PROM Programming Adapters for M16C/60 Series
User's Manual
Rev. 1.00 July 1, 2003 REJ10J0193-0100Z
• R4945 and R4945A are trademarks of Advantest Corporation.
• Renesas Technology Corporation and Renesas Solutions Corporation put the maximum effort into making semiconductor products better and more reliable, but there is always the possibility that trouble may occur with them. Trouble with semiconductors may lead to personal injury, fire or property damage. Remember to give due consideration to safety when making your circuit designs, with appropriate measures such as (i) placement of substitutive, auxiliary circuits, (ii) use of nonflammable material or (iii) prevention against any malfunction or mishap.
• These materials are intended as a reference to assist our customers in the selection of the Renesas Technology product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corporation, Renesas Solutions Corporation or a third party.
• Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage, or infringement of any third-party's rights, originating in the use of any product data, diagrams, charts, programs, algorithms, or circuit application examples contained in these materials.
• All information contained in these materials, including product data, diagrams, charts, programs and algorithms represents information on products at the time of publication of these materials, and are subject to change by Renesas Technology Corporation and Renesas Solutions Corporation without notice due to product improvements or other reasons. It is therefore recommended that customers contact Renesas Technology Corporation, Renesas Solutions Corporation or an authorized Renesas Technology product distributor for the latest product information before purchasing a product listed herein. The information described here may contain technical inaccuracies or typographical errors. Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage, liability, or other loss rising from these inaccuracies or errors. Please also pay attention to information published by Renesas Technology Corporation and Renesas Solutions Corporation by various means, including the Renesas home page (http://www.renesas.com).
• When using any or all of the information contained in these materials, including product data, diagrams, charts, programs, and algorithms, please be sure to evaluate all information as a total system before making a final decision on the applicability of the information and products. Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage, liability or other loss resulting from the information contained herein.
• Renesas Technology semiconductors are not designed or manufactured for use in a device or system that is used under circumstances in which human life is potentially at stake. Please contact Renesas Technology Corporation, Renesas Solutions Corporation or an authorized Renesas Technology product distributor when considering the use of a product contained herein for any specific purposes, such as apparatus or systems for transportation, vehicular, medical, aerospace, nuclear, or undersea repeater use.
• The prior written approval of Renesas Technology Corporation and Renesas Solutions Corporation is necessary to reprint or reproduce in whole or in part these materials.
• If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license from the Japanese government and cannot be imported into a country other than the approved destination. Any diversion or reexport contrary to the export control laws and regulations of Japan and/or the country of destination is prohibited.
• Please contact Renesas Technology Corporation or Renesas Solutions Corporation for further details on these materials or the products contained therein.
Keep safety first in your circuit designs!
Notes regarding these materials
• This product is a development supporting unit for use in your program development and evaluation stages. In mass-producing your program you have finished developing, be sure to make a judgment on your own risk that it can be put to practical use by performing integration test, evaluation, or some experiment else.
• In no event shall Renesas Solutions Corporation be liable for any consequence arising from the use of this product.
• Renesas Solutions Corporation strives to renovate or provide a workaround for product malfunction at some charge or without charge. However, this does not necessarily mean that Renesas Solutions Corporation guarantees the renovation or the provision under any circumstances.
• This product has been developed by assuming its use for program development and evaluation in laboratories. Therefore, it does not fall under the application of Electrical Appliance and Material Safety Law and protection against electromagnetic interference when used in Japan.
• This product is not qualified under UL or other safety standards and IEC or other industry standards. This fact must be taken into account when taking this product from Japan to some other country.
Renesas Tools Homepage http://www.renesas.com/en/tools
Precautions to be taken when using this product

