LOW POWER
SRAMs
Advanced technology with superior performance
and industry-leading support
2020.10
HIGH PERFORMANCE AND
HIGH RELIABILITY USING
RENESAS’S ORIGINAL TECHNOLOGY
LOW POWER
SRAMs
Contents
Low Power SRAM Roadmap .......................................................................................................03
Industry-Leading Support, Application of Renesas Low Power SRAM ......................................03
Advanced Low Power SRAM Technology with Superior Performance and Reliability ..............04
Product Differentiation ................................................................................................................04
Product Benchmark .....................................................................................................................04
Package Lineup for Low Power SRAM ........................................................................................05
Low Power SRAM Part Name Decoder .......................................................................................05
Product List ..................................................................................................................................06
Low Power SRAM Roadmap
MP Now
■
02-03
MP New
SRAM type
Low Power
SRAM
■
Widest product lineup from 256Kbit to 64Mbit
■
Long term and stable support
■
Highest quality with Renesas core advanced technology
■
Easy switch to higher density in the same package
Density, Voltage CY2019 2020 2021 2022 2123 2024
256Kb 5V/3V, 1Mb 5V/3V,
2Mb 3V, 4Mb 5V
4Mb 3V, 8Mb 3V,
16Mb 3V, 32Mb 3V(16Mbx2)
16Mb 3V
32Mb 3V
64Mb 3V
0.15μm
MP Now
0.15μm 0.11μm Advanced LPSRAM
0.15μm Advanced LPSRAM
0.11μm Advanced LPSRAM
0.13μm (ECC embedded)
0.11μm Advanced LPSRAM
Industry-Leading Support,
Application of Renesas Low Power SRAM
■ Consumer (5%)
• Amusement
• Musical instrument
• Calculator, etc.
Car accessories (4%)
• ETC
• Data logger, etc.
■ Medical/Healthcare (2%)
■ Office Automation (6%)
• MFP, Server, etc.
■ Social Infra. (6%)
• Elevator
• Railway system, etc.
■ Telecom (8%)
• Router, Switch
• Base station, etc.
Source: Renesas Electronics, 2019
■ Industrial (69%)
• FA (PLC/CNC)
• POS
• ATM/Vending machine
• Security machine
• Measuring instrument, etc.
Advanced Low Power SRAM Technology with
Renesas’ Advanced LPSRAM Technology: 3D Image of Memory Cell
Stores larger amount of charge
Superior Performance and Reliability
■
Low standby current
■
High reliability
–Soft error free
–Latch-up free
Product Differentiation
2nd stacked structure:
Separate physical capacitor
(not parasitic capacitance)
1st stacked structure:
p-type TFT
(thin film transistor)
Infrastructure:
NMOS formed in Si substrate
Soft error free:
Latch-up free:
No parasitic PNPN-structure
in the substrate
Low standby current:
Optimized leakage current
of transistors
Production Soft error countermeasure:
Renesas supports soft error free products for entire lineup of 256Kbit to 64Mbit
Vendor Process 256Kb 1Mb 2Mb 4Mb 8Mb 16Mb 32Mb 64Mb
0.13μm CMOS ECC embedded
Renesas
Competitor
0.15μm Advanced
0.11μm Advanced
90nm CMOS no ECC
65nm CMOS ECC embedded
(5V)
(3V)
Change to 0.11μm Advanced
Yes No
Product Benchmark
Only Renesas supports unique products that realize both lowest standby current and soft error free
vs.
Standby current
vs.
Soft error rate
Renesas
0.11μm Advanced LPSRAM
0.3μA (4Mb, typ.) 3μA (4Mb, typ.)
