1 Local Signal Maintenance Tool
The Local Signal Maintenance Tool enables the user to create, modify and delete local signals. Local
signals can be created singly or can be created as a series. Local sign als are used typically to store
the results of calculations or to trigger alarms.
Local signals are created in the following tables:-
• LocalRealAnalog_Table
• LocalIntegerAnalog_Table
• LocalDigital_Table
• LocalStringSignal_Table
• LocalTimeSignal_Table
• LocalMultiDigital2_Table
• LocalMultiDigital3_Table
• LocalMultiDigital4_Table
Because of the object oriented features of the OpenEnterprise database they will also automatically
become objects in the RealAnalog, IntegerAnalog, Digital, StringSignal, Time and MultiDigital2
tables, from which the Local tables are derived.
1.1 Command Line Arguments
When launched, the following parameters supplied to the 'COMMANDLINE' value on the
'OpenEnterprise\Tasks\OEToolBox\Editors\Local Signals' key in the Settings Editor will be supported.
–s%Database% -u%User% -p%Password% [-x]
Where:
Database is the data service of the database e.g. “rtrdb1”
User and Password are the credentials of the currently logged-on user.
x is a request to perform an export (all) and close.
1.2 Main Interface
The main interface of the 'Local Signal Maintenance Tool' enables the user to view, create, modify,
copy and delete local signals.
- 1 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.2.1 Menu Bar
The menu bar has an option to export the current local signal configuration from the OpenEnterprise
database to an SQL script file.
1.2.1.1 File
The 'File' m
1.2.1.1.1 Export
This optio
database to an SQL script file. This can be used at any time to restore the current local signal
configuration to the OpenEnterprise database.
enu has an option to export the current local signal configuration to an SQL script file.
n allows the user to save all local signal configuration currently in the OpenEnterprise
- 2 -
Reference Guide
D301655X412
April 2012
1.2.1.1.1.1 The Export File Dialog
The dialo
default OpenEnterprise Custom directory. This default directory can be changed using the
View>Options menu from the Toolbox. The suggested name of the file will be
'custom_localsignals.sql'.
The name of the file can be changed. If you do this, you should leave the '.sql' extension, which marks
it as an SQL script file. The directory can also be changed by using the [Browse...] button to search
for a new directory.
g opens with a fully qualified path-filename already in the 'File Name' field. It points to the
Local Signal Maintenance Tool
When [OK] is selected, OpenEnterprise will write the current local signal configuration from the
OpenEnterprise database to the file. A message will inform you that the file has been exported
successfully.
1.2.1.1.1.2 Restoring Local Signal Configuration
You can u
the following:
se the export file created with this operation to restore local signal configuration by doing
1. Open the SQL Client (Start>Programs>OpenEnterprise>SQL Client)
2. Type into the SQL Client the following SQL command on one line:
include 'C:\Documents and Settings\All
Users\Documents\Bristol\OpenEnterprise\Custom\custom_localsignals.sql'
;
- where the path and file name refer to the original .SQL file created by the Export operation.
1.2.2 Search Critieria
This section of the dialog contains controls to enable the user to apply filters when the [Find Signals]
button is selected.
1.2.3 Type
Select the signal type from this drop-down list. When viewing signals from the main interface, the
selection will be used to filter the signal list when the [Find Signals] button is selected.
- 3 -
Reference Guide
D301655X412
April 2012
When used from the 'Add Signal' dialog, the selection will determine the type of signal that will be
created.
Local Signal Maintenance Tool
1.2.4 Name
The string typed here will be applied as a filter on the signal query when the [Find Signals] button is
selected. Wildcard characters can be used.
The (*) or (%) wildcard characters can be used interchangeably. The wildcard character forces all text
before the wildcard to be ignored if it appears at the beginning of the string, or all text after it if it
appears at the end. Wildcard characters cannot be used in the middle of the string.
1.2.5 Description
A string that provides a fuller description of the signal.
1.2.5.1 Use in Main Interface
Filters the
wildcard characters can be used interchangeably. The wildcard character forces all text before the
wildcard to be ignored if it appears at the beginning of the string, or all text after it if it appears at the
end. Wildcard characters cannot be used in the middle of the string.
1.2.5.2 Use when adding signals
Whe
entered here.
