HD74HCT1G04
Inverter
REJ03D0193–0500Z
(Previous ADE-205-303C (Z))
Rev.5.00
Jan.28.2004
Description
Features
• The basic gate function is lined up as Renesas uni logic series.
• Supplied on emboss taping for high-speed automatic mounting.
• TTL compatible input level.
Supply voltage range : 4.5 to 5.5 V Operating temperature range : –40 to +85°C
• |I
| = IOL = 2 mA (min)
OH
• Ordering Information
Part Name Package Type Package Code Package
Abbreviation
HD74HCT1G04CME CMPAK-5 pin CMPAK-5V CM E (3,000 pcs/reel)
Taping Abbreviation (Quantity)
Rev.5.00, Jan.28.2004, page 1 of 7
HD74HCT1G04
Y
Outline and Article Indication
• HD74HCT1G04
Index band
Marking
F 5
CMPAK–5
Function Table
Input A Output Y
HL LH H : High level
L : Low level
Pin Arrangement
= Control code
NC
IN Y
GND
Rev.5.00, Jan.28.2004, page 2 of 7
1
2
3
(Top view)
54V
CC
OUT
HD74HCT1G04
Absolute Maximum Ratings
Item Symbol Ratings Unit Test Conditions
Supply voltage range V Input voltage range Output voltage range
*1
*1, 2
Input clamp current I Output clamp current I Continuous output current I Continuous current through
or GND
V
CC
Maximum power dissipation at Ta = 25°C (in still air)
CC
V
I
V
O
IK
OK
O
I
or I
CC
GND
P
T
*3
Storage temperature Tstg –65 to 150 °C Notes: The absolute maximum ratings are values, which must not individually be exceeded, and
furthermore, no two of which may be realized at the same time.
1. The input and output voltage ratings may be exceeded if the input and output clamp-current ratings are observed.
2. This value is limited to 5.5 V maximum.
3. The maximum package power dissipation was calculated using a junction temperature of 150°C.
–0.5 to 7.0 V –0.5 to VCC + 0.5 V –0.5 to VCC + 0.5 V Output : H or L ±20 mA VI < 0 or VI > V ±20 mA VO < 0 or VO >V ±25 mA VO = 0 to V
CC
±25 mA
200 mW
CC
CC
Recommended Operating Conditions
Item Symbol Min Max Unit Test Conditions
Supply voltage range V Input voltage range V Output voltage range V
Input rise / fall time
I
OL
I
OH
tr, t
CC
I
O
f
(0.3 V to 2.7 V) Operating temperature Ta –40 85 °C Note: Unused or floating inputs must be held high or low.
4.5 5.5 V
05.5V 0VCCV —2 V
mA
—–2
= 4.5 to 5.5 VOutput current
CC
VCC = 4.5 to 5.5 V
0 500 ns VCC = 4.5 to 5.5 V
Rev.5.00, Jan.28.2004, page 3 of 7
HD74HCT1G04
Electrical Characteristics
V
CC
Item Symbol
V
IH
V
IL
Output voltage
Input current I Operating
OH
V
OL
IN
I
CC
current Quiescent
I
CCT
supply current
(V)
4.5 to
5.5
4.5 to
5.5
4.5 4.4 4.5 — 4.4 — IOH = –20 µAV
4.5 4.18 4.31 — 4.13 —
4.5 — 0.0 0.1 — 0.1 IOL = 20 µA
4.5 — 0.17 0.26 — 0.33
5.5 — — ±0.1 — ±1.0 µAVIN = VCC or GND
5.5 — — 1.0 — 10.0 µAVIN = VCC or GND
5.5 — — 2.0 — 2.9 mA One input VIN = 2.4 V,
Ta = 25°C T
= –40 to 85°C
a
Min Typ Max Min Max
2.0 — — 2.0 —Input voltage
— — 0.8 — 0.8
Unit Test Conditions
V
V
VIN = V
IL
IOH = –2 mA
V
= V
IN
IH
IOL = 2 mA
other input VCC or GND
Rev.5.00, Jan.28.2004, page 4 of 7
HD74HCT1G04
Switching Characteristics
Ta = 25°C
Item Symbol
Output rise / fall time t
t t t
TLH THL
PLH
PHL
Min Typ Max
— 6 10 ns Test circuit
—7.512Propagation delay time —1017
(CL = 15 pF, tr = tf = 6 ns, VCC = 5 V)
Ta = 25°C
Item Symbol
Output rise / fall time t
Input capacitance C Equivalent capacitance C
t t t
TLH THL
PLH
PHL
IN
PD
V
CC
(V)
Min Typ Max Min Max
4.5 — 14 25 — 31 ns Test circuit
4.5 — 11.2 16 — 20Propagation delay time
4.5 — 16.4 27 — 31 ——2.55 — 5 pF ——10—— — pF
Ta = –40 to 85°C
(CL = 50 pF, tr = tf = 6 ns) Note: C
is equivalent capacitance inside of the IC calculated from the operating current without load (see
PD
test circuit). The average operating current without load is calculated according to the expression below. ICC (opr) = CPD • VCC • fIN + I
CC
Unit Test Conditions
ns Test circuit
Unit Test Conditions
ns Test circuit
Rev.5.00, Jan.28.2004, page 5 of 7
HD74HCT1G04
Test Circuit
V
CC
• Waveforms
Input
Pulse
Input
generator
50Ω
Note: 1. C includes probe and jig capacitance.
t = 6 ns
r
90%
L
90%
1.3 V
10%
t = 6 ns
1.3 V 10%
Output
C
L
f
3 V
GND
Output
t
Rev.5.00, Jan.28.2004, page 6 of 7
PHL
t
THL
90%
1.3 V 10%
t
PLH
t
TLH
1.3 V
10%
90%
V
OH
V
OL
HD74HCT1G04
Package Dimensions
(0.65)
5 – 0.2 ± 0.05
1.3 ± 0.2
2.0 ± 0.2
(0.65)
(0.2)
(0.425)(0.425) 1.25 ± 0.1
2.1 ± 0.3
0.9 ± 0.1
+ 0.1
0.15
– 0.05
0 – 0.1
Unit: mm
Package Code JEDEC JEITA
(reference value)
Mass
CMPAK–5V — Conforms
0.006 g
Rev.5.00, Jan.28.2004, page 7 of 7