Renesas
0.11μm Advanced LPSRAM
< 0.04 FIT / Mbit 500 to 1,000 FIT / Mbit
Competitor’s
65nm LPSRAM (with ECC)
Competitor’s
90nm LPSRAM (no ECC)
Package Lineup for Low Power SRAM
R1 L V 5256 E SA 5 S I #B1
Renesas Memory
Standby Current / Data Retention Current
Chip Configuration
Operating Voltage
Memory Density
04-05
28-pin
32-pin
44-pin
48-pin
(48-ball)
52-pin
SOP TSOP-I
256 Kb
1.27
17.5
1/4 Mb
1.27
20.75
11.93
0.55
14.1
0.5
0.5
256 Kb
13.4
1 Mb
20.0
8/16/32
64 Mb
20.0
TSOP-II
8.0
8.0
1/2/4
Mb
0.5
13.4
8.0
1.27
4 Mb
20.95
11.76
FBGAsTSOP μTSOP
x8
config.
x8 / x16
config.
9.5
8.0
16 Mb
(0.13μm)
12.0
2/4/8 Mb
0.8
18.41
11.76
8/16/32
64 Mb
0.4
10.79
10.49
4/8/16/32
8.5
64 Mb
(0.11μm)
7.5
■
Renesas provides 6 kinds of common packages, which are upward compatible, making it easy to expand density without changing the PCB.
Low Power SRAM Part Name Decoder
R1 L P 04 08 D SP --5 S I #B0
L
LPSRAM, Single chip
W
LPSRAM, Two chips
V
3V
P
5V
5256
01
02
04
08
16
32
64
RM 1#AS 2- 4L V 04 16 E G SB A
256Kb (x8)
1Mb
2Mb
4Mb
8Mb
16Mb
32Mb
64Mb
Bus Width
08
x8
16
x16
Chip Generation
Industrial Grade
Package Type
SA
TSOP-I (256Kb/8Mb/16Mb/32Mb/64Mb)
sTSOP (1Mb/2Mb/4Mb)
SB
TSOP-II
SD
µTSOP
SF
TSOP-I (1Mb)
SP
SOP (256Kb, 4Mb)
SN
SOP (1Mb)
BG
FBGA
Environment
A
Pb free (pure-Tin plating)
C
Pb free (non pure-Tin plating)
Operating Temperature
R
0 to 70˚C
I
-40 to 85˚C
2
-40 to 85˚C
Access Time
5
4
Packing, Environmental
#B0 / #B1
#S0 / #S1
Packing
A
Tray
C
Tube
H
Embossed Tape (TSOP, µTSOP, SOP)
K
Embossed Tape (FBGA, sTSOP)
L
Standard
S
55 ns
45 ns
Low power version
Packing Environmental
Tray or Tube Pb free
Embossed Tape Pb free
Assembly Site Rev., etc.
0
Rev. Code
1
Rev. Code
Product List
Process Density Configuration Part Name Package Access Time Voltage Temperature
R1LP5256ESP SOP (28) 55ns 4.5V to 5.5V -40 to 85°C
0.15μm
Advanced
0.15μm
Advanced
0.15μm
Advanced
0.15μm
Advanced
0.11μm
Advanced
0.11μm
Advanced
0.13μm
CMOS
0.11μm
Advanced
0.11μm
Advanced
0.11μm
Advanced
0.11μm
Advanced
256Kbit 32K x 8
1Mbit 128K x 8
2Mbit
4Mbit 512K x 8
4Mbit
8Mbit
16Mbit
(with ECC)
16Mbit
32Mbit
32Mbit 2M x 16 RMWV3216AGBG FBGA (48) 55ns 2.7V to 3.6V -40 to 85°C
64Mbit
256K x 8 R1LV0208BSA sTSOP (32) 55ns 2.7V to 3.6V -40 to 85°C
128K x 16 R1LV0216BSB TSOP-II (44) 55ns 2.7V to 3.6V -40 to 85°C
512K x 8
256K x 16
1M x 8 RMLV0808BGSB TSOP-II (44)
512K x 16
512K x 16 / 1M x 8
1M x 16 / 2M x 8 R1LV1616HSA TSOP-I (48) 45ns 2.7V to 3.6V -40 to 85°C
