1 Allen-Bradley RDI

1.1 Overview

The OpenEnterprise Allen-Bradley RDI (filename: abrdi.exe), has been designed to communicate with
Allen-Bradley PLC-5s over any of the interface cards and protocols supported by RSLinx ®.

1.2 Overview

The OpenEnterprise Allen-Bradley RDI (filename: abrdi.exe), has been designed to communicate with
Allen-Bradley PLC-5s over any of the interface cards and protocols supported by RSLinx ®.

1.3 System Requirements

The following environment is required to run the Allen-Bradley RDI.

1.3.1 Rockwell Software RSLinx ®

As a minimum the OEM type must be installed. See the RSLinx ® Driver Configuration topic.

1.3.2 Database Configuration

• If the Database Project Builder (DPB) is used to build the database select the Allen-Bradley
Device Driver.

• If the DPB is not being used, then you need to use the SQL Client to firstly 'include' the
ab_tables.sql script, found in the OpenEnterprise Database directory into the OpenEnterprise
Database. This script contains the Allen-Bradley RDI schema.

• Then you need to make sure to add a reference to the ab.cl file at the correct place in the
poly.cfg file.

• Finally, you need to include the ab_insert.sql script. This will add the Allen-Bradley Driver to
the database.

1.3.3 Allen-Bradley RDI application (abrdi.exe)

This is included in the OpenEnterprise Server installation, along with the ociapi.dll, which is also
required in order for it to function correctly.

1.3.4 Services File Entry

The OpenEnterprise installation should have written an entry for the 'abrdi' to the Services file in
winnt\system32\drivers\etc. This is the TCP/IP service name to which OE attempts to
connect.

1.3.5 Session Manager Configuration

The Allen-Bradley RDI is an application which should be configured to run as part of an
OpenEnterprise Session on the Master Server under the control of the Session Manager. Refer to
Session Manager Help for further details.

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 4

Allen-Bradley RDI

1.4 RSLinx Driver Configuration

To configure a driver, run the Rockwell Software RSLinx ® program and select Communications >
Configure Drivers.

Select a driver from the available driver list and complete the information required in the displayed
dialog box. All drivers will require a name that will be the same as that name entered in the
abNetwork_Table.

The dialog box then varies depending on the driver selected. For instance, for the Ethernet driver the
dialog will prompt for PLC TCP/IP address mapping to Driver station numbers.

1.5 Database Configuration

The following tables are added by the default SQL script ab_tables.sql. This is included when the
Allen-Bradley option is chosen on the Device Drivers page when running the Database Project Builder
wizard, or it can be included from the SQL Client, if building the database manually. The following
gives a description of the tables and their use.

1.5.1 abDriver_Table

There is a single driver table entry added by the ABDef.sql script as a part of the initial OE
Database build process. This SQL script inserts the mandatory OpenEnterprise Database
requirement for using the Allen-Bradley RDI. Other AB table entries are project specific.

The following columns must contain valid data:

drivername - table key.

address - TCP/IP host and service name that the GDI will attempt to connect with. Set to

'abrdi' if the driver is running locally. Make sure the Services file in winnt\system32\drivers\etc
contains an entry for 'abrdi'.

retryperiod - This determines how frequently the GDI will attempt to connect with the RDI.

Example:

insert into ABDriver_Table(drivername,address,retryperiod)

values ('ABRDI','abrdi',seconds(10));

commit;

1.5.2 ABNetwork_Table

There will be a table entry for each configured RSLinx ® Driver. The following columns must

contain valid data:

networkname - table key.

drivername - ABDriver_Table key.

driver_id - unique number for RSLinx ® Driver between 0 and 15.

driver_name - name for RSLinx ® Driver assigned during configuration.

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 5

Example:

insert into ABNetwork_Table
(networkname,drivername,driver_id,driver_name)values
('TEST1','ABRDI',1,'AB_ETH-1');

1.5.3 ABdevice_Table

There will be a table entry for each PLC or redundant pair. The following columns must contain
valid data:

devicename - table key.

networkname - ABNetwork_table key.

deviceaddress - the communications path that will be used by the RSLinx ® to access the

PLC (see topic entitled Allen-Bradley PLC Communication Paths).

redundant - Single PLC (false) or redundant pair (true).

b_addr_info(required if redundant pair) - path that will be used by the RSLinx ® to access the

backup PLC (see Appendix 1 - Allen-Bradley PLC Communication Paths).

Allen-Bradley RDI

main_ind(required if redundant pair) - PLC address for main PLC indicator signal. Set to 1 if

main, 0 if standby.

The following columns are optional:-

Heartbeat (optional) - PLC address of the heartbeat signal.

hb_rate (optional) - frequency in seconds for checking heartbeat .

