User’s Manual
H8SX/1651 Group PLQP0120LA-A
User System Interface Board for
E6000H Emulator
HS1651ECN61H User’s Manual
Renesas Microcomputer
Development Environment
System
H8SX Family / H8SX/1600 Series
HS1651ECN61HE
Rev.2.00 2008.09
Rev. 2.00 Sep. 08, 2008 Page ii of vi
REJ10J1394-0200
Notes regarding these materials
1. This document is provided for reference purposes only so that Renesas customers may select the appropriate
Renesas products for their use. Renesas neither makes warranties or representations with respect to the
accuracy or completeness of the information contained in this document nor grants any license to any
intellectual property rights or any other rights of Renesas or any third party with respect to the information in
this document.
2. Renesas shall have no liability for damages or infringement of any intellectual property or other rights arising
out of the use of any information in this document, including, but not limited to, product data, diagrams, charts,
programs, algorithms, and application circuit examples.
3. You should not use the products or the technology described in this document for the purpose of military
applications such as the development of weapons of mass destruction or for the purpose of any other military
use. When exporting the products or technology described herein, you should follow the applicable export
control laws and regulations, and procedures required by such laws and regulations.
4. All information included in this document such as product data, diagrams, charts, programs, algorithms, and
application circuit examples, is current as of the date this document is issued. Such information, however, is
subject to change without any prior notice. Before purchasing or using any Renesas products listed in this
document, please confirm the latest product information with a Renesas sales office. Also, please pay regular
and careful attention to additional and different information to be disclosed by Renesas such as that disclosed
through our website. (http://www.renesas.com )
5. Renesas has used reasonable care in compiling the information included in this document, but Renesas
assumes no liability whatsoever for any damages incurred as a result of errors or omissions in the information
included in this document.
6. When using or otherwise relying on the information in this document, you should evaluate the information in
light of the total system before deciding about the applicability of such information to the intended application.
Renesas makes no representations, warranties or guaranties regarding the suitability of its products for any
particular application and specifically disclaims any liability arising out of the application and use of the
information in this document or Renesas products.
7. With the exception of products specified by Renesas as suitable for automobile applications, Renesas
products are not designed, manufactured or tested for applications or otherwise in systems the failure or
malfunction of which may cause a direct threat to human life or create a risk of human injury or which require
especially high quality and reliability such as safety systems, or equipment or systems for transportation and
traffic, healthcare, combustion control, aerospace and aeronautics, nuclear power, or undersea communication
transmission. If you are considering the use of our products for such purposes, please contact a Renesas
sales office beforehand. Renesas shall have no liability for dama
8. Notwithstanding the preceding paragraph, you should not use Renesas products for the purposes listed below:
(1) artificial life support devices or systems
(2) surgical implantations
(3) healthcare intervention (e.g., excision, administration of medication, etc.)
(4) any other purposes that pose a direct threat to human life
Renesas shall have no liability for damages arising out of the uses set forth in the above and purchasers who
elect to use Renesas products in any of the foregoing applications shall indemnify and hold harmless Renesas
Technology Corp., its affiliated companies and their officers, directors, and employees against any and all
damages arising out of such applications.
9. You should use the products described herein within the range specified by Renesas, especially with respect
to the maximum rating, operating supply voltage range, movement power voltage range, heat radiation
characteristics, installation and other product characteristics. Renesas shall have no liability for malfunctions or
damages arising out of the use of Renesas products beyond such specified ranges.
10. Although Renesas endeavors to improve the quality and reliability of its products, IC products have specific
characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use
conditions. Please be sure to implement safety measures to guard against the possibility of physical injury, and
injury or damage caused by fire in the event of the failure of a Renesas product, such as safety design for
hardware and software including but not limited to redundancy, fire control and malfunction prevention,
appropriate treatment for aging degradation or any other applicable measures. Among others, since the
evaluation of microcomputer software alone is very difficult, please evaluate the safety of the final products or
system manufactured by you.
11. In case Renesas products listed in this document are detached from the products to which the Renesas
products are attached or affixed, the risk of accident such as swallowing by infants and small children is very
high. You should implement safety measures so that Renesas products may not be easily detached from your
products. Renesas shall have no liability for damages arising out of such detachment.