1M x 16 R1LV1616HBG FBGA (48) 45ns 2.7V to 3.6V -40 to 85°C
1M x 16 / 2M x 8
1M x 16 RMLV1616AGBG FBGA (48) 55ns 2.7V to 3.6V -40 to 85°C
2M x 16 / 4M x 8
2M x 16 RMLV3216AGBG FBGA (48) 55ns 2.7V to 3.6V -40 to 85°C
4M x 16 / 8M x 8
4M x 16 RMWV6416AGBG FBGA (48) 55ns 2.7V to 3.6V -40 to 85°C
R1LP5256ESA TSOP-I (28) 55ns 4.5V to 5.5V -40 to 85°C
R1LV5256ESP SOP (28) 55ns 2.7V to 3.6V -40 to 85°C
R1LV5256ESA TSOP-I (28) 55ns 2.7V to 3.6V -40 to 85°C
R1LP0108ESN SOP (32) 55ns 4.5V to 5.5V -40 to 85°C
R1LP0108ESF TSOP-I (32) 55ns 4.5V to 5.5V -40 to 85°C
R1LP0108ESA sTSOP (32) 55ns 4.5V to 5.5V -40 to 85°C
R1LV0108ESN SOP (32) 55ns 2.7V to 3.6V -40 to 85°C
R1LV0108ESF TSOP-I (32) 55ns 2.7V to 3.6V -40 to 85°C
R1LV0108ESA sTSOP (32) 55ns 2.7V to 3.6V -40 to 85°C
R1LP0408DSP SOP (32) 55ns 4.5V to 5.5V -40 to 85°C
R1LP0408DSB TSOP-II (32) 55ns 4.5V to 5.5V -40 to 85°C
RMLV0408EGSP SOP (32) 45ns 2.7V to 3.6V -40 to 85°C
RMLV0408EGSB TSOP-II (32) 45ns 2.7V to 3.6V -40 to 85°C
RMLV0408EGSA sTSOP (32) 45ns 2.7V to 3.6V -40 to 85°C
RMLV0414EGSB TSOP-II (44) 45ns 2.7V to 3.6V -40 to 85°C
RMLV0416EGSB TSOP-II (44) 45ns 2.7V to 3.6V -40 to 85°C
RMLV0416EGBG FBGA (48) 45ns 2.7V to 3.6V -40 to 85°C
45ns 2.7V to 3.6V -40 to 85°C
55ns 2.4V to 3.6V -40 to 85°C
RMLV0816BGSB TSOP-II (44)
RMLV0816BGBG FBGA (48)
RMLV0816BGSA TSOP-I (48)
RMLV0816BGSD μTSOP (52)
RMLV1616AGSA TSOP-I (48) 55ns 2.7V to 3.6V -40 to 85°C
RMLV1616AGSD μTSOP (52) 55ns 2.7V to 3.6V -40 to 85°C
RMLV3216AGSA TSOP-I (48) 55ns 2.7V to 3.6V -40 to 85°C
RMLV3216AGSD μTSOP (52) 55ns 2.7V to 3.6V -40 to 85°C
RMWV6416AGSA TSOP-I (48) 55ns 2.7V to 3.6V -40 to 85°C
RMWV6416AGSD μTSOP (52) 55ns 2.7V to 3.6V -40 to 85°C
45ns 2.7V to 3.6V -40 to 85°C
55ns 2.4V to 3.6V -40 to 85°C
45ns 2.7V to 3.6V -40 to 85°C
55ns 2.4V to 3.6V -40 to 85°C
45ns 2.7V to 3.6V -40 to 85°C
55ns 2.4V to 3.6V -40 to 85°C
45ns 2.7V to 3.6V -40 to 85°C
55ns 2.4V to 3.6V -40 to 85°C
MEMO
06-07
Notice
1. Descriptions of circuits, software and other related information in this document are provided only to illustrate the operation of semiconductor products and application examples. You are fully responsible for the incorporation or any other use of the circuits, software, and information in the
design of your product or system. Renesas Electronics disclaims any and all liability for any losses and damages incurred by you or third parties arising from the use of these circuits, software, or information.
