User’s Manual
M306V2T-RPD-E
User’s Manual
Emulation Pod for M306V2, M306V5 MCUs
Rev.1.00 2003.09
• Renesas Technology Corporation and Renesas Solutions Corporation put the maximum effort into making semiconductor products better
and more reliable, but there is always the possibility that trouble may occur with them. Trouble with semiconductors may lead to personal
injury, fire or property damage. Remember to give due consideration to safety when making your circuit designs, with appropriate
measures such as (i) placement of substitutive, auxiliary circuits, (ii) use of nonflammable material or (iii) prevention against any
malfunction or mishap.
Keep safety first in your circuit designs!
• These materials are intended as a reference to assist our customers in the selection of the Renesas Technology product best suited to
the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas
Technology Corporation, Renesas Solutions Corporation or a third party.
• Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage, or infringement of any
third-party's rights, originating in the use of any product data, diagrams, charts, programs, algorithms, or circuit application examples
contained in these materials.
• All information contained in these materials, including product data, diagrams, charts, programs and algorithms represents information
on products at the time of publication of these materials, and are subject to change by Renesas Technology Corporation and Renesas
Solutions Corporation without notice due to product improvements or other reasons. It is therefore recommended that customers contact
Renesas Technology Corporation, Renesas Solutions Corporation or an authorized Renesas Technology product distributor for the latest
product information before purchasing a product listed herein. The information described here may contain technical inaccuracies or
typographical errors. Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage,
liability, or other loss rising from these inaccuracies or errors. Please also pay attention to information published by Renesas Technology
Corporation and Renesas Solutions Corporation by various means, including the Renesas home page (http://www.renesas.com).
• When using any or all of the information contained in these materials, including product data, diagrams, charts, programs, and algorithms,
please be sure to evaluate all information as a total system before making a final decision on the applicability of the information and
products. Renesas Technology Corporation and Renesas Solutions Corporation assume no responsibility for any damage, liability or
other loss resulting from the information contained herein.
• Renesas Technology semiconductors are not designed or manufactured for use in a device or system that is used under circumstances
in which human life is potentially at stake. Please contact Renesas Technology Corporation, Renesas Solutions Corporation or an
authorized Renesas Technology product distributor when considering the use of a product contained herein for any specific purposes,
such as apparatus or systems for transportation, vehicular, medical, aerospace, nuclear, or undersea repeater use.
• The prior written approval of Renesas Technology Corporation and Renesas Solutions Corporation is necessary to reprint or reproduce
in whole or in part these materials.
• If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license from the
Japanese government and cannot be imported into a country other than the approved destination. Any diversion or reexport contrary to
the export control laws and regulations of Japan and/or the country of destination is prohibited.
• Please contact Renesas Technology Corporation or Renesas Solutions Corporation for further details on these materials or the products
contained therein.
Notes regarding these materials
• This product is a development supporting unit for use in your program development and evaluation stages. In mass-producing your
program you have finished developing, be sure to make a judgment on your own risk that it can be put to practical use by performing
integration test, evaluation, or some experiment else.
• In no event shall Renesas Solutions Corporation be liable for any consequence arising from the use of this product.
• Renesas Solutions Corporation strives to renovate or provide a workaround for product malfunction at some charge or without charge.
However, this does not necessarily mean that Renesas Solutions Corporation guarantees the renovation or the provision under any
circumstances.
• This product has been developed by assuming its use for program development and evaluation in laboratories. Therefore, it does not fall
under the application of Electrical Appliance and Material Safety Law and protection against electromagnetic interference when used in
Japan.
• Do not attempt to modify this equipment. If modified, your authority to operate this equipment might be voided by FCC.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
For inquiries about the contents of this document or product, fill in the text file the installer of the emulator debugger generates in the
following directory and email to your local distributor.
\SUPPORT\Product-name\SUPPORT.TXT
Renesas Tools Homepage http://www.renesas.com/en/tools
Precautions to be taken when using this product
( 2 / 72 )
Preface
The M306V2T-RPD-E is an emulation pod for the M306V2 and M306V5 of 16-bit microcomputers.