1.2.5.3 Use when modifying or copying signals
Enable
signal query on description attribute when used from the main interface. The (*) or (%)
n used from the 'Add Signal' dialog, a fuller description of the signal that will be created can be
s the user to change the description for the signal
1.2.6 Base
The Base part of the signal name. The string typed here will be applied as a filter on the signal query
when the [Find Signals] button is selected. Wildcard characters can be used.
The (*) or (%) wildcard characters can be used interchangeably. The wildcard character forces all text
before the wildcard to be ignored if it appears at the beginning of the string, or all text after it if it
appears at the end. Wildcard characters cannot be used in the middle of the string.
1.2.6.1 When adding a signal...
n adding a signal, the signal name will be parsed to extract the Base assuming the following
Whe
format:-
<DEVICE NAME>:<BASE>.<EXTENSION>.<ATTRIBUTE>
The Base will be the part of the name that comes after the colon (if a 'LOCAL' device name is used to
prefix the signal name) and before the first period in the name.
- 4 -
Reference Guide
D301655X412
April 2012
If no period appears in the name, the Base will be all text after the colon (if used), all text if no colon
and no period is used.
Local Signal Maintenance Tool
1.2.7 Extension
The Extension part of the signal name. The string typed here will be applied as a filter on the signal
query when the [Find Signals] button is selected. Wildcard characters can be used.
The (*) or (%) wildcard characters can be used interchangeably. The wildcard character forces all text
before the wildcard to be ignored if it appears at the beginning of the string, or all text after it if it
appears at the end. Wildcard characters cannot be used in the middle of the string.
1.2.7.1 When adding a signal...
n adding a signal, the signal name will be parsed to extract the Extension assuming the following
Whe
format:-
<DEVICE NAME>:<BASE>.<EXTENSION>.<ATTRIBUTE>
The Extension will be the part of the name that comes after the first period in the name. If no period
appears in the name, the signal will have no Extension when created.
1.2.8 Attribute
The Attribute part of the signal name. This will be the part of the name that comes after the second
period in the name. The string typed here will be applied as a filter on the signal query when the [Find
Signals] button is selected. Wildcard characters can be used.
The (*) or (%) wildcard characters can be used interchangeably. The wildcard character forces all text
before the wildcard to be ignored if it appears at the beginning of the string, or all text after it if it
appears at the end. Wildcard characters cannot be used in the middle of the string.
1.2.8.1 When adding a signal...
n adding a signal, the signal name will be parsed to extract the Base assuming the following
Whe
format:-
<DEVICE NAME>:<BASE>.<EXTENSION>.<ATTRIBUTE>
The Attribute will be the part of the name that comes after the second period in the name. If no
second period appears in the name, the signal will have no Attribute when created.
1.2.9 Match Case
When checked, the search will enforce case matching indicated in the filter fields.
1.2.10 Find Signals
Finds all signals matching the search criteria found in the 'Search Criteria' section. All signasl found
will be listed in the Signal List.
For instance if 'EP%' was entered into the name field, this would find the following signals if they
existed.
- 5 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.2.11 Details
Selecting the [...] button next to the signals opens the Properties dialog for that signal, which enables
all non primary attributes to be modified.
1.2.12 Signal List
Lists all signals found using the criteria in the 'Search Criteria' section when the [Find Signals] button
is selected.
Clicking on the [...] button to the left of a signal opens the 'Signal Properties' dialog, which enables the
user to edit most attributes of the signal.
1.2.13 Add..
Opens the 'Add Signal' dialog, which enables the user to add new local signals.
1.2.14 Modify...
Opens the 'Modify Signal' dialog which enables the user to modify a selected signal.
1.2.15 Delete
Deletes the selected signal. The user will be prompted to confirm the deletion before it takes place.
- 6 -
Reference Guide
D301655X412
April 2012
On selection of the [Yes] button, the signal will be deleted. If the [No] button is selected, the deletion
will be aborted.
Local Signal Maintenance Tool
1.2.16 Copy...
The 'Copy Signal' dialog will open, enabling the user to create another signal using the selected signal
as a template.
1.3 Add Signal
This dialog enables the user to create a new local signal.
1.3.1 Name
The name must be changed when copying a signal because the name has to be unique. Until the
user modifies the signal name, the [Apply] and [OK] buttons are disabled. When the name is modified,
these buttons become enabled.
- 7 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.3.2 Type
Select the signal type from this drop-down list. When viewing signals from the main interface, the
selection will be used to filter the signal list when the [Find Signals] button is selected.