12. This document may not be reproduced or duplicated, in any form, in whole or in part, without prior written
approval from Renesas.
13. Please contact a Renesas sales office if you have any questions regarding the information contained in this
document, Renesas semiconductor products, or if you have any other inquiries.
ges arising out of the uses set forth above.
Rev. 2.00 Sep. 08, 2008 Page iii of vi
REJ10J1394-0200
Rev. 2.00 Sep. 08, 2008 Page iv of vi
REJ10J1394-0200
IMPORTANT INFORMATION
READ FIRST
• READ this user's manual before using this user system interface board.
• KEEP the user's manual handy for future reference.
Do not attempt to use the user system interface board until you fully understand its
mechanism.
User System Interface Board:
Throughout this document, the term "user system interface board" shall be defined as the
following product produced only by Renesas Technology Corp. excluding all subsidiary products.
• User system interface board (HS1651ECN61H)
The user system or a host computer is not included in this definition.
Purpose of the User System Interface Board:
This user system interface board is for connecting the evaluation chip board and user system.
This user system interface board must only be used for the above purpose.
Improvement Policy:
Renesas Technology Corp. (including its subsidiaries, hereafter collectively referred to as
Renesas) pursues a policy of continuing improvement in design, performance, functions, and
safety of the user system interface board. Renesas reserves the right to change, wholly or
partially, the specifications, design, user's manual, and other documentation at any time without
notice.
Target User of the User System Interface Board:
This user system interface board should only be used by those who have carefully read and
thoroughly understood the information and restrictions contained in the user's manual. Do not
attempt to use the user system interface board until you fully understand its mechanism.
It is highly recommended that first-time users be instructed by users that are well versed in the
operation of the user system interface board.
Rev. 2.00 Sep. 08, 2008 Page I of VI
REJ10J1394-0200
LIMITED WARRANTY
Renesas warrants its user system interface boards to be manufactured
in accordance with published specifications and free from defects in
material and/or workmanship. Renesas will repair or replace any
user system interface boards determined to be defective in material
and/or workmanship. User system interface boards are wearing parts
which Renesas will not repair or replace if damaged and/or worn
through use. The foregoing shall constitute the sole remedy for any
breach of Renesas' warranty. This warranty extends only to you, the
original Purchaser. It is not transferable to anyone who subsequently
purchases the user system interface board from you. Renesas is not
liable for any claim made by a third party or made by you for a third
party.
DISCLAIMER
RENESAS MAKES NO WARRANTIES, EITHER EXPRESS OR
IMPLIED, ORAL OR WRITTEN, EXCEPT AS PROVIDED
HEREIN, INCLUDING WITHOUT LIMITATION THEREOF,
WARRANTIES AS TO MARKETABILITY, MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE OR USE, OR
AGAINST INFRINGEMENT OF ANY PATENT. IN NO EVENT
SHALL RENESAS BE LIABLE FOR ANY DIRECT, INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR
LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE
USER SYSTEM INTERFACE BOARD, THE USE OF ANY USER
SYSTEM INTERFACE BOARD, OR ITS DOCUMENTATION,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
EXCEPT AS EXPRESSLY STATED OTHERWISE IN THIS
WARRANTY, THIS USER SYSTEM INTERFACE BOARD IS SOLD
"AS IS ", AND YOU MUST ASSUME ALL RISK FOR THE USE
AND RESULTS OBTAINED FROM THE USER SYSTEM
INTERFACE BOARD.
Rev. 2.00 Sep. 08, 2008 Page II of VI
REJ10J1394-0200
State Law:
Some states do not allow the exclusion or limitation of implied warranties or liability for
incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may have other rights which may vary from
state to state.
The Warranty is Void in the Following Cases:
Renesas shall have no liability or legal responsibility for any problems caused by misuse,
abuse, misapplication, neglect, improper handling, installation, repair or modifications of the user
system interface board without Renesas' prior written consent or any problems caused by the user
system.
All Rights Reserved:
This user's manual and user system interface board are copyrighted and all rights are reserved
by Renesas. No part of this user's manual, all or part, may be reproduced or duplicated in any
form, in hard-copy or machine-readable form, by any means available without Renesas' prior
written consent.
