REJ10J0777-0100(T)

M306V8T-EPB

User’s Manual

Emulation Probe for M16C/60 Series M16C/6V Group M306V8

Rev.1.00 Aug. 1, 2005

Keep safety first in your circuit designs!

1. Renesas Technology Corp. puts the maximum effort into making semiconductor products better and more reliable, but there is always the possibility that trouble may occur with them. Trouble with semiconductors may lead to personal injury, fire or property damage. Remember to give due consideration to safety when making your circuit designs, with appropriate measures such as (i) placement of substitutive, auxiliary circuits, (ii) use of nonflammable material or (iii) prevention against any malfunction or mishap.

Notes regarding these materials

1. These materials are intended as a reference to assist our customers in the selection of the Renesas Technology Corp. product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corp. or a third party.

2. Renesas Technology Corp. assumes no responsibility for any damage, or infringement of any third-party's rights, originating in the use of any product data, diagrams, charts, programs, algorithms, or circuit application examples contained in these materials.

3. All information contained in these materials, including product data, diagrams, charts, programs and algorithms represents information on products at the time of publication of these materials, and are subject to change by Renesas Technology Corp. without notice due to product improvements or other reasons. It is therefore recommended that customers contact Renesas Technology Corp. or an authorized Renesas Technology Corp. product distributo for the latest product information before purchasing a product listed herein. The information described here may contain technical inaccuracies or typographical errors. Renesas Technology Corp. assumes no responsibility for any damage, liability, or other loss rising from these inaccuracies or errors. Please also pay attention to information published by Renesas Technology Corp. by various means, including the Renesas Technology Corp. Semiconductor home page (http:/ www.renesas.com).

4. When using any or all of the information contained in these materials, including product data, diagrams, charts, programs, and algorithms, please be sure to evaluate all information as a total system before making a final decision on the applicability of the information and products. Renesas Technology Corp. assumes no responsibility for any damage, liability o other loss resulting from the information contained herein.

5. Renesas Technology Corp. semiconductors are not designed or manufactured for use in a device or system that is used under circumstances in which human life is potentially at stake. Please contact Renesas Technology Corp. or an authorized Renesas Technology Corp. product distributor when considering the use of a product contained herein for any specific purposes, such as apparatus or systems for transportation, vehicular, medical, aerospace, nuclear, or undersea repeater use.

6. The prior written approval of Renesas Technology Corp. is necessary to reprint or reproduce in whole or in part these materials.

7. If these products or technologies are subject to the Japanese export control restrictions, they

must be exported under a license from the Japanese government and cannot be imported into a country other than the approved destination. Any diversion or reexport contrary to the export control laws and regulations of Japan and/ o the country of destination is prohibited.

8. Please contact Renesas Technology Corp. for further details on these materials or the

products contained therein.

M306V8T-EPB User’s Manual Preface

Preface

The M306V8T-EPB is an emulation probe for M16C/60 Series M16C/6V Group M306V8. The M306V8T-EPB is used by

connecting to the PC7501 emulator main unit.

This user's manual mainly describes specifications of the M306V8T-EPB emulation probe and how to setup it. For details on

the following products, which are used with the M306V8T-EPB, refer to each product's user's manual.

All the components of this product are shown in "1.1 Package components" (page 13). If there is any question or doubt about

this product, contact your local distributor.

The related manuals for using this product are listed below. You can download the latest manuals from the Renesas Tools

homepage (http://www.renesas.com/en/tools).

Related manuals

Item Manual

Emulator main unit PC7501 User’s Manual Integrated development environment High-performance Embedded Workshop User’s Manual

M16C R8C PC7501 Emulator debugger User’s Manual Emulator debugger M3T-PD30F User’s Manual

C compiler C compiler package for R8C/Tiny, M16C/60, 30, 20, 10 and Tiny Series

Compiler User's Manual

Assembler C compiler package for R8C/Tiny, M16C/60, 30, 20, 10 and Tiny Series

Assembler User's Manual

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 3 of 90

M306V8T-EPB User’s manual Important

Important

Before using this product, be sure to read this user’s manual carefully.

Keep this user’s manual, and refer to this when you have questions about this product.

Emulator:

The emulator in this document refers to the following products that are manufactured by Renesas Technology Corp.:

(1) PC7501 main unit

(2) Emulation probe

(3) Package converter board for connecting the user system

The emulator herein does not include the customer’s user system and host machine.

Purpose of use of the emulator:

This emulator is a device to support the development of a system that uses the M16C Family M16C/60 Series M16C/6V Group

M306V8 of Renesas 16-bit single-chip MCUs. It provides support for system development in both software and hardware.

Be sure to use this emulator correctly according to said purpose of use. Please avoid using this emulator for other than its

intended purpose of use.

For those who use this emulator:

This emulator can only be used by those who have carefully read the user’s manual and know how to use it.

Use of this emulator requires the basic knowledge of electric circuits, logical circuits, and MCUs.

When using the emulator:

(1) This product is a development supporting unit for use in your program development and evaluation stages. In mass-

producing your program you have finished developing, be sure to make a judgment on your own risk that it can be put to

practical use by performing integration test, evaluation, or some experiment else.

(2) In no event shall Renesas Solutions Corp. be liable for any consequence arising from the use of this product.

(3) Renesas Solutions Corp. strives to renovate or provide a workaround for product malfunction at some charge or without

charge. However, this does not necessarily mean that Renesas Solutions Corp. guarantees the renovation or the provision

under any circumstances.

(4) This product has been developed by assuming its use for program development and evaluation in laboratories. Therefore,

it does not fall under the application of Electrical Appliance and Material Safety Law and protection against

electromagnetic interference when used in Japan.

(5) Renesas Solutions Corp. cannot predict all possible situations or possible cases of misuse where a potential danger exists.

Therefore, the warnings written in this user’s manual and the warning labels attached to this emulator do not necessarily

cover all of such possible situations or cases. Please be sure to use this emulator correctly and safely on your own

responsibility.

(6) This product is not qualified under UL or other safety standards and IEC or other industry standards. This fact must be

taken into account when taking this product from Japan to some other country.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 4 of 90

M306V8T-EPB User’s manual Important

Usage restrictions:

This emulator has been developed as a means of supporting system development by users. Therefore, do not use it as a device

used for equipment-embedded applications. Also, do not use it for developing the systems or equipment used for the following

purposes either:

(1) Transportation and vehicular

(2) Medical (equipment where human life is concerned)

(3) Aerospace

(4) Nuclear power control

(5) Undersea repeater

If you are considering the use of this emulator for one of the above purposes, please be sure to consult your local distributor.

About product changes:

We are constantly making efforts to improve the design and performance of this emulator. Therefore, the specification or

design of this emulator or its user’s manual may be changed without prior notice.

About the rights:

(1) We assume no responsibility for any damage or infringement on patent rights or any other rights arising from the use of

any information, products or circuits presented in this user’s manual.

(2) The information or data in this user’s manual does not implicitly or otherwise grant a license for patent rights or any other

rights belonging to us or third parties.

duplicated or reproduced, in whole or part, without prior written consent of us.

About diagrams:

The diagrams in this user’s manual may not all represent exactly the actual object.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 5 of 90

M306V8T-EPB User’s Manual Precautions for safety

Precautions for Safety

Definitions of Signal Words

In both the user’s manual and on the product itself, several icons are used to insure proper handling of this product and also to

prevent injuries to you or other persons, or damage to your properties.

This chapter describes the precautions which should be taken in order to use this product safely and properly. Be sure to read

this chapter before using this product.

This symbol represents a warning about safety. It is used to arouse caution about a potential

DANGER

WARNING

CAUTION

IMPORTANT

In addition to the five above, the following are also used as appropriate.

means WARNING or CAUTION.

Example:

danger that will possibly inflict an injury on persons. To avoid a possible injury or death, please be sure to observe the safety message that follows this symbol.

DANGER indicates an imminently dangerous situation that will cause death or heavy wound

unless it is avoided. However, there are no instances of such danger for the product presented in this user's manual.

WARNING indicates a potentially dangerous situation that will cause death or heavy wound

unless it is avoided.

CAUTION indicates a potentially dangerous situation that will cause a slight injury or a

medium-degree injury unless it is avoided.

CAUTION with no safety warning symbols attached indicates a potentially dangerous

situation that will cause property damage unless it is avoided.

This is used in operation procedures or explanatory descriptions to convey exceptional conditions or cautions to the user.

CAUTION AGAINST AN ELECTRIC SHOCK

means PROHIBITION.

Example:

DISASSEMBLY PROHIBITED

means A FORCIBLE ACTION.

Example:

UNPLUG THE POWER CABLE FROM THE RECEPTACLE.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 6 of 90

M306V8T-EPB User’s Manual Precautions for safety

WARNING

Warnings for AC Power Supply:

 If the attached AC power cable does not fit the receptacle, do not alter the AC power cable and do not plug it

forcibly. Failure to comply may cause electric shock and/or fire.

 Use an AC power cable which complies with the safety standard of the country.

 Do not touch the plug of the AC power cable when your hands are wet. This may cause electric shock.

 This product is connected signal ground with frame ground. If your developing product is transformless (not

having isolation transformer of AC power), this may cause electric shock. Also, this may give an unrepairable damage to this product and your developing one. While developing, connect AC power of the product to commercial power through isolation transformer in order to avoid these dangers.

 If other equipment is connected to the same branch circuit, care should be taken not to overload the circuit.

 When installing this equipment, insure that a reliable ground connection is maintained.

 If you smell a strange odor, hear an unusual sound, or see smoke coming from this product, then disconnect

power immediately by unplugging the AC power cable from the outlet. Do not use this as it is because of the danger of electric shock and/or fire. In this case, contact your local distributor.

 Before setting up this emulator and connecting it to other devices, turn off power or remove a power cable to

prevent injury or product damage.

Warnings to Be Taken for This Product:

 Do not disassemble or modify this product. Personal injury due to electric shock may occur if this product is

disassembled and modified. Disassembling and modifying the product will void your warranty.

 Make sure nothing falls into the cooling fan on the top panel, especially liquids, metal objects, or anything

combustible.

Warning for Installation:

 Do not set this product in water or areas of high humidity. Make sure that the product does not get wet. Spilling

water or some other liquid into the product may cause unrepairable damage.

Warning for Use Environment:

 This equipment is to be used in an environment with a maximum ambient temperature of 35°C. Care should be

taken that this temperature is not exceeded.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 7 of 90

M306V8T-EPB User’s Manual Precautions for safety

Cautions to Be Taken for Turning On the Power:

 Turn ON/OFF the power of the emulator and user system as simultaneously as possible.

 Do not leave either the emulator or user system powered on, because of leakage current the internal circuits may

be damaged.

 When turning on the power again after shutting off the power, wait about 10 seconds.

Cautions to Be Taken for Handling This Product:

 Use caution when handling the main unit. Be careful not to apply a mechanical shock.

 Do not touch the connector pins of the emulator main unit and the target MCU connector pins directly. Static

electricity may damage the internal circuits.

 Do not pull this emulator by the communications interface cable or the flexible cable for connecting the user

system. And, excessive flexing or force may break conductors.

 Do not flex the flexible cable for connecting to the emulator main unit and emulation probe excessively. The

cable may cause a break.

 Do not use inch-size screws for this equipment. The screws used in this equipment are all ISO (meter-size) type

screws. When replacing screws, use same type screws as equipped before.

CAUTION

Caution to Be Taken for System Malfunctions:

 If the emulator malfunctions because of interference like external noise, do the following to remedy the trouble.

(1) Press the RESET button on the emulator front panel. (2) If normal operation is not restored after step (1), shut OFF the emulator once and then reactivate it.

Caution to Be Taken for External Trigger Input Voltage:

 Keep an external trigger input voltage of the emulator main unit less than a Vcc2 voltage. Overvoltage may

cause damage to the internal circuits.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 8 of 90

M306V8T-EPB User’s Manual Contents

Page

Preface..........................................................................................................................................................................3

Important.......................................................................................................................................................................4

Precautions for Safety ..................................................................................................................................................6

Contents........................................................................................................................................................................9

User Registration ........................................................................................................................................................11

Terminology ................................................................................................................................................................12

1. Outline.....................................................................................................................................................................13

1.1 Package Components ...................................................................................................................................13

1.2 Other Tool Products Required for Development ...........................................................................................14

1.3 System Configuration ....................................................................................................................................15

1.3.1 System Configuration..........................................................................................................................15

1.3.2 Names and Functions of the PC7501 Upper Panel LEDs ..................................................................16

1.4 Specifications ................................................................................................................................................18

1.5 Operating Environment..................................................................................................................................19

2. Setup.......................................................................................................................................................................20

2.1 Flowchart of Starting Up the Emulator ..........................................................................................................20

2.2 Installing the Emulator Debugger (Renesas Debugger Package for M16C) ................................................21

2.2.1 Installing the Emulator Debugger........................................................................................................21

2.3 Connecting the Host Machine .......................................................................................................................22

2.4 Connecting the PC7501 ................................................................................................................................23

2.5 Connecting the Power Supply for the Emulator ............................................................................................24

2.6 Turning ON the Power...................................................................................................................................25

2.6.1 Checking the Connections of the Emulator System............................................................................25

2.6.2 Turning ON/OFF the Power ................................................................................................................25

2.6.3 LED Display When the Emulator Starts Up Normally .........................................................................26

2.7 Downloading Firmware..................................................................................................................................27

2.7.1 When It is Necessary to Download Firmware .....................................................................................27

2.7.2 Downloading Firmware in Maintenance Mode....................................................................................27

2.8 Self-check......................................................................................................................................................28

2.8.1 Self-check Procedure..........................................................................................................................28

2.8.2 If an Error is Detected in the Self-check..............................................................................................29

2.9 Connecting the User System.........................................................................................................................30

2.9.1 Connecting the User System ..............................................................................................................31

2.10 Switch Settings ............................................................................................................................................32

2.10.1 Setting Switches of Emulation Probe ..................................................................................................32

2.10.2 Writing Data to the OSDROM ...........................................................................................................36

2.10.3 Pullup of Emulation Ports..................................................................................................................37

2.11 Selecting Clock Supply................................................................................................................................38

2.11.1 Clocks................................................................................................................................................38

2.11.2 Using an Internal Oscillator Circuit Board .........................................................................................38

2.11.3 Using the Oscillator Circuit on the User System ...............................................................................42

2.11.4 Using the Internal Generator Circuit..................................................................................................42

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 9 of 90

M306V8T-EPB User’s Manual Contents

Page

3. Usage (How to Use the Emulator Debugger) .........................................................................................................43