Example:

insert into
abDevice_Table(devicename,networkname,deviceaddress,redundant,b_addr_i
nfo,main_ind)

values ('AB1','TEST1','AB:LOCAL,1',true,'AB:LOCAL,2','N31:0/0');

1.5.4 dvi_schedule

There will be a table entry for each poll schedule. A single schedule is not restricted to a single
device (PLC) but can be implemented on one or more devices and networks. The following
columns must contain valid data:

scheduleid - table key

maxinterval - polling interval -This column is a datetime type ie the value is treated as if offset

from midnight on 01-JAN-0001. Thus 10 seconds is equivalent to 00:00:10 01-JAN-0001.

Example:

insert into dvi_schedule (scheduleid,maxinterval)

values (1, SECONDS(10));

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 6

1.5.5 ABPollList_Table

There will be a table entry for each range of PLC memory to be polled on each device. The
table row will be matched with a dvi_schedule row to determine the polling interval. The
following columns must contain valid data:

name - table key.

devicename - ABDevice_Table key.

regionname - dvi_region key. Must be 'AB_file'.

datumaddress - Allen-Bradley PLC file name eg N7

scheduleid - dvi_schedule key.

start_address - start address in PLC file (defined in datumaddress) for polling.

end_address - end address in PLC file (defined in datumaddress) for polling

Example:

Allen-Bradley RDI

insert into ABpolllist_table
(name,devicename,regionname,datumaddress,scheduleid,start_address,end_
address)

values ('N7','AB1','ab_file','N7',1,0,3);

1.5.6 ABIntegerAnalog_Table

The entries in this table represent 16 bit word data items in the following PLC memory files:

o Ascii Data (A)

o BCD Data (D)

o Integer (N)

o Status (S)

The following columns must contain valid data:

name - table key.

devicename - ABDevice_Table key.

regionname - dvi_region key. Must be 'AB_iana'.

ab_file - PLC memory address

Example:

insert into ABIntegerAnalog_Table
(name,regionname,devicename,ab_file,LowLimit,HighLimit)

values ('PLCN2','ab_iana','AB1','N7:1',0,4095);

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 7

1.5.7 ABRealAnalog_Table

The entries in this table represent data items in the following PLC memory files:

o Floating-point (F)

o Integer (N)

In this table, Integer(N) data items are used to store real numbers. The conversion from PLC to
OE Database is calculated as follows:

y = mx + c

The conversion from Database to PLC is calculated as follows:

x = (y-c)/m

Where y(real) = output to database, x(integer) = input from PLC,
m(real)=span, c(real) = zero

The following columns must contain valid data:

Allen-Bradley RDI

name - table key.

devicename - abDevice_Table key.

regionname - dvi_region key. Must be 'ab_rana'.

ab_file - PLC memory address

span - (required for integer/real conversion)

zero - (required for integer/real conversion)

Example:

insert into ABrealanalog_table (name,regionname,devicename,ab_file)

values ('PLCF1','ab_rana','ab1','F8:0');

1.5.8 ABDigital_Table

The entries in this table represent data items in the following PLC memory files:

o Bit (B)

o Bit (N)

o Output(O)

o Input(I)

In this table Integer(N) data items are used to store digital data.

The following columns must contain valid data:

name - table key.

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 8

devicename - abDevice_Table key.

regionname - dvi_region key. Must be 'ab_log'.

ab_file - PLC memory address

Example:

insert into abDigital_Table (name,regionname,devicename,ab_file)

values ('PLCB1','ab_log','ab1','B3:0/0');

1.5.9 ABComplex_Table

The entries in this table represent Structured Data items in the following PLC memory files:

• Timer (T) - 6 bytes

• Counter (C) - 6 bytes

• Control(R) - 6 bytes

Allen-Bradley RDI

• SFC Status(SC) - 6 bytes

• Blk-transfer Control (BT) - 12 bytes

• Token Data (TD) - 4 bytes

• ASCII String (ST) - 84 bytes

• PID Control (PD) - 164 bytes

• Message Control (MG) - 112 bytes

The data items are transferred as a block of binary data between the OE Database and the
RDI. The size of the data block is indicated above for each complex file type. For example,
when polling a Timer data item, the RDI will read the PLC memory and send 6 bytes of data to
the OE Database. When the OE Database updates a data item it will send 6 bytes to of data to
the RDI.

The following columns must contain valid data:

name - table key.

devicename - ABDevice_Table key.

regionname - dvi_region key. Must be 'ab_complex'.

ab_file - PLC memory address

Example:

insert into ABComplex_Table (name,regionname,devicename,ab_file)

values ('PLCT1','ab_complex','ab1','T4:0');

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 9

Allen-Bradley RDI

1.6 Running the Allen-Bradley RDI

The program abrdi is a windows application. Note that the TCP/IP service name 'abrdi' to which the
program binds is hard coded in the program.