Other Important Things to Keep in Mind:
1. Circuitry and other examples described herein are meant merely to indicate the characteristics
and performance of Renesas' semiconductor products. Renesas assumes no responsibility for
any intellectual property claims or other problems that may result from applications based on
the examples described herein.
2. No license is granted by implication or otherwise under any patents or other rights of any third
party or Renesas.
Figures:
Some figures in this user's manual may show items different from your actual system.
Limited Anticipation of Danger:
Renesas cannot anticipate every possible circumstance that might involve a potential hazard.
The warnings in this user's manual and on the user system interface board are therefore not all
inclusive. Therefore, you must use the user system interface board safely at your own risk.
Rev. 2.00 Sep. 08, 2008 Page III of VI
REJ10J1394-0200
SAFETY PAGE
READ FIRST
• READ this user's manual before using this user system interface board.
• KEEP the user's manual handy for future reference.
Do not attempt to use the user system interface board until you fully understand its
mechanism.
DEFINITION OF SIGNAL WORDS
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
DANGER
avoided, will result in death or serious injury.
WARNING
avoided, could result in death or serious injury.
CAUTION
avoided, may result in minor or moderate injury.
CAUTION
potentially hazardous situation which, if not avoided, may result
in property damage.
DANGER indicates an imminently hazardous situation which, if not
WARNING indicates a potentially hazardous situation which, if not
CAUTION indicates a potentially hazardous situation which, if not
CAUTION used without the safety alert symbol indicates a
NOTE emphasizes essential information.
Rev. 2.00 Sep. 08, 2008 Page IV of VI
REJ10J1394-0200
WARNING
Observe the precautions listed below. Failure to do so
will result in a FIRE HAZARD and will damage the user
system and the emulator product or will result in
PERSONAL INJURY. The USER PROGRAM will be
LOST.
1. Do not repair or remodel the emulator product by
yourself for electric shock prevention and quality
assurance.
2. Always switch OFF the E6000H emulator and user system
before connecting or disconnecting any CABLES or
PARTS.
3. Always before connecting any BOARDS, make sure that
pin 1 on both sides are correctly aligned.
Rev. 2.00 Sep. 08, 2008 Page V of VI
REJ10J1394-0200
Rev. 2.00 Sep. 08, 2008 Page VI of VI
REJ10J1394-0200
Preface
The HS1651ECN61H is a user system interface board that connects a user system for the
H8SX/1651 PQLP0120LA-A (former package: FP-120B) to the H8SX/1650 E6000H emulator
(HS1650EPH60H).
Contents
Preface ......................................................................................................................i
Section 1 Configuration........................................................................................... 1
Section 2 Connection Procedures............................................................................ 3
2.1 Connecting the User System Interface Board to the User System........................................ 3
2.1.1 Installing the IC Socket......................................................................................... 3
2.1.2 Soldering the IC Socket ........................................................................................ 4
2.1.3 Installing the IC Socket......................................................................................... 5
2.1.4 Fastening the Cable Head ..................................................................................... 5
2.2 Exchanging the Spacers of the Evaluation Chip Board ........................................................ 7
2.3 Connecting the User System Interface Board to the Evaluation Chip Board ....................... 8
2.4 Recommended Dimensions for the User System Mounting Pad (Footprint)...................... 10
2.5 Dimensions of the Evaluation Chip Board and the User System Interface Board.............. 11
2.6 Resulting Dimensions after Connecting the User System Interface Board......................... 12
Section 3 Installing the MCU on the User System................................................ 13
Section 4 Verifying Operation............................................................................... 15
Section 5 Restriction on the Interface.................................................................... 17
Section 6 Points for Caution..................................................................................19
Section 1 Configuration
Section 1 Configuration
Figure 1 and table 1 show the external appearance and components, respectively, of the user
system interface board for the PLQP0120LA-A package. Please make sure you have all of these
components after you have unpacked the box.
Evaluation chip board
Spacer
Screws (M2.0 x 6 mm)
Socket cover
User system
Screws (M2.0 × 10 mm)
(for fastening cable head)
Board
IC socket
Figure 1 User System Interface Board for the H8SX/1651 Group PLQP0120LA-A Package
Rev. 2.00 Sep. 08, 2008 Page 1 of 20
REJ10J1394-0200
Section 1 Configuration
CAUTION
Use an NQPACK120SE-ND socket and an HQPACK120SE
cover (manufactured by Tokyo Eletech Corporation) for the
PLQP0120LA-A-packaged IC socket on the user system.
