Application Note Renesas Synergy™ Platform

NetX™ and NetX Duo™ DNS Client Module Guide

Introduction

This module guide will enable you to effectively use a m odul e i n your own design. Upon completion of this guide, you will be able to add this module to your own design, configure it correctly for the target application, and write code using the included application project code as a reference and an efficient starting point. References to more detailed API descripti ons and suggestions of other application projects t hat il l ust rat e more advanced uses of the module are included in t his document and should be valuable resources for creating more complex designs.

Domain Name System (DNS) is a distributed database containing the mapping between domain names and physical IP addresses. The database is refer red t o as “distributed” because no single entity on the Internet contains the complete mapping. An entity, called a DNS server, maintains a portion of the mapping. Numerous DNS servers exist on the Internet, each of which contains a subset of the database. DNS servers also respond to DNS client requests for domain name mapping information, only if the server has the requested mapping. The DNS client protocol for NetX and NetX Duo provides the application with se rvices to request mapping information from one or more D NS Servers.

Note: Except where noted, the NetX Duo DNS Client is identical to the NetX DNS Client in application set-

up and running of DNS queries. To set up the IP instance for IPv6 in NetX Duo, see the NetX Duo

Key elements related to the NetX and NetX Duo DNS Client module implementation on the Renesas Synergy Platform are provided. The primary focus is to add and configure the NetX and NetX Duo DNS Client Module to a Renesas Synergy Platform project. For details, see NetX™ Domain Name System (DNS)

Client User Guide for the Renesas Synergy™ Platform or NetX Duo™ Domain Name System (DNS) Cli en t User Guide for the Renesas Synergy™ Platform. These documents reside in the X-Ware™ Component Documents for Renesas Synergy™ zip available for download at the Renesas Synergy Gallery site

(www.renesas.com/synergy/software).

User Guide for the Renesas Synergy™ Platform.

Contents

1. NetX and NetX Duo DNS Client Module Features .................................................................... 2

2. NetX and NetX Duo DNS Client Module APIs Overview ........................................................... 3

3. NetX and NetX Duo DNS Client Module Operational Overview ................................................ 5

3.1 NetX and NetX Duo DNS Client Module Important Operat i onal Notes and Limitations ......................... 8

3.1.1 NetX and NetX Duo DNS Client Module Operational Notes ................................................................. 8

3.1.2 NetX and NetX Duo DNS Client Module Limitations ............................................................................. 9

4. Including the NetX and NetX Duo DNS Client Module in an Application ................................... 9

5. Configuring the NetX and NetX Duo DNS Client Module ........................................................ 10

5.1 Configuration Settings for the NetX DNS Client Lower-Lev el M odules ................................................ 11

5.2 NetX and NetX Duo DNS Client Module Clock Configurat ion .............................................................. 14

5.3 NetX and NetX Duo DNS Client Module Pin Configuration .................................................................. 14

6. Using the NetX and NetX Duo DNS Client Module in an Application ...................................... 14

7. The NetX and NetX Duo DNS Client Module Application Project ........................................... 15

8. Customizing the NetX and NetX Duo DNS Client Module for a Target Application ................ 17

9. Running the NetX and NetX Duo DNS Client Module Application Project .............................. 18

R11AN0178EU0101 Rev.1.01 Page 1 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

10. NetX and NetX Duo DNS Client Module Conclusion ............................................................... 20

11. NetX and NetX Duo DNS Client Module Next Steps ............................................................... 20

12. NetX and NetX Duo DNS Client Module Reference Information ............................................. 20

Revision History .............................................................................................................................. 22

1. NetX and NetX Duo DNS Client Module Features

• Optional creation of separate packet pool for DNS operations

• Support of Type A, AAAA, and NS DNS queries

• Support of CNAME, SRV, TXT, SOA, and MX DNS resource types

• Support for DNS cache for storing and retrieving ca ched DNS data

• High-level APIs for  Name and IP address lookup  Adding and removing DNS servers  Creating and deleting the DNS instance

• NetX DNS is compliant with the following RFCs:  RFC1034 Domain Names – Concepts And Facilities  RFC1035 Domain Names — Implementation And Specification  RFC1480 The US Domain  RFC 2782 A DNS RR for specifying the locat i on of services (DNS SRV)  RFC 3596 DNS Extensions to Support I P Version 6

Figure 1. NetX and NetX Duo DNS Client Module

R11AN0178EU0101 Rev.1.01 Page 2 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Function Name

Example API Call and Description

nx_dns_create

nx_dns_create(&my_dns, &my_ip, "My DNS");

Create a DNS Client instance.

nx_dns_delete

nx_dns_delete(&my_dns);

Delete a DNS Client instance.

nx_dns_packet_pool_set

nx_dns_packet_pool_set(&my_dns, &packet_pool);

Set the DNS Client packet pool.

nx_dns_get_serverlist_size

nx_dns_get_serverlist_size (&my_dns, 5);

Return the size of the DNS Client’s Server list.

nx_dns_info_by_name_get

nx_dns_info_by_name_get(&my_dns, “www.abc1234.com”,

Return IPv4 address, port querying on input host name.

nx_dns_ipv4_address_by_na

nx_dns_ipv4_address_by_name_get(&client_dns,(UCHAR

Look up the IPv4 address for the specified host name.

nx_dns_host_by_address_ge

nx_dns_host_by_address_get(&my_dns, IP_ADDRESS(192.2.2.10),

addresses).

nx_dns_host_by_name_get

nx_dns_host_by_name_get(&my_dns, “www.my_example.com”,

addresses).

nx_dns_server_add

nxd_dns_server_add(&my_dns, server_address);

(supports only IPv4).

nx_dns_server_get

nx_dns_server_get(&my_dns, 5, &my_server_address);

only IPv4 addresses).

nx_dns_server_remove

nx_dns_server_remove(&my_dns, IP_ADDRESS(202,2,2,13));

addresses).

nx_dns_server_remove_all

nx_dns_server_remove_all(&my_dns);

Remove all DNS Servers from the Client list.

nx_dns_cache_initialize

nx_dns_cache_initialize(&my_dns, &dns_cache, 2048);

Initialize a DNS Cache.

nx_dns_cache_notify_clear

nx_dns_cache_notify_clear(&my_dns);

Clear the DNS cache full notify function.

nx_dns_cache_notify_set

nx_dns_cache_notify_set(&my_dns, cache_full_notify_cb);

Set the DNS cache full notify function.

nx_dns_cname_get

nx_dns_cname_get(&client_dns, (UCHAR *)"www.my_example.com

Look up the canonical domain name for the input domai n nam e al ias.

2. NetX and NetX Duo DNS Cli ent Module APIs Overview

The NetX and NetX Duo DNS Client module defines A PIs for connecting, binding, listening, sending, an d receiving. A complete list of the available API s, an example API call, and a short description of each API can be found in the following table. The end of the summary table lists nx services unique to NetX and NetX Duo BSD. Following the API summary table is a list of status return values.