3.1 Starting Up the Emulator Debugger ..............................................................................................................43

3.1.1 INIT Dialog Box ...................................................................................................................................43

3.1.2 MCU Setting Dialog Box .....................................................................................................................48

3.1.3 Checking Connections of the Emulator System..................................................................................51

3.2 Editor (Source) Window.................................................................................................................................52

3.3 Hardware Breakpoint Setting Window...........................................................................................................55

3.4 Trace Window................................................................................................................................................60

3.5 RAM Monitor Window....................................................................................................................................63

4. Hardware Specifications .........................................................................................................................................64

4.1 Target MCU Specifications............................................................................................................................64

4.2 Access Timing ...............................................................................................................................................65

4.2.1 Operation Timing of Memory Expansion Mode and Microprocessor Mode (Vcc1=Vcc2=Vcc3=3.3V)

......................................................................................................................................................................65

4.3 Differences between the Actual MCU and Emulator.....................................................................................70

4.4 Connection Diagrams ....................................................................................................................................73

4.5 External Dimensions......................................................................................................................................75

4.5.1 External Dimensions of the Emulation Probe .....................................................................................75

4.5.2 External Dimensions of the M306V8T-PTC ........................................................................................76

4.6 Notes on Using This Product.........................................................................................................................77

5. Troubleshooting ......................................................................................................................................................82

5.1 Flowchart to Remedy the Troubles ...............................................................................................................82

5.2 When the Emulator Debugger Does Not Start Up Properly ..........................................................................83

5.3 How to Request for Support ..........................................................................................................................86

6. Maintenance and Guarantee ..................................................................................................................................87

6.1 User Registration...........................................................................................................................................87

6.2 Maintenance ..................................................................................................................................................87

6.3 Guarantee......................................................................................................................................................87

6.4 Repair Provisions ..........................................................................................................................................87

6.5 How to Make Request for Repair ..................................................................................................................88

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 10 of 90

M306V8T-EPB User’s Manual User Registration

User Registration

When you have purchased the emulator presented in this user's manual, please be sure to register it. As the hardware tool user

registration FAX sheet is included with this manual, fill it in and FAX it to your local distributor or email the same contents to

the following address. Your registered information is used for only after-sale services, and not for any other purposes. Without

user registration, you will not be able to receive maintenance services such as a notification of field changes or trouble

information. So be sure to carry out the user registration.

For more information about user registration, please email to the following address.

regist_tool@renesas.com

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 11 of 90

M306V8T-EPB User’s Manual Terminology

Terminology

Some specific words used in this user's manual are defined as follows:

Emulator system

This means an emulator system built around the PC7501 emulator. The PC7501 emulator system is configured with an

emulator main unit, emulation probe, host machine and the integrated development environment High-performance Embedded

Workshop.

Emulator main unit (Hereafter PC7501)

This means an emulator main unit for M16C Family.

Emulation probe

This means the emulation probe (this product) for the M16C Family M16C/60 Series M16C/6V Group M306V8 MCUs.

Integrated development environment High-performance Embedded Workshop

This tool provides powerful support for the development of embedded applications for Renesas microcomputers. It has an

emulator debugger function allowing for the emulator and emulation probe to be controlled from the host machine via an

interface. Furthermore, it permits a range of operations from editing a project to building and debugging it to be performed

within the same application. What’s more, it supports version management.

Emulator debugger

This means a software tool starting up from the High-performance Embedded Workshop to control the emulator and this

product and enables debugging.

Firmware

Program that analyzes contents of communication with the emulator debugger and controls the emulator hardware. This

program is installed in the flash memory in the emulator main unit. This program is downloadable from the emulator debugger

to upgrade the firmware or to support other MCUs.

Host machine

This means a personal computer used to control the emulator main unit and emulation probe.

Software break

A software break is a function to break the program before the system executes an instruction at the specified address. The

instruction at the preset address will not be executed.

Hardware break

A hardware break is a function to break the program when the system detects a write/read of data to/from memory or a

leading/trailing edge of the signal entered from the external trace cable. The former break function is called address break; and

the latter break function is called trigger break. While the instruction at the address where the software break is set is not

executed, a hardware break is performed after the specified instruction is executed.

Target MCU

This means the MCU you are going to debug.

User system

This means a user's application system using the microcomputer to be debugged.

User program

This means the program you are going to debug.

Evaluation MCU

This means the MCU mounted on the emulation probe which is operated in the specific mode for tools.

In this user's manual, this symbol is used to show active Low. (e.g. RESET*: Reset signal)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 12 of 90

M306V8T-EPB User’s Manual 1. Outline

1. Outline

This chapter describes the package components, the system configuration, the specifications of the emulator functions and the

operating environment.

1.1 Package Components

The M306V8T-EPB package consists of the following items. When unpacking it, check to see if your M306V8T-EPB contains

all of these items.

Table 1.1 Package components

Item Quantity

M306V8T-EPB emulation probe 1 M306V8T-PTC (pre-mounted) converter board for 116-pin 0.65-mm-pitch LQFP 1 NQPACK116SB, YQPACK116SB and YQ-GUIDE(x4) for connecting the M306V8T-PTC and user system OSC-3 (16MHz) oscillator circuit board 1 OSC-2 oscillator circuit bare board 1 Network registers for ports P0--P5 pullup (51kΩ x 8) 6 Hardware tool user registration FAX sheet (English) 1 Hardware tool user registration FAX sheet (Japanese) 1 M306V8T-EPB User’s Manual (this manual) 1 M306V8T-EPB User’s Manual (Japanese) 1 M306V8T-EPB Supplementary Document (English) 1 M306V8T-EPB Supplementary Document (Japanese) 1

* Please keep the M306V8T-EPB's packing box and cushion material in your place for reuse at a later time when sending your

product for repair or other purposes. Always use these packing box and cushion material when transporting this product.

* If there is any question or doubt about the packaged product, contact your local distributor.

* NQPACK116SB, YQPACK116SB and YQ-GUIDE are trademarks of Tokyo Eletech Corporation. For purchasing or

technical information, contact your local distributor.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 13 of 90

M306V8T-EPB User’s Manual 1. Outline

1.2 Other Tool Products Required for Development

To bring forward programs development on an M16C/60 Series of the M16C/6V Group M306V8 MCUs, the products listed

below are necessary in addition to those contained package above. Get them separately.

Table 1.2 Other tool products required for development

Product Product name

Emulator main unit PC7501

Renesas Debugger Package for M16C Family Emulator debugger

M3T-PD30

* For purchasing these products, contact your local distributor.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 14 of 90

M306V8T-EPB User’s Manual 1. Outline

1.3 System Configuration

1.3.1 System Configuration

Figure 1.1 shows a configuration of the M306V8T-EPB system.

AC adapter

(3) Emulator PC7501

(4) Host machine

LPT parallel, USB or LAN interface

(1) Emulation probe

M306V8T-EPB

(2) Converter board

M306V8T-PTC

(5) User system

Figure 1.1 System configuration

(1) Emulation probe M306V8T-EPB

This is an emulation probe for the M16C/60 Series M16C/6V Group M306V8 MCUs and contains an evaluation MCU.

(2) Converter board M306V8T-PTC

This is a converter board for connecting to 116-pin 0.65-mm-pitch LQFP foot pattern on the user system. For details, refer

to "2.9 Connecting the User System" (page 30).

(3) Emulator main unit PC7501

The emulator main unit for the M16C family to be used with this product.

(4) Host machine

A personal computer to control the emulator.

(5) User system

This is your application system.

This emulator cannot supply the power to the user system. Therefore design your system so that the user system is powered

separately.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 15 of 90

M306V8T-EPB User’s Manual 1. Outline

1.3.2 Names and Functions of the PC7501 Upper Panel LEDs

Figure 1.2 shows the names of the LEDs on the upper panel of the emulator.

System status

LEDs

Target status

LEDs

Figure 1.2 Names of the LEDs on the upper panel of the PC7501

(1) System Status LEDs

The system status LEDs indicate the emulator PC7501's power supply, firmware operating status, etc. Table 1.3 lists the

definition of each system status LED.

Table 1.3 Definitions of the system status LEDs

Name Status Meaning

ON Emulator system power supply is turned ON. POWER

OFF Emulator system power supply is turned OFF.

SAFE

ON Emulator system is operating normally.

Flashing

1. The self-check is being executed.

2. Downloaded firmware is being written into memory.

3. If the ERROR LED is flashing on at the same time or alternately, it indicates that the self-check error occurred.

PC7501 system is not operating normally (system status error). PC7501 system is not operating normally (system status error).

1. Firmware is being downloaded.

ERROR

OFF

Flashing

2. If the SAFE LED is flashing at the same time or alternately, it indicates that the selfcheck error occurred.

OFF

PC7501 system is operating normally.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 16 of 90

M306V8T-EPB User’s Manual 1. Outline

(2) Target Status LEDs

The target status LEDs indicate operating status of the target MCU and power supply of the user system. Table 1.4 lists the

definition of each target status LED.

Table 1.4 Definition of the target status LEDs

Name Status Meaning

ON Power is supplied to the user system. POWER

OFF Power is not supplied to the user system.

ON Target MCU clock is oscillating. CLOCK

OFF Target MCU clock is not oscillating.

ON Target MCU is being reset. RESET

OFF Target MCU is not being reset.

ON User program is being executed. RUN

OFF User program has been halted.

ON Address 00000h and 00001h have been read out wrongly. WARNING

OFF Address 00000h and 00001h have not been read out wrongly.

IMPORTANT

Note on Usage in Memory Expansion or Microprocessor Mode:

 When you use this product in memory expansion or microprocessor mode, be sure to design your system so that

pins RDY* and HOLD* are not active at startup. Otherwise, it cannot startup normally.

Note on the Target Status POWER LED:

 If your MCU has two or more Vcc terminals, the LED does not light unless power is supplied to all the

terminals.

Note on the Target Status CLOCK LED:

 If the LED is not turned on, check the following.

(1) After powering on the PC7501 (before starting up the emulator debugger): Make sure that the oscillator circuit board is properly installed in the PC7501 and it is oscillating normally. (2) After the emulator debugger is started up (after the Init dialog box settings are completed): Make sure that the oscillator selected in the Init dialog box is oscillating normally.

Note on Accessing Addresses 00000h and 00001h:

 With the M16C/60 Series MCUs, when a maskable interrupt is generated, the interrupt data (interrupt number

and interrupt request level) stored in addresses 00000h and 00001h are read out. Also, the interrupt request bit is cleared when address 00000h or 00001h is read out. Consequently, when the address 00000h or 00001h readout instruction is executed or when address 00000h or 00001h is read out in the cause of a program runaway, a malfunction occurs in that the interrupt is not executed despite the interrupt request, because the request bit of the highest priority interrupt factor enabled is cleared. For this malfunction, when the reading out to address 00000h or 00001h is generated excluding the interrupt, the WARNING LED (yellow) lights up to alarm. When this LED lights, there is a possibility of wrong read access, therefore check the user program.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 17 of 90

M306V8T-EPB User’s Manual 1. Outline

1.4 Specifications

Tables 1.5 lists the specifications of the M306V8T-EPB.

Table 1.5 Specifications of the M306V8T-EPB

Applicable MCU M16C/60 Series M16C/6V Group M306V8 Applicable MCU mode Single-chip mode

Memory expansion mode 16 bit bus width (Normal, Memory expansion mode 2) Microprocessor mode 16 bit bus width (Normal, Memory expansion mode 2)

Maxi. ROM/RAM capacity 1. MCU internal flash ROM: 516KB (0F000h--0FFFFh, 80000h--FFFFFh)

2. MCU internal RAM: 16KB (00400h--043FFh)

3. MCU internal flash OSDRAM: 4KB (08000h--08FFFh)

4. MCU internal flash OSDROM: 128KB (30000h--4FFFFh) Applicable power supply Vcc1 = Vcc2 = Vcc3: 3.15--3.45 V Maximum operating frequency Power supply voltage 3.15 to 3.45 V: 16 MHz Emulation memory 1. Access area: Flash ROM of MCU

Max. operating frequency: 10 MHz

2. External area (CS3*--CS0* area) Possible to allocate up to 4 areas by 4 KB

- Maximum operating frequency (at 3.3 V) 0 wait: 6 MHz 1--3 wait: 16 MHz

Basic debugging functions - Download

- Address match break (max. 8 points)

- Software break (max. 64 points)

- Program execution/stop (allows free-run execution supporting software breaks)

- Memory reference/setting (reference/setting C-variables, run-time execution)

- Register reference/setting

- Disassemble display

- C-level debugging, etc.

Real-time trace function - 256K-cycle bus information recordable

(Bus, external trigger, time stamp)

- 5 trace modes supported (Break/Before/About/After/Full)

- Can be recorded ON/OFF by events

Real-time RAM monitor function - 4,096 bytes (256 bytes x16)

- Data/last access result Hardware break function 8 points (Execution address, bus detection, interrupt, external trigger signal) Execution time measurement function Time between program start and stop

Maximum/minimum/average execution time and pass count of specified four zones.

Count clock: Equal to MCU Clock or 16 MHz C0 coverage 8,192 KB (256 KB x 32 blocks) External trigger input/event output External trigger input (MCU-dependent-voltage CMOS level x8) or event output

(break x1, event x7) Host machine interface - LPT parallel (ECP, EEP, Byte/compatibility and Nibble/compatibility modes)

- USB (USB 1.1, full-speed)*

- LAN (10BASE-T) Power supply to emulator Supplied from included AC adapter (power supply voltage: 100--240 V, 50/60 Hz) Connecting the User System (see 2.9 "Connecting the User System" on page 30)

* Available to connect the host machine that supports USB 2.0.

With the USB interface, not all hardware (such as host machine, USB devices, USB hub) combination will work and

guaranteed.

M306V8T-PTC (pre-mounted) converter board for 116-pin 0.65-mm-pitch LQFP (116P6A-A)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 18 of 90

M306V8T-EPB User’s Manual 1. Outline

1.5 Operating Environment

Be sure to use this emulator with the operating environmental of the emulator and host machine listed in Tables 1.6 and 1.7.

Table 1.6 Operating environmental conditions

Item Description

Operating temperature 5 to 35°C (no dew) Storage temperature -10 to 60°C (no dew)

Table 1.7 Operating environment of the host machine

Item Description

Host machine IBM PC/AT compatibles OS Windows Me

Windows 98SE Windows XP Windows 2000

CPU Pentium III 600 MHz or more recommended Memory 128 MB or more recommended Pointing device such as mouse Mouse or any other pointing device usable with the above OS that can be

connected to the main body of the host machine.

