Page 1
How to get a great shave
from your Remington
®
MicroScreen®3 Shaver
Thank you for buying this premium
shaver from Remington®.
Inside you'll find tips on using and
caring for your shaver to get the
best shave possible.
®
INSTRUCTIONS
When using an electric shaver, basic precautions
should always be observed, including the following.
Read all instructions before using this shaver.
DANGER
To reduce the risk of electric shock:
IMPORTANT SAFETY
■ Do not reach for a
water. Unplug immediately.
■ Do not use while bathing or in a shower.
■ Do not place or store
be pulled into a tub or sink. Do not place in or
drop into water or other liquid.
■ Except when charging, always unplug this
shaver
from the electrical outlet immediately
after using.
■ Unplug this
WARNING
shaver
shaver
before cleaning.
that has fallen into
shaver
where it can fall or
■ Use this
described in this manual. Do not use attachments not recommended by the manufacturer.
■ Keep the cord away from heated surfaces.
■ Never operate this shaver if it has a damaged
cord or if it is not working properly, if it has
been dropped or damaged, or dropped into
water. Return the
center for examination and repair.
■ Never drop or insert any object into any
opening.
■ Do not use outdoors or operate where aerosol
(spray) products are being used or where
oxygen is being administered.
■ Do not use this
ken cutter or head, as facial injury may occur.
■ Always attach plug to
To disconnect, turn all controls to “Off,” then
remove plug from outlet, then detach power
cord from the
■ Always store your shaver and cord in a
moisture-free area. Make sure your cord is
disconnected from the shaver.
■ “Household Use Only”.
shaver
only for its intended use as
shaver
to a service
shaver
with a damaged or bro-
shaver
shaver
for storage.
, then to outlet.
To reduce the risk of burns, fire,electric shock, or
injury to persons:
■ A
shaver
should never be left unattended when
plugged in, except when charging your
rechargeable shaver.
■ Close supervision is necessary when this
shaver
is used by, on, or near children
or invalids.
SAVE THESE
INSTRUCTIONS
Page 2
Getting a Close, Comfortable Shave
Congratulations on your purchase of a premium
R e m i n g t o n®M i c r o S c r e e n®3 Shaver. Yo u r
R e m i n g t o n®M i c r o S c r e e n®3 Shaver is a wise
investment for men who are concerned with looking well-groomed. It will give you years and years
of close, comfortable shaves. As with every shaver,
your shave will improve over time. So allow about
three weeks to develop an effective shaving style
and for your beard to adjust to the new shaver. T h e
adaptation period may take a little longer if your
skin is sensitive, if you are switching from a diff e rent way of shaving, or if you alternate between
shaving methods.
When you first removed your M i c r o S c r e e n®3
Shaver from its box, you may have noticed what
appear to be small particles of white or gray powder on the MicroScreen or in or around the cutter
assembly. The particles are from a coating of a
special lubricant applied to the new foil and cutters to smooth breaking in your new shaver.They
will disappear with use.
The Best Technique
It’s simple to get a great shave out of your new
shaver. Your M i c r o S c r e e n®3 Shaver is designed
to do all the work. The first foil sets up the beard
so that more hairs enter the cutting chamber of
the second foil where they are cut just below the
level of the skin. The third foil helps give you an
extra-close shave. Here are a few tips for getting
the closest shave possible:
Always use a clean, dry shaver.
Wait at least 15 minutes after rising
1 2
9 3
to allow the puffiness that most
men experience upon waking to
6
disappear.
Make sure your face is clean and dry before
starting.
Hold the shaver so all three foils touch your face
t o g e t h e r. This allows the shaver to work the way
it was designed for the closest shave and minimum foil wear. Avoid holding the shaver at an
angle so only one foil touches the skin. This will
d i s t o rt the foil and may cause some skin irr i t a t i o n .
Use short, circular strokes.
Use your free hand to stretch your skin. This
encourages your whiskers to stand out, making it
easier for them to enter the cutting mechanism.
Never press hard. Pressing only flattens your
whiskers, which makes it harder for them to
enter the cutting mechanism. It will also wear
out the foils more quickly.