Contents

1. Precautions for Safety.........................................................................................................4
1.1 Safety Symbols and Meanings ..............................................................................4
2. Introduction ........................................................................................................................6
2.1 Things to Check When Unpacking .......................................................................6
3. How to Write the Program .................................................................................................7
3.1 Programming Procedures ......................................................................................7
3.2 Attaching the Adapter to a PROM Programmer ...................................................8
3.3 Setting the Switch .................................................................................................9
3.4 Inserting an MCU into the Adapter.....................................................................10
3.5 Setting Programming Area..................................................................................12
3.6 Recommended PROM Programmers ..................................................................13
4. Specifications ...................................................................................................................14
4.1 Specifications ......................................................................................................14
4.2 Memory Maps .....................................................................................................15
5. Troubleshooting................................................................................................................17
5.1 Errors That Occur When Writing to PROM .......................................................17
(1) When Newly Purchased ...........................................................................17
(2) Previously Written Normally ...................................................................17
5.2 When MCUs Do Not Function Normally ...........................................................17
5.3 Other Precautions ................................................................................................18
(1) About the Recommended PROM Programmers ......................................18
(2) About Reading Out of Device Identification Code..................................18
5.4 How to Request for Support................................................................................18

1. Precautions for Safety

In both the user's manual and on the product itself, several icons are used to insure proper handling of this product and also to prevent injuries to you or other persons, or damage to your properties.
This chapter describes the precautions which should be taken in order to use this product safely and properly. Be sure to read this chapter before using this product.

1.1 Safety Symbols and Meanings

WARNING
CAUTION
IMPORTANT
In addition to the three above, the following are also used as appropriate.
If the requirements shown in the "WARNING" sentences are ignored, the equipment may cause serious personal injury or death.
If the requirements shown in the "CAUTION" sentences are ignored, the equipment may malfunction.
It means important information on using this product.
means WARNING or CAUTION.
Example: CAUTION AGAINST AN ELECTRIC SHOCK
means PROHIBITION.
Example: DISASSEMBLY PROHIBITED
means A FORCIBLE ACTION.
Example:
The following pages describe the symbols "WARNING", "CAUTION", and "IMPORTANT".
UNPLUG THE POWER CABLE FROM THE RECEPTACLE.
WARNING
Warning for Use Environment:
• This equipment is to be used in an environment with a maximum ambient temperature of 35˚C. Care should be taken that this temperature is not exceeded.
• Select the proper programming mode of the PROM programmer.
CAUTION
Caution to Be Taken for Modifying This Product:
• Do not disassemble or modify this product. Disassembling and modifying the product will void your warranty.
Cautions to Be Taken for This Product:
• Use caution when handling this product. Be careful not to apply a mechanical shock such as falling.
• Do not directly touch the connector pins of this product.
• Be careful with the static electricity when handling this product and MCUs.
When Not Using This Product for a Long Time:
(1) Attach the connector pins of this product to the conductive sponge. (2) Put it into a conductive polyvinyl, and keep it in the package case shipped from the factory. (3) Store it in the place where humidity and temperature are low and direct sunshine does not strike.
IMPORTANT
Note on This Product:
•We cannot accept any request for repair.
When Using This Product:
• Attach this product to the IC socket on the PROM programmer properly.
• Insert the MCU to the IC socket of this product properly.
•When opening and closing the IC socket of this product, be sure to keep it horizontal.
• Be sure to set the programming area as described in this user's manual.
• Do not use the PROM programmer's device identification code readout function.

2. Introduction

This product is a PROM programming adapter for the Renesas M16C/60 Series of 16-bit MCUs. The adapter is a tool that can be used to write programs into internal PROM of an MCU using a PROM programmer commercially available. This user's manual describes specifications of the PCA7412F­100, PCA7412L-100, PCA7412G-100 and PCA7413F-80 and how to use them.
Figure 2.1 shows the external view of the PROM programming adapter and its constituent parts.
Figure 2.1 External view of the programming adapter and its constituent parts

2.1 Things to Check When Unpacking

This product package consists of the following parts. Check to see that it contains all the parts shown in Table 2.1 below.
Table 2.1 Contents
PCA7412F-100
package
Main unit
Interface unit
Connector
User's
Manual
If any part is missing or there is any doubt about your product package, contact your local distributor.
PCA7412F-100
PCA7412B
PCA7476E (32-pin)
PROM Programming Adapters for M16C/60 Series User's Manual
PCA7412L-100
package
PCA7412L-100
(This manual)
PCA7412G-100
package
PCA7412G-100
PCA7412C
PCA7402E (32-pin)
PCA7413F-80
package
PCA7413F-80
PCA7412B
PCA7476E (32-pin)

3. How to Write the Program

This chapter describes how to write programs with a PROM programmer. For the operation of the PROM programmer, refer to the user's manual of the PROM programmer.