When used from the 'Add Signal' dialog, the selection will determine the type of signal that will be
created.
1.3.3 Description
A string that provides a fuller description of the signal.
1.3.3.1 Use in Main Interface
Filters the
wildcard characters can be used interchangeably. The wildcard character forces all text before the
wildcard to be ignored if it appears at the beginning of the string, or all text after it if it appears at the
end. Wildcard characters cannot be used in the middle of the string.
1.3.3.2 Use when adding signals
Whe
entered here.
1.3.3.3 Use when modifying or copying signals
Enable
signal query on description attribute when used from the main interface. The (*) or (%)
n used from the 'Add Signal' dialog, a fuller description of the signal that will be created can be
s the user to change the description for the signal
1.3.4 Add Range
Check this box if you want to add a range of local signals numbered serially, rather than a single
signal. When modifying a signal the 'Add Range' controls are disabled. See the 'Using Format' topic
for information on different serial numbering systems available.
1.3.5 From
The starting number for a range of signals that will be created. This control is disabled when
modifying a signal.
1.3.6 To
The end number for a range of signals that will be created. This control is disabled when mod i fying a
signal.
1.3.7 Using format
A drop-down list that determines the format for the serial number part of a range of signals. This
control is only available when adding signals.
- 8 -
Reference Guide
D301655X412
April 2012
1.3.7.1 Range Format (.001)
Local Signal Maintenance Tool
If this option is sel
with a name of 'MYANALOG' with a range from 1 to 999, starting at 1 would be 'MYANALOG.001'.
The last signal in the range would be 'MYANALOG.999'. If the digits required for the range exceeds 3
(e.g. 1000), the adjustment will be made automatically.
1.3.7.2 Range Format (.01)
With this opti
signal with a name of 'MYANALOG' with a range from 1 to 99, starting at 1 would be
'MYANALOG.01'. The last signal in the range would be 'MYANALOG.99'. If the number of digits
required for the range exceeds 2 (e.g. 100), the adjustment will be made automatically.
1.3.7.3 Range Format (.1)
With this opti
with a name of 'MYANALOG' with a range from 1 to 100, starting at 1 would be 'MYANALOG.1'. The
last signal in the range would be 'MYANALOG.100'.
ected, the range of signals will be created with two leading zeros, so the first signal
on selected, the range of signals will be created with a single leading zero, so the first
on selected, the range of signals will be created with no leading zeros, so the first signal
1.3.8 Access area
The Access Area for the signal. This can be changed when modifying the signal.
1.3.9 Plant area
The Plant Area for the signal. This can be changed when modifying the signal.
1.3.10 Manual inhibit
When checked, the signal's 'ManualInhibit' attribute is set to True.
1.3.11 Alarm inhibit
When checked, the signal's 'AlarmInhibit' attribute is set to True.
1.3.12 Value
The controls in this section vary depending on the type of signal selected. The options below
represent the signal types that can be selected.
• Analog
• Digital
- 9 -
Reference Guide
D301655X412
April 2012
• Multidigital
• String
Local Signal Maintenance Tool
• Time
1.3.12.1 Analog Value
Both Analog
high and low limits.
1.3.12.1.1 Default value
The default value of the si
and Integer type signals have this same section for defining the default value, units and
gnal. This value can be modified at any time.
1.3.12.1.2 Units
The de
1.3.12.1.3 High limit
The high
signal's value beyond this.
signated units of the signal. This value can be modified at any time.
est possible value of the signal. OpenEnterprise will not allow any client to increase the
- 10 -
Reference Guide
D301655X412
April 2012
The 'High Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
1.3.12.1.4 Low limit
Local Signal Maintenance Tool
The lowest p
signal's value below this.
The 'Low Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
1.3.12.2 Digital Value
The value se
1.3.12.2.1 Digital Default
One of the two values in th
1.3.12.2.2 On Text
ossible value of the signal. OpenEnterprise will not allow any client to decrease the
ction of the Add Signal and Modify Signal dialog has these controls.
e drop-down list must be selected for the default value of a Digital signal.
Type the text
1.3.12.2.3 Off Text
Type the text
1.3.12.3 Multidigital Value
Multidigital si
dialog.
