Renesas RSKM16C6NK User Manual

REG10J0017-0200
Renesas Starter Kit
RSKM16C6NK User’s Manual
RENESAS SINGLE-CHIP MICROCOMPUTER
M16C FAMILY
Rev.2.00 Renesas Technology Europe Ltd. Revision date:30.OCT.2007 www.renesas.com
i
Table of Contents
Chapter 1. Preface..................................................................................................................................................1
Chapter 2. Purpose.................................................................................................................................................2
Chapter 3. Power Supply........................................................................................................................................3
3.1. Requirements...............................................................................................................................................3
3.2. Power – Up Behaviour .................................................................................................................................3
Chapter 4. Board Layout.........................................................................................................................................4
4.1. Component Layout.......................................................................................................................................4
4.2. Board Dimensions........................................................................................................................................5
Chapter 5. Block Diagram.......................................................................................................................................6
Chapter 6. User Circuitry.........................................................................................................................................7
6.1. Switches.......................................................................................................................................................7
6.2. LEDs.............................................................................................................................................................7
6.3. Potentiometer...............................................................................................................................................7
6.4. Serial port.....................................................................................................................................................8
6.5. LCD Module..................................................................................................................................................8
6.6. Option Links..................................................................................................................................................9
6.7. Oscillator Sources ......................................................................................................................................15
6.8. Reset Circuit...............................................................................................................................................15
Chapter 7. Modes..................................................................................................................................................16
7.1. Boot mode...............................................................................................................................................16
7.2. Single chip mode ....................................................................................................................................16
Chapter 8. Programming Methods........................................................................................................................17
Chapter 9. Headers...............................................................................................................................................18
9.1. Microcontroller Headers.............................................................................................................................18
9.2. Application Headers ...................................................................................................................................20
Chapter 10. Code Development ...........................................................................................................................24
10.1. Overview...................................................................................................................................................24
10.2. Mode Support...........................................................................................................................................24
10.3. Breakpoint Support...................................................................................................................................24
10.4. Memory Map.............................................................................................................................................25
Chapter 11. Component Placement......................................................................................................................26
Chapter 12. Additional Information........................................................................................................................27
ii

Chapter 1. Preface

Cautions
This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas
Technology Europe Limited.
Trademarks
All brand or product names used in this manual are trademarks or registered trademarks of their respective companies or organisations.
Copyright
© Renesas Technology Europe Ltd. 2007. All rights reserved. © Renesas Solutions Corporation. 2007. All rights reserved. © Renesas Technology Corporation. 2007. All rights reserved. Website:
Glossary
CPU Central Processing Unit RTE Renesas Technology Europe Ltd. HEW High-performance Embedded Workshop RSO Renesas Solutions Organisation. LED Light Emitting Diode RSK Renesas Starter Kit PC Program Counter E8a E8a On-chip debugger module
http://www.eu.renesas.com/
1

Chapter 2. Purpose

This RSK is an evaluation tool for Renesas microcontrollers. Features include:
Renesas Microcontroller Programming.
User Code Debugging.
User Circuitry such as Switches, LEDs and potentiometer(s).
User or Example Application.
Sample peripheral device initialisation code.
The RSK board contains all the circuitry required for microcontroller operation.
2

Chapter 3. Power Supply

3.1. Requirements

This RSK operates from a 5V power supply. A diode provides reverse polarity protection only if a current limiting power supply is used. RSK boards are supplied with an E8a debugger module. This product is able to power the RSK board with up to 300mA. When the RSK is
connected to another system then that system should supply power to the RSK. All RSK boards have an optional centre positive supply connector using a 2.1mm barrel power jack.
Warning
The RSK is neither under nor over voltage protected. Use a centre positive supply for this board.

