Operation Instructions
LABORATORY EQUIPMENT
IN
IN
STAINLESS STEEL
POLIRET
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: +49(0)5472-9432-0 | Fax: +49(0)5472-9432-40
www.reitel.com | info@reitel.com
II
Dear Customer!
The POLIRET is a powerful stainless steel polishing unit with two spindles. The comfortable
housing width enables simultaneous and independent working of both spindles. Continuous
speed control between 800 and 4.500 t./min, perfectly adapting to requirements. The
brushless motors are powerful, maintenance free and extremely durable. The POLIRET
offers economic and precise grinding, polishing, cleaning and brushing of metal and plastic
material. The integrated, silent suction absorbs dust directly at the spindle. The textile filter
bags are washable and reusable. Closing one ventilation flap maximum suction power is
achieved on the other side. Since the exhaust air outlet is located on top of the housing the
device can be placed directly at a wall without losing suction power. Connection to an
external suction is not provided, however it’s available on request.
Prior to installation of the device operating instructions and especially the safety instructions
must be read and followed by all personnel who use this device.
After having unpacked the device, please check carefully whether transportation damages of
any kind have occurred. If that is the case, the carrier or manufacturer must be notified within
3 days. The company will not be responsible for any damages found after that.
These operating instructions must be read and followed by all personnel who use this device.
To ensure quick access we recommend to keep it at a safe place near the device. In case of
loss it can be ordered at a nominal fee from the manufacturer.
III
INDEX
TECHNICAL DESCRIPTION ......................................................................................... 4
BASIC EQUIPMENT ....................................................................................................... 4
SPECIAL ACCESSORIES ................................................................................................ 4
DEVICE COMPONENTS ................................................................................................. 5
TECHNICAL DATA ......................................................................................................... 7
SAFETY NOTES ................................................................................................ ........... 8
GENERAL SAFETY NOTES ............................................................................................ 8
SPECIFIC SAFETY INSTRUCTIONS ................................................................................. 9
INSTALLATION ...........................................................................................................10
INSTALLATION .............................................................................................................10
TOOL ASSEMBLY ........................................................................................................10
OPERATION ................................................................................................................10
CHRONOLOGICAL RUN OF OPERATION ..........................................................................10
EMERGENCY STOP BUTTON .........................................................................................11
FILTER REPLACEMENT ................................................................................................11
LAMP REPLACEMENT ..................................................................................................11
TROUBLESHOOTING .................................................................................................12
MAINTENANCE ...........................................................................................................13
WARRANTY.................................................................................................................14
DISPOSAL REGULATIONS .......................................................................................17
SPARE PARTS LIST ...................................................................................................18
EC CONFORMITY DECLARATION .............................................................................19
4
Technical Description
Basic Equipment
• POLIRET Polishing unit
• Right and left polishing spindle
• 2 filter bags
Special Accessories
• Order-No.: 24800000 Vario-lifting table
• Order-No.: 22603000 Workholding fixture for polishing and grinding device
incl. drill chuck
• Order-No.: 22702000 Filter bag
• Order-No.: 22604000 Speed-Display
5
Device Components
1 Left locking screw
2 Left ventilation flap open/shut
3 Speed control polishing motor
4 Left safety panel
5 Left polishing spindle (with ring)
6 Switch polishing motor
7 Right locking screw
8 Right ventilation flap
9 Emergency stop button
10 Suction switch
11 Power switch
12 Right safety panel
13 Right polishing spindle (without ring)
14 Cover
15 Device’s fuse
16 Main plug
17 Lamp
18 Motor shaft sealings
19 Polishing trough
20 Filter bags
21 Holding rings
22 Filter neck
23 Air sheet
6
Fig.: Device view
Fig.: Side view
1
2
3
4
12 7 6
5
8
11
10
9
13
19
17
18
14
15
16
Fig.: Air sheet
Fig.: Interior of the device
20
23
21
22
1
2
7
Technical Data
Line voltage
230 V/50–60 Hz
Power consumption motor
550 W
Power consumption suction
400 W
Height/width/depth
500+100/730/560 mm
Weight
60 kg
Variable speed
270–4.500 rpm
Suction
800 m³/h
Filter
Class M (<0,1% residual dust)
Sound level
≤ 70 dB(A)
Housing
Stainless steel
Order-No.:
10328000
Made in Germany (Subject to modifications)
8
Safety Notes
General Safety Notes
• All equipment undergoes final inspection and testing before leaving our factory. However,
if equipment is damaged during shipping or through any other circumstances, it must not
be used in service. Please check the device regularly for damages. Damaged parts
should be replaced immediately.