Table 1. NetX and NetX Duo DNS Client Module API Summary

&ip_address, &port,

200);

me_get

*)"www.my_example.com", record_buffer,sizeof(record_buffer),&record_count,500);

&resolved_name[0], BUFFER_SIZE, 450);

Look up a host name from a specified IP address (supports o nly IPv4

&ip_address, 4000);

Look up an IP address from the host name (supports only IPv4

Add a DNS Server of the specified IP address to the Client ’s Server list

Return the DNS Server in the Client list at the specif i ed i ndex (supports

Remove a DNS Server from the Client list (supports only IPv4

record_buffer, sizeof(record_buffer), 500);

R11AN0178EU0101 Rev.1.01 Page 3 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Function Name

Example API Call and Description

nx_dns_authority_zone_start

nx_dns_authority_zone_start_get(&client_dns, (UCHAR

name.

nx_dns_domain_name_serve

nx_dns_domain_name_server_get(&client_dns, (UCHAR *)"

nx_dns_domain_mail_exchan

nx_dns_domain_mail_exchange_get(&client_dns, (UCHAR *)"

Look up the mail exchange associated with the specified host name.

nx_dns_domain_service_ge

nx_dns_domain_service_get(&client_dns, (UCHAR

nxd_dns_ipv6_address_by_

nxd_dns_ipv6_address_by_name_get(&client_dns,

Look up the IPv6 address from the specified host name.

nxd_dns_host_by_address_

nxd_dns_host_by_address_get(&my_dns, &host_address,

nxd_dns_host_by_name_get

nxd_dns_host_by_name_get(&my_dns, “www.my_example.com”,

IPv6 addresses).

nxd_dns_server_add**

nxd_dns_server_add(&my_dns, &server_address);

nxd_dns_server_get**

nxd_dns_server_get(&my_dns, 5, &my_server_address);

both IPv4 and IPv6 addresses).

nxd_dns_server_remove**

nxd_dns_server_remove(&my_dns,& server_ADDRESS);

_get

r_get

ge_get

name_get**

*)"www.my_example.com", record _buffer, sizeof(record_buffer), &record_count, 500);

Look up the start of a zone of authority associated with the specified host

www.my_example.com ", record_buffer, sizeof(record_buffer), &record_count, 500);

Look up the authoritative name servers for the input domain zone

www.my_example.com ",record_buffer, sizeof(record_buffer), &record_count, 500);

*)“www.my_example.com ", record_buffer, sizeof(record_buffer), &record_count, 500);

Look up the service(s) associated with the specifie d host name.

(UCHAR *)"www.my_example.com", record__buffer, sizeof(record_buffer), &record_count, 500);

get**

Note: For details on operation and definitions of t he f unct i on data structures, typedefs, defines, API dat a,

API structures, and function variables, review the associated Express Logic User’s Manual listed in the References section.

**This API is only available in NetX Duo DNS Client. For definitions of of NetX Duo spe cif i c data types, see the NetX Duo User Guide for the Renesas Synergy™ Plat form.

resolved_name, sizeof(resolved_name), 4000);

Look up a host name from the input IP address (support s both IPv4 and IPv6 addresses).

&ip_address, 4000, NX_IP_VERSION_V4);

Look up an IP address from the input host name (supports both IPv4 and

Add the input DNS Server to the Client server list (supports both IPv4 and IPv6 addresses).

Return the DNS Server in the Client list at the specif i ed i ndex (supports

Remove a DNS Server of the specified IP address from the Client list (supports both IPv4 and IPv6 addresses).

R11AN0178EU0101 Rev.1.01 Page 4 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Name

Description

NX_SUCCESS

API Call Successful

NX_DNS_NO_SERVER

Client server list is empty

NX_DNS_QUERY_FAILED

No valid DNS response received

NX_DNS_NEED_MORE_RECORD_BUFFER

Input buffer size insufficien t to hold the minimum data

NX_PTR_ERROR*

Invalid IP or DNS pointer

NX_CALLER_ERROR*

Invalid caller of this service

NX_DNS_ERROR

Internal error in DNS Client processing

NX_DNS_PARAM_ERROR

Invalid non-pointer input

NX_DNS_CACHE_ERROR

Invalid Cache pointer

NX_DNS_TIMEOUT

Timed out on obtaining DNS mutex

NX_DNS_BAD_ADDRESS_ERROR

Null input address

NX_DNS_INVALID_ADDRESS_TYPE

Index points to invalid address type (e.g. I Pv6)

NX_DNS_IPV6_NOT_SUPPORTED

Cannot process record with IPv6 disabled

NX_NOT_ENABLED

Client not configured for this option

NX_DNS_DUPLICATE_ENTRY

DNS Server is already in the Client list

NX_NO_MORE_ENTRIES

No more DNS Servers allowed (list is full)

NX_DNS_SERVER_NOT_FOUND

Server not in client list

Table 2. Status Return Values

Note: Lower-level drivers may return common error codes. See SSP User’s Manual API References for the

associated module for a definition of all relevant status return values.

* These error codes are only returned if error checking is enabled. For details on error-checking

services, see NetX User Guide for the Renesas Synergy™ Platform or NetX Duo User Guide f or t he Renesas Synergy™ Platform in NetX and NetX Duo, respectively

3. NetX and NetX Duo DNS Client Module Operational Overview

DNS Messages

The NetX DNS Client module creates the IP instance, enables UDP services in NetX, and initializes the network driver while registering a valid IP address. The module creates an UDP socket for sending and receiving DNS messages to DNS servers listening on port 53 for DNS queries.

To obtain a mapping, the DNS client prepares a DNS query message containing the name or the I P address to be resolved. The message goes to the first D NS server in the server list. If the server has a mappin g, it replies to the DNS client using a DNS response message containing the requested mapping. If the server does not respond, the DNS client queries the next server on its list until all its DNS servers have been queried. If no response is received from all its DNS servers, the DN S client retransmits the DNS message starting back at the top of the server list. DNS queries are sent until the retransmission timeout expi res. Until a response is received, each iteration down the list of servers doubles the retransmission timeout until the maximum transmission timeout is reached. This timeout is set in the Maximum duration to retransmit a DNS query (seconds) property. The default value is 64 seconds; the maximum number of times the DNS client iterates down the server list, which is set by the Maximum retries for a server property and defaults to 3.

The typical NetX DNS Client queries are:

• IPv4 address lookups (type A) by using the nx_dns_host_by_name_get service.

• Reverse lookups of IP addresses (type PTR querie s) to obtain web host names using the

nx_dns_host_by_address_get service.

• IPv6 address lookups (type AAAA) or IPv4 address lookups (type A), specified in the IP address data type input, in the nxd_dns_host_by_name_get service. (This is only available in the NetX Duo DNS Client.)

• Reverse lookups of IP addresses (type PTR querie s) to obtain web-host names using the nxd_dns_host_by_address_get service. (This is only av ai labl e i n the NetX Duo DNS Client.)

R11AN0178EU0101 Rev.1.01 Page 5 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

The NetX Duo DNS Client module still supports nx_dns_host_by_name_get and nx_dns_host_by_address_get services. These are equivalent services, but they are limited to IPv4 networ k communication, so developers are encouraged to use the nxd_dns_host_by_name_get and nxd_dns_host_by_address_get services instead.