3.2. Power – Up Behaviour

When the RSK is purchased the RSK board has the ‘Release’ or stand alone code from the example tutorial code pre-programmed into the Renesas microcontroller. On powering up the board the user LEDs will start to flash. After 200 flashes, or after pressing a switch the LEDs will flash at a rate controlled by the potentiometer.
3

Chapter 4. Board Layout

4.1. Component Layout

The following diagram shows the top layer component layout of the board.
E8a Header
Figure 4-1: Board Layout
4

4.2. Board Dimensions

The following diagram gives the board dimensions and connector positions. All through hole connectors are on a common 0.1” grid for easy interfacing.
120.00mm
115.00mm
86.36mm
Short Board = 85 mm
50.80 mm
43.18 mm
35.56 mm
27.00mm
Corners x4
3mm
radius
SW1SW2SW
Other
E8
80.01mm
POT
3
JA2
Applies to connector
J1 -
with micriocontroller pin1
(LCD)
J2
(Expansion Bu s)
Application Header
Application Header
MCU
JA6
J4
RING
100.00mm
85.00mm
J3
Serial D9
SKT
45.00mm
R
JA4
E S
5.00mm
JA1
JA5
14.00mm
3.81mm
JA3
Figure 4-2 : Board Dimensions
5

Chapter 5. Block Diagram

Figure 5-1 is representative of the CPU board components and their connectivity.
Power Jack Option
LCD
Application Board
Headers
Microcontroller Pin
Headers
Debug Header Option
ADC Input
Serial Connector Option
Boot mode pins
Microcontroller
RESET pin
IRQ pin IRQ pin IRQ pin
RESn
Boot Circuitry
D-type latch
BOOT & BOOTn signals
Potentiometer
Figure 5-1: Block Diagram
Figure 5-2 is representative of the connections required to the RSK.
SW3SW2
SWITCHES
User: 4 LEDS
1Green, 1Orange, 2Red
LEDs
BOOT
Power: Green Boot: Orange
RES
Figure 5-2 : RSK Connections
6

Chapter 6. User Circuitry

6.1. Switches

There are four switches located on the RSK. The function of each switch and its connection are shown in Table 6-1.
Switch Function Microcontroller
RES When pressed the RSK microcontroller is reset. RESn SW1/BOOT* Connects to an IRQ input for user controls.
The switch is also used in conjunction with the RES switch to place the device in BOOT mode when not using the E8a module.
SW2* Connects to an IRQ line for user controls. INT1 Pin17
SW3* Connects to the ADC trigger input. Option link allows connection to
IRQ line. The option is a pair of 0R links.
Table 6-1: Switch Functions
*Refer to schematic for detailed connectivity information.
INT0 Pin18 (Port 8, pin 2)
(Port 8, pin 3) ADTRG Pin 98 (Port 9, pin 7)
OR INT2 Pin16 (Port 8, pin 4)

6.2. LEDs

There are six LEDs on the RSK board. The green ‘POWER’ LED lights when the board is powered. The orange BOOT LED indicates the device is in BOOT mode when lit. The four user LEDs are connected to an IO port and will light when their corresponding port pin is set low.
Table 6-2, below, shows the LED pin references and their corresponding microcontroller port pin connections.
LED Reference (As shown
on silkscreen)
LED0 Port 4.0 52 LED1 Port 4.1 51 LED2 Port 4.2 50 LED3 Port 4.3 49
Microcontroller Port Pin function Microcontroller Pin Number
Table 6-2: LED Port

6.3. Potentiometer

A single turn potentiometer is connected to AN0.0 (P10.0) of the microcontroller. This may be used to vary the input analogue voltage value to this pin between AVCC and Ground.
7

6.4. Serial port

The microcontroller programming serial port 1 is connected to the RS232 connector. A serial port can be used by moving option resistors and fitting the D connector. This can be connected to serial channel 1 if the E8a is disabled from using channel 1; or serial channel 0 while the E8a is enabled.
Description Function Fit For E8a Remove for
E8a
TxD1 Programming
Serial Port
RxD1 Programming
Serial Port
CLK1 Programming
Serial Port
If a serial port is used the D-connector U3 must be fitted and the RS232 transceiver enabled.
Description Function Fit For RS233
RS232 Transceiver
Disables/Enables U3 RS232
R13 R68 R69 R68 R68 R69, R13
R12 R44 R47 R44 R44 R47, R12
R14 NA NA NA NA R14
Table 6-3: Serial port connections
Remove for
Enable
R42 R39 R39 R42
RS233 Enable
Fit for
RS232
Channel 0
Remove for
Channel 0
Fit For RS233
Disable
RS232
Fit for
RS232
Channel 1
Remove for RS233 Disable
Remove for
RS232
Channel 1
Enable
An additional serial port is connected to the application headers.
Transceiver
Table 6-4: RS232 enable