CD drive Needed to install the emulator debugger or refer to the user’s manual

* Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States

and other countries.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 19 of 90

M306V8T-EPB User’s Manual 2. Setup

2. Setup

This chapter describes the preparation for using this product, the procedure for starting up the emulator and how to change

settings.

2.1 Flowchart of Starting Up the Emulator

The procedure for starting up the emulator is shown in Figure 2.1. For details, refer to each section hereafter. And, when the

emulator does not start up normally, refer to “5. Troubleshooting” (page 82).

Connect the M306V8T-EPB to the emulator.

Debug a program with various functions of

Figure 2.1 Flowchart of starting up the emulator

Check the package components. Refer to “1.1 Package Components” (page 13).

▼

User registration Refer to “User Registration” (page 11).

▼

Install the Renesas Debugger Package for

M16C.

▼

Connect the host machine.

▼

Connect the power supply for the emulator. Connect a power supply for the emulator.

▼

Connect the user system. Connect the user system as occasion demands.

▼

Turning on the power supply.

▼

Check the LED display of the emulator.

▼

Start up the emulator debugger from the

High-performance Embedded Workshop.

▼

Set the operating environment

of the emulator debugger.

▼

the emulator debugger

Install or the Renesas Debugger Package for M16C.

Connect the PC7501 to the host machine with the LPT parallel interface cable, USB interface cable or LAN interface cable. Set the interface selection switch on the rear panel of the PC7501 to the using interface.

Connect the M306V8T-EPB and the M3T-FLX160-EPB of the PC7501.

Turn ON the power to the emulator and the user system as simultaneously as possible.

Check that system status LED, and POWER, CLOCK, RESET and WARNING of target status LED are lighting. When the user system is not connected, the POWER LED does not light up.

Start up the High-performance Embedded Workshop, and the emulator debugger.

Set the INIT dialog box and MCU Setting dialog box of the emulator debugger.

For how to use the High-performance Embedded Workshop and the emulator debugger, refer to each online manual.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 20 of 90

M306V8T-EPB User’s Manual 2. Setup

2.2 Installing the Emulator Debugger (Renesas Debugger Package for M16C)

If the OS used in your host machine is Windows XP or 2000, this installation must be executed by a user with administrator

rights. Be aware that users without administrator rights cannot complete the installation.

Install the emulator debugger Renesas Debugger Package for M16C following the procedure described below.

2.2.1 Installing the Emulator Debugger

(1) Downloading the Renesas Debugger Package for M16C

Download the Renesas Debugger Package for M16C from the URL below.

http://download.renesas.com/eng/mpumcu/upgrades/in_circuit_emulators/m16c/index.html

(2) Launching the installer

Start the “setup.exe” program.

(3) Entering the user information

In the “user information” dialog box, enter the user information (contractor, section, contact address, and host machine).

The supplied information will be turned into a format by which technical support will be provided by e-mail.

(4) Selecting components

In the “component selection” dialog box, select the components you want to install. In this dialog box you can change the

directory in which to install.

(5) Completing the installation

A dialog box will be displayed indicating that setup has been completed. It means that the installation you made is

completed.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 21 of 90

M306V8T-EPB User’s Manual 2. Setup

2.3 Connecting the Host Machine

When connecting the emulator PC7501 to a host machine, you can choose your desired interf ace from LPT parallel interface, USB interface and LAN interface. Use the interface selection switch on the emulator PC7501's rear panel to specify your desired interface. Figure 2.2 shows the outline to connect each interface cable.

Figure 2.2 Outline for interface cable connections

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 22 of 90

M306V8T-EPB User’s Manual 2. Setup

2.4 Connecting the PC7501

Figure 2.3 shows how to connect the PC7501 and the emulation probe.

(1) Slide the upper cover of the

M306V8T-EPB to the M306V8TPTC side.

(2) Remove the upper cover.

(3) Unscrew the two screws. (4) Remove the metal plate.

M306V8T-EPB

(1)

(2)

M306V8T-PTC

(3)

(4)

M306V8T-EPB

M306V8T-PTC

(5) Connect CN1 and CN2 of the M3T-

M3T-FLX160-EPB

(5)

FLX160-EPB to J1 and J2 of the M306V8T-EPB, respectively.

* Place the CN1 of the M3T-FLX160-

EPB under the metal plate to connect

M306V8T-EPB

M306V8T-PTC

(7)

the M306V8T-EPB. Place the flexible cable on the upper side of the metal

plate. (6) Attach the metal plate. (7) Tighten the two screws.

(6)

M3T-FLX160-EPB

M306V8T-EPB

Enlarged view

M306V8T-PTC

(8)

(8) Attach the upper cover. (9) Slide the upper cover of the

M306V8T-EPB to the PC7501 side.

(9)

M306V8T-EPB

M306V8T-PTC

Figure 2.3 Connecting the PC7501 and emulation probe

CAUTION

Cautions for Connecting the PC7501:

 When connecting the emulation probe, be sure to hold the both sides of the emulation probe horizontally and

insert it directly.

 Always shut OFF power before connecting the emulation probe. Otherwise, internal circuits may be damaged.  The connectors of the M306V8T-EPB are guaranteed for only 50 insertion/removal iterations.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 23 of 90

M306V8T-EPB User’s Manual 2. Setup

2.5 Connecting the Power Supply for the Emulator

The power is supplied from AC adapter to the emulator PC7501. Here following explains how to connect the AC adapter.

(1) Turn OFF the power to the PC7501.

(2) Connect the DC cable of AC adapter to the PC7501.

(3) Connect the AC power cable to the AC adapter.

(4) Connect the AC power cable to the receptacle.

CAUTION

Cautions for AC Adapter:

 Use only the AC adapter included in PC7501 package.  The included AC adapter is for PC7501. Do not use it for other product.  Before installing this equipment or connecting it to other equipment, disconnect the AC power cable from its

outlet to prevent injury or accident.

 The DC plug on the included AC adapter has the below polarity.

 The included AC adapter has no power supply switch. The AC adapter is always active while connecting the

AC power cable. Check if the power is supplied by the LED of AC adapter.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 24 of 90

M306V8T-EPB User’s Manual 2. Setup

2.6 Turning ON the Power

2.6.1 Checking the Connections of the Emulator System

Before turning the power ON, check the connection of the interface cable with host machine, PC7501, emulation probe, and

user system.

2.6.2 Turning ON/OFF the Power

 Turn ON the power of the emulator and user system as simultaneously as possible.

 Turn OFF the power of the emulator and user system as simultaneously as possible.

 Do not leave either the emulator or user system powered on, because of leakage current the internal circuits may be

damaged.

 When turning ON the power again after shutting OFF the power, wait for about 10 seconds.

IMPORTANT

Notes on Power Supply:

 The emulator's pin Vcc is connected to the user system in order to monitor user system voltage. For this reason,

the emulator cannot supply power to the user system. Therefore, provide the user system with a separate power supply from that of the emulator.

 The voltage of the user system should be as follows.

3.15 V ≤ Vcc1 = Vcc2 = Vcc3 ≤ 3.45 V

 Do not change user system power supply voltage after power has been activated.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 25 of 90

M306V8T-EPB User’s Manual 2. Setup

2.6.3 LED Display When the Emulator Starts Up Normally

Figure 2.4 shows upper panel LED lighting status when the emulator started up properly. Check it when starting up the

emulator system.

・If this LED does not light, check the voltage of the user system. ・Check that power is supplied to all the power terminals. ・W hen the user system is not connected, this LED does not light.

POWER

SAFE

ERROR

SYSTEM

STATUS

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

: ON : OFF : Flashing

Figure 2.4 LED display when the power turned on PC7501

IMPORTANT

Note on Memory Expansion or Microprocessor Mode:

 To use the memory expansion or microprocessor mode, be sure to set pins RDY* and HOLD* so that they are

not active at startup. Otherwise the emulator system will not start up correctly.

Note on the Target Status POWER LED:

 If your MCU has two or more Vcc terminals, the LED does not light unless power is supplied to all the

terminals.

Note on the Target Status CLOCK LED:

 If the LED is not turned on, check the following.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 26 of 90

M306V8T-EPB User’s Manual 2. Setup

2.7 Downloading Firmware

2.7.1 When It is Necessary to Download Firmware

It is necessary to download the firmware in the cases listed below. Normally, the following are automatically detected when the emulator debugger is started up, and the firmware is downloaded.

 When you use this product for the first time  When the firmware has been upgraded  When the emulator debugger or firmware has been upgraded  When you use this product with a PC7501 which was used with another emulation probe before

When you use this product for the first time or when the power is unexpectedly shut down, redownload the firmware in maintenance mode.

2.7.2 Downloading Firmware in Maintenance Mode

Download firmware in the special mode called maintenance mode as explained here following. Figure 4.2 shows LED displays when downloading firmware.

The user system must not be connected when you download the firmware.

(1) Set the interface select switch on the rear panel of the PC7501 to the LPT side and connect the LPT parallel interface

cable to the PC7501 and the host machine.

(2) Within 2 seconds of activating power to the emulator, press the system reset switch on the PC7501 front panel to start

maintenance mode. When the emulator is switched to maintenance mode, the System Status SAFE LED begins to flash.

(3) Start up the emulator debugger. When settings in the Init dialog box are complete, the dialog which urges to downlo ad th e

firmware will appear. Download firmware following messages. Required time for downloading the firmware is about 60 seconds.

POWER

SAFE

ERROR

SYSTEM

STATUS

POWER

SAFE

ERROR

SYSTEM

STATUS

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

POWER

SAFE

ERROR

SYSTEM

STATUS

Maintenance mode

POWER

ERROR

SYSTEM

STATUS

Download complete

TARGET

started

SAFE

TARGET

POWER CLOCK RESET RUN WARNING

STATUS

POWER CLOCK RESET RUN WARNING

STATUS

: ON : OFF : Flashing

POWER

SAFE

ERROR

SYSTEM

STATUS

Downloading firmware

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

Figure 2.5 LEDs during firmware download

IMPORTANT

Note on Downloading Firmware:

 Do not shut OFF power while firmware is being downloaded. Doing so, the emulator will not start up properly.

If power is shut off by mistake, redownload the firmware in maintenance mode.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 27 of 90

M306V8T-EPB User’s Manual 2. Setup

2.8 Self-check

2.8.1 Self-check Procedure

To run the self-check of the emulator, do so as explained here below. While the self-check is in progress, the LEDs will change

as shown in Figure 2.6.

(1) If the user system is connected, disconnect it.

(2) Set the switches as the factory-settings to execute the self-check (see Table 2.1 on page 34 and Table 2.2 on page 35).

(3) Within 2 seconds of activating power to the emulator, press the system reset switch on the emulator front panel to switch

the emulator to maintenance mode.

(4) Check the "SAFE" LED starts flashing and then press the system reset switch again.

(5) The self-check will start. If the normal result is displayed in about 30 seconds, the self-check terminated normally.

POWER

SAFE

ERROR

SYSTEM

STATUS

Maintenance mode

SAFE and ERROR flash

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

started

ERROR 1

ERROR 2

SAFE flashes and

ERROR lights

ERROR 3

SAFE and ERRO R

light alternately

ERROR 4

SAFE goes out and

ERROR lights

Figure 2.6 LED displays in the self-check

POWER

SAFE

ERROR

SYSTEM

STATUS

Self-check te rm in a te d

POWER

SAFE

ERROR

SYSTEM

STATUS

Emulation probe and firmware

do not m a tch

POWER

SAFE

ERROR

SYSTEM

STATUS

TARGET

normally

TARGET

POWER CLOCK RESET RUN WARNING

STATUS

POWER CLOCK RESET RUN WARNING

STATUS

POWER CLOCK RESET RUN WARNING

STATUS

PC7501 system status error

POWER

SAFE

ERROR

SYSTEM

STATUS

Emulation probe initialization

POWER

SAFE

ERROR

SYSTEM

STATUS

error

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

POWER CLOCK RESET RUN WARNING

TARGET

STATUS

Emulation probe status error

: ON : OFF : Flashing

・When the firmware does not support the emulation probe ・When the emulation probe is not connected properly

・When the PC7501 system is not working properly

・When a clock is not supplied to the emulation probe

・When the emulation probe is not working properly

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 28 of 90

M306V8T-EPB User’s Manual 2. Setup

2.8.2 If an Error is Detected in the Self-check

If the self-check does not result normally (ERROR 1 to ERROR 4 in Figure 2.6), check the following.

(1) Recheck the connection of the emulation probe and PC7501.

(2) Redownload the proper firmware.

IMPORTANT

Note on the Self-check:

 Perform the self-check while not connecting the user system.

 If the self-check does not result normally (excluding user system errors), the emulation probe may be damaged.

Then contact your local distributor.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 29 of 90

M306V8T-EPB User’s Manual 2. Setup

2.9 Connecting the User System

Figure 2.7 shows how to connect this product according to your user system.

Emulation probe

M306V8T-EPB

116-pin

0.65-mm pitch

Figure 2.7 Connecting the user system according to user systems

CAUTION

Note on Connecting the User System:

 Take care not to attach a converter board in a wrong direction. It may cause a fatal damage to the emulator and

user system.

M306V8T-PTC

116-pin LQFP

●: No.1 pin

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 30 of 90

M306V8T-EPB User’s Manual 2. Setup

2.9.1 Connecting the User System

When connecting the emulation probe to a 116-pin 0.65-mm-pitch foot pattern on the user system, follow the procedures

below.

(1) Mount the NQPACK116SB (included) to the user system.

(2) Connect the YQPACK116SB (included) to the NQPACK116SB and secure it with the YQ-Guide’s.

(3) Connect M306V8T-PTC to the YQPACK116SB.

M306V8T-PTC

On-board evaluation

(3)

HQPACK116SB

YQ-GUIDE(x4)

YQPACK116SB

(not incluede)

NQPACK116SB

These corners are not round.

(2)

116-pin 0.65-mm-pitch

(116P6A-A) foot patten

(1)

No.1 pin

User system

FLASH MCU etc.

Figure 2.8 Connecting to an 116-pin 0.65-mm-pitch foot pattern

* NQPACK, YQPACK, YQSOCKET, YQ-GUIDE and HQPACK are trademarks of Tokyo Eletech Corporation.

CAUTION

Notes on Connecting the User System:

 Take care not to attach a converter board in a wrong direction. It may cause a fatal damage to the emulator and

user system.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 31 of 90

M306V8T-EPB User’s Manual 2. Setup

2.10 Switch Settings

2.10.1 Setting Switches of Emulation Probe

Set the switches of the emulation probe according to the condition. Figure 2.9 shows the positions of the switches of the

M306V8T-EPB.