Extended DNS Resource Record Types

If the Extended RR types support property is enabled, t he Net X DNS Client module also supports the following record type queries:

CNAME contains the canonical name for an alias TXT contains a text string NS contains an authoritative name server SOA contains the start of a zone of authority MX used for mail exchange SRV contains information on the service offered by the domain

Except for CNAME and TXT record types, the application must su pply a 4-byte aligned buffer to receive the DNS data record.

In the NetX DNS Client module, the record data is stored to make efficient use of buffer space. The following example shows a record buffer of fixed length (type AAAA reco rd).

For queries whose record types have a variable data-length (such as NS records with variable-length host names), the NetX DNS Client module saves the data using the following methodology:

• Organizes the buffer supplied in the DNS Client query into fixed-length data and unstructu red memory areas.

• Organizes the top of the memory buffer into 4-byte aligned record entries.

• For each record entry, holds the IP address and a pointer to the variable-length data for that IP address.

• Stores variable-length data for each IP address in unstructured area memory starting at the end of the

memory buffer.

• Saves variable-length data for each suc cessive record entry in the next area of memory, adjacent to t he previous record entries’ variable data.

• ‘Grows’ the variable data towards the structured area of memory holding record entries until there is insufficient memory to store another record entry and variable data (see following figure).

R11AN0178EU0101 Rev.1.01 Page 6 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

The NetX DNS Client queries use the record storage format to return the number of records saved to the record buffer; this information enables the application to extract NS records from the record buff er. A fter calling the nx_dns_domain_service_get with the receive_buffer pointer to the storage space, the application extracts the SRV data sequential l y, taking advantage of the known size of the SRV entry:

NX_DNS_SRV_ENTRY *nx_dns_srv_entry_ptr[RECORD_COUNT];

status = nx_dns_domain_service_get(&client_dns, (UCHAR *)"www.my_example.com", &record_buffer[0], BUFFER_SIZE, &record_count, NX_IP_PERIODIC_RATE);

for(i =0; i< record_count; i++) { nx_dns_srv_entry_ptr[i] = (NX_DNS_SRV_ENTRY *)(record_buffer + i * sizeof(NX_DNS_SRV_ENTRY)); }

DNS Cache

If the Cache support property is enabled, the NetX DNS Client m odule supports the DNS cache feature. The application must set up the DNS cache using the nx_dns_cache_initialize service. When c aching is enabled, the DNS client checks the DNS cache resource recor ds bef ore sending a DNS query. If it finds the answer in the cache, it directly returns it to the application. Otherwise, it sends out a query message to a DNS server and waits for the reply. When the DNS client gets the response message, it adds a resource record to the cache, if there is a cache entry available.

Each cache entry is a data structure used to hold a resource record. String entries (resource record name and data) in resource records are variable length, and as such, are not stored directly in the resource record. Instead, the resource record sets a pointer to the act ual memory location in the cache where the strings a re stored. Strings and resource records share the cach e. Records are stored from the beginning of the cac he and grow towards the end of the cache. String entries start from the end of the cache and grow towards the beginning of the cache. Each string entry has a length field and a counter field. When a string entry is added to the cache, and the same string is already present in the table, the counter value is incremented, and no memory is allocated for the string. The cache is considered full if no more resource records or new string entries can be added to the cache.

R11AN0178EU0101 Rev.1.01 Page 7 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

3.1 NetX and NetX Duo DNS Client Module Important Operational Notes and

Limitations

3.1.1 NetX and NetX Duo DNS Client Module Operational Notes

The NetX DNS Client requires a packet pool for transmitting DNS messages; the packet pool must be before using DNS client services. This can either be the pac ket pool used by the IP instance (g_packet_pool0), or it can be a separate packet pool added to the project: X-ware -> NetX Duo -> NetX Duo Packet Pool Instance (or X-ware -> NetX -> NetX Packet Pool Instance in NetX DNS Client).

• If the Use application packet pool is disabled, the DNS Client application must create the packet pool when the DNS client is created, and then register it with t he DNS Client by calling the nx_dns_packet_pool_set service. The module guide project sets this project to enabled, so this is not necessary. The DNS Client shares the same packet pool with the IP instance.

• The Maximum DNS queries size property determines the si ze of the packet payload and defaults to 512 bytes.

• The Packets in DNS packet pool property sets the number of pa ckets in the DNS Client packet pool

Note: For user-created packet pools, the packet size holds the DNS maximum message size property. The

Before sending DNS queries, the application must add one or more DNS servers to the server list kept by the DNS client. The maximum server list size is set by the Maximum number of DNS Servers in the Client server list property.

To add a DNS server, the application can use either the nx_dns_server_add service (limited to IPv4 packets) or the nxd_dns_server_add service supporting IPv4 and IPv6 packets.

Note In the NetX Duo DNS Client, enabling the Client has DNS and Gateway Server property has no effect

(defaults to 6).

default message size is 512 bytes, plus room for the UDP header (8 byt es), IPv4 header (20 bytes), or IPv6 header (40 bytes), and the network frame header. The Ethernet frame header is rounded up to 16 bytes for 4-byte alignment. This user-created packet pool is onl y used to send DNS packets. The IP packet pool is set to a 1568-byte packet paylo ad. This packet pool setting works best for the Synergy network driver and the device MTU (typically, 1518 bytes), and it also avoids the need to chain packets in the driver layer.

in the SSP 1.2.0 and earlier. When the DNS client is created, the IP instance does not have a router/gateway address set. Therefore In the NetX DNS Client, the Client has Gatewa y S erver can be

left disabled. To explicitly add a DNS server, default gateway server or otherwise, use the nx_dns_server_add. To

set the default gateway as the server you can type ip conf i g i n a command line shell and find out what the default gateway address is. This is explained in greater detail in chapter 9.

If the IP instance in your SSP does have the Default Gateway Address property, then Client has DNS and Gateway Server if enabled will add the default gateway to the DNC Client server list as the primary DNS server.

• To set up the DNS cache, the application can use t he nx_dns_cache_initialize service with the cache memory buffer pointing to a previously defined buffer. To be notified if the cache is full, use the

nx_dns_cache_notify_set service. This callback can be ‘disabled’ by clearing the callback using the nx_dns_cache_notify_clear service.

• A useful feature is the Clear previous DNS queries from queue property; this property enables the DNS client to remove any old DNS server responses from the DNS client receive queu e when looking for a response that matches the current query. This means older packets received from previous DNS queries are discarded to prevent the DNS client socket from o verflowing and dropping valid packets.

Refer to the following list for NetX DNS services and their NetX Duo DNS equivalents:

R11AN0178EU0101 Rev.1.01 Page 8 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Resource

ISDE Tab

Stacks Selection Sequence

g_dns0 NetX DNS Client

Threads

New Stack> X-Ware> NetX> Protocols> NetX DNS Client

g_dns0 NetX Duo DNS Client

Threads

New Stack> X-Ware> NetX Duo> Protocols> NetX Duo DNS Client

NetX DNS API service NetX Duo DNS API service (IPv4 only) (IPv4 and IPv6 supported) nx_dns_host_by_name_get nxd_dns_host_by_name_get nx_dns_host_by_address_get nxd_dns_host_by_address_get nx_dns_server_get nxd_dns_server_get nx_dns_server_add nxd_dns_server_add nx_dns_server_remove nxd_dns_server_remove

3.1.2 NetX and NetX Duo DNS Client Module Limitations

• The DNS client supports one DNS request at a time; threads attempting to make another DNS request

are temporarily blocked until the previous DNS request is complete.