6.5. LCD Module

An LCD module is supplied to be connected to the connector J11. This should be fitted so that the LCD module lies over J3. Care should be taken to ensure the pins are inserted correctly into J11.The LCD module uses a 4 bit interface to reduce the pin allocation. No contrast control is provided; this is set by a resistor on the supplied display module. The module supplied with the RSK only supports 5V operation.
Table 6-5 shows the pin allocation and signal names used on this connector.
8
J11
Pin Circuit Net Name Device
Pin
1 Ground - 2 5V Only ­3 No Connection - 4 DLCDRS 70 5 R/W (Wired to Write only) - 6 DLCDE 69 7 No Connection - 8 No Connection ­9 No Connection - 10 No Connection ­11 DLCD4 66 12 DLCD5 65 13 DLCD6 64 14 DLCD7 63
Table 6-5: LCD Module Connections
Pin Circuit Net Name Device
Pin

6.6. Option Links

Table 6-6 below describes the function of the option links associated with Power configuration. The default configuration is indicated by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R9 Board VCC
R32 Microcontroller
VCC1
R33 Microcontroller
VCC2
R25 Board VCC1 Board VCC1 connected to
R28 Board VCC1
R23 Board VCC1
R26 Board VCC2 Board VCC2 connected to
R29 Board VCC2
Supply to board from J5
Supply to microcontroller VCC1 Supply to microcontroller VCC2
Connector 3V3
Board VCC1 connected to Connector 5V Board VCC1 connected to Connector J5
Connector 3V3
Board VCC2 connected to Connector 5V
Fit Low ohm resistor to measure current Fit Low ohm resistor to measure current Fit Low ohm resistor to measure current
Disconnected
Disconnected R23,R25
Disconnected R25,R28
Disconnected
Disconnected R24,R26
R33
R32
R23,28
R24,29
R24 Board VCC2
Board VCC2 connected to Connector J5
Table 6-6: Power Configuration Links
9
Disconnected R26,R29
Table 6-7 below describes the function of the option links associated with Clock configuration. The default configuration is indicated by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R96 External Oscillator Connects External Ring header
pins to Microcontroller
R100 External Oscillator Connects External Ring header
pins to Microcontroller
R97 External Oscillator Parallel resistor for crystal R103 External Subclock
Oscillator
R105 External Subclock
Oscillator
R106 External Subclock
Connects External Ring header pins to Microcontroller
Connects External Ring header pins to Microcontroller
Parallel resistor for crystal
Oscillator
Table 6-7: Clock Configuration Links
Disconnects sensitive microcontroller signals from external pins. Disconnects sensitive microcontroller signals from external pins. Not fitted Disconnects sensitive microcontroller signals from external pins. Disconnects sensitive microcontroller signals from external pins. Not fitted
R100
R96
R105
R103
10
Table 6 -8 below describes the f unction of the option links associated with Serial configuration. The default configuration is indicated by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R14 Programming
Connects SCK to E8a
Serial Port
R12 Programming
Serial Port
R13 Programming
Serial Port
R44 Programming
Serial Port
R68 Programming
Serial Port
Connects E8a to Programming Serial port. Connects E8a to Programming Serial port.
Connects RS232 port to Programming SCI port Connects RS232 port to Programming SCI port
R42 RS232 Driver Enables RS232 Serial
Transceiver
R39 RS232 Driver
Disables RS232 Serial Transceiver
R41 Serial Connector Connects Alternate serial (CH2)
to D connector
SCK disconnected from E8a
MUST be removed if R44 fitted. R44
Should be removed if R68 fitted. R68
MUST be removed if R12, R47
R12, R47, R49
or R49 fitted. MUST be removed if R13, R69
R13, R69, R72
or R72 fitted. MUST be removed if R39
R39
Fitted
MUST be removed if R42 Fitted R42
Disconnects Alternate serial
R40
from D connector.
R40 Serial Connector Connects Alternate serial (CH2)
to D connector
R55 Alternate Serial Connects Alternate Serial (CH2
- SCIb) to RS232 Transceiver
R50 Alternate Serial Connects Alternate Serial (CH2
- SCIb) to RS232 Transceiver
R72 RS232 Serial on
Application Header
R49 RS232 Serial on
Application Header
R69 RS232 Serial on
SCIa CH0
R47 RS232 Serial on
SCIa CH0
Connects Application Header to RS232 Transceiver Connects Application Header to RS232 Transceiver Connects Serial Channel 0 to RS232 Transceiver Connects Serial Channel 0 to RS232 Transceiver
Table 6-8: Serial Configuration Links
Disconnects Alternate serial from D connector. Should be removed if SCIb not used for RS232. Should be removed if SCIb not used for RS232. MUST be removed if R68 or R69 fitted. MUST be removed if R44 or R47 fitted. MUST be removed if R68 or R72 fitted. MUST be removed if R44 or R49 fitted.
R41
R50
R55
R68, R69
R44, R47
R68, R72
R44, R49
11
Table 6-9 below describes the function of the option links associat ed with Analog configuration. The default configuration is indicate d by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R31 Analogue Power