It's used with a PC4701 emulator.
This user's manual mainly describes specifications of the M306V2T-RPD-E emulation pod and how
to setup it. For details on the following products, which are used with M306V2T-RPD-E, refer to each
product's user's manual.
• Emulator: PC4701M/PC4701HS/PC4701L User's Manual
• Emulator debugger: M3T-PD30 User's Manual
All the components of this product are shown in "2.2 Package Components" (page 19) of this user's
manual. If there is any question or doubt about this product, contact your local distributor.
To use the product properly
Precautions for Safety
• In both this User's Manual and on the product itself, several icons are used to insure
proper handling of this product and also to prevent injuries to you or other persons,
or damage to your properties.
• The icons' graphic images and meanings are given in "Chapter 1. Precautions for
Safety". Be sure to read this chapter before using the product.
When using outside Japan
• When using in Europe, the United States, or Canada, be sure to use both the emulator
and the emulation pod which meet overseas standards. EMI standards are not met
when the M306V2T-RPD-E is used with the PC4700H or PC4700L emulator.
( 3 / 72 )
Contents
Chapter 1. Precautions for Safety ...........................................................................................7
1.1 Safety Symbols and Meanings ..............................................................................8
Chapter 2. Preparation ..........................................................................................................17
2.1 Terminology ........................................................................................................18
2.2 Package Components ..........................................................................................19
2.3 Other Tool Products Required for Development ................................................19
2.4 Name of Each Part ..............................................................................................20
(1) System Configuration...............................................................................20
(2) Inside of Emulation Pod...........................................................................21
2.5 When Using the Emulator for the First Time......................................................22
Chapter 3. Setting Up ...........................................................................................................23
3.1 Removing the Upper Cover ................................................................................24
3.2 Switch Settings....................................................................................................25
3.3 Selecting Clock Supply .......................................................................................29
(1) Using the Oscillator Circuit on the Target System ..................................30
(2) Changing the Internal Oscillator Circuit of Emulation Pod.....................31
(3) Replacing the Oscillator Circuit Boards ..................................................32
3.4 Circuits of Data Slicer I/O Signal and OSD Clock I/O Signal ...........................33
3.5 A-D Conversion Bypass Capacitor .....................................................................35
3.6 Connecting the PC4701 and Emulation Pod .......................................................36
(1) Connecting the Cable to the PC4701 .......................................................36
(2) Connecting the Cable to the Emulation Pod ............................................37
3.7 Connecting the Target System ............................................................................38
Chapter 4. Usage ..................................................................................................................39
4.1 Turning On the Power .........................................................................................40
(1) Checking the Connection of Emulator System ........................................40
(2) Turning On the Power ..............................................................................40
(3) LED Display When PC4701 Starts Up Normally....................................41
4.2 Downloading Firmware ......................................................................................42
(1) When It is Necessary to Download Firmware .........................................42
(2) Downloading Firmware in Maintenance Mode .......................................42
4.3 Self-checks ..........................................................................................................43
(1) Self-check Procedure ...............................................................................43
(2) If an Error is Detected in Self-checks ......................................................43
( 4 / 72 )
Chapter 5. Specifications......................................................................................................45
5.1 Specifications ......................................................................................................46
5.2 Operation Timing in Memory Expansion and Microprocessor Modes (5V) ......47
(1) Separate Bus, No-Wait.............................................................................47
(2) Separate Bus, With Wait, Accessing External Memory Area .................49
(3) Multiplex Bus, With Wait, Accessing External Memory Area ...............51
(4) Timing Requirements...............................................................................53
5.3 Electrical Characteristics.....................................................................................55
5.4 Connection Diagram ...........................................................................................56
5.5 External Dimensions ...........................................................................................58
(1) External Dimensions of Emulation Pod ...................................................58
(2) External Dimensions of Pitch Converter Board (FLX-100LCC) ............59
Chapter 6. Troubleshooting ..................................................................................................61
6.1 Flowchart to Remedy the Troubles .....................................................................62
6.2 When the Emulator Debugger Does Not Start Up Properly ...............................63
(1) When the LED Display of PC4701 is Abnormal .....................................63
(2) Errors Occur When the Emulator Debugger Starts Up
(When the target system is connected)....................................64
(3) Errors Occur When the Emulator Debugger Starts Up
(When the target system is not connected) .............................65
6.3 Operation Differs from That of Actual MCUs....................................................65
(1) A-D Conversion Values are Different from Expected Values ....................65
Chapter 7. Maintenance and Guarantee................................................................................67
7.1 Maintenance ........................................................................................................68
7.2 Guarantee ............................................................................................................68
7.3 Repair Provisions ................................................................................................68
7.4 How to Request for Repair..................................................................................69
( 5 / 72 )
MEMO
( 6 / 72 )
Chapter 1. Precautions for Safety
This chapter describes precautions for using this product safely and properly. For precautions for the emulator main unit
and the emulator debugger, refer to each user's manual included with your product.