(2)

(1)

(Enlarged illustration)

Opening the upper cover (1) Slide aside the upper cover. (2) Then pull the cover upward.

Closing the upper cover Attach the cover, and slide it aside to close.

RM1

RM2

RM3

RM4

RM5

RM6

IC3

C3R1C4C5C6C7R2

SW1 SW2 SW3

R5 R6 R7

C14

SW4

C13

SW5

C10

C11

R8R9 C12

R14

C15

JP2

JP3

R15

C16

Figure 2.9 Positions of the switches

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 32 of 90

M306V8T-EPB User’s Manual 2. Setup

(1) Circuits for JP2, JP3, SW1 to SW5 on the M306V8T-EPB board, OSD resistor, capacitors, etc.

Figure 2.10 shows these circuits.

IC3

OUT2 OUT1

SCL6

SDA6

SCL5

DA0

SDA5

SCL4

SDA4

HSYNC2/DA1

DIGB2 DIGG2 DIGR2 DIGB1 DIGG1 DIGR1

OSCOUT

B/DIGB0

G/DIGG0 R/DIGR0

CVIN1

OUT2

OUT1

SCL6

SDA6

SCL5

DA0

SDA5

SCL4

SDA4

HSYNC2/DA1 DIGB2

A3 A4

DIGG2

DIGR2

DIGB1

DIGG1 DIGR1

OSCOUT

B/DIGB0

G/DIGG0

SW4

CVIN

R/DIGR0

TRGT

EPB

C11

560pF

470ohm

1Mohm

C12

0.1uF

RCA

User system

CVIN2

OSC1/OSCHLF

OSC2/VSYNC1/INT2*

VHOLD1

VHOLD2

HLF1

HLF2

VCC3(OSD)

CNVSS2

TRGT

SW5

CVIN2

EPB

SW1

OSC1

SW2

OSC2

220pFC81uF

560pF

TRGT

EPB

TRGT

1kohm

C15

R14

R15

0ohm

1kohm

470ohm

0ohm

220pF

C16

1Mohm

1kohm

0.1uF

1uF

VCC

RCA

2pF

C13

0.015uF

1000pF

1 2

3 2 1

C14

1000pF

EPB

TRGT

EPB

User system

JP2

User sytem User sytem

JP3

AN3/CAP

C10

SW3

P103/CAP

PORT

CAP

User sytem

C10

1uF

Figure 2.10 Circuits for JP2, JP3, SW1 to SW5, and OSD

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 33 of 90

M306V8T-EPB User’s Manual 2. Setup

(1) Setting JP2, JP3, SW1 to SW5 on the M306V8T-EPB

Tables 2.1 and 2.2 show the settings of JP2, JP3, SW1 to SW5 on the M306V8T-EPB.

Table 2.1 Switch settings of the M306V8T-EPB (JP2, JP3, SW1 to SW5) (1/2)

Switch

Switch name Setting Description

JP2 VCC3

JP3 CNVSS2

(Factory-setting)

●EPB TRGT

1 2 3

●EPB TRGT

1 2 3

●EPB TRGT

Connects pin VCC3 of the evaluation MCU to the internal power supply of the M306V8T-EPB. When the user system is not connected, use this setting.

Connects pin VCC3 of the evaluation MCU to the user system.

Connects pin CNVSS2 of the evaluation MCU to GND in the M306V8T-EPB. When the user system is not connected, use this setting.

1 2 3

●EPB TRGT

Connects pin CNVSS2 of the evaluation MCU to the user system.

SW1,SW2 OSC1,OSC2

OSC1

OSC2

SW1

SW2

●EPB TRGT

(Factory-setting)

OSC1

SW1

●EPB TRGT

OSC2 SW2

●EPB TRGT

Connects pins OSC1 and OSC2 of the evaluation MCU to the internal circuit of the M306V8T-EPB. When the user system is not connected, use this setting

Connects pins OSC1 and OSC2 of the evaluation MCU to the user system.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 34 of 90

M306V8T-EPB User’s Manual 2. Setup

Table 2.3 Switch settings of the M306V8T-EPB (JP2, JP3, SW1 to SW5) (2/2)

Switch

Switch name Setting Description

SW3 P103/CAP

SW4 CVIN1

SW5 CVIN2

P103/CAP

SW3

●TRGT EPB

(Factory-setting)

P103/CAP

SW3

CVIN1 SW4

CVIN2

SW5

●TRGT EPB

●EPB TRGT

Connects pin P103/CAP of the evaluation MCU to the user system.

Connects pin P103/CAP of the evaluation MCU to the internal circuit of the M306V8T-EPB.

Connects pin CVIN1 of the evaluation MCU to the internal circuit of the M306V8T-EPB. When the user system is not connected, use this setting.

Connects pin CVIN1 of the evaluation MCU to the user system.

Connects pin CVIN2 of the evaluation MCU to the internal circuit of the M306V8T-EPB. When the user system is not connected, use this setting.

CVIN2

SW5

●EPB TRGT

Connects pin CVIN2 of the evaluation MCU to the user system.

IMPORTANT

Notes on Switch Settings:

 Be sure to turn of the power before setting the switches or connecting the cables. Otherwise, the internal circuits

may be damaged.

 Use the SWI and SW2 only in the combination of the setting described in Table 2.1.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 35 of 90

M306V8T-EPB User’s Manual 2. Setup

2.10.2 Writing Data to the OSDROM

This product is not able to write data into the OSDROM (internal resources of the evaluation MCU). Remove the evaluation

MCU of IC3 from the IC socket and write data to the OSDROM using the dedicated programmer.

Figure 2.11 shows removing and attaching the evaluation MCU (1 to 6)。

An IC socket lever is on the right side in the figure. The lever may be on the left side, but the evaluation MCU will be removed

and attached in the same procedure.

IC3 (1)

IC3

(3)

(2)

(1) Pull the level. (2) Pull the lever until it stops.

(3) Pull the evaluation MCU upward to remove it.

IC3

Evaluation MCU has been removed. The data will be written into the OSDROM.

IC3

(4)

(5)

IC3 (6)

(4) Attach the evaluation MCU to the IC socket (check position of the No. 1 pin

indicated by the bigger arrow).

(5) Push the lever forward.

(6) Push the lever forward to until it stops.

Figure 2.11 Removing/attaching evaluation MCU

IMPORTANT

Notes on Removing/Attaching Evaluation MCU:

 Before removing or attaching the evaluation MCU, be sure to turn OFF the power supply. Otherwise, the

internal circuit may be damaged.

 When attaching the evaluation MCU to the IC socket, check the position of No.1 pin, Incorrect attachment may

cause a break of evaluation MCU.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 36 of 90

M306V8T-EPB User’s Manual 2. Setup

2.10.3 Pullup of Emulation Ports

Because this product emulates some I/O ports (P0 to P5, P10), you can not pullup ports P0 to P5 by the pullup control registers.

Install the included resistor arrays (51 kΩ) as necessary. Figure 2.12 shows the positions of the pullup resistors. And, Table 2.3

lists the emulation port numbers and the pullup resistor part numbers.

IC3

RM1

RM2

RM3 RM4

RM5

RM6

VCC

b7 b0

VCC

RM1

RM2

RM3

RM4

RM5

RM6

R5 R6 R7

C3R1C4C5C6C7R2

SW1 SW2

SW4

C13

C14

SW5

C10

R8R9C12

C11

C15

SW3

R14

JP2 JP3

R15

C16

Figure 2.12 Positions of the pullup resistors

Table 2.3 Emulation ports and pullup resistor part numbers

Port Resistor part P00--P07 RM1 (51 kΩ pullup) P10--P17 RM2 (51 kΩ pullup) P20--P27 RM3 (51 kΩ pullup) P30--P37 RM4 (51 kΩ pullup) P40--P47 RM5 (51 kΩ pullup) P50--P57 RM6 (51 kΩ pullup)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 37 of 90

M306V8T-EPB User’s Manual 2. Setup

2.11 Selecting Clock Supply

2.11.1 Clocks

You can choose a clock supplied to the evaluation MCU by the Emulator tab in the Init dialog box of the emulator debugger.

Table 2.4 shows the clocks and their initial settings.

Table 2.4 Clock supply to the MCU

Clock

Main (XIN-XOUT)

Sub (XCIN-XCOUT)

Display of

emulator debugger

Internal

External Oscillator circuit on the user system -

Generate

Internal

External Oscillator circuit on the user system Yes

Internal oscillator circuit board

Description Default setting

(OSC-3 or OSC-2)

Internal generator circuit

(1.0--16.0 MHz)

Internal oscillator circuit

(32.768 kHz)

Yes

IMPORTANT

Notes on Changing the Clock Supply:

 The clock supply can be set by the Init dialog box when starting up the emulator debugger or inputting CLK

command on the script window.

2.11.2 Using an Internal Oscillator Circuit Board

(1) Kinds of Oscillator Circuit Boards

The PC7501 comes with an oscillator circuit board OSC-3 (30 MHz). And an oscillator circuit board OSC-3 (16 MHz)

and an oscillator circuit board OSC-2 (bare board) are included with this product. If you use the internal oscillator

circuit board OSC-3 (16 MHz) or OSC-2 of the PC7501 as a main clock, choose "Internal" in the emulator debugger

after replacing oscillator circuit boards to change a clock supplied to an MCU.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 38 of 90

M306V8T-EPB User’s Manual 2. Setup

(2) Replacing an Oscillator Circuit Board

1. Remove the four screws of both sides of this product and lift off the upper cover (see Figure 2.13).

Figure 2.13 Removing the upper cover

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 39 of 90

M306V8T-EPB User’s Manual 2. Setup

1. Replace the oscillator circuit board (see Figure 2.14).

The oscillator circuit board of the PC7501 is in the lower right corner of the board.

Unscrew the screw securing the oscillator circuit board.

Lift off the oscillator circuit board.

Attach another oscillator circuit board to the connector.

Secure the new oscillator circuit board with the screw.

Figure 2.14 Replacing the oscillator circuit board

2. Reinstall the upper cover and secure the four screws.

CAUTION

Note on Replacing the Oscillator Circuit Board:

 Always shut OFF power when removing the upper cover or replacing oscillator circuit board. Otherwise,

internal circuits may be damaged.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 40 of 90

M306V8T-EPB User’s Manual 2. Setup

(3) Using the Internal Oscillator Circuit Bare Board

To use the emulation probe at a frequency you like, build a desired oscillator circuit on the included OSC-2 oscillator circuit

bare board. Figure 2.15 shows an external view of the OSC-2 oscillator circuit bare board and where the connector pins are

located. Figure 2.16 shows the circuitry of the oscillator circuit bare board OSC-2. Use the number of oscillator circuits

recommended by the oscillator manufacturer.

J1-4：GND J1-3：Oscillator output J1-2：GND J1-1：VCC

Figure 2.15 External view of the oscillator circuit board OSC-2 and its connector pin positions

IC1

1011 89

IC1

CLK

X1 ,X2

IC1

1213

IC1

J1-3

Vcc

J1-1

J1-2

GND

J1-4

GND

X1:5.08-mm-pitch 2-pin oscillator

X2:2.54-mm-pitch 2-pin oscillator X3:2.54-mm-pitch 3-pin oscillator

Figure 2.16 Circuits of the oscillator circuit bare board OSC-2

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 41 of 90

IC1:Inverter (Unbuffer)

M306V8T-EPB User’s Manual 2. Setup

2.11.3 Using the Oscillator Circuit on the User System

To operate this product with an external clock, construct the oscillator circuit as shown in Figure 2.17 in the user system and

input the oscillator output at 50% duty (within the operating range of the evaluation MCU) into pin X

. And pin X

OUT

should

be open. Choose "External" in the emulator debugger to use this clock.

Figure 2.17 External oscillator circuit

Make note that in the oscillator circuit shown in Figure 2.18 where a resonator is connected between pins X

and X

OUT

oscillation does not occur because a converter board and other devices are used between the evaluation MCU and the user

system. It is same for sub-clock oscillator circuits (X

CIN

and X

COUT

Figure 2.18 Circuit in which oscillation does not occur

2.11.4 Using the Internal Generator Circuit

The dedicated circuit in the PC7501 can generate any arbitrary frequency specified by the emulator debugger, and it can be

supplied as a main clock. It does not depend on either the oscillator circuit board in the PC7501 or the oscillator circuit on the

user system. If you want to debug programs without the user system or change a frequency temporarily, you can check its

operation before purchasing an oscillator. If you want to use the internal generator circuit in the PC7501 as a main clock,

choose "Generate" in the emulator debugger and specify a frequency you like to use this clock.

Although you can change a frequency between 1.0 and 99.9 MHz by 0.1 MHz for the PC7501, do not specify a value

exceeding the maximum input frequency of the X

of an MCU.

IMPORTANT

Note on Using the Internal Generator Circuit:

 The internal generator circuit is equipped for temporary debugging purposes. Temperature characteristics of

frequencies are not guaranteed.

 Be sure to evaluate your system with an oscillator or oscillator module whose frequency is same as that of the

internal oscillator circuit (internal clock) for final evaluation purposes.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 42 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3. Usage (How to Use the Emulator Debugger)

This chapter describes how to start up the emulator debugger from the High-performance Embedded Workshop.

3.1 Starting Up the Emulator Debugger

When debugging the completed programs, switch the session. The session can be changed by the drop down list of the tool bar shown below.

You will have as many sessions created as the number of targets you selected when creating a project, so select the session that corresponds to the target to be connected from the drop-down list. To connect to the PC7501 + M16C Emulation Probe, select “SessionM16C_R8C_PC7501_Emulator.”

3.1.1 INIT Dialog Box

After specifying the session, an Init dialog box to connect the target is displayed. Th e Init dialog box is used to set the items that need to be set when the emulator debugger starts up. The contents set in this dialog box remain effective the next time you start the debugger. When you have finished settings (1) through (4), click OK.

(1) MCU tab 1 Specifying the MCU file

Specifying the MCU file

Specifying the MCU file (1) Click the “Refer…” Button”. (2) ”Select MCU File” dialog box will be displayed.

Specify the MCU file “M16C6V_512.MCU” for the target MCU.

- The MCU file contains the information specific to the target MCU.

- The MCU file you have selected is displayed in the

MCU section of the MCU tab.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 43 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

2. Specifying the communication interface

Specifying the communication interface (LPT communication)

- For selecting the LPT communication, click the radio

button “LPT” of the MCU tab.

