The RT101 Plug-in Repeater Unit is designed to increase the
transmission range of your alarm system. The Repeater receives the
signal from a distant Transmitter (e.g. a PIR or Door/Window Sensor or
Remote Control, etc) and re-transmits the signal to your Receiver (e.g.
a Control Panel, Solar Siren, etc).
The Repeater Unit is suitable for use with any miGuard 433MHz Alarm
System.
Ideally, the Repeater Unit should be installed mid-way between the
Transmitting Device and the Receiver (Control Panel).
Description
RT101
User Manual
Plug-in Wireless
Signal Repeater
LED Indication
Gre en LED on: working status
Blue LED f las he s once: signal t ran sm itt in g
Gre en and bl ue LEDs f las h al terna tely: i n learn/delete mo de
Extend Transm iss io n Dista nce Bet ween Ac cesso ries and
Contro l Pane l
When the Re pe ate r Unit is in learn/delete mode, press the
learn/delete button , th en trigger a Wi re le ss Sen sor (e .g. press an y
butt on on the Remo te Con tr ol or trip the Sensor). The bl ue LED
ligh ts up for 2 s econd s and goe s off, then the Repeater Unit goes
back into learn/delete mode and the blue LEDs flash alternately. You
can repeat the above operation to add more accessories.
Extend Transm iss io n Dista nce Bet ween Co ntrol Panel and S iren
When the Re pe ate r Unit is in learn/delete mode, press the
learn/delete button . Press the ARM button on the G5 Control Panel, for
all other System Control Panels press the SOS Button, successful
connection of the Repeater Unit to the Contro l Pan el is made a f ter the
blue LED ligh ts u p for 2 s ec ond s and goe s off, and then the g reen
and bl ue LEDs f lash al te rnately.
Adding and Deleting Accessories
When a dd ing o r delet in g acc es sor ie s, the Repea ter Unit must be in
lear n/ delete mode . Fi rst ly, turn the s witch f ro m OFF to ON (if t he
Repeater is in O N mo de, swi tc h it to OFF f irs t an d the n switc h it t o
ON), t he R epeat er will e nter le arn/d elete mo de f or one min ute, as
indicated when the green an d blue LEDs fl ash in tu rn.
Specifications
Power Sup ply: AC 110 V-240V, 50/60 Hz
Wirele ss Trans mitti ng Rang e:≤300m
Wirele ss R ece iv ing Range:≤90m
Radi o Fr eq uency: 315MH z or 433M Hz (±75 KHz)
Stat ic C urrent:≤15.5 mA
Trans mit ti ng Curren t:≤1.1A
Maxi mu m Acc es sor ie s Suppo r tab le : 40 PC S
Back-u p Batte r y: 3. 7V 600m Ah Li th ium Bat ter y, 2.2 2Wh
Housin g Mater ial: AB S pla st ic
Oper at ion C on dition:
Tempe ra ture:-1 0°C ~ +55 °C
Relative Hu mi dit y:≤80% (non-co nd ens in g)
Dimension(L x W x H): 140x86x87mm
Appearance
Learn/Delete B utton
Power ON/ OFF
Inte r fac e for
Exte rna l Ant enna
Antenn a
Not e: For opti mum p erfo rmanc e exte nd the a nten na
Sign al tra ns mi tt in g
Wor kflow :
Sign al tra ns mi tt in g
Con tr ol Panel a rm/
dis ar m/ ala rm
Rep ea te r Unit
rec ei ves sig na l
Sir en re ceive s
sig na l
Max . di st anc e
(in o pe n are a)≤ 90m
Max . di st anc e
(in o pe n are a)≤ 300 m
Not e: I f th e Repe ater Unit ex its lea rn /de lete m ode , sw it ch of f an d th en sw itch on the
Rep ea te r to re -e nte r the learn/delete mod e. Then r ep eat the a bo ve o perat ion to ad d
mor e acc essor ies.
Deleti ng Accessori es
When the Re pe ate r Unit is in learn/delete mode, p ress a nd ho ld t he
learn/delete button f or 5 seco nds, the Re pe ate r Unit di sco nnect s
from all accessories afte r the blu e LE D light s up fo r 2 se conds and
goes off. Th en the gree n LED stays on.
Sign al tra ns mi tt in g
Wor kflow :
Sign al tra ns mi tt in g
Trigg er Sensor o r ac tiv at e
Remo te Contr ol
Con tr ol Panel
rec ei ves sig na l
Max . di st anc e
(in o pe n are a)≤ 90m
Max . di st anc e
(in o pe n are a)≤ 300 m
Rep ea te r Unit
rec ei ves sig na l
www.responseelectronics.com
Response Electronics Limited
Roman House, Lysons Avenue, Ash Vale, Surrey, GU12 5QF
email: info@responseelectronics.com
The product is guaranteed for one year from the date of purchase against faulty materials and
workmanship. No liability can be accepted for any problems caused by fair wear and tear,
buyer’s negligence, improper fitting or use, wilful or accidental damage, or any consequential
loss or damage howsoever caused. This guarantee does not affect your statutory rights and is
valid for UK and EIRE only.
If you believe the product to be faulty or in the unlikely event of the product developing a fault
during the warranty period, then please contact our Technical Support Team (contact details
shown below) for product assistance. Product repair or replacement will be offered for faulty
products only with our prior agreement. Should you need to return a product then:
1. Contact the Helpline on the number below to obtain a Return Authorisation Number
2. Return your product adequately packaged, ideally in its original packaging to prevent damage
in transit, and include the following:
a. A copy of your original invoice/receipt
b. A covering letter giving your full contact details, including email address (if applicable)
c. A description of the fault or problem
GUARANTEE
Disposal and Recycling
Disposal of this product is covered by the Waste Electrical or Electronic Equipment (WEEE)
Directive. It should not be disposed of with other household or commercial waste.
At the end of its useful life the packaging and product should be disposed of via a suitable
recycling centre. Please contact your local authority or the retailer from where the
product was purchased for information on available facilities.
lines open 0900 to 1700 Monday to Friday
“ whatever your question, we’re just a phone call away “
0345 257 1000
Customer Helpline
miGuard is a trademark of Response Electronics Limited
© copyright 2014 All rights reserved
MG-RT 101-1 433