• The NetX DNS Client module does not use data from authoritati ve answers to forward additional DNS

queries to other DNS servers.

See the latest SSP Release Notes for any other operational limitations that apply to t hi s modul e.

4. Includi ng the NetX and Net X D uo DNS Client Module in an Application

To include the NetX and NetX Duo DNS Client module in an application using the SSP configurator, use the following instructions.

Note: It is assumed you are familiar with creating a project, adding threads, adding a stac k t o a t hread, and

configuring a block within the stack. If you are unfami l i ar wit h any of these items, refer to the first few chapters of the SSP User’s Manual to learn how to manage each of these important steps in creating

To add the NetX DNS Client Module to an application, simply add it to a thread using the stacks selection sequence listed in the following table. The default name for the NetX DNS Client is g_dns0; the name can be changed in the associated Properties window.

SSP-based applications.

Table 3. NetX and NetX Duo BSD Support Module Selection Sequence

The following figure shows when the NetX or NetX Duo DNS Client module is added to the thread stack the configurator automatically adds any needed lower-level drivers. Any drivers needing additional configuration information are box-text highlighted in Red. Modules wit h a Gray band are individual, standalone modules. Modules with a Blue band are shared or in common and need only be added once to be used by multiple stacks. Modules with a Pink band may require selecting lower-level drivers, with these drivers either optional or recommended. If lower-level drivers are needed, the user sees “Add” in the module description. Clicking any Pink-banded modules displays the “New” icon and possible choices.

As configured in the figure, the NetX DNS Client module automatically creates its own packet pool. To add a separate packet pool, click the + icon and select New Stack> X-Ware> NetX > NetX Packet Pool instance (or New Stack> X-Ware> NetX Duo > NetX Duo Packet Pool instance for NetX Duo). In the DNS Client thread entry code, use the nx_dns_packet_pool _set service to set this packet pool (probably g_packet_pool1) as the DNS Client packet pool.

R11AN0178EU0101 Rev.1.01 Page 9 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Figure 2. NetX DNS Client Module Stack

5. Configuring the NetX and NetX Duo DNS Client Module

The user configures the NetX and NetX Duo DNS Client Module fo r the desired operation. The SSP configuration window automatically identifies (by highlighting the block in red) any required configuration selections, such as interrupts or operating modes. These settings must be c onfigured for lower-level modules for successful operation. Only properties that can be changed without conflict are available for modificati on. Other properties are ‘locked’ from changes and unavailable. Unavailable properties are identifi ed with a lock icon for the ‘locked’ property in the ISDE Propertie s window. This approach simplifies the configuration process and makes it much less error-prone than previous manual approaches to configuration. The available configuration settings and defaults for all the user-accessible properties are available f rom the SSP Configurator Properties tab and are listed in the following tables for easy reference.

One of the properties most often identified as requi ring a change is the interrupt priority; this configuration setting is available in the Properties window of the as sociated module. Simply select the indicated module and view the Properties window; the interrupt settings are often toward the bottom of the list, so scroll down until they become available. Note that the interrupt priorities listed in the ISDE Properties window indicates the validity of the setting based on the MCU targeted ( CM4 or CM0+). This level of detail is not included in the following configuration properties tables but is easily visible within the ISDE when configuring interruptpriority levels.

Note: You may want to open your ISDE and create the NetX DNS Cli ent module and explore the property

settings in parallel with looking over the followin g configuration table settings. This help to orient you and can be a useful ‘hands-on’ approach to learning the ins and outs of developing with SSP.

R11AN0178EU0101 Rev.1.01 Page 10 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

ISDE Property

Value

Description

DNS Control Type of Service

Normal, Minimum delay,

Default: Normal

DNS control type of service

Time to live

128

Time to live selection

Client DNS IP version (**Not included in NetX)

IPv4, IPv6 Default: IPv4

Client DNS IP version selection

Maximum number of DNS Servers in

Maximum number of DNS Servers

Maximum DNS queries size (bytes)

512

Maximum DNS queries size selection

Packets in DNS packet pool (units)

Packets in DNS packet pool

Maximum retries for a server

Maximum retries for a server selection

Maximum duration to retransmit a

Maximum duration to retransmit a Packet allocate timeout (seconds)

Packet allocate timeout selection

Client has DNS and Gateway server

Enable, Disable

If enabled, the default gateway

Section 3.1.1

Use application packet pool

Enable, Disable

NetX)

Use application packet pool

Clear previous DNS queries from

Enable, Disable

Clear previous DNS queries from

Extended RR types support

Enable, Disable Default: Disable

Extended RR types support

Cache support

Enable, Disable

Cache support selection Name

g_dns0

Module name

Table 4. Configuration Settings for the NetX and NetX Duo DNS Client Module

the Client server list

DNS query (seconds)

Maximum data, Maximum reliability, Minimum cost

Default: Disable

selection

in Client server list selection

selection

DNS query selection

address is set as the DNS server.

n SSP 1.2.0 there is no effect

See explanation in

Default: Enable (for NetX Duo)

Default: Disable (for

queue

Note: The example settings and defaults are for a project using the Synergy S7G2 Family. Other MCUs may

have different default values and available configuration settings.

In some cases, settings other than the defaults for lower-level modules can be desirable. For example, i t might be useful to select different MAC or IP Addresse s. T he configurable properties for the lower-level stac k modules are given in the following sections for complet eness and as a reference.

Note: Most of the property settings for lower-level modules are intuitive to configure and usually can be

determined by inspection of the associated properties window from the SSP configurator.

Default: Disable

selection

queue selection

selection

5.1 Configuration Settings for the NetX DNS Client Lower-Level Modules

Typically, only a small number of settings must be modified from the default for lower-level modules, as indicated via the red text in the thread stack block. Notice that some of the configuration properties must be set to a certain value for proper framework operat i on and are locked to prevent user modification. The following table identifies all the settings within the properties section for the module. You must ensure that entries highlighted in yellow will work with your environment.

R11AN0178EU0101 Rev.1.01 Page 11 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

ISDE Property

Value

Description

Name

g_ip0

Module name

IPv4 Address (use commas for

192,168,0,2

IPv4 Address selection. This address Subnet Mask (use commas for

separation)

255,255,255,0

Subnet Mask selection

**IPv6 Global Address (use commas

0x2001, 0x0, 0x0, 0x0,

IPv6 global address selection; not

Default Gateway Address (use

1.2.0.

192,168,0,1

IP address of the local host network

**IPv6 Link Local Address (use

0x0, 0x0, 0x0, 0x0, 0x0,

IPv6 link local address selection. This IP Helper Thread Stack Size (bytes)

Recommend: 2048 Default: 1024

IP Helper Thread Stack Size (bytes)

IP Helper Thread Priority

Recommend: 1

IP Helper Thread Priority selection.