Shaving Longer Hairs
Your Remington®MicroScreen®3 Shaver is
equipped with a special push-up trimmer that
allows you to shave stubborn long hairs on facial
and neck areas or trim a beard or mustache
quickly and easily. Just push the trimmer button
upward until the trimmer locks into position.
Stroke the hairs being trimmed lightly. To extend
battery life, turn off the trimmer while you are
shaving.
For a Better Shave...
To help maximize your shaver’s performance, consider using
the Remington®Pre-Shave Powder Stick (SP-5). Just rub it
over your beard. It absorbs moisture and facial oils, helping
set up the hairs so they enter the cutting chamber more easily.
It makes shaving quicker and more comfortable.
Cleaning Your Shaver
TO ASSURE SMOOTH, EFFICIENT PERFORMANCE, IT
IS IMPORTANT TO CLEAN YOUR SHAVER.
your Remington®MicroScreen®3 Shaver is easy.
■ Remove the head assembly
by holding onto the sides of the
head assembly at the arro w s
and gently lifting the assembly
away from the shaver.
■ Tap the base of the head
assembly lightly on a flat surface. This should dislodge most
of the hairs trapped within it. To
g u a rd against inadvertent damage, do not remove the foil
a s s e m b l y, except to replace it.
■ Next, clean the cutter
assembly while it is still on the
s h a v e r. Hold the shaver and
cutter assembly as shown,
and, using shorter bristles on
the brush supplied, lightly bru s h
and blow the hair clippings fro m
between the blades.
Ti p :To help reduce wear and tear, spray the foils and
head assembly with Remington®Spray Shaver- S a v e r
Lubricant after every shave. This helps remove hairs
while keeping your shaver operating smoothly.
Cleaning
®
Trimmer Care
The trimmer on your
Shaver is easy to maintain.
■ When you clean your shaver, just brush off any
clippings that may accumulate around the trimmer
Assembly.
Using the longer bristles on the brush supplied will
enable you to get into the area between the trimmer and the shaver.
R e m i n g t o n® MicroScreen®3
Page 3
■ Every six months, lubricate the trimmer
teeth by applying a drop of light machine oil
one-third and two-thirds of the way along
the blade. Using your finger tip, spread the
oil along the teeth, and run the trimmer for
a few seconds.
Replacing Foils and Cutters
Because they are subject to daily use, the cutters and foils of
your
R e m i n g t o n
re q u i re replacement to maintain a close, comfortable shave.
Depending on your shaving technique and habits, the foils will
usually last six months; the cutters, one year. Some signs that
your foils and cutters need replacing are :
■ Irritation. As foils get worn, you may notice your skin feeling
more sensitive after a shave, particularly when you apply aftershave.
■ Pulling. As cutters wear, your shave may not feel as close,
and you may feel your shaver is pulling at your whiskers.
■ Wear-through. You may notice that the cutters have worn
through the foil.
To prevent inadvertent damage to the Foils and Cutter
Assembly, do not attempt to remove them unless you
are replacing them. To remove the old foil and cutters follow
the instructions that come with the foil and cutter replacement
package. It's always a good idea to replace the foils when you
replace the Cutter Assembly.
®
MicroScreen®3 Shaver will wear and eventually
To Replace a Cutter
Assembly That is Removed
Unintentionally:
■ Hold the assembly in the middle
of the "T."
■ Gently place the forked legs into
the opening at the top of the oscilla-
■ Do not push downward on the ends of the cutters, as you
may bend the cutter, reducing its ability to operate smoothly.
■ Do not remove cutters from the plastic pieces to which they
are attached, as you may damage the assembly.
tor tips.
Removing the Headguard
Before operating your
MicroScreen
®
3 Shaver, remove the headguard,
which protects the foils and cutter
assembly. It is important to remove
the headguard correctly to avoid
damaging the clips that hold it
firmly to the shaver.
■ Press lightly on the top of
the headguard.
■ Lift the lower rear edge.
■ Pull the headguard away from the shaver.
Cordless Operation
The TA-3070/4570/5570 shavers are designed for
cordless operation and can be recharged easily. For
cordless operation, just press the locking bar in the
center of the On/Off button and push the button
toward the head of the shaver.
Charging
Prior to using your shaver for the first time, put it
on charge for 24 hours. To charge your shaver:
■
Slide the On/Off button to the “Off” position.