2. Renesas Electronics hereby expressly disclaims any warranties against and liability for infringement or any other claims involving patents, copyrights, or other intellectual property rights of third parties, by or arising from the use of Renesas Electronics products or technical information described
in this document, including but not limited to, the product data, drawings, charts, programs, algorithms, and application examples.
3. No license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property rights of Renesas Electronics or others.
4. You shall not alter, modify, copy, or reverse engineer any Renesas Electronics product, whether in whole or in part. Renesas Electronics disclaims any and all liability for any losses or damages incurred by you or third parties arising from such alteration, modification, copying or reverse
engineering.
5. Renesas Electronics products are classified according to the following two quality grades: “Standard” and “High Quality”. The intended applications for each Renesas Electronics product depends on the product’s quality grade, as indicated below.
"Standard": Computers; office equipment; communications equipment; test and measurement equipment; audio and visual equipment; home electronic appliances; machine tools; personal electronic equipment; industrial robots; etc.
"High Quality": Transportation equipment (automobiles, trains, ships, etc.); traffic control (traffic lights); large-scale communication equipment; key financial terminal systems; safety control equipment; etc.
Unless expressly designated as a high reliability product or a product for harsh environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not intended or authorized for use in products or systems that may pose a direct threat to
human life or bodily injury (artificial life support devices or systems; surgical implantations; etc.), or may cause serious property damage (space system; undersea repeaters; nuclear power control systems; aircraft control systems; key plant systems; military equipment; etc.). Renesas Electronics
disclaims any and all liability for any damages or losses incurred by you or any third parties arising from the use of any Renesas Electronics product that is inconsistent with any Renesas Electronics data sheet, user’s manual or other Renesas Electronics document.
6. When using Renesas Electronics products, refer to the latest product information (data sheets, user’s manuals, application notes, “General Notes for Handling and Using Semiconductor Devices” in the reliability handbook, etc.), and ensure that usage conditions are within the ranges specified
by Renesas Electronics with respect to maximum ratings, operating power supply voltage range, heat dissipation characteristics, installation, etc. Renesas Electronics disclaims any and all liability for any malfunctions, failure or accident arising out of the use of Renesas Electronics products
outside of such specified ranges.
7. Although Renesas Electronics endeavors to improve the quality and reliability of Renesas Electronics products, semiconductor products have specific characteristics, such as the occurrence of failure at a certain rate and malfunctions under certain use conditions. Unless designated as a high
reliability product or a product for harsh environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not subject to radiation resistance design. You are responsible for implementing safety measures to guard against the possibility
of bodily injury, injury or damage caused by fire, and/or danger to the public in the event of a failure or malfunction of Renesas Electronics products, such as safety design for hardware and software, including but not limited to redundancy, fire control and malfunction prevention, appropriate
treatment for aging degradation or any other appropriate measures. Because the evaluation of microcomputer software alone is very difficult and impractical, you are responsible for evaluating the safety of the final products or systems manufactured by you.
8. Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental compatibility of each Renesas Electronics product. You are responsible for carefully and sufficiently investigating applicable laws and regulations that regulate the inclusion or use
of controlled substances, including without limitation, the EU RoHS Directive, and using Renesas Electronics products in compliance with all these applicable laws and regulations. Renesas Electronics disclaims any and all liability for damages or losses occurring as a result of your
noncompliance with applicable laws and regulations.
9. Renesas Electronics products and technologies shall not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited under any applicable domestic or foreign laws or regulations. You shall comply with any applicable export control laws and regulations
promulgated and administered by the governments of any countries asserting jurisdiction over the parties or transactions.
