6 - Installation and Commissioning
Installation must meet valid rules and may be done only by qualified staff. The tank shall be placed on the
floor, as close to the heat source as possible.
Warning: Defects caused by improper installation, use or
handling are not covered by warranty.
6.1 - Connection to heat sources
Connect heating circuits to the inlet and outlet of the heating coil. The heat source for the tank - an enameled
coil - connect with G 5/4” couplings.
6.2 - Connection to a solar system
The tank can be used with a solar system. In such a case, the inlet for hot heat-carrying liquid coming from the
solar system shall be connected to the G 5/4” upper sleeve and the lower outlet connects to the return piping
to the solar system. Insulate all the piping between the tank and the solar system.
6.3 - Heating rod installation
The G 6/4“ side sleeve is designed to accommodate an electric heating rod (RBC 1000HP tank has no sleeve
for a heating rod). Heating rods of output up to 12 kW can be used (depending on the tank diameter and rod
length), connected either directly to the mains (thermostat-equipped rods), or to a heating system controller.
The installation may be done by qualified staff only.
Warning: Electric heating elements shall be protected by a safety thermostat.
6.4 - Connection to water mains
DHW piping shall be done according to valid rules. G 5/4” threaded couplers are used to connect the tank to
a cold water inlet and hot water outlet. A 6bar safety valve shall be installed at the cold water inlet. Installation
of a reducing valve to the tank inlet is recommended. If the pressure from water mains exceeds 6 bar,
a reducing valve is necessary. In order to prevent water loss, an expansion tank should be installed at the cold
water inlet as well (8 l volume for RBC 200HP, 12 l volume for RBC 300HP and 400HP, 18 l for RBC 500HP,
24 l for RBC 750HP and 35 l for RBC 1000HP).
Should the water be too hard, install a water softener before the tank. In case the water contains mechanical
impurities, install a strainer.
A suitable thermostatic mixing valve should be installed at the hot-water outlet from the tank, preventing too
hot water from entering the taps.
Install a drain valve to the lowest point of the tank.
Complete DHW piping shall be properly insulated.
6.5 - Electronic anode rod installation
A so called electronic anode rod can be used instead of the magnesium one. Its principle advantage is that
its proper function is signaled by an indication lamp while a magnesium anode rod needs to be taken out for
check. In such a case, just visual check of the indication lamp is sufficient.
Please use a G 5/4” to G ½” reducing coupler when installing an electronic anode. A space equal to the anode
length (see the table below) is needed between the tank top and ceiling to install/exchange the electronic
anode rod. In order to protect the tank properly and meet its warranty conditions, select an anode from the
table below.
Kit for RBC storage water heaters
Code Anode rod length [mm] For storage water heaters
9173 350 (200/150) RBC 200HP
9174 500 (350/150) RBC 300HP to RBC 500HP
9175 750 (550/200) RBC 750HP to RBC 1000HP
