Wireless
Security
Solutions
RE124GH Honeywell-to-GE Wireless Translator
Features
• Listens to Honeywell protocol wireless devices.
• Transmits GE protocol wireless.
• Enrolls up to 64 devices.
• Unique wireless ID (or loop) for each zone, plus 1 for main device.
• All alarm, supervisory and trouble signals are passed through.
• Dual antennas for both Receive and Transmit diversity for reliable range.
• Back-up battery operation.
• Complete supervision of tampers, external power supply fault and low
battery.
Key Instructions
• External supply: 9-18V AC or DC at least 50 mA.
• 3 AAA Alkaline batteries are for backup in case of external supply
failure.
• Enrolling:
Sensors
• Press Enroll switch until Device type LED matches
• Activate particular sensor
• Translator beeps and flashes red.
Main device enrolled by tamper switch on the board.
Operation
• Existing Honeywell protocol sensors transmit as usual. Translator passes
information on to control panel as if they were GE transmitters.
• Translator Main Zone wireless transmission ( unique ID):
Tamper, when cover opened.
Low battery, when either low AAA batteries, OR loss of AC.
Supervisory every hour.
• LED Operation
Green LED: On if AC power present.
Red LED: On if device tamper or device low battery
RE124GH_HNW-to-GE Wireless Translator.doc
Page 1 of 3 13-Nov-09
www.ResolutionProducts.com
Specifications
GE Device Type: 10 (Translator device ID).
Backup batteries: Three AAA Alkaline.
External supply: 9-18V AC or DC, at least 50mA.
Current draw with supply: 4mA, normal operation.
AC Fail Conditions: AC gone for 15 minutes. Restores on AC restore.
Device Low Battery Conditions: Low battery for 1 minute. Restores on
Back-up Battery Life on AC Fail: 72 hours.
Housing dimensions: 4x6x1 inches
Specifications subject to change without notice.
Internal Picture
device tamper, AC restore.
2 Antennas for:
Dual Diversity Receive and
Dual Diversity Transmit
Power Terminals
Device Type Indicator LEDs
Device Type select switch
Battery bucket for 3 AAAs
Tamper Switch & spring
Indicator LEDs & buzzer
Page 2 of 3 13-Nov-09
RE124GH_HNW-to-GE Wireless Translator.doc
www.ResolutionProducts.com
Notices
“GE”, “Honeywell”, and “DSC” are trademarks owned by General Electric Company,
Honeywell International Inc., and Tyco Safety Products Canada LTD, respectively.
Resolution Products, Inc. products will function with one of either GE, DSC or Honeywell
systems. However, no Resolution product is produced by, endorsed by, nor is officially
associated with GE, Honeywell or DSC. Resolution recommends verifying operation at
installation.
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may be received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the Resolution Engineering, Inc.
could void the user's authority to operate this equipment.
FCC ID: U5X-RE124HG
IC Notice
This product meets the applicable Industry Canada technical specifications/Le présent
materiel est conforme aux specifications techniques applicables d’Industrie Canada.
IC: 8310A-RE124HG
RE124GH_HNW-to-GE Wireless Translator.doc
Page 3 of 3 13-Nov-09
www.ResolutionProducts.com