3.1 Programming Procedures

Follow these procedures (1) through (8) to write programs into the MCU.
(1) Read the program.
1) For M306V0EE, M306V2EE
• OSD ROM, internal ROM: offset (80000h) required
2) For M306XXEC
• Internal ROM: offset (C0000h) required
3) For other MCUs
• Internal ROM: offset (E0000h) required
Read the program into the PROM programmer.
(2) Attach the adapter to the PROM programmer. (See section 3.2)
(3) Set the JP1 switch. (See section 3.3)
(4) Insert the MCU into the adapter. (See section 3.4)
(5) Set the programming area. (See section 3.5)
*1
Set the MCU's programming area with the PROM programmer.
(6) Check to erase the programming area.
*2
Using the PROM programmer's erase check function, check whether data can be written into the MCU's programming area.
(7) Write the program into the MCU.
*2
Write the program into the programming area of the MCU using the PROM programmer.
(8) Check to verify the programming area.
*2
Check to verify the programming area of the MCU using the PROM programmer. Check whether the program is written into the MCU correctly.
Notes:
*1 Be sure to set the programming area. Otherwise the mode's shift to the programming mode may
not be performed successfully. The erase check function etc. may not also be performed completely.
*2 Some PROM programmers perform the steps (6) through (8) automatically.

3.2 Attaching Adapter to PROM Programmer

As shown in Figure 3.1, attach the pin No. 1 of the PROM programmer connector, PCA7402E or PCA7476E (standard-pitch 32-pin pin-header mounted) to the No.1 pin of the IC socket of the PROM programmer.
Be careful when attaching to the PROM programmer because an incorrect insertion can cause fatal damage to the MCU.
Figure 3.1 Attaching the adapter to a PROM programmer

3.3 Setting the Switch

The position of the JP1 and its default setting are shown in Figure 3.2. For how to set the switch, see Table 3.1.
Top view
Figure 3.2 Position of the JP1 switch
Table 3.1 Setting the JP1 switch
Group Example JP1
Other than M16C/6V M30612E4-XXXFP 1M
M16C/6V M306V2EEFP 4M
CAUTION
Cautions for Setting the Switch:
•Make the setting properly, because an incorrect setting can cause fatal damage to the MCU.
• Select the proper programming mode of the PROM programmer.
• An example setting shown in Figure 3.2 is also applied to the PCA7412L-100, PCA7412G-100, and PCA7413F-80.
•To use this product in M27C201 mode, set the JP1 switch to the 1M side.

3.4 Inserting an MCU into the Adapter

As shown in Figure 3.3, insert the MCU into the IC socket aligning the No. 1 pin. This also applies to the PCA7412L-100, PCA7412G-100, and PCA7413F-80.
Be careful when inserting the MCU because an incorrect insertion can cause fatal damage to the MCU.
Top view
Figure 3.3 Inserting an MCU
( 10 / 20 )
CAUTION
Caution to Be Taken for Handling an MCU:
• Do not touch the connector in the IC socket and the pins on the PROM programmer connector. Otherwise it can cause an electrical insulation failure because of dirt. When not using, attach the connector pins of this product to the conductive sponge as it was shipped from the factory.
Caution When Opening and Closing the IC Socket:
• When opening and closing the IC socket, hold the adapter horizontally as shown in Figure 3.4. Otherwise the inside of the IC socket may become damaged and cause an electrical insulation failure.
Side view
Figure 3.4 Opening the IC socket
( 11 / 20 )