1.1 Safety Symbols and Meanings ..................................................................................................... 8
WARNING
CAUTION
IMPORTANT
Warning for Installation...............................................................................................9
Warnings for Use Environment ...................................................................................9
Caution to Be Taken for Modifying This Product ....................................................... 9
Cautions to Be Taken for This Product........................................................................ 9
Note on Malfunctions in the PC4701 System..............................................................9
Notes on Downloading Firmware..............................................................................10
Notes on Target System ............................................................................................. 10
Note on Reset Input ...................................................................................................10
Notes on Watchdog Function..................................................................................... 10
Note on When the Emulator Debugger Ends.............................................................10
Note on DMA Transfer..............................................................................................11
Note on Setting the Work Area..................................................................................11
Notes on Stack Area................................................................................................... 11
Note on Address 0 Access ......................................................................................... 11
Note on Stop and Wait Modes ................................................................................... 11
Notes on MAP References and Settings ....................................................................12
Notes on S/W Breaks and H/W Breaks ..................................................................... 12
Note on BRK Instruction ...........................................................................................12
Note on NMI* Input................................................................................................... 13
Notes on HOLD* Input..............................................................................................13
Notes on Address Match Interrupt.............................................................................13
Note on Software Reset .............................................................................................13
Note on Protect Resister (PRC2) ............................................................................... 13
Note on Setting BCLK Output Disable Bit (PM07) ..................................................13
Note on Differences between Actual MCU and Emulator ........................................ 14
( 7 / 72 )
Chapter 1. Precautions for Safety
In both the user's manual and on the product itself, several icons are used to insure proper handling
of this product and also to prevent injuries to you or other persons, or damage to your properties.
This chapter describes the precautions which should be taken in order to use this product safely and
properly. Be sure to read this chapter before using this product.
1.1 Safety Symbols and Meanings
If the requirements shown in the "WARNING"
WARNING
CAUTION
IMPORTANT
In addition to the three above, the following are also used as appropriate.
sentences are ignored, the equipment may
cause serious personal injury or death.
If the requirements shown in the "CAUTION"
sentences are ignored, the equipment may
malfunction.
It means important information on using this
product.
means WARNING or CAUTION.
Example: CAUTION AGAINST AN ELECTRIC SHOCK
means PROHIBITION.
Example: DISASSEMBLY PROHIBITED
means A FORCIBLE ACTION.
Example:
The following pages describe the symbols "WARNING", "CAUTION", and "IMPORTANT".
UNPLUG THE POWER CABLE FROM THE RECEPTACLE.
( 8 / 72 )
WARNING
Warning for Installation:
• Do not set this product in water or areas of high humidity. Spilling water or some other liquid into
the main unit can cause an unrepairable damage.