- For the Type area, specify the LPT interface

communication mode to be used.

- Specify the I/O address of the parallel port at the I/O

address area.

- For BIOS setup, the following addresses are

available.

- 378h

- 278h

Specifying the communication interface

(LAN communication)

- For selecting the LAN communication, click the radio

button “LAN” of the MCU tab.

- Specify the IP address of the emulator at the IP

address area.

- Specify the IP address by one byte of decimal number

separating each four bytes with a period.

- Specify the port number at the Port area.

Specifying the communication interface

(USB communication)

- For selecting the USB communication, click the radio

button “USB” of the MCU tab

- The emulators connected by USB cable are shown at

Serial No. area.

- Select the serial No. of the emulator you are going to

connect.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 44 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3. Executing the self-check

Executing the self-check

Enable this function when you want the emulator to be self-

checked at startup. Be sure to select the check box only when

you want the emulator to be self-checked at startup.

This function may be enabled in the following cases:

- When you are using the emulator you have just purchased,

and fail to download the firmware.

- When you successfully download the firmware, but fail to

start up the emulator

- When you want to confirm whether the emulator is

operating normally because, for example, the MCU runs

out of control or something is wrong with the trace results

This function can be enabled only when you are starting up the emulator debugger.

4. Using or not using the address match break function

Using or not using the address match break function

Specify whether or not to use the address match break

function.

- To use the address match break function (default),

Select the check box. In this case, the address match

interrupt is used by the emulator, and cannot be used in the

user program.

- When not using the address match break function,

Deselect the check box. In this case, the address match

interrupt can be used in the user program.

This option can be selected or deselected only when you are starting up the emulator debugger.

5. Using or not using CPU rewrite mode

Using or not using CPU rewrite mode

Specify whether or not to debug in CPU rewrite mode. To

debug the user system that uses CPU rewrite mode, select the

check box. This option can be selected or deselected only

when you are starting up the emulator debugger.

[Supplementary explanation]

When debugging in CPU rewrite mode is enabled, the

following functions cannot be used while executing the user

program:

- Setting the address match breakpoint

- Software breakpoint setting in the internal ROM area

- Execution of COME in the internal ROM area

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 45 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(2) Debugging Information tab

Specifying the compiler used and the object format

Specify the compiler you are using and the format of the object file

output by the compiler.

- Compiler

Select the compiler you are using.

(By default, the C compiler from Renesas is selected.)

- Object Format

Select the format of the object file that is output by the compiler you

are using.

Specifying the method for storing debug information

There are two methods for storing debug information: on-memory

method where data is held in memory and an on-demand method where

data is held in a temporary file.

When selecting the on demand method, check the [On Demand] check

box.

- On Memory Debugging information is stored in the internal memory of your

computer. This method is suitable when the load module (user program) size is small.

- On Demand Debugging information is stored in a reusable temporary file on the

hard disk of your computer. Because the stored debugging information is reused, the next time you download the same load module it can be downloaded at high speed. This method is suitable when the load module (user program) size is large.

(3) Emulator tab

Specifying the target clock

Specify the clock sources supplied to the MCU (main clock and sub

clock). Select the appropriate clock sources according to the clock

used by your target MCU.

- Internal (default)

Emulator PC7501’s internal clock

- External

User system clock

- Generated Clock created in PC7501

The option you have specified here remains effective the next time you start up.

Selecting the event output/trigger input cable

Select input/output of the event output/trigger input cable of the

PC7501.

- Input from External Trigger (default)

Inputs the external trigger from the cable

- Output Events Outputs events from the cable

“Input from External Trigger” is set at startup (the previous setting becomes null).

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 46 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(4) Automatically executing a script command

Automatically executing a script command

To automatically execute a script command when starting

up the debugger, click the “Refer...” button and specify the

script file to be executed.

Clicking the “Refer...” button brings up a file selection

dialog box. The script file you have selected is displayed in

the Init File: section of the dialog box shown here. If you do

not want to automatically execute a script command, delete

the character string displayed in the Init File: section of the

dialog box.

What you specify here is reflected at only startup. If you

specify back again in the Init dialog box after startup,

whatever you specified has no effect. (Be sure to restart the emulator debugger.)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 47 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.1.2 MCU Setting Dialog Box

MCU setting dialog box sets the information of the user system. It will be displayed after closing the Init dialog box.

(1) MCU tab

1. MCU Setting

Specifying the processor mode

Select the appropriate processor mode that suits your system.

Specifying the bus width

M16C/6V8

When specifying memory expansion mode or microprocessor mode, select “16-bit” for “External Data Bus Width”.

Using or not using the memory space expansion function

Specifies whether or not to use the memory space expansion function when selecting memory expansion mode or microprocessor mode. When using the memory space expansion function, select “4MB Mode”. When not, select “Normal Mode”

Using or not using the internal reserved area expansion

Specifies whether or not to expand the internal reserved area. Check this box if the internal reserved area expansion bit (PM13) is “1”.

PM13=0: Internal RAM area: 00400h--03FFFh Internal ROM area: D0000h--FFFFFh PM13=1: Internal RAM area: 00400h--043FFh

Internal ROM area: 80000h--FFFFFh

Switching the CS2 area

Specifies CS2 area. When using the CS2 switching bit (data block enable bit) (PM10) as “1”, check this box. PM10 = 0: 09000h--26FFFh PM10 = 1: 10000h--26FFFh

IMPORTANT

Notes on Selecting a Processor Mode:

 When setting single-chip mode or memory expansion mode, the level of pin CNVSS of the MCU status should

be "L". The MCU status shows the pin level of the user system.

 When setting microprocessor mode, the level of pin CNVSS of the MCU status should be "H".  When setting memory expansion mode or microprocessor mode, pins RDY* an d HOLD* of the user system

should be "H".

 When the user system is not connected, all modes are available.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 48 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

2. Option

M16C/6V8

Setting the debug options

Check the box when not downloading the program to the

internal flash ROM of the MCU. If this box is checked,

the working efficiency (downloading, software break,

etc.) will be improved because the program is

downloaded in the emulation memory in the PC7501.

However, maximum operating frequency is 10MHz The box is unchecked by default.

3. MCU Status

Referring to the MCU Status

It shows the status of each MCU pin. Check it to see if

the MCU status matches the selected processor mode.

“NC” means that the pin status is indeterminate.

M16C/6V8

IMPORTANT

Notes on Selecting a Processor Mode:

 The MCU status is shown in “MCU Status” of the EMEM dialog box. Check that it matches to the processor

mode to be set.

 Check that the RDY* and HOLD* are “H” level. If they are “L” level, as the MCU enters a wait status and the

emulator debugger cannot receive the signal from the MCU, an error is displayed.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 49 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(2) MAP tab

Specifying the emulation memory allocation

Sets the memory area assigned to the emulation memory

by 4KB. Up to four areas can be set.

An area set to [INTERNAL] will be allocated to the

INTERNAL

emulation memory. An unchecked area or an unset area

will be allocated to external area.

The setting is effective only in the CS3*, CS2*, CS1*

and CS0*. The maps of SFR, internal ROM and RAM are set automatically.

Be sure to set the OSDRAM area (8000h -- 8FFFh) to

INTERNAL, and set the OSDROM area (30000h --

4FFFFh) to EXTERNAL (default).

(3) Flash Clear

Setting to clear the MCU’s internal flash ROM

Specify whether or not you want the MCU’s internal

flash ROM to be cleared when downloading the user

program or data. (When cleared, the content of the flash

ROM is initialized to 0xFF.) The MCU’s internal flash

ROM is listed in block units.

- Any block which has had its check box selected is not

cleared when downloading. The memory content of

this block remains intact unless overwritten by

downloading.

- Any block which has had its check box deselected is

cleared when downloading.

- Click the Select All button, and all blocks will be

selected (marked by a check mark, so that none of the

blocks is cleared when downloading).

- Click the Clear All button, and all blocks will be

deselected (check marks removed, so that all of them

are cleared when downloading).

The option you have specified here remains effective the next time you start up.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 50 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.1.3 Checking Connections of the Emulator System

Checking connections of the emulator system

When the emulator debugger is connected correctly to the emulator after you’ve finished setting up the Init dialog box and the MCU Setting dialog box, you will see a message “Connected” displayed on the Debug tab of the Output window.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 51 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.2 Editor (Source) Window

(1) Program window

(2) Program execution

Editor (Source) window

The editor (source) window is a window that always

shows the content of the source file corresponding to the

current position of the program counter. It automatically

opens when the emulator starts up. The program counter

position is identified by the yellow background color.

Here, you can execute the program up to the cursor

position, set or clear software breakpoints, and line-

assemble the source file.

Because the present emulator uses the MCU’s internal flash ROM, the initial value for the ROM area data at the time of purchase is “FFh.”

CPU reset

Resets the CPU.

Runs the program beginning with the current PC position.

Reset Go

Runs the program after reset.

Step In

Single-steps the program executing each statement (including those in functions).

Step Over

Single-steps the program executing each function call as one step.

Step Out

Exists a function and stops at a statement in the program next to the one that called the function.

STOP

Stops the program.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 52 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(3) Setting break points

1. Screen after software breakpoint setup

Breakpoint setup screen

There are three types of breakpoints as described

below.

- Address match breakpoint

This breakpoint can be set only when you chose to

use the address match break function on the MCU

tab of the Init dialog box.

A breakpoint can be set or cleared by double-

clicking in the address match breakpoint display

area in the editor (source) window. (A blue circle

is displayed at the setting line)

Up to eight breakpoints can be set. When this

limit is exceeded, software breakpoints are set.

The address match break causes the program to

stop before executing the address at which a

breakpoint is set.

- Software breakpoint

A software breakpoint can be set or cleared by

double-clicking the software breakpoint display

area in the editor (source) window (A red circle is

displayed at the setting line).

This is rewritten to a break instruction, therefore,

because of rewriting flash ROM, program

execution starts with a delay of several seconds

after setting ROM area.

If the breakpoint you set is a software breakpoint,

the program stops before executing the instruction

at the set breakpoint.

- Hardware breakpoint

A hardware breakpoint can be set or cleared by

right-clicking the breakpoint display area.

If the breakpoint you set is a hardware breakpoint,

the program stops after executing the instruction

at the set breakpoint (after several cycles).

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 53 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(4) Executing up to the cursor position (Come command)

1. Specifying the Come command

Setup procedure for executing COME command

(1) Click the line in the program display area at which

you want the program to execute.

2. After the Come command has finished

(2)

Click the Come button

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 54 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.3 Hardware Breakpoint Setting Window

(1) Breakpoint setup dialog box

1. Opening the hardware breakpoint setup dialog box

2. Hardware Break Point Setting Window in initial state

Hardware Break Point

Clicking this button opens the hardware breakpoint setup dialog box.

H/W breakpoint Setting Window in initial state

Select the “Enable H/W Break” check box, and this break function will be enabled, allowing you to set hardware breakpoints.

Setting Break Event

Click the event line at which you want set a break event.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 55 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3. Opening the break event setting dialog box

Specifying the event type

Click to select the event type you want to set.

- FETCH

Detects an instruction prefetch.

- DATA ACCESS

Detects a memory access.

- BIT SYMBOL

Detects a bit access.

- INTERRUPT

Detects an interrupt occurrence or interrupt termination.

- TRIGGER

Detects a signal from the external trace signal input

cable.

(2) When FETCH is selected

1. Window for setting addresses

Setting the address

You can set eight conditions, e.g., a specified address, a

specified address range, etc. When you have finished

setting the address, click OK.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 56 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(3) When DATA ACCESS is selected

1. Window for setting the address

Setting the address

You can set eight conditions, e.g., a specified address, a

specified address range, etc.

When you have finished setting the address, click OK.

2. Window for setting data

Setting data

You can set eight conditions, e.g., a specified data, a

specified data range, etc.

Setting the access condition

You can set three conditions, e.g., read, write, and

read/write. When you have finished setting the data and

access condition, click OK.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 57 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3. Example Data Settings

Setting events for wordwise accesses to the even-addresses

STE.W A0,20E8h(A0=5423h)

High-order and low-order data effective

Setting events for wordwise accesses to the odd-addresses STE.W A0,20E5h(A0=AB79h)

Odd-address high-order data effective Even-address low-order data effective

Setting events for wordwise accesses to the even-addresses STE.B R0L,[A1A0](R0L=E5h,A1=0000h,A0=20E2h)

Low-order data effective

Setting events for wordwise accesses to the odd-addresses STE.B R0L,[A1A0](R0L=E6h,A1=0000h,A0=20E3h)

Setting a break event

A1 Address 1 : 0020E8 Data 1 : 5423 MASK : FFFF Access : WRITE

Setting a break event (using 2 events)

A1 A2 Address 1 : 0020E5 Address 1 : 0020E6 Data 1 : 7900 Data 1 : 00AB MASK : FF00 MASK : 00FF Access : WRITE Access : WRITE

Set the combinatorial events to AND.

Setting a break event

A1 Address 1 : 0020E2 Data 1 : 00E5 MASK : 00FF Access : WRITE

Setting a break event

A1 Address 1 : 0020E3 Data 1 : E600 MASK : FF00 Access : WRITE

High-order data effective

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 58 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(4) Setting the combinatorial event condition

1. Window for setting the combinatorial event condition

Setting the combinatorial event condition

There are following four conditions that you can choose for

the combinatorial events.

- AND

The program breaks when all of the specified events

occur.

- AND (Same Time)

The program breaks when the specified events occur at

the same time.

- OR

The program breaks when one of the specified events

occurs.

- STATE TRANSITION

The program breaks when the state transition diagram

goes into the break state.

For each event, a pass count (number of passing) is

specifiable (1--255). When “AND” (same time) is specified

for Combination, you can not specify the pass count (fixed

to one).

When you have finished setting the combinatorial event condition, click the “Set” button.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 59 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.4 Trace Window

The trace window is used to show the results of real-time trace measurements.

(1) Trace window

1. Trace window display

Trace window

The trace window is used to show the results of real-time trace

measurements. It has the following four display modes:

- Bus mode

Bus information per cycle can be inspected. The contents are

displayed in order of execution paths.

- Disassemble + data access mixed mode

The executed instruction and the content of the accessed data

can be inspected together. Contents are displayed in order of

the execution paths.

- Disassemble mode

The execution paths of the executed instructions can be

inspected. The contents are displayed in order of execution

paths.

- Source mode

The execution paths of the source program can be inspected.

These modes can be switched over using the respective toolbar

buttons.