■
Connect the cord to the shaver and then to the
electric outlet. The charging indicator light will glow
green, indicating your shaver is charging.
■
The TA-4570 charging indicator will begin to
flash slowly as the shaver reaches full charge.
■
Your shaver cannot be overc h a rged, so you can
leave it plugged in and charging between shaves.
■
Use only the cord supplied with shaver. The TA3070 is designed for cordless operation only. Plugging in the cord will not provide the power to shave.
The TA-4570/5570 on the other hand, comes with a
special feature that allows you to shave while your
shaver is being recharged. Just follow the steps
above to plug in the cord. Turn on the shaver by
pressing on the locking bar and sliding the On/Off
button upward. Your shaver will not recharge while
you are shaving, so after shaving, leave it plugged in
so it can be recharged.
■
The TA-4570/5570 will provide a week’s worth of
shaving after a one hour charge or a single shave after
five minutes of charging.
Charging: GREEN LED appears when shaver is plugged in and
charging.
Cordless: When the shaver is operating from the battery in a fully charged
state, the LED will appear GREEN. The LED will gradually change to
AMBER as the battery is depleted. When approximately two shaves
remain, the LED will change from AMBER to RED.
Troubleshooting
■
If your TA-4570/5570 shaver battery is completely discharged or the
s h a ver has not been used for an extended period of time, the shaver
may not start when operated using the cord. If this condition occurs,
c h a rge the shaver for approximately five minutes before shaving.
■
Your TA-4570/5570 cord / c o rdless shaver should not be used
strictly as a cord-operated shaver, as continued cord only use will
result in reduction of battery life.
■
In order to pre s e rve the life of the batteries, they should be fully
d i s c h a rged every six months and then fully charged for 24 hours.
Dual Voltage
You can take your Micro S c re e n®3 shaver with you when you travel
just about anywhere in the world. your Micro S c re e n®3 shaver
f e a t u res worldwide automatic dual voltage conversion providing AC
c u rrent between 100-240 volts, 50-60 Hz. Just plug it in to the local
outlet (you may need an adapter plug) and use as usual. Your shaver
will convert automatically to the local current re q u i re m e n t s .
The following procedures should
be followed for battery removal:
■ Make sure your shaver is unplugged from
any outlets,so you don't risk an electrical
shock.
■ Remove the head assembly by gently lifting
the assembly away from the shaver.
■ Using a small Phillips head screwdriver, remove the four screws
from the upper and lower back of the shaver.
■ Pull or gently pry the shaver halves apart,exposing the battery.
■ Lift the rubber Side Panels from their cradles and put
them aside.
■ Hold each battery in place and very carefully slide the clips
from the terminals on each battery.
■ Lift or pry the battery out of the shaver.
CAUTION:THESE NICKEL-CADMIUM BATTERIES MUST BE RECYCLED OR DISPOSED IN ACCORDANCE WITH STATE AND LOCAL
REGULATIONS.Do not burn or mutilate,as they may burst or
release toxic materials.Do not short-circuit,as it may cause burns.
Page 4
Battery Removal
The EPA certified RBRC®Battery Recycling Seal on the nickel-cadmium
(Ni-Cd) battery indicates Remington is voluntarily participating in an
industry program to collect and recycle these batteries at the end of their
useful life, when taken out of service in the United States or Canada. The
RBRC®program provides a convenient alternative to placing used NiCd batteries into the trash or the municipal waste stream, which may be
illegal in your area. Please call 1-800-8-BATTERY™for information on
Ni-Cd battery recycling and disposal bans/restriction in your area.
Remington involvement in this program is part of our commitment to
preserving our environment and conserving our natural resources.”
Remington MicroScreen®3 Models
Which model is yours?
TA-3070
TA-4570
TA-5570
Cordless, rechargeable operation with
charging indicator light. Dual voltage
105-130 volts, AC 60 Hz, 105-240
volts, AC 50 Hz.
Cord and cordless, rechargeable
operation with charging indicator
light and quick 5 minute and 1-hour
charging. Dual voltage 100-240 volts,
AC 50-60 Hz.