Table 1 HS1651ECN61H Components
No. Component Quantity Remarks
1 Board 1
2 IC socket 1 For the PLQP0120LA-A package
3 Socket cover 1 For installing an PLQP0120LA-A packaged MCU
4 Screw (M2.0 x 10 mm) 4 For fastening cable head
5 Screw (M2.0 x 6 mm) 4 For installing an PLQP0120LA-A packaged MCU
6 Guide pins (φ1 mm) 3 For determining the IC socket location
7 Spacers (2.6 MP x 25 mm) 2
8 Screwdriver 1 For tightening screws
9 User’s manual 1 User’s manual for HS1651ECN61H (this manual)
Rev. 2.00 Sep. 08, 2008 Page 2 of 20
REJ10J1394-0200
Section 2 Connection Procedures
Section 2 Connection Procedures
2.1 Connecting the User System Interface Board to the User System
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE BOARD
is connected or removed. Before connecting the two, make
sure that pin 1 on both sides are correctly aligned. Failure to
do so will result in a FIRE HAZARD and will damage the
user system and the emulator product or will result in
PERSONAL INJURY. The USER PROGRAM will be LOST.
To connect the cable head to the user system, follow the instructions below.
2.1.1 Installing the IC Socket
After checking the location of pin 1 on the IC socket fasten it to the user system before soldering.
CAUTION
After confirming the location of pin 1 on the IC socket,
apply epoxy resin adhesive to the end of the four projections
at the bottom of the IC socket, and fasten it to the user
system.
Rev. 2.00 Sep. 08, 2008 Page 3 of 20
REJ10J1394-0200
Section 2 Connection Procedures
Use the guide pins provided with the product to determine where to install the IC socket, as shown
in figure 2.
Pin 1
Guide pins
4 projections to apply
epoxy resin adhesive to
Bottom view of IC socket
Figure 2 Correctly Placing the IC Socket
2.1.2 Soldering the IC Socket
After fastening, solder the IC socket for an PLQP0120LA-A package to the user system.
User system
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
CAUTION
Be sure to completely solder the leads so that the solder
gently covers the leads and forms solder fillets. (Use
slightly more solder than with the MCU.)
Rev. 2.00 Sep. 08, 2008 Page 4 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.1.3 Installing the IC Socket
CAUTION
Check the location of pin 1 before inserting.
After checking the location of pin 1 on the user system interface board and pin 1 on the IC socket
connector, align the guide pins on the IC socket connector with the guide holes on the user system
interface board, and insert the IC socket connector into the IC socket (figure 3).
2.1.4 Fastening the Cable Head
CAUTION
1. Use a screwdriver whose head matches the screw head.
2. The tightening torque must be 0.054 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be
caused by a crack in the IC socket solder.
3. If the emulator does not operate correctly, cracks might
have occurred in the solder. Check conduction with
a tester and re-solder the IC socket if necessary.
Fasten the user system interface cable head to the IC socket for an PLQP0120LA-A package on
the user system with the four screws (M2.0 x 10 mm) provided. Each screw should be tightened a
little at a time, alternating between screws on opposing corners. Take special care, such as by
manually securing the IC socket soldered area, to prevent the soldered IC socket from being
damaged by overtightening the screws or twisting the components.
Rev. 2.00 Sep. 08, 2008 Page 5 of 20
REJ10J1394-0200
Section 2 Connection Procedures
Pin 1
Screws (M2.0 x 10 mm)
Board
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
User system
Figure 3 Connecting the User System Interface Board to the User System
Rev. 2.00 Sep. 08, 2008 Page 6 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.2 Exchanging the Spacers of the Evaluation Chip Board
After connecting the user system interface board to the user system, be careful not to apply load to
the user system.
Exchange the spacers (2.6MP × 10 mm) for the evaluation chip board with the spacers (2.6MP ×
25 mm) provided with the user system interface board.
