Model E1 Zoom
Image Sensor 1/2.7" CMOS Sensor
Display Resolution 2560x1920 (5 Megapixels)
Lens f=2.8-8mm Autofocus, F=1.6, with IR Cut
Zoom 3X Optical Zoom
Horizontal: 48° - 98°
Vertical: 37° - 75°
Horizontal: 355°
Vertical: 50°
Minimum Illumination 0 Lux (with IR Illuminator)
IR Distance 12 Meters (40ft) (LED: 10pcs/14mil/850nm)
Dimension Φ80x111mm
Weight 250g
Power Input DC 5.0V/1A
Power Interface
Micro SD Card Slot
Built-in Microphone and Speaker
Reset Button
Protocols & Standards HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Image Compression H.264
Maximal Frame Rate 20fps
Code Rate 1024Kbps ~ 4096Kbps (Default: 4096Kbps)
Audio Two-Way Audio
Maximal User Access 20 Users (1 admin account & 19 user accounts); Supp ort up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
Browser Supported IE, Edge, Chrome, Firefox, Safari
OS Supported PC: Windows, Mac OS; Smartphone: iOS, Android
Record Mode Motion Recording
Alarm Siren; Customized Voice-Recordable Alerts
Works with Google Assistant; Reolink Cloud *available in some countries
Wireless Standard IEEE 802.11a/b/g/n
Operating Frequency 2.4/5 GHz
Wireless Security WPA-PSK/WPA2-PSK
Operating Temperature: -10°C~+55°C
Storage Temperature: -40°C~70°C
Operating Humidity: 20% ~ 85%
Storage Humidity: 10% ~ 90%
Waterproof No
E1-Zoom-IP-Camera-Specifications
Angle of View
Pan/Tilt Angle
Interface
Wireless
Features
Other
Parameters
Temperature
Humidity
Hardware
Features
Software
Features