1.3.12.3.1 Default
The default value for a Mul
that can be used in displays to indicate the ON condition here.
that can be used in displays to indicate the OFF condition here.
gnal types have these controls in the Value section of the Add Signal and Modify Signal
tidigital signal type can have the following values:-
- 11 -
Reference Guide
D301655X412
April 2012
• Multidigital2 - an integer from 1 to 4
• Multidigital3 - an integer from 1 to 8
• Multidigital4 - an integer from 1 to 16
1.3.12.3.2 State Text
Local Signal Maintenance Tool
This is th
1.3.12.4 String Value
String sig
1.3.12.4.1 Default
The default value of the string sig
1.3.12.5 Time Value
Time sig
e text that can be used to describe the default for the current state of the multidigital signal.
nals only have one default control. This is the signal value, which is a string.
nals have a default combined date/time field.
nal is entered here as text.
1.3.12.5.1 Time Value Default
The default value for a Tim
the time directly in..
1.3.12.5.1.1 Calendar
A calend
calendar.
ar control appears when the default field is selected. The default date is selected from the
e signal can be entered using a calendar control for the date, and by typing
- 12 -
Reference Guide
D301655X412
April 2012
1.3.12.5.1.2 Direct Entry
The default time can b
e entered directly into the control.
Local Signal Maintenance Tool
1.3.13 Apply and OK buttons
There is a small difference in the operation of these buttons. They both initiate the process of
inserting, copying or modifying a signal depending on the context. However, if the [Apply] button is
selected, the dialog remains open, whereas if the [OK] button is selected, the currently open dialog is
closed also.
1.3.13.1 Modifying
The [Apply] and [OK] buttons are only e
dialog.
1.3.13.2 Copying
n the name has been changed the [Apply] and [OK] buttons become enabled, indicating that the
Whe
user can select them to initiate the copying of the signal.
When the user is copying a signal, if the new name that they provided in the 'Name' field is found to
be already in the database, the user is warned of this and the copy is aborted.
nabled after a change has been made on the 'Modify Signal'
1.4 Signal Properties
This dialog enables the user to view and modify most attributes of the selected signal.
- 13 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.4.1 Attribute name
All attributes of the selected signal are listed here.
1.4.2 Attribute value
The value of each attribute. All attribute values except for Name, Devicename and Regionname can
be changed.
Attributes value fields are sensitive to the data type.
1.4.2.1 Digital attribute values
These displa
y a TRUE/FALSE list when selected. The user can select the desired option.
- 14 -
Reference Guide
D301655X412
April 2012
1.4.2.2 Date/Time attribute values
Local Signal Maintenance Tool
Display a cal
1.4.2.3 Realtime, Integer and String attribute values
These are just text control
endar when selected. The user can select the desired date and time.
s into which the desired value or string is typed.
1.4.3 Scroll bar
The user can use the scroll bar to see any extra attributes.
1.4.4 Re-size dialog
The dialog can be re-sized by clicking and dragging with the mouse on the bottom left corner.
- 15 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.5 Modify Signal
Enables the user to modify the selected signal's value or most of it's configuration details.
1.5.1 Name
When modifying a signal, the Name attribute cannot be changed. The control is disabled.
1.5.2 Type
When modifying or copying a signal, the Type cannot be changed. The control is disabled.
1.5.3 Description
A string that provides a fuller description of the signal.
1.5.3.1 Use in Main Interface
Filters the
wildcard characters can be used interchangeably. The wildcard character forces all text before the
wildcard to be ignored if it appears at the beginning of the string, or all text after it if it appears at the
end. Wildcard characters cannot be used in the middle of the string.
signal query on description attribute when used from the main interface. The (*) or (%)
- 16 -
Reference Guide
D301655X412
April 2012
1.5.3.2 Use when adding signals
n used from the 'Add Signal' dialog, a fuller description of the signal that will be created can be
Whe
entered here.
1.5.3.3 Use when modifying or copying signals
Local Signal Maintenance Tool
Enable
s the user to change the description for the signal
1.5.4 Add Range
When modifying a signal, all signal Range controls are disabled.
1.5.5 Access area
The Access Area for the signal. This can be changed when modifying the signal.
1.5.6 Plant area
The Plant Area for the signal. This can be changed when modifying the signal.
1.5.7 Manual inhibit
When checked, the signal's 'ManualInhibit' attribute is set to True.
1.5.8 Alarm inhibit
When checked, the signal's 'AlarmInhibit' attribute is set to True.