Warnings for Use Environment:
• The emulation pod is air-cooled with the ventilation slot. Therefore, do not block the ventilation
slot. When heated to high temperatures, the emulation pod may not work properly.
• This equipment is to be used in an environment with a maximum ambient temperature of 35°C. Care
should be taken that this temperature is not exceeded.
CAUTION
Caution to Be Taken for Modifying This Product:
• Do not disassemble or modify this product. Disassembling or modifying this product can cause
damage. Disassembling and modifying the product will void your warranty.
Cautions to Be Taken for This Product:
• Use caution when handling the main unit. Be careful not to apply a mechanical shock.
• Do not touch the connector pins of the emulator main unit and the target MCU connector pins . Static
electricity may damage the internal circuits.
• Do not pull the emulation pod main unit by the flexible cable (FLX120-RPD) for connecting to the
emulator main unit or the flexible cable (FLX64, FLX100 or FLX160) for connecting the target
system. The cable may cause a break.
• The flexible cable (FLX120-RPD) for connecting to the emulator main unit and the flexible cable
(FLX64, FLX100 or FLX160) for connecting the target system are different from earlier models.
The slits make them more flexible. However, excessive flexing or force may break conductors.
•Do not use inch-size screws for this equipment. The screws used in this equipment are all ISO
(meter-size) type screws. When replacing screws, use same type screws as equipped before.
IMPORTANT
Note on Malfunctions in the PC4701 System
• If the emulator malfunctions because of interference like external noise, do the following to remedy
the trouble.
(1) Press the RESET switch on the emulator front panel.
(2) If normal operation is not restored after step (1), shut OFF power to the emulator once and then
reactivate it.
( 9 / 72 )
IMPORTANT
Notes on Downloading Firmware:
• Before using this product for the first time, it is necessary to download the dedicated firmware
(control software for the emulation pod built into the PC4701). Please note that, to do this, it is
necessary to start up the PC4701 in the maintenance mode. For firmware download procedures, see
"4.2 Downloading Firmware" (page 42). Once the firmware has been downloaded, the product can
be used by simply turning on the power.
• Do not shut off the power while downloading the firmware. If this happens, the product will not
start up properly. If power is shut off unexpectedly, redownload the firmware.
• Except when a target status error occurs, if self-checks are not completed successfully, there may
be trouble with the product. In such case, contact your sales representative. However, perform selfchecks in the below setup.
(1) Target system: Not connected
(2) Emulation pod internal switches: At their factory settings
Notes on Target System:
• The Vcc pin of emulator is connected to the target system to observe the voltage of the target system.
For this reason, it is impossible to supply the power from the emulator to the target system.
Therefore design your system so that the target system is powered separately.
• The voltage of the target system should be within the range of the MCU specification.
•Do not change the voltage of the target system after turning on the power.
• Before powering on your emulator system, check that the host machine, the emulator main unit,
the converter board and target system are all connected correctly. Next, turn on the power to each
equipment following the procedure below.
(1) Turn ON/OFF the target system and the PC4701 emulator as simultaneously as possible.
(2) When the PC4701 and emulator debugger start up, check the target status LEDs on the
emulator main unit's front panel to see if this product is ready to operate.
• Is the power supplied? Check that target status LED (POWER) is ON.
For details, refer to "Chapter 4. Usage" (page 39).
Note on Reset Input:
• The reset input from the target system is accepted only while a user program is being executed (only
while the RUN status LED on the PC4701's front panel is lit).
Notes on Watchdog Function:
• The MCU's watchdog timer can be used only while programs are being executed. To use it
otherwise, disable the timer.
• If the reset circuit of the target system has a watchdog timer, disable it when using the emulator.
Note on When the Emulator Debugger Ends:
• To restart the emulator debugger after it ends, always shut power to the emulator module off once
and then on again.