To run the Allen-Bradley RDI from the Command line, type the name of the executable file, followed
by a space, then by the name of the designated Allen-Bradley TCP/IP service: -

C:\> abrdi abrdi

When running the abrdi as part of an OpenEnterprise Session the CommandLine value for the abrdi
task will also need to contain the text 'abrdi' (without the quotes).

Error and information messages will appear in the abrdi.exe program window. The program holds a
maximum of 10,000 messages in dynamic memory. These messages will also be written into a disk
file abrdi.log. This file will be overwritten each time the program is run. Messages are also written into
the 'Allen-Bradley Driver' entry in the OE Database journaltask_table.

Control Language errors and messages will appear in the RTRTB window.

While the RDI is running, it can accommodate some OE Database Table changes. Any other changes
will be ignored. Below is a list of what can and cannot be changed in runtime.

• The single abDriver_Table entry should not be deleted.

• abNetwork_table entries can be added and deleted.

• abDevice_Table entries can be added and deleted. The heartbeat and hb_rate columns can

be modified. The redundant, main_ind and b_addr_info columns can be modified once only to
turn the device into a redundant pair.

• Signal Datums can be added or deleteted. Note that if a new datum is outside the poll range
defined in the associated abPollList_Table entry it will not be polled.

• abPollList_Table can be added or deleted.

• dvi_schedule entries cannot be added, deleted or modified.

The OpenEnterprise Allen-Bradley Configuration Tool simplifies the process of changing Allen­Bradley data within the OE Database. The user should consult the Allen-Bradley Configuration Tool
Reference Guide for further details.

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007 - Page 10

2 Index

A

Allen-Bradley RDI

Running ................................................... 8

Allen-Bradley RDI........................................ 8

O

OE Database Configuration#ABNetworkTable 2

Overview ..................................................... 1

R

RSLinx Driver Configuration........................ 2

Running

Allen-Bradley RDI .................................... 8

Running ....................................................... 8

S

System Requirements ................................. 1

Allen-Bradley RDI

Remote Automation Solutions

Website: www.EmersonProcess.com/Remote

Reference Guide

D5092
11-Dec-2007

NOTICE

Remote Automation Solutions (“RAS”), division of Emerson Process Management shall not be liable for technical or editorial errors in this manual or omissions from this
manual. RAS MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING TH E IMPLIED WARRANTIES OF MERCHANTABILITY AND F ITNESS FOR A
PARTICULAR PURPOSE W ITH RESPECT TO THIS MANUAL AND, I N NO EVENT SHALL RAS BE LIABLE FOR ANY INCID ENTAL, PUNITIVE, SPECIAL OR
CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PRODUCTION, LOSS OF PROFITS, LOSS OF REVENUE OR USE AND COSTS
INCURRED INLCUDING WITHOUT LIMITATION FOR CAPITAL, FUEL AND POW ER, AND CLAIMS OF THIRD PARTIES.

Bristol, Inc., Bristol Babcock Ltd, Bristol Canada, BBI SA de CV and the Flow Computer Division are wholly owned subsidiaries of Emerson Electric Co. doing business as
Remote Automation Solutions (“RAS”), a division of Emerson Process Management. ROC, FloBoss, ROCLINK, Bristol, Bristol Babcock, ControlWave, TeleFlow and
Helicoid are trademarks of RAS. AMS, PlantWeb and the PlantWeb logo are marks of Emerson Electric Co. The Emerson logo is a trademark and service mark of the
Emerson Electric Co. All other trademarks are property of their respective owners.

The contents of this publication are presented for informational purposes only. While every effort has been made to ensure informational accuracy, they are not to be
construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. RAS reserves the right to
modify or improve the designs or specifications of such products at any time without notice. All sales are governed by RAS’ terms and conditions which are available
upon request.

RAS does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any RAS product
remains solely with the purchaser and end-user.

Engineered and supported by:

Remote Automation Solutions,

Bristol Babcock Ltd. Blackpole Road, Worcester, WR3 8YB, UK

Reg office: 2nd Floor, Accurist House, 44 Baker Street, London, W1U 7AL

Registered in England and Wales, Reg No. 2580226

VAT Reg No. GB 880 9839 67

Allen-Bradley RDI

Emerson Process Management
Remote Automation Solutions

1100 Buckingham St
Watertown, CT 06795
T 1 [phone]
F 1 [phone]
www.EmersonProcess.com/Remote
[e-mail]

© 2007 Remote Automation Solutions, division of Emerson Process Management. All rights reserved.

Emerson Process Management
Remote Automation Solutions

Blackpole Road
Worcester, WR3 8YB
T 44 (0) 1905 856848
F 44 (0) 1905 856930
www.EmersonProcess.com/Remote
[e-mail]