1.5.9 Value
The controls in this section vary depending on the type of signal selected. The options below
represent the signal types that can be selected.
• Analog
• Digital
• Multidigital
- 17 -
Reference Guide
D301655X412
April 2012
• String
• Time
Local Signal Maintenance Tool
1.5.9.1 Analog Value
Both Analog
high and low limits.
1.5.9.1.1 Default value
The default value of the si
1.5.9.1.2 Units
The de
1.5.9.1.3 High limit
The high
signal's value beyond this.
and Integer type signals have this same section for defining the default value, units and
gnal. This value can be modified at any time.
signated units of the signal. This value can be modified at any time.
est possible value of the signal. OpenEnterprise will not allow any client to increase the
The 'High Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
1.5.9.1.4 Low limit
The lowest p
signal's value below this.
The 'Low Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
ossible value of the signal. OpenEnterprise will not allow any client to decrease the
- 18 -
Reference Guide
D301655X412
April 2012
1.5.9.2 Digital Value
Local Signal Maintenance Tool
The value se
1.5.9.2.1 Digital Default
One of the two values in th
1.5.9.2.2 On Text
Type the text
1.5.9.2.3 Off Text
ction of the Add Signal and Modify Signal dialog has these controls.
e drop-down list must be selected for the default value of a Digital signal.
that can be used in displays to indicate the ON condition here.
Type the text
1.5.9.3 Multidigital Value
Multidigital si
dialog.
1.5.9.3.1 Default
The default value for a Mul
• Multidigital2 - an integer from 1 to 4
• Multidigital3 - an integer from 1 to 8
• Multidigital4 - an integer from 1 to 16
that can be used in displays to indicate the OFF condition here.
gnal types have these controls in the Value section of the Add Signal and Modify Signal
tidigital signal type can have the following values:-
- 19 -
Reference Guide
D301655X412
April 2012
1.5.9.3.2 State Text
Local Signal Maintenance Tool
This is th
1.5.9.4 String Value
String sig
1.5.9.4.1 Default
The default value of the string sig
1.5.9.5 Time Value
Time sig
e text that can be used to describe the default for the current state of the multidigital signal.
nals only have one default control. This is the signal value, which is a string.
nals have a default combined date/time field.
nal is entered here as text.
1.5.9.5.1 Time Value Default
The default value for a Tim
the time directly in..
1.5.9.5.1.1 Calendar
A calend
calendar.
1.5.9.5.1.2 Direct Entry
The default time can b
ar control appears when the default field is selected. The default date is selected from the
e signal can be entered using a calendar control for the date, and by typing
e entered directly into the control.
- 20 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.6 Copy Signal
This dialog enables the user to create a new signal or range of signals from a signal which is selected
from the Signal List. The user must change the name so that the new signal name is unique, but all
other attributes can be re-used.
1.6.1 Name
The name must be changed when copying a signal because the name has to be unique. Until the
user modifies the signal name, the [Apply] and [OK] buttons are disabled. When the name is modified,
these buttons become enabled.
1.6.2 Type
When modifying or copying a signal, the Type cannot be changed. The control is disabled.
- 21 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
1.6.3 Description
A string that provides a fuller description of the signal.
1.6.3.1 Use in Main Interface
Filters the
wildcard characters can be used interchangeably. The wildcard character forces all text before the
wildcard to be ignored if it appears at the beginning of the string, or all text after it if it appears at the
end. Wildcard characters cannot be used in the middle of the string.
1.6.3.2 Use when adding signals
Whe
entered here.
1.6.3.3 Use when modifying or copying signals
Enable
signal query on description attribute when used from the main interface. The (*) or (%)
n used from the 'Add Signal' dialog, a fuller description of the signal that will be created can be
s the user to change the description for the signal
1.6.4 Add Range
Check this box if you want to add a range of local signals numbered serially, rather than a single
signal. When modifying a signal the 'Add Range' controls are disabled. See the 'Using Format' topic
for information on different serial numbering systems available.
1.6.5 From
The starting number for a range of signals that will be created. This control is disabled when
modifying a signal.
1.6.6 To
The end number for a range of signals that will be created. This control is disabled when mod i fying a
signal.
1.6.7 Using format
A drop-down list that determines the format for the serial number part of a range of signals. This
control is only available when adding signals.