• All power/air/water/gas sources should be rated for the demands of the device as listed in
the technical data sheets. Maximum ratings must not be exceeded. All VDE (Verein
Deutscher Elektro-Ingenieure) standards should be followed. Equipment should be
grounded according to standards.
• Adherence to valid regulations regarding necessary checks (e.g. according to Accident
Prevention & Insurance or electrical equipment) is exclusively taken over by the
buyer/user of this product.
• This device has been designated to be used only for its intended purpose. All other
applications must be prohibited for safety reasons as otherwise the manufacturer’s
warranty expires.
• The device should be set-up in a clean, well-ventilated room, if necessary under a hood.
• Supporting surfaces should be straight, flat and adequately stable.
• Don’t place anything on top of the machine.
• To avoid injury, appropriate protection should be worn (e.g. gloves, safety glasses, safety
shoes, hearing protection etc.)
• If the machine is defective or working improperly it must be taken out of service. In case
of further use of the machine the owner will be held responsible for any consequential
damage.
• To prevent accidents from water, fire or explosion, all power/air/water/gas sources should
be turned off after working hours and during breaks, and secured against unauthorized
access.
• When carrying out maintenance works or repairs or when opening the device always turn
off the main power switch and unplug the whole unit.
• Repairs should be carried out only by the manufacturer or by qualified and certified
personnel appointed according to chapter 7 – warranty.
• In case of leaking water out of housing or tank shut down device and call service.
9
Specific Safety Instructions
• Tools and the lamp may only be changed when the spindle stands still and the whole unit
is unplugged.
• Fold the protective panel down and wear protective glasses.
• Only use appropriate and no unbalanced tools. Make sure all tools are fastened securely.
• Switch suction on.
• Never touch the running machine.
• Always respect the instructions of the polishing and grinding tool’s manufacturer (e.g.
max. speed, appropriate material to be treated).
• Use only appropriate material for polishing. Always resepect the instructions of the
polishing and grinding tool’s manufacturer, especially regarding health protection.
• Always wear clothing which is tight at the forearms and hands. Avoid loose hair and
jewels which could get into the spindle or tools.
• Use only clean or disinfected material with the machine.
• In case of danger press the emergency stop switch (9). Turning to the right, the
emergency stop switch can be unlocked.
• Hold the object to be polished tight. Danger of injury from flying particles and danger of
damage to workpiece.
Attention:
• Wait for at least 2 min. before unplugging the mains plug for cutting off the device from
the domestic supply line in order to unload the condensers.
• The tool must be securely fastened to the spindle.
Danger of injury!
• Operation at too high speed – risk of burns!
• Always keep the housing dry and clean.
10
Installation
The equipment delivered is ready for immediate use. The sealed plug can be connected
directly to the mains supply 230 V / 16 A. For installation please refer to chapter 2.
Installation
For exhaust air and change of filters save a minimum space of 20 cm above the device.
Connect the power supply.
Tool Assembly
1. Slide the polishing spindles (5) and (13) over the axle shaft, fixing them tightly with the
Allen head screw.
2. Fix the required polishing tool on the polishing spindles (5) and (13) check for correct
fitting.
Right side: right-hand thread
Left side: left-hand thread.
3. Removing the Allen head screw the polishing spindles (5) und (13) can be removed from
the axle shaft. If necessary use a removing tool.
Operation
Chronological run of operation
1. Turn off motor switch (6). Press power switch on (11).
2. Fix the polishing tool. If required fill polishing troughs (19) with polishing paste/pumice or
apply paste/pumice to polishing tools.
3. Activate polishing motor with switch (6). Speed is adjustable with the speed control (3).
4. Switch the suction on with the suction switch (10). Closing one ventilation flap (2) or (8)
suction power on the other side is increased.
5. Hold the object to be polished tight, slightly pressing it against the rotating polishing tool.
6. When work is finished, use switch (6) and the power switch (11) to switch off the
polishing motor.
11
Emergency stop button
1. After pressing the emergency stop button (9), the device will enter the stop mode.
2. Turn off the main switch (11) and the switch of the polishing motor (6).
3. Turn the emergency stopt button to the right to unlock it.
4. After approx. 8 sec. Waiting time, the main switch can be switched on again and the
polishing motor can be switched on.
