· Do not try to remove the battery pack shell.
· Do not install battery pack under dangerous conditions,
otherwise spark will cause explosion.
Insert the top part of the
battery pack into the top 2
slots of the transceiver and
then press the battery pack
down until a "click" sound is
heard.
To remove the battery pack,
make sure the transceiver has
been turned off, and then press
the battery released latch in the
bottom of transceiver, and pull
the bottom part of battery away
from the transceiver body, and
remove the battery.
5.Install Antenna
Hold the base of antenna,
rotate it tightly into the connector
of the top of transceiver clockwise.
6.Install/Remove Belt Clip
If necessary, install the supplied
screws into the belt clip at the back
of battery pack for easy carry.
To remove the belt clip, directly
remove the two screws only.
7.Install Hand Strap
Install the hand strap at the
middle circle of the transceiver.
04 05
Ante nna
Chan nel knob
Powe r/Volu me
swit ch
Stat us Indica tor
ligh t
Spea ker
(Out put sound )
Micr op ho ne
(Inp ut s ou nd)
PTT
S K1
S K2
SP/MIC/
Program Jack
(SP/MIC)
Battety Pack for
Charging the Radio
06 07