Evaluation chip board
Spacer
(2.6MP × 25 mm)
Figure 4 Exchanging the Spacers
Rev. 2.00 Sep. 08, 2008 Page 7 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.3 Connecting the User System Interface Board to the Evaluation Chip
Board
WARNING
Observe the precautions listed below. Failure to do so
will result in a FIRE HAZARD and will damage the user
system and the emulator product or will result in
PERSONAL INJURY. The USER PROGRAM will be
LOST.
1. Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE BOARD
is connected or removed. Before connecting the two,
make sure that the pin 1 positions on both sides are
correctly aligned.
2. The user system interface board must be used with the
emulator for which it was designed.
1. Make sure the user system and emulator are turned off.
2. Align the connectors on the user system interface board with those on the evaluation chip
board by matching the numbers on the connectors (figure 5).
3. Adjust the height of the spacers of the evaluation chip board to accommodate the user system.
Rev. 2.00 Sep. 08, 2008 Page 8 of 20
REJ10J1394-0200
Section 2 Connection Procedures
Evaluation chip board
Connector No.
Evaluation
Chip Board
Connector No.
UCN1 UCN1
UCN2
Board
Board
Connector No.
UCN2
Figure 5 Connecting the User System Interface Board to the Evaluation Chip Board
Rev. 2.00 Sep. 08, 2008 Page 9 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.4 Recommended Dimensions for the User System Mounting Pad
(Footprint)
Figure 6 shows the recommended dimensions for the mounting pad (footprint) for the user system
with the IC socket for an PLQP0120LA-A package (NQPACK120SE-ND: manufactured by
Tokyo Eletech Corporation). The dimensions in figure 6 are somewhat different from those of the
mounting pad for the system with the actual MCU. Also, note the user system can not be
connected to the user system interface board with inserting the guide pins in place.
0.40 x 29 = 11.6 ± 0.05
17.0 min
13.0 MAX
0.40 ± 0.05
0.2 ± 0.05
3.0 - φ1.0
0.40 ± 0.05
5.8
5.8
0.40 x 29 = 11.6 ± 0.05
Unit: mm
Figure 6 Recommended Dimensions for the Mounting Pad
Rev. 2.00 Sep. 08, 2008 Page 10 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.5 Dimensions of the Evaluation Chip Board and the User System
Interface Board
The dimensions of the evaluation chip board and the user system interface board are shown in
figure 7.
140.0
100.0
Evaluation chip board
118.5
102.5 16.0
84.5
69.0
34.5
78.5
User system interface board
Unit: mm
Tolerance:
±
0.5 mm
Figure 7 Dimensions of the Evaluation Chip Board and the User System Interface Board
Rev. 2.00 Sep. 08, 2008 Page 11 of 20
REJ10J1394-0200
Section 2 Connection Procedures
2.6 Resulting Dimensions after Connecting the User System Interface
Board
The dimensions of the assembly after the user system interface board has been connected to the
user system, are shown in figure 8.
Evaluation chip board
54.9
32.9
13.3
Spacer (φ5.8)
56.5
User system
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
56.5
45.0
45.0
Unit: mm
Tolerance: ±1.0 mm
Figure 8 Dimensions of the Assembly after Connection of the User System Interface Board
Rev. 2.00 Sep. 08, 2008 Page 12 of 20
REJ10J1394-0200
Section 3 Installing the MCU on the User System
Section 3 Installing the MCU on the User System
CAUTION
1. Check the location of pin 1 before inserting the MCU.
2. Use a screwdriver whose head matches the screw head.
3. The tightening torque must be 0.054 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be
caused by a crack in the IC socket solder.
4. If the MCU does not operate correctly, cracks might have
occurred in the solder. Check conduction with a tester
and re-solder the IC socket if necessary.
Check the location of pin 1 before inserting the MCU into the IC socket on the user system, as
shown in figure 9. After inserting the MCU, fasten the socket cover with the four screws (M2.0 x
6 mm) provided for this. Take special care, such as by manually securing the IC socket soldered
area, to prevent the IC socket from being damaged by overtightening the screws or twisting the
components.