Filter Replacement
1. Unscrew the fixing screws (1) and (7) on top of the device and remove the lid (14).
2. Remove the old filter bags (20) by detaching the holding rings (21) from the filter inlet
fitting (22).
3. Empty the filter bag, if necessary wash it (machine washing 60 degr.C)
4. Insert the new filter bag on the filter inlet fitting, close the holding ring and reinsert the lid.
Lamp Replacement
1. Switch off power switch (11) and pull the plug.
2. Remove plexiglas cover.
3. Pull out the lamp.
4. Insert the new lamp and check for tight fit.
5. Then refasten the plexiglas cover.
12
Troubleshooting
Device doesn’t start.
a. Emergency stop button was pressed.
Unlock it by turning the button to the
right. Turn off machine and motor
switch and wait 8 sec. to restart.
b. wait approx. 2 sec. between main
switch and motor switch
c. Power failure →check the main fuse in
the building. Switch off and on polishing
motor (6).
d. Check fuse of the building (15).
Overload relay has tripped.
Motor becomes overloaded, caused by
continuous use and/or too high contact
pressure →
Turn off power switch, ensure that the
spindle is free running and turn power
switch on again after a few minutes of
cooling.
Insufficient suction power.
a. Clean filter bag(20) or replace it. The
filter is machine washable at 60 degr.
C. Please respect the polishing paste
manufacturer’s instructions.
b. Lid (14) is untight and has to be fixed.
Motor power is too low
a. Polishing brush is too large (max.
diameter approx. 150 mm).
b. Contact pressure is too high.
Uneven run of the machine.
a. Unbalanced disc or polishing spindle.
b. Remove spindle with Allen head key
and replace it.
c. Replace tool (pay attention to thread).
13
Maintenance
• Please check the device regularly for damages. Pay attention to visible damages at the
housing or cable.
• Regularly clean dirty tools and polishing troughs (19).
• Regluarly replace worn or worn tools.
• Regularly replace or wash the filter bag (20) (see chapter 4.2 filter replacement).
Note
Clean and protect your device at regular intervals with the REITEL stainless steel care
spray (Order-No.: 90405000) to remove lime, plaster and dust as well as other
contaminants from the surface of the equipment and to prevent corrosion. The spray
creates a lasting, water repellent protective film which helps keep the equipment clean.
14
Warranty
We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven
date of purchase. This warranty covers all defects traceable to materials, design or
workmanship. The following warranty regulations are applicable:
Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees
at its sole option, to perform repair or replace this product at no charge covering all defects
traceable to materials, design or workmanship. Warranty only applies to appropriate use and
regular maintenance of this product according to the operating instructions. Claims under
warranty are restricted to complementary performance. Additional claims, especially claims
for indemnifications, are not covered by this warranty.
1.
Warranty claims have to be addressed to the distributor the product was purchased from or
directly to our service department.
Contact:
REITEL Feinwerktechnik GmbH
Senfdamm 20
49152 Bad Essen
Germany
Phone: +49(0)5472-9432-32 (Service Department)
Phone: +49(0)5472-9432-0 (Reception)
Fax-No: +49(0)5472-9432-40
2.
In case of warranty claim application the sales receipt or your purchase invoice showing the
date of purchase of the product and the serial number must be furnished. Securely pack and
ship the device, freight charges prepaid, at your own risk to us, along with a report describing
the defect. We reserve the right to decline warranty if this information has been removed or
modified after purchase of the product or if they are not included in case of warranty claims.
3.
Warranty repairs have to performed by REITEL Feinwerktechnik GmbH or by authorised
distributors. Repairs performed by non-authorised companies will void the claim for refund
since damages to the product resulting hereof are not covered by warranty.
4.
15
If the unit sent in for repair or replacement is still under the original warranty then warranty is
to the end of the original 1 year warranty.
5.
If the unit is destined to be operated in another country than originally intended and
manufactured for, modifications to the product might be necessary to comply to special
technical and /or safety standards of that specific country. Such modifications are no defects
traceable to materials, design or workmanship. and are therefore expressly excluded from
warranty claims.
Modification costs or damages arising from operation of the product under deviating
conditions are not covered by warranty.
6.
