CR2430
24,5
0
3
0
-0.3
20
min 0.08
2.7 kΩ6.81 kΩ5.62 k
Ω
12 kΩ27 k
Ω
-20°C
0°C
23°C
70°C
0°C
70°C
23°C
-20°C
70°C
3V Lithium Battery OEM
Swiss Made
Technical Data Sheet
Specifications Dimensions
Chemical System Li / MnO2
Nominal Voltage 3 V
Rated Capacity 285 mAh
Standard Discharge Current 0.5 mA
Max. Cont. Discharge Current 4.0 mA
Average Weight 4.1 g
Operating Temperature* -40 - +85 °C
Self Discharge at 23°C < 1% / year
Performance
Discharge performance at 23°C
3.5
3.0
2.5
2.0
1.5
Voltage [V]
1.0
0.5
0.0
0 200 400 600 800
Time [h]
(According to IEC 60086)
Ref. Ø20
∅∅∅∅
∅∅∅∅
Discharge performance at 23°C
3.5
3.0
2.5
2.0
1.5
Voltage [V]
1.0
0.5
0.0
0 500 1000 1500 2000 2500 3000
-0.3
Time [h]
Renata SA Tel. +41 (0)61 975 75 75 sales@renata.com
CH-4452 Itingen/Switzerland Fax. +41 (0)61 975 75 95 www.renata.com
Temperature performance Load 12k
3.5
3.0
2.5
2.0
1.5
Voltage [V]
1.0
0.5
0.0
0 250 500 750 1000 1250
*
Information and contents in this data sheet are for reference purpose only. They do not constitute any warranty or representation and are subject to change
Time [h]
In applications where the battery is exposed to temperatures above 70 °C, please contact Renata for consultancy.
without notice. For most current information and further details, please contact your Renata representative.
ΩΩΩΩ
Cell capacity at various loads
300
275
250
225
200
Capacity [mAh]
175
150
1 10 100
Load [k
]
ΩΩΩΩ
Rev. CR2430. 07 / 02.08