Cord and cordless, rechargeable
operation with ColorView™Power
indicator. Quick 5 minute and onehour charging features. Dual voltage
100-240 volts, AC 50-60 Hz.
Remington®Money-Back Offer
You have just bought one of the finest
shavers available today. If for any reason
within 30 days from when you purchased
your Remington®MicroScreen®3 Shaver,
you are not satisfied with your shaver and
would like a refund, just return your
shaver, together with the sales receipt,
to the retailer from whom you purchased
it. Remington will reimburse all retailers
who accept shavers within 30 days of
purchase. If you have any questions
regarding this money-back guarantee,
please call 1-800-736-4648.
Full One-Year Warranty
Remington warrants that your product,except as noted below,i s ,o n
d ate of purchase,free from defect in material and workmanship.
Remington will correct any such defect without charge if you return
the complete product either in person or by mail,p o s t age paid,to a
Remington Company - owned Service Center or Authorized Serv i c e
Dealer within one year after date of purchase.
Do not return the product to the retailer from whom the product
was purchased.
This warranty does not cover damage by accident,m i s u s e , abuse or
by affixing an unauthorized accessory or alteration to the product,o r
by connection of the product to any but the specific current and voltage indicated in an accompanying instruction booklet, or by any
other conditions beyond our control.REMINGTON SHALL NOT BE
RESPONSIBLE FOR ANY INCIDENTA L ,SPECIAL OR CONSEQUENTIAL
D A M A G E S .
IN A D D I T I O N ,THIS WARRANTY DOES NOT COVER THE FLEXIBLE
SCREEN A S S E M B LY ON OUR FOIL TYPE SHAV E R S .
ALL IMPLIED WARRANTIES INCLUDING BUT NOT LIMITED TO IMPLIED
WARRANTIES OF FITNESS AND MERCHANTA B I L I T Y ,ARE LIMITED IN
D U R ATION TO ONE YEAR FROM DATE OF ORIGINAL PURCHASE.
This warranty gives you specific legal rights,and you may also hav e
other rights that vary from state to stat e . Some states do not allow
the exclusion limitation of incidental or consequential damages or
l i m i t ations on how long an implied warranty lasts,so that the above
l i m i t ations and exclusions may not apply to you.
No responsibility,o b l i g at i o n , or liability is assumed for the installat i o n
or maintenance of this product.
Page 5
Warranty service must be performed by a Remington Company owned Service Center or Authorized Service Dealer and damage or
loss of any kind resulting from servicing by any other person is not
covered under warranty. E n closed is a listing of Company - ow n e d
S e rvice Centers. Authorized Service Center Dealers may be found
in the yellow pages of your directory. If you wish,you may mail
the product,p o s t p a i d , to Remington Products Company L.L.C.,6 0
Main Street,B r i d g e p o r t , CT 06604 A t t e n t i o n :S e rvice Department.
U.S. Warranty Service
In the United States, service is pro v i d e d
by our Company-owned Service Centers
and over 300 Authorized Service Dealers.
The addresses of our Company-owned
S e rvice Centers are enclosed. For the
a d d ress of your nearest Authorized Serv i c e
D e a l e r, please consult the Yellow Pages
under “Shaver - Electric - Repair.” If you
wish, you may mail the product, postpaid,
to Remington Products Company L.L.C.,
60 Main Street, Bridgeport, CT 06604,
Attention: Service Depart m e n t .
International Warranty Service
S e rvice under the Remington warranty can
be obtained outside the United States by
Remington-Authorized Distributors and
S e rvice Dealers. Please consult your local
telephone dire c t o ry for the nearest location.
For questions or comments,please write:
Remington Products Company, L . L . C .
P. O . Box 1536,
H o r s h a m ,PA 19044-6536
A t t e n t i o n :Consumer A f f a i r s
Questions or Comments: Please call 1-800-736-4648.
Visit us at http:\\www. r e m i n g t o n - p r o d u c t s . c o m
PR O DU CTS COM P A N Y, L .L .C.
60 Main Street Bridgeport,CT 06604
R e m i n g t o n ,MicroScreen and
S h av e r S aver are trademarks of
Remington Corporat i o n ,L . L . C .
© 1998 RPC, L . L . C . Rev 8/98
Part No.1 2 6 4 0
Loading...
