HD74UH04

Inverter

REJ03D0201–0400Z

(Previous ADE-205-016B (Z))

Rev.4.00

Feb.02.2004

Description

The HD74UH04 is high-speed CMOS inverter using silicon gate CMOS process. With CMOS low power
dissipation, it provides high-speed equivalent to LS-TTL series. The internal circuit of three stages
construction with buffer provides wide noise margin and stable output.

Features

• Encapsulated in very small 5pins package of 2.9 × 1.6 × 1.1 mm, the efficiency to mount on substrate is

significantly improved.

• The basic gate function is lined up as Renesas uni logic series.

• Supplied on emboss taping for high-speed automatic mounting.

• Electrical characteristics equivalent to the HD74HC04

Supply voltage range: 2 to 6 V
Operating temperature range: –40 to +85°C

• | I

• Ordering Information

Part Name Package Type Package Code Package

HD74UH04EL MPAK-5 pin MPAK-5V − EL (3,000 pcs/reel)

| = IOL = 2 mA (min)

OH

Abbreviation

Taping Abbreviation
(Quantity)

Rev.4.00, Feb.02.2004, page 1 of 1

HD74UH04

Y

Pin Arrangement

NC

IN Y

1

54V

CC

2

GND

3

OUT

(Top view)

Article Indication

Marking

Lot number

H 5 A

Absolute Maximum Ratings

Item Symbol Ratings Unit

Supply voltage V
Input voltage V
Output voltage V
Input diode current I
Output diode current I
Output current I
VCC/GND current ICC, I
Power dissipation P

CC

IN

OUT

IK

OK

OUT

GND

T

Storage temperature Tstg –65 to +150 °C

–0.5 to +7.0 V
–0.5 to VCC +0.5 V
–0.5 to VCC +0.5 V
±20 mA
±20 mA
±25 mA
±25 mA
200 mW

Rev.4.00, Feb.02.2004, page 2 of 6

HD74UH04

Recommended Operating Conditions

Item Symbol Ratings Unit

Supply voltage V
Input voltage V
Output voltage V

CC

IN

OUT

2 to 6 V
0 to V

CC

0 to V

CC

V

V
Operating temperature Topr –40 to +85 °C
Input rise/fall time tr, t

f

0 to 1000 (VCC = 2.0 V)

ns

0 to 500 (VCC = 4.5 V)
0 to 400 (VCC = 6.0 V)

Electrical Characteristics

Ta = 25°C Ta = –40 to 85°C

V

CC

tem Symbol

Input voltage

Output voltage

Input current I
Operating

V

IH

V

IL

V

OH

V

OL

IN

I

CC

current

(V)

Min Typ Max Min Max

2.0 1.5 — — 1.5 —

4.5 3.15 — — 3.15 —

6.0 4.2 — — 4.2 —

2.0 — — 0.5 — 0.5

4.5 — — 1.35 — 1.35

6.0 — — 1.8 — 1.8

2.0 1.9 2.0 — 1.9 —

4.5 4.4 4.5 — 4.4 —

6.0 5.9 6.0 — 5.9 —

4.5 4.18 4.31 — 4.31 — IOH = –2 mA

6.0 5.68 5.80 — 5.63 —

2.0 — 0.0 0.1 — 0.1

4.5 — 0.0 0.1 — 0.1

6.0 — 0.0 0.1 — 0.1

4.5 — 0.17 0.26 — 0.33 IOL = 2 mA

6.0 — 0.18 0.26 — 0.33

6.0 — — ±0.1 — ±1.0 µA VIN = VCC or GND

6.0 — — 1.0 — 10.0 VIN = VCC or GND

Unit Test Conditions

V

V

VV

VV

IN

IN

= V

= V

IL

IH

I

= –20 µA

OH

IOH = –2.6
mA

I

= 20 µA

OL

IOL = 2.6 mA

Rev.4.00, Feb.02.2004, page 3 of 6