Connects Board VCC1 supply to Analogue supply
Analogue supply MUST be provided from external interface
JA1,R43
pins. (Fit R43)
R43 Analogue Power Connects AVCC supply to
R31 must be fitted
R31
Application headers
R109 VREF
Connects Board VCC1 supply to VREF
VREF can be provided from external interface pins. (Fit
JA1,R110
R110)
R110 VREF VREF to Application headers
R109 should be fitted
R109
Table 6-9: Analog Configuration Links
Table 6-10 below describes the function of the option links associated with micro controller pin function select configuration. The default configuration is indicated by BOLD text.
12
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R82 Microcontroller pin
function select
R80 Microcontroller pin
function select
R78 Microcontroller pin
function select
R76 Microcontroller pin
function select
R114 Microcontroller pin
function select
R115 Microcontroller pin
function select
R60 Microcontroller pin
function select
R61 Microcontroller pin
function select
Connects microcontroller pin 28 to IICSDA
Connects microcontroller pin 28 to TXD2 pin
Connects microcontroller pin 27 to IICSCL
Connects microcontroller pin 27 to RXD2
Connects microcontroller pin 95 to ADPOT
Connects microcontroller pin 95 to AN0 Connects microcontroller pin 44 to Wrn pin
Connects microcontroller pin 44 to WRLn pin
MUST be removed if R80 fitted. R80
Should be removed if R82
R82 fitted. MUST be removed if R80 fitted. R76
Should be removed if R78
R78 fitted. MUST be removed if R115
R115 fitted.
Should be removed if R114
R114
fitted. MUST be removed if R61
R61
fitted.
Should be removed if R60 fitted. R60
R94 Microcontroller pin
function select
R93 Microcontroller pin
function select
R92 Microcontroller pin
function select
R90 Microcontroller pin
function select
R84 Microcontroller pin
function select
R83 Microcontroller pin
function select
R87 Microcontroller pin
function select
R85 Microcontroller pin
function select
Connects microcontroller pin 20 to TA4OUT pin
Connects microcontroller pin 20 to Up pin
Connects microcontroller pin 19 to TA4IN pin
Connects microcontroller pin 19 to Un pin
Connects microcontroller pin 26 to CLK2 pin
Connects microcontroller pin 26 to Vp pin
Connects microcontroller pin 24 to TA2OUT pin
Connects microcontroller pin 24 to Wp pin
MUST be removed if R93
R93 fitted. Should be removed if R94 fitted. R94
MUST be removed if R92
R90 fitted. Should be removed if R92 fitted. R92
MUST be removed if R83
R90
fitted.
Should be removed if R84 fitted. R92
MUST be removed if R85
R87 fitted. Should be removed if R87 fitted. R85
R88 Microcontroller pin
function select
R86 Microcontroller pin
function select
Connects microcontroller pin 23 to TA2IN pin
Connects microcontroller pin 23 to Wn pin
13
MUST be removed if R86
R86 fitted. Should be removed if R88 fitted. R88
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R128 Microcontroller pin
function select
R130 Microcontroller pin
function select
R118 Microcontroller pin
function select
R116 Microcontroller pin
function select
R131 Microcontroller pin
function select
R129 Microcontroller pin
function select
R117 Microcontroller pin
function select
R119 Microcontroller pin
function select
Connects microcontroller pin 47 to A21 pin
Connects microcontroller pin 47 to CS2N pin
Connects microcontroller pin 46 to A22 pin
Connects microcontroller pin 46 to CS1N pin
Connects microcontroller pin 90 to AN4 pin
Connects microcontroller pin 90 to CAN0 EN pin
Connects microcontroller pin 89 to AN5 pin
Connects microcontroller pin 89 to CAN0 STBn pin
MUST be removed if R130 fitted.
Should be removed if R128 fitted.
MUST be removed if R116 fitted.
Should be removed if R118 fitted.
MUST be removed if R129 fitted.
Should be removed if R131 fitted.
MUST be removed if R117 fitted.
Should be removed if R119 fitted.
R130
R128
R116
R118
R129
R131
R119
R117
R67 Microcontroller pin
function select
R66 Microcontroller pin
function select
R45 Microcontroller pin
function select
R46 Microcontroller pin
function select
Connects microcontroller pin 88 to AN6 pin
Connects microcontroller pin 88 to CAN1 EN pin
Connects microcontroller pin 87 to AN7 pin
Connects microcontroller pin 87 to CAN1 STBn pin
MUST be removed if R66
R66
fitted.
Should be removed if R67
R67 fitted.
MUST be removed if R46
R46
fitted.
Should be removed if R45 fitted. R45
Table 6-10: MCU Pin Function Select Configuration Links
Table 6-11 below describes the function of the o ption links asso ciated with other options. The default c onf iguration is indicated by BOLD
text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R35 SW3 Connects SW3 to Analogue
Disconnected
R34
Trigger input
R34 SW3
Connects SW3 to INT2 input
Disconnected R35
Table 6-11: Other Option Links
14

