Remote Automation Solutions Guide: OpenEnterprise Printer Control Reference Guide Manuals & Guides

Reference Guide

D301523X412
APRIL 2012

OpenEnterprise Printer Control
Reference Guide (V2.83)

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D301523X412
APRIL 2012

Printer Control

Contents

1 Printer Component..................................................................................................................1

1.1 The Print Properties Page...................................................................................................1

1.2 Header or Footer Selection List ..........................................................................................1

1.3 Change Print Color..............................................................................................................2

1.4 Header or Footer Text Box .................................................................................................2

2 Index .........................................................................................................................................3

- i -

Reference Guide

D301523X412
APRIL 2012

Printer Control

1 Printer Component

1.1 The Print Properties Page

The Print Properties page is common to five of the OpenEnterprise Viewers. It enables you to
configure Headers and Footers and Foreground/Background colours that will be used when the View
is printed using the Print context menu from the View component within the OEDesktop. Note that
the Print context menu is not available for the OEGraphics View. To print OEGraphics displays from
the OEDesktop it is recommended to use the File->Print menu option from the OEDesktop's menu
bar.

1.2 Header or Footer Selection List

This list displays the possible options for printing in any Header or Footer position. When an option is
selected it is copied into the selected Header/Footer text field.

- 1 -

Reference Guide

D301523X412
APRIL 2012

1.3 Change Print Color

Default Text and Background colors for printing
are Black text and White background, but these
may changed. The "Use this
background/foreground color" boxes must be
checked. Then when the adjacent color boxes
are double clicked the the color selection box is
displayed for selection of a new color.

Printer Control

1.4 Header or Footer Text Box

These text boxes represent the positional placement of the Header and Footer when the View is
printed. Place the cursor in the desired box and make a selection from the Header or Footer selection
list.

The selected option will be pasted into the Header or Footer field selected from this dialog. It will
appear on the printed page in the position stated above the field (i.e Center Header etc.).

- 2 -

Reference Guide

D301523X412
APRIL 2012

2 Index

1

C

Change Print Color............................................. 4

F

Footer Selection List .......................................... 3

Printer Control

Footer Text Box ..................................................4

H

Header............................................................3, 4

- 3 -