1.6.7.1 Range Format (.001)
If this option is sel
with a name of 'MYANALOG' with a range from 1 to 999, starting at 1 would be 'MYANALOG.001'.
The last signal in the range would be 'MYANALOG.999'. If the digits required for the range exceeds 3
(e.g. 1000), the adjustment will be made automatically.
1.6.7.2 Range Format (.01)
With this opti
signal with a name of 'MYANALOG' with a range from 1 to 99, starting at 1 would be
'MYANALOG.01'. The last signal in the range would be 'MYANALOG.99'. If the number of digits
required for the range exceeds 2 (e.g. 100), the adjustment will be made automatically.
ected, the range of signals will be created with two leading zeros, so the first signal
on selected, the range of signals will be created with a single leading zero, so the first
- 22 -
Reference Guide
D301655X412
April 2012
1.6.7.3 Range Format (.1)
Local Signal Maintenance Tool
With this opti
with a name of 'MYANALOG' with a range from 1 to 100, starting at 1 would be 'MYANALOG.1'. The
last signal in the range would be 'MYANALOG.100'.
on selected, the range of signals will be created with no leading zeros, so the first signal
1.6.8 Manual inhibit
When checked, the signal's 'ManualInhibit' attribute is set to True.
1.6.9 Alarm inhibit
When checked, the signal's 'AlarmInhibit' attribute is set to True.
1.6.10 Value
The controls in this section vary depending on the type of signal selected. The options below
represent the signal types that can be selected.
• Analog
• Digital
• Multidigital
• String
• Time
- 23 -
Reference Guide
D301655X412
April 2012
1.6.10.1 Analog Value
Local Signal Maintenance Tool
Both Analog
high and low limits.
1.6.10.1.1 Default value
The default value of the si
1.6.10.1.2 Units
The de
1.6.10.1.3 High limit
The high
signal's value beyond this.
The 'High Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
1.6.10.1.4 Low limit
and Integer type signals have this same section for defining the default value, units and
gnal. This value can be modified at any time.
signated units of the signal. This value can be modified at any time.
est possible value of the signal. OpenEnterprise will not allow any client to increase the
The lowest p
signal's value below this.
The 'Low Limit' value can be modified at any time by selecting the signal and using the [Modify]
button or by using the Properties dialog for the signal.
1.6.10.2 Digital Value
The value se
1.6.10.2.1 Digital Default
One of the two values in th
ossible value of the signal. OpenEnterprise will not allow any client to decrease the
ction of the Add Signal and Modify Signal dialog has these controls.
e drop-down list must be selected for the default value of a Digital signal.
- 24 -
Reference Guide
D301655X412
April 2012
1.6.10.2.2 On Text
Local Signal Maintenance Tool
Type the text
1.6.10.2.3 Off Text
Type the text
1.6.10.3 Multidigital Value
Multidigital si
dialog.
1.6.10.3.1 Default
The default value for a Mul
that can be used in displays to indicate the ON condition here.
that can be used in displays to indicate the OFF condition here.
gnal types have these controls in the Value section of the Add Signal and Modify Signal
tidigital signal type can have the following values:-
• Multidigital2 - an integer from 1 to 4
• Multidigital3 - an integer from 1 to 8
• Multidigital4 - an integer from 1 to 16
1.6.10.3.2 State Text
This is th
1.6.10.4 String Value
String sig
e text that can be used to describe the default for the current state of the multidigital signal.
nals only have one default control. This is the signal value, which is a string.
- 25 -
Reference Guide
D301655X412
April 2012
1.6.10.4.1 Default
Local Signal Maintenance Tool
The default value of the string sig
1.6.10.5 Time Value
Time sig
1.6.10.5.1 Time Value Default
The default value for a Tim
the time directly in..
1.6.10.5.1.1 Calendar
A calend
calendar.
nals have a default combined date/time field.
ar control appears when the default field is selected. The default date is selected from the
nal is entered here as text.
e signal can be entered using a calendar control for the date, and by typing
1.6.10.5.1.2 Direct Entry
The default time can b
e entered directly into the control.
1.6.11 Apply and OK buttons
There is a small difference in the operation of these buttons. They both initiate the process of
inserting, copying or modifying a signal depending on the context. However, if the [Apply] button is
selected, the dialog remains open, whereas if the [OK] button is selected, the currently open dialog is
closed also.