6.7.Oscillator Sources

A crystal oscillator is fitted on the RSK and used to supply the main clock input to the Renesas microcontroller. details theTable 6-12 oscillators that are fitted and alternative footprints provided on this RSK:
Component
Crystal (X1) Fitted 10MHz (HC/49U
package)
Subclock (X2) Fitted
Table 6-12: Oscillators / Resonators
32.768kHz (90SMX package)

6.8. Reset Circuit

The CPU Board includes a simple latch circuit that links the mode selection and reset circuit. This provides an easy method for swapping the device between Boot Mode, User Boot Mode and User mode. This circuit is not required on customers boards as it is intended for providing easy evaluation of the operating modes of the device on the RSK. Please refer to the hardware manual for more information on the requirements of the reset circuit. The Reset circuit operates by latching the state of the boot switch on pressing the reset button. This control is subsequently used to modify the mode pin states as required.
The mode pins should change state only while the reset signal is active to avoid possible device damage.
The reset is held in the active state for a fixed period by a pair of resistors and a capacitor. Please check the reset requirements carefully to ensure the reset circuit on the user’s board meets all the reset timing requirements.
15

Chapter 7. Modes

The RSK supports Boot mode and Single chip mode. Details of programming the FLASH memory is described in the M16C/6NK Group Hardware Manual.

