Remote Technologies RT10500 User Manual
T4
Installation & Operation Guide
v1.0
T4
IR-PRO
Universal System Controller
Professional Infrared Code Capture System
i
Reorient or relocate the receiving antenna.
FEDERAL COMMUNICATIO NS COMMISSION NOTICE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC ID: MMURTI0500
CAN: 3166-RTI0500
T4 Universal System Controller
ii
BATTERY DISPOSAL
For environmental reasons, your T4 universal system
controller uses “environmentally sound” Lithium-ion
rechargeable batteries. These batteries do not contain
any poisonous heavy metals that can damage the
Li-polymer
environment.
In the interest of recycling, please do not dispose of these ba tteries
in the household waste at the end of their useful life. Instead,
dispose of them at an appropriate collection site.
SAFETY SUGGESTIONS
Read Instructions. Read all safety and operating instructions
before operating the unit.
Heat. Keep the unit away from heat sources such as radiators,
heat registers, stoves, etc., including amplifiers that produce heat.
Power Sources. Connect the docking station only to the power
supply that was included with the unit. Recharge the battery only
with the docking station that was included with the unit.
Power Cord Protection. Route power supply cords so that they
are not likely to be walked on or pinched by items placed on or
against them, paying particular attention to the cords at power
receptacles and at the point at which they exit from the unit.
Nonuse Periods. Unplug the power supply from the outlet when
the unit is to be left unused for a long period.
Water and Moisture. Do not use the unit near water—for
example, near a sink, in a wet basement, near a swimming pool,
near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to
be spilled into the enclosure through openings.
Cleaning. The unit should be cleaned only as recommended in the
operating guide.
iii
Servicing. Do not attempt any service beyond that described in
the operating guide. Refer all other service needs to qualified
service personnel.
Damage Requiring Service. The unit should be serviced by
qualified service personnel when:
• The power supply cord or the plug has been damaged.
• Objects have fallen or liquid has been spilled into the unit.
• The unit does not appear to operate normally or exhibits a
marked change in performance.
LIMITED WARRANTY
Remote Technologies Incorporated warrants its products for a
period of one (1) year from the date of purchase from Remote
Technologies Incorporated or an authorized Remote Technologies
Incorporated distributor.
This warranty may be enforced by the original purchaser and
subsequent owners during the warranty period, so long as the
original dated sales receipt or other proof of warranty coverage is
presented when warranty service is required.
Except as specified below, this warranty covers all defects in
material and workmanship in this product. The following are not
covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote
Technologies Incorporated.
4. Causes other than product defects, including lack of skill,
competence or experience of user.
5. Shipment of this product (claims must be made to carrier).
6. Being altered or which the serial number has been defaced,
modified or removed.
T4 Universal System Controller
iv
Remote Technologies Incorporated is not liable for any damages
caused by its products or for its failure of its products to perform,
including any lost profits, lost savings, incidental damages, or
consequential damages.
Remote Technologies Incorporated is not liable for damages based
upon inconvenience, loss of use of the product, loss of time,
interrupted operation, commercial loss, any claim made by a third
party or made by you for a third party.
Remote Technologies Incorporated’s liability for any defective
product is limited to repair or replacement of the product, at our
option.
If your T4 needs service, please contact Remote Technologies
Incorporated by telephone, fax or e-mail for return information.
Please do not return products to RTI without return
authorization.
DISCLAIMER
All rights are reserved. No part of this document may be
photocopied, reproduced, or translated without the prior written
notice of Remote Technologies Incorporated.
The information contained in this document is subject to change
without notice. Remote Technologies Incorporated shall not be
liable for errors or omissions contained herein or for consequential
damages in connection with the furnishing, performance, or use of
this guide.
Microsoft and Windows are registered trademarks of Microsoft
Corporation. Other brands and their products are trademarks or
registered trademarks of their respective holders.
T4, It’s Under Control, TheaterTouch , and the RTI logo are
trademarks of Remote Technologies Incorporated.
Contents
Federal Communications Commission Notice-----------------------i
Battery Disposal -----------------------------------------------------------ii
Safety Suggestions -------------------------------------------------------- ii
Limited Warranty -------------------------------------------------------- iii
Disclaimer------------------------------------------------------------------ iv
Contents------------------------------------------------------------------------ v
Chapter 1. Welcome --------------------------------------------------------- 1
Compatibility Note-------------------------------------------------------- 2
Unpacking and Inspection ---------------------------------------------- 2
Product Contents---------------------------------------------------------- 2
Software Requirements -------------------------------------------------- 2
Chapter 2. Introduction ---------------------------------------------------- 3
Features---------------------------------------------------------------------- 3
Important Notes -----------------------------------------------------------4
Cleaning--------------------------------------------------------------------- 5
Battery and Docking Station --------------------------------------------5
Getting Started------------------------------------------------------------- 7
Remote Reference ---------------------------------------------------------8
Chapter 3. Operation-------------------------------------------------------- 9
The Touchscreen Display------------------------------------------------ 9
The Control Panel Page ------------------------------------------------ 10
Backlight Level-------------------------------------------------------- 11
Time Out---------------------------------------------------------------- 13
Set Clock---------------------------------------------------------------- 14
Sound-------------------------------------------------------------------- 15
v
T4 Universal System Controller
vi
Calibrate Touchscreen----------------------------------------------- 16
Tilt Switch-------------------------------------------------------------- 17
Battery------------------------------------------------------------------- 18
Network Information------------------------------------------------ 19
The Web Browser-------------------------------------------------------- 20
Chapter 4. Programming------------------------------------------------- 21
Programming The T4 --------------------------------------------------- 21
Chapter 5. Troubleshooting--------------------------------------------- 23
Display is Dim, Blank or Unreadable ------------------------------- 23
USB Communication Problems -------------------------------------- 23
IR Code Problems ------------------------------------------------------- 24
Chapter 6. Service and Support ---------------------------------------- 25
Updates and New Products------------------------------------------- 25
Contacting Remote Technologies Incorporated ------------------ 25
RTI Technical Support-------------------------------------------------- 25
Specifications--------------------------------------------------------------- 27
Chapter 1. Welcome
Thank you for purchasing the T4 universal controller. The T4 is an
advanced wireless universal system controller that provides a selfcontained control system for controlling audio/video
components, lights, and other electronic systems in the home. Its
design maintains the perfect balance between display size and
resolution. At 6.4 inches the LCD is small enough to be a truly
hand-held device, yet it provides the full VGA resolution
necessary for displaying video windows and web pages. The T4
interface is fully programmable using RTI’s TheaterTouch
Designer™ software, making it easy to display custom buttons,
text, graphics, and animations.