The trace window shows the measurement result when a real-

time trace measurement has finished. The trace window

remains blank until the real-time trace measurement in

progress finishes.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 60 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

2. Trace window (Bus display)

3. Trace window (Disassemble display)

4. Trace window (Source display)

Explanation of the trace window (bus display)

The following explains the displayed contents, from left to right.

- Address Shows the status of the address bus.

- Data Shows the status of the data bus.

- BUS

Shows the width of the external data bus. In the present

emulator, only “16b” for 16 bits wide bus is displayed.

- BHE*

Shows the status (0 or 1) of the BHE (Byte High Enable)

signal. If this signal = 0, the odd-address data is valid.

- BIU

Shows the status between the BIU (Bus Interface Unit) and

memory or I/O.

Symbol Status

- : No change

DMA : Data access except for CPU INT : Starts INTACK sequence IB : Instruction code read (bytes) by CPU DB : Data access (bytes) by CPU IW : Instruction code read (words) by CPU DW : Data access (words) by CPU

- R/W

Shows the status of the data bus. Displayed as “R” for Read,

“W” for Write, and “–” for no access.

- RWT

This is the signal to indicate a valid bus cycle. When valid,

RWT = 0. The Address, Data, and the BIU signals are effective

when this signal is 0.

- CPU

Shows the status between the CPU and BIU (Bus Interface

Unit).

Symbol Status

CB : Op-code read (bytes) RB : Operand read (bytes) QC : Clears instruction queue buffer CW : Op-code read (words) RW : Operand read (words)

- QN Shows the byte count stored in the instruction queue buffer. The display range is 0 to 4.

- 76543210 Shows the level of external trace signal input cable EXTIN0 to EXTIN7.

- h” m’ s: ms. us

Shows the elapsed time after starting the user program.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 61 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

(2) Trace point setup window

1 Trace point setup window

Trace Point Setting Window in initial state

Clicking this toolbar button opens the trace point setting

window.

You can set events in the same way as for the hardware breakpoints.

Specifying a trace range

You can specify a trace range for the trace event.

- Break 256K cycles of instruction execution before the user program stopped is recorded.

- Before 256K cycles of instruction execution before a trace point condition was met is recorded.

- About 128K cycles of instruction execution before and after a trace point condition was met is recorded.

- After 256K cycles of instruction execution after a trace point condition was met is recorded.

- Full 256K cycles of instruction execution after a trace began is recorded.

2. Setting the trace write condition

Setting the trace write condition

You can specify a condition for the cycles to be written into the trace memory.

- Total

All cycles are written into memory.

- Pick up

Only the cycles in which the specified condition was met are

written into memory.

- Exclude

Only the cycles in which the specified condition was not met are

written into memory.

When you have finished setting the trace write condition, click this button. The Realtime-trace Write Condition dialog box shown below will appear.

3. Realtime trace Write Condition dialog box

Write mode

Only the cycle in which the specified Start event occurred

A range of cycles from when the specified Start event occurred to when the specified Start event became nonexistent.

A range of cycles from when the specified Start event occurred to

when the specified End event occurred.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 62 of 90

M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)

3.5 RAM Monitor Window

This function makes it possible to make reference to the changes in memory contents without impairing the real-time

performance for target program execution. The emulator PC7501 system is provided with the 4KB RAM monitor area. This

RAM monitor area can be divided into the 16-block area in units of arbitrary continuous address or 256 bytes for mapping or

layout.

(1) RAM monitor window

1. RAM monitor area setting window in initial state

RAM monitor

Clicking this button opens the RAM monitor window.

Changing the RAM monitor display area

You can change the manner in which the RAM monitor area you have set in the above dialog box is displayed.

: Shows the blocks at the preceding addresses.

: Shows the blocks at the following addresses.

The background colors of the data display and the code display sections

change with the access attribute as described below.

- Green : Addresses accessed for read

- Red : Addresses accessed for write

- White : Addresses not accessed

The background colors can be changed as necessary.

RAM Monitor Area Setting Window in initial state

By default, the monitor area is set to 000400h through 0007FFh. To

change it, click the line you want to set.

Specifying the start address

You can set the start address of the RAM area to be monitored. To add

a RAM monitor area, click the "Add..." button. The RAM Monitor Area

Setting Window will be displayed.

2. RAM monitor area setting dialog box

Specifying the start address

You can set the start address of the RAM area to be monitored.

Specifying the size

You can set the size to be monitored by specifying the number of blocks

from the start address. One block is 256 bytes in size.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 63 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4. Hardware Specifications

This chapter describes specifications of this product.

4.1 Target MCU Specifications

Table 4.1 lists the specifications of target MCUs which can be debugged with this product.

Table 4.1 Specifications of target MCUs for the M306V8T-EPB

Item Description

Applicable MCU M16C/60 Series M16C/6V Group M306V8

Evaluation MCU M306V8FJGS

ROM size : 512KB＋4KB , RAM size : 16KB

Applicable MCU mode Single-chip mode

Memory expansion mode 16 bit bus width (NORMAL, 4MB) Microprocessor mode 16 bit bus width (NORMAL, 4MB)

Maxi. ROM/RAM capacity 1. MCU internal flash ROM: 516KB (0F000h--0FFFFh, 80000h--FFFFFh)

2. MCU internal RAM: 16KB (00400h--043FFh)

3. MCU internal flash OSDRAM: 4KB (08000h--08FFFh)

4. MCU internal flash OSDROM: 128KB (30000h--4FFFFh)

Power supply voltage 3.15 V ≤ Vcc1 = Vcc2 = Vcc3 ≤ 3.45 V

Operating voltage/frequency Power supply voltage 3.15 to 3.45 V: 16 MHz

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 64 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.2 Access Timing

Because this product emulates some ports, access timings are different from those of the actual MCUs. Chapter 4.2.1 describes

the access timing using this product.

4.2.1 Operation Timing of Memory Expansion Mode and Microprocessor Mode (Vcc1=Vcc2=Vcc3=3.3V)

(1) Separate Bus Timing

Table 4.2 and Figure 4.1 show the bus timing in memory expansion mode and microprocessor mode.

Table 4.2 Memory expansion mode and microprocessor mode (3-wait, accessing external area)

Actual MCU

Symbol Item

td(BCLK-AD) Address output delay time 30 36 th(BCLK-AD) Address output hold time (BCLK standard) 4 See left th(RD-AD) Address output hold time (RD standard) 0 -3 th(WR-AD) Address output hold time (WR standard) (*2) (*3) td(BCLK-CS) Chip-select output delay time 30 See left th(BCLK-CS) Chip-select output hold time (BCLK standard) 4 See left td(BCLK-ALE) ALE signal output delay time 30 See left th(BCLK-ALE) ALE signal output hold time -4 See left td(BCLK-RD) RD signal output delay time 30 33 th(BCLK-RD) RD signal output hold time 0 See left td(BCLK-WR) WR signal output delay time 30 38 th(BCLK-WR) WR signal output hold time 0 See left td(BCLK-DB) Data output delay time (BCLK standard) 40 43 th(BCLK-DB) Data output hold time (BCLK standard) 4 See left td(DB-WR) Data output delay time (WR standard) (*1) See left th(WR-DB) Data output hold time (WR standard) (*2) (*3)

*1 Calculated by the following formula according to the frequency of BCLK.

()

BCLKf

×−

105.0 40

−

[ns] n: "3" for 3-wait

)(

[ns]

Min. Max. Min. Max.

This product

[ns]

*2 Calculated by the following formula according to the frequency of BCLK.

105.0

BCLKf

*3 Calculated by the following formula according to the frequency of BCLK.

BCLKf

[ns]

)(

105.0 17

−

[ns]

)(

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 65 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

Read timing

BCLK

CSi

ADi

BHE

ALE

DBi

Write timing

BCLK

td(BCLK-CS)

tcyc

td(BCLK-AD)

td(BCLK-ALE)

Hi-Z

td(BCLK-CS)

th(BCLK-ALE)

td(BCLK-RD)

tac2(RD-DB)

tsu(DB-RD)

th(BCLK-CS)

th(RD-CS)

th(BCLK-AD)

th(RD-AD)

th(BCLK-RD)

th(RD-DB)

th(BCLK-CS)

CSi

tcyc

td(BCLK-AD)

ADi

BHE

td(BCLK-ALE)

th(BCLK-ALE)

ALE

td(BCLK-WR)

WR ,

WRL , WRH

td(BCLK-DB)

DBi

Hi-Z

td(DB-WR)

Figure 4.1 Memory expansion mode and microprocessor mode (3-wait, accessing external area)

th(WR-CS)

th(BCLK-AD)

th(WR-AD)

th(BCLK-WR)

th(BCLK-DB)

th(WR-DB)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 66 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

(2) Multiplex Bus Timing

Table 4.3 and Figure 4.2 show the bus timing in memory expansion mode and microprocessor mode (2-wait, accessing

external area, using multiplex bus).

Table 4.3 Memory expansion mode and microprocessor mode (2-wait, accessing external area, using multiplex bus)

Actual MCU

Symbol Item

td(BCLK-AD) Address output delay time 50 See left th(BCLK-AD) Address output hold time (BCLK standard) 4 See left th(RD-AD) Address output hold time (RD standard) (*1) (*4) th(WR-AD) Address output hold time (WR standard) (*1) (*4) td(BCLK-CS) Chip-select output delay time 50 See left th(BCLK-CS) Chip-select output hold time (BCLK standard) 4 See left th(RD-CS) Chip-select output hold time (RD standard) (*1) See left th(WR-CS) Chip-select output hold time (WR standard) (*1) See left td(BCLK-RD) RD signal output delay time 40 See left th(BCLK-RD) RD signal output hold time 0 See left td(BCLK-WR) WR signal output delay time 40 See left th(BCLK-WR) WR signal output hold time 0 See left td(BCLK-DB) Data output delay time (BCLK standard) 50 See left th(BCLK-DB) Data output hold time (BCLK standard) 4 See left td(DB-WR) Data output delay time (WR standard) (*2) See left th(WR-DB) Data output hold time (WR standard) (*1) See left td(BCLK-ALE) ALE output delay time (BCLK standard) 40 See left th(BCLK-ALE) ALE output hold time (BCLK standard) -4 See left td(AD-ALE) ALE output delay time (Address standard) (*3) See left th(ALE-AD) ALE output hold time (Address standard) (*4) See left td(AD-RD) After address RD signal output delay time 0 -25 td(AD-WR) After address WR signal output delay time 0 -25 tdz(RD-AD) Address output floating start time 8 25

*1 Calculated by the following formula according to the frequency of BCLK.

105.0

BCLKf

[ns]

)(

[ns]

Min. Max. Min. Max.

This product

[ns]

*2 Calculated by the following formula according to the frequency of BCLK.

()

BCLKf

*3 Calculated by the following formula according to the frequency of BCLK.

105.0

BCLKf

*4 Calculated by the following formula according to the frequency of BCLK.

105.0

BCLKf

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 67 of 90

×−

105.0 50

−

[ns] n: "2" for 2-wait

)(

−

[ns]

)(

−

[ns]

)(

M306V8T-EPB User’s Manual 4. Hardware Specifications

Read timing

tcyc

BCLK

CSi

td(BCLK-CS)

th(BCLK-CS)

ADi

/DBi

ADi

BHE

ALE

Write timing

BCLK

CSi

ADi

/DBi

ADi

BHE

td(AD-ALE) th(ALE-AD)

td(BCLK-AD)

td(BCLK-ALE)

th(BCLK-ALE)

tcyc

td(BCLK-CS)

td(AD-ALE) th(ALE-AD)

td(BCLK-AD)

td(BCLK-ALE)

tdz(RD-AD)

td(AD-RD)

td(BCLK-RD)

td(BCLK-DB)

td(AD-WR)

tac3(RD-DB)

Hi-Z

td(DB-WR)

tsu(DB-RD)

th(RD-CS)

th(RD-DB)

th(BCLK-AD)

th(RD-AD)

th(BCLK-RD)

th(BCLK-CS)

th(WR-CS)

th(BCLK-DB)

th(WR-DB)

th(BCLK-AD)

th(WR-AD)

ALE

th(BCLK-ALE)

td(BCLK-WR)

th(BCLK-WR)

WR,

WRL,WRH

Figure 4.2 Memory expansion mode and microprocessor mode (2-wait, accessing external area, using multiplex bus)

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 68 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

(3) Timing Requirements

Tables 4.4 and Figure 4.3 list the timing requirements.

Table 4.4 Timing requirements

Symbol Item

Actual MCU

[ns]

This product

[ns]

Min. Max. Min. Max. tsu(DB-RD) Data input setup time 50 75 tsu(RDY-BCLK) RDY* input setup time 40 60 tsu(HOLD-BCLK) HOLD* input setup time 50 70 th(RD-DB) Data input hold time 0 See left th(BCLK-RDY) RDY* input hold time 0 See left th(BCLK-HOLD) HOLD* input hold time 0 See left td(BCLK-HLDA) HLDA* output delay time 40 See left

Common to “with wait” and “no wait” (actual MCU)

BCLK

tsu(HOLD-BCLK)

HOLD input

HLDA output

P0,P1,P2,P3,P4,

0 - P5 2

Common to “with wait” and “no wait” (this product)

BCLK

tsu(HOLD-BCLK)

input

HOLD

output

HLDA

td(BCLK-HLDA)

P0,P1,P2,P3,P4,

0 - P5 2

td(BCLK-HLDA)

th(BCLK-HOLD)

Hi-Z

th(BCLK-HOLD)

Hi-Z

td(BCLK-HLDA)

Figure 4.3 Timing requirements

* Compared with an actual MCU, this product enters high-impedance state after a 0.5 cycle delay.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 69 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.3 Differences between the Actual MCU and Emulator

Differences between the actual MCU and emulator are shown below. When debugging the MCU using this product, be careful

about the following precautions.

IMPORTANT

Note on Differences between the Actual MCU and Emulator:

 Operations of the emulator system differ from those of actual MCUs as listed below.

