RCG12C - GARAGE & GATE
REMOTE PROGRAMMING
The following procedure is for programming a RCG12C remote to your gate motor:
1 2
Identify your gate motor.
5
Press the orange ‘SET’ button
once, the display should show
the above message and the
unit will start beeping.
RCG12C
3 4
To remove the cover locate
the two cover screw, one
located on each side, and
unscrew them.
6
3UHVVDQGUHOHDVHWKH¿UVW
button on your new remote
once.
All information contained on this sheet is the property of Remote King PTY LTD. Unauthorised use or reproduction is prohibited.
Lift off the cover to reveal the
receiver board and digital
display.
7
The display will show the
following message and the unit
will start beeping faster.
Press the blue ‘NEXT’ button
once till the display shows
‘Code Transmitter’.
8
Press and release the same
button on your new remote
again.
Continued
27B
RCG12C - GARAGE & GATE
REMOTE PROGRAMMING
The following procedure is for programming a RCG12C remote to your gate motor:
9 2
The display will now show the
above message. Press the
‘SET’ button once.
RCG12C
The display will show the
message ‘Transmitter Stored!’. This
means your new remote was
successfully programmed. Replace
cover and test at the motor to
FRQ¿UP
All information contained on this sheet is the property of Remote King PTY LTD. Unauthorised use or reproduction is prohibited.
27B
RCG12C - GARAGE
REMOTE PROGRAMMING
The following procedure is for programming a RCG12C remote to your garage door:
1 2
Identify your roller door motor.
If necessary remove the light
cover to reveal the Control
Panel.
4 5
Release the button for 2
seconds.
RCG12C
1
Or
Identify your sectional door
motor. On the motor locate
the Control Panel.
Press and hold the ‘Door
Code’ button on the reciev
er board. Continue holding
through steps 3, 4 & 5.
6
Press and hold the same
button again for 2 seconds.
All information contained on this sheet is the property of Remote King PTY LTD. Unauthorised use or reproduction is prohibited.
Release the ‘Door Code’
button. Your new remote is
now programmed.
3
Press and hold a transmitter
button on your new
remote for 2 seconds.
27B