( 10 / 72 )
IMPORTANT
Note on DMA Transfer:
•With this product, the program is stopped with a loop program to a specific address. Therefore, if
a DMA request is generated by a timer or other source while the program is stopped, DMA transfer
is executed. However, make note of the fact that DMA transfer while the program is stopped may
not be performed correctly. Also note that the below registers have been changed to generate DMA
transfer as explained here even when the program is stopped.
DMA0 transfer counter register TCR0
DMA1 transfer counter register TCR1
Note on Setting the Work Area:
• To use this product, it is necessary to set the work area in the internal reserved area of the MCU.
However, do not set it in the last 10 bytes of the internal reserved area. And be sure to set the internal
reserved area to INTERNAL. (Set the work area by the INIT dialog of emulator debugger M3TPD30.)
Example: When debugging the program of the MCU whose internal reserved area is 0180016 to
02BFF16, set the work area within the range of 0180016 to 02BF616.
For instance, when setting the work area at 0180016, the emulator uses 10 bytes area of 0180016 to
0180916.
Notes on Stack Area:
•With this product, a maximum 8 bytes of the user stack is consumed.
• If the user stack does not have enough area, do not use areas which cannot be used as stack (SFR
area, RAM area which stores data, or ROM area) as work area. Using areas like this is a cause of
user program crashes and destabilized emulator control. Therefore, ensure the +8 bytes maximum
capacity used by the user program as the user stack area.
Note on Address 0 Access:
• With the M306V2 and M306V5 MCUs, when a maskable interrupt is generated, the interrupt data
(interrupt No. and interrupt request level) stored in address 0 is read out. Also, the interrupt request
bit is cleared when address 0 is read out. Consequently, when the address 0 readout instruction is
executed or when address 0 is read out in the cause of a program runaway, a malfunction occurs
in that the interrupt is not executed despite the interrupt request, because the request bit of the
highest priority interrupt factor enabled is cleared.
For this malfunction, when the reading out to the 0 address is generated excluding the interrupt, the
yellow LED lights up to alarm. When this LED lights, there is a possibility of wrong access,
therefore check the program. This LED is turned off by the RESET switch of the emulator main
unit.
Note on Stop and Wait Modes:
•Do not perform step execution at addresses in the stop or wait mode. It may cause communication
errors.
( 11 / 72 )
IMPORTANT
Notes on MAP References and Settings:
• For details on referencing and setting MAP information, see User's Manual of emulator debugger
M3T-PD30.
•Be sure to set the SFR area to EXTERNAL.
•When setting 0FFFC16 to 0FFFF16 to EXTERNAL:
This product uses the 4 byte area 0FFFC16 to 0FFFF16 as the stack area when the RESET command
of emulator debugger M3T-PD30 is executed. If this 4 byte memory cannot be read or written to,
reset cannot be properly effected. As a result, you need to alter the map settings if the condition
given below is met.
(1) With the system which shifts from the single-chip mode to the memory expansion (or
microprocessor) mode, using the 4-byte area of 0FFFC16 to 0FFFF16 set to EXTERNAL.
(2) With the system which starts up in microprocessor mode, using the 4-byte area of 0FFFC16
to 0FFFF16 set to EXTERNAL and there is not enough memory to read or write.
The procedures to alter the MAP settings when the conditions (1) or (2) above are met.
(1) Set the 4-byte area of 0FFFC16 to 0FFFF16 to INTERNAL.
(2) Execute the RESET command by use of emulator debugger M3T-PD30.
(3) Set the stack pointer.
(Example)
RESET:
FCLR I
LDC #4000H, SP <-- Set the stack pointer
○○
(4) Set the 4-byte area 0FFFC16 through 0FFFF16 to EXTERNAL.
Notes on S/W Breaks and H/W Breaks:
•S/W breaks generate BRK interrupts by substituting the proper instruction to the BRK instruction.
Therefore, when referencing the result of a trace in bus mode, "0016" is displayed for the instruction
fetch address where a software break is set, and when referencing in reverse assemble mode,
"BRK" instruction is displayed.
• It is not possible to use a S/W break and a H/W break at the same time. If doing so, it may not operate
normally.