(1) Reset condition Set the time for starting up (0.2 Vcc to 0.8 Vcc) 1 μs or less. (2) Initial values of internal resource data of an MCU at power-on (3) Interrupt stack pointer (ISP) after a reset is released (4) Capacities of the internal memories (ROM, RAM, OSDRAM and OSDROM) The evaluation MCU of this product has RAM of 16 KB (00400h--043FFh) and flash ROM of 4 KB

(0F000h--0FFFFh) + 512 KB (80000h--FFFFFh), OSDRAM of 4 KB (8000h--8FFFh) and OSDROM of

128KB (30000h--4FFFh). (5) Oscillator circuit In the oscillator circuit where an oscillator is connected between pins X

occur because a converter board is used between the evaluation MCU and the user system. It is same for

pins X

CIN

and X

. For notes on when using the oscillator circuit on the user system, refer to "2.11.3

COUT

Using the Oscillator Circuit on the User System " (page 42). (6) A/D conversion The characteristics of the A/D converter differ from those of actual MCU because there are a converter

board and other devices between the evaluation MCU and the user system. (7) Ports P0 to P5, P10 This product emulates some I/O ports (P0 to P5, P10). Therefore, the electrical characteristics of these

ports differ from those of an actual MCU. (8) Address and status of BHE* When the internal RAM or ROM area of an MCU is accessed during user program execution, actual

MCUs retain a preceding address and status of BHE*, while this product does not. (9) Status of a data bus In stop or wait mode, actual MCUs retain a preceding status of a data bus, while with this product a data

bus is floating. (10) Operation after releasing the reset After releasing the reset, for about max. 380 cycles, a program to control the emulator will be executed.

Note that this will be included in the user program execution time and tracing result.

Note on RESET* Input:

 A low input to pin RESET* from the user system is accepted only when a user program is being executed (only

while the RUN status LED on the emulator's upper panel is lit).

Note on RDY* Input:

 Be sure to input "L" to pin RDY* of the user system during the user program executing (when the RUN status

LED on the PC7501's upper panel is lit). Inputting "L" to pin RDY* during the user program stopping may cause a malfunction of the emulator.

Note on HOLD* Input:

 Be sure to input "L" to pin HOLD* of the user system during the user program executing (when the RUN status

LED on the PC7501's upper panel is lit). Inputting "L" to pin HOLD* during the user program stopping may cause a malfunction of the emulator.

and X

, oscillation does not

OUT

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 70 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Notes on Reset Vector Area:

 Memory in the emulator main unit is always selected as a reset vector area (FFFFCh--FFFFFh) in order to

operate the evaluation MCU in the emulator-dedicated mode. Set the contents of the reset vector area in one of the following ways.

(1) Download a user program to an area including the reset vector area. (2) Set the reset vector using a memory window of the emulator debugger etc.

 A reset vector area can be changed only when a program is stopped.

 Do not access the rest vector area as data. It may not be accessed properly, and the program may not run

properly in the next bus cycle.

Notes on Stack Area:

 With this product, a maximum 8 bytes of the user stack is consumed as a work area. Therefore, ensure the +8

byte maximum capacity used by the user program as the user stack area. If the user stack does not have enough area, do not use areas which cannot be used as stack (SFR area, RAM area which stores data, or ROM area) as work area. Using areas like this is a cause of user program crashes and destabilized emulator control.

 With this product, the interrupt stack pointer (ISP) is set to 00500h and used as stack area after the reset is

released.

Notes on Maskable Interrupts:

 Even if a user program is not being executed (including when run-time debugging is being performed), the

evaluation MCU keeps running so as to control the emulation probe. Therefore, timers and other components do not stop running. If a maskable interrupt is requested when the user program is not being executed (including when run-time debugging is being performed), the maskable interrupt request cannot be accepted, because the emulator disables interrupts. The interrupt request is accepted immediately after the user program execution is started.

 Take note that when the user program is not being executed (including when run-time debugging is being

performed), a peripheral I/O interruption is not accepted.

Note on DMA Transfer:

 With this product, the user program is stopped with a loop program to a specific address. Therefore, if a DMA

request is generated by a timer or other source while the user program is stopped, DMA transfer is executed. However, make note of the fact that DMA transfer while the program is stopped may not be performed correctly. Also note that the below registers have been changed to generate DMA transfer as explained here even when the user program is stopped. (1) DMA0 transfer count register TCR0 (2) DMA1 transfer count register TCR1

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 71 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Notes on Pullup Control:

 Because this product emulates some I/O ports (P0 to P5, P10), you can not pullup ports P0 to P5 by the pullup

control registers, Install the included resistor arrays (51 kΩ) as necessary.

 The initial value of pullup control register 1 PUR1 of this product is different from that of an actual MCU.

When a Vcc level is input to pin CNVss, the value of an actual MCU is “02h” (bit 1 PU11 is “1”), while that of this product is “00h”.

Note on Setting "1" to Protect Bit 2 (PCR2) with Sub Clock:

 When the CPU clock is set to the sub-clock (low-speed mode or low power dissipation mode), even if you

enable the PRC2 bit, writing to the register protected by the PRC2 bit (PD9, address 0362h and 0366h registers) cannot be done properly. When you enable the PRC2 bit and write to the register protected by the PRC2 (PD9, address 0362h and 0366h registers), do not set the CPU clock to the sub-clock.

Note on Setting "1" to Protect Bit 2 (PRC2) in Division by 2 Mode:

 Under the following conditions, even if you enable the PRC2 bit, writing to the register protected by the PRC2

bit (PD9, address 0362h and 0366h registers) cannot be done properly. (1) Between when stop mode is released and when a hardware reset is executed (2) Between when low power dissipation mode is enabled and when a hardware reset is executed Therefore, if the condition (1) or (2) applies, when you enable the PRC2 bit and write to the register protected by the PRC2 (PD9, address 0362h and 0366h registers), set the CPU clock neither to the main clock in division by 2 mode nor to the on-chip oscillator clock in division by 2 mode.

Note on the Input Thresholds for the Pins P1_5/D13/INT3, P1_6/D14/INT4 and P1_7/D15/INT5

 With this product, regarding pins P1_5/D13/INT3, P1_6/D14/INT4 and P1_7/D15/INT5, a device which port or

data bus inputs to and a device which INT interrupt inputs to are different as follows:

Device which port or data bus inputs to: Port emulation FPGA (input level: TTL) Device which INT interrupt inputs to: Evaluation MCU for emulating peripheral functions (input level:

CMOS Schmidt) Therefore, the port input level can be read as “H” immediately after an INT interrupt (falling), and the port input level can be read as “H” immediately before an INT interrupt (rising).

Note on Final Evaluation:

 Be sure to evaluate your system with an evaluation MCU. Before starting mask production, evaluate your

system and make final confirmation with a CS (Commercial Sample) version MCU.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 72 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.4 Connection Diagrams

Figure 4.4 shows a connection diagram of the M306V8T-EPB. This connection diagram mainly show the circuit to be

connected to the user system. The circuits not connected to the user system such as the emulator’s control system are omitted.

Tables 4.5 and 4.6 show IC electric characteristics of this product for reference purpose.

IC3

M16C/6V8 I/O Emulate

IC4

Port Emulation FPGA

P67--P60 P77--P70

P83,P82 P91,P90

P86/Xcout

Xout

P87/Xcin

OSD Signal

AN7--AN3

P17--P15

P67--P60 P77--P70 P83,P82

74HC4066

7WH125

74HC4066

R3：0Ω

R2：0Ω

Vcc

*: Connected to the inside of the emulator .

510kΩ Vcc

51kΩ Vcc

74HC4066

Vcc

51kΩ

Vcc

51kΩ

510kΩ Vcc

Pullup registers in indicated by dashed line: socket mounted.

Vcc

P91,P90

P86/Xcout

Xout

P87/Xcin

OSD SignalOSD circuit

P107--P103

P07--P00

P27--P20

P17--P10 P37--P30 P47--P40 P57--P50

CNVss1

BYTE

RESET*

Xin

User system

Figure 4.4 Connection diagram

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 73 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

Table 4.5 Electrical characteristics of the 74HC4066

Symbol Item

RON ON resistor

ΔRON ON resistor difference

IOFF Leak current (Off)

IIZ Leak current (On, output: open) 12.0V - - ±100

Condition Standard values Unit

VCC

Min. Standard Max.

4.5V - 96 170

4.5V - 10 -

12.0V - - ±100

Ω

µA

Table 4.6 Electrical characteristics of port emulation FPGA

Symbol Item Condition

Standard values

Min. Standard Max.

Unit

VIH "H" level input voltage 2.0 - 5.5 VIL "L" level input voltage -0.5 - 0.8

VOH "H" level output voltage

VOL "L" level output voltage

IOH=-8mA DC, Vcc=4.75V I

OH=-8mA DC,

Vcc=3.00V IOL=8mA DC, Vcc=4.75V I

OL=8mA DC,

Vcc=3.00V

2.4 - -

- - 0.45

IOZ Leak current (Tristate) Vo=Vcc or GND -40 - 40 µA

IN=0V,

CIN I/O pin input capacitance

V f=1.0MHz

- - 8 pF

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 74 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.5 External Dimensions

4.5.1 External Dimensions of the Emulation Probe

Figure 4.5 shows external dimensions of the M306V8T-EPB.

665

320 290 55

RENESAS

140

Figure 4.5 External dimensions of the emulation probe

Unit: mm

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 75 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.5.2 External Dimensions of the M306V8T-PTC

Figure 4.6 shows external dimensions of the converter board M306V8T-PTC for a 116-pin LCC (included with the M306V8T-

EPB).

53.0

M306V8T-PTC REV.A

53.0

CN1

116

CN2

87 88

IC1

129

MADE IN JAPAN

59 58

0.25

19.0

23.0

0.65

19.0

23.0

16.5

Unit: mm

Figure 4.6 External dimensions of the M306V8T-PTC

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 76 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

4.6 Notes on Using This Product

Notes on using this product are listed below. When debugging the MCU using he emulator, be careful about the following

precautions.

IMPORTANT

Note on the Version of the Emulator Debugger:

 Be sure to use this product with one of the following emulator debuggers.

1. Renesas Debugger Package for M16C R8C PC7501 V.1.00.00 Release 01 or later

2. M3T-PD30F V.2.20 Release 1 or later

Note on Selecting the MCU File:

 Select the MCU file “M16C6V8.mcu” at emulator startup.

Notes on Downloading Firmware:

 Before using this product for the first time, it is necessary to download the dedicated firmware. Please note that,

to do this, it is necessary to start up the emulator main unit in maintenance mode. For downloading firmware, see "2.7 Downloading Firmware" (page 27). Once the firmware has been downloaded, the product can be used by simply turning on the power.

 Do not shut off the power while downloading the firmware. If this happens, the product will not start up

properly. If the power is shut off unexpectedly, redownload the firmware.

 Download the firmware with the user system not connected.

Notes on Self-check:

 If the self-check does not result normally (excluding user system errors), the emulation probe may be damaged.

Then contact your local distributor.

 Run the self-check with the user system not connected.

Note on Quitting the Emulator Debugger:

 To restart the emulator debugger, always shut power to the emulator module off once and then on again.

Note on Display of MCU Status:

 "MCU status" you can refer to in the MCU tab of the MCU Setting dialog box of the emulator debugger shows

pin levels of the user system. Make sure that proper pin levels are specified according to the mode you use.

(1) When single-chip mode is used: CNVss: Low (2) When memory expansion mode 16-bit data bus width is used: CNVss: Low, BYTE: Low, HOLD*: High, RDY*: High (3) When microprocessor mode 16-bit data bus width is used: CNVss: High, BYTE: Low, HOLD*: High, RDY*: High

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 77 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Note on Clock Supply to the MCU:

 A clock supplied to the evaluation MCU is selected by the Emulator tab in the Init dialog box of the emulator

debugger. (1) When "Internal" is selected: A clock generated by the oscillator circuit board in the PC7501 is supplied. It is continually supplied

regardless of the status of the user system clock and that of the user program execution. (2) When "External" is selected: A clock generated by the oscillator in the user system is supplied. It depends on the status of the oscillation

(on/off) of the user system. (3) When "Generate" is selected: A clock generated by the dedicated circuit in the PC7501 is supplied. It is continually supplied regardless of

the status of the user system clock and that of the user program execution.

Note on Operating Frequency:

 You can not use this product with a main clock (XIN-X

than 1 MHz, contact your local distributor.

Notes on Map Settings:

 Be sure to set the OSDRAM area (8000h -- 8FFFh) to INTERNAL.

 Be sure to set the OSDROM area (30000h -- 4FFFFh) to EXTERNAL.

Note on Stop and Wait Modes:

 Do not single step an instruction shifting to stop or wait mode. It may cause communication errors.

Note on the Watchdog Function:

 If the reset circuit of the user system has a watchdog timer, disable it when using the emulator.

Note on Access Prohibited Area:

 You cannot use internally reserved areas. Write signals to the areas will be ignored, and values read will be

undefined.

Note on Protect Register:

 The protect is not canceled when bit 2 of protect register PRCR (PRC2), which enables writing into the PD9,

address 0362h and 0366h registers, is changed with the below procedure. (1) Step execution of an instruction setting PRC2 to "1" (2) Setting a break point between an instruction setting PRC2 to "1" and a point where the PD9, address 0362h

and 0366h registers are set

(3) Setting PRC2 to "1" by the memory window or script window

) less than 1 MHz. To use it with a main clock less

OUT

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 78 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Note on Breaks:

 The area displaying break points in the program window of the emulator debugger shows the following breaks.

(1) Address-match break This is a debugging function which breaks a program, using the address-match interrupt function of the

MCU, immediately before the system executes an instruction at a specified address. The instruction at the

preset address will not be executed. (2) Software break This is a debugging function which generates a BRK interruption by changing an instruction at a specified

address to a BRK instruction (00h) to break a program immediately before the system executes an

instruction at a specified address. The instruction at the preset address will not be executed. (3) Hardware break This is a debugging function which breaks a program by setting the detection of an execution of an

instruction at a specified address as a break event. The program will break after the instruction at the

specified address is executed.

Notes on Software Breaks:

 Software breaks change the instruction at a specified address to a BRK (00h). Therefore, take note that when

you reference the result of a trace in bus mode, "00h" is displayed.

 The BRK instruction can be used for the emulator only. You cannot use it in a user program.  You can neither set nor cancel a software breakpoint in the internal ROM area of an MCU during user program

execution, while you can set or cancel it in the internal RAM area of an MCU or an area where chip select CS3* to CS0* are set to INTERNAL (emulation memory).

Notes on Address-Match Breaks:

 As the processing speed of setting and canceling address-match breaks is relatively fast, you can save the times

of writing into the internal flash ROM of an MCU. Therefore, address-match breaks precede the other breaks when setting breakpoints in the internal flash ROM area of an MCU.

 Address-match breaks can be set only in RAM and ROM areas of an MCU.  Address-match breaks can be set at up to eight points. The other breaks are set as software breaks.  Address-match breaks can be set or canceled even when the user program is being executed.

Notes on Power Supply to the User System:

 Pins Vcc1 and Vcc2 are connected to the user system to observe the voltage. Therefore, the power is not

supplied to the user system from the emulator, design your system so that the user system is powered separately.