3.5 Setting Programming Area

To write programs into the MCU, be sure to set the programming area. And also, specify a device by the PROM programmer. For programming areas and devices, see Tables 3.2 and 3.3.
Table 3.2 List of programming areas (other than M16C/6V)
MCU
Type name
M306XXE4
M306XXE8
M306XXEA
M306XXEC
Example
M30612E4FP
M30613E4TGP
M30600E8FP
N/A
M30610ECFP
ROM size
32 KB
64 KB
96 KB
128 KB
Table 3.3 List of programming areas (M16C/6V)
MCU
Type name
Example
M306V2EEFSM306VXEE
ROM size
OSD ROM
(128 KB)
Internal ROM
(192 KB)
PROM programmer
Device
M5M27C101
M5M27C201
PROM programmer
Device
M5M27C401
Programming
area
18000h--1FFFFh
10000h--1FFFFh
08000h--1FFFFh
20000h--3FFFFh
Programming
area
10000h--2FFFFh
50000h--7FFFFh
ROM area
of MCU
F8000h--FFFFFh
F0000h--FFFFFh
E8000h--FFFFFh
E0000h--FFFFFh
ROM area
of MCU
90000h--AFFFFh
D0000h--FFFFFh
CAUTION
When Setting a Programming Area:
• Specify a proper programming mode, because an incorrect setting can cause fatal damage to the MCU.
• The programming method for M5M27C101, M5M27C201 or M5M27C401 mode is the byte-programming method.
• The MCUs listed above are shown as examples. Therefore, some MCUs may not be available in the future.
( 12 / 20 )

3.6. Recommended PROM Programmers

The PROM programmers listed in Table 3.4 are recommended for the adapters. Using the actual products, we have verified that these PROM programmers can be used to write programs without problem. For the latest types of PROM programmers from Advantest, please contact the company to confirm whether it can be used for your product.
Table 3.4 Recommended PROM programmers
Manufacturer
Advantest
Corporation
Type name Programming voltage (Vpp)
R4945
R4945A
Device
M5M27C101 mode M5M27C201 mode M5M27C401 mode M5M27C101 mode M5M27C201 mode M5M27C401 mode
12.75 V
12.75 V
CAUTION
Regarding Recommended PROM Programmers:
• Specify the proper programming mode, because an incorrect setting can cause fatal damage to the MCU.
• The programming method for M5M27C101, M5M27C201 or M5M27C401 mode is the byte-programming method.
12.5 V
12.5 V
( 13 / 20 )

4. Specifications

4.1 Specifications

Tables 4.1 lists common specifications of the programming adapters, and Table 4.2 individual specifications.
Table 4.1 Common specifications
Operating clock frequency
Power supply
Main unit
Board
configuration
Interface unit
(PCA7412B or
PCA7412C)
Connector
(PCA7402E or
PCA7476E)
Table 4.2 Individual specifications
Product name
PCA7412F-100
Item
MCU
IC socket
Internal ROM type
8 MHz (Supplied by the ceramic oscillator mounted on the adapter)
Supplied from Vcc of the PROM programmer Board to insert a programmable MCU
(IC socket for MCU mounted on it) Interface board
(Connected by two rows of standard-pitch 18-pin connectors and two rows of standard-pitch 16-pin connectors to the upper and lower boards)
Board to connect to the PROM programmer (Standard-pitch 32-pin pin-header mounted)
Description
M16C/60 Series 100-pin QFP (100P6S-A) e.g. M30600E8FP
IC51-1004-814-6 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 100-pin LCC (100D0) e.g. M30600E8FS
IC51-1004-804 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 100-pin QFP (100P6Q-A) e.g. M30600E8GP
IC51-1004-809 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 80-pin QFP (80P6S-A) e.g. M30601E8GP
IC51-804-711 (made by Yamaichi Electronics Co. Ltd.)
EPROM
PCA7412L-100
PCA7412G-100
PCA7413F-80
MCU
IC socket
Internal ROM type
MCU
IC socket
Internal ROM type
MCU
IC socket
Internal ROM type
Note: As this product is designed to support the same packages of the M16C/60 Series, it is ready
for most of the products which will be introduced in the future.
( 14 / 20 )