• In the area where the MAP setting is EXTERNAL, S/W breaks cannot be used.
Note on BRK Instruction:
(Stop the program after executing this instruction)
• BRK instruction cannot be used.
( 12 / 72 )
IMPORTANT
Note on NMI* Input:
• NMI* input from the target system is accepted only while a user program is being executed (only
while the RUN status LED on the PC4701's front panel is lit).
Notes on HOLD* Input:
• Be sure to input "Low" to the HOLD* pin of the target system during the user program executing
(while the RUN status LED on the PC4701's front panel is lit). Inputting "Low" to the HOLD* pin
when stopping the user program or when run-time debugging may cause a malfunction of the
emulator.
• When inputting "Low" to the HOLD* pin to run into the HOLD state, P00 to P52 will be in the HOLD
state delaying by 2.5 cycles than the actual MCU (see Table 5.5, Figure 5.5).
Notes on Address Match Interrupt:
• Do not set software breaks at the same addresses as address-match interrupts as the program may
run out of control.
• Do not set a hardware break within 4 instructions before an address at which an address-match
interrupt occurs. If you do set a hardware break in this range, the program will run out of control.
•When an address at which an address-match interrupt occurs is executed in one-step mode, the
program stops after executing the first instruction after returning from the address-match interrupt
processing.
Note on Software Reset:
• Do not use a software reset.
Note on Protect Resister (PRC2):
• Make note of the fact that the protect is not canceled when the protect register (PRC2), which
enables writing in the port P9 direction register, is changed with the below procedure.
(1) Step execution of the "instruction for setting ("1") PRC2".
(2) Setting the break point from the "instruction for setting ("1") PRC2" to the "setting the register
for the protect".
(3) "Setting ("1") PRC2" from the dump window, script window or others.
Note on Setting BCLK Output Disable Bit (PM07):
•Do not set the 7th bit (PM07: BCLK output disable bit) of the processor mode register 0 (address
000416) to "1". Otherwise, this emulation pod does not work properly.
( 13 / 72 )
IMPORTANT
Note on Differences between Actual MCU and Emulator:
•Operations of the emulator differs from those of actual MCUs as listed below.
(1) Reset condition
Set the time for starting up (0.2Vcc to 0.8Vcc) 1µs or less.
(2) Data values of ROM area at power-on
(3) Internal memories (RAM and ROM) capacities etc.
(4) Characteristics of Port P00 to P57
Ports P00 to P57 are connected via port emulation circuits. The device used for the port
emulation circuit is:
Device: M60074-0111FP
(5) A-D input
As a flexible cable, a pitch converter board and other devices are used between the evaluation
MCU and the target system, some characteristics are slightly different from those of the actual
MCU. Therefore, be sure to evaluate your system with an evaluation MCU. Before starting
mask production, evaluate your system and make final confirmation with an ES (Engineering
Sample) version MCU.
(6) Pull-up control
Port P0-P5 pullup control in this product is different between modes as shown in Table 1.1.
There is not difference for ports P6 to P10.
Table 1.1 P0-P5 Pullup control
Actual MCU
This
emulation
pod
Single-chip mode
(1) Enabled for only input
ports
(2) Can be set bitwise
(1) Always enabled irrespective of operation mode
(Also enabled when used as address/data bus or output ports)
(2) Cannot be set bitwise
Can only be set in units of 4 bits (P00-P03, P04-P07, ... P50-P53,
P54-P57). If any bit in the 4-bit unit is enabled for pullup, all of the four
bits are enabled for pullup.
Memory expansion/microprocessor mode
Disabled
(Enabled if P44 (CS0) to P47 (CS3) are used
as input ports, however.)
(7) Write to pullup control registers 0, 1 (addresses 03FC16, 03FD16)
When you write to pullup control registers 0, 1 (addresses 03FC16, 03FD16), always be sure
to write in units of words beginning with address 03FC16.