Programming is easy and convenient thanks to the Windows®
based TheaterTouch Designer™ software. Because RTI’s remote
control products are sold only through professional
installers/programmers, and never directly to consumers, it is our
philosophy to not incorporate programming capability directly
into our products. Instead, we are committed to providing our
dealers with the hardware and software tools that allow them to
create re-usable programming databases and templates in the
most efficient and reliable way possible.
The T4 is capable of both infrared and radio frequency output.
Optional RF receivers are available for transmission through walls
and cabinets. The RF receivers connect to an RTI control system
for the ultimate in control reliability and flexibility. RTI control
systems provide many advanced features such as IR routing, local
macro execution, power sensing, and RS-232 control.
The T4 can be used as a stand-alone device or as part of an
expandable central control system. When used with the available
RTI accessory devices, the T4 is capable of infrared routing, relay
control, power sensing, and RS -232 communications for advanced
control.
1
T4 Universal System Controller
2
COMPATIBILITY NOTE
The T4 and TheaterTouch Designer™ software are compatible with
infrared (IR) commands with carrier frequencies between 15KhZ
and 460KhZ, as well as those commands that do not use a carrier.
This covers virtually all of the remotes that exist to date.
UNPACKING AND INSPECTION
After unpacking your new T4 universal system controller, save all
of the packing materials in case you ever have to ship the unit.
Thoroughly inspect the T4 and packing materials for signs of
damage. Report any damage to the carrier immediately. Report
any equipment malfunctions to Remote Technologies
Incorporated or an authorized Remote Technologies Incorporated
distributor.
PRODUCT CONTENTS
Contents within the box include the following items:
§ One (1) T4 universal system controller
§ One (1) Docking Station
§ One (1) Universal Power Supply
§ One (1) Operation guide
SOFTWARE REQUIREMENTS
The recommended minimum system requirements needed to run
the TheaterTouch Designer software are as follows:
§ Windows 98SE
®
, Windows ME®, Windows 2000®, Windows
XP® or later version.
§ A free USB port.
§ At least 64 Megabytes of RAM.
§ At least 100 Megabytes of free disk storage.
Chapter 2. Introduction
FEATURES
The T4 provides superior quality and reliability as well as these
specific features:
§ Ergonomic design permits effortless operation.
§ Full color TFT LCD to display custom buttons, text,
graphics, and animations.
§ Integrated 802.11 WiFi.
§ Integrated high--resolution touchscreen.
§ Powerful 32--bit, 400MHz XScale processor.
§ 32MByte of Flash Memory
§ Tilt switch can automatically turn on backlight when
picked up.
§ Extremely bright, backlit display and keys with adjustable
brightness.
§ Stereo speakers.
§ Thirteen assignable/programmable keys.
§ Transmits IR and RF (or both -on a single button or within
a macro).
§ Optional RF receiver allows you to transmit through walls,
cabinets, etc.
§ Includes a Lithium--Polymer Battery and docking station.
§ Completely customizable, programmable, and
upgradeable.
§ Extremely wide IR transmitting frequency range.
§ Optional VESA mounting module with Power-Over-
Ethernet and analog video inputs.
§ Optional ‘Voltage’ and ‘Video’ power sensing modules.
3
T4 Universal System Controller
4
§ Optional interface for RS-232 controlled equipment.
§ Interchangeable front and back bezel colors.
§ Non--volatile Flash memory stores your program even
when power is lost.
§ Easy--to-use Windows based software for programming
and customization.
§ Field upgradeable firmware.
§ USB Programming.
IMPORTANT NOTES
Please read these important notes about the T4:
§ The T4 should be placed in an area where it is around
normal room temperature (between 60°F to 90°F). If the
temperature is too hot, the display appears dim. If the
temperature is too cold, the display appears dark and may
respond slowly.
§ Avoid installing the T4 in a location where it can come in
contact with direct sunlight.
§ Do not use sharp objects on the touchscreen. It is designed to
operate with a touch of your finger.
§ Do not let the T4 get wet. It should not be handled with wet
hands or placed in an area where it could get wet.
§ Do not subject the T4 to smoke, dust, or vibrations. The
display may be damaged from excessive shock or vibration.
§ Only use the power supply that is specified for the T4 . Using
the wrong type of power supply may result in damage.
§ Do not disassemble the unit. Service of the T4 should be
performed by authorized personnel only.
Loading...