ARP

Enable

ARP selection

ARP Cache Size in Bytes

512

ARP Cache Size in Bytes selection

Reverse ARP

Enable, Disable Default: Disable

Reverse ARP selection

TCP

Enable, Disable

TCP selection UDP

Enable

UDP selection

ICMP

Enable, Disable

ICMP selection

IGMP

Enable, Disable Default: Enable

IGMP selection

IP fragmentation

Enable, Disable

IP fragmentation selection

ISDE Property

Value

Description

No configurable properties

Table 5. Configuration Settings for the NetX IP Instance

separation)

for separation)

commas)

This property is not available in SSP

commas for separation, All zeros means use MAC address)

0x0, 0x0, 0x0, 0x1

0x0, 0x0, 0x0

Default: 3

must be on the same local network as the default gateway. The value listed is the default value

necessary if IPv6 is not used. Only applicable in NetX Duo DNS Client, not NetX DNS Client

default gateway.

is set automatically based on the network interface MAC address unless you specify a different address here.

selection

The IP thread should be the highest priority of all threads using NetX services for optimal performance

Default: Enable

Default: Disable

Notes:

• **Indicates properties only included with NetX Duo.

• The example settings and defaults are for a project using the Synergy S7G2. Other MCUs may

Table 6. Configuration Settings for the NetX Common Instance

Note: The example settings and defaults are for a project using the Synergy S7G2. Other MCUs may have

have different default values and available confi guration settings.

different default values and available configuration settings.

R11AN0178EU0101 Rev.1.01 Page 12 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

ISDE Property

Value

Description

Name

g_packet_pool0

Module name

Packet Size in Bytes

Default: 640

Packet size selection. If this is shared by the DNS Client, this

Number of Packets in

Default: 16

Number of packets in pool selection. The default value is

performance.

ISDE Property

Value

Description

Parameter Checking

BSP, Enabled, Disabled Default: BSP

Enable or disable the parameter

Channel 0 Phy Reset Pin

IOPORT_PORT_09_PIN_03

Channel 0 Phy reset pin

Channel 0 MAC Address High Bits

0x00002E09

Channel 0 MAC address high bits selection

Channel 0 MAC Address

0x0A0076C7

Channel 0 MAC address low

Channel 1 Phy Reset Pin

Default IOPORT_PORT_07_PIN_06

IOPORT_PORT_08_PIN_06

Channel 1 Phy reset pin Channel 1 MAC Address

0x00002E09

Channel 1 MAC address high

Channel 1 MAC Address Low Bits

0x0A0076C8

Channel 1 MAC address low bits selection

Number of Receive Buffer

Number of receive buffer

Number of Transmit Buffer Descriptors

Number of transmit buffer descriptors selection

Ethernet Interrupt Priority

Priority 0 (highest), Priority 1:2, Priority

Default: Disabled

Ethernet interrupt priority

Name

g_sf_el_nx

Module name

Channel

Default: 0 Set to: 1

Channel selection Callback

NULL

Callback selection

Table 7. Configuration Settings for the NetX Packet Pool Instance

is plenty large enough for most DNS packets. If the DNS packet fails to receive server DNS packets, try incre asing the size. A Wireshark packet trace is a helpful tool for knowing what size packets the DNS Client is getting.

Pool

Note: The example settings and defaults are for a project using the Synergy S7G2. Other MCUs may have

different default values and available configurati on settings.

Table 8. Configuration Settings for the NetX Port ETHER

The entries in yellow must be changed to work properl y with the SK-S7G2 board.

Low Bits

Set to:

adequate for the IP instance. If this packet pool is shared with the DNS Client, and there is heavy network traffic, increasing the number of packets may help improve

checking

selection

bits selection

selection

High Bits

Descriptors

Note: The example settings and defaults are for a project using the Synergy S7G2. Other MCUs may have

different default values and available configuration settings.

3 (CM4: valid, CM0+: lowest- not valid if using ThreadX), Priority 4:14 (CM4: valid, CM0+: invalid), Priority 15 (CM4 lowest - not valid if using ThreadX, CM0+: invalid), Disabled

bits selection

descriptors selection

selection. Any priority level will suffice for this project, but do not leave it disabled.

R11AN0178EU0101 Rev.1.01 Page 13 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

ISDE Property

Value

Description

No configurable properties

Resource

ISDE Tab

Pin selection Sequence

ETHERC

Pins

Select Peripherals > Connectivity:ETHERC > ETHERC1.RMII

Property

Value

Description

Pin Group Selection

Mixed, _A only (Default: _A only)

Pin group selection

Operation Mode

Disabled, Custom, RMII (Default: Disabled)

Select RMII as the Operation Mode for REF50CK

P701

REF50CK Pin

TXD0

P700

TXD0 Pin

TXD1

P406

TXD1 Pin

TXD_EN

P405

TXD_EN Pin

RXD0

P702

RXD0 Pin

RXD1

P703

RXD1 Pin

RX_ER

P704

RX_ER Pin

CRS_DV

P705

CRS_DV Pin

MDC

P403

MDC Pin

MDIO

P404

MDIO Pin

Table 9. Configuration Settings for the NetX Common Instance

Note: The example settings and defaults are for a project using the Synergy S7G2. Other MCUs may have

different default values and available configurat i on settings.

5.2 NetX and NetX Duo DNS Client Module Clock Configurat i on

The ETHERC peripheral module uses PCLKA as its clock source. The PCLKA frequency is set by using the SSP configurator clock tab prior to a build, or by using the CGC Interface at run-time.

5.3 NetX and NetX Duo DNS Client Module Pin Configurat i on

The ETHERC peripheral module uses pins on the MCU t o communicate to external devices. I/O pins are selected and configured as required by the external device. The following table lists the pin selection method within the SSP configuration window.

Note: The operating mode selected determines the peripheral signals available and the MCU pins required.

Table 10. Pin Selection for the ETHERC Module

Note: The selection sequence assumes ETHERC1 is the desired hardware target for the driver.

Table 11. Pin Configuration Settings for the ETHERC1

ETHERC1

Note: The example settings are for a project using the Synergy S7G2 MCU and the SK-S7G2 Kit. Other

Synergy MCUs and other Synergy Kits may have different available pi n configuration settings.

6. Using the NetX and NetX Duo DNS Client Module in an Application

The following example assumes the NetX sy st em is already initialized. Use these typical steps when implementing the NetX DNS Client module in an application:

1. Wait for valid IP address using the nx_ip_status_check API.

2. Enable DNS caching by calling the nx_dns_cache_initialize [optional].

3. Add one or more servers to the client list using the nx_dns_server_add API.

4. Send DNS name query using nxd_dns_host_by_name_get API to obtain an IP address.

5. Extract DNS server resource records using know n size and arrangement of records packaged by the

DNS client.

The following diagram shows these common steps a in a typical operation al flow.