This paragraph constitutes a limitation on M306V2T-RPD-E.
(8) Ports P50-P53
When you enable the pullup resistors of these ports in single-chip mode by setting pullup
control register 1 bit 2 (PUR12) to "1", always be sure to set processor mode register 0 bit 2
(PM02) and bit 7 (PM07) both to "0".
This paragraph constitutes a limitation on M306V2T-RPD-E.
( 14 / 72 )
IMPORTANT
(9) Outputs of the actual MCU and this product
Table 1.2 Differences of outputs between actual MCU and this product (when executing program)
Access area Signal Actual MCU
SFR area
(MAP=EXT)
Internal RAM
Internal ROM
External area
Address
BHE*
Data
RD*
WR*
CS*
ALE
Address
BHE*
Data
RD*
WR*
CS*
ALE
Address
BHE*
Data
RD*
WR*
CS*
ALE
(floating during read operating)
(WR*=Low at write cycle,
(inputs external data at read cycle)
(WR*=Low at write cycle,
Outputs
Outputs
Outputs
RD*=Low at read cycle)
Does not output
(fixed to High output)
Does not output
(fixed to Low output)
Retains previous status
Floating
Does not output
(fixed to High output)
Does not output
(fixed to High output)
Does not output
(fixed to Low output)
Outputs
Outputs
Outputs
RD*=Low at read cycle)
Outputs
Outputs
This product
Outputs
Floating
Does not output
Does not output
(fixed to High output)
Outputs
Outputs
Floating
Does not output
(fixed to High output)
Does not output
(fixed to High output)
Outputs
Outputs
Outputs
(inputs external data at read cycle)
Outputs
(WR*=Low at write cycle,
RD*=Low at read cycle)
Outputs
Outputs
∗ for difference
∗
∗
∗
∗
∗
Table 1.3 Differences of outputs between actual MCU and this product (when stopping program)
Access area Signal
Address
BHE*
Data Floating
RD*
WR*
CS*
ALE
Actual MCU
( 15 / 72 )
This product
Outputs
Outputs RD* only
(WR* is fixed to High output)
Outputs
Outputs
∗ for difference
IMPORTANT
Table 1.4 Differences of outputs between actual MCU and this product (in stop mode)
Access area Signal
Address
BHE*
Data Floating
RD*
WR*
CS*
ALE
Actual MCU
Retains previous status
Retains previous status
Does not output
(fixed to High output)
Retains previous status
Does not output
(fixed to High output)
Table 1.5 Differences of outputs between actual MCU and this product (in wait mode)
Access area Signal
Address
BHE*
Data Floating
RD*
WR*
CS*
ALE
Actual MCU
Retains previous status
Retains previous status
Does not output
(fixed to High output)
Retains previous status
Does not output
(fixed to High output)
This product
Retains previous status
Does not output
(fixed to High output)
Retains previous status
Does not output
(fixed to High output)
This product
Retains previous status
Does not output
(fixed to High output)
Retains previous status
Does not output
(fixed to High output)
∗ for difference
∗ for difference
∗
∗
( 16 / 72 )
Chapter 2. Preparation
This chapter describes the package components, the system configuration and the preparation for using this product for the
first time.
2.1 Terminology ...............................................................................................................................18
2.2 Package Components.................................................................................................................. 19
2.3 Other Tool Products Required for Development........................................................................ 19
2.4 Name of Each Part......................................................................................................................20
(1) System Configuration ...........................................................................................................20
(2) Inside of Emulation Pod .......................................................................................................21
2.5 When Using the Emulator for the First Time.............................................................................22
( 17 / 72 )
Chapter 2. Preparation
2.1 Terminology
Some specific words used in this user's manual are defined as follows:
Emulator system
This means an emulator system built around the PC4701 emulator. The PC4701 emulator system is
configured with an emulator main unit, emulation pod, host machine and emulator debugger.
Emulator main unit (Hereafter PC4701)
This means a generic name for emulators for 8 and 16-bit MCUs. For details on specific models of
PC4701, visit the Renesas Tools Homepage.
