Resolution CryptiX, HeliPad RE656 Series Setup Manual

RE656 Series CryptiX™ HeliPad

™

HeliPad is an arming station that provides real-time

system status. It is battery powered and requires no
installation tools. A direct wireless link to Helix allows
for local control of the Helix control panel, regardless
of network connectivity.

Features

• E ink® display provides real-time status

• Non-mechanical capacitive touch interface

• Runs on user-replaceable AAA batteries

• 5 year warranty

Screw

Location

VHB Tape

Mounting

Plate

VHB Tape

Operate using the capacitive buttons, which click when

activated. Note, Arming buttons won’t click until they
are held for at least one second.

• Disarm by entering a valid 4-10 digit user
code on the number pad.

• Arm Away by pressing ARM AWAY
until HeliPad clicks.

• Arm Stay by pressing ARM STAY
until HeliPad clicks.

• Trigger a panic alarm by pressing ARM
STAY

& ARM AWAY together
until the display indicates a panic alarm.
HeliPad will click rapidly while buttons are
held.

Enroll by rst removing the battery pull tab. Then, press

MENU to enter the enrollment menu. Next, place
Helix control panel into wireless enrollment mode.
Finally, press SELECT to enroll HeliPad.

• Once enrolled, arm and disarm Helix to
verify HeliPad is within range of Helix and
properly enrolled.

Install on vertical surface using the 3M VHB

®

tape on the

back of the mounting plate.

• See Pro Tips for recommendations about
using VHB tape.

• A #4 or #6 screw may also be used, but
only in addition to the VHB tape. The tape
prevents HeliPad from rotating on the wall.

Use the Helix installation guide to verify proper system setup.

I

N

S

T

A

L

L

G

U

I

D

E

I

Home

Screen

Panel AC Status

AC OK

AC Removed

System Status

Arming Level

Disarmed

Armed Stay

Armed Night

Armed Away

Miscellaneous

Normal Display

Low Battery Warning

Helipad is receiving

new rmware from

control panel

Helipad rmware has

successfully updated

OK

Trouble

View system status using the icons

displayed on the home screen.

• Arming Level shows the
current arming level of the
system.

• Panel AC Status indicates
whether Helix has AC Power.

• System Status indicates
whether there are any
trouble conditions. Tap

MENU

to view trouble

conditions.

• Miscellaneous indicators are
sometimes displayed instead
of the dealer logo (e.g. low
battery, update in progress).

Silent Arming

On

Off

Entry Delay

On

Off

Night Arming

On

Off

Chime Mode

On

Off

Change arming settings and chime mode using the

quick settings tab. The quick settings tab is opened by
pressing SELECT .

Quick Settings Navigation

• Use

UP/DOWN to select a setting.

• Use SELECT

to enable/disable a setting.

• Use MENU

to close the quick settings.

Quick Settings Tips

• When night arming is enabled pressing ARM

STAY

will arm to NIGHT rather than STAY.

• The quick settings tab will automatically close
after roughly 5 seconds of inactivity.

Alarm status indications use the entire HeliPad screen. See examples below.

Change HeliPad settings using the extended menu. Hold MENU

until the HeliPad chirps three times (roughly 3 seconds) to open the
extended menu.

Extended Menu Navigation

• Use UP/DOWN

to select a setting.

• Use SELECT

to enable/disable a setting.

• Use MENU

is used to close the extended menu.

• You can use the menu item numbers as “Hot Keys” to

navigate or change a setting.

Extended Menu Tip

• Helix must be put into wireless enrollment mode before
unenrolling a HeliPad.

Extended Menu Items

* Enabling these settings will signicantly reduce battery life

1. Enrollment Opens the HeliPad enrollment menu

2. Poll Slow/Fast

*

Controls Helipad check-in interval

3. Entry Off/On

*

Enables/disables beeps during an entry delay

4. Exit Off/On

*

Enables/disables beeps during an exit delay

5. Btns Click/Beep Selects click or beep tone for button feedback

6. Sensitivity Opens the button sensitivity menu

7. Version Shows the hardware and rmware version

Pro Tips

3M VHB tape works great if the surface is properly prepared and rm pressure is

applied for over 10 seconds.

Surface Preparation

• Clean the surface

• Ensure the mounting surface is above 50 °F

To replace the batteries, pull the bottom thumb grip to remove the Helipad from the

mounting plate. Replace the batteries and install the HeliPad back onto the mounting
plate.

Status update delays are normal. It can take several seconds before status updates

are displayed on the HeliPad. Such delays are both normal and expected.

Normal Status Update Delays

• System State Changes can take 1 to 10 seconds

• Arming/Disarming can take 1 to 6 seconds

• Viewing Troubled Zones can take 1 to 6 seconds

Return directly to the Home Screen from any menu or status screen by holding

MENU until the HeliPad chirps three times.

Hold arming buttons until the HeliPad clicks (roughly 1 second). Conrm the system

has successfully armed before departing. You will know it has armed when the screen
shows arming/exit delay.

PHYSICAL

Housing Dimensions
Weight with Battery
Mounting Fastener

4.50 x 2.80 x 0.75 inches (11.4 x 7.1 x 1.9 cm)

4.0 ounces (113 grams)
3M VHB (Very High Bond) Tape or #4/#6 screw
(mounting screw not provided)

ENVIRONMENTAL

Operating Temperature
Maximum Humidity

32 to 120 °F (0 to 49 °C)
85% non-condensing relative humidity

SENSOR SPECIFICATIONS

Frequency
Replacement Battery
Nominal Battery Life
Battery Voltage
Current Draw
Transmitted Indications

2.4 GHz
Two Panasonic AAA (Alkaline)
1 year

3.0 VDC (Nominal), 2.3 VDC (Low)
70mA (Maximum), 70uA (Quiescent)
Low Battery, Supervision

CERTIFICATIONS

RE656
RE656-CE

UL1023, ULC1023, UL985, ULCS45-02, ETL, FCC, IC
EN 60950-1, EN 300 220, EN 301 489, CE, RCM

Specications

Specications subject to change without notice

47-0008-08 • REV C • 2016-09-21

Tech Support [phone]

www.ResolutionProducts.com

WARRANTY

Resolution Products, Inc. will replace products that are defective in

their rst ve (5) years.

IC NOTICE

This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference

that may cause undesired operation of the device.

Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.

IC: 8310A-RE656

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,

including interference that may cause undesired operation.

Changes or modications not expressly approved by the Resolution

Products, Inc. could void the user’s authority to operate this
equipment.

FCC ID: U5X-RE656

CE DECLARATION OF CONFORMITY

Hereby, Resolution Products, Inc. declares that this RE656-CE is
in compliance with the essential requirements and other relevant
provisions of directive 1999/5/EC.

(This declaration can be translated to other languages via a myriad
of translation tools found on the Internet.)
