Page 1
Quick guide
ReSound LiNX 3D
™
MIH
Page 2
Product: ReSound LiNX 3D
Model: MIH
Serial number (R):
_______________________________
Serial number (L):
_______________________________
Battery size: 312 or 13
My hearing aid information
Volume control (C):
(if set up by your hearing care professional)
ACTION RESULT
Rotate forward
(toward your face)
Volume increases
Rotate backward
(away from your
face)
Volume decreases
PROGRAM WHEN TO USE BEEPS
1
1
2
2
3
3
4
4
Programs:
(if set up by your hearing care professional)
Page 3
Get to know your hearing aid
A
D
E
B
C
View ReSound hearing aid tutorial videos at youtube.com/resoundus.
A. Microphone
B. Battery door
C. Program button (optional)
D. Retrieval line
E. Vent
GN ReSound
XXXXXXXXXX
LTxMIH
G
H
I
F. Wax guard
G. Manufacturer
H. Serial number
I. Model
D
F
Page 4
Getting started: On/O function
ON: Insert battery & completely
close battery door (B).
Program 1 will be active.
OFF: Open the battery door (B).
Use fingertip to pull it all the way.
ON
OFF
What you need to know
Inserting/Replacing the battery:
1. Open the
battery door (B)
completely by
using your
fingertip.
2. Remove protective sticker from
battery and wait 2 minutes before
inserting the
battery into the
hearing aid to
allow full activation of the battery.
3. Insert the new battery
with the positive side
(flat side) in the correct
position, as shown.
4. Gently close the battery door (B).
If it doesn’t close easily, check to
see if the battery is upside down.
Page 5
Daily: Clean your hearing aid.
Keep your hearing aids dry. Clean
the hearing aids using a soft cloth
or tissue.
Monthly: Change the wax guard (F)
or see your hearing care professional.
For changing CeruSTOP™ (white) wax
guards, complete the following steps:
Removal: Insert the removal side
of the wax guard tool into the used
wax guard so that the shaft of the
tool is touching the rim of the wax
guard. Slowly pull the wax guard
straight out.
Regular care & maintenance
removal side replacement side
Wax guard tool
For changing HF3 wax guard (F),
complete the following steps:
1. Brush the sound
outlet area with
the sound outlet
pointed down.
2. Insert the threaded end of the wax
guard tool into the used wax guard,
and rotate clockwise.
3. Gently pull until
the used guard is
removed.
Insertion: To insert the new wax
guard, gently press the replacement
side of the wax guard tool straight
into the hole of the sound outlet until
the outer ring lies flush with the
outside of the receiver. Pull the tool
straight out. The new wax guard will
remain in place.
Page 6
4. Discard
the used
guard in
the slot
located
in the wax guard kit by pressing it
into the center, sliding it to one end
of the slot, and pull until the filter
is discarded.
5. Flip the wax guard
tool around, locate
a new guard in the
dial, and press the
tip of the tool into
the center of the dial.
6. Gently pull the new
filter out of the dial.
7. Press the new guard to the canal
tip of the hearing aid. Move the
tool gently side to side and pull it
away from the hearing aid.
400707011 Rev A 2017.02
ReSound Government Services
8001 E. Bloomington Freeway
Bloomington, MN 55420
1.800.392.9932
www.resound.com/veterans
Manufacturer according
to FDA:
ReSound North America
8001 E. Bloomington Freeway
Bloomington, MN 55420
1.888.735.4327
resound.com
Manufacturer according
to Health Canada:
ReSound Canada
303 Supertest Road
Toronto, Ontario M3J 2M4
1.888.737.6863
resound.com
For more information
Refer to the user guide included in
your hearing aid box.
Your hearing care professional can
be reached at:
View ReSound hearing aid tutorial
videos at youtube.com/resoundus.
Page 7
If there are any other problems not mentioned in this guide, please contact
ReSound or your hearing care professional.
SYMPTOM CAUSE POSSIBLE REMEDY
No sound Battery door not closed
Dead battery
Battery door will not close
Blocked wax guard
Turn on by closing the battery door (B)
Replace battery
Insert battery properly
Replace wax guard (F) or consult your
hearing care professional
Not loud
enough
Blocked sound outlet
Change in hearing, volume
too low
Excessive ear wax
Change wax guard (F) or consult your
hearing professional
Consult your hearing care professional
Consult your hearing care professional
Excessive
whistling/
feedback
Incorrect placement in ear
Excessive ear wax
If none of the above
Re-insert hearing aid carefully
Clean guard/consult your hearing
care professional
Consult your hearing care professional
Troubleshooting
View ReSound hearing aid tutorial videos at youtube.com/resoundus.