 The voltage of the user system should be as follows.

3.15 V ≤ Vcc1 = Vcc2 = Vcc3 ≤ 3.45 V

 Do not change the voltage of the user system after turning on the power.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 79 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Notes on Internal Flash ROM of the MCU:

 In single-chip mode and memory expansion modes, this product downloads a user program to the flash ROM of

an MCU. By checking "Debug Option" in the MCU tab of the MCU setting dialog box of the emulator debugger, you can disable the operation of the internal flash ROM of the MCU to use the emulation memory. The maximum operating frequencies are as follows. (1) "Debug Option " unchecked

Access area: Flash ROM of MCU Max. operating frequency: 16 MHz (0 wait, 1 wait)

(2) "Debug Option " checked

Access area: Emulation memory of the PC7501 Max. operating frequency: 10 MHz (0 wait, 1 wait)

 Because the number of write/erase cycles of the internal flash ROM of the MCU is limited, it must be replaced

at the end of its service-life.

 If the following errors occur frequently when downloading a program, replace the MCU board.

(1) Flash ROM erase error occurred ERROR (16258) (2) Flash ROM verify error occurred ERROR (16259) To purchase products for replacement, contact your local distributor.

Note on Memory Area Expansion Function (Normal Mode):

 During debugging in memory expansion mode or microprocessor mode with this product, the emulation

Note on Memory Area Expansion Function (4-MByte Mode):

memory can be allocated. The emulation memory can be specified up to 4 areas by 4 MB in the MAP tab of the MCU setting dialog box of the emulator debugger.

Each maximum operating frequency is as follows.

- Maximum operating frequency (at 3.3 V) 0 wait: 6 Hz 1 wait to 3 wait: 16 MHz

 When using the memory area expansion function (4-Mbyte mode), please note that the memory to which the

evaluation MCU is connected differs depending on processor modes and debugger settings. For details, refer to the table below. Areas connected when using the memory area expansion function (4-Mbyte mode)

OFS

Processor mode PM13*1

Memory expansion mode

Microprocessor mode ---

*1: Indicates bit 3 at address 00005h.

Accessed area of target MCU Banks 0--5 Bank 6 Bank 7

50000h--7FFFFh

80000h--BFFFFh

50000h--7FFFFh

80000h--BFFFFh

50000h--7FFFFh

80000h--BFFFFh

C0000h--FFFFFh

50000h--7FFFFh

80000h--BFFFFh

EXT

EXT EXT MAP

EXT MAP ---

EXT EXT MAP

EXT EXT ---

EXT EXT MAP

EXT MAP ---

EXT MAP*4

--- --- MAP

*2: Indicates bit 2 at address 0000Bh. *3: Indicates memory access in the user system. *4: Indicates area access dependent on how the MAP tab of the debugger’s MCU settings dialog box is set

(INT: internal emulation memory of the PC7501, EXT: memory in the user system).

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 80 of 90

M306V8T-EPB User’s Manual 4. Hardware Specifications

IMPORTANT

Notes on Debugging in CPU Rewrite Mode:

 When you debug an M16C/60 Series MCUs in CPU rewrite mode, do not change the block 0 area (FF000h--

FFFFFh) of the flash memory. Otherwise, the emulator will be uncontrollable.

 If you check "Debug the program using CPU Rewrite Mode" in the MCU tab of the Init dialog box of the

emulator debugger, you cannot use the following functions.

(1) Setting software breakpoints in an internal ROM area (2) Executing COME in an internal ROM area

 In CPU rewrite mode and erase suspend mode, do not stop the program. And do not single step an instruction

shifting to CPU rewrite mode or erase suspend mode. The emulator will be uncontrollable in CPU rewrite mode and erase suspend mode.

 To reference data after executing CPU rewrite, stop the program at other then a rewrite control program area

and use the memory window etc. As the following interrupt vectors are used by the emulator system, the read data is different from expected value.

(1) BRK instruction (FFFE4h--FFFE7h) (2) Address match (FFFE8h--FFFEBh) (3) Single-step (FFFECh--FFFEFh) (4) DBC (FFFF4h--FFFF7h)

Notes on Address-Match Interrupts:

 When you use the address-match interrupt function in a user program, uncheck "Enable the Address Match

Interrupt Break Function" in the MCU tab of the Init dialog box of the emulator debugger. Thus, normal software breaks are used for the internal RAM and ROM areas of an MCU.

 Do not set a software break at an address where an address-match interrupt occurs. Otherwise, a user program

may be run out of control. Set a software or hardware break in the top address in address-match interrupt processing.

 When you single step an address where an address-match interrupt occurs, the program stops after executing the

first instruction after returning from address-match interrupt processing.

Note on Accessing Addresses 00000h and 00001h:

 With the M16C/60 Series MCUs, when a maskable interrupt is generated, the interrupt data (interrupt number

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 81 of 90

M306V8T-EPB User’s Manual 5. Troubleshooting

5. Troubleshooting

This chapter describes how to troubleshoot when this product does not work properly.

5.1 Flowchart to Remedy the Troubles

Figure 5.1 shows the flowchart to remedy the troubles from when power to the emulator is activated until the emulator

debugger starts up. Check this while the user system is disconnected. For the latest FAQs visit the Renesas Tools Homepage.

http://www.renesas.com/en/tools

Turning on emulator

Upper panel LED

of emulator

Normal

Init dialog box of emulator

debugger displayed

Normal

MCU Setting dialog box of

emulator debugger

Normal

Not normal

1 . Check the connection of power supply cable.

See “2.5 Connecting the Power Supply for the Emulator

( page 24).

2 . Check that the power is properly supplied to the use system.

“

2.7 Downlo ading Firmware” ( page 27).

See

3. Restart the emulator system.

Not normal/Error displayed

1 . Check the operating environment etc. of the emulator

debugger.

See the user

2 . Reinstall the emulator debugger.

Not normal/ Error displayed

See “5.2.(2) MCU Setting Dialog Box Does Not Appear at

Emulator Debugger Startup”(page 84).

’

s manual of the emulatordebugger.

”

Program window of emulator

debugger displayed

Normal

Emulator debugger startup completed

Error displayed

See “5.2.(3) Err ors Occur at Emulator Debugger Startup”(page 85).

Figure 5.1 Flowchart to remedy the troubles

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 82 of 90

M306V8T-EPB User’s Manual 5. Troubleshooting

5.2 When the Emulator Debugger Does Not Start Up Properly

(1) When the LEDs of the PC7501 Do Not Display Normally

Table 5.1 Errors LEDs show and their checkpoints

Error

LEDs do not light up. - Check that the power cable is connected.

All LEDs remain lit. - Recheck the connection between the PC7501 and this product.

Target Status POWER LED does not light up.

Target Status CLOCK LED does not light up.

Connected When the clock is supplied from an external oscillator, check that

Target Status RESET LED does not go out.

Connection to

the user system

See "2.5 Connecting the Power Supply for the Emulator" (page 24) and the user's manual of the PC7501.

See "2.4 Connecting the PC7501" (page 23).

Connected Check that power (Vcc) is properly supplied to the user system and

that the user system is properly grounded.

Not connected (1) Check that both the main and sub clocks of the emulator

debugger are not set to "EXT".

See the CLK command of the emulator debugger.

(2) Check the oscillation circuit in the emulator is oscillating.

See "2.11 Selecting Clock Supply" (page 38).

the oscillator circuit in the user system is oscillating properly.

Connected Check that the reset pin of the user system is pulled up.

Checkpoint

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 83 of 90

M306V8T-EPB User’s Manual 5. Troubleshooting

(2) MCU Setting Dialog Box Does Not Appear at Emulator Debugger Startup

Table 5.2 Checkpoints of errors at debugger startup

Error Checkpoint

Communication error occurred. Data was not sent to the target.

Check all emulator debugger settings, interface cable settings and switches on the rear of the PC7501 match.

See the user's manuals of PC7501 and emulator debugger.

User system cannot be properly built. (1) Download the proper firmware.

See "2.7 Downloading Firmware" (page 27).

(2) Recheck the connection between the PC7501 and this product.

See "2.4 Connecting the PC7501" (page 23).

Emulator’s version is not the same version as the firmware in the target.

Download the proper firmware.

See "2.7 Downloading Firmware" (page 27).

Target MCU is in the reset state. (1) Check the reset pin of the user system is pulled up.

(2) Check the reset pin of the user system has changed from "L" to "H"

level.

Target MCU cannot be reset. (1) In memory expansion mode or microprocessor mode, check pins

RDY* and HOLD* are at “H” level.

(2) If the reset circuit of the user system has a watchdog timer, disable

the watchdog timer.

(3) Check that power is properly supplied to the user system and that the

user system is properly grounded.

Target is in "HOLD" state. (1) In memory expansion mode or microprocessor mode, check pins

RDY* and HOLD* at “H” level.

(2) The MCU is either in stop mode or wait mode. Either reset the MCU

or cancel the mode with an interrupt.

See MCU specifications.

Target clock is stopped. When the clock is supplied from an external oscillator, check that the

oscillator circuit in the user system is oscillating properly.

Target MCU is not receiving power. Check that power is properly supplied to the user system and that the

user system is properly grounded.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 84 of 90

M306V8T-EPB User’s Manual 5. Troubleshooting

(3) Errors Occur at Emulator Debugger Startup

Table 5.3 Checkpoints of errors at debugger startup

Error Checkpoint

Target MCU is uncontrollable. (1) Check that the NQPACK etc. mounted on the user system is soldered

properly. (2) Check that the connector is installed properly to the user system. (3) In memory expansion mode or microprocessor mode, check pins

RDY* and HOLD* are at “H” level.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 85 of 90

M306V8T-EPB User’s Manual 5. Troubleshooting

5.3 How to Request for Support

After checking the items in "5 Troubleshooting", send the following information to your local distributor.

Customer Information

- Company:

- Address:

- Department:

- Name:

- Phone:

- Fax:

- Email address:

Product information

- Software name:

- Version:

- Host machine:

- OS:

PDxx support information

1. Target MCU:

2. Emulator (Check one that applies):

( ) PC4701U ( ) PC4701M ( ) PC4701HS ( ) PC4701L ( ) PC7501 ( ) Other

3. Emulator's serial number:

4. Product name of the emulation pod/probe:

5. Serial number of the emulation pod/probe:

6. Interface:

( ) USB ( ) LPT parallels ( ) LAN ( ) Serial ( ) Dedicated parallel

7. Optional product used:

8. Serial number of the optional product:

Remarks:

For prompt response, please specify the following information:

(1) Operating environment

- Operating voltage:

- Operating frequency:

- Clock supply to the MCU: Internal oscillator/External oscillator

(2) Condition

- The emulator debugger starts up/does not start up

- The error is detected/not detected in the self-check

- Frequency of errors: always/frequency ( )

(3) Problem

[V]

[MHz]

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 86 of 90

M306V8T-EPB User’s Manual 6. Maintenance and Guarantee

6. Maintenance and Guarantee

This chapter describes how to maintenance, repair provisions and how to request for repair.

6.1 User Registration

When you purchase our product, be sure register as a user. For user registration, refer to “User registration” (page 11) of this

user's manual.

6.2 Maintenance

(1) If dust or dirt collects on any equipment of your emulation system, wipe it off with a dry soft cloth. Do not use thinner or

other solvents because these chemicals can cause the equipment's surface coating to separate.

(2) When you do not use this product for a long period, for safety purposes, disconnect the power cable from the power

supply.

6.3 Guarantee

If your product becomes faulty within one year after its purchase while being used under good conditions by observing

"IMPORTANT" and "Precautions for Safety" described in this user's manual, we will repair or replace your faulty product free

of charge. Note, however, that if your product's fault is raised by any one of the following causes, we will repair it or replace it

with new one with extra-charge:

- Misuse, abuse, or use under extraordinary conditions

- Unauthorized repair, remodeling, maintenance, and so on

- Inadequate user's system or misuse of it

- Fires, earthquakes, and other unexpected disasters

In the above cases, contact your local distributor. If your product is being leased, consult the leasing company or the owner.

6.4 Repair Provisions

(1) Repair with extra-charge

The products elapsed more than one year after purchase can be repaired with extra-charge.

(2) Replacement with extra-charge

If your product's fault falls in any of the following categories, the fault will be corrected by replacing the entire product

instead of repair, or you will be advised to purchase new one, depending on the severity of the fault.

- Faulty or broken mechanical portions

- Flaw, separation, or rust in coated or plated portions

- Flaw or cracks in plastic portions

- Faults or breakage caused by improper use or unauthorized repair or modification

- Heavily damaged electric circuits due to overvoltage, overcurrent or shorting of power supply

- Cracks in the printed circuit board or burnt-down patterns

- Wide range of faults that makes replacement less expensive than repair

- Unlocatable or unidentified faults

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 87 of 90

M306V8T-EPB User’s Manual 6. Maintenance and Guarantee

(3) Expiration of the repair period

When a period of one year elapses after the model was dropped from production, repairing products of the model may

become impossible.

(4) Transportation fees at sending your product for repair

Please send your product to us for repair at your expense.

6.5 How to Make Request for Repair

If your product is found faulty, follow the procedure below to send your product for repair.

Customer

Distributor

Fill in the Repair Request Sheet included with this product, then send it along with this product for repair to your local distributor. Make sure that information in the Repair Request Sheet is written in as much detail as possible to facilitate repair.

After checking the contents of fault, the distributor should please send the faulty product along with the Repair Request Sheet to Renesas Solutions Corp.

Renesas Solutions When the faulty product is repaired, it will be returned to the customer at the earliest

convenience.

CAUTION

Note on Transporting the Product:

 When sending your product for repair, use the packing box and cushion material supplied with this product

when delivered to you and specify handling caution for it to be handled as precision equipment. If packing of your product is not complete, it may be damaged during transportation. When you pack your product in a bag, make sure to use conductive polyvinyl supplied with this product (usually a blue bag). When you use other bags, they may cause a trouble on your product because of static electricity.

REJ10J0777-0100 Rev.1.00 2005.08.01 Page 88 of 90

Emulation Probe for M16C/60 Series M16C/6V Group M306V8 User’s Manual M306V8T-EPB

Publication Date: Aug. 1, 2005 Rev.1.00

Published by:

Edited by:

Sales Strategic Planning Div. Renesas Technology Corp.

Microcomputer Tool Development Department Renesas Solutions Corp.

M306V8T-EPB

User’s Manual

Renesas M306V8T-EPB User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Important

Precautions for Safety

Contents

User Registration