7.1. Boot mode

The boot mode settings for this RSK are shown in Table 7-1: Boot Mode pin settings below:
CNVSS P5.0 P5.5
1 1 0
Table 7-1: Boot Mode pin settings
The software supplied with this RSK only supports Boot mode using an E8a and HEW. However, hardware exists to enter boot mode manually, do not connect the E8a in this case. Press and hold the SW1/BOOT. The mode pins above are held in their boot states while reset is pressed and released. Release the boot button. The BOOT LED will be illuminated to indicate that the microcontroller is in boot mode.
When neither the E8a is connected nor the board is placed in boot mode (with CNVSS and P5.5 being pulled low during reset) as above, the P5.5 pin is pulled high by a 10k resistor, the P.5.0 pin is pulled high by a 100k resistor and the CNVSS is pulled low by a 100k resistor.
When an E8a is used these three pins are controlled by the E8a.
LSI State after Reset
End
Boot Mode

7.2. Single chip mode

This RSK is configured to always boot in Single Chip mode when the E8a is not connected and the boot switch is not depressed as CNVSS is pulled down by a 100k resistor. Refer to M16C/6NK Group Hardware Manual for details of Single chip mode.
CNVSS P5.0 P5.5
0 1 1
Table 7-2: Single Chip Mode pin settings
LSI State after Reset
End
Single Chip Mode
16

Chapter 8. Programming Methods

The board is intended for use with HEW and the supplied E8a module. Refer to the M16C/6NK Group Hardware Manual for details of programming the microcontroller without using these tools.
17

Chapter 9. Headers

9.1. Microcontroller Headers

Table 9-1 to Table 9-4 show the microcontroller pin headers and their corresponding microcontroller connections. The header pins connect directly to the microcontroller pins
Pin Circuit Net Name Device
1 CAN1OUT 99 2 CAN1IN 100 3 DA1 1 4 DA0 2 5 TXD2 3 6 RXD2 4 7 CLK3 5 8 BYTE 6 9 E8_CNVSS 7 10 CON_XCIN 8 11 CON_XCOUT 9 12 RESn 10 13 CON_XOUT 11 14 GROUND 12 15 CON_XIN 13 16 UC_VCC1 14 17 NMIn 15 18 INT2 16 19 INT1 17 20 INT0 18 21 TA4IN_Un* 19 22 TA4OUT_Up* 20 23 CAN0IN 21 24 CAN0OUT 22
. * Marked pins are subject to option links.
J1
Pin Circuit Net Name Device
Pin
Pin
25 TA2IN_Wn 23 26 TA2OUT_Wp* 24 27 Vn 25 28 CLK2_Vp* 26 29 IIC_SCL_RXD2* 27 30 IICSDA_TXD2* 28
Table 9-1: J1
J2
Pin Circuit Net Name Device
Pin
1 PTTX 29 2 PTRX 30 3 PTCK 31 4 E8_BUSY 32 5 TXD0 33 6 RXD0 34 7 CLK0 35 8 CTSRTS 36 9 RDY 37 10 ALE 38 11 E8_EPM 39 12 UD 40 13 TRSTn 41 14 RDn 42 15 WRHn 43 16 WRLn_WRn 44 17 A23n_CS0n 45 18 A22_CS1n 46
Pin Circuit Net Name Device
Pin
19 A21_CS2n 47 20 A20_CS3n 48
Table 9-2: J2
18
J3
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 A19_LED3 49 2 A18_LED2 50 3 A17_LED1 51 2 A16_LED0 52 5 A15_IO7 53 6 A14_IO6 54 7 A13_IO5 55 8 A12_IO4 56 9 A11_IO3 57 10 A10_IO2 58 11 A9_IO1 59 12 UC_VCC2 60 13 A8_IO0 61 14 GROUND 62 15 A7_DLCD7 63 16 A6_DLCD6 64 17 A5_DLCD5 65 18 A4_DLCD4 66 19 A3 67 20 A2 68 21 A1_DLCDE 69 22 A0_DLCDRS 70 23 D15 71 24 D14 72 25 D13 73 26 D12 74 27 D11 75 28 D10 76 29 D9 77 30 D8 78
Table 9-3: J3
J4
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 D7 79 2 D6 80 3 D5 81 4 D4 82 5 D3 83 6 D2 84 7 D1 85 8 D0 86 9 AN7_CAN1STBn 87 10 AN6_CAN1EN 88 11 AN5_CAN0STBn 89 12 AN4_CAN0EN 90 13 AN3 91 14 AN2 92 15 AN1 94 16 AVss 94 17 ADPOT_AN0 96 18 CON_AVREF 96 19 CON_AVCC 97 20 ADTRG 99
Table 9-4: J4
19