Emulation pod
This means M306V2T-RPD-E (this product). This emulation pod is for M306V2 and M306V5
MCUs.
Host machine
This means a personal computer used to control the emulator and emulation pod.
http://www.renesas.com/en/tools
Emulator debugger
This means a software tool M3T-PD30 to control the emulator from the host machine through an
interface.
Firmware
Program that analyzes contents of communication with the emulator debugger and controls the
emulator hardware. This program is installed in the EEPROM. This program is downloadable from
the emulator debugger to upgrade the firmware or to support other MCUs.
Evaluation MCU
This means the microcomputer mounted on the emulation pod which is operated in the specific mode
for tools.
Target MCU
This means the microcomputer you are going to debug.
Target system
This means a user's application system using the microcomputer to be debugged.
*
In this user's manual, this symbol is used to show active "Low". (e.g. RESET*: Reset signal)
( 18 / 72 )
2.2 Package Components
The M306V2T-RPD-E package consists of the following items. When unpacking, check to see if
your M306V2T-RPD-E contains all of these items.
Item
M306V2T-RPD-E emulation pod main unit
FLX120-RPD flexible cable for connecting PC4701
FLX100 flexible cable for connecting pitch converter board (pre-installed in emulation pod)
FLX-100LCC pitch converter board for connecting target system
OSC-3 (10MHz) oscillator circuit board (pre-installed in emulation pod)
OSC-2 (32.768kHz) oscillator circuit board (pre-installed in emulation pod)
OSC-2 oscillator circuit board
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M306V2T-RPD-E user's manual (this manual)
M306V2T-RPD-E user's manual (Japanese)
Quantity
1
1
1
1
1
1
1
1
1
1
1
Please keep the M306V2T-RPD-E’s packing box and cushion material in your place for reuse at a
later time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting this product.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.3 Other Tool Products Required for Development
To bring forward programs development on the M306V2 and M306V5 MCUs, the products listed
below are necessary in addition to those contained package above. Get them separately.
Emulator main unit
Emulator debugger
Pitch converter board
(Required for M306V5 MCU)
100D0
M306V2
100P6S
Programming adapter
M306V5
To purchase these products, contact your nearest distributer.
PC4701
M3T-PD30
M306V5T-PTC
PCA7412L-100 (necessary for OSD ROM)
PCA7412F-100 (necessary for OTP version)
PCA7412L-100 (necessary for OSD ROM)
PCA7412E4S-64 (necessary for EPROM version or
OTP version)
( 19 / 72 )
2.4 Name of Each Part
(1) System Configuration
Figure 2.1 System configuration
(1) to (4) in Figure 2.1 are included with this product package.
(1) Emulation pod (M306V2T-RPD-E)
This emulation pod contains an evaluation MCU, emulation memory and circuit to feature the
debugging functions.
(2) Flexible cable (FLX120-RPD)
This is a 120-pin flexible cable for connecting the PC4701 emulator and the emulation pod.
(3) Flexible cable (FLX100)
This is a 100-pin flexible cable for connecting the emulation pod and the target system.
(4) Pitch converter board
This is a pitch converter board for connecting to the target system. For details, refer to "3.7
Connecting the Target System" (page 38).
( 20 / 72 )
(2) Inside of Emulation Pod
Figure 2.2 Internal view of emulation pod
(1) MCU-dependent board
Board which groups parts (pins and added functions) which vary according to MCU model.
(2) Base board
Board for the M16C/60 Series MCUs which controls the interface with the PC4701 and the
evaluation MCU.
(3) Memory board
Board on which is mounted the emulation memory (1MB) and the map memory (4 bits×1M) for
the M16C/60 Series MCUs.
(4) Oscillation circuit board
Oscillator circuit board on which the 10.000MHz of oscillation module device and 32.768kHz
of crystal oscillator are mounted.
( 21 / 72 )
Loading...