R11AN0178EU0101 Rev.1.01 Page 14 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Resource

Revision

Description

e2 studio

5.3.1

Integrated Solution Development Environment

SSP

1.2.0

Synergy Software Platform

IAR EW for Renesas Synergy

7.71.1

IAR Embedded Workbench® for Renesas Synergy™

SSC

5.3.1.002

Synergy Standalone Configurator

SK-S7G2

v3.0 to v3.1

Starter Kit

Figure 3. Flow Diagram of a Typical NetX DNS Client Module Application

7. The NetX a nd NetX Duo DNS Client Module Application Project

The application project associated with this module guide demonstrates the steps needed in a ful l design. The project can be found using the link provided in the References section. You may want to import and open the application project within the ISDE and view the configuration settings for the NetX DNS Client module. You can also read over the code (in dns_client_thread_entry.c) that shows the NetX DNS Client module APIs in a complete design.

The application project demonstrates the typical use of the NetX DNS Client module APIs. It sets the DNS Client packet pool and adds a DNS Server IP address to its server list; it then sends a query to get the IP address for a website. If it succeeds, it prints the list of IP addresses parsed from the server response(s ).

Table 12. Software and Hardware Resources Used by the Application Project

The following figure shows a simple flow of the application project client and server functions.

R11AN0178EU0101 Rev.1.01 Page 15 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Figure 4. NetX and NetX Duo DNS Client Module Application Project

The dns_client_thread_entry.c file is located in the proj ect once it has been imported in the ISDE. The dns_client_thread_entry function call s the run_dns_client_session function in the DNS_Client_MG_AP.c file which actuall y performs the DNS query. You can open these files within the ISDE,

read the description, and follow along to help ident i fy key uses of the APIs provided. The first section of dns_client_thread_entry.c lists the header files, dns_client_thread.h and

DNS_Client_MG_AP.h. It also includes studio.h and a code section which allows semi-hosting to display results using printf(). DNS_Client_MG_AP.h in turn lists the nxd_dns.h (or nx_dns.h) f o r NetX DNS Client which references the DNS client-instance structure.

The dns_client_thread_entry.c sets up the DNS server address, the buffer for receiving the DNS server data, and the size of the buffer; it also defines the hostname to query on.

The next section in dns_client_thread_entry.c is the entry function for the main program -control section. The code checks that the IP instance and driver are properly initialized, and the IP instance has a valid IP address. Then it sets the gateway address for communicating with external hosts outside the current network segment using the nx_ip_gateway_address_set API. This is not required to run this project if the DNS server resides on the local network. Note this only applies for IPv4 networks. For IPv6 networks, it set s t he default router using the nxd_ipv6_default_router_add API. Next, the thread entry function sets the DNS client packet pool, which in this case is shared with the IP instance default packet pool, g_packet_pool0. This packet pool is specifically used by the DNS client to send queries. Finally, it sets up the DNS server addresses, including a DNS IPv6 server address if USE_IPV6 is defined in DNS_Client_MG_AP.h. In NetX Duo, the NXD_ADDRESS type is preferred since it supports IPv4 and IPv6 addresses. In NetX , IP addresses are stored in the ULONG data ty pe.

At this point the application is ready to run a DNS client session and send queries out. It calls the run_dns_client_session function, which adds the input server address to the DNS client list of servers,

R11AN0178EU0101 Rev.1.01 Page 16 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

ISDE Property

Value Set

Use application packet pool

Enable

Name

g_dns0

ISDE Property

Value Set

Packet Size (bytes)

1568

Name

g_packet_pool0

then sends a DNS query out with the input host name. I t ret urns a buffer pointing to the list of records extracted from the DNS server response (and the number of records) if no errors occur. If an error occurs, it returns the number of errors as the ‘status’ return.

Note: This description assumes you are familiar with using printf() with the Debug Console in the

Synergy Software Package. If you are unfamili ar with this, see “How do I Use Printf() with the Debug Console in the Synergy Software Package” Knowledge Base article, available in the References section at the end of this document. Alternativel y, the user can see results via the watch variables in the debug mode.

A few key properties are configured in this application project to support the required operations and the physical properties of the target board and MC U. The properties with the values set for this specific p roj ect are listed in the following tables. You can also open the application project and view these settings in the Properties window as a hands-on exercise.

Table 13. NetX DNS and NetX Duo DNS Client Module Configuration Settings for Application P roj ect

Table 14. NetX and NetX Duo Packet Pool Configuration Settings for Application Project

8. Customiz i ng the NetX and NetX Duo DNS Client Module for a Target Application

Some configuration settings are normally changed by the developer from those shown in the application project. For example, the application can make alte rnative queries such as an MX query to obtain a mail exchanger server that accepts delivery of email for the specified domain.

/* Send DNS MX query, and record the multiple mail exchange info. */ status = nx_dns_domain_mail_exchange_get(&client_dns, (UCHAR *)"google.com", &record_buffer[0], 500, &record_count, 4 * NX_IP_PERIODIC_RATE);

/* Check the record buffer. */ nx_dns_mx_entry_ptr1 = (NX_DNS_MX_ENTRY *)record_buffer; nx_dns_mx_entry_ptr2 = (NX_DNS_MX_ENTRY *)(record_buffer + sizeof(NX_DNS_MX_ENTRY)); nx_dns_mx_entry_ptr3 = (NX_DNS_MX_ENTRY *)(record_buffer + (2 * sizeof(NX_DNS_MX_ENTRY))); nx_dns_mx_entry_ptr4 = (NX_DNS_MX_ENTRY *)(record_buffer + (3 * sizeof(NX_DNS_MX_ENTRY))); nx_dns_mx_entry_ptr5 = (NX_DNS_MX_ENTRY *)(record_buffer + (4 * sizeof(NX_DNS_MX_ENTRY)));

You can customize the DNS client application further by enabling the Cle ar previous DNS queries from queue property. If this property is enabled, the DNS client removes older DNS server responses from the

DNS client receive queue until it finds a response that matches the current query. This prevents the DNS client socket from overflowing and dropping newer (valid) packets.

Another common customization is to create a separate packet pool specifically for the DNS client to send packets. This requires setting the Use Applicati on packet pool property to disabled; and a packet pool to be added to the DNS thread stacks pane. Click the (+) icon -> X-ware -> NetX -> NetX Packet Pool Instance or, if using NetX Duo DNS Client, X-ware -> NetX Duo -> NetX Duo Packet Pool Instance.

Lastly, the NetX and NetX Duo DNS Client modules can enable caching by calling nx_dns_cache_initialize with a pointer to cache memory and cache size as inputs. This requires set t i ng the Cache support property of the DNS Client inst ance. The DNS client stores the DNS server response data. On subsequent DNS client queries, the DNS client first checks the cache if the information alre ady exists.

R11AN0178EU0101 Rev.1.01 Page 17 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

9. Running the NetX and Net X D uo DNS Client Module Application Project

To run the NetX DNS Client module application project and see if it executed on a target kit, you can simply import it into your ISDE, compile, and run debug. See the Renesas Synergy™ Project Import Guide (included in the package) for instructions on importing the project into e build and run the application.

