01
The TSG series offers excellent sonic character, simple operation
and streamlined appearance. Ideal for courtrooms, boardrooms,
government chambers, schools and churches.
Integral mute switch on base with three modes (push-to-mute,
toggle, push-to-talk) and LED indicator light.
Small-diameter rigid-pipe design with pivoting ball-in-socket.
Sturdy metal desk stand base houses with 3-pin XLRM-type
output connector.
Features:
05
Polar pattern
(Picture 1)
02
Element
Polar Pattern
Frequency Response
Sensitivity
Impedance
Maximum Input Sound Level
Dynamic Range(Typical)
S/N Ratio
Switch
Power Supply
Weight
Microphone Length
Output connector
Accessories Furnished Windscreen
Color Black / Silver
03
Mc1 cable series : singl e core shielding un balan ced cab le
Type: XLRM+6.3m etal co nnector Length av ailab le
MC1-03 3M/MC1- 05 5M
MC1-10 10M/MC1 -20 20M
Technical Specifications:
Fixed-charge back plate, permanently
polarized condensers
Cardioid
30Hz~18KHz
-35 dB (17.7mV) 1Pa at 1V
25 0Ω
133 dB SPL, 1KHz at 1% T.H.D
109 dB, 1 kHz at Max SPL
70dB,1kHz at 1Pa
(on circuit board) Mute/Toggle/Talk
TSG-100: AAx2 /
TSG-200: AAx2 / 11-52V DC, 4 mA typical
860g
340mm,420mm(standard),480mm
Integral 3-pin XLRM-type
Optional accessories
06
07
Frequency
Microphone picture
Wor k indic ation l ight
(Picture 2)
Cap sule
MC2 cable series : singl e core shielding ba lance d cable
Type: XLRM+XLRF L ength a vailable
MC2-03 3M/MC2- 05 5M
MC2-10 10M/MC2 -20 20M
P-48V1S: Singl e Chann el 48V Phantom Powe r Suppl y
(With switch to co ntrol e xtern al connect ed micr ophon e)
04
Condenser micr ophon e now is not over sensi tive fo r
the environmen t. Howe ver, it may be also eas ily
damaged in extre mely hi gh or low temperatu re.
Output electri c level m ay be gradually or pe rmane ntly
attenuated whe n micro phone is exposed in t he high
temperature. M icrop hone should not be ex posed i n
the sunshine pla ce or pla ces where the tempe ratur e
is over 43 degree or w ith hig h dampness.
Attention
(Picture 3)
Mut e Switc h
The way of setup battery
(Picture4)
Connection: co nnect t he
microphone out put jac k
to other equipme nt like
amplifier or mix er.
(Picture 5)