9.2. Application Headers

Table 9-5 and Table 9-6 below show the standard application connections. * Marked pins are subject to option links.
JA1
Pin Generic Header Name RSK Signal
Name
1 Regulated Supply 1 5V 2 Regulated Supply 1 GROUND 3 Regulated Supply 2 3V3 4 Regulated Supply 2 GROUND 5 Analogue Supply AVcc 97 6 Analogue Supply AVss 94 7 Analogue Reference AVref 96 8 ADTRG ADTRG 98 9 ADC0 I0 ADPot_AN0* 95 10 ADC1 I1 AN1 93 11 ADC2 I2 AN2 92 12 ADC3 I3 AN3 91 13 DAC0 DA0 2 14 DAC1 DA1 1 15 IOPort A8_IO_0 61 16 IOPort A9_IO_1 59 17 IOPort A10_IO_2 58 18 IOPort A11_IO_3 57 19 IOPort A12_IO_4 56 20 IOPort A13_IO_5 55 21 IOPort A14_IO_6 54 22 IOPort A15_IO_7 53 23 Interrupt IRQAEC D13_INT3 73 24 I²C Bus - (3rd pin) NC ­25 I²C Bus IIC_SDA* 28 26 I²C Bus IIC_SCL* 27
Device
Pin
Table 9-5: JA1 Standard Generic Header
Pin Header Name RSK Signal
Name
Device
Pin
JA2
Pin Header Name RSK Signal
Name
1 Reset RESn 10 2 External Clock Input EXTAL ­3 Interrupt NMIn 15 4 Regulated Supply 1 Vss1 5 SPARE - - 6 Serial Port TxD0 33 7 Interrupt INT0 18 8 Serial Port RxD0 34 9 Interrupt INT1 17 10 Serial Port CLK0 35 11 Motor control UD 40 12 Serial Port Handshake CTSRTS 36 13 Motor control Up* 20 14 Motor control Un* 19 15 Output Vp* 26 16 Motor control Vn 25 17 Input Wp* 24 18 Motor control Wn* 23 19 Output TA2OUT* 23 20 Output TA4OUT 20 21 Input TA2IN* 20 22 Input TA4IN 19 23 Open drain INT2 16 24 Tristate Control TRSTn 41 25 SPARE - 26 SPARE -
Device
Pin
Pin Header Name RSK Signal
Name
Device
Pin
Table 9-6: JA2 Standard Generic Header
20
Table 9-7 to Table 9-9 below show the optional generic header connections. * Marked pins are subject to option links.
JA3
Pin Header Name RSK Signal
Name
Device
Pin
Pin Header Name RSK Signal
Name
Device
Pin
1 A0 A0 70 2 A1 A1 69 3 A2 A2 68 4 A3 A3 67 5 A4 A4 66 6 A5 A5 65 7 A6 A6 64 8 A7 A7 63 9 A8 A8 61 10 A9 A9 59 11 A10 A10 58 12 A11 A11 57 13 A12 A12 56 14 A13 A13 55 15 A14 A14 54 16 A15 A15 53 17 D0 D0 86 18 D1 D1 85 19 D2 D2 84 20 D3 D3 83 21 D4 D4 82 22 D5 D5 81 23 D6 D6 80 24 D7 D7 79 25 RDn RDn 42 26 WRn WRn 44 27 CSan A23_CS0n 45 28 CSbn CS1n 46 29 D8 D8 78 30 D9 D9 77 31 D10 D10 76 32 D11 D11 75 33 D12 D12 74 34 D13 D13 73 35 D14 D14 72 36 D15 D15 71 37 A16 A16 52 38 A15 A15 51 39 A18 A18 50 40 A19 A19 49 41 A20 A20 48 42 A21 A21 47 43 A22 A22 46 44 SDCLK --- --­45 CScn CS2n 47 46 ALE ALE 38 47 HWRn WRHn 43 48 LWRn WRLn 44 49 CASn --- --- 50 RASn --- ---
Table 9-7: JA3 Optional Generic Header
21
JA5
Pin Header Name RSK Signal
Name
Device
Pin
Pin Header Name RSK Signal
Name
Device
Pin
1 ADC4 I4 AN4* 90 2 ADC5 I5 AN5* 89 3 ADC6 I6 AN6* 88 4 ADC7 I7 AN7* 97 5 CAN CAN0OUT 22 6 CAN CAN0IN 21 7 CAN CAN1OUT 99 8 CAN CAN1IN 100 9 Reserved 10 Reserved 11 Reserved 12 Reserved 13 Reserved 14 Reserved 15 Reserved 16 Reserved 17 Reserved 18 Reserved 19 Reserved 20 Reserved 21 Reserved 22 Reserved 23 Reserved 24 Reserved
Table 9-8: JA5 Optional Generic Header.
JA6
Pin Header Name RSK Signal
Name
Device
Pin
Pin Header Name RSK Signal
Name
Device
Pin
1 DMA --- --- 2 DMA DACK -­3 DMA --- --- 4 Standby (Open drain) STBYn --­5 Host Serial SCIdTX RS232TX --- 6 Host Serial SCIdRX RS232RX --­7 Serial Port RXD2* 27 8 Serial Port TxD2* 28 9 Serial Port Synchronous TXD3* 3 10 Serial Port CLK2 26 11 Serial Port Synchronous CLK3 5 12 Serial Port Synchronous RxD3* 4 13 Reserved 14 Reserved 15 Reserved 16 Reserved 17 Reserved 18 Reserved 19 Reserved 20 Reserved 21 Reserved 22 Reserved 23 Reserved 24 Reserved 25 Reserved 26 Reserved
Table 9-9: JA6 Optional Generic Header
22
Table 9-10 below shows the CAN connections
J14
Pin Function Signal Name Device Pin
1 CAN0 Positive CAN0H 21 2 GROUND 3 CAN0 Negative CAN0L 22
J15
Pin Function Signal Name Device Pin
1 CAN1 Positive CAN1H 100 2 GROUND 3 CAN1 Negative CAN1L 99
Table 9-10: CAN Headers
23