To implement the NetX DNS Client module application in a new project, follow the steps to define, configure, auto-generate files, add code, compile, and debug on the target kit. Following these steps is a hands-on approach to help make the development process with S SP practical, while just reading over this guide tends to be more theoretical.

Note: The following steps are detailed sufficiently for someone experienced with the basic flow through the

Renesas Synergy development process. If these steps are unfamiliar, see the SSP User’s Manual for guidance.

To create and run the DNS Client application project, simply follow these steps:

1. Create a new Renesas Synergy project for the S7G2 -SK called DNS_CLIENT_AP.

2. Select the Threads tab.

3. Click the + icon in the Threads panel.

4. Set the stack size to 2048 and set the thread instance t o dns_client_thread.

5. In the thread stack pane, cl i ck the + icon and select X-Ware -> NetX Duo -> Protocols -> NetX Duo

DNS Client (or X-Ware -> NetX -> Protocols -> NetX DNS Client for NetX application).

6. Set the properties for the DNS Client instance, IP instance, and the NetX Port ETHER driver. Be sure to set the Ethernet Interrupt Priority; its default value is Disabled. For the SK-S7G2 board,

select Channel 1. The Channel 1 Phy Reset Pin should be IOPORT_PORT_08_PIN_06. These properties default to 0 and IOPORT_PORT_07_PIN_06.

7. Set the IPv4 address (and IPv6 if using IPv6 network) of the IP instance, as follows:  Get the IP address assigned to your board: type ipconfig at the command line of a PC on the local

network. Use the PC’s network address to create an IP address for the board. For exam ple, if the ipconfig command lists 192.2.2.201 as the PC’s IP address, create IP address 192.2.2.x, where x is any value between 2 and 254.

 Now check whether that address is in use by se ndi ng a ping command. If there is no response, you

can use this IP address. You can also type arp -r for assi gned IP addresses on the network. Pick an address NOT listed!

studio or IAR EW for Synergy to

R11AN0178EU0101 Rev.1.01 Page 18 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

8. If you would like to make the network router the DNS server, and the IP component has a Default

Gateway Address property (not available in SSP 1.2.0), be sure to set that prope rty to the router address and set the DNS Client Client has DNS and Gateway Server property to enabled. The router address/gateway is also listed in the ipconfig output above (192.2.2.1).

9. Alternatively, you can define SERVER_IP_ADDRESS at the top of dns_client_t hread_entry.c to set the

DNS server IP address. If you have set Client has DNS and Gateway Server to enabled (and the IP component has a Default Gateway Address property) this adds that DNS server to the DNS Cli ent list of servers.

Notes:

1. The DNS Client can have more than one DNS server, but in the interests of simplicity, this demonstration project only registers one DNS server IP address with the Client.

2. The local router/gateway and SERVER_IP_ADDRESS — whichever (or both) that you use — should be on the same network as your DNS Client.

3. When using the DNS Client with IPv6, define USE_IPV6 in DNS_Client_MG_AP.h and set the server IPv6 address to your DNS server IPv6 address. Note that the Client has DNS and the Gateway Server has no effect on IPv6 DNS clients. For example:

server_duo_address.nxd_ip_address.v6[0] = 0x20010db8; server_duo_address.nxd_ip_address.v6[1] = 0x0; server_duo_address.nxd_ip_address.v6[2] = 0x0;

server_duo_address.nxd_ip_address.v6[3] = 0x1;

4. Click the Generate Project Content button.

5. Set optimization to none -O2 ( should default to this value):

 Right-click the project and choose Properties -> C/C++ Build -> Settings -> Optimization. Set the

Optimization Level to None (-O2).

 For optimal debugging, at the expense of perf ormance, you can set this to -O0.

6. Enable debug output [optional]. A. Right click the project and choose Properties -> C/C++ Build -> Settings -> Cross ARM C

Compiler -> Preprocessor.

B. Add a define in the Defined symbols pane by clicking on the + icon. Type SEMI_HOSTING.

7. For NetX Duo DNS Client applications, define NETX_DUO in the project preprocessor list: A. Right click the project and choose Properties -> C/C++ Build -> Settings -> Cross ARM C

Compiler -> Preprocessor.

B. Add define in the Defined symbols pane by clicking the + icon. Type NETX_DUO.

8. Right-click the project and choos e Build Project.

9. Right-click the project and choos e Debug as -> Renesas GDB Hardware Debugging

10. Connect to the host PC to the board via Ethernet (not Wifi) via a micro-USB cable to J19 on SKS7G2. The PC should not be connected to another networ k interface such as Wifi.

11. Run the application. If the return value from the run_dns_client_session service is zero, print out the results of the query (the IP address may vary):

Figure 5. Example Output from NetX and NetX Duo DNS Client (IPv4) Application Project

If USE_IPV6 is defined on the application (NetX Duo DNS Client only ), the results should look like this:

Figure 6. Example Output from NetX and NetX Duo DNS Client Application Project

R11AN0178EU0101 Rev.1.01 Page 19 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

10. NetX and NetX Duo DNS Client Module Conclusion

This module guide has provided all the background inf ormation needed to select, add, configure, and u se the module in an example project. Many of these steps were time consuming and error-prone activit ies in previous generations of embedded systems. T he Renesas Synergy Platform makes these steps much less time consuming and removes the common errors, like conflicting configuration settings or incorrect selection of lower-level drivers. The use of high-level APIs (as demonstrated in the application project) illustrate additional development time savings by allowing work to begin at a high level and avoiding the time req uired in older development environments to use or, in some cases, create, lower-level drivers.

11. NetX and NetX Duo DNS Client Module Next Steps

After you have mastered a simple DNS Client project, you may want to review a more complex example. The DNS Client has many other types of queries, esp ecial l y if RR record support is enabled. This lets the

application make SOA, MX, PTR, CNAME and other q ueries using similar API. Note that the DNS Client module takes care of packet handling and releasing packets back to the packet pool.

You may also find that setting a DHCP Client is a better fit for your target application than setting a static IP. The NetX™ DHCP Client Module Guide shows how to use it to obtain a dynamic provided IP address from a DHCP Server.

12. NetX and NetX Duo DNS Client Module Reference Information

The SSP User Manual is available in HTML in the SSP distribution package, and as a pdf from the Synergy Gallery (www.renesas.com/synergy/software).

Links to all the most up-to-date NetX and NetX Duo Module Guide Resources are available on the Synergy Knowledge Base: https://en-

support.renesas.com/search/NetX%20DNS%20Client%20Module%20Guide%20Resources.

R11AN0178EU0101 Rev.1.01 Page 20 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Website and Support

Visit the following vanity URLs to learn about key elements of the Synergy Platform, download components and related documentation, and get support.