Rev. 2.00 Sep. 08, 2008 Page 13 of 20
REJ10J1394-0200
Section 3 Installing the MCU on the User System
Screws (M2.0 x 6 mm)
Socket cover
(HQPACK120SE
manufactured by
Tokyo Eletech Corporation)
MCU
Pin 1
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
User system
Figure 9 Installing the MCU on the User System
Rev. 2.00 Sep. 08, 2008 Page 14 of 20
REJ10J1394-0200
Section 4 Verifying Operation
Section 4 Verifying Operation
1. Turn on the emulator according to the procedures described in the H8SX/1650 E6000H
Emulator User's Manual (HS1650EPH60HE).
2. Verify the user system interface cable connections by checking the pin states with the CHECK
command (emulator command) and checking the bus states with the FILL command (emulator
command). If an error is detected, recheck the soldered IC socket and the location of pin 1.
3. The emulator connected to this user system interface board supports three kinds of clock
sources as the MCU clock. For details, refer to the H8SX/1650 E6000H Emulator User's
Manual (HS1650EPH60HE).
⎯ To use the emulator internal clock
Select the clock in the emulator by the CLOCK command (emulator command).
⎯ To use the external clock on the user system
Supply the external clock from the user system to the emulator by inputting the signal
to the EXTAL pin (pin 84) on the user system interface board or connecting a crystal
oscillator to the XTAL (pin 83) and EXTAL pins. For details, refer to the H8SX/1651
Hardware Manual.
Figure 10 shows the clock oscillator on the user system interface board.
1 MΩ
HCU04
EXTAL XTAL
System clock
HCU04
HCU04
270 Ω
HCU04
HCU04
HCU04
Figure 10 Clock Oscillator
0 Ω
Rev. 2.00 Sep. 08, 2008 Page 15 of 20
REJ10J1394-0200
To E6000H
emulator
Section 4 Verifying Operation
⎯ To use the crystal oscillator mounted on the evaluation chip board
Install the crystal oscillator into the crystal oscillator terminals on the evaluation chip
board.
Enlarged
view
Crystal
oscillator
X1 X2
Crystal oscillator terminals
Evaluation chip
board
Figure 11 Installing the Clock Oscillator
Rev. 2.00 Sep. 08, 2008 Page 16 of 20
REJ10J1394-0200
Section 5 Restriction on the Interface
Section 5 Restriction on the Interface
The following restriction applies to the interface when pins PF7, PF6, and PF5 of the MCU are
selected as CS-output pins by the emulator, to which the user system interface board is connected.
Jumper pins (SW1 to SW3) are used to switch the functions of pins PF7, PF6, and PF5 between
port and CS-output functions. While these pins are in use as CS-output pins, the functions of PF7,
PF6, and PF5 are disabled.
MCU
PF7
CS7
PF6
CS6
PF5
CS5
1
3
SW1
1
3
SW2
1
3
SW3
Figure 12 Interface Circuit
User system
PF7
PF6
PF5
Rev. 2.00 Sep. 08, 2008 Page 17 of 20
REJ10J1394-0200
Section 5 Restriction on the Interface
Rev. 2.00 Sep. 08, 2008 Page 18 of 20
REJ10J1394-0200
Section 6 Points for Caution
Section 6 Points for Caution
1. Before connecting any parts or cables, make sure that the pins at the pin 1 position on both
sides are correctly aligned.
2. Do not apply excessive force to the user system interface board while it is connected to the
user system.
3. The dimensions of the recommended mounting pad for the IC socket for this user system
interface board are different from those of the pad for the MCU.
4. This user system interface board is specifically designed for the HS1650EPH60H emulator.
Do not use this board with any other emulator.
5. When power is not being supplied to the Vcc pin on the user system interface board, the
emulator displays ** VCC DOWN. In this situation, the emulator will not operate correctly.
6. The P1 short connector is used for testing. Do not remove the inserted jumper pin.
SW1
SW2
SW3
3
3
3
1
1
1
P1
3
1
Figure 13 P1 Jumper Socket
7. The terminals of SW1 to SW3 are used to switch pins between port and CS-output functions.
Insert the jumper pins to select the desired function. When the pins are used for CS output, the
port functions are disabled. When the port functions of the pins are in use, the CS output
functions are disabled. At shipment, the port functions are enabled (i.e., the jumper pins are
inserted in “1”).
Rev. 2.00 Sep. 08, 2008 Page 19 of 20
REJ10J1394-0200
Section 6 Points for Caution