Exclusions from warranty:
Service and maintenance work as well as repair and replacement of consumables according
to our consumables‘ list
Transportation cost of the machine or installation and dismounting expenses incurred
Damages due to use of the product other than for its intended purpose
Damages due to faulty installation or insufficient maintenance of the product (e.g.
decalcification)
Damages due to natural disaster e.g. lightning, water, fire, act of nature beyond control, war,
inadequate line voltage, insufficient ventilation, no decalcification, insufficient care and
cleaning or non-adherence to operation and maintenance instructions according to the
accompanying operation guide.
Damage due to use of the product other than in accordance with the instructions provided by
REITEL Feinwerktechnik GmH;
The warranty does not cover the cost of removal and replacement of parts and accessories,
unless supplied as original equipment by REITEL Feinwerktechnik GmbH
All kind of damages occurred not directly at the device as well as consequential damages
(e.g. damages to furniture due to a lack of water, downtime of the machine, material, lost
working hours, wages and other consequential damages).
This warranty shall be rendered null and void if:
the product has been subject to any modification, repair or replacement other than as
authorised by REITEL Feinwerktechnik GmbH
16
the product is continued to be operated despite a functional defect
7.
The warranty is device specific and may be claimed, within the warranty period, by any
person who has legally acquired the device.
8.
Consumables are excluded from warranty. Spare parts are subject to a warranty coverage of
6 months against all defects traceable to materials, design or workmanship according to
these warranty regulations.
9.
Legal default claims on the part of the purchaser remain unaffected by this warranty.
10.
We reserve the right to charge a fee if repair of the device is rejected and the device is
destined to be sent back unrepaired.
11.
Please note:
Upon repair or replacement of this unit, personal data and settings might get lost or
damaged. We don’t accept liability for all kind of data loss. The customer is advised to
backup essential programs and data before sending for service.
12.
This warranty shall be interpreted in accordance with German law to the exclusion of UN
sales law. Place of jurisdiction is our business location.
13.
If any provisions of this warranty are judged to be illegal or unenforceable, the continuation in
full force and effect of the remaining provisions will not be prejudiced. The provisions of this
warranty judged to be illegal or unenforceable shall be construed so as to give effect to the
intent manifested by the provision held invalid, illegal or unenforceable and to give effect to
section 13 hereof.
14.
Should you need to borrow a device while your device is being repaired, please contact
Messrs. REITEL or your distributor. These loans are a service for which availability cannot
necessarily be guaranteed. After the warranty period, a fee may be charged for loan
equipment as well as for shipping and packaging.
17
Disposal Regulations
According to valid laws our devices are properly disposed of according to B2B –
regulations for proper disposal. Pls. contact your local dealer for additional
information.
18
Spare Parts List
Best.-Nr.
Ref.
Poliret + Poliret Twin 27
Ersatzteilliste / Spare parts list - 03/2019
Stck/ME
Qty.
ME
Unit
E6158800
Beleuchtung Scheibe, Acryl 185*50*4dick
Acrylic screen for lamp
1
Stck
piece
E6134910
Dichtung f.Polierspindel, Leder
1
Stck
piece
22702000
Filterbeutel mit Reissverschluß (1 Pack= 2 Stück )
Filter bag with zipper (2 pcs.)
1
Pack
pack
E6152200
Gummieinlage für Trog (1Satz=2 Stück)
Rubber pad for trough (1 set)
1
Satz
set
E6152100
Kantenschutzprofil
Edge protection profile
1
m
22603000
Polier- und Schleifaufnahme m.Bohrfutter
1
Stck
piece
E61453-E
Polierspindel POLIRET / E aktuell, zylindrisch, bitte Gerätenummer
angeben), li oder re
1
Stck
piece
E6145300
Polierspindel POLIRET TWIN, zylindrisch
Polishing spindle POLIRET TWIN, cylindric, li oder re
1
Stck
piece
E6152700
Prallschutz ( 2 Stück/Satz )
Baffle absorber 2 pcs./pack
1
Satz
set
E6064800
Schalter mit Lampe grün
Switch with green lamp
1
Stck
piece
E6156000
Schutzglas mit Haltebügelsatz
Support for protecting glass, incl. glass
1
Stck
piece
E6153020
Sieb Kunststoff, für Absaugkanal
Plastic sieve for suction channel
1
Stck
piece
E6150500
Trog für POLIRET
Trough for POLIRET
1
Stck
piece
19
EC Conformity Declaration
We manufacture in compliance with Quality Management ISO 9001:2015 incorporating
established standards.
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: +49(0)5472-9432-0 | Fax: +49(0)5472-9432-40
www.reitel.com | info@reitel.com
062019
Loading...