Chapter 10. Code Development

10.1. Overview

Note: For all code debugging using Renesas software tools, the RSK board must be connected to a PC USB port via an E8a. An E8a is supplied with the RSK product.

10.2. Mode Support

HEW connects to the Microcontroller and programs it via the E8a. Mode support is handled transparently to the user.

10.3. Breakpoint Support

HEW supports breakpoints on the user code, both in RAM and ROM. Double clicking in the breakpoint column in the code sets the breakpoint. Breakpoints will remain unless they are double clicked to remove
them.
24

10.4. Memory Map

Figure 10-1: Memory Map
25

Chapter 11.Component Placement

Figure 11-1: Component Placement
26

Chapter 12. Additional Information

For details on how to use High-performance Embedded Workshop (HEW, refer to the HEW manual available on the CD or from the web site.
For information about the M16C/6NK series microcontrollers refer to the M16C/6NKGroup Hardware Manual For information about the M16C/6NK assembly language, refer to the M16C SeriesSoftware Manual.
Online technical support and information is available at:
Technical Contact Details America: Europe: Japan:
General information on Renesas Microcontrollers can be found on the Renesas website at:
techsupport.rta@renesas.com tools.support.eu@renesas.com csc@renesas.com
http://www.renesas.com/renesas_starter_kits
http://www.renesas.com/
27
Renesas Starter Kit for M16C/6NK User's Manual Publication Date Rev.02.00 30.OCT.2007
Published by:
Renesas Technology Europe Ltd.
Duke’s Meadow, Millboard Road, Bourne End Buckinghamshire SL8 5FH, United Kingdom
©2007 Renesas T e chnology Europe and Renesas Solutions Corp., All Rights Reserved.
Renesas Starter Kit for M16C/6NK
User's Manual
Renesas Technology Europe Ltd.
Duke’s Meadow, Millboard Road, Bourne End
Buckinghamshire SL8 5FH, United Kingdom
Loading...