10. It is the responsibility of the buyer or distributor of Renesas Electronics products, or any other party who distributes, disposes of, or otherwise sells or transfers the product to a third party, to notify such third party in advance of the contents and conditions set forth in this document.
11. This document shall not be reprinted, reproduced or duplicated in any form, in whole or in part, without prior written consent of Renesas Electronics.
12. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in this document or Renesas Electronics products.
(Note 1) “Renesas Electronics” as used in this document means Renesas Electronics Corporation and also includes its directly or indirectly controlled subsidiaries.
(Note 2) “Renesas Electronics product(s)” means any product developed or manufactured by or for Renesas Electronics.
SALES OFFICES
Refer to "http://www.renesas.com/" for the latest and detailed information.
Renesas Electronics Corporation
TOYOSU FORESIA, 3-2-24 Toyosu, Koto-ku, Tokyo 135-0061, Japan
Renesas Electronics America Inc. Milpitas Campus
1001 Murphy Ranch Road, Milpitas, CA 95035, U.S.A.
Tel: +1-408-432-8888, Fax: +1-408-434-5351
Renesas Electronics America Inc. San Jose Campus
6024 Silver Creek Valley Road, San Jose, CA 95138, USA
Tel: +1-408-284-8200, Fax: +1-408-284-2775
Renesas Electronics Canada Limited
9251 Yonge Street, Suite 8309 Richmond Hill, Ontario Canada L4C 9T3
Tel: +1-905-237-2004
Renesas Electronics Europe GmbH
Arcadiastrasse 10, 40472 Düsseldorf, Germany
Tel: +49-211-6503-0, Fax: +49-211-6503-1327
Renesas Electronics (China) Co., Ltd.
Room 101-T01, Floor 1, Building 7, Yard No. 7, 8th Street, Shangdi, Haidian District, Beijing 100085, China
Tel: +86-10-8235-1155, Fax: +86-10-8235-7679
Renesas Electronics (Shanghai) Co., Ltd.
Unit 301, Tower A, Central Towers, 555 Langao Road, Putuo District, Shanghai 200333, China
Tel: +86-21-2226-0888, Fax: +86-21-2226-0999
Renesas Electronics Hong Kong Limited
Unit 1601-1611, 16/F., Tower 2, Grand Century Place, 193 Prince Edward Road West, Mongkok, Kowloon, Hong Kong
Tel: +852-2265-6688, Fax: +852 2886-9022
Renesas Electronics Taiwan Co., Ltd.
13F, No. 363, Fu Shing North Road, Taipei 10543, Taiwan
Tel: +886-2-8175-9600, Fax: +886 2-8175-9670
Renesas Electronics Singapore Pte. Ltd.
80 Bendemeer Road, #06-02 Singapore 339949
Tel: +65-6213-0200, Fax: +65-6213-0300
Renesas Electronics Malaysia Sdn.Bhd.
Unit No 3A-1 Level 3A Tower 8 UOA Business Park, No 1 Jalan Pengaturcara U1/51A, Seksyen U1, 40150 Shah Alam, Selangor, Malaysia
Tel: +60-3-5022-1288, Fax: +60-3-5022-1290
Renesas Electronics India Pvt. Ltd.
No.777C, 100 Feet Road, HAL 2nd Stage, Indiranagar, Bangalore 560 038, India
Tel: +91-80-67208700
Renesas Electronics Korea Co., Ltd.
17F, KAMCO Yangjae Tower, 262, Gangnam-daero, Gangnam-gu, Seoul, 06265 Korea
Tel: +82-2-558-3737, Fax: +82-2-558-5338
(Rev.4.0-1 November 2017)
www.renesas.com
© 2020 Renesas Electronics Corporation.
Document No. R10CP0007EJ0200
All rights reserved.
Loading...