Synergy Software www.renesas.com/synergy/software Synergy Software Package www.renesas.com/synergy/ssp Software add-ons www.renesas.com/synergy/addons Software glossary www.renesas.com/synergy/softwareglossary

Development tools www.renesas.com/synergy/tools

Synergy Hardware www.renesas.com/synergy/hardware Microcontrollers www.renesas.com/synergy/mcus MCU glossary www.renesas.com/synergy/mcuglossary Parametric search www.renesas.com/synergy/parametric

Kits www.renesas.com/synergy/kits

Synergy Solutions Gallery www.renesas.com/synergy/solutionsgallery Partner projects www.renesas.com/synergy/partnerprojects

Application projects www.renesas.com/synergy/applicationprojects

Self-service support resources:

Documentation www.renesas.com/synergy/docs Knowledgebase www.renesas.com/synergy/knowledgebase Forums www.renesas.com/synergy/forum Training www.renesas.com/synergy/training Videos www.renesas.com/synergy/videos Chat and web ticket www.renesas.com/synergy/resourcelibrary

R11AN0178EU0101 Rev.1.01 Page 21 of 22 Jan.04.19

Renesas Synergy™ Platform NetX™ and NetX Duo™ DNS Client Module Guide

Rev.

Date

Description

Page

Summary

1.00

Jan.12.18

—

Initial Release

1.01

Jan.04.19

—

Minor changes and correction throughout

Revision History

R11AN0178EU0101 Rev.1.01 Page 22 of 22 Jan.04.19

Corporate Headquarters

Contact information

www.renesas.com

Trademarks

of their respective owners.

Notice

1. Descriptions of circuits, software and other related information in this document are provided only to illustrate the operation of semiconductor products and application examples. You are fully responsible for the incorporation or any other use of the circuits, software, and information in the design of your product or system. Renesas Electronics disclaims any and all liability for any losses and damages incurred by you or third parties arising from the use of these circuits, softw a r e, or information.

2. Renes as Electronics hereby expressly disclaims any warranties against and liability for infringement or any other claims involving patents, copyrights, or other intellectual property rights of third parties, by or arising from the use of Renesas Electronics products or technical information described in this document, including but not limited to, the product data, drawings, charts, programs, algorithms, and application examples.

3. No lic ense, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property rights of Renesas Electronics or others.

4. You shall not alter, modify, copy, or reverse engineer any Renesas Electronics product, whether in whole or in part. Renesas Electronics disclaims any and all liability for any losses or damages incurred by you or third parties arising from such alteration, modification, copying or reverse engineering.

5. Renes as Electronics products are classified according to the following two quality grades: “Standard” and “High Quality”. The intended applications for each Renesas Electronics product depends on the product’s quality grade, as indicated below. "Standard": Computers; office equipment; communications equipment; test and measurement equipment; audio and visual equipment; home

"High Quality": Transp ortation equipment (automobiles, trains, ships, etc.); traffic control (traffic lights); large-scale communication equipment; key

Unless expressly designated as a high reliability product or a product for harsh environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not intended or authorized for use in products or systems that may pose a direct threat to human life or bodily injury (artificial life support devices or systems; surgical implantations; etc.), or may cause serious property damage (space system; undersea repeaters; nuclear power control systems; aircraft control systems; key plant systems; military equipment; etc.). Renesas Electronics disclaims any and all liability for any damages or losses incurred by you or any third parties arising from the use of any Renesas Electronics product that is inconsistent with any Renesas Electronics data sheet, user’s manual or other Renesas Electronics document.

6. When using Renesas Electronics products, refer to the latest product information (data sheets, user’s manuals, application notes, “General Notes for Handling and Using Semiconductor Devices” in the reliability handbook, etc.), and ensure that usage conditions are within the ranges specified by Renesas Electronics with respect to maximum ratings, operating power supply voltage range, heat dissipation characteristics, installation, etc. Renesas Electronics disclaims any and all liability for any malfunctions, failure or accident arising out of the use of Renesas Electronics products outside of such specified ranges.

7. Although Renesas Electronics endeavors to improve the quality and reliability of Renesas Electronics products, semiconductor products have specific characteristics, such as the occurrence of failure at a certain rate and malfunctions under certain use conditions. Unless designated as a high reliability product or a product for harsh environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not subject to radiation resistance design. You are responsible for implementing safety measures to guard against the possibility of bodily injury, injury or damage caused by fire, and/or danger to the public in the event of a failure or malfunction of Renesas Electronics products, such as safety design for hardware and software, including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures. Because the evaluation of microcomputer software alone is very difficult and impractical, you are responsible for evaluating the safety of the final products or systems manufactured by you.

8. Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental compatibility of each Renesas Electronics product. You are responsible for carefully and sufficiently investigating applicable laws and regulations that regulate the inclusion or use of controlled substances, including without limitation, the EU RoHS Directive, and using Renesas Electronics products in compliance with all these applicable laws and regulations. Renesas Electronics disclaims any and all liability for damages or losses occurring as a result of your noncompliance with applicable laws and regulations.

9. Renes as Electronics products and technologies shall not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited under any applicable domestic or foreign laws or regulations. You shall comply with any applicable export control laws and regulations promulgated and administered by the governments of any countries asserting jurisdiction over the parties or transactions.

10. It is the responsibility of the buyer or distributor of Renesas Electronics products, or any other party who distributes, disposes of, or otherwise sells or transfers the product to a third party, to notify such third party in advance of the contents and conditions set forth in this document.

11. This document shall not be reprinted, reproduced or duplicated in any form, in whole or in part, without prior written consent of Renesas Electronics.

12. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in this document or Renesas Electronics products.

(Note1) “Renesas Electronics” as used in this document means Renesas Electronics Corporation and also includes its directly or indirectly controlled

(Note2) “Renesas Electronics product(s)” means any product developed or manufactured by or for Renesas Electronics.

subsidiaries.

electronic appliances; machine tools; personal electronic equipment; industrial robots; etc.

financial terminal systems; safety control equipment; etc.

(Rev.4.0-1 November 2017)

TOYOSU FORESIA, 3-2-24 Toyosu, Koto-ku, Tokyo 135-0061, Japan

Renesas and the Renesas logo are trademarks of Renesas Electronics Corporation. All trademarks and registered trademarks are the property

For further information on a product, technology, the most up-to-date version of a document, or your nearest sales office, please visit:

www.renesas.com/contact/.

Renesas NetX, NetX Duo User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. NetX and NetX Duo DNS Client Module Features

2. NetX and NetX Duo DNS Cli ent Module APIs Overview

3. NetX and NetX Duo DNS Client Module Operational Overview

3.1.1 NetX and NetX Duo DNS Client Module Operational Notes

3.1.2 NetX and NetX Duo DNS Client Module Limitations

4. Includi ng the NetX and Net X D uo DNS Client Module in an Application

5. Configuring the NetX and NetX Duo DNS Client Module

5.1 Configuration Settings for the NetX DNS Client Lower-Level Modules

5.2 NetX and NetX Duo DNS Client Module Clock Configurat i on

5.3 NetX and NetX Duo DNS Client Module Pin Configurat i on

6. Using the NetX and NetX Duo DNS Client Module in an Application

7. The NetX a nd NetX Duo DNS Client Module Application Project

8. Customiz i ng the NetX and NetX Duo DNS Client Module for a Target Application

9. Running the NetX and Net X D uo DNS Client Module Application Project

10. NetX and NetX Duo DNS Client Module Conclusion

11. NetX and NetX Duo DNS Client Module Next Steps

12. NetX and NetX Duo DNS Client Module Reference Information

Revision History