- 26 -
Reference Guide
D301655X412
April 2012
1.6.11.1 Modifying
Local Signal Maintenance Tool
The [Apply] and [OK] buttons are only e
dialog.
1.6.11.2 Copying
n the name has been changed the [Apply] and [OK] buttons become enabled, indicating that the
Whe
user can select them to initiate the copying of the signal.
When the user is copying a signal, if the new name that they provided in the 'Name' field is found to
be already in the database, the user is warned of this and the copy is aborted.
nabled after a change has been made on the 'Modify Signal'
- 27 -
Reference Guide
D301655X412
April 2012
Local Signal Maintenance Tool
2 Index
1
A
Access area ............................................... 12, 20
Add Range ...........................................11, 20, 25
Add Signal........................................................ 10
Alarm inhibit ......................................... 12, 20, 26
Analog Value........................................13, 21, 27
Apply .......................................................... 16, 29
Attribute.............................................................. 8
Attribute name.................................................. 17
Attribute value .................................................. 17
B
Base................................................................... 7
C
Command Line Arguments................................ 4
Copy Signal...................................................... 24
D
Default................................14, 15, 22, 23, 27, 28
Default value........................................13, 21, 27
Delete................................................................. 9
Description .......................................7, 11, 19, 24
Details ................................................................ 9
Digital Value......................................... 14, 21, 27
E
Extension............................................................ 8
F
Find Signals ....................................................... 8
H
High limit............................................... 13, 21, 27
L
Low limit ............................................... 14, 21, 27
M
Main Interface .................................................... 4
Manual inhibit........................................12, 20, 26
Match Case.........................................................8
Modify Signal ....................................................18
Multidigital Value...................................14, 22, 28
N
Name ................................................7, 10, 19, 24
O
Off Text.................................................14, 22, 28
OK buttons..................................................16, 29
Overview.............................................................4
P
Plant area....................................................12, 20
R
Resize dialog ....................................................18
S
Scroll bar...........................................................18
Search Critieria...................................................6
Signal List ...........................................................9
Signal Properties...............................................16
State Text..............................................15, 22, 28
String.....................................................15, 23, 28
T
Text.......................................................14, 22, 27
Time Value............................................15, 23, 29
Time Value Default ...............................15, 23, 29
Type..................................................6, 11, 19, 24
U
Units......................................................13, 21, 27
Using format................................................11, 25
V
Value.................................. 12, 15, 20, 23, 26, 28
- 28 -
Reference Guide
D301655X412
April 2012
DISCLAIMER
Bristol, Inc., Bristol Babcock Ltd, Bristol Canada, BBI SA de CV and the Flow Computer Division , are wholly owned subsidiaries of Emerson Electric Co. doing business
as Remote Automation Solutions (“RAS”), a division of Emerson Process Management. ROC, FloBoss, ROCLINK, Bristol, Bristol Babcock, ControlWave, TeleFlow and
Helicoid are trademarks of RAS. AMS, PlantWeb and the PlantWeb logo are marks of Emerson Electric Co. The Emerson logo is a trademark and service mark of the
Emerson Electric Co. All other marks are property of their respective owners.
The contents of this publication are presented for informational purposes only. While every effort has been made to ensure informational accuracy, they are not to be
construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. RAS reserves the right to
modify or improve the designs or specifications of such products at any time without notice. All sales are governed by RAS’ terms and conditions which are available upon
request. RAS does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, us e and maint enance of any RAS
product remains solely with the purchaser and end-user.
Engineered and supported by:
Remote Automation Solutions,
Blackpole Road, Worcester, WR3 8YB, UK
Registered office: Meridian East, Leicester, LE19 1UX
Registered in England and Wales, Registration No. 00671801
VAT Reg No. GB 705 353 652
Emerson Process Management
Remote Automation Solutions
1100 Buckingham St
Watertown, CT 06795
T 1 (860) 945 2200
F 1 (860) 945 2278
www.EmersonProcess.com/Remote
binfo@EmersonProcess.com
© 2001-2012 Remote Automation Solutions, division of Emerson Process Management. All rights
reserved.
Emerson Process Management
Remote Automation Solutions
Blackpole Road
Worcester, WR3 8YB
T 44 (0) 1905 856848
F 44 (0) 1905 856930
www.EmersonProcess.com/Remote
oedsupport@EmersonProcess.com
Loading...