4.2 Memory Maps

Figure 4.1 shows memory maps of the MCU (M306V0EE and M306V2EE) and the PROM programmer. Figure 4.2 shows memory maps of the other MCUs and the PROM programmer.
MCU
00000h
Unused area
8FFFFh 90000h
OSD ROM area AFFFFh B0000h
Unused area CFFFFh D0000h
Internal ROM area Programming area
FFFFFh 7FFFFh
PROM programmer
Offset: 80000h
00000h
Unused area
0FFFFh 10000h
OSD ROM area
2FFFFh 30000h
Unused area
4FFFFh 50000h
Figure 4.1 Memory maps (M306V0EE and M306V2EE)
( 15 / 20 )
00000h
MCU
PROM programmer
00000h
Unused area
YYYYYh
Internal ROM area Programming area
FFFFFh ZZZZZh
ROM areas
ROM size (byte) Address YYYYY Address XXXXX Address ZZZZZ
E4: About 32K F8000h 18000h 1FFFFh E8: About 64K F0000h 10000h 1FFFFh
EA: About 96K E8000h 08000h 1FFFFh
EC: About 128K E0000h 20000h 3FFFFh
Unused area
XXXXXh
Figure 4.2 Memory map (other MCUs)
( 16 / 20 )

5. Troubleshooting

The table below summarizes errors to be checked carefully before you determine them to be a fault.

5.1 Errors That Occur When Writing to PROM

(1) When Newly Purchased
Cause
Is the adapter attached to the correct position of the PROM programmer?
Programming adapter
PROM programmer
Contact failure
Is the switch on the PROM programmer set properly? Is the MCU attached to the correct position? Is the area specification set correctly? Is the correct device selected? The IC socket of the PROM programmer may be stained. The
socket needs replacing.
(2) Previously Written Normally
Cause
Is the adapter attached to the correct position of the PROM programmer?
Programming adapter
Is the switch on the PROM programmer set properly? Is the MCU attached to the correct position?
Remedy
Remedy
See page
8
9 10 12 13
-
See page
8
9 10
Is the area specification set correctly?
PROM programmer
Is the correct device selected? The IC socket of the PROM programmer may be stained. The
socket needs replacing.
Contact failure
The PROM programmer connector at which the PROM programmer is contacted may be stained. Clean it with alcohol, etc.

5.2 When MCUs Do Not Function Normally

If the program operates normally on the emulator, but when the MCU that has normally been written is attached the same program does not function normally.
(1) Is the offset address specified correctly when copying data into the PROM programmer? (2) In the emulator, NOPs are often inserted in the area where the program has not been read, therefore
the program happens to appear functioning normally even though it may have gone wild. Check your program again.
(3) The emulator and the actual MCU may differ in characteristics. Consult the user's manual of the
emulation pod to check for differences in characteristics again.
12 13
-
-
( 17 / 20 )

5.3 Other Precautions

(1) About the Recommended PROM Programmers
Not all PROM programmers available on the market can be checked to see if they function properly. There are several PROM programmers that we have verified to function properly. These products are listed as recommended PROM programmers in this user's manual. Other PROM programmers may also be used providing that you verified them to function properly.
Note: No matter which type of the PROM programmer you use, it is necessary to verify completion
of programming by executing screening, etc. that are stipulated for each MCU used.
(2) About Reading Out of Device Identification Code *
Please do not use the PROM programmer's device identification code readout function. Using this function may break down the MCU. The device identification code is included in EPROM
to indicate the manufacturer code and device code; it is not included in the MCU. *1 Depending on PROM programmer manufacturers, this may be referred to by another name (e.g.
ID code).

5.4 How to Request for Support

After checking this manual, fill in the following information and email to your local distributor. For prompt response, please specify the following information: (1) Contact address
• Company name
•Department
• Responsible person
• Phone number
• Fax number
• E-mail address
(2) Product information
• Name of the programming adapter
• Serial number
• Date of purchase
• Target MCU
• Symptoms (Fails blank check/Cannot write a program/Fails verification etc.)
• Detailed symptoms
• Frequency of the problem (2 out of 10 etc.)
•When did the problem start to occur? (Since purchase/Used to work correctly)
• Type name of the PROM programmer (Advantest R4945A etc.)
• Specified device when writing to PROM (M27C101 etc.)
•Specified programming area when writing to PROM
• Switch settings of the adapter when writing to PROM
1
( 18 / 20 )
PROM Programming Adapters for M16C/60 Series User's Manual
Rev. 1.00 July 1, 2003 REJ10J0193-0100Z
COPYRIGHT ©2003 RENESAS TECHNOLOGY CORPORATION AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED
Loading...
